ST60Wind说明书

W60/W80 SeriesShut Off & Divert ValvesAPPLI CATI ONWhen stopping or diverting flow in a process system, the W60 single seat valve line provides both a flexible and reliable solution. These valves are pneumatically or manually operated, and offered in a wide variety of body configurations. Available in 1” to 6” (25mm – 152mm) OD sizes.Adapters: Refer to page 27 for descriptions of W80 options.MATE R IALSProduct Wetted: ASTM 316L (UNS-S31603); (DIN-1.4404)Non-Product: ASTM 304 (UNS-S30400); (DIN-1.4301)Seat Material: T ef Flow TM (Std) See Page 3 for other available seat options.Elastomers: FKM (Std) EPDM (Opt) FFKM (Opt)Finish:< 32Ra (<0.8 µm) Other finishes available upon requestPR E S S U R E RATI N G SNote:*6” valves available in W61 Shutoff and W65 Divert only.OPTI ON S AN D ACCE S S OR I E SPR E S S U R E RATI N G SNote:For higher temperature applications than those listed, please consult the factory.*Operating conditions such as flow rate and pressure must be considered when operating near max temperaturerating.Note:3, 4 or 6 inch high pressure clamp not available.For other valve types contact factory. For all valve options see Valve Key Datasheet (DS-1204).Control T opsFEATURES AND BENEFITS• Transparent Control T op keeps all electrical components visible.• Maintainable, designed with the user in mind, making assembly and troubleshooting worry free and easy.• Waukesha Cherry-Burrell uses the industry’s most widely recognized electrical components, so access to off the shelf replacement parts is easy, ensuring quick delivery and less down time.• NEMA 4x (IP64)• Stainless Steel Control Top Option WAU K E S HA CH E R RY-B U R R E LL CONTR OL TOPCU4 & CU4plus CONTR OL TOPCONNECTOR OPTIONS• S/O Cord Grip for hard wire (std)• Quick Disconnect Pin ConnectorsINTERFACE OPTIONS • AS-i Field Bus Card• Device Net Field Bus Network CardPOSITION INDICATION • Set & Forget Switch• Inductive Proximity Switches 20-140V AC/DC, 2-Wire (Std)• Microswitches 24V DC, 110V AC • Intrinsically safe options 5-24V DCSOLENOID VALVES • 24VDC or 110V AC• Select from 0 to 3 SolenoidsFEATURES AND BENEFITS• Automated control and position monitoring for reliable processing • Reduces compressed air and electrical connections • Helps reduce external solenoid valve cabinets • Accelerates valve response time• Innovative seat lift detection is fully integrated without need for external sensor wiring to provide additional position monitoring• Reliability and long service life - robust clamp connection, reinforced stainless steel air coupling threads to avoid air leakages, and water tight seals• Ease of operation - contains manual override solenoids and adjustment screw to throttle air flow to actuator to ensure optimal opening and closing• Clarity - clear and bright indication of valve position - 5 diodes in LED panel and convenient location• Standardization - same control top used on various SPX FLOW valve lines, offers common look and controls interface • NEMA 6 (IP67) washdown rating CONNECTOR OPTIONS• S/O Cord Grip for hard wire (standard)• M12 4-pin connector (optional)INTERFACE OPTIONS • 24V DC Direct Connect • AS-i Field Bus CardSOLENOID VALVES • 24V DC or 110V AC• Select 1 solenoid or solenoid with NOT element (air/air or air assist)POSITION INDICATION OPTIONS• C U4: 2 internal feedback sensors for valve open/valve closed position detection•CU4plus: Automatic teaching of all positions with press of single button 4Air Volume Required • 4" AR = 12.7 in 3/81 cm 3• 4" AL = 14 in 3/90 cm 3• 5" AR = 21.5 in 3/138 cm 3• 5" AL = 27.1 in 3/174 cm 3• 6" AR = 36.1 in 3/223 cm 3• 6" AL = 33.1 in 3/213 cm 3Note: Normal air supply requirement: 50 PSI for 4, 5, and 6 inch, A, B and C size actuators and long stroke actuators; 75 PSI for 4, 5, and 6 inch heavy duty spring actuators. These estimates may vary depending on other factors such as air pressure, pipe line pressure and air routing through solenoid.Standard stroke length is the same for maintainable and maintenance-free actuators.STR OK E LE N GTH8681 CONTR OL TOP Actuator Options8681 Control TopsFEATURES AND BENEFITS• Contact free position sensor including (3) programmable feedback signals• Positions easily taught via intuitive push buttons or Autotune feature to ensure quick & easy set-up• Ultra-bright 360° visual LED position indication with adjustable red, yellow, & green color assignments provide clarity from all points of view and avoid confusion• Manual override and air throttle adjustable solenoids to assist start-up, maintenance, and troubleshooting • Up to IP69K washdown rating available (IP65/67 as standard) for high washdown environments • Built-in microcontroller tracks cycles and alerts operator when preventive maintenance is required • Simple and robust stainless steel adapter & chemically resistant polycarbonate head • Supplied by industry leading Burkert Fluid ControlsCONNECTOR OPTIONS• Quick Disconnect Pin Connector INTERFACE OPTIONS• AS-i Field Bus Card• DeviceNet™ Field Bus Network Card • Available on request CANOpen, IO-LinkPOSITION INDICATION• (3) programmable position sensors in control top SOLENOID VALVES• 24V DC• Manual override and air throttle adjustment • Up to (3) available in control top5All ”A” Dimension are in fully extended (open) position.*For sizing Over-Pressure valves, select a Heavy-Duty spring actuator with a holding pressure greater than the desired relief pressure. Designate with the “R” the valve model (i.e. WR61) and actuator size (i.e. 5RHAR). Refer to DS-1224 for more details on Over-Pressure Valves.“A” - D I M E N S I ON SCONTR OL TOP D I M E N S I ONAL AD D ER4AR-4" Air to RaiseMaintainableM - MicrometerH - Hand LockHLG -Hand Lock, long stroke 6YLG - Hand LockNote: Add control top dimension above to “A” dimension of selected valve and actuator size64AR3 - 4" Air to Raise, 3 position4AL3 - 4" Air to Lower, 3 position6ARY - 6" Air to Raise, extra long stroke• 4AR - 4" (101mm) Air to Raise• 4HAR³ - 4" (101mm) Air to Raise, Heavy Duty Spring• 4RHAR 4 - 4" (101mm) Air to Raise, Spring Adjustable, Heavy Duty Spring • 4ARLG - 4” (101mm) Air to Raise, Long Stroke • 4AL - 4" (101mm) Air to Lower• 4HAL³ - 4" (101mm) Air to Lower, Heavy Duty Spring• 4RHAL 4 - 4" (101mm) Air to Lower, Spring Adjustable, Heavy Duty Spring • 4ALLG - 4” (101mm) Air to Lower, Long Stroke • 4AA - 4" (101mm) Air to Air• 5AR - 5" (127mm) Air to Raise• 5HAR³ - 5" (127mm) Air to Raise, Heavy Duty Spring• 5RHAR 4 - 5" (127mm) Air to Raise, Spring Adjustable, Heavy Duty Spring • 5AL - 5" (127mm) Air to Lower• 5HAL³ - 5" (127mm) Air to Lower, Heavy Duty Spring• 5RHAL 4 - 5" (127mm) Air to Lower, Spring Adjustable, Heavy Duty Spring • 5AA - 5" (127mm) Air to Air• 6AR - 6" (152mm) Air to Raise• 6HAR³ - 6" (152mm) Air to Raise, Heavy Duty Spring • 6RHAR 4 - 6" (152mm) Air to Raise, Spring Adjustable, Heavy Duty Spring• 6ARLG - 6” (152.mm) Air to Raise, Long Stroke • 6AL - 6" (152mm) Air to Lower• 6HAL³ - 6" (152mm) Air to Lower, Heavy Duty Spring • 6RHAL 4 - 6" (152mm) Air to Lower, Spring Adjustable, Heavy Duty Spring• 6ALLG - 6" (152mm) Air to Lower, Long Stroke • 6AA - 6" (152mm) Air to Air• 6ARY² - 6" (152mm) Air to Raise, Extra Long Stroke • 6AL Y² - 6" (152mm) Air to Lower, Extra Long Stroke• A1 - 3" (74mm) Air to Raise • A2 - 3" (74mm) Air to Lower • A3 - 3" (74mm) Air to Air• B1 - 4.5" (110mm) Air to Raise • B2 - 4.5" (110mm) Air to Lower • B3 - 4.5" (110mm) Air to Air • C1 - 6.5" (165mm) Air to Raise • C2 - 6.5" (165mm) Air to Lower •C3 - 6.5" (165mm) Air to AirA1-3" (74mm) Air toRaise, Maintainance FreeActuators4ARP 4" (101 mm) Air to Raise w/positioner 4ALP 4" (101 mm) Air to Lower w/positioner 5ARP 5" (127 mm) Air to Raise w/positioner 5ALP 5" (127 mm) Air to Lower w/positioner 6ARP 6" (152 mm) Air to Raise w/positioner 6ALP6" (152 mm) Air to Lower w/positionerH Hand Lock M Micrometer7A4ALEP 4" (102 mm) Air to Lower, ElectropneumaticPositioner5ALEP 5" (127 mm) Air to Lower, ElectropneumaticPositioner6ALEP 6" (152 mm) Air to Lower, ElectropneumaticPositioner4AREP 4" (102 mm) Air to Raise, ElectropneumaticPositioner5AREP 5" (127 mm) Air to Raise, ElectropneumaticPositioner6AREP 6" (152 mm) Air to Raise, ElectropneumaticPositioner² U sed with Y-B ody valves. Consult with application engineering for use with 6" (152 mm) OD size valves.³ Use TFP metal or TR seats for heavy spring actuators.4Used with over-pressure valves, use TFP or metal seats.4AR3 4" (101 mm) Air to Raise, 3 position 4AL3 4" (101 mm) Air to Lower, 3 positionACCCBD BBCCG HCCFB ODY CON FI G U RATI ON S (1 OF 2)W61 Shut-offW63/W83 Shut-off (W68R/W88R Throttling)W61 and W63 Shut-off - One Piece BodiesCSCDTL TOP RTDTM TOP LTSCMCOPCY TBTDTSA1B1B2B3C1E1CSCDCBIVALVE D I M E N S I ONSTPS and CPS Bodies TM and CM Bodies8B ODY CON FI G U RATI ONS (2 OF 2)TTTCCTCCTTSW62/W82 DivertW65/W85 Divert (W685/W885 Throttling)VALVE D I M E N S I ON S123TTT 12345CTC 1234CTT 12345CCT 12345TCCCCCTTCTCTW64/W84 Tank Outlet (NOTE: Tank Flanges sold separately)T(W64R)C(W64R)T(W64)C(W64)9W80 valves are charted below under corresponding W60 header. Curves are based on water 70ºF (21°C).Pressure Loss Curves501001502002503003504000.00.51.01.52.02.53.03.54.04B to S CV 5353B t o SC V 2622.5B t oS C V 142 B t oS C V891.5 B t o S C V 421 B t o S C V 174 St o B C V6423 S t oBCV 2722.5 S t oB C V 1312 S t oB C V 851.5 S t o B C V 431 S t o B C V 18H e a d L o s s - F TG P M*Note: For W61 S to S curves see W62 T to T curves.M OD E L W61 & W64R100200300400024681012144B t o S CV1583 Bt o S C V 1192.5B t o SC V 842 B t o S C V 541.5 Bt o SC V 301 B t o S C V164St oB C V1743S t oBC V 1282.5St o B C V 912 St oB C V 611.5 S t o B C V 221 S t o B C V15H e a d L o s s - F TG P MM OD E L W63 & W64501001502002503003504000.00.51.01.52.02.54 Tt o T CV 643T t o T C V 3832.5T to TC V 2152 Tt oT C V 1341.5 Tt o TC V 751 T t o T C V 224 St oSCV 5373St oS C V2842.5S to S CV 1632 S t oS C V 1081.5 S to S C V581 S t o S C V 21H e a d L o s s - F TG P MM OD E L W62N OTE: Pressure drop curves shown are for estimation purposes only. Contact application engineering for specific pressure drop details.10100200300400024681012144 St o B C V2103 S t o B C V 1492.5 S t o B C V 1092 S t o B C V 761.5 S t o B C V 431 S t o B C V 174 S t oT C V 1583 S t oT CV 1192.5 S t o T C V 842 S t o T C V 541.5 S t o T C V 301 S t o T C V 16H e a d L o s s - F TG P M 0100200300400024681012144 S t oT CV 1583St oT C V1192.5St oT CV 842 S to T CV 541.5 S to T C V 301 S t oT C V 16H e a d L o s s - F TG P M 100200300400024681012144B t o SC V 2003 B t o S C V1602.5B t o SC V 1172 B t o S C V 811.5 B t o S C V361 B t o S C V 184T t o S CV 1743 T t o S C V 1282.5 Tt o SC V 912 T t o S C V 611.5 T t o S C V 221 T t o S C V 15H e a d L o s s - F TG P MM OD E L W62M OD E L W65M OD E L W62Note: Y-Body must use 6ARY/AL ActuatorW61Y-B ODY (AI R-TO-RAI S E) - E XTRA LON G STR OK EW61 & W64R Holding Pressure ChartsW61 AL/HAL (AI R-TO-LOWE R) - STAN DAR D STR OK EW61 AR (AI R-TO-RAI S E) - LON G STR OKEW61 AL (AI R-TO-LOWE R) - LON G STR OK EW61Y-B ODY (AI R-TO-LOWE R) - E XTRA LON G STR OKEW62 AR /HAR (AI R-TO-RAI S E) - STAN DAR D STR OK EW62 Holding Pressure Charts• If pressure rating is higher than documented in tables consult factory before exceeding.• Minimum air supply requirements: 50 PSI for 4, 5 and 6 inch standard spring actuators; 75 PSI for 4, 5 and 6 inch heavy spring and 4 and 6 inch long stroke actuators; 87 PSI for A, B and C size actuators.• Please contact the factory for holding pressure values not listed.W62 AR /HAR (AI R-TO-RAI S E) - STAN DAR D STR OK E (CONTI N U ED)W62 AR (AI R-TO-RAI S E) - LON G STR OKEW62 AL (AI R-TO-LOWE R) - LON G STR OKEW62 AL/HAL (AI R-TO-LOWE R) - STAN DAR D STR OK EW62 AL/HAL (AI R-TO-LOWE R) - STAN DAR D STR OK E (CONTI N U E D)W63 AR (AI R-TO-RAI S E) - LON G STR OK EW63 AR /HAR (AI R-TO-RAI S E) - STAN DAR D STR OK EW63 & 64 Holding Pressure Charts• If pressure rating is higher than documented in tables consult factory before exceeding.• Minimum air supply requirements: 50 PSI for 4, 5 and 6 inch standard spring actuators; 75 PSI for 4, 5 and 6 inch heavy spring and 4 and 6 inch long stroke actuators; 87 PSI for A, B and C size actuators.• 1For sizing Over-Pressure valves, select a Heavy-Duty spring actuator with a holding pressure greater than the desired relief pressure. Designate with the “R” valve model (i.e. WR61) and actuator size (i.e. 5RHAR).• Please contact the factory for holding pressure values not listed.W63 AL (AI R-TO-LOWE R) - LON G STR OK EW63 AL/HAL (AI R-TO-LOWE R) - STAN DAR D STR OKEW65 AR /HAR (AI R-TO-RAI S E) - STAN DAR D STR OK EW65 Holding Pressure Charts• If pressure rating is higher than documented in tables consult factory before exceeding.• Minimum air supply requirements: 50 PSI for 4, 5 and 6 inch standard spring actuators; 75 PSI for 4, 5 and 6 inch heavy spring and 4 and 6 inch long stroke actuators; 87 PSI for A, B and C size actuators.• Please contact the factory for holding pressure values not listed.21W65 AR /HAR (AI R-TO-RAI S E) - STAN DAR D STR OK E (CONTI N U ED)W65 AR (AI R-TO-RAI S E) - LON G STR OK EW65 AL (AI R-TO-LOWE R) - LON G STR OKE22W65 AL/HAL (AI R-TO-LOWE R) - STAN DAR D STR OKE23W65 AL/HAL (AI R-TO-LOWE R) - STAN DAR D STR OK E (CONTI N U ED)24AI R B OOST F OR P ORT BAI R B OOST F OR PORT AChart shows additional product holding pressure per 1 PSI or BAR of air applied to port B to:(1) air assist spring holding force 1 (spring to close)(2) calculate holding power on air to air actuator(3) calculate additional holding power above the nominal air requirement of the actuator 3 (4) Maximum Air Assist Pressures should not exceed: - 70 psi on 4”, 5”, 6” Maintainable Actuators- 15 psi on A, B or C sized Maintenance Free Actuator (5) Air Assist pressures should be air regu-lated to the lowerest required amount of air pressureNote: * Y Body Valve is only available with 6ARY and 6AL Y actuatorsPRODUCT PRESSURE APPLIED TO BOTTOM OF PLUG.• 1 Refer to W61 & W65 holding pressure charts for spring only holding force. • 2 Refer to W62 & W63 holding pressure charts for spring only holding force.• 3 Air requirements: 50 PSI to actuate 4”, 5”, & 6” Actuators 75 PSI to actuate 4”, 5” & 6” heavy spring and 4” & 5” long stroke actutators; 87 PSI for A, B, and C size actuators (refer to holding pressure charts for holding power).Air Assist ChartsExample:W61T-3" with 5" Air to Raise (Spring to Close) actuator required to hold against 75 PSI product pressure.Holding pressure required: 75 PSI Minus Spring only holding force: - 55 PSI (From page16)Additional holding power required: 20 PSIAir Assistpressure required =7.79Additional holding power required 20 Product Ratio from chart above2.6PSIAir Requiredto Port BChart shows additional product holding pressure per 1 PSI or BAR of air applied to port A to:(1) air assist spring holding force 1 (spring to close)(2) calculate holding power on air to air actuator(3) calculate additional holding power above the nominal air requirement of the actuator 3 (4) Maximum Air Assist Pressures should not exceed: - 70 psi on 4”, 5”, 6” Maintainable Actuators- 15 psi on A, B or C sized Maintenance Free Actuator (5) Air Assist pressures should be air regu-lated to the lowerest required amount of air pressure25Cleanable, Designed For Sanitary / Hygienic Applications • 316L Stainless Steel wetted parts• Minimal internal crevices and high surface finishes• Free-spinning, snap-on TFM or PEEK seats for reliable sealing: choice of T ef-Flow, T ef-Flow P, tri-ring, or metal• Captive, supported stationary seals located forward to the product zone: choice of o-ring, quad, or wiping stem seals• Free draining in multiple positions – including upside down •3-A compliant, FDA approved materialsHeavy-duty Construction • Machined-from-bar body construction can withstand mishandlings of active plant environment & lead to long service life• Consistently thick body wall dimensions & laser welded port extensions minimize body distortion during manifolding & extreme fluid temperature changes • Deep, inter-locking bodies and adapters• Heavy-Duty Clamps & High Pressure Adapters for up to 1220 PSI applications •Multiple split TFM bearing support of stemsFlexibility & Modularity • Major components (body, stem, adapter, actuators) are modular in design to quickly and easily assemble or retrofit in field a valve to meet specific applications• Choice of standard fully maintainable actuator or cost-effective maintenance-free actuator with 5-year warranty with various sizes and spring options• True-line mix body sizes and custom 45° or other angled ports available to match complicated pipe design • One-piece bodies or two-piece clamped• AL6XN alloy product zone parts available for corrosive products• Custom port lengths and center-to-center dimensions can match competitor and legacy series valves to provide easy drop-in replacements• Various control top models available to fit customer needs: cost-effective CU4 full-featured, robustWCB control tops, or state-of-the-art Burkert 8681Low Cost of Ownership • Heavy-duty construction maximizes service life• Minimum propriety parts gives off-the-shelf availability and low price of most spares and components • Available spare parts from local distributor or factory in Delavan, WI•Modular design enables multi-use parts, easy training & familiarity with whole family of valves, minimum spares required on shelf• Long life standard actuator is field-maintainable with finger-safe, caged springs and cartridge piston assemblies• Commonality of parts: same part numbers used multiple places• Simple, easy-to-maintain design is intuitive and does not require advanced mechanical skills Domestic Manufacture, Local Support• Value-Added Distributor Relationships • Face-to-Face Representation•Manufacturing, Assembly, Inventory, Engineering & Customer Service in Delavan, Wisconsin, USAW62TTHeavy-duty ConstructionW60 Series Valves: Safe, Strong and Sanitary26The ‘standard’ adapter is used on all models of short and long stroke W60 Series valves. Machined from 316LSS bar with a thick cross-section, the adapter adds strength to the valve body and provides alignment for the stem. The outer perimeter seals to the valve body with an O-ring that is located forward to the product zone to minimize crevices. The product stem passes through the adapter and is sealed to the adapter with an O-ring. A TFM split bearing guides the stem and takes up the mechanical loading imparted by hydraulic forces. This increases the service life of the stem seal. Adapters are made in 1"-6"(25mm -152mm) sizes.The pressure limitation of the W60 adapter is the sealing capability of the dynamic O-ring on the product stem. This variation of the W60 adapter uses a backing ring added on the atmospheric side to support the stem O-ring. This significantly boosts the pressure rating on the stem O-ring. The product stem passes through the adapter and is sealed to the adapter with an O-ring and is guided by a TFM split bearing.This adapter is used to convert a ‘standard’ W60 series valve to a W80. The outer perimeter seals to the valve body with an O-ring that is located forward to the product zone to minimize crevices. The product stem passes through the adapter and is sealed in the upper part and the lower part of the adapter with O-rings. The space between the O-rings is flushed with a suitable liquid or steam. The TFM split bearing is located in the flushed chamber. Adapters are made in 1"-6" (25mm - 152mm) sizes. For vacuum-rated, extended shelf-life (ESL) applications, the W80A adapter adds steam trace to the adapter-to-valve body connection.For high-risk and hard to clean product applications, the wiping stem seal fills the gap between the product zone and the traditional O-ring stem seal. The adapter is a two-piece design to allow easy inspection or replacement of the wiping stem seal. The outer perimeter seals to the valve body with an O-ring that is located forward to the product zone to minimize crevices. A TFM split bearing is used to guide and support the valve stem.27SPX FLOW, Inc. reserves the right to incorporate our latest design and material changes without notice or obligation.Design features, materials of construction, dimensional data and certifications as described in this bulletin, are provided for your information only and should not be relied upon unless confirmed in writing. Please contact your local sales representative for product availability in your region. For more information visit .The green “” and “” are trademarks of SPX FLOW, Inc.WCB_Valves-Single-Seat-DS-1201_DST_US Version: 01/2021COPYRIGHT © 2021 SPX FLOW, Inc.Identification Number: DS-1201-USS PX FLOW611 Sugar Creek Road Delavan, WI 53115P: (262) 728-1900 or (800) 252-5200E:**********************Based in Charlotte, North Carolina, SPX FLOW, Inc. (NYSE: FLOW) is a multi-industry manufacturing leader. For more information, please visit 。

W60Z SERIES TECHNICAL GUIDE2W60Z DIMENSIONSCircled dimensions correspond to the line numbers on the tabulated chart inside the Technical Guide. Dimensions are in inches (millimeters).Right Angle Stacking Single Polyurethane Load Wheel (std.)3.25 x 6.5E q u a l I n t e r s e c t i n g R i g h t A n g l e A i s l e w i t h 48.0 (1,220) x 40.0 (1,015) p a l l e t 12111.0(25)27.0(686)32.6(828)9.1(230)1034.0(864)9812111.0(25)27.0(686)32.6(828)9.1(230)10Floor to Top of Battery Rollers6.8(173)49.1(1247)6.0 (152)34.7(882)42%3.6 (92)9.5(240)34.4 (874)Forks Lowered 7.0 (178)10.0 x 5.0 x 6.5PolyurethaneDrive TireForks Raised 11.7 (297)39%3.3(83)9.3(235)1398BATTERY SIZE DIMENSIONSNUMBER OF CELLS CELL SIZE PLATESPER CELLCAPACITYLENGTH WIDTH HEIGHT WEIGHT Ah (Kwh)in (mm)in (mm)in (mm)lbs (kg)12757225 (5.2)25.6 (651)8.8 (224)23.3 (592)536 (243)12857255 (6.0)25.5 (648)8.6 (219)23.3 (592)590 (269)127511375 (8.7)26.5 (674)13.0 (331)23.3 (592)825 (374)128511425 (9.9)26.1 (663)12.8 (326)23.3 (592)865 (392)3CERTIFICATION: Hyster lift trucks meet the design and construction requirements of B56.1-1969, per OSHA Section 1910.178(a)(2), and also comply with the B56.1 revision in effect at time of manufacture. Certification of compliance with the applicable ANSI standards appears on the lift truck.† NOTE: Performance specifications / ratings are for truck equipped as described under Standard Equipment in this technical guide. Performance specifications are affected by the condition of the vehicle and how it is equipped, as well as by the nature and condition of the operating area. Specifications are subject to change and the proposed application should be discussed with your authorized Hyster Company Dealer.Optional load wheels affect outside turning radius and right angle stacking aisles. Contact your dealer if these dimensions are critical.G E N E R A L1Manufacturer Hyster Company2Model W60Z 3Capacity, rated lb (kg)6,000 (2 700)4Voltage24D I M E N S I O N S5Nominal fork length in (mm)36.0 (915)42.0 (1 067)48.0 (1 219)6Width across forksin (mm)27.0 (685)7Chassis length, with 13.4” battery compartment in (mm)34.4 (874)8Overall length, with 13.4” battery compartment in (mm)70.2 (1 783)76.2 (1 935)82.2 (2 087)9Wheelbase, lowered with 13.4” battery compartment in (mm)53.8 (1 367)59.8 (1 519)65.8 (1 670)Wheelbase, raised with 13.4” battery compartment in (mm)49.1 (1 247)55.1 (1 400)61.1 (1 551)10Turning radius, lowered, with 13.4” battery compartmentin (mm)63.2 (1 605)69.2 (1 758)75.2 (1 910)Turning radius, raised, with 13.4” battery compartment in (mm)58.5 (1 485)64.5 (1 638)70.5 (1 790)11Right angle aisle stack, 13.4” batt. comp. w/ 40”x 48” pallet in (mm)71.2 (1 808)76.6 (1 946)82.1 (2 096)12Equal intersecting aisle, 13.4” batt. comp. w/ 40.0” wide pallet in (mm)56.5 (1 435)59.8 (1 519)62.9 (1 596)13Grade clearance, center wheelbase, raised with pallet%393431Grade clearance, forks first, raised with pallet %39Grade clearance, chassis first, raised with pallet %4214Overall lift height (TOF)in (mm)9.3 (236)15Overall fork lifting heightin (mm)6.0 (154)B A T T E R Y16Battery compartment size, 13.4” batt. compartment (L x W x H)*in 32.0 x 13.4 x 31.0Battery compartment size, 13.4” batt. compartment (L x W x H)*(mm)(812 x 340 x 787)18Battery weight, 13.4” batt. compartment, 24-Volt - minimumlb (kg)536 (243)Battery weight, 13.4” batt. compartment, 24-Volt - maximumlb (kg)865 (392)P E R F †19Travel speed, NL / RL mphmph (km/h) 3.7 (6.0) / 2.6 (4.2)20Lift / lower speed, w/ 13.4” batt. compartment, 24-Volt NLseconds 3.7 / 3.0Lift / lower speed, w/ 13.4” batt. compartment, 24-Volt RL seconds4.7 / 1.8W H L21Drive tire size (Rubber)in 10.0 x 5.0 x 6.522Load wheel size, Single (Polyurethane)in 3.25 x 6.523Weight, total approx. with 13.4” batt. compartment w/o batterylb (kg)987 (448)1,007 (457)1,022 (464)W60Z SPECIFICATIONS* Length is measured side to side of truck. Width is measured front to back on the truck.W60Z pallet trucks use SB175 red connector - 16.0” (406 mm) 1/0 gauge leads, B position.Number of plates for the industrial battery is 7 to 11, depending on the amp hour rating chosen.Maximum battery height with optional load backrest extension (LBE) and battery rollers is 23.3” (592 mm).The W60Z walkie pallet truck can utilize a battery with a maximum amp hour capacity of 510 Ah (11.9 kw).6.0(152)6.0(152)9.0(229)9.0(229)18.0 (457)48.0 + 0.125 (1,219 + 4) Fork Trucks OnlyR A N G E 39.875 t o 40.125(1,013t o 1,019)F o r k & P al l e t T r u c k sSlats - Minimum Width5.625 (143)GMA PALLET - STANDARD DIMENSIONSHyster Company P .O. Box 7006Greenville, North Carolina 27835-7006Part No. W60Z/TG 12/2016 Litho in U.S.A.All trucks shown with optional equipment. © 2016 Hyster Company. All rights reserved.Hyster, , and STRONG PARTNERS. TOUGH TRUCKS. and MONOTROL are registered trademarks in the United States and certain other jurisdictions. Hyster products are subject to change without notice.Visit us online at or call us at 1-800-HYSTER-1.。

READ THIS BOOKThis operator’s book has important information for the use and safe operation of this machine. Read this book care-fully before starting the machine. Keep this book and tell all operators to read the book. If you do not follow the instructions, you can cause an injury or damage equipment,furniture or buildings.For new books write to: Pacific2259 S. SheridanMuskegon, MI 49442-6252Carefully inspect all components to ensure that there is no concealed freight damage. If such damage is discovered,file a “CONCEALED DAMAGE REPORT” immediately with the delivering carrier.The contents of this manual are based on the latest product information available at the time of publication. Pacific Steamex reserves the right to make changes or improve-ments to its machines without notice.FOR YOUR CONVENIENCE, RECORD THE FOLLOWING IMPORT ANT INFORMATION:MODEL _______________________________SERIAL NUMBER _______________________PART NUMBER ________________________DATE PURCHASED _____________________OPERATING & MAINTENANCEINTRODUCTION INSTRUCTIONSWET/DRY V ACUUMSPWD 600PWD 609PWD 612PWD 615Gulper 600S Gulper 609S Gulper 612S Gulper 615SIMPORTANT SAFETY INSTRUCTIONSREAD AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONSBEFORE USING THIS MACHINE!WARNING! To reduce the risk of fire, electric shock, or injury:1.You must be trained to operate this machine. This machine is to be operated for its intended useonly.2.Do not operate this machine unless it is completely assembled.3.Always use a three-wire electrical system connected to the electrical ground. For maximum protec-tion against electrical shock, use a circuit that is protected by a ground fault circuit interrupter. Con-sult your electrical contractor.4.To prevent electrical shock: Always remove the electrical plug from the electrical outlet before per-forming any repairs, maintenance or cleanup and when leaving the machine unattended.5.To prevent electrical shock: Keep the machine surface dry; Do not subject to rain; Store the machinein a dry building area; Clean the machine with a dry cloth only.6.Machines can cause an explosion when near flammable materials and vapors. Do not use or storethis machine with or near fuels, grain dust, solvents, thinners, or other flammable materials. Do not use flammables to clean this machine.7.Maintenance and repairs must be done by a qualified or authorized person.8.If the machine is not working as it should, has been dropped, damaged, left outdoors, or dropped intowater, return it to a service center.9.To avoid damage to the machine’s electrical cord, always lift the machine over the cord. Do not runthe machine over the electircal cord.10.Make sure all labels, decals, warnings, cautions and instructions are fastened to the machine.This machine must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric cur-rent to reduce the risk of electric shock. This machine is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be inserted into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.WARNING - Improper connection of the equipment-grounding con-ductor can result in a risk of electric shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the machine - if it will not fit the outlet, have a proper outlet installed by a qualified electrician.This machine is for use on a nominal 120-volt circuit, and has a grounded plug that looks like the plug illustrated in figure A. A temporary adapter that looks like the adapter illustrated in figures B and C may be used to connect this plug to a 2-pole receptacle as shown in figure B if a properly grounded outlet is not available. The temporary adapter should be used only until a properly grounded outlet (figure A) can be installed by a qualified electrician. The green colored rigid ear, lug, or the like extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by a metal screw.NOTE: In Canada, the use of a temporary adapter is not permitted by the Canadian Electrical CodeEXTENSION CORDSUse only three-wire 16/3 or larger gauge approved extension cords that have three-prong grounding type plugs and three-pole receptacles that accept the appliance’s plug. Replace or repair any damaged cords or plugs.When servicing, refer to authorized person only. Use only identical replace-ment parts.Grounding InstructionsNOTE: Do not use adapters shown in figures B & C in CanadaMAINTENANCEGood maintenance procedures assure better operation, fewer repairs and longer life to your machine.DISCONNECT THE ELECTRICAL PLUG OF THE MA-CHINE FROM THE ELECTRICAL OUTLET BEFORE DOING ANY CLEANUP, REPAIRS OR MAINTENANCE OF THE MACHINE AND WHEN LEA VING THE MACHINE UNA TTENDED.CLEAN THE MACHINE AFTER EACH USE:1. Wipe the outside with a clean cloth.2. Clean the collector tank: Release the clamps on each sideof the tank and head assembly. Lift the head assembly off and set aside. Lift the filter assembly out of the collector tank and set aside. Then wipe the inside of the collector tank with a clean cloth.3. Empty and check the filter assembly: Empty the recoveredsoilage into a suitable container and shake to remove clinging dirt. Brush the outside of the filter bag to remove embedded dirt. Check the filter assembly for tears or holes; repair or replace if necessary. Install the clean filter assembly into the ELECTRICAL CABLE:Check the cord for any nicks, cuts or damage. Report these to your supervisor for correction.V ACUUM HEAD ASSEMBLY:1. Gaskets: Clean the vacuum head gasket and the float shut-offgasket.2. Float Shut-Off Device: This should move freely. Removeany debris or strings from the float cage.3. Head Assembly: Replace and leave ajar if the collector tank isdamp to prevent mildew.WHEELS AND CASTERS:Check these for cuts and nicks. Remove any strings or debris that may restrict the free movement of the wheels. Wipe the treads clean.CARBON BRUSH INSPECTION:Check for wear at six month intervals or every 600 hours of operation. The carbon brushes must be replaced if worn shorter than 3/8 inch.OPERATING PROCEDURESWARNING! For the safe operation of this machine follow the instructions given in this booklet and the training given by your supervisor. Failure to do so can result in personal injury and/or damage to machine and property!DO NOT OPERA TE MACHINE IN AN EXPLOSIVE ENVIRONMENT!To prepare the machine for operation, make sure it is of the correct voltage and properly assembled. If in doubt, ask your supervisor. FOR DRY PICK-UP:“Dry” refers to material such as dust, dirt, debris and dry foam shampoo.1.Release the clamp on each side of the tank and head assembly.Lift the head assembly off and set it aside.2.Then lift the cloth filter assembly out of the collector tank.Clean the cloth filter if needed (reference the “Maintenance”section).3.Empty the collector tank of all dust and debris. If the debrisis wet, empty and dry the inside of the tank thoroughly. 4.Place the cloth filter assembly back into the collector tank.Check for a good seal around the outer filter lip and tank rim.5.Replace the head assembly and fasten both clamps. Attachthe hose, wand and floor tool of choice (reference page 5).6.Plug the power cord into a 115-volt, 60 cycle grounded outlet.7.Turn the machine’s motor on by pressing the rocker switchwhich is located on the head assembly.W ARNING! NEVER USE THIS MACHINE TO PICK UP VOLA TILE OR EXPLOSIVE MA TERIALS.FOR WET PICK-UP:“Wet” refers to liquids such as water, scrub solutions and deter-gents; NOT VOLATILE OR EXPLOSIVE MA TERIALS. 1.Release the clamp on each side of the tank and head assembly.Lift the head assembly off and set it aside.2.Then lift the cloth filter assembly out of the collector tank.Store the filter assembly for future, dry pick-up use. DO NOT REINSTALL.3.Empty the collector tank of all dust and debris. Also wipethe inside of the collector tank to remove clinging dust.4.Check the float shut-off device on the lower portion of thehead assembly. The float should have free movement. When the recovered liquid soilage reaches the collector tank capac-ity, the float will rise to shut off the air flow, stopping the liquid recovery. This prevents damaging overflow and signals the operator when to empty the collector tank.5.Replace the head assembly and fasten both clamps. Attachthe hose, wand and floor tool of choice (reference page 5).6.Plug the power cord into a 115-volt, 60 cycle grounded outlet.7.Turn the machine’s motor on by pressing the rocker switchwhich is located on the head assembly.123457891011121314151617181920212223152425262728293031333435363738394032123912134567810111415161920171821222425233334353632262728293938374042414344453031123457810111213149615161718192021222324252627282930313233343536373839404142434445464847495051525354555657585933PWD 615 and Gulper 615S2314568911128131415161712181920OPTIONAL ACCESSORY CARPET TOOL- ITEM 218912DELUXE TOOL KIT PART #608510TOOL KIT ASSEMBL Y :1.Connect the hose to the collector tank by inserting thelarge, grooved hose adapter end into the tank adapter.Pull the locking pin up to allow the hose adapter to slide further in. Release the locking pin to engage the large groove.2.Insert the upper wand half firmly into the lower wand assembly. The dimple on the lower wand aligns with the groove of the upper half to assure a rigid fit.3.Insert the wand end into the free end of the vacuum hose.Then fasten the proper floor tool to the to the wand by inserting the mating end of the floor tool into the adapter collar of the wand assembly. Pull the tool locking pin to allow total engagement of the adapter and tool. Release the pin to lock the tool to the wand.4.The hand tools may also be used by inserting their adapter directly into the free end of the vacuum hose.5.Tool Selection: Choosing the proper tool will give the best results. To vacuum dust and debris from floors or walls-select the bristle floor tool. To remove water, liquid waste, strip solution, etc. from hard surfaced floors-use the squeegee floor tool. When vacuuming carpets or rugs-choose the carpet tool.11OPTIONAL SQUEEGEE ASSEMBLYPART #6085191234567891011121314151617451863002010/01W ARRANTY POLICY WET/DRY V ACUUMSThe Pacific Steamex Inc. Wet/Dry Vacuum has been manufactured, tested and inspected in accordance with specific engi-neering requirements and is W ARRANTED to be free from defects in workmanship and materials as follows:One (1) year parts & labor - All components unless excluded below.This warranty extends to the original user/purchaser and only when used, operated and maintained in accordance with Pacific Steamex Inc. Operating and Maintenance instructions.This warranty does not apply to certain wear parts and accessories of the machine such as electrical cords, carbon motor brushes, floor brushes, hoses, tools, filters, casters, wheels, etc. Nor does it apply to damage or failure caused by improper use, abuse or neglect. Warranty credit or replacement of return parts including motors, etc., is subject to incoming inspection of those items.To secure repair under this warranty, the following procedure should be taken:•The inoperative machine or warranted parts must be delivered to the authorized dealer with shipping and deliverycharges prepaid. If unable to locate the Dealer, you may contact Pacific Steamex Inc. at the address listed herein for the location of the nearest Pacific Steamex Inc. repair center or agent or for other instructions pertaining to your warranty difficulty.•Upon compliance with the above warranty procedure, all warranted repairs would be completed at no additional charge or cost to the user.•Only Pacific Steamex Inc. or its authorized dealers and agents may make no charge warranty repairs on this product. All others do so at their own risk.This warranty limits Pacific Steamex Inc. liability to the repair of the product and/or warranted parts replacement and does not include incidental or consequential damages arising from the use of a Pacific Steamex Inc. machine whether defective or not.This warranty is in lieu of all other expressed or implied warranties and is extended to the original purchaser/user.2259 SheridanMuskegon, Michigan 49442Ph: (800) 968-1332 Fax: (231) 773-1642。

Product Data SheetTrigonox EHP-W60 Di(2-ethylhexyl) peroxydicarbonateTrigonox® EHP-W60 is an initiator (60% emulsion in water and methanol) for (co)polymerization of vinyl chloride and vinylidene chloride.CAS number16111-62-9EINECS/ELINCS No.240-282-4TSCA statuslisted on inventoryMolecular weight346.5Active oxygen contentperoxide4.62%SpecificationsActive oxygen 2.72-2.82 %Appearance White to off-white emulsionAssay59.0-61.0 %Viscosity, -10°C (Brookfield LVT, spindle #3)200-1000 mPa.sCharacteristicsDensity, 0 °C0.980 g/cm³ApplicationsPolymerization of vinyl chloride: Trigonox® EHP-W60 is applied as an initiator for the suspension polymerization of vinylchloride in the temperature range between 40°C and 65°C. Trigonox® EHP-W60 can be used in combination with other peroxides such as 1,1,3,3-Tetramethylbutyl peroxyneodecanoate (Trigonox® 423), Cumyl peroxyneodecanoate (Trigonox® 99) or Dilauroyl peroxide (Laurox) to increase reactor efficiency. Reasons to use a water based peroxide emulsion instead of a solvent based peroxide are the following: enhanced safety, easy to use (pumpable) in 'closed reactor technology', easy to dilute with water.Half-life dataThe reactivity of an organic peroxide is usually given by its half-life (t1/2) at various temperatures. The half-life ofTrigonox® EHP-W60 in chlorobenzene is:0.1 hr83°C1 hr64°C10 hr47°CFormula 1kd = A·e-Ea/RTFormula 2t½ = (ln2)/kdEa122.45 kJ/moleA 1.83E+15 s-1R8.3142 J/mole·KT(273.15+°C) KThermal stabilityOrganic peroxides are thermally unstable substances, which may undergo self-accelerating decomposition. The lowest temperature at which self-accelerating decomposition of a substance in the original packaging may occur is the Self-Accelerating Decomposition Temperature (SADT). The SADT is determined on the basis of the Heat Accumulation Storage Test.SADT5°C (0°C for IBC)Emergency temperature (Tₑ)-5°C (-10°C for IBC)Control temperature (Tc)-15°C (-20°C for IBC)Method The Heat Accumulation Storage Test is a recognized test method for thedetermination of the SADT of organic peroxides (see Recommendations on theTransport of Dangerous Goods, Manual of Tests and Criteria - United Nations, NewYork and Geneva).StorageDue to the relatively unstable nature of organic peroxides a loss of quality can be detected over a period of time. To minimize the loss of quality, Nouryon recommends a maximum storage temperature (Ts max.) for each organic peroxide product.Ts Max.-15°C (-20°C for IBC)Ts Min.-25°CNote When stored under these recommended storage conditions, Trigonox® EHP-W60will remain within the Nouryon specifications for a period of at least three monthsafter delivery.Packaging and transportThe standard packaging is a 30-liter HDPE can (Nourytainer®) for 25 kg peroxide emulsion. Delivery in a 1250-liter stainless steel Intermediate Bulk Container (IBC) is also possible in a number of countries. Both packaging and transport meet the international regulations. For the availability of other packed quantities contact your Nouryon representative. Trigonox®EHP-W60 is classified as Organic peroxide type F; liquid, temperature controlled, Division 5.2; UN 3119.Safety and handlingKeep containers tightly closed. Store and handle Trigonox® EHP-W60 in a dry well-ventilated place away from sources of heat or ignition and direct sunlight. Never weigh out in the storage room. Avoid contact with reducing agents (e.g. amines), acids, alkalis and heavy metal compounds (e.g. accelerators, driers and metal soaps). Please refer to the Safety Data Sheet (SDS) for further information on the safe storage, use and handling of Trigonox® EHP-W60. This information should be thoroughly reviewed prior to acceptance of this product. The MSDS is available at /sds-search.Major decomposition productsCarbon dioxide, 2-EthylhexanolAll information concerning this product and/or suggestions for handling and use contained herein are offered in good faith and are believed to be reliable.Nouryon, however, makes no warranty as to accuracy and/or sufficiency of such information and/or suggestions, as to the product's merchantability or fitness for any particular purpose, or that any suggested use will not infringe any patent. Nouryon does not accept any liability whatsoever arising out of the use of or reliance on this information, or out of the use or the performance of the product. Nothing contained herein shall be construed as granting or extending any license under any patent. Customer must determine for himself, by preliminary tests or otherwise, the suitability of this product for his purposes.The information contained herein supersedes all previously issued information on the subject matter covered. The customer may forward, distribute, and/or photocopy this document only if unaltered and complete, including all of its headers and footers, and should refrain from any unauthorized use. Don’t copythis document to a website.Trigonox® and Laurox are registered trademarks of Nouryon Chemicals B.V. or affiliates in one or more territories.Contact UsPolymer Specialties Americas************************Polymer Specialties Europe, Middle East, India and Africa*************************Polymer Specialties Asia Pacific************************2022-6-30© 2022Polymer production Trigonox EHP-W60。

Proportional pressure relief cartridge withi ntegrated electronics◆pilot operated◆Q max = 100 l/min◆p max = 400 bar◆p N max = 350 bar M22 x 1,5ISO 7789DESCRIPTIONPilot operated proportional pressure relief valve with integrated electronics as screw-in cartridge for cavity according to ISO 7789. When the operating pressure adjusted by means of the pro-portional solenoid is reached, the valve opens and connects the protected line with the drain to the tank. The back pressure in T (2) affects the pressure in P (1). This proportional valve is very sensitively adjustable and suitable for high pressures. The Plug & Play valves are factory set and adjusted and have therefore a high valve-to-valve reproducibility. The control takes place via an analogue interface or a fieldbus interface (CANopen, J1939 or Profibus DP). The parameterisation takes place by means of the free of cost parameterisation and diagnostics software «PASO» or via fieldbus interface. The USB parameterisation interface is accessible through a screw plug. As an option, these valves are available with integrated controller. As feedback value genera-tors sensors with voltage or current output can be connected d irectly. The available controller structures are optimised for a pplications with hydraulic actuations. APPLICATIONProportional pressure relief valves with integrated electronics are perfectly suitable for demanding applications in which the pressure frequently has to be changed. They are used in applications where high valve-to-valve reproducibility, easy installation, comfortable operation and high precision are very important. The integrated controller reliefs the machine control and operates the pressure control in a closed loop circuit. The applications are in the industri-al as well as in the mobile hydraulics for the smooth control of h ydraulic actuations. The screw-in cartridge is perfectly suitable for installation in control blocks and is installed in sandwich- (vertical stacked systems) and in flange plates (corresponding data sheets in this register). For machining the cartridge cavity in steel and aluminum blocks, cavity tools are available (hire or purchase). Please refer to the data sheets in register 2.13.Note!…PASO” is a Windows programm in the flow diagram style, which enables the intuitive adjustment and storingof all variable parameters. The data remain saved incase of a power failure and can also be reproduced andtransferred to other DSV.SYMBOLELECTRICAL SPECIFICATIONSNote!Exact electrical specifications and detailed description of «DSV» electronics can be found on data sheet1.13-76.ACTUATION MANUAL OVERRIDE HB4,5 as standardTYPE CODEB V P PM22 - - / M E - HB4,5 #Pressure relief valve Pilot operated ProportionalScrew-in cartridge M22 x 1,5Nominal pressure range p N 20 bar 20 200 bar 200 63 bar 63 275 bar 275100 bar 100 350 bar 350160 bar 160Nominal voltage U N12 VDC G12 24 VDCG24Slip-on coilMetal housing square Connection executionIntegrated electronicsHardware configurationAnalog command value signal 12 pole A17 poleD1 (0 … 10 V preset)Analog command value signal 12 pole A4 7 pole D4 (4 … 20 mA preset)CANopen according to DSP-408C1Profibus DP according to Fluid Power Technology P1CAN J1939 (on request)J1Function AmplifierController with current feedback value signal (0…20 mA / 4… 20 mA) R1Controller with voltage feedback value signal (0…10 V) R2Sealing material NBRFKM (Viton)D1Manual overrideDesign index (subject to change)2.3-537GENERAL SPECIFICATIONSHYDRAULIC SPECIFICATIONSELECTRICAL CONNECTIONNote!The mating connector is not included in the deliveryPERFORMANCE SPECIFICATIONSOil viscosity u = 30 mm 2/sFACTORY SETTINGSDither set for optimum hysteresis● = Deadband: solenoid switched off at command value signal < 5 %■ = Limited pressure in port P (1) at 70 % command value signalHYDRAULIC CONNECTIONCavity drawing according to ISO 7789–22–02–0–98Note!For detailed cavity drawing and cavity tools see data sheet 2.13-1003PARTS LISTDIMENSIONSWith analog interface, 7 pole connectorAmplifier and controllerWith fieldbus interface ControllerWith analog interface, 12 pole connector Amplifier and controller With fieldbus interface AmplifierACCESSORIESAttention!Auxiliary conditions for the cable:– External diameter 12 pol: 3,5…14,7 mm – External diameter 7 pol: 8…10 mm – Wire cross section max. 1 mm 2– Recommended wire cross section:0…25 m = 0,75 mm 2 (AWG18)25…50 m = 1 mm 2 (AWG17)SURFACE TREATMENT◆The cartridge body and the solenoid are zinc-nickel coated ◆The electronics housing is made of aluminium.SEALING MATERIALNBR or FKM (Viton) as standard, choice in the type codeSTANDARDSINSTALLATION NOTESCOMMISSIONINGFor DSV amplifiers as a rule no parameter adjustments by the cusot-mer are required. The plugs have to be connected in accordance with the chapter «Electrical connection».Controllers are supplied configured as amplifiers. The adjustment of the mode of control and of the controller are carried out by the custo-mer by means of the software adjustment (USB interface, Mini B).Further information can be found on: «».Free- of charge download of the «PASO» software and the operation instructions for «DSV» hydraulic valves as well as the operation inst-ructions CANopen Protocol resp. Profibus DP Protocol, with Device Profile DSP-408 for «DSV».Note!The mating connectors and the parameterisation cable are not part of the delivery. Refer to chapter «Accesso-ries».Wandfluh AG Postfach C H -3714 FrutigenTel. +41 33 672 72 72 Fax +41 33 672 72 12 ******************。

DescriptionSingle pole, 3-way, 1.5A, 120V/AC, 60HzDesign features•Set up and control fan speed control using theEaton Brightlayer Home App or by voice commands • No hub required•LED indicator system alerts if the device is not set up in the network•Preset whether your device comes on or stays off following a power outage• Neutral required for installation•Dimmable white LED indicators illuminate to indicate (ON, OFF) status•Can be wired with standard 3-way switch where traveler wire exists for 3-way.EWFFSC15Project Name:Prepared By:Project Number:Date:Catalog Number:Type:T able 1. Wi-Fi smart fan speed controlCompliances, specifications and availability are subject to change without notice.Rating DescriptionColor suffixCatalog no.AV/AC Hz1.512060Wi-Fi smart fan speed controlW, C2, C6, C7Amazon, Alexa and all related logos are trademarks of , Inc. or its affiliates. Google and Google Play are trademarks of GoogleLLC. Wi-Fi CERTIFIED logo is a trademark of the Wi-Fi Alliance.Wi-Fi smart fan speed control2EATON/connectedhome Technical DataEffective April 2023Wi-Fi smart fan speed controlCatalog No.EWFFSC15PerformanceMaximum amperage: 1.5ARating:120V/AC, 60HzInstallation & programming For installation and programming the device, see the Wi-Fi Smart Fan Speed Control Quick Start Guide included with product.Testing & code compliance cULus Listed 244B. NOM Certified. Complies with FCC Part 15, Class B.TerminationsFan speed controller has screw terminals for line, load, ground, neutral and traveler 3-way wire Material characteristics Flammability: Meets UL94 requirements; V2 rated Temperature rating: 32°F to 104°F (0°C to 40°C)Warranty2-year limited product warrantyEaton’s Wi-Fi smart fan speed control replaces regular switches (where a neutral is present) to provide local and remote control for ceiling fans. The fan speed controller can be remotely controlled and the user can create routines, schedules and group devices using the Eaton Brightlayer Home App. Eaton’s Wi-Fi smart fan speed control has additional features such as a selection of 3 fan speed controls (High, Medium, Low).ApplicationsProject Name:Prepared By:Project Number:Date:Catalog Number:Type:T able 2. SpecificationsCompliances, specifications and availability are subject to change without notice.Figure 1. EWFFSC15For ordering devices, include Catalog No. followed by the Color Suffix: W (White),C2 (Color Change Kit: LA, W, V), C6 (Color Change Kit: W, RB, SG), C7 (Color Change Kit: B, BK, GY)Decorator series color options:(White)C2 Color KitLA (Light Almond), W (White),V (Ivory)C7 Color KitB (Brown), BK (Black), GY (Gray)C6 Color KitRB (Oil Rubbed Bronze), W (White),SG (Silver Granite)T able 3. Color ordering information3EATON /connectedhome Single location control installationWi-Fi smart fan speed control Technical DataEffective April 2023Project Name:Prepared By:Project Number:Date:Catalog Number:Type:Certifications & compliancesKEY:cULusNOMFCCRelated productsWi-Fi smart productsEWFD30, EWACD, EWFTRCR15Compliances, specifications and availability are subject to change without notice.WallplatesPJS26, PJS262Single Location Control Installation (requires one Wi-Fi Fan Speed Control)3-Way location control installation Electrical Sector 1123 Hwy 74 SPeachtree City, GA 30269United States /WifiSmartElectrical Sector Canada Operations 5925 McLaughlin RoadMississauga, Ontario, L5R 1B8CanadaEatonCanada.ca/WifiSmartElectrical Sector Mexico Operations Carr. Tlalnepantla -Cuautitlan Km 17.8 s/n Col. Villa Jardin esq.Cerrada 8 de MayoCuautitlan, Mexico CP 54800Mexico Eaton.mx/WifiSmartEaton1000 Eaton Boulevard Cleveland, OH 44122United States Eaton is a registered trademark. All other trademarks are property of their respective owners.© 2023 EatonAll Rights Reserved Printed in USAPublication No. TD610147EN April 2023。

共2份
图1 TRT系统结构示意图
第二章起动、运行与停机
第一节透平发电机在下列情况下禁止起动
一、调速阀、紧切阀、旁通阀、静叶或保安系统不正常。

二、转速表全部失灵。

三、辅助油泵自启动装置工作不正常。

四、透平发电机在盘车时发现转动部分有磨擦声。

五、机组振动不合格。

六、油质不合格。

七、高低压电力系统不正常。

八、自动化控制系统不正常。

九、氮气压力不足
十、粉尘含量过高
第二节起动前的准备工作
一、详细检查全部设备，检查工作全部结束运行，专用工具应齐全。

二、起动前静态试验（如危急保安器，紧急停机按钮），试验紧急切断阀快关、旁通快开、静叶快关。

Key BenefitsVersatility and reliabilityWindCube Scan offers full 3D scanning with typical ranges up to 3km, 6km, or 10km (depending on model) — as well as multiplescanning patterns that make it ideal for many campaign types. Thesystem boasts outstanding uptime, reliability, and a robust onsite maintenance program, making it an ideal solution for long-term projects. And it can be moved and repurposed to support a variety of applications, providing outstanding value over time.At-a-glance data insight and reportingGet rich campaign insight through your choice of data management tools. WindCube Scan offersflexible data management through API requests, communication with an FTP server, or through a user-friendly and robust graphical user interface.Supported by the industry leaderWindCube Scan is supported by decades of experience, scientific tools and expertise, and industry-standard support services — all of which enable customers to get the most from their equipment over its full life span.Wind farms are growing larger and more denselyfilled with turbines, and turbine technology continues to evolve. WindCube ® Scan reliably and affordably provides accurate wind mapping and wake analysis that are now indispensable to onshore and offshore projects.WindCube Scan is the industry’s tool of choice for providing reliable, precise spatial wind data at any stage of a wind farm project, from prospecting to operation. Suitable for short-term rental changing placements during development campaigns or long-term operations.WindCube units feature rugged, industrial designs and can be placed in extreme environments. They are among the mostflexible and accurate wind measurement technologies available complementing met masts and accurate vertical profiling lidars. Each system is fully configurable for several uses including monitoring, atmospheric cross-sectioning, and wind profiling.WindCube ScanLong-range, fully flexible wind data for wind farm development and operationsProduct SpotlightPlease contact us at/contactsScan the code formore informationRef. B211907EN Rev. A ©Vaisala 2020This material is subject to copyright protection, with all copyrights retained by Vaisala and its individual partners. All rights reserved. Any logos and/or product names are trademarks of Vaisala or its individual partners. The reproduction, transfer, distribution or storage of information contained in this brochure in any form without the prior written consent of Vaisala is strictly prohibited. All specifications — technical included — are subject to change without notice.Applications• Large-scale wind resourceassessment, onshore or offshore • Measurement of wind turbine wake and wind farm blockage effect• Short-term forecasting for farm power prediction • Single or multiple power performance tests run simultaneouslyKey featuresFull 3D fast scanFully configurable lidar scanning strategy based on PPI, RHI, DBS and single beam scans to meet all needsProvides NetCDF files, a robust auto-documented format that gives flexibility to the userA wind reconstruction tool proven by international third parties is also availableDedicated reprocessing and display softwareAPI available for user's own configuration and data accessWindCube Scan series specificationsWindCube Scan at a glanceWhy Leosphere, A Vaisala Company?business end-to-end, with complementary services, robust customer service, and consultation. Today, WindCube lidar technology is also backed by 80 years of experience and worldwide services.。

This specification describes the requirements of 600W with active P.F.C Switching Power Supply with an ATX form-factor,+5V standby voltage,fan control,ATX12V 2.3/EPS12V 2.91 Power supply version, remote on/off control,full range input capability and forced air cooling characteristics.1. AC INPUT REQUIREMENTSThe input voltage, current, and frequency requirements for continuousoperation are stated below.Power factor correction (PF)>0.95 at full load.1.1 Inrush current limiting50A @ 115Vrms100A @ 230Vrms (at 25 C ambient cold start).2. DC OUTPUT2.1 DC voltage regulation01STRIDER SST-ST60F2.2 Load Ranges2.2.1 Typical Power Distribution for 600W ATX12V Configuration1.Maximum continuous total DC output power should not exceed 600W2.Maximum continuous combined load on +3.3VDC and +5VDC outputs shall notexceed 170W3.The maximum peak total DC output power shall not exceeed 620 watts4.Peak power and current loading shall be supported for a minimum of 12 second.5.Maximum combined current for the 12V outputs shall be 48A.2.3 DC Output Ripple/Noise.2.3.1 Ripple regulation2.3.2 DefinitionThe ripple voltage of the outputs shall be measured at the pins of the output connector when terminated in the load impedance specified in figure 1. Ripple and noise are measured at the connectors with a 0.1uF ceramic capacitor and a 10uF electrolytic capacitor to simulate system loading.Ripple shall be measured under any condition of line voltage,output load,line frequency,operation temperature.022.3.3 Ripple/Noise voltage test circuitFigure 1. Ripple/Noise voltage test circuit2.4 OvershootAny overshoot at turn on or turn off shall be less 10% of the nominal voltage value, alloutputs shall be within the regulation limit of section 2.0 before issuing the power goodsignal of section 4.0.2.5 Efficiency2.5.1 Power supply typical efficiency is 80% min under 20% Load / 50% Load / 100%Load at nominal input voltage of 115VAC .2.5.2 Other Low Power System RequirementsTo help meet the Blue Angel*, RAL-UZ 78, US Presidential executive order 13221, future EPA requirements, and other low Power system requirements, it is recommended that the +5VSB standby supply should be as efficient as possible. Standby efficiency is measured with the main outputs off (PS_ON# high state). Standby efficiency should be greater than 50% with a minimum loading of 100mA at input 115Vac. Pin 1W with a minimum loading of 50mA at input 230Vac.2.6 Remote on/off controlWhen the logic level "PS-ON" is low, the DC outputs are to be enabled.When the logic level is high or open collector, the DC outputs are to be disabled.03STRIDER SST-ST60F3. PROTECTION3.1 Over-power protectionThe power supply will be shutdown and latch off when output power is 110%~150%.3.2 Over voltage protectionThe over voltage sense circuitry and reference shall reside in packages that are separate and distinct from the regulator control circuity and reference.No single point fault shall be able to cause a sustained over voltage condition on any or all outputs.The supply shall provide latch-mode over voltage protection as defined in Table.3.3 Under voltage protectionThe under voltage sense circuitry and reference shall reside in packages that are separate and distinct from the regulator control circuity and reference.No single point fault shall be able to cause a sustained under voltage condition on any or all outputs.The supply shall provide latch-mode under voltage protection as defined in Table.3.4 Over Current Protection+5VDC, +12V1DC, +12V2DC and +3.3VDC have separate over current protection circuitsto meet 240VA safety requirement.3.5 Short circuitAn output short circuit is defined as any output impedance of less than 0.1 ohms.The power supply shall shut down and latch off for shorting the +3.3VDC,+5VDC,or+12VDCrails to return or any other rail. Shorts between main output rails and +5VSB shall not cause any damage to the power supply. The power supply shall either shut down and latch off or fold back for shorting the negative rails.+5VSB must be capable of being shorted indefinitely,but when the short is removed,the power supply shall recover automatically or by cycling PS_ON#.The power supply shall be capable of withstandinga continuous short-circuit to the output without damage or overstress to the unit.043.6 No load operationNo damage or hazardous condition should occur with all the DC output connectors disconnected from the load.The power supply may latch into the shutdown state.3.7 Over temperature protectionIn the event of a fan failure or the vents being blocked, the power supply shall have protection such that any over temperature condition caused by these events shall protect the power supply from damage or abnormal and/or dangerous operation.A shutdown of the power supply is acceptable A temperature derating factor less than 110% for the critical components is recommended before the power supply is shut down. Temperature derating factors higher than 110% can be evaluated on a case by case basis.4. TIMING4.1 Signal timing drawingFigure 4 is a reference for signal timing for main power connector signals and rails.VACPS-ON+12V/+5V/+3.3V O/PPW-OKnominalFigure 2. PS-OK Timing Sequence(1)T2: Rise time (0.1ms~20ms)(2)T3: Power good turn on delay time (100ms~500ms)(3)T4: Power good turn off delay time (1ms min)(4)T5: Rise time (10ms max)4.2 Hold up time (T6 of figure 2.)When the power loss its input power, the output shall maintain 16ms in regulationranges at nominal input voltage. (AC:115V/60Hz or 230V/50Hz)05STRIDER SST-ST60F065. ENVIRONMENT5.1 Operation5.2 Shipping and Storage5.3 Altitude6. SAFETY6.1 Underwriters Laboratory (UL) recognition.The power supply designed to meet UL 1950.6.2 The power supply must bear the German Bauart Mark from TUV.7.0 ELECTROMAGNETIC COMPATIBILITY (EMC)7.1 ELECTROSTATIC DISCHARGE (ESD) – EN 61000 – 4 - 2 19957.2 ELECTRICAL FAST TRANSIENT / BURST ( EFT/B) – EN 61000 – 4 - 4 19957.3 SURGE – EN 61000 – 4 - 5 19957.4 POWER FREQUENCY MAGNETIC FIELD – EN 61000 – 4 - 8 1993 7.5 VOLTAGE DIPS – RN 61000 – 4 - 11 19947.6 RADIATED SUSCEPTIBILTY – EN 61000 – 4 - 3 19967.7 CONDUCTED SUSCEPTIBILTY – EN 61000 – 4 - 6 19967.8 VOLTAGE FLUCTATION – EN 61000 – 3 - 3 1995STRIDER SST-ST60F0810. FAN SPEED CONTROLFan voltage varies with the ambient temperature or output power. 09STRIDER SST-ST60F10。
