ME2100系列升压转换IC

UC-2100-W SeriesArm Cortex-A81GHz palm-sized IIoT gateways with built-in LTE Cat.M1/NB-IoT moduleFeatures and Benefits•Armv7Cortex-A81000MHz processor•Integrated LTE NB-IoT/Cat.M1module with global band support•LTE-ready computer with Verizon/AT&T certification and industrial-grade CE/FCC/UL certifications•Dual-SIM slots•Moxa Industrial Linux with10-year long-term support•Dual auto-sensing Ethernet ports(10/100Mbps and10/100/1000Mbps)•Dual CAN ports with industrial CAN2.0A/B protocol supported•microSD socket for storage expansion•Programmable LEDs and a programmable button for easy installation andmaintenance•-40to75°C operating temperature rangeCertificationsIntroductionThe UC-2100-W Series computing platform is designed for embedded data acquisition and processing applications.The computer comes with up to two software selectable RS-232/422/485full-signal serial ports and single or dual LAN ports.This palm-sized series of Arm-based computing platforms includes a variety of models for a wide range of interface requirements,such as serial and LAN ports,and wireless connections.The versatile communication capabilities allow users to efficiently adapt the UC-2100-W Series for a variety of complex communications solutions running on a compact palm-sized computer.The UC-2100-W Series has a built-in Cortex-A8Arm-based processor that has been optimized for a variety of industrial solutions.With flexible interface options,this tiny embedded computer is a reliable and secure gateway for data acquisition and processing at field sites and is a useful communication platform for many other large-scale deployments.Models designed for wide-temperature applications are available for extreme environments such as those found in the Oil and Gas industry.Furthermore,all models use Moxa’s industrial-grade Linux platform,which provides optimized software features and superior long-term support.AppearanceUC-2114UC-2116SpecificationsComputerCPU Armv7Cortex-A81GHz DRAM512MB DDR3Storage Pre-installed8GB eMMCPre-installed OS Moxa Industrial Linux(Debian9,Kernel4.4)See /MILComputer InterfaceStorage Slot Micro SD Slot x1Ethernet Ports Auto-sensing10/100Mbps ports(RJ45connector)x1Auto-sensing10/100/1000Mbps ports(RJ45connector)x1Serial Ports RS-232/422/485ports x2,software selectable(DB9male)CAN Ports CAN2.0A/B x2(5-pin terminal block)Cellular Antenna Connector SMA x1GPS Antenna Connector UC-2116-T-LX:SMA x1Number of SIMs2SIM Format NanoConsole Port RS-232(TxD,RxD,GND),4-pin header output(115200,n,8,1)Buttons Reset buttonEthernet InterfaceMagnetic Isolation Protection 1.5kV(built-in)Serial InterfaceBaudrate50bps to921.6kbpsData Bits5,6,7,8Stop Bits1,1.5,2Parity None,Even,Odd,Space,MarkPull High/Low Resistor for RS-4851kilo-ohm,150kilo-ohmsESD Protection4kV,for all signalsFlow Control RTS/CTS,XON/XOFF,ADDC®(automatic data direction control)for RS-485,RTSToggle(RS-232only)Serial SignalsRS-232TxD,RxD,RTS,CTS,DTR,DSR,DCD,GNDRS-422Tx+,Tx-,Rx+,Rx-,GNDRS-485-2w Data+,Data-,GNDRS-485-4w Tx+,Tx-,Rx+,Rx-,GNDCAN InterfaceIndustrial Protocols CAN2.0A,CAN2.0BBaudrate10to1000kbpsIsolation2kV(built-in)Signals GND,CAN_L,CAN_SHLD,CAN_H,CAN_V+Cellular InterfaceBand Options LTE Bands:Band1(2100MHz)/Band2(1900MHz)/Band3(1800MHz)/Band4(1700MHz)/Band5(850MHz)/Band8(900MHz)/Band12(700MHz)/Band13(700MHz)/Band18(850MHz)/Band19(850MHz)/Band20(800MHz)/Band25(1900MHz)/Band26(850MHz)/Band28(700MHz)Carrier Approval:Verizon,AT&TLED IndicatorsSystem Power x1Programmable x1LAN2per port(10/100Mbps)Serial2per port(Tx,Rx)Wireless Signal Strength3CAN2per port(Tx,Rx)Power ParametersInput Voltage9to48VDCPower Consumption 5.8WInput Current0.6A@9VDC,0.12A@48VDCReliabilityAlert Tools External RTC(real-time clock)Automatic Reboot Trigger External WDT(watchdog timer)Physical CharacteristicsHousing MetalDimensions(with ears)111x99x34.5mm(4.37x3.90x1.36in)Weight396g(0.87lb)Installation Wall-mounting,DIN-rail mounting(with optional kit)Environmental LimitsOperating Temperature-40to75°C(-40to167°F)Storage Temperature(package included)-40to85°C(-40to185°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsSafety EN62368-1,IEC62368-1,UL62368-1EMC EN55032/24EMI CISPR32,FCC Part15B Class AEMS IEC61000-4-2ESD:Contact:4kV;Air:8kVIEC61000-4-3RS:80MHz to1GHz:3V/mIEC61000-4-4EFT:Power:1kV;Signal:0.5kVIEC61000-4-5Surge:Power:0.5kV;Signal:1kVIEC61000-4-6CS:3VIEC61000-4-8PFMFShock IEC60068-2-27Vibration2Grms@IEC60068-2-64,random wave,5-500Hz,1hr per axis(without any USBdevices attached)Hazardous Locations Class I Division2,ATEXCarrier Approvals VerizonAT&TGreen Product RoHS,CRoHS,WEEEMTBFTime UC-2114-T-LX:533,149hrsUC-2116-T-LX:496,650hrsStandards Telcordia(Bellcore)StandardWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x UC-2100-W Series computerInstallation Kit1x power jackCable1x console cableDocumentation1x quick installation guide1x warranty cardDimensionsUC-2114UC-2116Ordering InformationModel Name CPU RAM Storage Serial Ethernet CAN Cellular GPS Operating Temp.UC-2114-T-LX1000MHz512MB8GB22(1GigaLAN)2NB-IoT/Cat.M1–-40to75°CUC-2116-T-LX1000MHz512MB8GB22(1GigaLAN)2NB-IoT/Cat.M1Yes-40to75°CAccessories(sold separately)Power AdaptersPWR-12150-USJP-SA-T Locking barrel plug,12VDC1.5A,100to240VAC,US/JP plug,-40to75°C operating temperature PWR-12150-EU-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,EU plug,-40to75°C operating temperature PWR-12150-UK-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,UK plug,-40to75°C operating temperature PWR-12150-AU-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,AU plug,-40to75°C operating temperature PWR-12150-CN-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,CN plug,-40to75°C operating temperature CablesCBL-F9DPF1x4-BK-100Console cable with4-pin connector,1mAntennasANT-LTEUS-ASM-01GSM/GPRS/EDGE/UMTS/HSPA/LTE,1dBi,omnidirectional rubber-duck antennaANT-LTE-OSM-03-3m BK700-2700MHz,multiband antenna,specifically designed for2G,3G,and4G applications,3m cable ANT-LTE-ASM-04BK704to960/1710to2620MHz,LTE omnidirectional stick antenna,4.5dBiANT-LTE-OSM-06-3m BK MIMO Multiband antenna with screw-fastened mounting option for700-2700/2400-2500/5150-5850MHzfrequenciesANT-LTE-ASM-05BK704-960/1710-2620MHz,LTE stick antenna,5dBiDIN-Rail Mounting KitsDK35A DIN-rail mounting kit,35mm©Moxa Inc.All rights reserved.Updated Apr28,2022.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。

2100芯片
2100芯片是一种高性能的集成电路芯片，它具有强大的计算
能力和低功耗特性。

下面是对2100芯片的详细介绍。

2100芯片采用新一代工艺技术制造，具有先进的制程工艺和
设计，能够在较小的芯片面积上集成更多的功能单元，提供更高的性能。

该芯片主要面向高性能计算、人工智能、云计算等领域的应用，能够处理大规模的数据和复杂的算法。

2100芯片采用多核设计，每个核心都具有独立的算术逻辑单元、寄存器和缓存，可以同时执行多个指令，支持并行计算。

每个核心还具有独立的能源管理单元，可以根据负载情况实时调整电压和频率，实现动态功耗管理。

2100芯片集成了丰富的外设接口，包括通用串行总线、通用
并行总线、以太网接口、高速存储器接口等，可以与外部设备进行高速数据传输和通信。

此外，该芯片还支持硬件加速器和专用指令集，可以加速特定的计算任务，提高计算效率。

2100芯片采用先进的低功耗设计和优化，能够在高性能的同
时保持较低的功耗。

其功耗管理单元可以根据实时工作负载和功耗需求，在运行时动态调整电压和频率，以平衡性能和功耗。

这使得2100芯片在高性能计算和节能环境中表现出色。

总之，2100芯片是一种具有高性能和低功耗特性的集成电路
芯片，适用于高性能计算、人工智能和云计算等领域的应用。

它采用先进的制程工艺和设计，支持多核并行计算、丰富的外
设接口和硬件加速器，能够处理大规模的数据和复杂的算法。

同时，它还具有低功耗设计和功耗管理特性，能够在高性能的同时保持较低的功耗。

ME2188
■ 产品简介
系列芯片是采用CMOS 工艺制造的低静态电流的PFM 开关型同步整流DC/DC 升压转换器。

该
系列芯片采用先进的电路设计和制造工艺，极大地改善了开关电路固有的噪声问题，减小对周围电路的干扰，非常适合应用于电池供电的设备仪器。

■ 产品特点
■ 产品用途
■ 封装形式和管脚功能定义
● 1-3节电池供电的电子设备
● LED 手电筒、LED 灯、LED 背光源
● 无线鼠标、无线键盘、照相机、摄像机、PDA 、手持电话、电动玩具等便携设备
升压同步整流DC-DC
升压
■ 型号选择
■ 原理框图
同步整流DC-DC
■ 应用电路
■ 极限参数
注：极限参数是指无论在任何条件下都不能超过的极限值。

一旦超过此极限值，将有可能造成产品劣化等物理性损伤；同时在接近极限参数下，不能保证芯片可以正常工作。

升压同步整流DC-DC
■电学特性
■
Fig.1 Ci=100uF，Co=100uF，L1=47uH( 4X6)
升压同步整流DC-DC
Fig.3
Fig.4
Fig.5 RIN=100R,Co=100uF
Fig.2 RIN=100R,Co=100uF
R OP_SW
=(VIN-Vo)/Iout
Fig.7
R ON_SW =RIN*Vwave_L/(VIN-Vwave_L); RIN=10R,Co=100uF
Fig.6
升压同步整流DC-DC
ME2188C27
■ 特性曲线图 （M5G ）
3、输出电压 VS. 输出电流
升压同步整流DC-DC
■ 封装信息。

ME2188高效PFM 同步升压DC-DC 转换芯片概述ME2188是一系列高转换效率、低功耗、高工作频率的PFM 同步升压DC-DC 转换芯片。

芯片利用PFM 控制电路，根据负载电流大小自动切换占空比系数，可获得低纹波、高效率、宽输出电压范围的一系列产品。

芯片内置同步开关管及芯片的低消耗电流，有效的提高了DC-DC 的转换效率和设备的使用周期。

外围仅需要三个元件，就可以完成低输入电池电压升压到所需的工作电压。

特点 ● 高效率：93%● 低启动电压： 0.9V @IOUT=1mA ● 低静态电流：7uA ● 频率：320KHz● 可选输出电压：1.9V~5.0V ● 输出精度：±2% ● 输出电流：300mA ● 低纹波、低噪声 ● 同步整流应用场合 封装形式● 1~2节干电池的电子设备 ● 5-pin SOT23-5● 数码相机、LED 手电筒、LED 灯、血压计、 ● 3-pin SOT23、SOT23-3、SOT89-3、TO92 遥控玩具、无线耳机、无线鼠标键盘、医疗器械、汽车防盗器、充电器、VCR 、PDA 等手持电子设备典型应用图LX VOUTGNDME2188VINCIN10uFCOUT 100uFVOUT RLCEL22uF选购指南1. 产品型号说明产品功能:A/C/E/F ME 21 88封装形式:公司标识产品类别产品品种X GX 环保标识M3-SOT23-3M5-SOT23-5X-SOT23P-SOT89-3T-TO92X 产品电压值：33-3.3V产品型号 产品说明ME2188A33M3G V OUT =3.3V ，不带使能端，封装形式：SOT23-3 ME2188C33M5GV OUT =3.3V ，带使能端，封装形式：SOT23-5目前产品的电压值共有11种：2.2V 、2.3V 、2.5V 、2.7V 、2.8V 、3.0V 、3.3V 、3.6V 、3.7V 、4.5V 、5.0V 。

Ver 07ME2100APackageP–SOT89 M–SOT23Version or Function Feature Code27–2.7V 30–3.0V 33–3.3 50–5.0V …...MicronexxXProduct Type Product SeriesTYPE POSTFIX PACKAGESWITCHING TRANSISTORCEFUNCTIONFEATURESM3 SOT23-3 ME2100AxxP SOT89-3Build_inTransistor No Lx M3 SOT23-3ME2100BxxP SOT89-3Extemal Transistor No Ext M5 SOT23-5 ME2100CxxP5 SOT89-5Build_inTransistor Yes Lx+CE M5 SOT23-5 ME2100DxxP5 SOT89-5ExtemalTransistor Yes Ext+CE ME2100F M5 SOT23-5ExtemalTransistor No FBME2100 Series is a PFM Step-up DC/DCconverter IC with low supply current by CMOS process. High frequency noise that occurs during switching is reduced by using advanced circuit designed, output voltage is programmable in0.1V steps between 2.0~7.0V and maximum frequency is 100KHz(Typ.). A low ripple, highefficiency step-up DC/DC converter can be constructed of ME2100Xxx with only threeexternal components. Also available is aCE(chip enable) function that reduce powerdissipation During shut-down mode. ME2100Xxx is suitable for use with battery-powered instruments with low noise andlow supply current.• Power source for battery-poweredequipment ；• Power source for wireless mouse, wireless keyboard, toys, cameras, camcorders, VCRs, PDAs, and hand-held communication equipment ； • Power source for appliances which require higher cell voltage than that of batteries used in the appliances 。

SummaryMicrochip SmartIOC 2100 SAS I/O Controller products provide reliable ultra-high perfor-mance HBA functionality with industry-leading low-power operation. These SmartIOCs provide unparalleled flexibility along with a broad range of standard features designed to meet the most demanding server storage applications.These SmartIOC controllers offer optional entry-level hardware RAID 0/1/10/5 modes without any external DRAM. The 24- and 16-port devices also offer additional dedicated RAID-capable boot ports.The controllers support Microchip Smart Storage Solution drivers for all major operating systems and a comprehensive set of management tools, including a GUI and CLI.12 Gbps SmartIOC 2100 SAS IO ControllersPM8222, PM8225, PM8238, PM8239, PM8242 and PM8243FeaturesHBA Features• Persistent logging and binding• Up to 1.6M IOPS performance for PM8242, PM8243, PM8238, PM8239 and up to 1.4M IOPS performance for PM8222, PM8225 (4K random reads)• Up to 6.9 GB/s bandwidth• Transport Layer Retry (TLR) support • Multi-initiator (host)/clustering for SAS • TRIM and UNMAP support for SSDs• SAS dual path failover (RAID stack managed Active/Standby)• Baseboard Management Controller (BMC) support with Management Component Transport Protocol (MCTP) over PCIe or I 2C• 4K native sector support • Hot plug drive support• Adapter power management modes • S.M.A.R.T. diagnostic access • SMP commands using ARCONF• Supports eight lanes of PCIe 3.0 to the host, each lane supporting PCIe Gen 3 rates up to 8.0 Gbps• Enclosure Management: SES-2/3 SGPIO: SFF-8485 IBPI: SFF-8489 SGPIO as a virtual SES enclosure: SFF-8448Entry-Level RAID Features• Flexible configuration for RAID mode • Dynamic sector repair • Multiple LUN support• Support for up to 238 raw devices• Support for up to 32 target devices in RAID mode• Supports up to eight SAS/SATA Logical/RAID volumes • Split mirror and combine • Copyback hot spare• Displays raw devices on connector • RAID build modes •Quick initialization• Background initialization • Rapid parity initialization • Heal array and move array • Bootable array support • Erase drive• Configurable stripe size • Bad stripe marking• Hot spare support (dedicated, global, or predictive)• Persistent logging for RAID and HBA •4K native sector support in RAIDMicrochip Storage Management Utilities maxView TM provides both server-based and remote admin-istration. This fully browser-based tool supports all standard browsers and is available through a USB boot image. maxView controller management components include:• maxView GUI• ARCCONF CLI• Event Monitor (event logging and email alerts)• VSphere plug-in• OpenStack plug-in• Smart Storage Administrator CLIHighlights• Industry-leading throughput• Compatible with Microchip Smart Storage solution drivers for all major operating systems and their unified manage-ment utilities• Two additional 6G SAS/SATA boot ports with RAID 1 sup-port included in 24 and 16 port configurations• RAID 0, 1, 10, 5 with hardware acceleration and no ad-ditional host software requirements• No DDR memory required, regardless of mode• The PM8243, PM8239, PM825 include support for maxCrypto™ controller-based encryptionTools for Setup and Troubleshooting Microchip provides a complete suite of design-in collateral to support embedded designs with this product including: refer-ence designs, detailed hardware specifications and design-in guides.• UEFI HII configuration tool• CTRL-A Legacy BIOS configuration tool• ChipLink diagnostic tools• Extensive debug, diagnostics, configuration and analy-sis tools with an intuitive GUI• Access to configuration data, management capabili-ties, and signal integrity analysis tools such as real-time eye capture• Connects to device over UART Operating System Support• Extensive operating system support includes major software releases for Windows®/Server, VMware ESXi, Red Hat Enterprise Linux®, SUSE Enterprise Linux, Ubuntu, CentOS, XenServer, Fedora, Debian, and Solaris• Certification for Microsoft WHQL, VMware IOVP and VMware VSAN High-Speed I/O• x8 PCIe Gen 3 8 GT/s• PCIe link rates supported: 8 GT/s, 5 GT/s, 2.5 GT/s• PCIe-compliant link training and manual PHYconfiguration• PM8243/PM8242: 24x SAS-3/SATA PHYs for high-speed targets• PM8239/PM8238: 16x SAS-3/SATA PHYs for high-speed targets• PM8222/PM8225: 8x SAS-3/SATA PHYs for high-speed targets• SAS or SATA operation on a per-PHY basis• SAS link rates supported: 12 Gbps, 6 Gbps, 3 Gbps• SATA link rates supported: 6 Gbps, 3 Gbps, 1.5 Gbps • PM8241/PM8242 and PM8239/PM8238: 2x SAS-2/SATA PHYs for boot devices• Independent per-channel selectable high-speed outputs support multiple programmable levels of pre-emphasis and output swing• Multiple programmable levels of receive equalization • Integrated resistive termination• Automatic negotiation of link speed• Decision Feedback Equalizer provides robust recovery of 12 Gbps SAS signals over lossy channels Peripheral I/O Interfaces• PM8241/PM8240 and PM8237/PM8236: Eight multi-master and seven master-only Two-Wire Interfaces (TWIs)• PM8205/PM8204: Seven multi-master and two master-only TWIs• TWIs support variable bit rates up to 400 Kbps• Two industry-standard 16750 UARTs• Seven SFF-8485-compliant Serial GPIO (SGPIO) ports • Up to 30 GPIO ports depending on SGPIO port configuration• Firmware API for peripheral control including features such as activity LED, UART configuration, zoning configuration, interprocessor communications and enclosure control Note: Some peripheral I/O interface pins are multiplexed. maxCrypto Encryption(PM8243, PM8239, PM825 Only)• AES data encryption and decryption with key sizes of 128/196/256The Microchip name and logo and the Microchip logo are registered trademarks, and maxCrypto and maxView are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. All other trademarks mentioned herein are property of their respective companies.© 2019, Microchip Technology Incorporated. All Rights Reserved. 8/19 DS00003021AExample ApplicationEfficient SDS for Hyperscale Data Centers• Support for high-density single-controller configurations• Up to 24 ports + 2 additional boot ports • Hardware RAID 1 on boot devices• Lower power and higher performance than multi-controller designs • No external memory required• Hardware-based value RAID 5 available• Support for vSAN and Storage Spaces DirectStorage PortsPM8243A-F3EI (with encryption)For More Informationhttps:///product-directory/smart-storage-platform/4097-12g-smartioc-2100-controllersx4SAS-3x4SAS-3。

GEPON SERIESNEC’s ME2100Optical Line Terminal (OLT) provides a direct optical interface to the Ethernet/IP network core. Together with NEC’s Optical Network Unit (ONU), it completes the end-to-end optical last mile with up to 1 Gbps of bandwidth to residential and business customers. Combining the economic benefits of Ethernet Passive Optical Network (GEPON) with built-in L2/L3 switching and routing functionalities, the ME2100’s is an optimal transport platform for bandwidth-intensive triple play services.KEY BENEFITSCost-effective Triple Play TransportME2100supports up to 8 PON links, each delivering 1 Gbps of shared bandwidth between up to 64 subscribers, serving a maximum of 512 subscribers from a compact 1U chassis. High subscriber density and low cost of entry, combined with the operational cost savings of passive GEPON technology make ME2100a compelling alternative to legacy, last-mile access solutions.Customized Broadband Service OfferingsME2100’s QoS features allow operators to oversubscribe bandwidth while protecting delay-sensitive traffic based on individualized Service Level Agreement (SLA). Dynamic bandwidth allocation enables operators to bill bandwidth in 1 Mbps increments. For video services, IGMP support allows for multicast control and ensures efficient utilization of network infrastructure.Flexible Provisioning, Quick to RevenuePowerful OAM functions enable remote diagnostics, flexible provisioning, and reconfiguration of the ME2100platform.KEY FEATURESIEEE 802.3AH GEPON32 SPLITS, 20KM REACH64 SPLITS,10KM REACH512 SUBSCRIBERS SERVED IN COMPACT 1U CHASSIS ADVANCED L2/L3FUNCTIONS DYNAMIC BANDWIDTH ALLOCATION INDIVIDUALIZED BILLING PER SERVICE LEVEL AGREEMENT MULTICAST SUPPORT FOR VIDEO STREAMINGREMOTE PROVISIONING AND MANAGEMENTADVANCED SECURITYME2100CARRIER GRADE OPTICAL ACCESS PLATFORM COMPACT GIGABIT ETHERNET PASSIVE OPTICAL NETWORK (GEPON) PLATFORM DELIVERS HIGH-SPEED VOICE, DATA AND VIDEO SERVICES TO RESIDENTIAL AND BUSINESS Subscribers OPTICAL LINE TERMINAL (OLT)Technical SpecificationsBefore installing, connection or using this product, be sure to carefully read and observe the cautionary and prohibited matters provided in the instruction manual.Safety Precautionsy The company names and product names given in this catalog are trademarks or registered trademarks of the respective companies.y The configuration or specifications are subject to change without prior notice due to continual improvements.!For inquiries, contact :Published by:NEC CorporationGlobal Network DivisionIssue 1.0 APRIL.2008•IEEE 802.3ad link aggregation and load balance •Packet mirroring per ingress/egress port•STP (IEEE 802.1d), RSTP(IEEE 802.1w) and PVST+ Support •16K MAC table support•MAC management( Learning control, limit and aging) support •802.1X support for ONU AAALAYER 3 ROUTING FUNCTIONS•L3 switching and full line speed support •Static Route•ARP support( static ARP, proxy ARP per RFC1027,ARP per RFC826)•TCP/IP, ICMP per RFC792 support •DHCP server/relayMULTICAST FEATURES•IGMPv1/v2 snooping and Proxy •Fast Leave•Up to 512 Multicast groupsQUALITY OF SERVICE•Up to four CoS queues per subscriber •Strict Priority and WRR Scheduling •IEEE 802.1 p •IPv4 TOS priority •Egress rate shaping•Upstream Dynamic Bandwidth Allocation (DBA) per ONU •Downstream Bandwidth Control per ONU SECURITY•Access Control List (ACL)•Global and Per VLAN User Isolation•EPON Frame Encryption: AES128(Future)•Broadcast/Multicast/DLF storm control USER AUTHENTICATION •IEEE 802.1x/RadiusSYSTEM MANAGEMENT•FTP, SNMP v1 & v2c, DHCP, Telnet, console interface with CLI •In-Band/Out-of-band management •Auto provision of ONUs •Environmental monitoringCERTIFICATION•UL, VCCI ,CE, FCC Part 15 ClassA, MICENVIRONMENTAL SPECIFICATIONS OPERATING TEMPERATURE•0ºC to +50ºC (Continuous)RELATIVE HUMIDITY•5% to 90% non condensing STORAGE TEMPERATURE •–40 to +75ºCSTORAGE HUMIDITY •75% (maximum)HARDWAREMAIN CHASSIS•PHYSICAL DIMENSION:482.6mm (W) x 280mm (D) x 43.6mm (H)•WEIGHT: 12 Pounds•Power consumption of each module: Max.30 Watt•Power consumption of chassis with two LTM modules: Maximum 100 Watts•Power supply: DC:–36V to -72V, 2 pluggable -48V DC power module for redundancy protection•Architecture: 2 pluggable OLT module, hot swappable 1 pluggable GSM module, 1 pluggable Fan module •Console Port: 1 RS232•LAN management: 1 RJ45 10/100Base-T Fast Ethernet •UP Link Ports: 4 SFP Connectors for insertion of either electrical or optical transceivers MTBF•GSM2Module: 269,944Hours •Power Module: 2,362,686 Hours •Fan Tray: 678,978 Hours •LTM: 437,523HoursAVAILABLE MODULES•Controller and Switch Module: GSM/GSM2. One Per Chassis •OLT Module: LTM4/LTM6: Up to 2 per Chassis •Power Modules: PWR: Up to 2 per Chassis •FAN Tray: 1 Per Chassis AVAILABLE CONFIGURATIONS PMC BASED•PWR, FAN, LTM4 and GSM CORTINA BASED•PWR, FAN, LTM6 and GSM2OLT MODULE•NUMBER OF OLT PORT: 4 port/Module; 8 port /Chassis •COMPLIANCE: IEEE802.3ah•OPTICAL FIBER: Single SMF Fiber •CONNECTOR: SC Connector•SPLITS PER OLT PORT: 1:32 ; 1:64•DATA RATE: 1 Gbps up and down stream •OPTICAL LOSS BUDGET: 29 dB for PON link •WAVELENGTH: Tx: 1490 nm, Rx: 1310 nmADVANCED FEATURESLAYER 2 SWITCHING FUNCTIONS •Non-blocking line rate switching•Port based VLAN , protocol based VLAN and 802.1q VLAN •Per ONU Q in Q support。
