CSNE151中⽂资料Representative photograph, actual product appearance may vary.Due to regional agency approval requirements, some products may not be available in your area. Please contact your regional Honeywell office regarding your product of choice. CSNE151CSN Series closed loop current sensor, measures AC, DC or impulse current, 25 amp-turns nominal, ± 36 amp-turns range, smaller housing, 1000 turnFeaturesCurrent sensing up to 1200 ampsMeasures ac, dc and impulse currentsCompetitive cost/performance ratioRapid responseHigh overload capabilityHigh level of electrical isolation between primary and secondary circuitsIndustrial operating temperature rangeSmall size and weightTypical ApplicationsVariable speed drivesOvercurrent protectionGround fault detectorsCurrent feedback control systemsRoboticsUPS and telecommunication power suppliesWelding power suppliesAutomotive - Battery management systemsWattmetersDescriptionThe CSN Series of closed loop current sensors are based on the principles of the Magnetoresistive or Hall effects, and the null balance or zero magnetic flux method (feedback system). The magnetic flux in the sensor core is constantly controlled at zero. The amount of current required to balance zero flux is the measure of the primary current flowing through the conductor, multiplied by the ratio of the primary to secondary windings. This closed loop current is the output from the device and presents an image of the primary current reduced by thenumber of secondary turns at any time. This current can be expressed as a voltage by passing it through a resistor.CSNE151CSN Series closed loop current sensor, measures AC, DC or impulse current, 25 amp-turns nominal, ± 36 amp-turns range, smaller housing, 1000 turnProduct SpecificationsSensor Type Closed Loop LinearSensed Current Type ac or dcSensed Current Range± 36 APackage Style Series Connect PCB MountOutput Type CurrentMaximum Continuous Current± 36 ASupply Current± 10 mA + outputSupply Voltage± 15.0 VdcOffset Current< ± 0.15 mAOffset Current Drift< ± 0.6 mACoil Resistance @ 70 °C110 OhmResponse Time< 1 µsCoil Turns1000Output Nominal25 mAOperating Temperature Range0 °C to 70 °C [32 °F to 158 °F]Storage Temperature Range-40 °C to 90 °C [-40 °F to 194 °F]Minimum Measuring Resistance100 OhmMaximum Measuring Resistance320 OhmHousing Material Glass-filled PBT (UL94-V0)Mounting PCB on 13 pinsPinout Style 5 pinAccuracy± 0.5 %Availability GlobalComment Standard 25 A sensor with 5 integral primary turns. UNSPSC Code411121UNSPSC Commodity411121 TransducersSeries Name CSN SeriesCSNE151CSN Series closed loop current sensor, measures AC, DC or impulse current, 25 amp-turns nominal, ± 36 amp-turns range, smaller housing, 1000 turnCSNE151CSN Series closed loop current sensor, measures AC, DC or impulse current, 25 amp-turns nominal, ± 36 amp-turns range, smaller housing, 1000 turn PERSONAL INJURYDO NOT USE these products as safety or emergency stop devices, or in any other application where failure of the product could result in personal injury.Failure to comply with these instructions could result in death or serious injury.MISUSE OF DOCUMENTATIONThe information presented in this product sheet (or catalog) is for reference only.DO NOT USE this document as product installation information.Complete installation, operation and maintenance information is provided in the instructions supplied with each product. Failure to comply with these instructions could result in death or serious injury.Copyright Honeywell Inc.1998-2006 All rights reserved.。
MF Series§ High Temperature Tolerance§ High Solvent Resistance§ Low EMI§ Typical Reel Size 1500pcsECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1303 SeriesMF1303T-R100.10 @25.2 MHz J,K 406800.081380MF1303T-R120.12 @25.2 MHz J,K 406400.091300MF1303T-R150.15 @25.2 MHz J,K 386000.101230MF1303T-R180.18 @25.2 MHz J,K 355500.121120MF1303T-R220.22 @25.2 MHz J,K 335100.141040MF1303T-R270.27 @25.2 MHz J,K 334300.16975MF1303T-R330.33 @25.2 MHz J,K 304100.22830MF1303T-R390.39 @25.2 MHz J,K 303650.30710MF1303T-R470.47 @25.2 MHz J,K 303300.35660MF1303T-R560.56 @25.2 MHz J,K 303000.50550MF1303T-R680.68 @25.2 MHz J,K 282750.60500MF1303T-R820.82 @25.2 MHz J,K 282500.85420MF1303T-1R0 1.0 @25.2 MHz J,K 25230 1.00390MF1303T-1R2 1.2 @7.96 MHz J,K 251500.18620MF1303T-1R5 1.5 @7.96 MHz J,K 281400.22560MF1303T-1R8 1.8 @7.96 MHz J,K 301250.30480MF1303T-2R2 2.2 @7.96 MHz J,K 301150.40415MF1303T-2R7 2.7 @7.96 MHz J,K 371000.55355MF1303T-3R3 3.3 @7.96 MHz J,K 45900.85285MF1303T-3R9 3.9 @7.96 MHz J,K 4580 1.00263MF1303T-4R7 4.7 @7.96 MHz J,K 4575 1.20239MF1303T-5R6 5.6 @7.96 MHz J,K 5065 1.80195MF1303T-6R8 6.8 @7.96 MHz J,K 5060 2.00185MF1303T-8R28.2 @7.96 MHz J,K 5555 2.70160MF1303T-10010 @7.96 MHz J,K 5550 3.30144MF1303T-12012 @2.52 MHz J,K 4540 2.70160MF1303T-15015 @2.52 MHz J,K 4535 2.80157MF1303T-18018 @2.52 MHz J,K 5030 3.10149MF1303T-22022 @2.52 MHz J,K 5025 3.30144MF1303T-27027 @2.52 MHz J,K 5020 3.50140MF1303T-33033 @2.52 MHz J,K 4524 3.40130MF1303T-39039 @2.52 MHz J,K 4522 3.60125MF1303T-47047 @2.52 MHz J,K 4520 4.50110MF1303T-56056 @2.52 MHz J,K 4518 5.70100MF1303T-68068 @2.52 MHz J,K 5015 6.7092MF1303T-82082 @2.52 MHz J,K 50147.3088MF1303T-101100 @2.52 MHz J,K 50138.0084MF1303T-121120 @ 0.796 MHz J,K 301213.066MF1303T-151150 @ 0.796 MHz J,K 301115.061MF1303T-181180 @ 0.796 MHz J,K 301017.057MF1303T-221220 @ 0.796 MHzJ,K30921.052TOLERANCES J=5%; K= 10%.** = Test Frequency as specified in ‘L’ columnECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1303 Series Continued…MF1303T-271270 @ 0.796 MHz J,K 30825.047MF1303T-331330 @ 0.796 MHz J,K 30728.045MF1303T-391390 @ 0.796 MHz J,K 30 6.535.040MF1303T-471470 @ 0.796 MHz J,K 30642.036MF1303T-561560 @ 0.796 MHz J,K 30546.035MF1303T-681680 @ 0.796 MHz J,K 30 4.260.030MF1303T-821820 @ 0.796 MHz J,K 30 3.865.029MF1303T-1021000 @ 0.796 MHzJ,K303.472.028MF1304 SeriesMF1304T-R150.15 @25.2 MHz J 505250.032740MF1304T-R180.18 @25.2 MHz J 504800.042580MF1304T-R220.22 @25.2 MHz J 504500.052020MF1304T-R270.27 @25.2 MHz J 454000.071740MF1304T-R330.33 @25.2 MHz J 453600.091580MF1304T-R390.39 @25.2 MHz J 453300.111450MF1304T-R470.47 @25.2 MHz J 453100.121370MF1304T-R560.56 @25.2 MHz J 502800.131390MF1304T-R680.68 @25.2 MHz J 502500.151220MF1304T-R820.82 @25.2 MHz J 502200.221020MF1304T-1R0 1.0 @25.2 MHz J 502000.29880MF1304T-1R2 1.2 @7.96 MHz J 331800.42730MF1304T-1R5 1.5 @7.96 MHz J 331600.50670MF1304T-1R8 1.8 @7.96 MHz J 331500.65590MF1304T-2R2 2.2 @7.96 MHz J 331350.95485MF1304T-2R7 2.7 @7.96 MHz J 33120 1.20430MF1304T-3R3 3.3 @7.96 MHz J 33110 2.00335MF1304T-3R9 3.9 @7.96 MHz J 33100 2.30310MF1304T-4R7 4.7 @7.96 MHz J 3390 2.60294MF1304T-5R6 5.6 @7.96 MHz J 45600.32565MF1304T-6R8 6.8 @7.96 MHz J 50550.50450MF1304T-8R28.2 @7.96 MHz J 50500.60410MF1304T-10010 @7.96 MHz J 55450.90335MF1304T-12012 @2.52 MHz J 6542 1.10305MF1304T-15015 @2.52 MHz J 6540 1.40271MF1304T-18018 @2.52 MHz J 7534 2.25213MF1304T-22022 @2.52 MHz J 7530 2.50202MF1304T-27027 @2.52 MHz J 6025 2.60198MF1304T-33033 @2.52 MHz J 6519 3.00185MF1304T-39039 @2.52 MHzJ60142.60198TOLERANCES J=5%; K= 10%; M=20%.** = Test Frequency as specified in ‘L’ columnECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1304 Series continued…MF1304T-47047 @2.52 MHz J 5513 2.75193MF1304T-56056 @2.52 MHz J 5512 3.00184MF1304T-68068 @2.52 MHz J 5511 3.30176MF1304T-82082 @2.52 MHz J 5010 3.90162MF1304T-101100 @2.52 MHz J 509.5 4.50151MF1304T-121120 @ 0.796 MHz J 658.7 5.20140MF1304T-151150 @ 0.796 MHz J 658 6.05130MF1304T-181180 @ 0.796 MHz J 658 6.05130MF1304T-221220 @ 0.796 MHz J 65 6.27.45117MF1304T-271270 @ 0.796 MHz J 65 5.711.0143MF1304T-331330 @ 0.796 MHz J 65 5.112.0136MF1304T-391390 @ 0.796 MHz J 65 4.516.3117MF1304T-471470 @ 0.796 MHz J 65 3.917.9112MF1304T-561560 @ 0.796 MHz J 65 3.819.5107MF1304T-681680 @ 0.796 MHz J 65 3.127.291MF1304T-821820 @ 0.796 MHz J 65 2.730.086MF1304T-1021000 @ 0.796 MHzJ652.333.082MF1501 SeriesMF1501T-R100.10 @25.2 MHz J 502500.0251790MF1501T-R120.12 @25.2 MHz J 502500.0341530MF1501T-R150.15 @25.2 MHz J 502500.0371470MF1501T-R180.18 @25.2 MHz J 502500.0471300MF1501T-R220.22 @25.2 MHz J 502500.0671100MF1501T-R270.27 @25.2 MHz J 452500.11855MF1501T-R330.33 @25.2 MHz J 452500.13788MF1501T-R390.39 @25.2 MHz J 452500.18670MF1501T-R470.47 @25.2 MHz J 452350.25565MF1501T-R560.56 @25.2 MHz J 402100.33490MF1501T-R680.68 @25.2 MHz J 401900.45420MF1501T-R820.82 @25.2 MHz J 401800.59370MF1501T-1R0 1.0 @25.2 MHz J 451400.071070MF1501T-1R2 1.2 @7.96 MHz J 451300.10895MF1501T-1R5 1.5 @7.96 MHz J 451150.12815MF1501T-1R8 1.8 @7.96 MHz J 451050.14775MF1501T-2R2 2.2 @7.96 MHz J 451000.19650MF1501T-2R7 2.7 @7.96 MHz J 45920.28535MF1501T-3R3 3.3 @7.96 MHz J 45850.35480MF1501T-3R9 3.9 @7.96 MHz J 45750.40450MF1501T-4R74.7 @7.96 MHzJ45700.55380TOLERANCES J=5%; K= 10%; M=20%.** = Test Frequency as specified in ‘L’ columnECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1501 Series continued…MF1501T-5R6 5.6 @7.96 MHz J 45650.72335MF1501T-6R8 6.8 @7.96 MHz J 5055 1.02280MF1501T-8R28.2 @7.96 MHz J 5050 1.32250MF1501T-10010 @7.96 MHz J 5046 1.62220MF1501T-12012 @2.52 MHz J 5544 2.00200MF1501T-15015 @2.52 MHz J 45490.80315MF1501T-18018 @2.52 MHz J 45450.89300MF1501T-22022 @2.52 MHz J 45410.96290MF1501T-27027 @2.52 MHz J 4538 1.19260MF1501T-33033 @2.52 MHz J 4534 1.37240MF1501T-39039 @2.52 MHz J 5029 1.93205MF1501T-47047 @2.52 MHz J 5027 2.11195MF1501T-56056 @2.52 MHz J 5025 2.23190MF1501T-68068 @2.52 MHz J 5021 2.70170MF1501T-82082 @2.52 MHz J 5010.5 2.44180MF1501T-101100 @2.52 MHz J 5010 3.12160MF1501T-121120 @ 0.796 MHz J 559.7 3.60150MF1501T-151150 @ 0.796 MHz J 558.5 4.10140MF1501T-181180 @ 0.796 MHz J 558 4.40135MF1501T-221220 @ 0.796 MHz J 557.5 5.00125MF1501T-271270 @ 0.796 MHz J 557 5.80115MF1501T-331330 @ 0.796 MHz J 55 6.5 6.40110MF1501T-391390 @ 0.796 MHz J 60 6.27.40105MF1501T-471470 @ 0.796 MHz J 60 5.79.5092MF1501T-561560 @ 0.796 MHz J 60 4.710.5090MF1501T-681680 @ 0.796 MHz J 60 4.511.880MF1501T-821820 @ 0.796 MHz J 60 4.213.080MF1501T-1021000 @ 0.796 MHz J 60 3.817.570MF1501T-1221200 @ 0.252 MHz J 45 1.522.160MF1501T-1521500 @ 0.252 MHz J 45 1.226.555MF1501T-1821800 @ 0.252 MHz J 45 1.029.950MF1501T-2222200 @ 0.252 MHz J 450.9733.850MF1501T-2722700 @ 0.252 MHz J 450.9247.340MF1501T-3323300 @ 0.252 MHz J 450.8453.040MF1501T-3923900 @ 0.252 MHz J 450.8073.835MF1501T-4724700 @ 0.252 MHz J 450.7481.631MF1501T-5625600 @ 0.252 MHz J 450.7398.928MF1501T-6826800 @ 0.252 MHz J 400.6611127MF1501T-8828200 @ 0.252 MHz J 400.5411926MF1501T-10310000 @ 0.252 MHzJ400.4713724TOLERANCES J=5%; K= 10%; M=20%.** = Test Frequency as specified in ‘L’ columnECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1302 SeriesMF1302T-R150.15 @25.2 MHz J,K 505100.0303050MF1302T-R180.18 @25.2 MHz J,K 504750.0322980MF1302T-R220.22 @25.2 MHz J,K 504150.0352800MF1302T-R270.27 @25.2 MHz J,K 503800.0502400MF1302T-R330.33 @25.2 MHz J,K 503500.0652000MF1302T-R390.39 @25.2 MHz J,K 503200.0801850MF1302T-R470.47 @25.2 MHz J,K 503000.0851700MF1302T-R560.56 @25.2 MHz J,K 502700.1251450MF1302T-R680.68 @25.2 MHz J,K 452500.0151300MF1302T-R820.82 @25.2 MHz J,K 402100.2051100MF1302T-1R0 1.0 @25.2 MHz J,K 402000.290930MF1302T-1R2 1.2 @7.96 MHz J,K 301800.400785MF1302T-1R5 1.5 @7.96 MHz J,K 301700.485700MF1302T-1R8 1.8 @7.96 MHz J,K 301500.740550MF1302T-2R2 2.2 @7.96 MHz J,K 301400.970505MF1302T-2R7 2.7 @7.96 MHz J,K 30120 1.200460MF1302T-3R3 3.3 @7.96 MHz J,K 30700.140990MF1302T-3R9 3.9 @7.96 MHz J,K 30650.155870MF1302T-4R7 4.7 @7.96 MHz J,K 30600.210745MF1302T-5R6 5.6 @7.96 MHz J,K 30500.280645MF1302T-6R8 6.8 @7.96 MHz J,K 30500.375560MF1302T-8R28.2 @7.96 MHz J,K 30480.440540MF1302T-10010 @7.96 MHz J,K 30420.605440MF1302T-12012 @2.52 MHz J,K 5036 1.05370MF1302T-15015 @2.52 MHz J,K 5530 1.20310MF1302T-18018 @2.52 MHz J,K 6030 1.95255MF1302T-22022 @2.52 MHz J,K 6024 2.20240MF1302T-27027 @2.52 MHz J,K 6522 2.75205MF1302T-33033 @2.52 MHz J,K 5518 2.30300MF1302T-39039 @2.52 MHz J,K 5516 2.50285MF1302T-47047 @2.52 MHz J,K 5514 3.40245MF1302T-56056 @2.52 MHz J,K 4514 4.10225MF1302T-68068 @2.52 MHz J,K 4511 4.20220MF1302T-82082 @2.52 MHz J,K 459.3 4.40215MF1302T-101100 @2.52 MHz J,K 458.5 4.90205MF1302T-121120 @ 0.796 MHz J,K 607.3 5.40195MF1302T-151150 @ 0.796 MHz J,K 60 6.2 6.20180MF1302T-181180 @ 0.796 MHzJ,K605.77.10170TOLERANCES J=5%; K= 10%; M=20%.** = Test Frequency as specified in ‘L’ columnECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1302 Series Continued…MF1302T-221220 @ 0.796 MHz J,K 60 5.27.90160MF1302T-271270 @ 0.796 MHz J,K 65 5.68.20110MF1302T-331330 @ 0.796 MHz J,K 65 5.09.10105MF1302T-391390 @ 0.796 MHz J,K 65 4.510.0100MF1302T-471470 @ 0.796 MHz J,K 65 4.011.195MF1302T-561560 @ 0.796 MHz J,K 65 3.612.391MF1302T-681680 @ 0.796 MHz J,K 60 3.413.785MF1302T-821820 @ 0.796 MHz J,K 60 3.115.181MF1302T-1021000 @ 0.796 MHzJ,K602.816.578MF1309 SeriesMF1309T-1R0 1.0 @25.2 MHz J,K 652000.141900MF1309T-1R2 1.2 @7.96 MHz J,K 401800.191640MF1309T-1R5 1.5 @7.96 MHz J,K 401600.281340MF1309T-1R8 1.8 @7.96 MHz J,K 401500.371160MF1309T-2R2 2.2 @7.96 MHz J,K 401350.501000MF1309T-2R7 2.7 @7.96 MHz J,K 401200.65875MF1309T-3R3 3.3 @7.96 MHz J,K 40105 1.00710MF1309T-3R9 3.9 @7.96 MHz J,K 40100 1.20645MF1309T-4R7 4.7 @7.96 MHz J,K 4090 1.80530MF1309T-5R6 5.6 @7.96 MHz J,K 35550.131960MF1309T-6R8 6.8 @7.96 MHz J,K 35500.201580MF1309T-8R28.2 @7.96 MHz J,K 35440.221510MF1309T-10010 @7.96 MHz J,K 35420.261380MF1309T-12012 @2.52 MHz J,K 45340.451060MF1309T-15015 @2.52 MHz J,K 45320.52980MF1309T-18018 @2.52 MHz J,K 50280.70840MF1309T-22022 @2.52 MHz J,K 6024 1.00705MF1309T-27027 @2.52 MHz J,K 6022 1.30620MF1309T-33033 @2.52 MHz J,K 6020 1.50575MF1309T-39039 @2.52 MHz J,K 7016 2.00500MF1309T-47047 @2.52 MHz J,K 10018 2.20475MF1309T-56056 @2.52 MHz J,K 10016 2.30465MF1309T-68068 @2.52 MHz J,K 10014 3.00465MF1309T-82082 @2.52 MHz J,K 10012.5 3.50375MF1309T-101100 @2.52 MHz J,K 9511 3.80365MF1309T-121120 @ 0.796 MHz J,K 9010 4.20345MF1309T-151150 @ 0.796 MHz J,K 758.3 5.00315MF1309T-181180 @ 0.796 MHzJ,K8065.30305TOLERANCES J=5%; K= 10%; M=20%.** = Test Frequency as specified in ‘L’ columnECM Electronics Limited, Penmaen House, Ashington, West Sussex, RH20 3JR, UKECM PartL (µH)Tol %Q Min.(**MHz)SRF Min.(MHz)R DC MAX (Ω)I DC I N(mA)MF1309 Series Continued…MF1309T-221220 @ 0.796 MHz J,K 80 5.5 5.90290MF1309T-271270 @ 0.796 MHz J,K 805 6.60275MF1309T-331330 @ 0.796 MHz J,K 75 4.27.20260MF1309T-391390 @ 0.796 MHz J,K 75 3.98.60240MF1309T-471470 @ 0.796 MHz J,K 80 3.69.00235MF1309T-561560 @ 0.796 MHz J,K 80 3.49.70225MF1309T-681680 @ 0.796 MHz J,K 75 3.110.0220MF1309T-821820 @ 0.796 MHz J,K 70 2.612.0200MF1309T-1021000 @ 0.796 MHz J,K 75 2.615.0180MF1309T-1221200 @ 0.252 MHz J,K 60 2.318.0165MF1309T-1521500 @ 0.252 MHz J,K 70 2.121.0150MF1309T-1821800 @ 0.252 MHz J,K 70 2.023.0145MF1309T-2222200 @ 0.252 MHz J,K 75 1.726.0135MF1309T-2722700 @ 0.252 MHz J,K 75 1.433.0120MF1309T-3323300 @ 0.252 MHz J,K 65 1.239.0110MF1309T-3923900 @ 0.252 MHz J,K 65 1.044.0105MF1309T-4724700 @ 0.252 MHz J,K 650.964.085MF1309T-5625600 @ 0.252 MHz J,K 650.8568.085MF1309T-6826800 @ 0.252 MHz J,K 600.8070.082MF1309T-8228200 @ 0.252 MHz J,K 700.7572.080MF1309T-10310000 @ 0.252 MHz J,K700.7076.080TOLERANCES J=5%; K= 10%; M=20%.** = Test Frequency as specified in ‘L’ columnCustomers specifications also welcome。
