中联重科泵车电器原理图信及元件说明
SANY标准化小组 #QS8QHH-HHGX8Q8-GNHHJ8-HHMHGN# 中联重科泵车电器原理图信号及元件说明 ZOOMLION TRUCK PUMP ELECTRICAL PRINCIPLE DIAGRAM SIGNAL & ELEMENT DESCRIPTION 第一页 遥控系统 Page 1 control system
302：遥控器电源的正极。当电控柜面/遥转换开关拨到遥控侧，并且支腿/臂架转换开关拨到臂架侧时，302号线有电。 302: The anode of remote control power supply. When choosing remote control by panel/remote switch, on condition that outrigger/boom switch is to the boom side, the cable 302 is with power. 6：遥控器电源的负极。与电控柜内的接地线相连接。 6: The cathode of remote control power supply, connecting to the ground in the electric cabinet. NA、NB、REL4：遥控器内部开关，当遥控器的发射器开启后，这两个开关闭合。 NA、NB、REL4：internal switch in the remote control, which close when the emitter opened. 101：操作顺回转时，101号线有电流输出，控制顺回转动作，臂架动作的快慢由电流的大小决定。 101：When operation clockwise slewing, the 101 wire should be current output to control clock-wise slewing, the boom movement speed by the current. 102：操作逆回转时，102号线有电流输出，控制逆回转动作。 102: When operation counter-clockwise slewing, the 102 wire should be current output to control counter clock-wise slewing 103：操作一臂上时，103号线有电流输出，控制一臂上动作。 103: When operation the first section boom to up, the 103 wire should be a current output, control the first section to up 104：操作一臂下时，104号线有电流输出，控制一臂下动作。 104: When operation the first section boom to down, the 104 wire should be current output to control the first section up 105：操作二臂上时，105号线有电流输出，控制二臂上动作。 105: when operation the second section boom up, the 105 wire should be current output to control the second section boom up . 106：操作二臂下时，106号线有电流输出，控制二臂下动作。 106: when operation the second section boom down, the 106 wire should be current output to control the second section boom down. 107：操作三臂上时，107号线有电流输出，控制三臂上动作。 107: when operation the third section boom up, the 107 wire should be current output to control the third section boom up . 108：操作三臂下时，108号线有电流输出，控制三臂下动作。 108: when operation the third section boom down, the 108 wire should be current output to control the third section boom down. 109：操作四臂上时，109号线有电流输出，控制四臂上动作。 109: when operation the 4th.section boom up, the 109 wire should be current output to control the 4th.section boom up. 110：操作四臂下时，110号线有电流输出，控制四臂下动作。 110: when operation the 4th.section boom down, the 110 wire should be current output to control the 4th.section boom down. 111：操作五臂上时，111号线有电流输出，控制五臂上动作。 111: when operation 5th.section boom up, the 111 wire should be current output to control the 5th.section boom up. 112：操作五臂下时，112号线有电流输出，控制五臂下动作。 112: when operation 5th.section boom down, the wire 112 should be current output to control 5th.section boom down. 113：操作任何臂架动作时，113号线有24V电压输出，控制电子锁死电磁铁。 113: when operation every movement of boom, the 113 wire should be 24V current output to control the solenoid controlled relief valve of the multiplex valve 21：用遥控器操作正泵动作时，21号线有24V电压输出。 21: when use the remote control to operation normal pumping, the 21 wire should be voltage 24V output. 22：用遥控器操作反泵动作时，22号线有24V电压输出。 22: when use the remote control to operation reverse pumping, the 22 wire should be voltage 24V output. 23：用遥控器操作加速动作时，23号线有24V电压输出。 23: when use the remote control to acceleration of the engine, the wire 23 should be voltage 24V output. 24：用遥控器操作减速动作时，24号线有24V电压输出。 24: when use the remote control to deceleration of the engine, the wire 24 should be voltage 24V output. 29：用遥控器调节排量开关时，0～10档对应有0～10V电压输出。 29: when use the remote control to adjust the switch of the main pump displacement, 0-10 gear should be voltage 0-10V output. 52：用遥控器操作停发动机按钮时，52号线有24V电压输出。 52: when use the remote control to stop the engine, the wire 52 should be voltage 24V output. 53：用遥控器操作电笛按钮时，53号线有24V电压输出。 53: when use the remote control to press the horn button, the wire 53 should be voltage 24V output. 第二页 辅助控制系统 Page 2 the auxiliary control system
SA0：电源总开关，闭合时与电瓶电源相连，断开时则切断与电瓶电源的连接。 SA0: the master switch of the power supply, when it close up, should be connected the battery, when it turn off, should be cut off power supply from the battery. 95：冷却风机的总电源。 95: power supply of the cooler moter. 1：电控系统其他元器件的总电源。 1:the power supply for the electrical system auxiliary element. 12（QF3）：看料灯、工作灯电源。 12(QF3): the power supply for the hopper lamp, working light 11：电笛电源。 11: the power supply for the horn 2（KA1）：上装控制系统总电源继电器。 2(KA1): the relay of power supply for the boom kit. 3：控制器、触摸屏电源。 3: the power supply for the controller and the touch screen. 4：面/遥转换开关转换到遥控侧后的电源（支腿、臂架电源）。 4:the power supply of the panel/remote control switch to remote control side(outrigger & boom power supply) 10：面控电源。 10: the power supply for the panel control 5：泵送系统、润滑系统、清洗系统电源。 5: the power supply for the pumping system, lubrication system, cleaning system 11A：滤芯系统电源。 11A: the power supply for the filter system 16A：振动电机电源。 16A: the power supply for the vibrator KA33：振动电机启动继电器。 KA33: the relay for the vibrator motor KA3：冷却风扇继电器， KA3: the relay for the cooler SA6：冷却风扇选择开关。 SA6: the switch for the cooler 第三页 作业控制系统1
