ElecKits_AS3992_UHF_RFID读写模块使用手册150903

基于AS3992芯片的远距离RFID读写器设计随着物联网在智能电网、智能交通、智能物流和生态监视等国民经济方方面面的大量应用，UHF频段的RFID技术更是发展迅速，它是一种非接触式的自动识别技术，通过射频信号可以自动识别目标对象、获取相关数据，识别工作无须人工干预，适用于各类恶劣环境。

RFID系统由标签、读写器和天线三部分构成，其中RFID读写器最为关键。

1系统方案设计基于AS3992芯片的远距离RFID读写器系统主要包括射频部分和基带部分，如图1所示。

射频部分围绕RFID集成芯片AS3992展开设计，环路滤波器配合内置VCO产生精确频率；发射链路主要由巴伦、功率放大器、耦合器、高频开关和多路天线接口组成，在关键通路上使用LC网络和型网络调整阻抗匹配；射频接收链路由天线、高频开关、耦合器、低噪放和巴伦组成。

基带部分配置了可升级的MCU主控制器及通用外围接口。

2硬件电路设计2.1 AS3992及其外围电路AS3992是奥地利微电子推出的一款高性能UHF频段的读写器芯片，它集成了混频器、增益滤波器、压控振荡器、锁相环、模数/数模转换器等模拟前端，并且内置了ISO18000-6C 的完整协议处理系统。

外部控制器仅需通过8位并口或者SPI口即可实现对AS3992的所有通信和控制。

UHF载波信号的通信频率为840 MHz~960 MHz，AS3992集成了VCO、预分频器、主除法器、参考除法器、鉴相器和电荷泵，外围电路只要提供一个环路滤波器即可组成一个完整的锁相环（PLL）电路，如图2所示。

PLL的输出频率由参考除法器的设定值和主除法器的乘积决定。

电荷泵（CP）的主要作用是将数字逻辑脉冲转换为模拟电流。

CP信号经过低通滤波器反馈到VCO引脚用来调整振荡器频率精度。

为了获得稳定的VCO调谐电压，外部的环路滤波电路特别重要，它起到了维持环路稳定性、控制环路带内外噪声、防止VCO调谐电压控制线上电压突变、抑制参考边带杂散干扰等重要作用。
