存储HCIP试题与参考答案一、单选题（共38题，每题1分，共38分）1.同事为客户定制双活容灾方案，客户已经有套第三方存储系统，计划新购置一套OceanStor5300V3，把这两套设备分别放置到两个数据中心实施双活容灾，该方案：A、可行，存储设备满自足双活容灾方案要求。

B、不可行，双活容灾方案需要至少两套OceanStorV3存储。

C、不可行，双活容灾方案只支持华为存储，不支持第三方存储。

正确答案：B2.某客户初始备份容量为1T，平均每天数据增量10G，备份策略是每周做一次全备，周二到周日每天一次差异增备，全备和增备数据的保存周期均为4周，在不考虑重删，冗余比，复制等的情况下所需的后端容量应该不少于哪个值？A、4940GB.B、4280GB.C、5940GB.D、5280GB.正确答案：C3.华为分布式存情块服务的压缩功能，哪个选项描述是正确的A、压缩引擎采用三种不同压缩算法组合运行B、在同一个存储池只能选择一个压缩算法C、存储池压缩算法的修改会影响已经压缩的数据D、同一个存储池可以选择多种压缩算法，提高压缩速度和比例正确答案：D4.关于源端重删，以下描述不正确的是哪一项？A、当数据从源端传输到目标端的过程中，在源端先对被传输的数据块进行哈希比对并去重。

B、占用源端资源进行去重处理。

C、只需要将新数据块的数据传输到目标端，无需传输老数据块相关的信息D、相比目标端重删可节约传输带宽。

正确答案：C5.华为UltaPath提供多种负载均衡算法，会根据每个io请求的块大小计算出总体负载数据量，然后进行负载均和的算法是以下哪种算法？A、least-blockB、round-robinC、least-into正确答案：A6.下面哪项属于oceanstor18000存储系列产品RAID2.0+技术支持的自动负载均衡技术？A、smartmotionB、smarttierC、smartqosD、smartpartition正确答案：A7.华为本地高可用方案中，如果采用HyperMirror特性，那么还必须使用哪种特性才能对异构存储整列创建镜像。

Easy-MSAP系列光同步多业务接入平台MSAP网管软件用户手册（V1.6）北京亿兆未来宽带网络技术有限公司版权声明：版权所有，保留一切权力。

非经本公司书面授权，任何单位、组织或个人不得擅自摘抄、复制本书部分或全部，并不得以任何形式传播文档说明本用户手册根据中华人民共和国通信行业标准，并结合本公司MSAP和MST-LCD＋系列设备实际情况编写，为MSAP和MST-LCD＋设备使用者提供参考。

时间版本说明2008年3月10日V1.0 本用户手册发布目录一、概述 (4)1.1特点 (4)1.2系统要求 (4)二．功能介绍 (5)2.1配置管理 (5)2.2告警管理 (5)2.3性能管理 (6)2.4维护管理 (6)2.5网管与设备的连接 (6)三．基本操作 (6)3.1登录 (6)3.2网管主界面 (7)3.2.1界面组成 (7)3.2.2 语言选择 (8)3.2.3 新建文件 (9)3.2.4保存文件 (11)3.2.5读取文件 (12)3.3网管子窗口 (13)3.4I P地址的设置 (16)3.5配置数据管理 (17)3.6 系统时钟设定 (19)3.7网管通道的建立 (20)3.8告警功能管理 (22)四．业务板卡设置 (25)4.1主板参数设置 (25)4.2光卡参数设置 (32)4.2.1光群路卡（适用于ESDH系列设备） (32)4.2E1参数设置（适用于ESDH、MST-LCD+系列设备） (35)4.4以太参数设置 (38)4.5 V.35参数设置（适用于ESDH、MST-LCD系列设备） (46)五．应用举例 (49)5.1业务要求 (49)5.2工程准备 (49)5.3工程开通 (51)一、概述EZWELL NMS网管软件是本公司针对ESDH和MST-LCD＋系列设备所设计的网管软件，其管理功能强大，包括配置管理、告警管理、性能管理、维护管理和安全管理等。

通过F接口(支持SNMP协议)可与电信管理网连接，以实现对整个网络系统局、远端设备的管理控制。
