22PF-5U..Flow sensorUltrasonic flow sensor provides precise fluid measurement in a heating or cooling system. Equipped with automatic temperature and glycol compensation that ensures reliable measurement. Optional Thermostat Heater or Humidistat Heater to prevent condensation. Seamless integration via BACnet, Modbus andMP-Bus. Parameters can be easily set using NFC.Type OverviewType DN DN ["]FS [GPM]Degree of protection NEMA/UL22PF-5UC 151/27.9NEMA 222PF-5UD 203/413NEMA 222PF-5UE 25118.5NEMA 222PF-5UF 321 1/431.7NEMA 222PF-5UG 401 1/252.7NEMA 222PF-5UH 50279.2NEMA 222PF-5UHH502120NEMA 2FS: Full scale, maximum flow∆p: Pressure drop at FSTechnical dataElectrical DataNominal voltageAC/DC 24 V Nominal voltage frequency 50/60 HzNominal voltage range AC 19.2...28.8 V / DC 21.6...28.8 V Power consumption AC 2.2 VA Power consumption DC 1.1 WConnection supplycable , 6 x 0.75 mm²Data bus communicationCommunicationBACnet MS/TP Modbus RTU MP-BusNumber of nodesBACnet / Modbus see interface description MP-Bus max. 8 (16)Functional Data Sensor Technology Ultrasonic time-of-flight (with glycol and temperature compensation)Application waterWater-glycol mixture Configuration via NFC, Belimo Assistant AppVoltage output1 x 0...10 V, 0.5...10 V, 2...10 V or user defined22PF-5U..Functional Data Output signal active note DC 0...10 V (factory setting), selectable via NFCmax. load 1 mAUser defined:- Lower limit: 0...8 V- Upper limit: 2...10 VInstallation position upright to horizontalServicing maintenance-freeVelocity range0.08-7.73 FPSMeasuring Data Measured values FlowTemperatureMeasuring fluid chilled or hot water, up to 60% glycol max(open loop/steam not allowed)Measuring principle Ultrasonic volumetric flow measurementMeasuring accuracy flow±2% of the measured value (20...100% FS) @20°C / glycol 0% vol.±0.4% of FS (0...20% FS) @ 20°C / glycol 0% vol.Measuring accuracy flow note Additional information on measuring accuracy(with diagram) can be found in the section"Measuring accuracy".Measurement Repeatability±0.5% (Flow)Min. flow measurement0.2% of FSMaterials Fluid wetted parts Brass nickel-plated, Brass, Stainless steel, PEEK,EPDMFlow measuring pipe brass body nickel-platedSafety Data Protection class IEC/EN III, Protective Extra-Low Voltage (PELV)Power source UL Class 2 SupplyDegree of protection IEC/EN IP54Degree of protection NEMA/UL NEMA 2Enclosure UL Enclosure Type 2Certification IEC/EN IEC/EN 60730-1:11 and IEC/EN 60730-2-15:10Quality Standard ISO 9001UL Approval cULus acc. to UL94Type of action Type 1Rated impulse voltage supply0.8 kVPollution degree3Ambient humidity Max. 95% RH, non-condensingAmbient temperature-22...130°F [-30...55°C]-22...122°F [-30...50°C] (UL)Fluid temperature-5...250°F [-20...120°C]At a fluid temperature of < 2°C [< 36°F], frostprotection must be guaranteedStorage temperature-40...176°F [-40...80°C]Safety NotesThis device has been designed for use in stationary heating, ventilation and air-conditioningsystems and must not be used outside the specified field of application, especially in aircraft orin any other airborne means of transport.Outdoor applications: Only possible where (sea) water, snow, ice, sunlight or aggressive gasescannot interfere directly with the device and it can be guaranteed that the ambient conditionsremain at all times within the thresholds according to the data sheet.Only authorized specialists may carry out installation. All applicable legal or institutionalinstallation regulations must be complied during installation.The device contains electrical and electronic components and must not be disposed of ashousehold refuse. All locally valid regulations and requirements must be observed.22PF-5U..Mode of operationFunctionsPatented glycol compensationProduct FeaturesThe ultrasonic flow sensor is equipped with a flow pipe, two flow transmitters and an electronic circuit. A temperature sensor is mounted in the flow pipe to compensate the temperature effects.A sensor error occurs when the ultrasonic path is interrupted (air bubbles in the system, connection to ultrasonic transducers interrupted).Detailed error reports are available via Belimo Assistant App or BACnet, Modbus and MP-Bus.Collective error report displayIf the output signal is set to 0.5...10 V or 2...10 V and also to flow, a collective error report isdisplayed with a voltage of 0.3 V. This indicates a measurement error of the temperature sensor or flow sensor.Wires 6 and 7 are for the Modbus or BACnet communication. The physical bus address can be defined via the app.Wire 5 can be parametrized with the app as an output signal 0...10 V (factory setting), 0.5...10 V, 2...10 V, user defined or as an MP-Bus communication. For the output signal, the flow or the fluid temperature can be selected.The output signal can be scaled to achieve a better resolution. Factory setting is 10 V = FS (see diagram, example of output voltage characteristic curve 22PF-5UC).Example output voltage characteristic 22PF-5UCU = Output voltage q = Measured flow ∆ = Alternative settings□ = Factory settingGlycol changes the viscosity of the heat transfer fluid and as a result affects the measuredvolumetric flow. Without glycol compensation, volumetric flow measurements can show errors of as much as 30 percent. The patented automatic glycol compensation significantly reduces the degree of measurement error.Selection of the fluid used:– Water– Propylene glycol – Ethylene glycol – Antifrogen L – Antifrogen N – DowCal 200– DowCal 10022PF-5U..Measuring accuracyPressure dropMeasuring accuracy for water (glycol 0% vol.):±2% (@ 20…100% FS)At a temperature range of 15…120 °C.Measuring accuracy for water + glycol (glycol 0...60% vol.)±5% (@ 20…100% FS)±0.01 FS, but not more than 30% of q (@ 0.8…20% FS)At a temperature range of -20...120°C.— Water---- Water + glycol (≤60% glycol)y = Measuring accuracyq = Measured flowFS = Full scale, maximum flow22PF-5U..Recommended installation positionsInstallation in returnInlet sectionWater quality requirementsServicingFlow direction Avoiding cavitationCleaning of pipes Prevention of stressesInstallation notesThe sensor can be installed upright to horizontal. The sensor may not be installed in a hangingposition.Installation in the return is recommended.In order to achieve the specified measuring accuracy, a flow-calming section or inflow section in the direction of the flow is to be provided upstream from the flow sensor. Its dimensions shouldbe at least 5x DN.The water quality requirements specified in VDI 2035 must be adhered to.Sensors are maintenance-free.Before any service work on the sensor is carried out, it is essential to isolate the sensor from the power supply (by unplugging the electrical cables if necessary). Any pumps in the part of the piping system concerned must also be switched off and the appropriate slide valves closed (allow all components to cool down first if necessary and always reduce the system pressure to ambient pressure level).The system must not be returned to service until the sensor has been correctly reassembled in accordance with the instructions and the pipeline has been refilled by professionally trained personnel.The direction of flow, specified by an arrow on the housing, is to be complied with, since otherwise the flow rate will be measured incorrectly.To avoid cavitation, the system pressure at the outlet of the flow sensor must be a minimum of 1.0 bar at FS (maximum measurable flow) and temperatures up to 90°C.At a temperature of 120°C the system pressure at the outlet of the flow sensor must be at least 2.5 bar.Before installing the flow sensor, the loop must be thoroughly rinsed to remove impurities.The flow sensor must not be subjected to excessive stress caused by pipes or fittings.AccessoriesToolsDescriptionTypeBelimo Assistant App, Smartphone app for easy commissioning, parametrising and maintenance Belimo Assistant AppConverter Bluetooth / NFCZIP-BT-NFC22PF-5U..NFC connectionNotesServiceBelimo equipment marked with the NFC logo can be operated and configured using the Belimo Assistant App.Requirements:- Smartphone with NFC or Bluetooth- Belimo Assistant App (Available on Google Play & Apple AppStore)Smartphone with NFC:Place NFC-capable smartphone flat on the room sensor so that both NFC antennas are superposed.Smartphone with Bluetooth without NFC:Connect Bluetooth enabled smartphone via ZIP-BT-NFC (Bluetooth to NFC Converter) to the sensor. Technical data and operation instructions are shown on the ZIP-BT-NFC technical data sheet.Readable values: volumetric flow, accumulated flow, fluid temperature, glycol content in %,alarm/error messagesWiring DiagramSupply from isolating transformer.The wiring of the line for BACnet MS/TP / Modbus RTU is to be carried out in accordance with applicable RS485 regulations.Modbus / BACnet: Supply and communication are not galvanically isolated. Connect earth signal of the devices with one another.Sensor connection: An additional sensor can optionally be connected to the flow sensor. This can be an active sensor with output DC 0...10 V (max. DC 0...32 V with resolution 30 mV) or a switching contact (switching current min. 16 mA @ 24 V). Thus the analogue signal of the sensor can be easily digitized with the flow sensor and transferred to the corresponding bus system.Analogue output: An analogue output (wire 5) is available on the flow sensor. It can be selected as 0...10 V, 0.5...10 V, 2...10 V or user defined. For example, the flow rate or the temperature of the temperature sensor (Pt1000 - EN 60751, 2-wire technology) can be output as an analogue value.22PF-5U..AC/DC 24 V, output signalCable colours:1 = black, GND 2 = red, AC/DC 24 V3 = white, Sensor optional5 = orange, DC 0...10 V, MP-Bus6 = pink, C1 = D- = A7 = grey, C2 = D+ = BBACnet MS/TP / Modbus RTUMP-Bus, supply via 3-wire connection MP-Bus via 2-wire connection, local power supplyA) additional MP-Bus nodes (max. 8)A) additional MP-Bus nodes (max. 8)Connection with active sensorConnection with switching contactDimensions22PF-5U..Type DN DN ["]A_1B_1C_1D_1E_1F_1Weight22PF-5UC151/28.0" [203]4.7" [119]6.1" [154]5.5" [140]1.8" [46]1.8" [46] 1.7 lb[0.750 kg]22PF-5UD203/47.8" [198]5.9" [150]6.3" [159]5.5" [140]1.8" [46]1.8" [46] 1.7 lb[0.750 kg]22PF-5UE2518.4" [213]6.2” [157]6.4" [163]5.5" [140]1.8" [46]1.8" [46] 1.7 lb[0.750 kg]22PF-5UF321 1/48.6" [218]6.5" [165]6.7" [169]5.6" [142]1.8" [46]1.8" [46] 1.7 lb[0.750 kg]22PF-5UG401 1/28.8" [224]6.8" [173]7.0" [178]5.8" [148]1.8" [46]1.8" [46] 1.7 lb[0.750 kg]22PF-5UH5029.0" [229]7.1" [180]7.4" [187]6.0" [152]1.8" [46]1.8" [46] 1.7 lb[0.750 kg]22PF-5UHH5029.0" [229]7.1" [180]7.4" [187]6.0" [152]1.8" [46]1.8" [46] 1.7 lb[0.750 kg] Further documentation• Overview MP Cooperation Partners• Description Data-Pool Values• BACnet Interface description• Modbus Interface description• Installation instructions。
Instruction manual O2Transmitter 4100 eOrder number: 52 121 114ContentsMettler-Toledo GmbH, Process Analytics, Industrie Nord,CH-8902 Urdorf, Tel. (01) 736 26 36Subject to technical changes. Mettler-Toledo GmbH, 10/03.WarrantyDefects occurring within 1 year from delivery date shall be remedied free of charge at our plant (carriage and insurance paid by sender).Subject to change without noticeDisposal (Directive 2002/96/EC of January 27, 2003)Please observe the applicable local or national regulations concerning the disposal of “waste electrical and electronic equipment”.ContentsSafety information Array Be sure to read and observe the following instruc-tions!The device has been designed in accordance with the state ofthe art and complying with the applicable safety regulations.When operating the device, certain conditions may neverthe-less lead to danger for the operator or damage to the device.Caution!Commissioning may only be carried out by trained experts.Whenever it is likely that protection has been impaired, thedevice shall be made inoperative and secured against unintend-ed operation.The protection is likely to be impaired if, for example:•the device shows visible damage•the device fails to perform the intended measurements•after prolonged storage at temperatures above 70 °C•after severe transport stressesBefore recommissioning the device, a professional routine testin accordance with EN 61010-1 must be performed. This testshould be carried out by the manufacturer.Intended useThe O2Transmitter 4100 e is used for dissolved oxygen and tem-perature measurement in biotechnology, pharmaceutical industry, as well as in the field of environment, food processing, and sewage treatment.The rugged molded enclosure can be wall or pipe mounted or fixed into a control panel.The protective hood provides additional protection against direct weather exposure and mechanical damage.The Transmitter has been designed for application with ampero-metric sensors of the InPro6000 ... InPro6800 Series. TrademarksThe following names are registered trademarks. For practical rea-sons they are shown without trademark symbol in this manual. InPro®EasyClean®EC Declaration of conformityOverview of O 2Transmitter 4100 eDo not connect!CathodeGuardAnodeReference electrode RTDRTDshieldHOLD HOLD/CONTROL CONTROL+ Output 1- Output 1/2+ Output 2Relay 1Relay 1/2Relay 2AlarmAlarmClean Clean Power PowerPackage contentsCheck the shipment for transport damage and completeness. The package should contain:• Front unit• Lower case• Bag containing small parts• Instruction manual• Specific test reportAssemblyFig.: Pipe-mount kitPipe mounting, panel mountingInstallation and connectionCaution!•Installation may only be carried out by trained experts in accordance with this instruction manual and as per applicable local and national codes.•Be sure to observe the technical specifications and input ratings.•Be sure not to notch the conductor when stripping the insulation.•Before connecting the device to the power supply, make sure that its voltage lies within the range 20.5 to 253 V AC/DC.•When commissioning, a complete configuration must be carried out by the system administrator.The terminals are suitable for single wires and flexible leads upto 2.5 mm2(AWG 14)Warning!Additional safety precautions have to be taken for applications in hazardous locations to CSA (CLI DIV2 GPA,B,C,D T4, Ex nA IIC T4)!(See Pg 93.)Protective wiring of switching contactsRelay contacts are subjected to electrical erosion. Especially with inductive and capacitive loads, the service life of the con-tacts will be reduced. For suppression of sparks and arcing,components such as RC combinations, nonlinear resistors,series resistors and diodes should be used.Protective wiringA: DC application with inductive loadB: AC/DC applications with capacitive load C: Connection of incandescent lampsA1Inductive loadA2Free-wheeling diode, e.g. 1N4007 (Observe polarity)A3ContactB1Capacitive loadB2Resistor, e.g. 8 Ohms/1 W at 24 V / 0.3 A B3ContactC1Incandescent lamp, max 60 W / 230 V , 30 W / 115 V C3ContactWarning!Make sure that the maximum ratings of the relay contacts are not exceeded even during switching!Typical protective wiring measuresProtective wiringUser interface, displayDisplayOperation: KeypadSensocheck, Sensoface sensor monitoringSensocheck continuously monitors the sensor and leads.Sensocheck can be switched off (Configuration, Pg 46).Safety featuresMode codesThe mode codes allow fast access to all functions CalibrationOverview of configuration stepsNote:The Transmitter 4100 e has a device a resolution of 0.01 ppm. For the sensor type B, we recommend the O2Transmitter 4100ppb with a device resolution of 0.001 ppm.Polarization voltage. Process pressure. Salt correction.Two complete parameter sets are stored in the EEPROM. As delivered, the two sets are identical but can be edited. Note:Fill in your configuration data on the following pages.Default settings of parameter setsCode. Parameter Setting o1. Sensor type ________________________o1. %, mg/l, ppm ________________________o1. 0/4-20 mA________________________o1. Current beginning ________________________o1. Current end ________________________o1. Filter time ________________________o1. 22mA signal ________________________o1. Hold behavior ________________________o1. Fix current ________________________o2. Unit °C / °F ________________________o2. Temp probe ________________________o2. 0/4...20mA________________________o2. Current beginning ________________________o2. Current end ________________________o2. Filter time ________________________o2. 22mA signal ________________________o2. Hold behavior ________________________o2. Fix current________________________Co. Polarization voltage ________________________Co. Pressure unit ________________________Co. Pressure ________________________Co. Salinity ________________________CA. Cal mode ________________________CA. Cal interval ________________________AL. Sensocheck ________________________AL. Alarm delay ________________________AL. LED Hold________________________Parameter set – user settingsCode. Parameter Setting rL. Relay function ________________________L1. Contact function ________________________L1. Contact response ________________________L1. Switching point ________________________L1. Hysteresis ________________________L1. Delay________________________L2. Contact function ________________________L2. Contact response ________________________L2. Switching point ________________________L2. Hysteresis ________________________L2. Delay________________________Ct. Setpoint ________________________Ct. Neutral zone ________________________Ct. P action ________________________Ct. I action ________________________Ct. D action________________________Ct. PLC/PFC controller ________________________Ct. Pulse length ________________________Ct. Pulse frequency ________________________Ct. Hold behavior ________________________Pb. Probe selection ________________________Pb. Rinsing interval ________________________Pb. Rinse duration ________________________Pb. Contact type ________________________Pb. Cleaning interval________________________Pb. Lock cleaning interval________________________It is always recommended to calibrate in air.Compared to water, air is a calibration medium which is easy to handle, stable, and thus safe. In the most cases, however, the sensor must be dismounted for a calibration in air.When dealing with biotechnological processes which require sterile conditions, the sensor cannot be removed for calibration. Here, calibration must be performed with aeration directly in the process medium (e.g. after sterilization).The calibration procedures for these two common applications are described on the following pages. Of course, other combina-tions of process variable and calibration mode are possible.Note:When a 2-point calibration is required, the zero point calibration should be performed prior to saturation or concentration cali-bration, resp.All calibration procedures must be performed by trainedpersonnel.Zero point calibrationNote:In Hold mode the controller output acts as configured (Y = const. or Y = 0).50 %X w10 / (1.00)20 / (2.00)30 / (3.00)40 / (4.00)50 / (5.00) ControlleroutputYProportional action (Gradient K C[%])Neutral zone (Y=0)Tolerated deviation from setpoint.The setting “010%”, for example, permits a deviation of ±5 % from the desired value without activating the controller.Pulse length / pulse frequency controllerPulse length controller (PLC)The pulse length controller is used to operate a valve as an actuator. It switches the contact on for a time that depends on the controller output. The period is constant. A minimum ON time of 0.5 sec is maintained even if the controller output takes corresponding values.Pulse frequency controller (PFC)The pulse frequency controller is used to operate a frequency-controlled actuator. It varies the frequency with which the contacts are switched on. The maximum pulse frequency [pulses/min] can be defined. It depends on the actuator.The Contact ON time is constant. It is automatically calculated from the user-defined maximum pulse frequency:Output signal (switching contact) of pulse frequency controllerOutput signal (switching contact) of pulse length controllerOperation with automatic cleaning system“EasyClean” is a separate automatic cleaning system. The cleaning cycle is activated according to the cleaning interval defined during configuration (Pg 55).Calibration error messagesNoteThe worsening of a Sensoface criterion leads to the devaluation of the Sensoface indicator (Smiley becomes “sad”). An improvement of the Sensoface indicator can only take place after calibration or removal of a sensor defect.SensocheckContinuously monitors the sensor and lines for short circuits or open circuits. Critical values make the Sensoface “sad” and the corresponding icon flashes:The Sensocheck message is also output as error messageErr33. The alarm contact is active, the red LED is lighted, out-put current 1 is set to 22 mA (when configured corresponding-ly). Sensocheck can be switched off during configuration (then Sensoface is also disabled). Exception: After a calibration aAppendixProduct line and accessoriesDevices Order No. O2Transmitter 4100 e52 121 103 Mounting accessoriesPipe-mount kit52 120 741 Panel-mount kit52 120 740 Protective hood52 120 739 SensorsMettler-Toledo GmbH, Process Analytics offers a wide range of sensors for the following fields of applications:- Chemical process industry- Pharmaceutical industry- Food and beverage industry- Water/waste-waterFor more information concerning our sensors and housings program, please refer to .DO input Sensor Type A: InPro6000 – 6800Sensor Type B:InPro6900Measuring current-2 to 1800 nA,Resolution 0.05nA(with Vpol = 800 mV and Vref = 200 mV)Saturation (-10 to 80 °C)0 to 500 %Meas. error1,2,30.5 % meas.val. + 0.5 %Concentration (-10 to 80 °C)0.00 to 50.00 mg/l0.00 to 50.00 ppmMeas. error1,2,30.5 % meas.val. + 0.05 mg/lor 0.05 ppmAdm. guard current≤20 µAPolarization voltage*0 to 1000 mV,Process pressure *0.000 to 9.999 bars(to 999.9 kPa / to 145.0 psi)Salt correction *00.00 to 45.00 g/kgSensor standardizationOperating modes *DO saturation (automatic)DO concentration (automatic)Product calibrationZero point calibrationCalibration range Zero point±2 nASensor Type A Slope25 to 130 nA(at 25 °C, 1013 mbars)Calibration range Zero point±2 nASensor Type B Slope200 to 550 nA(at 25 °C, 1013 mbars)Calibration timer *0000 to 9999 hPressure correction *0.000 to 9.999 bars / 999.9 kPa / 145.0 psiSensocheck Monitoring for short circuits / open circuits (can be disabled)Sensoface Provides information on the sensor conditionEvaluation of zero/slope, response,calibration interval, Sensocheck Temperature NTC 22 kOhms / NTC 30 kOhms, selectableinput2-wire connection, adjustableMeasurement range-20.0 to +150.0 °C / -4 to +302 °FAdjustment range10 KResolution0.1 °C / 1 °FMeas. error1,2,3< 0.5 K (<1 K at > 100°C)HOLD input Galv. separated (OPTO coupler)Function Switches Transmitter to HOLD modeSwitching voltage Inactive0 to 2 V (AC/DC)Active10 to 30 V (AC/DC) CONTROL input Galv. separated (OPTO coupler)Function Control input for automatic cleaning system Switching voltage Inactive0 to 2 V (AC/DC)Active10 to 30 V (AC/DC) Output 10/4 to 20 mA, max. 10 V, floating(galv. connected to output 2)Process variable *DO saturation/DO concentrationOverrange *22 mA in the case of error messagesOutput filter *Low-pass, filter time constant 0 to 120 sMeas. error 1< 0.3 % current value + 0.05 mAStart/end of scale Configurable within selected rangeAdm. span 5 to 500 % / 0.5 to 50 mg/l (ppm)Output 20/4 to 20 mA, max. 10 V, floating(galv. connected to output 1)Process variable TemperatureOverrange *22 mA in case of temp error messagesOutput filter *Low-pass, filter time constant 0 to 120 sMeas. error 1< 0.3 % current value + 0.05 mAStart/end of scale*-20 to +150 °C / -4 to +302 °FAdm. span 20 to 170 K (68 to 338 °F)Alarm contact Relay contact, floatingContact ratings AC< 250 V / < 3 A / < 750 VADC< 30 V / < 3 A / < 90 WContact response N/C (fail-safe type)Response delay *0000 to 0600 sLimit values Output via relay contacts R1, R2Contacts R1, R2 floating but inter-connected Contact ratings AC< 250 V / < 3 A / < 750 VADC< 30 V / < 3 A / < 90 WContact response*N/C or N/OResponse delay *0000 to 0600 sSwitching points*Within selected rangeHysteresis*000.0 to 050.0 % / 00.00 to 05.00 mg/l (ppm)PID Output via relay contacts R1, R2process controller(Relay R1: below setpoint,Relay R2: above setpoint)Setpoint specification*0 to 500 % / 0.00 to 50.00 mg/l (ppm)Neutral zone*000.0 to 050.0 % / 00.00 to 05.00 mg/l (ppm)P-action component*Controller gain Kp: 0010 to 9999 %I-action component*Reset time Tr:0000 to 9999 s(0000 s = no integral action) D-action component*Rate time Td: 0000 to 9999 s(0000 s = no derivative action) Controller type*Pulse length controller or pulse frequency controller Pulse period*0001 to 0600 s, min. ON time 0.5 s(pulse length controller)Max. pulse frequency*0001 to 0180 min-1(pulse frequency controller)Cleaning function*Relay contact, floating, for controlling a simple rinsingsystem or an automatic cleaning system (EasyClean) Contact ratings AC< 250 V / < 3 A / < 750 VADC< 30 V / < 3 A / < 90 WContact response*N/C or N/OInterval *000.0 ... 999.9 h(000.0 h = cleaning function switched off)Rinse duration*0000 ... 1999 sDisplay LC display, 7-segment with iconsMain display Character height 17 mm, unit symbols 10 mm Secondary display Character height 10 mm, unit symbols 7 mmSensoface 3 status indicators (friendly, neutral, sad Smiley)Mode indicators 5 status bars“meas”, “cal”, “alarm”, “cleaning”, “config”18 further icons for configurationand messagesAlarm indication Red alarm LED in case of alarm or HOLD (user defined) Keypad 5 keysService functionsCurrent source Current specifiable for output 1 and 2 (00.00 to 22.00 mA) Manual controller Controller output entered directly (start of control process) Device self-test Automatic memory test (RAM, FLASH, EEPROM)Display test Display of all segmentsLast Error Display of last error occurredSensor monitor Display of direct, uncorrected sensor signalRelay test Manual control of the four switching contactsParameter sets Two selectable parameter sets for differentapplicationsData retention Parameters and calibration data > 10 years (EEPROM)Protection against Protective separation of all extra-low-voltage circuits against electrical shock mains by double insulation as per EN 61010-1Power supply24 (-15%) to 230 V AC/DC (+10%); approx. 5 VA, 2.5 WAC: 45 to 65 Hz; Overvoltage category II, Class IINominal operating conditionsAmbient temperature-20 to +55 °CTransport/Storage temp.-20 to +70 °CRelative humidity 10 to 95 % not condensingPower supply24 (-15%) to 230 V AC/DC (+10%)Frequency for AC45 to 65 HzEMC EN 61326Emitted interference Class B (residential environment)Class A for mains supply > 60 V DCImmunity tointerference IndustrialenvironmentExplosion protectionFM: NI Class I Div 2 Group A, B, C & D,T4T a = 55 °C; T ype 2NI Class I Zone 2Group IIC,T4 T a = 55°C; T ype 2CSA:Class I Div 2 Groups A, B, C and D,T4Ex nA IIC T4Enclosure Molded enclosure made of PBT (polybutylene terephtalate) Color Bluish gray RAL 7031Assembly• Wall mounting• Pipe mounting: dia 40 to 60 mm, 30 to 45 mm• Panel mounting, cutout to DIN 43 700Sealed against panelDimensions H 144 mm, B 144 mm, T 105 mmIngress protection IP 65 / NEMA 4XCable glands 3 breakthroughs for cable glands M20x1.52 breakthroughs for NPT 1/2 “orRigid Metallic ConduitWeight Approx. 1 kg*) User-defined) To IEC 746 Part 1, at nominal operating conditions) ±1 count) Plus sensor errorExplosion protectionWarnings and notesto ensure safe operation2-point calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6122 mA signal for error message . . . . . . . . . . . . . .37, 43, 78Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85Alarm settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46Alarm contact . . . . . . . . . . . . . . . . . . . . . . . . .46, 88, 78Alarm delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78Operating states . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10Cal timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61Calibration to concentration (Conc) . . . . . . . . . . . . . . . .64Calibration to saturation (SAT) . . . . . . . . . . . . . . . . . . . .62Display of calibration data . . . . . . . . . . . . . . . . . . . . . . .71Specify calibration mode . . . . . . . . . . . . . . . . . . . . . . . .47Cleaning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54Lock cleaning interval . . . . . . . . . . . . . . . . . . . . . . . . . .54Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26Configuration steps . . . . . . . . . . . . . . . . . . . . . . . . . . . .28Menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27Configuration: Alarm settings . . . . . . . . . . . . . . . . . . . . . .46Alarm delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47LED in HOLD mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .47Sensocheck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47Configuration: Correction . . . . . . . . . . . . . . . . . . . . . . . . .44Polarization voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . .44Process pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44Salt correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44Configuration: Calibration mode . . . . . . . . . . . . . . . . . . .46Cal timer interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47Configuration: Controller . . . . . . . . . . . . . . . . . . . . . . . . .52IndexConfiguration: Limit function . . . . . . . . . . . . . . . . . . . . . .48Settings for relay 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .48Settings for relay 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . .50Use of relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49Configuration: Output 1 . . . . . . . . . . . . . . . . . . . . . . . . . .30Measurement procedure . . . . . . . . . . . . . . . . . . . . . . . .30Output current during Error . . . . . . . . . . . . . . . . . . . . . .36Output current range . . . . . . . . . . . . . . . . . . . . . . . . . .32Output signal during HOLD . . . . . . . . . . . . . . . . . . . . . .37Select sensor type . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30Time constant of output filter . . . . . . . . . . . . . . . . . . . . .34Configuration: Output 2 . . . . . . . . . . . . . . . . . . . . . . . . . .38Output current during HOLD . . . . . . . . . . . . . . . . . . . . .42Set output current range . . . . . . . . . . . . . . . . . . . . . . . .39Temperature error . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42Temperature probe . . . . . . . . . . . . . . . . . . . . . . . . . . . .39Temperature unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38Time constant of output filter . . . . . . . . . . . . . . . . . . . .40Configuration: Rinsing and calibration probes . . . . . . . . . .54Control drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94, 96Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62Controller equations . . . . . . . . . . . . . . . . . . . . . . . . . . .75Controller test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73Pulse length / pulse frequency controller . . . . . . . . . . . .74Controller: behavior during HOLD . . . . . . . . . . . . . . . . .53Current source 1/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72Diagnostics functions . . . . . . . . . . . . . . . . . . . . . . . . . . . .71Controller test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73Display of calibration data . . . . . . . . . . . . . . . . . . . . . . .71Display of last error message . . . . . . . . . . . . . . . . . . . . .71Display of output currents . . . . . . . . . . . . . . . . . . . . . . .71Display of sensor current . . . . . . . . . . . . . . . . . . . . . . . .71。
To buy, sell, rent or trade-in this product please click on the link below: /Nav-Aids-Ltd-PHENOM300-945-Pitot-Static-Adapter-Kit.aspxAIR DATA ACCESSORIES KITMODEL No. PHENOM300-945EMBRAER PHENOM 300AIRCRAFTFor Standard & RVSM TestingAIR DATA ACCESSORIES KIT MODEL No. PHENOM300-945PHENOM 300 AIRCRAFTFor Standard & RVSM TestingThe kit contains all the equipment required to connect and test from source the complete pitot & static air data system (including RVSM), as well the means of pre-testing all test adaptors and hoses prior to being fitted to the aircraft.For exact air data test procedures, refer to the Embraer PHENOM 300 Aircraft Maintenance Manual.This kit consists of the following components:Test Adaptor – RH IASPPart No. APA86300R-4-4-4-4 (1 req’d.) This test adaptor fits the IASP probe (Integrated Air Data and Stall Protection Probe) located on the right nose section of the aircraft.The test adaptor has the following labeled hose connections:- Pt for Pitot- Psb for Static- Pa1 for Alpha- Pa2 for AlphaTest Adaptor- LH IASPPart No. APA86300L-4-4-4-4 (1 req’d.) This test adaptor fits the IASP probe located on the left nose section of the aircraft.The test adaptor has the following labelled hose connections:- Pt for Pitot- Psb for Static- Pa1 for Alpha- Pa2 for Alpha Pre-Test Probefor IASP Test AdaptorPart No. PT421-632 (2 req’d.)When it becomes necessary to test the integrity of the IASP test adaptors, test hoses and air data test set (ADTS), the pre-test probes are installed into the test adaptors, thus simulating the IASP probe. With pitot and static pressure applied, a leak-check can be performed.Pitot-Static Test Adaptor – StandbyPart No. PS73458-4-4 (1 req’d.)This unit fits the standby pitot probe located on the right nose section of the aircraft.The test adaptor has the following labeled hose connections:- Pt for Pitot- Ps for StaticPre-Test Probefor Pitot-Static Test Adaptor-StandbyPart No. PT421-458 (1 req’d.)When it becomes necessary to test the integrity of the pitot-static test adaptor, test hoses and air data test set, the pre-test probe is installed into the test adaptor, thus simulating the standby pitot-static probe. With pitot and static pressure applied, a leak-check can be performed.AIR DATA ACCESSORIES KIT MODEL No. PHENOM300-945PHENOM 300 AIRCRAFTFor Standard & RVSM TestingPitot Test Hose AssemblyPart No. PHENOM3-7270 (1 req’d.)This hose assembly is connected to the pitot inlets of the IASP test adaptors and pitot-static test adaptor-standby (As per Maintenance Manual). The remaining end is connected to the pitot outlet (Pt) of the air data test set (ADTS).Static-Alpha2 Test Hose AssemblyPart No. PHENOM3-5160 (1 req’d.)This hose assembly is connected to the designated static(Psb)and alpha(Pa2) inlets of the IASP test adaptors and pitot-static test adaptor-standby.The remaining end is connected to the static (Ps2) outlet of the air data test set.Alpha1 Test Hose AssemblyPart No. PHENOM3-8381 ( 1 req’d.)This hose assembly is connected to the Alpha (Pa1) inlets of the IASP test adaptors. The remaining end is connected to the static outlet (Ps1) of the air data test set. Lubricating FluidPart No. LF5050 (1 req’d.)This fluid is used to lubricate the seals inside the test adaptors.This is accomplished by use of finger tip or cotton swab, applying a very thin film of lubricating fluid to the surface of the pre-test probe, inserting the probe into the test adaptor with a rotating motion and then retracting it. This action will ensure smooth test adaptor installation onto the pitot probe and will keep the test adaptor seals moist. Seal Kit – IASP Test AdaptorPart No. SK6300 (2 req’d.)Two sets of spare seals for the IASP test adaptors are stowed in the case.Seal Exchange for Pitot Test Adaptors: Removal: The seals inside the pitot test adapter can be exchanged by removing the circlip located inside the body of the adaptor. The circlip is removed by inserting a suitable pin tool in the small hole located just aft of the compression nut and pushing the circlip out of its seat. The compression nut can now be removed along with the spacers and seals from inside the adaptor.Installation: Clean all components before assembly. With reference to the drawing, the seals are exchanged and placed in the exact same location and sequence between the spacers. Carefully thread the compression nut onto the adaptor body and reinstall the circlip.The integrity of the adaptor is verified by applying pressure to the adaptor inlets with the pre-test probe installed.Seal Kit - Pitot Static Test Adaptor -StandbyPart No. SK1458 (1 req’d.)One set of spare seals for pitot-static test adaptor-standby are stowed in the case. Seal Exchange for Pitot-Static Test Adaptor-Standby: Same procedure as for IASP test adaptor (above),except circlip is located inside compression nut.AIR DATA ACCESSORIES KITMODEL No. PHENOM300-945PHENOM 300 AIRCRAFTFor Standard & RVSM TestingTool Kit – Seal ExchangePart No. 421-ASTK (1 req’d.)This tool kit contains the necessary tools toassist in the seal replacement of testadaptors. Instructions on how to changeseals are included in the kit.Manual - Part No. 444-PHENOM300-945One manual is supplied with eachPHENOM300-945 Air Data Accessories kit.This manual contains drawings and parts listsof test adaptors and hose assemblies.The above equipment is enclosed in a caseassembly: Model No. STR-PHENOM300-945。
供赛盛2分流量传感器安全操作及保养规程赛盛2分流量传感器是一种用于测量液体或气体流量的设备。
为了保证传感器的正常运行和延长使用寿命，以下是对赛盛2分流量传感器的安全操作和保养规程。
安全操作规程：1.在操作传感器之前，应先熟悉传感器的操作手册和安装指南，并按照指南正确安装传感器。
2.在安装传感器时，应保证传感器与管道之间没有杂质和异物，以避免对传感器的损坏或影响测量准确性。
3.在操作传感器之前，确保仪表供电正常并处于安全状态。
4.传感器在使用过程中应避免受到剧烈震动和振荡，以免影响传感器的测量准确性。
5.避免在传感器周围有强磁场、高温或潮湿环境，以免影响传感器的性能和寿命。
6.传感器在测量液体流量时，应避免对传感器的浸入，防止液体对传感器的腐蚀和损坏。
7.避免在传感器周围有腐蚀性气体的存在，以免对传感器的材质和性能造成损害。
8.在操作传感器时，应遵循相关的安全规定和操作流程，切勿擅自拆卸或修理传感器。
保养规程：1.定期检查传感器的表面是否有腐蚀、污垢或磨损，如有需要及时清洗或更换传感器。
2.对于液体流量传感器，应定期检查传感器的密封件是否完好，并及时更换破损的密封件。
3.定期检查传感器的连接电缆是否松动或损坏，如有需要及时修复或更换。
4.对于电子设备内部的粉尘和杂物应定期进行清理，以保证仪器的正常运行。
5.定期校准传感器的测量准确性，可以参照仪器的校准手册进行校准或请专业人员进行测量校准。
6.在长时间不使用传感器时，应将传感器存放在干燥、通风、无腐蚀性气体的环境中，以避免传感器受潮或发生损坏。
以上是对赛盛2分流量传感器的安全操作和保养规程的介绍。
通过正确的操作和定期的保养，不仅可以保证传感器的正常运行和测量准确性，还可以延长传感器的使用寿命，提高传感器的工作效率。
因此，在使用赛盛2分流量传感器时，请务必严格遵守以上规程，确保传感器的安全可靠。
消防流量传感器型号及参数详解
消防流量传感器是一种能够实时监测消防设备中水流的设备,并将相应数据输出给消防控制系统以实现消防系统的智能化控制。
下面是常见的消防流量传感器型号及其参数的详细介绍：
1. FLSC-02型消防流量传感器
参数：
- 测量范围：0.1-6m/s
- 测量误差：≤±2%
- 工作压力：1.6MPa
- 工作温度：0-60℃
- 电气接口：M20*1.5
- 输出信号：4-20mA、RS485、HART协议、Modbus
2. FLS-LG/N型消防流量传感器
参数：
- 测量范围：0.05-10m/s
- 测量误差：≤±1%
- 工作压力：1.6MPa
- 工作温度：0-60℃
- 电气接口：1/2 NPT
- 输出信号：4-20mA、RS485、HART协议、Modbus
3. VHSB-N型消防流量传感器
参数：
- 测量范围：0.3-6m/s
- 测量误差：≤±2%
- 工作压力：1.6MPa
- 工作温度：0-60℃
- 电气接口：1/2 NPT
- 输出信号：4-20mA、RS485、HART协议、Modbus
4. TDWZ-N型消防流量传感器
参数：
- 测量范围：0.5-10m/s
- 测量误差：≤±2%
- 工作压力：1.6MPa
- 工作温度：0-60℃
- 电气接口：M20*1.5
- 输出信号：4-20mA、RS485、HART协议、Modbus
以上是一些比较常见的消防流量传感器型号及其参数介绍,具体选择时需要根据实际需要进行选择。
Flow sensors SFAB2d Internet: /catalogue/...Subject to change – 2023/08Flow sensors SFABKey featuresAt a glance4[1] Quick and secure installationthanks to QS fitting[2] Display can be rotated 270°[3] – High-contrast LCD display withblue background and white 9-segment display– Bar chart depicts current measured value– Switching point-dependent colour change [4] Central electrical connection viaan M12 plug[5] Panel mounting of the sensorusing retaining screws 5 measuring ranges from0.1 … 10 l/min to 10 … 100 l/min [6] Manifold mounting of the sensorwith H-rail or individually with adapter plate for wall mountingImpressive, straightforward, reliable Easy to operateThe flow sensors, featuring an attrac -tive display and control concept, are very impressive when it comes to:• Leakage detection in production • Leak testing of end products • Flow monitoring in parts feedingThe sensor provides:• Absolute flow rate information – with threshold values and – convenient switching point adjustment via a display • Cumulative air consumption measurement• Patented – adjustable consump-tion-based switching pulse for cu-mulative air consumption measure-ment via the switching output • A large, illuminated LCD display increases the operational safety and makes the currently displayed flow rate or consumption values easy to read.• Measured values outside the measuring range are visualised: flow rates are shown flashing.• Values that fall below or exceed the threshold values can also be identified from a distance or if the sensor is in an inaccessible location by the display changing colour.• Simple checking of the current sensor settings in SHOW mode • Simple switching between consumption and flow rate indicationFlexible installationSystematically more reliable Convenient This is made possible by the extremely compact design that dispenses with an upstream laminar flow inlet and outlet – the SFAB has an integrated flow steadying channel.The sensor can provide precise infor-mation even when flow conditions are fluctuating and unreliable thanks to the very large measuring range.• Clear and fast menu navigation • Integrated QS fittings • Fast teach-in • Rotatable display• Secure connections with extremely short assembly times•Manual consumption measurement with start/stop and reset functionalityAdvantages For the designerFor the machine operator• Owing to the high dynamic response of the measurement and large measuring range, a rough estimate of the system air consumption is sufficient to configure the sensor• Festo plug and work solution• The same device can be used for different applications• The sensor covers a large measuring range with a specified accuracy thanks to its high dynamic response of 1:100• NPN/PNP can be switched via the software • Minimal assembly times• Alternatively with 4 ... 20 mA or 0 ... 10 V analogue output• Flexible installation without restrictions caused by laminar flow inlets, any mounting position• Large choice of pneumatic connections is provided by the modular system • Construction of more powerful machines• Precise information is available even with fluctuating pressure conditions • Flow values can be read easily and reliably• Visualisation of deviations (colour change, flashing value)• Easy operation, no need for training • Greater system reliability •Values shown on the display:– can be shown for flow and consumption for different standard conditions – can be filtered/averaged independently of the analogue output in the case of high dynamic response of the measurement• Fast commissioning thanks to easy-to-use, intuitive teach-in functionFlow sensors SFAB Peripherals overview3 2023/08 – Subject to change d Internet: /catalogue/...Flow sensors SFABType codes4d Internet: /catalogue/...Subject to change – 2023/0852023/08 – Subject to changed Internet: /catalogue/...Flow sensors SFABData sheetFunction• Analogue output 0 ... 10 V , adjustable switching outputs 2x PNP or 2x NPN• Analogue output 4 ... 20 mA, adjustable switching outputs 2x PNP or 2x NPN• Freely selectable pulse output for consumption measurement• Analogue filter for setting the rise time• Digital filter for smoothing thedisplay valuesFlow sensors SFABData sheet1) Accuracy with nominal conditions (6 bar, 23°C and horizontal mounting position)2) % FS = % of the final value in the measuring range (full scale)6d Internet: /catalogue/...Subject to change – 2023/08Flow sensors SFAB Data sheet7 2023/08 – Subject to change d Internet: /catalogue/...Flow sensors SFABData sheet8d Internet: /catalogue/...Subject to change – 2023/08Flow sensors SFAB Data sheet9 2023/08 – Subject to change d Internet: /catalogue/...Flow sensors SFABOrdering data – Modular product system[1] Q6, T14 Not with flow measuring range 200, 600, 1000[2] Q8, T516 Not with flow measuring range 600, 100010d Internet: /catalogue/...Subject to change – 2023/08Flow sensors SFAB AccessoriesAdapter plate SDE1- ...-W ...For wall or surface mounting Material:Steel1) Included in the scope of delivery with SFAB-...-W...1) Additional accessories may be required for adaptation to the pneumatic connection.11 2023/08 – Subject to change d Internet: /catalogue/...Festo - Your Partner in AutomationConnect with us/socialmedia 1Festo Inc.2Festo Pneumatic 3Festo Corporation 4Regional Service Center 5300 Explorer DriveMississauga, ON L4W 5G4CanadaAv. Ceylán 3,Col. Tequesquináhuac 54020 Tlalnepantla, Estado de México1377 Motor Parkway Suite 310Islandia, NY 117497777 Columbia Road Mason, OH 45040Festo Customer Interaction CenterTel:187****3786Fax:187****3786Email:*****************************Multinational Contact Center 01 800 337 8669***********************Festo Customer Interaction Center180****3786180****3786*****************************S u b j e c t t o c h a n g e。
