气体仪器及采集控制终端通讯协议----南京更佳电子科技有限公司Version date author NoteV0.12015-12-12尹志军 CreateV0.22015-12-22尹志军修改 AH =0; AL =0寄存器为通道个数1. 概述气体仪器成为工业生产、日常生活中极其重要的检测工具,与健康、安全、舒适密切相关。
但是国内各厂家各自为阵,通讯接口标准纷繁杂乱。
而且协议不公开,导致国内外不同厂家的产品无法对接。
为此, 南京更佳电子愿意成为行业通讯标准的领导者, 以行业标准化为己任, 联合各行业的专家对气体产品功能进行深刻分析,制定出实用、统一、清晰的通讯协议。
该协议适用于如下产品:1 气体变送器(在线式气体检测仪,总线接口适用、红外通迅适用、显示板接口适用2 单一便捷式气体检测仪3 多合一便捷式气体检测仪4 单点壁挂式气体检测仪5 气体采集主机(气体控制主机,单通道、双通道、四通道、八通道、十六通道、三十二通道、六十四通道均适用; RS485总线适用、以太网接口适用6 气体变送器显示板(自带 CPU 型2. 通讯协议2.1. 通讯属性1 总线通讯协议:适用于 RS232、 RS485、 MBUS 、 PowerBUS波特率:默认为 1200;(波特率可通过菜单调整起始位:1bit数据长度:8bit校验类型:无停止位:1bit通讯原则:此协议中,被访问仪器作为从设备,等待外部命令并按协议进行回复。
2 网络通讯协议:适用于 IPV4(10M/100M/1000M、 GPRS 远程通讯默认 IP 地址:192.168.1.188默认 IP 掩码:255.255.255.0默认 IP 网关:192.168.1.1默认 IP 端口号:9002通讯原则:此协议中,被访问仪器作为服务器,等待外部连接。
连接成功后,等待客户端的 MODBUS 指令并按协议进行回复。
2.2. 通讯帧结构通讯帧遵循通用 MODBUS帧格式。
testo 316-EX · gas leak detector Instruction manual21 Safety and the environment1Safety and the environment1.1.About this documentUse> Please read this documentation through carefully andfamiliarize yourself with the product before putting it to use. Payparticular attention to the safety instructions and warning advicein order to prevent injuries and damage to the products.> Keep this document to hand so that you can refer to it whennecessary.> Hand this documentation on to any subsequent users of theproduct.1.2.Ensure safety> Do not operate the instrument if there are signs of damage at the housing, mains unit or feed lines.> Only operate the product properly, for its intended purpose and within the parameters specified in the technical data. Do notuse any force.> Do not store the product together with solvents. Do not use any desiccants.> Only use the device in closed, dry rooms and protect it from rain and moisture.> Carry out only the maintenance and repair work on thisinstrument that is described in the documentation. Follow theprescribed steps exactly. Use only original spare parts fromTesto.1.3.Protecting the environment> Dispose of faulty rechargeable batteries/spent batteries inaccordance with the valid legal specifications.> At the end of its useful life, send the product to the separatecollection for electric and electronic devices (observe localregulations) or return the product to Testo for disposal.32 Specifications42 Specifications2.1.UseThe testo 316-EX is a gas leak detector for the short-term detection of gases in areas at risk of explosion according to Directive 2014/34/EU (ATEX).Areas of application are the gas detection in rooms and the location of leaks at gas systems. The instrument is designed for use by trained personnel. For operation in areas at risk of explosion, also observe the Safety instructions document.Explosion limits of flammable substancesA flammable substance in the air has a lower explosion limit (LEL) and an upper explosion limit (UEL). The air/gas mixture isflammable anywhere between these two limits, potentially leading to an explosion (critical range). Below the LEL, the mixture is too lean for an explosion, and above the UEL it is too rich (non-critical range).The explosion limits depend on the substance:• Methane CH4: LEL 4.4 vol% / UEL 16.5 vol%• Propane C3H8: LEL 1.7 vol% / UEL 10.9 vol%• Hydrogen H2: LEL 4.0 vol% / UEL 77.0 vol%Restrictions of the application rangeDo not use the instrument as a monitoring instrument for personal safety! The testo 316-EX is no protective equipment!Do not use the instrument as a gas analyzer! The sensor detects almost all flammable gases to the same extent.2 Specifications5 2.2. Technical dataCharacteristicValuesType Semi-conductorResponse threshold 1 ppmReaction time (t90) 14 sMeasuring range Methane CH4: 0 ppm up to 2.5 vol%Propane C3H8: 0 ppm up to 1.0 vol%Hydrogen H2: 0 ppm up to 2.0 vol%Accuracy (at 20 to 50 % RH, 0 to 40 °C/32 to 104 °F)at 100 ppm: -50 ppm to +150 ppm at 0.1 vol%: -250 ppm to +0.2 vol% Accuracy (at20…50 % RH,-10 to 0 °C/14 to 32 °F) at 100 ppm: -60 ppm to +150 ppm at 1,0 Vol%: -0,4 Vol% to +0,3 Vol%Accuracy at 50% LEL (at 20 to 50 % RH, 0 to 40 °C/ 32 to 104 °F)CH4 (2.2 Vol%): -0.2 to +0.2 Vol% C3H8 (1.0 Vol%): -0.2 to +0.3 Vol% H2 (2.0 Vol%): -0.2 to +0.2 Vol% Resolutionat 0 to 999 ppm: 1 ppm at 0.1 to 2.5 vol%: 0.1 vol% Power supply 2 x 1.5 V mignon/AAType approved for use in areas at risk of explosion: CamelionAlkaline PLUS AABattery lifeapprox. 6 h (typical) Storage/transportconditions-10 to 50 °C / 14 to 122 °F 0 to 70 % RH Operatingconditions-10 to 40 °C / 14 to 104 °F 20 to 80 % RH not condensing Weight approx. 200 g/0.44 lb. (incl. battery) Dimensions (L x W x H) Housing: approx. 135 x 45 x 25 mm / 5.31 x 1.77 x 0.99"Long, flexible sensor shaft includingsensor head: approx. 200 mm/7.87"Protection class IP542 Specifications6Characteristic ValuesEC Directives 2014/34/EU (ATEX)EN 60079-0: 2012 + A11:2013EN 60079-11: 2012ATEX instrumentlabelling1258 II 2 G Ex ib IIC T1Gb3 Product description3Product description3.1.Overview1 S ensor head with gas sensor and exchangeable protection cap2 F lexible sensor shaft3 A larm LED4 D isplay5 R eadiness LED6 Battery compartment (on rear)7 Control key8 On/off switch74 First steps84 First steps4.1.CommissioningInserting batteries✓ The instrument is switched off.1. Open battery compartment (on rear of instrument) usingenclosed Allen key. Battery type approved for use in areas at risk of explosion: Camelion Alkaline PLUS AA2. Insert batteries/rechargeable batteries (observe the polarity!).3. Close battery compartment, tighten Allen head bolt by hand.4.2. Getting to know the productSwitching onOnly switch on the instrument in fresh air as an automatic zeroing is performed at the end of the warm-up time. The ambienttemperature during zeroing should correspond to the temperature at the measuring location. If required, zero again manually at themeasuring location.When not in use for a long period of time, the sensor becomes contaminated due to oxidation, causing the zero point to become unstable. If the instrument has not been in operation for a long period of time (> 2 weeks), it must be switched on approx. 30‑45 minutes before use andthereafter zeroed manually.If the instrument has been stored at temperatures <0°C/<32 °F, it must be switched on 10 minutes before use and thereafter zeroed manually. > Push up on/off switch on the right side of the instrument. - T he sensor is warmed up (duration: approx. 60 s).During the warm-up time, the following information is shown in succession:• All segments light up. Display segment test• WAIT : wait• V3.03 (example): firmware version (important information inthe event of service)4 First steps9• T126 (example): sensor table version (important informationin the event of service)• PPM : measuring unit, alarm LED (red) and status LED(green) alternately light up• Display light is switched on• 152 (example): check value (important information in theevent of service)• CH4 (methane), C3H8 (propane) or H2 (hydrogen): set gastype• EN (English), DE (German), FR (French), ES (Spanish), IT(Italian) or CS (Czech): set instrument language• batt and bar graph: remaining battery capacity• NP and two short signal tones: automatic zeroing isperformed- T he instrument is ready for use if the status LED (green) lightsup and a reading is shown in the display.- With ToN3 (readiness tone) function activated, a short signaltone is also emitted every 20 s as an indication of the readiness for operation.Switching off> Push down on/off switch on the right side of the instrument. Set languageThe instrument language is set to EN (English) in the condition on delivery. Proceed as follows to change the instrument language: ✓ The instrument is in the measurement view.1. Press and hold [--> 0 <--] for approx. 8 s until a pulsed signaltone sequence sounds.2. Repeatedly press [--> 0 <--] briefly until LANGUA is shown.3. Press and hold [--> 0 <--] until the display changes.4. Repeatedly press [--> 0 <--] briefly until the desired language isshown: EN (English), DE (German), FR (French), ES (Spanish), IT (Italian) or CS (Czech).5. Press and hold [--> 0 <--] until the display changes.- EXIT is displayed.6. Press and hold [--> 0 <--] until the display changes.- The instrument is once again in measurement view.5 Using the product10 5 Using the product5.1. Performing settingsOpen configuration menu✓ The instrument is in measurement view.> Press and hold [--> 0 <--] for approx. 8 s until a pulsed signaltone sequence sounds.- The instrument is in configuration view.Selecting, opening and setting functions> To select the next function: Briefly press [--> 0 <--].> To open the selected function: Press and hold [--> 0 <--] untilthe display changes.> To set the opened function: Briefly press [--> 0 <--].> To end the function: Press and hold [--> 0 <--] until the displaychanges.Adjustable functionsEnsure correct settings: All settings are applied immediately; there is no cancel function.Function Setting options/commentsLIGHT (display light) OFF (display light cannot be activated) or ON(display light can be activated)SOUND1 (alarm tone) ON (acoustic alarm on) or OFF (acousticalarm off).The frequency sequence of the alarm tonebecomes faster with a higher concentration.ALARM (alarmthreshold) Any value within the measuring range. If a value above the measuring range final value is set: The alarm tonesounds after reaching the measuringrange final value (CH4: 2.5 vol%,C3H8: 1.0 vol%, H2: 2.0 vol%).The respective flashing number can be set;the number that can be set changes if abutton is not pressed for 5 s.5 Using the product11 Function Setting options/commentsPROBE (detection characteristic curve) CH4 (methane), C3H8 (propane) or H2 (hydrogen)SOUND3(readiness tone)OFF (readiness tone off) or ON (readiness tone on). A short signal tone every 20 s. CONTRAST(display contrast)Value between 0005 and 0025 LANGUA (instrumentlanguage) EN (English), DE (German), FR (French), ES (Spanish), IT (Italian) or CS (Czech)Exit (close configuration menu) -5.2. Performing gas detectionCAUTIONDestruction of the sensor by external influences!> Do not expose the sensor to high concentrations of H 2S(hydrogen sulphide), SO x (sulphur dioxides), Cl 2 (chlorine) or HCl (hydrogen chloride).> Avoid contact between alkaline materials or water and thesensor.> Avoid the effect of moisture and frost on the sensor.Have the instrument calibrated by the manufacturerannually.Checking natural gas pipelines or hydrogen pipelines:Methane (the main constituent of natural gas) andhydrogen are lighter than air. The detection should takeplace above the line/the suspected leak.Checking propane gas pipelines: Propane is heavier than air. The detection should take place below the line/thesuspected leak, starting from the ground up. > Guide the sensor head as near as possible and at a low speed(approx. < 2 cm per second) over the components that are to be checked for leaks.- If the set alarm value is exceeded, the Alarm LED lights up red.If the acoustic alarm is switched on a warning tone also sounds,5 Using the product12the frequency sequence of which becomes faster as theconcentration increases.Manually perform zeroingIt is only possible to manually set the zero point if the gasconcentration currently detected is below 1000 ppm.Gas concentrations present at the point of the zeroing aresuppressed by means of the zeroing. The reading showntherefore no longer conforms to the gas concentrationactually present.✓ The instrument is in the measurement view.> Briefly press [--> 0 <--].- The zero point is reset.Switching display light on/off✓ The instrument is in the measurement view.✓ The LIGHT function is activated.> Press and hold [--> 0 <--] until a signal tone sounds.- The display light is switched on or off.- The display light automatically goes out if no buttons are pressed for 2 minutes.6 Maintaining the product136 Maintaining the productChanging the batteriesDo not change the battery in areas at risk of explosion. ✓ The instrument is switched off.1. Open battery compartment (on rear of instrument) usingenclosed Allen key.Battery type approved for use in areas at risk of explosion: Camelion Alkaline PLUS AA2. Remove empty batteries and insert new batteries (observe thepolarity!).3. Close battery compartment, tighten Allen head bolt by hand. Cleaning the instrument> I f the housing of the instrument is dirty, clean it with a dampcloth.Do not use any aggressive cleaning agents or solvents! Weak household cleaning agents and soap suds may be used. Clean protection capContamination at or in the protection cap can be removed using compressed air. CAUTIONDestruction of the sensor> With the sensor protection cap open, take care that the sensoris not damaged.>Do not direct the compressed air jet at the sensor, do not touchthe sensor.1. Carefully unscrew protection cap from sensor shaft.2. Blow out protection cap and then screw on again.7 Tips and assistance147 Tips and assistance7.1. Questions and answersQuestionPossible causes Possible solution Error isdisplayed. Instrument error > Contact Testo Customer Service oryour dealer.F30 is shown and the red LED lights upSensor faulty > Contact TestoCustomer Service oryour dealer. Zero pointinstable Contamination of the sensor due to oxidation during long periods of non-use> Leave instrument switched on until thezero point stabilizes(can take up to 45 minutes).The instrument does not change tomeasuringmode (remainsin the warm-upphase)Battery voltage toolow> Change batteries. If we could not answer your question, please contact your dealer or Testo Customer Service. You can find the contact data in the Internet under: /service-contact7 Tips and assistance157.2. Accessories and spare partsDescription Article no. Camelion Alkaline PLUS AA battery, 1 pc. Note: 2 batteries are required for thetesto 316-EX0515 0316 Sensor protection cap 0180 03160977 3166 en 08。
Instruction manualtesto 316-2Leakage detector for gasSafety and environment2Safety and environmentOn this document> Read this document through carefully, and familiarize yourself with the product before you put it to use. Keep this documentation close to hand in order to be able toconsult it if required. Pass this documentation on to later users of the product.> Pay particular attention to information which is marked with the following symbols:· W ith the signal word Warning!:Warns of dangers which can lead to serious injury if the prescribed safety measuresare not taken.· W ith the signal word Attention!:Warns of dangers which can lead to light injuries or material damage if the prescribedsafety measures are not taken.· Important informationAvoiding personal injury/material damage> U se the measuring instrument only for the purpose for which it is intended, and within the parameters stated in the technical data. Do not use force.> I f damage, malfunction or incorrect display occur, have the instument checked. Do not use faulty instruments.> Do not carry out measurements with the product on or near live parts.> N ever store the product together with solvents, acids or other corrosive substances. > C arry out only repair and maintenance work described in the instruction manual.Observe the prescribed handling steps. Use only original spare parts from Testo. Protecting the environment> D ispose of faulty rechargeable batteries/empty batteries at the proper collection points.> S end the product back to Testo at the end of its life. We will ensure that it is disposed of in an environmentally friendly manner.Specifications3 SpecificationsFunctions and applicationThe testo 316-2 is a gas leak detector for the fast and reliable detection of leakages on gas pipes.monitoring instrument for your personal safetyThe sensor head cannot be removed!Do not use on live parts!Do not use the instruments in environments with over 80 %RH (condensive).O bserve permitted storage and transport temperature as well as the permittedoperating temperature (e. g. protect measuring instrument from direct sunlight)!D o not use testo 316-2 in closed rooms in which gases have collected into anexplosive mixture.E nsure that the gas concentration does not exceed 20 % LFL (Lowerflammability limit).Always carry out a functionality test before gas detection.S etting the sensitivity of the sensor in gas-contaminated surroundings lowersthe alarm thresholds.T he warranty becomes void if the instrument is not used as intended or if forceis applied!Do not allow the sensor to come into contact with moisture or acids, as it willreact cross-sensitively.Specifications4Technical dataTechnical measuring dataSensor: Gas-sensitive semi-conductor· Reaction threshold: 10 ppm bei C3H8, CH4 und H2 · Reactions time: <2s· Alarm thresholdsFurther instrument dataOperating conditions: -5 to 50°C / 23 to 122°F / 20 to 80%RH, with limited functionality (only audible indi-cation, reduced accuracy, reduced operating time) can also be used in the range -20°C to -5°C / -4 to 23°F· Storage/transp. conditions: -25...60°C / -13...140°F/ 20...80%rF· Minimum bend radius gooseneck: 40 mm· Current supply: Rech. battery pack NiMh · Battery life: appprox. 6h (at 22°C / 72°F)· Charging time: approx. 8h· Dimensions: 57 x 190 x 42mm· Weight: 348gGuidelines, norms and tests· Instrument complies with worksheet DVGW G465-4Sensor dataM eas. parameter Measuring range Bar display Reaction time CH4 10 ppm to 4.0 Vol. % 1 - 18 bars < 2 sec. with pumpC3H8 10 ppm to 1.9 Vol. % 1 - 18 bars < 2 sec. with pumpH2 10 ppm to 4.0 Vol. % 1 - 18 bars < 2 sec. with pumpAlarm thresholdsM eas. parameter 1. Alarm threshold 1. Alarm 2. Alarm threshold 2. Alarm(12 bars) Accuracy (17 bars) AccuracyCH4 200 ppm ±2 bars 10.000 ppm ±2 bars C3H8 100 ppm ±2 bars 5.000 ppm ±2 bars H2 200 ppm ±2 bars 10.000 ppm ±2 barsProduct description5 Product descriptionAt a glanceÀS ensor head with gas sensor.ÁF lexible probe shaft.ÂT op: earplug socket, mains unit socket.ÃD isplay.Ä Operating buttons.Display and operating elementsDisplay MeaningColour of the display illuminationgreen No gas detected.red Gas detected.SymbolsG as concentration trend display: No gas detected / Gas detected.G as concentration trend display: First alarm threshold / Second alarm threshold.G as concentration maximum value display : Maximum gas concentration detectedsince the last reset of the maximum display or since the last time the instrumentwas switched on.Type of gas to be detected.Suppress background concentrationBattery capacity: Battery full / battery partly discharged / remaining capacity < 15min.Audible signal: on / off.Buttons FunctionInstrument: on / off.Type of gas to be detected: Select.Audible signal: on / off.+Trend display is resetone-off suppression of the background concentration (1. alarm threshold only),cancel suppression6First stepsAudible notificationThe audible notification takes place with a signal tone whose interval frequency increases with increasing gas concentrations. A continuous signal sounds when the second alarm threshold is passed.First stepsã Charging battery:Use only the original mains unit 0554 1093!The rechargeable battery can only be charged at an ambient temperatureof 0 to 45°C ( 32 to 113°F).If the rechargeable battery is completely discharged, charging takes approx. 8h.In order to ensure as long a battery life as possible, the battery shoud always becompletely discharged and recharged.The instrument can continue to be used during charging.1Plug the mains plug into the country-specific adapter and then plug into the mains socket.2Plug the instrument plug into the mains unit socket of the instrument.- Charging begins: , and light up alternately.- Charging stops automatically when the rechargeable battery is full: lights up.ã Using the earplug:Use only the original earplug 0554 5001!The instrument loudspeaker is deactivated when the earplug is plugged in!> Plug the connection plug of the earplug into the earplug socket of the instrument.Using the product7 Using the productã Switching on the instrument:1 Press .- All display segments light up (duration: 3 sec), the suction pump starts (ventilator noise).- The initialization phase is carried out (heating, auto-test). The remaining duration is displayed.- After the end of the initialization phase: OK lights up (duration: 2 sec).Attention! Danger of burning from the hot sensor head after prolonged use!>B efore touching the sensor head or packing up the instrument, switch offand allow to cool.ã Selecting gas to be detected:> Press several times, until the arrow lights up under the desired gas type.ãSuppress background concentration> Press .- lights up. The background concentration is suppressed.> Press again.- goes out. Background suppression is removed. The current gas concentration is displayed.Using the product8ã Carrying out gas detection:Attention! Destruction of the sensor by non-desorbant substances (e.g. oils)!>Do not use the instrument in dirty surroundings.> Move the sensor head as close as possible, and slowly (3 to 5 cm per second) over the parts which are to be examined for leaks.ã Resetting maximum value display:> Press and simultaneously.ã Switching instrument off:> Press and hold until the display switches off.Maintaining the product9 Maintaining the productâ Charging the rechargeable battery:See chapter “First steps”â Cleaning the sensor:Tobacco smoke, dirty air, oils, grease, silicones and evaporating liquids or gases can lead to deposits on the surface of the sensor. This can result in reduced sensitivity and falsified display of concentrations. If necessary clean the sensor.> Switch on the instrument, wait until the end of the initialization phase and switch off again. Repeat this procedure several times.â Clean the sensor head from the outside> If dirty, clean the sensor head with a soft dry cloth.â Cleaning the housing:> If dirty, clean the housing with a damp cloth (soap solution). Do not use aggressive cleaning products or solvents!â Switching on regularlyIf the instrument is used infrequently, deposits may build up on the sensor.Switching the instrument on prevents deposits building up on the sensor. Testorecommends switching the instrument on regularly to avoid deposits building upon the sensor.â Storage & transportationTo avoid contamination of the sensor, the instrument should not be storedor transported in an environment where there is tobacco smoke, foul air, oils,greases, silicones or evaporating liquids or gases. Any sensor that is contaminated as a result of storage or transportation must be cleaned before use, see Cleaning the sensor.â Regular servicing:Testo recommends yearly servicing of the gas detector by an authorized servicecentre.Tips and assistance10Tips and assistanceQuestions and answersQuestion Possible causes / solutions“Error 01” · I nstrument error: please contact your dealer or Testo customer service.“Error 02” · S ensor defective (wire breakage): please contact your dealer or Testo customerservice.“Error 03” · S ensor connection faulty: Steckverbidnung des Sensorkopfes prüfen Pleasecontact your dealer or Testo customer service“Sensor” blinkt · S ensor dirty: clean sensor, see chapter “Maintaining product”.If we were not able to answer your question, please contact your dealer or Testocustomer service. For contact data, see back of this document or web page www.testo.com/service-contact.Accessories and spare partsDescription Part no.Earplug 0554 5001 Mains unit 0554 1093 testo 316-2 0632 316211 e d n e。
医用液体和气体用小孔径连接件泄露试验方法原标题：YY/T 0916.1-2023医用液体和气体用小孔径连接件泄露试验方法孔径连接件按照YY/T0916.1-2023标准中规定，适用于医疗器械特定领域。
如血压计连接管路、止血带、肠给养器、中心静脉导管、注射器、皮下注射针、外周静脉导管、血管内输液器等等。
标准中附录E给出了特定用途的医用领域和对应医疗器械产品。
小孔径连接件泄漏测试用什么检测仪器？鲁尔接头性能测试仪众测机电研发生产的鲁尔接头性能测试仪LEY-T01检测仪器用来测定小孔径连接件泄露，也称为小孔径连接件泄漏测试仪，本试验机除了能够满足GB 1962.1、GB1962.2规定的测试项目之外，还适用于YY/T 0916.1-2023规定的测试项目。
小孔径连接件泄漏试验方法1、将小孔径连接件与目标过盈连接件或结构进行组装,以大约为 10 N/s1N/s 的速率施加a)70N士1N的轴向力,同时施加0.12 Nm002Nm力矩,或旋转不超过90、力矩从顺时针方向施加。
2、保持该组装力和力矩或旋转角度10s士1s。
3、在无任何锁合或解锁合机构的作用下,释放该施加的力和力矩。
4、将式样链接到LEY-T01鲁尔接头性能测试仪上，使试评价小孔径连接件和目标过盈/干涉连接件或结构以及管路(B.3616)的出口保持同一水平面。
5、仪器自动充水，直到孔或管路端有水滴落。
6、将注射器置于称重仪上,按下皮重键清零。
7、用水充入注射器。
8、对充水注射器在称重仪上称重,并记录该质量 m1,(注射器中水的重量)。
9、将充水注射器推入模拟配对连接件和止流夹的开口。
10、确定注射器和模拟配对连接件之间的连接在试验过程中没有水泄漏。
11、将称重盘放在称重仪上,按皮重键清零。
12、将称重盘放在孔或管路下方,这样使从管路出来的水收集到称重盘中。
13、慢慢推注射器芯杆使水在7s到15s内全部排出。
14、对装有从管部开口端收集的水称重盘称重，记录该质量 m2、这代表了没有从装配组件中泄漏的水。
