PMC功能讲述PMC功能和PMC程序编写的基本事项这里讲述以下内容：●PMC的基本功能●功能指令一览●种类编程语言梯形图级数 3 3 第一级执行周期4/8msec基本指令处理速度25nsec/step 1μsec/stepI/O Link最大信号点数2048/2048 1024/1024 0i-D ○○B 0i-Mate D —○T地址范围T0~T499,T9000~T9499 T0~T79,T9000~T9079C地址范围C0~C399,C5000~C5199 C0~C79,C5000~C5039K地址范围K0~K99,K900~K999 K0~K19,K900~K999D地址范围D0~D9999 D0~D2999A地址范围A0~A249,A9000~A9249 A0~A249,A9000~A9249 基本规格16字符符号扩展规格40字符基本规格30字符指令扩展规格255字符“○B”为软件包B包的标准配置。

I/O Link第二通道功能，为选项功能，需要指定。

使用符号和指令扩展规格时，需要使用FANUC LADDER-III软件。

系统信号#7 #6 #5 #4 #3 #2 #1 #0 地址R9091 FL FL2 RUN ON OFF FL ：1秒周期信号（ON/OFF 比1：1）FL2 ：0.2秒周期信号（ON/OFF 比1：1）RUN ：PMC运行ON ：常1信号OFF ：常0信号#7 #6 #5 #4 #3 #2 #1 #0 地址R9015 STPR RUNR STPR ：梯形图停止信号RUNR ：梯形图运行信号梯形图运行状态扫描周期梯形图运行开始信号R9015.0梯形图停止信号R9015.1梯形图运行状态R9091.2PMC的数据形式分为二进制形式、BCD码形式和位型三种。

CNC和PMC间的接口信号为二进制形式。

一般来说，PMC数据也采用二进制形式。

●带符号的二进制形式（Binary）●可进行1字节，2字节，4字节的二进制处理●可使用的数值范围如下1字节-128~+1272字节-32768~+327674字节-2147483648~+2147483647采用2的补码表示●在顺序程序中指令数据的长度和初始地址●在诊断画面（PMCDGN）确认2字节，4字节的地址数据时，地址号大的为高位地址。
