普通彩电IC芯片的代换一、CH-13机芯:该机芯使用了CH04T1301,1302,1303,1304,1306,1307,1308,1309等几种芯片。
其中需要注意的是:CH04T1303和1307芯片具有EW(枕效)信号输出和消磁控制信号输出,这2种芯片不能与其它的芯片相互代换。
代换注意事项:(1)CH04T1301为VS版本的CPU;CH04T1302为FS版本的CPU; 两种IC芯片最好不要直接代换,否则会出现收不到台,如果应急使用还需要更换所匹配的高频头。
(2)CH04T1306为默认的FS版本的CPU,但总线里面可以调整为VS版本使用,如果用CH04T1306代换1301时,需要把总线OPT.VS/FS和OPT.IIC都改为0,否则会收不到台;CH04T1306代换CH05T1302时需要注意IC的总线引脚(如果IC的31、32脚为总线,需要将OPT.IIC设置为1;如果IC的36、37脚为总线,则需要把OPT.IIC设置为0);(3)CH04T1309可以代换CH04T1308; CH04T1308可以代换CH04T1306、1304、1302、1301;如果代换IC芯片后出现图像上、下卷边现象,请注意适当的加大或减小R321B的阻值,但不能超过1K.并更换成代换所对应的IC芯片的存储器。
(4)CH04T1307可以直接代换CH04T1303CH-13机芯的代表机型有:CH-13机芯进总线的方法:用户遥控器将音量减到0,按遥控器的图像键设置为“亮丽”,长按“排序”键进入“M”状态,再按“菜单”键,在字符没有消失前长按“排序”键即可进入总线模式,通过上、下键翻页,左、右键调整数据。
二、CH-16机芯:(老机芯)CH-16机芯前期使用的芯片为TDA93**芯片,用于21—34寸彩电,长虹掩膜芯片为:CH05T16**系列(1)芯片TDA9373掩膜芯片有:CH05T1606、05T1608、05T1619;其中CH05T1619可以代换1606和1608,但1606和1608不能代换CH05T1619.(2)芯片TDA9370掩膜的芯片有:CH05T1602、1604、1607。
