北京现代新胜达技术亮点解读作者：樊啸来源：《汽车与驾驶维修》2013年第02期新胜达是北京现代于2012年底推出的一款高级运动型多功能车，该车搭载2.0TGDI发动机，匹配6挡全电子控制自动变速器，装备了全景天窗、车道偏离警告、电动后尾门、电子机械驻车、四轮驱动及自动泊车等系统。
为了加强广大读者对该车的了解，在此对其部分技术亮点进行简要介绍。
一、车载网络通信系统1 网络通信系统北京现代新胜达的通信网络由21个控制单元通过传动系统CAN通信（C-CAN）、车身CAN通信（B-CAN）和多媒体CAN通信（M-CAN）组成（图1），以执行系统控制功能。
根据通信协议，车身控制单元（BCM）是C-CAN与B-CAN通信的网关；智能钥匙（SMK）不是网关，通过B-CAN与C-CAN通信连接。
SMK的C-CAN通信可以接收信息但不能传送，SMK通过BCM传送与C-CAN通信相关的信息至控制单元。
仪表是C-CAN与M-CAN通信的网关。
2 诊断通信在老款车型上，控制单元通过K线路与诊断工具通信。
在新胜达车型上，统一诊断服务（USD）用于根据CAN通信线执行诊断（图2）。
二、车道偏离系统（LDWS）LDWS是安全系统，在车辆运行过程中，如果车辆偏离车道，之后系统会在视觉和听觉上警告驾驶员危险。
通过安装在挡风玻璃顶部的摄像头监视前方道路，若车辆在转向信号灯未亮时偏离车道，仪表板上的警告灯将点亮，同时蜂鸣器也会鸣响警告驾驶员。
1 系统结构组成LDWS主要包括带摄像头的控制单元、仪表、蜂鸣器、智能接线盒（SJB）及车身控制单元（BCM）等元件（图3）。
LDWS系统的工作示意图如图4所示。
2 LDWS警告条件（1）车辆行驶速度在60km/h以上。
（2）雨刮器未高速工作。
（3）LDWS开关必须置于ON位置。
3 LDWS系统的各种警告显示如图5所示。
三、电动尾门（PTG）新胜达装备了PTG系统，因此使用者可以通过操作按钮控制后尾门的自动打开、关闭以及扣紧碰锁，它使用内部开关或遥控器都可以很容易地进行操作。
