STa 6000扭矩测量仪更好、更快的检查质量，功能强大，操作灵活。

为质量监控人员和操作人员改善日常任务。

STa 6000质量轻便，设计紧凑，易于在生产线中使用。

可用于检查工具库和生产线上的工具及拧紧的螺栓，保证质量。

优质产品，为您的工具和工艺而打造产品特点直观彩色屏幕STa 6000配有彩色屏幕和直观的图标菜单，支持多语言版本，包含中文。

反馈清晰清晰显示反馈，可添加仪表式显示，对信息进行完全定制。

无需电脑一切都可以直接在设备上进行设置和分析－ 不再需要使用电脑！重量0.5 Kg 屏幕大小3.2” 320x240电池持续时间正常情况下使用8小时连续运行6小时(至少每30秒进行一次测试)传感器SRTT, SRTT-L, IRTT, MRTT, QRTT传感器mV/V 和 V 传感器内存16 GB - 1000 Pset 和工具 - 50000 个结果和曲线模块IRC-B, IRC-W, Barcode 便于检查当将ST a 6000安装到墙壁上并连接到SRTT -L上时，操作者可在生产前快速测试其工具。

如果生产线正在调整，则仅需更换SRTT-L 传感器，而不是整个系统。

备注－ 可预设定或新设定STa 6000使添加测试备注很容易。

可以提前准备注然后在STa 6000上快速选择。

可以随时在测试中添加新备注。

橡胶保护装置和支架STa 6000可配套一个橡胶保护装置，易于操作者拿握。

STa 6000支架可在配有或没有橡胶保护装置的情况下使用。

该橡胶保护装置牢靠但仍可便携。

E F C D A B防错工具测试和校准生产品质与生产线中使用的工具性能息息相关。

因此，在生产线上自始至终对工具进行检查至关重要。

借助STa6000质量人员能在生产线对工具进行巡检而不会干扰生产过程。

更佳的是，无需电脑即可进行设备编程。

可直接在设备上修改Pset或编程。

拧紧工具的校准和调整不再需要外包给其他公司。

借助于STa6000质量部门能够自己完成校准-仅仅需要通过以太网电缆或小型USB串行接口适配器将STa6000连接到阿特拉斯•科普柯控制器即可。
