产品规格书电池类型：圆柱型锂离子电池电池型号：HYY18650-2000(带PTC)制 定 审 核 批 准3.0 电池性能3.1电化学性能序号项目标准测试方法1 常温放电性能放电容量/标称容量×100％A）0.2C5A ≥100％B）0.5C5A ≥98％C）1C5A ≥95％在1标准大气压，环境温度25℃±2℃，相对湿度为35％～85％的条件下，电池0.5C标准充电后（以下若没有特别说明，均在此条件下放置，皆按此充电方式），搁置10min，分别以0.2C5A、0.5C5A、1C5A、进行放电至下限电压2.75V，循环三次，当有一次达到标准，即达到标准要求（下同）。
2 常温荷电保持能力剩余容量≥标称容量*85％恢复容量≥标称容量*90％开路电压减小率≤3％内阻增加率≤20％测量电池的初始状态和初始容量，电池标准充电后，开路放置28天，测量电池最终状态；以0.2C5A放电至2.75V，测量电池的剩余容量；0.5C/0.2C测量电池的恢复容量。
可循环三次，当有一次达到标准，即达到标准要求。
1.0 基本特性型号18650-2000外壳材质镀镍钢标称容量（0.2C5A）2000mAh 额定电压 3.7V最大充电电压 4.2 V放电截至电压 2.75V最大充电电流 1 C5A最大放电电流 1 C5A 电池直径（包PVC套）≤18.40mm电池高度（包PVC套） ≤65.30mm电池重量(Approx.) ≤45.2g内阻（Max, at 1000Hz.）≤60 mΩ(充电态)标准0.5 C5A×7.5hrs充电方法(CC/CV) 快速 1 C5A×2.5hrs.放电方法标准0.2 C5A×6 hrs.充电0℃～45℃放电-10℃～50℃操作温度贮存-20℃～25℃2.0 外形图3 循环寿命容量≥标称容量*80％测量电池的初始状态和初始容量，0.5C/0.2C循环300次后测量电池的最终状态。
18650单电芯规格书BATTERY CO., LTD. DOC NO.: QR-WI-733-003-002/A REV. : APAGE: 1 of 8Specification Approval Sheet (cylinder Cell) 产品规格确认书（圆柱电池）Model/型号：ZZ18650Capacity/容量：1500mAhVoltage/电压：3.7V制定（Prepared By）审核（CheckedBy）批准（ApprovedBy）DOC NO.: QR-WI-733-003-002/A REV. : APAGE: 2 of 81.0基本特性Basic performance型号Model BJ18650P 外壳材质Can Material 镀镍钢Nickel-plated 标称容量NominalCapacity，（0.2C5A）1300mAh额定电压Nominal 3.70V 充电截止电压Max 4.20 V 放电终止电压 2.80V 最大充电电流Max.Charge Current1C5A标准持续放电流10C5A最大瞬间放电电流Max. Discharge Curent20 C5A电池最大直径（光壳）18.5电池最大高度（光壳）66mm 电池重量(Approx.) 约36g 内阻（Max, at 1000Hz.）≤16mΩ充电方法Charge 标准0.2C5A×快速 1 C5A×操作温度Operating Temperature 充电Charge0℃～45℃放电Discharge-20℃～60℃贮存Storage-10℃～45℃2.0 外形图figure2.1结构图Structure3.0 主要放电曲线Mainly capability graphBJ18650P-1300mAh 15C Discharge Cruve BJ18650P-1300mAh 1C Charge CruveBJ18650P-1300mAh 13C Cycle Life BJ18650P-1300mAh -20℃Discharge CruveDOC NO.: QR-WI-733-003-002/A REV. : APAGE: 3 of 84.0 电池性能Characteristic若没有特别说明，电池在做各项试验前，均需在86KPa～106 KPa大气压，环境温度20℃±5℃，相对湿度为45％～75％的条件下，以0.2C5A恒流放电至终止电压2.8V，并在收到产品两周内进行以下试验。
03-Jan-202003-Jan-2020 NO:20202011Product Name wsrriors 18650 2000MAH 3.7V Lithium-ion battery warriors 18650 2000MAH 3.7V Lithium-ion battery SAFETY DATA SHEETHCS-2012 APPENDIX D TO §1910.1200Version 1Issue Date Product Name Revision date _____________________________________________________________________________________________ _____________________________________________________________________________________________1. IDENTIFICATION OF THE SUBSTANCE/MIXTURE AND OF THE COMPANY/UNDERTAKINGProduct identifierOther means of identification Product Code Voltage: 3.7VAmpere hour: 100MAHRecommended use of the chemical and restrictions on use Recommended Use Power supply Uses advised against No information availableDetails of the supplier of the safety data sheet Supplier Suzhou Xinlvzhou Electronics Co., Ltd Address No. 158 Sanji Road, Xiangcheng District, Suzhou, Jiangsu Postal Code 215131 Phone +86-512-68702665 FAX +86-512-68669435 E-mail ***********************.cnEmergency telephone number +86-512-687026652. HAZARDS IDENTIFICATIONGHS Classification Not classifiedLabel elementsSymbols/Pictograms None Signal word None Hazard Statements Not classified Precautionary Statements Prevention None Response None Storage None Disposal NoneHazards not otherwise classified (HNOC)Batteries may vent, ignite and produce sparks when subjected to high temperature, when damaged or abused(e.g., mechanical damage); may burn rapidly with flare-burning effect; may ignite other batteries in clothes proximity.This product should not present a health hazard when used under reasonable conditions. If contact with the internal components of the battery may be irritating to skin, eyes and mucous membranes. Fire will produce irritating, corrosive and/or toxic gases. Burning batteries may produce toxic hydrogen fluoride gas. Fumes may cause dizziness or suffocation.If the battery is discarded into the environment, the harmful contents inside may be dangerous.Unknown acute toxicity No information available3. COMPOSITION/INFORMATION ON INGREDIENTSChemical nature MixtureChemical Name CAS No Weight-% Lithium Cobalt Oxide (CoLiO2) 12190-79-3 40Aluminum foil 7429-90-5 29Carbon black 1333-86-4 21Copper 7440-50-8 8 Phosphate(1-), hexafluoro-, lithium 21324-40-3 24. FIRST AID MEASURESDescription of first aid measuresGeneral advice No effect under routine handling and use. If exposure to internal materials withincells due to damaged outer metal casing, the following actions are recommended.Inhalation If inhaled, remove from exposure and move to fresh air immediately. Rinse mouthand nose with water. Get medical aid immediately. DO NOT use mouth-to-mouthresuscitation. If breathing has ceased apply artificial respiration using oxygen anda suitable mechanical device.Skin Contact In case of contact, immediately flush skin with copious amounts of water for atleast 15 minutes while removing contaminated clothing and shoes. Wash clothingand shoes before reuse. Get medical aid.Eye contact Rinse immediately with plenty of water during at least 15-30 minutes, occasionallylifting the upper and lower eyelids. Check for and remove any contact lenses ifeasily possible. DO NOT rubbing eyes with hand. Get medical aid immediately.Ingestion Do not induce vomiting. If the injured is fully conscious: wash mouth out withwater, then give 2-4 cupfuls of milk or water. Never give anything by mouth to anunconscious person. Get medical aid immediately.Most important symptoms and effects, both acute and delayedSee Section 11 for more information.Indication of any immediate medical attention and special treatment neededTreat symptomatically and supportively.5. FIRE-FIGHTING MEASURESExtinguishing mediaSuitable extinguishing media Use extinguishing measures that are appropriate to local circumstances and thesurrounding environment.Unsuitable extinguishing media No information available.Specific hazards arising from the chemicalToxic vapor may release in case of fire. Thermal shock may cause battery case to crack open. Containers may explode when heated. Firefighting water runoff and dilution water may be toxic and corrosive and may cause adverse environmental impacts. On some bad using conditions (e.g., mechanical damage, external short circuit.) and in case of a bad functioning, some electrolyte can be removed from the cell by the security vent. Exposure to the ingredients contained within the battery pack could be harmful under some circumstances.Protective equipment and precautions for firefightersAs in any fire, wear self-contained breathing apparatus pressure-demand, MSHA/NIOSH (approved or equivalent) and full protective gear. Evacuate personnel to safe areas.6. ACCIDENTAL RELEASE MEASURESPersonal precautions, protective equipment and emergency procedures_____________________________________________________________________________________________Toxic vapor may release in case of fire. Thermal shock may cause battery case to crack open. Containers may explode when heated. Firefighting water runoff and dilution water may be toxic and corrosive and may cause adverse environmental impacts. On some bad using conditions (e.g., mechanical damage, external short circuit.) and in case of a bad functioning, some electrolyte can be removed from the cell by the security vent. Exposure to the ingredients contained within the battery pack could be harmful under some circumstances.Methods and material for containment and cleaning upAvoid dispersal of spilled material and runoff and contact with soil, water ways, drains and sewers.Remove all sources of ignition or heat. Stop leak if safe to do so. Move containers from spill area. Carefully collect undamaged batteries in a clean, dry and appropriate container for reuse or disposal. If electrolyte leaks or spills, collect all released material in an appropriate container before proper disposal.7. HANDLING AND STORAGEPrecautions for safe handlingThis product should be stored, handled and used in accordance with good industrial hygiene practices and in conformity with any legal regulation. Eating, drinking and smoking should be prohibited in areas where this material is handled, stored and processed. Wash hands, forearms and face thoroughly after handling chemical products, before eating, smoking and using the lavatory and at the end of the working period.Conditions for safe storage, including any incompatibilitiesStore in a cool and dry area, but prevent condensation on cell or battery terminals. High temperature may damage the performance of the battery. Protect from physical damage and short circuits. To avoid risk of fire or explosion, keep sparks and other sources of ignition away from the battery. Do not allow metal objects to simultaneously contact both positive and negative terminal of batteries. Do not stack battery directly on another battery. Do not store batteries on electrically conductive surfaces.8. EXPOSURE CONTROLS/PERSONAL PROTECTIONControl parametersChemical Name ACGIH TLV OSHA PEL NIOSH IDLH Denmark European Union Lithium Cobalt Oxide(CoLiO2) (CAS #:12190-79-3)TWA: 0.02 mg/m3Co - - TWA: 0.01 mg/m3-Aluminum foil (CAS #: 7429-90-5)TWA: 1 mg/m3respirable fractionTWA: 15 mg/m3 totaldustTWA: 5 mg/m3respirable fraction(vacated) TWA: 15mg/m3 total dust(vacated) TWA: 5mg/m3respirablefraction (vacated)TWA: 5 mg/m3 AlAluminumTWA: 10 mg/m3total dustTWA: 5 mg/m3respirable dust TWA: 5mg/m3AlTWA: 5 mg/m3TWA: 2 mg/m3-Carbon black (CAS #: 1333-86-4)TWA: 3 mg/m3inhalable fraction- IDLH: 1750 mg/m3TWA: 3.5 mg/m3TWA: 0.1 mg/m3Carbon black inpresence of Polycyclicaromatic hydrocarbonsPAHTWA: 3.5 mg/m3-Copper (CAS #: 7440-50-8) TWA: 0.2 mg/m3fume TWA: 1 mg/m3Cu dust and mist - IDLH: 100 mg/m3dust, fume and mistIDLH: 100 mg/m3 Cudust and mistTWA: 1 mg/m3 dustand mistTWA: 0.1 mg/m3fume TWA: 1 mg/m3Cu dust and mistTWA: 1.0 mg/m3TWA: 0.1 mg/m3-Phosphate(1-), hexafluoro-,lithium (CAS #: 21324-40-3)TWA: 2.5 mg/m3F - - TWA: 2.5 mg/m3-_____________________________________________________________________________________________Chemical Name Latvia France Finland Germany Italy Lithium Cobalt Oxide(CoLiO2) (CAS #:12190-79-3)- TWA: 0.02 mg/m3Skin -Aluminum foil (CAS #: 7429-90-5) TWA: 2 mg/m3TWA: 10 mg/m3TWA: 5 mg/m3TWA: 1.5 mg/m3 TWA:4mg/m3TWA: 1.5 mg/m3-Carbon black (CAS #: 1333-86-4) TWA: 3.5 mg/m3 TWA:3.5mg/m3STEL: 7 mg/m3Skin -Copper (CAS #: 7440-50-8) TWA: 0.5 mg/m3STEL: 1 mg/m3TWA: 0.2 mg/m3TWA: 1 mg/m3STEL: 2 mg/m3TWA: 1 mg/m3TWA: 0.1 mg/m3TWA: 0.01 mg/m3Ceiling / Peak: 0.02mg/m3 Ceiling / Peak:0.2 mg/m3-Phosphate(1-), hexafluoro-, lithium (CAS #: 21324-40-3) - - TWA: 1 mg/m3Skin-Chemical Name Poland Portugal Spain Switzerland NetherlandsAluminum foil (CAS #: 7429-90-5) TWA: 2.5 mg/m3TWA: 1.2 mg/m3TWA: 10 mg/m3 TWA:5 mg/m3TWA: 10 mg/m3 TWA:5 mg/m3TWA: 3 mg/m3-Copper (CAS #: 7440-50-8) - - - - TWA: 0.1 mg/m3 Chemical Name Norway United Kingdom Australia Austria BelgiumLithium Cobalt Oxide (CoLiO2) (CAS #:12190-79-3) TWA: 0.02 mg/m3STEL: 0.02 mg/m3- - Skin -Aluminum foil (CAS #: 7429-90-5) TWA: 5 mg/m3STEL: 5 mg/m3STEL: 30 mg/m3STEL: 12 mg/m3TWA: 10 mg/m3TWA: 4 mg/m310 mg/m35 mg/m3STEL 20 mg/m3TWA: 10 mg/m3-Carbon black (CAS #: 1333-86-4) TWA: 3.5 mg/m3STEL: 3.5 mg/m3- 3 mg/m3- -Copper (CAS #: 7440-50-8) TWA: 0.1 mg/m3TWA: 1 mg/m3STEL: 0.1 mg/m3STEL: 1 mg/m3- 1 mg/m30.2 mg/m3STEL 4 mg/m3STEL 0.4 mg/m3TWA: 1 mg/m3TWA: 0.1 mg/m3-Phosphate(1-), hexafluoro-,lithium (CAS #: 21324-40-3)- - 2.5 mg/m3- -Appropriate engineering controlsGeneral room ventilation is sufficient during normal use and handing. Do not install these batteries in sealed, unventilated areas. Facilities storing or utilizing this material should be equipped with an eyewash facility and a safety shower.Remove jewelry, rings, watches and any other metallic objects while working on battery. All tools should insulate to avoid the possibility of shorting connections. DO NOT lay tools on top of the battery. The work area should be equipped with the corresponding species and quantity of fire equipment and leakage emergency equipment. Individual protection measures, such as personal protective equipmentRespiratory protection If exposure limits are exceeded or irritation is experienced, NIOSH/MSHAapproved respiratory protection should be worn. Positive-pressure supplied airrespirators may be required for high airborne contaminant concentrations.Respiratory protection must be provided in accordance with current localregulations.Hand Protection Under normal condition of use and handling no special protection is required forsealed battery. In the event of battery case breakage, should be wear appropriatesafety gloves.Eye/face protection Under normal condition of use and handling no special protection is required forsealed battery. Use appropriate safety glasses when there is the risk of splash.Skin and body protection Under normal condition of use and handling no special protection is required forsealed battery. It is recommended to wear appropriate protective clothing whenthe battery case is broken.9. PHYSICAL AND CHEMICAL PROPERTIESInformation on basic physical and chemical properties_____________________________________________________________________________________________Appearance SolidColor Black Array Odor OdorlessOdor Threshold Not determinedpH Not determinedMelting point/freezing point Not determinedBoiling point / boiling range Not determinedFlash point Not determinedEvaporation rate Not determinedFlammability (solid) Not flammableFlammability Limit in Air Not applicableVapor Pressure Not determinedVapor density Not applicableDensity Not determinedRelative density Not determinedBulk density Not determinedSpecific gravity Not determinedWater solubility Insoluble in waterPartition coefficient (LogPow) Not determinedAutoignition temperature Not applicableDecomposition temperature Not determinedKinematic viscosity Not determinedDynamic viscosity Not determinedExplosive properties Not an explosiveOxidizing properties Not determinedOther informationNo information available10. STABILITY AND REACTIVITYReactivityStable under recommended storage and handling conditions (see SECTION 7, handling and storage).Chemical stabilityStable under normal conditions.Possibility of Hazardous ReactionsWhen a battery cell is exposed to an external short-circuit, crushed, modification, high temperature, open flames, it will be the cause of heat generation and ignition.Conditions to avoidExposed to an external short-circuit, crushed, modification, high temperature, open flames, incompatible materials, direct sunlight and high humidity.Incompatible materialsConductive materials, water, seawater, strong oxidants, strong acid, strong bases, etc.Hazardous Decomposition ProductsIn case of a fire or high temperature, metal oxides and irritating/harmful fumes/smoke may be generated.11. TOXICOLOGICAL INFORMATIONInformation on likely routes of exposureInhalation No effect under routine handling and use for sealed battery. If battery is broken,inhale fume and dust may cause upper respiratory irritation and lung irritation._____________________________________________________________________________________________Eye contact No effect under routine handling and use for sealed battery. Exposure to theelectrolyte contained inside the battery may result in irritation.Skin Contact No effect under routine handling and use for sealed battery. Exposure to theelectrolyte contained inside the battery may result in chemical burns.Ingestion No effect under routine handling and use for sealed battery. Harmful if swallowedthe electrolyte contained inside the battery. Exposure to the electrolyte containedinside the battery may cause irritation to mouth, esophagus and gastrointestinalsystem.Information on toxicological effectsAcute toxicityChemical Name Oral LD50 Dermal LD50 Inhalation LC50 Carbon black (CAS #:1333-86-4)> 8000 mg/kg (rat) > 3000 mg/kg (Rabbit) -Copper (CAS #: 7440-50-8) > 2500 mg/kg bw(rat) > 2000 mg/kg bw(rat) =1.03 mg/L/4 h(rat)Skin corrosion/irritationNo effect under routine handling and use for sealed battery. Exposure to the electrolyte contained inside the battery may result in chemical burns.Serious eye damage/eye irritationNo effect under routine handling and use for sealed battery. Exposure to the electrolyte contained inside the battery may result in irritation.SensitizationNo sensitization responses were observed.Germ cell mutagenicityNo information availableCarcinogenicityChemical Name ACGIH IARC NTP OSHA Lithium Cobalt Oxide(CoLiO2) (CAS #:12190-79-3)A3 Group 2B - -Carbon black (CAS #:1333-86-4)A3 Group 2B - -Reproductive toxicityNo information availableSTOT - single exposureNo information availableSTOT - repeated exposureNo information availableAspiration hazardNo information available12. ECOLOGICAL INFORMATIONEcotoxicityChemical Name Algae/aquatic plants EC50 Fish LC50 Crustacea EC50Lithium Cobalt Oxide (CoLiO2) (CAS #: 12190-79-3) - 275 mg/L/96h(Fundulusheteroclitus)-_____________________________________________________________________________________________2016 Edition, including the passing of the UN38.3 test ID:1118010201.965 of 61th DGR Manual of IATA( 2019 edition )or special provision188 of IMDG CODE (Amdt37-14)_____________________________________________________________________________________________Copper (CAS #: 7440-50-8)0.031 - 0.054 mg/L/96h Pseudokirchneriella subcapitata static 0.0426 - 0.0535 mg/L/72h Pseudokirchneriella subcapitata static 1.25: 96 h Lepomis macrochirus mg/L LC50 static 0.3: 96 hCyprinus carpio mg/L LC50semi-static 0.8: 96 h Cyprinus carpio mg/L LC50 static 0.112:96 h Poecilia reticulata mg/LLC50 flow-through 0.0068 - 0.0156: 96 h Pimephales promelas mg/L LC50 0.3: 96 h Pimephales promelas mg/L LC50 static 0.2: 96 h Pimephales promelas mg/L LC50 flow-through 0.052: 96 h Oncorhynchus mykiss mg/LLC50 flow-through-Persistence and degradability No information availableBioaccumulative potential No information availableMobility in soilNo information availableOther adverse effects No information available13. DISPOSAL CONSIDERATIONSWaste treatment methods Disposal of wastesDisposal should be in accordance with applicable regional, national and local laws and regulationsContaminated packaging Dispose of in accordance with federal, state and local regulationsChemical NameCalifornia Hazardous Waste StatusLithium Cobalt Oxide (CoLiO2)12190-79-3 ToxicAluminum foil 7429-90-5 Ignitable powderCopper 7440-50-8Toxic14. TRANSPORT INFORMATION15. REGULATORY INFORMATIONInternational InventoriesLabel for conveyance: Lithium Battery Label, Class 9UN Number: UN3480Packaging Group: N/A EmS No: 4.1-06Marine pollutantÿNo Proper Shipping name: Lithium ion batteries Hazard Classification: The goods shall be complied with the requirements of Section IBof Packing InstructionsRevision date 03-Jan-2020 Issue Date 03-Jan-2020_____________________________________________________________________________________________Component AICS DSL/NDSL EINECS/ELINCSENCS IECSC KECL PICCS TSCA Lithium Cobalt Oxide (CoLiO2) 12190-79-3 ( 40% )X X XX X X - X Aluminum foil 7429-90-5 ( 29% ) X X X Expect X X X X Carbon black 1333-86-4 ( 21% )X X X X X X X X Copper7440-50-8 ( 8% ) X X X Expect X X X X Phosphate(1-), hexafluoro-, lithium 21324-40-3 ( 2% )XXXXXXXX"-" Not Listed"X" ListedUS Federal Regulations SARA 313Chemical NameSARA 313 - Threshold Values %Aluminum foil - 7429-90-51.0SARA 311/312 Hazard Categories Not applicableCWA (Clean Water Act)Chemical Name CWA - ReportableQuantitiesCWA - Toxic PollutantsCWA - Priority PollutantsCWA - Hazardous SubstancesCopper 7440-50-8-XX-CERCLA Not applicableUS State RegulationsCalifornia Proposition 65Chemical Name California Proposition 65Carbon black - 1333-86-4CarcinogenU.S. State Right-to-Know RegulationsChemical NameNew JerseyMassachusettsPennsylvaniaLithium Cobalt Oxide (CoLiO2)12190-79-3 X--Aluminum foil 7429-90-5 X X X Carbon black 1333-86-4 X X - Copper 7440-50-8X X - Phosphate(1-), hexafluoro-, lithium21324-40-3X--16. OTHER INFORMATIONRevision Note Revision Note Not applicableKey or legend to abbreviations and acronyms used in the safety data sheet TWA - TWA (time-weighted average)STEL - STEL (Short Term Exposure Limit)Ceiling - Maximum limit valueTSCA - United States Toxic Substances Control Act Section 8(b) InventoryDSL/NDSL - Canadian Domestic Substances List/Non-Domestic Substances ListEINECS/ELINCS - European Inventory of Existing Chemical Substances/European List of Notified Chemical Substances ENCS - Japan Existing and New Chemical SubstancesIECSC - China Inventory of Existing Chemical SubstancesKECL - Korean Existing and Evaluated Chemical SubstancesPICCS - Philippines Inventory of Chemicals and Chemical SubstancesAICS - Australian Inventory of Chemical SubstancesDisclaimerThe information provided in this Material Safety Data Sheet is correct to the best of our knowledge, information and belief at the date of its publication. The information given is designed only as a guidance for safe handling, use, processing, storage, transportation, disposal and release and is not to be considered a warranty or quality specification. The information relates only to the specific material designated and may not be valid for such material used in combination with any other materials or in any process, unless specified in the text.-------- End of Safety Data Sheet --------_____________________________________________________________________________________________。
18650-2000电芯规格书德赛能源科技有限公司承认书文件名称：18650圆柱型锂离子电芯文件编号： D.DD.S £1-138送交确认版别：文件编号 D.DD.S-01 -38受控号：日期2004/10/17批准:审核:承办:此标准文件仅供贵司确认之用。
当贵司确认后，将根据贵司反馈意见发放正式受控文件。
我司规格数据表型密圭寸圆柱可充锂离子电池ICR18650186503.6V45cJ20 GmAh ---------O0mAh7充电 ---------- 4.200压± 0.049V最~~大~~持~~续~~充电电~~流 ----------------------------- 1500mA 最大持续放电电流---------------------------- 3000mA 尺寸（包括热缩 外套）直径， d 18.0 ± 0.2mm 高度， h65.0 ±0.5mm ------容量（20 °C, 0.2 C 5 to 2.75V ）最小容量20mA快速充电 1500mA 至4.2V,4.2V 恒压至电流小于 20mA使用环境（建议） 储存--- 温 度（15-35 C ）相对湿度（45-75%）大气压力（86-106kPa ）放电-20-60 C标准充电0-45 C完全充电后测量）-------- 小于80nn Q充电条件（20 C5C )标准充电------ 1000mA至4.2V,4.2V 恒压至电流小于2000mAh内阻(20°C 5°C,相对湿度<93% 标准测试环境 温20°C± 5°C20%如有更改，以新版本为准，不另行通知。
1.性能86-106kPa非另外要求）湿45度版别： 文件编号D.DD.S-01 -38受控号：日期 2004/10/17放电容量:- >60%C 5的.囉24辩、万Che 恒4电龍2AW 充「c m巧标跟亡.22〔疑H^o压量度应M 谷池2池电・境电處、田1^:(^4保护功能当锂离子可充电池在高于允许的电压或电流的情况下工作，电解液可能会分解，这样会影响到电池的安全性能。
18650（3600mah）规格书（标准书）文件名称产品型号修改记录产品型号目录1 适用范围 (4)2 引用标准 (4)3 定义........................................ .. (4)3.1 手机用电池battery for cellular phone ..... . (4) 3.2 充电限制电压 limited charge voltage ............... .. (4)3.3 额定容量 rated capacity ........................... .. (4)3.4 标称电压 nominal voltage (4)3.5 终止电压 cut-off voltage (4)4 技术参数 (4)4.1 电芯参数表 (4)4.2 主要参数表 (5)4.3 保护板参数表 (5)5 要求 (5)5.1 测试条件 (5)5.2 测量仪表与设备要求 (6)5.3 外观 (6)5.4 充电制式 (6)5.5 20℃放电性能 (6)5.6 高温性能 (6)5.7 低温性能 (6)5.8 荷电保持能力 (6)5.9 循环寿命 (7)5.10 环境适应性 (7)5.11 安全保护性能 (7)5.12 电池完全完全充电后内阻 (8)6 运输、贮存 (8)7 安全规程及使用说明 (8)8 特殊要求 (8)9 PCB原理图，电芯基本特性及外形图 (9)10 电芯充放电曲线图11 成品电池尺寸图产品型号1 适用范围本规格书适用于可充电锂离子电池产品的定义、要求、测试方法、质量评定程序及标志、包装、运输、贮存。
用户请务必严格按照规格书中的测试或使用方法进行测试或使用，如对表中的测试项目或测试方法有异议，请与供应方协商解决2 引用标准下列标准所包含的条文，通过在本规范中引用而构成为本规范的条文。
GB/T 2828-1987 逐批检查计数抽样程序及抽样表（适用于连续批的检查）GB/T 2829-1987 周期检查计数抽样程序及抽样表（适用于生产过程稳定性的检查）GB/T 2900.11-1988 蓄电池名词术语3 定义本规范采用GB/T 2900.11 中规定的术语和下列定义。
圆柱型锂离子电芯规格书PRODUCT SPECIFICATIONCylindrical Lithium-ion CellSignature 签名 Date 日期Company Name ：公司名称 ：Customer Approval 客户认同Company Stamp ：公司印章 ：Prepared By首发 Checked By核对 QA 质量确认Approved By批准TEL: (86) -22-83710503 FAX: (86)-22-83711060Product SpecificationTianjin Lishen Battery Joint-Stock Co., Ltd.CONFIDENTIALREV: V2TITLE: Cylindrical Lithium Ion Cell LR18650SK Page:1of20Date: 20101018_______________________________________________________________________________________________________ History of revision 修订记录LS431.1206GSRevision 修订状态Date日期Originator拟制人Reason of Revision修订记录0 07/10/2009 Wangxiaodan Original Release 1 09/03/2010 Wangxiaodan Add Chinese Parts 2 10/18/2010 WangxiaodanProduct SpecificationTianjin Lishen Battery Joint-Stock Co., Ltd.CONFIDENTIALREV: V2TITLE: Cylindrical Lithium Ion Cell LR18650SK Page:220ofDate: 20101018_______________________________________________________________________________________________________1 SCOPE 适用范围The product specification describes the requirement of the Cylindrical Lithium-ion Cell to be supplied to thecustomer by Tianjin Lishen Battery J/S Co.,Ltd.. Should there be any additional information required by thecustomer, customer are advised to contact Tianjin Lishen Battery J/S Co.,Ltd..本规格书规定了由天津力神电池股份有限公司生产的圆柱型锂离子电芯的技术要求，测试方法及注意事项，如需获取本规格书以外的技术要求，请与力神电池股份有限公司联系相关事宜。
18650电池规格书LGCRP/BTC Ryu, Duk HyunLRB-PS-CY2402003-07-16 0ApprovedDescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A3P R O D U C T S P E C I F I C A T I O NRechargeable Lithium Ion Battery Model : ICR18650 A3 2400mAhREVISIONDATE ORIGINATOR REASON FOR CHANGE 0 2004-07-16Ryu, Duk HyunOriginal ReleasePrepared Reviewed Approved Ryu, Duk HyunJung, Jae HanKim, Soo RyoungDate :’04. 07. 16. Date : ’03. 07. 16.Date : ’04. 07. 16.20 YOIDO-DONG YOUNGDUNGPO-GU,SEOUL 150-721, KOREATEL : (82) 2-3773-3599, 3659 FAX : (82) 2-3773-7005/doc/268f9d4769eae009581bec86.htmlLGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A31. ScopeThis product specification defines the requirements of the rechargeable lithium ion battery to be supplied to the customer by LG Chem, Ltd. Should there be any additional information required by the customer, customers are advised to contact LG Chem, Ltd. before selecting a solution.2. Description and Model2.1 Description : Rechargeable Lithium Ion Battery2.2 Model : ICR18650 A33. Technical Information3.1 Capacity Nominal : 2430 mAh (by standard charge and discharge)Minimum : 2380 mAh3.2 Nominal V oltage : Average 3.7 V3.3 Standard Charge : Constant Current and Constant V oltage (CC/CV)mACurrent =1200V oltage = 4.2 VEnd Current = 50 mA3.4 Max. Charge Current : 2400 mA3.5 Standard Discharge : Constant Current (CC)Current = 480 mAEnd V oltage = 3.0 V3.6 Max. Discharge Current : 4800 mA (for continuous discharge)3.7 Weight : Approx. 46.1 g3.8 Operating Temperature Charge :0 to 45 o CDischarge : -20 to 60 o C3.9 Storage Temperature 1 month : -20 to 60 o C3 months : -20 to 45 o C1 year : -20 to 20 o CLGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A34. Cell DimensionsDiameter : 18.3 ± 0.1 mm ( Max. 18.4 mm )Height : 64.9 ± 0.2 mm ( Max. 65.1 mm )5. AppearancesThere shall be no such defects as deep scratch, crack, rust, discoloration or leakage, which may adversely affect the commercial value of the cell.6. Characteristics6.1 Standard ChargeUnless otherwise specified, “Standard Charge” shall consist of charging at constant current of 1200mA. The cell shall then be charged at constant voltage of 4.2V while tapering the charge current. Charging shall be terminated when the charging current has tapered to 50mA. For test purposes, charging shall be performed at 23oC ± 2oC.6.2 Standard Discharge“Standard Discharge” shall consist of discharging at a constant current of 480mA to 3.0V.Discharging is to be performed at 23 oC ± 2 oC unless otherwise noted (such as capacity versus temperature).6.3 Initial CapacityCells shall be charged per 6.1 and discharged per 6.2 within 1 hour after full charge. Initial capacity shall meet the following requirement.Initial Capacity ≥ 2380 mAh6.4 Cycle LifeCells shall be charged at constant current of 1200mA to 4.2V with end current of 50mA. Cells shall be discharged at constant current of 1200mA to 3.0V. Cells are to rest 10 minutes after charge and20 minutes after discharge. A cycle is defined as one charge and one discharge. Discharge capacityshall be measured per 6.1 and 6.2 after 300 cycles.Discharge capacity (301th Cycle) ≥80 % (of minimum capacity in 3.1)6.5 Initial AC ImpedanceLGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A3Initial AC impedance is measured at 1kHz after standard charge.Initial AC Impedance ≤ 90 m? (with PTC)6.6 Temperature Dependency of CapacityCells shall be charged per 6.1 at 23oC ± 2oC and discharged per 6.2 at the following temperatures.Relative capacity at each temperature shall meet the following.Charge Temp. Discharge Temperature-10oC0oC 23oC 60oC23oC70 % 90 % 100 % 95 %6.7 Storage CharacteristicsCells shall be charged per 6.1 and stored in a temperature-controlled environment at 23oC ± 2oC for30 days. After storage, cells shall be discharged per 6.2 to obtain the remaining capacity.Remaining capacity ≥90 % (of minimum capacity in 3.1)6.8 Cell V oltage (as of shipment)V oltage range : 3.7 ~ 3.9 V7. Mechanical Characteristics7.1 Drop TestTest method : Cells charged per 6.1 are dropped onto an wooden floor from 4 feet height for 3 cycles, where each cycle consists of 3 drops, 2 drops from each cell terminal and1drop from the side of cell can (Total number of drops = 9). After test, cells aredischarged per 6.2 and cycled per 6.1 and 6.2 for 3 cycles to obtain recoveredcapacity.Criteria : No leakage, Capacity recovery rate ≥ 80 %7.2 Vibration TestTest method : Cells charged per 6.1 are vibrated for 90 minutes per each of the three mutually perpendicular axis (x, y, z) with an amplitude of 0.8mm, frequency of 10Hz to55Hz and sweep of 1Hz change per minute. After test, cells are discharged per6.2 and cycled per 6.1 and 6.2 for 3 cycles to obtain recovered capacity.Criteria : No leakage, Capacity recovery rate ≥ 80 %LGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A38. Environmental Test8.1 High Temperature Storage TestTest method : Cells are charged per 6.1 and stored in a temperature-controlled environment at 60oC for 1 week. After test, cells are discharged per 6.2 and cycled per 6.4 for 3cycles to obtain recovered capacity.Criteria : No leakage, Capacity recovery rate ≥ 80 %8.2 High Temperature and High Humidity TestTest method : Cells are charged per 6.1 and stored at 60oC (95% RH) for 168 hours. After test, cells are discharged per 6.2 and cycled per 6.4 for 3 cycles to obtain recoveredcapacity.Criteria : No leakage, No rust, Capacity recovery rate ≥ 80 %8.3 Thermal Shock TestTest method : 65oC (8Hrs) ← 3hrs →-20oC (8Hrs) for 8 cycles with cells charged per 6.1.After test, cells are discharged per 6.2 and cycled per 6.4 for 3 cycles to obtainrecovered capacity.Criteria : No leakage, Capacity recovery rate ≥ 80 %9. Safety Test9.1 Abnormal Charge TestTest method : Cells are discharged per 6.2, then charged at constant current of 7200mA and constant voltage of 4.2V while tapering the charge current. Charging is continuedfor 48 hours (Per UL1642).Criteria : No rupture, No fire9.2 External Short-circuiting TestTest method : Cells are charged per 6.1, and the positive and negative terminal is connected bya 100m?-wire for 1 hour (Per UL1642).Criteria : No rupture, No fire9.3 Overdischarge TestTest method : Cells are discharged at constant current of 480mA to 250% of the minimum capacity (Per UL1642).Criteria : No rupture, No fireLGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A39.4 Nail TestTest method : A nail (diameter : 2.5~5mm) is penetrated vertically through the center of cells charged per 6.1 and left for 6 hours.Criteria : No rupture, No fire9.5 Heating TestTest method : Cells are charged per 6.1 and heated in a circulating air oven at a rate of 5oC per minute to 150oC. At 150oC, oven is to remain for 10 minutes before test isdiscontinued (Per UL1642).Criteria : No rupture, No fire9.6 Impact TestTest method : Cells charged per 6.1 are impacted with their longitudinal axis parallel to the flat surface and perpendicular to the longitudinal axis of the 15.8mm diameter bar(Per UL1642).Criteria : No rupture, No fire9.7 Crush TestTest method : Cells charged per 6.1 are crushed with their longitudinal axis parallel to the flat surface of the crushing apparatus (Per UL1642).Criteria : No rupture, No fire10. Standard Test ConditionsUnless otherwise specified, all tests stated in this Product Specification are conducted at temperature 23±2oC and humidity 65 ± 20 %RH.11. Product LiabilityThe coverage of LG Chem, Ltd. is for the cell itself, while the customer assumes the liability of the product including the cell and its protection circuit.12. WarrantyAs long as the cell is treated in accordance with this Product Specification and/or Proper Use and Handling, LG Chem, Ltd. warrants that the cell should be free from any defect for a period of 1 year from date of manufacturing.LGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0 Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A3The warranty set forth above or described in Proper Use and Handling excludes a defect which is not related to manufacturing on the cell.13. OthersAny matter not included in this specification shall be conferred between the both parties.This document shall replace the document bearing a former revision index, and customers are kindly requested to destroy the former document in possession.LGCRP/BTC Ryu, Duk Hyun LRB-PS-CY240 2003-07-16 0 Approved DescriptionLGCRP/BTC Kim, Soo Ryoung Lithium Ion ICR18650 A3Fig 1. Dimensional Drawing of ICR18650 A3。
创明新能源股份有限公司锂离子二次电池规格书高能倍率圆柱型电池CMICR18650F2P-2000mAh编制审核批准宇妍赵悠曼程建良2013-09-18发布2013-09-18生效1.适用范围本规格书规定了创明新能源股份有限公司向客户提供的CMICR18650F2P(2000mAh)圆柱型锂离子电池的技术参数及测试标准。
该参数及标准的拟定，主要参照GB/T18287-2013《移动电话用锂离子蓄电池及蓄电池组总规范》。
2.型号类别2.1类别：圆柱型锂离子二次电池2.2型号：CMICR18650F2P-2000mAh3.基本规格及性能3.1容量标称容量：2000mAh(0.2C放电至3.0V)最低容量：1950mAh(0.2C放电至3.0V)3.2标称电压 3.6V3.3电池内阻≤20mΩ3.4放电终止电压 3.0V3.5充电上限电压4.20±0.05V 3.6标准充电电流0.2C3.7快速充电电流1C3.8标准放电电流0.2C3.9最大持续放电电流10C3.10最大瞬间放电电流20C(<200ms) 3.11电池重量44.0±1g3.12最大尺寸直径(φ):18.6mm 高度(H):65.3mm3.13工作温度充电：0~45℃；放电：-10~60℃3.14贮存温度1个月内：-5~45℃6个月内：0~45℃4.测试条件实验和测量要在标准温度(23±2)℃及标准湿度(65±20)%的条件下进行。
4.1标准充电0.2C恒流恒压充电(CC/CV)至上限电压4.20+/-0.05V，然后以0.02C电流截止；4.2标准放电以0.2C恒流放电至3.0V电压截止5.性能5.1电性能项目测试程序标准5.1.1标称电压电池按4.1充满电后，按0.2C放电过程的平均工作电压. 3.6V 5.1.2放电性能电池按4.1充满电后，以0.2C恒流放电到3.0V。
≥292min5.1.3循环寿命常规寿命在环境温度23±2℃的条件下，以0.5C先恒流充电至上限电压4.20+/-0.05V，再恒压充电至0.02C截止电流；搁置10min后以1C放电至3.0V，放电结束后搁置10min后进行下一个循环，直至连续两次放电容量为首次的80%，则认为寿命终止。
倍率型圆柱电池商丘市迈科新能源有限公司DOC NO.:REV. :PAGE: 1 of 8Specification Approval Sheet (cylinder Cell) 产品规格确认书（圆柱电池）Model/型号： 18650PCapacity/容量 2000mAhVoltage/电压： 3.7V制定（Prepared By）审核（Checked By）批准（Approved By）温庆 屈明明 熊胜任4.0 电池性能Characteristic若没有特别说明，电池在做各项试验前，均需在86KPa～106 KPa大气压，环境温度20℃±5℃，相对湿度为45％～75％的条件下，以0.2C5A恒流放电至终止电压2.75V，并在收到产品两周内进行以下试验。
Without special instructions, the following tests should be done under the condition of : temperature(20℃±5℃), atmospheric pressure (86KPa～106 Kpa), relative humidity (45％～75％), and the tests should be done within two weeks after receiving the products.一些术语的定义：the definitions of some nomenclatures of this specification标准充电：在环境温度20℃±5℃的条件下，以0.2C5A充电，当电池端电压达到充电截止电压时，改为恒压充电，直到充电电流小于或等于0.01C5A后停止充电。
standard Charge: Charge with current0.2C5A to limit charge voltage under the condition of 20℃±5℃ surrounding t emperature, then change to charge with constant voltage till the current less than or equal to 0.01 C5A.4.1电化学性能Electrical Characteristic序号NO.项目Item 标准Standard 测试方法Test Method1常温放电性能DischargeCharacteristics0.5C5A ≥2h在1标准大气压，环境温度20℃±5℃，相对湿度为45％～75％的条件下，电池标准充电后（以下若没有特别说明，均在此条件下放置，皆按此充电方式），搁置30min，以0.5C5A进行放电至终止电压，循环三次，当有一次达到标准，即达到标准要求（下同）。
Standard charged under the condition of normalatmospheric pressure and the environmental temperature of25℃±5℃ and 45％～75％RH, then rest for 30min anddischarge at0.5C5A to the discharge cut-off voltagerespectively. Charge/discharge cycle can be conducted for 3times before meeting the Standards（the same below）2 常温荷电保持能力Normal Storage放电时间≥255minDischarge Time≥255min电池标准充电后，开路放置28天，再以0.2C5A放电至终止电压。
Store for 28 days after standard charged, then discharge at0.2C5A to the discharge cut-off voltage.3 循环寿命Cycle Life循环500次后放电时间≥96minDischarge Time≥96min0.5C5A放电至终止电压，搁置30min，以此模式循环500次Conduct 1C5A cycle for 500 times and measure finalcapacity.4.2安全性能Safety Characteristic序号NO.项目Item 标准Standard 测试方法Test Method1过充性能Overcharge不爆炸、不起火No fire、No explosion电池标准充电后，以3C5A电流充电至4.8V,然后转恒压充电至截至电流0.01C5A时终止。
Standard charge. Charge at 3 C5A to 4.8V, then change tocharge with constant voltage till the current less than or equal to0.01 C5A. Observe the variation of the battery’s appearance2过放性能Over Discharge不起火、不爆炸No fire、No explosion电池标准充电后，以1C5A进行放电至终止电压，然后用10Ω的电阻将电池正负极相连，搁置14天。
Standard charged. Discharge at 1C5A to discharge cut-offvoltage and then connect the positive and negative terminalswith a resistor of 10Ω for 14 days.3常温短路性能Short Circuit atRoomTemperature不爆炸、不起火最高温度<150℃No fireNo explosionMax.temperature<150℃电池标准充电后，置于防爆玻璃罩中直接短路其正负极（线路总电阻不大于50mΩ），当电池温度下降到比峰值约低10 ℃时试验结束。
观察电池的温度及外观变化。
Standardcharged. Keep the battery into a ventilation cabinet andshort-circuit the positive and negative terminals directly (generalresistance shall be less than or equal to 50mΩ). Stop the testwhen the temperature falls to value 10 ℃lower than the peakvalue. Observe the variation of the battery’s appearance andtemperature.4 挤压测试Crush不着火不爆炸No fire and noexplosion挤压测试前电池用0.2C充满电，搁置24小时。
从径向挤压压力达到13KN。
Charge at 0.2C,and then leave for 24hrs, The crushing wascontinued until a force of 3000 lb (13 kN)5 重物冲击性能Impact 不爆炸、不起火No fireNo explosion电池标准充电后，放在平面上，并与热电偶相连，将一直径为15.8mm的棒放在电池高度方向中间位置，让重量9.1kg的重物从610mm高度自由垂落至冲击台面。
Standard charge. Keep the battery connected with athermocouple and put it on a impaction platform, place a 15.8mmdiameter bar across the center of the biggest surface, then let a9.1kg heavy hammer self fall off to the platform from a height of610mm. Observe the variation of the battery’s appearance.6 热冲击安全性能Hot Oven 不起火、不爆炸No fire、No explosion电池标准充电后，放置于热箱中，并与热电偶相连，温度以（5 ℃±2 ℃）/min的速率升至130 ℃±2 ℃并保温30Min。
Standard charge. Keep the battery connected with athermocouple and put it into a circulating air oven. Temperatureis raised at a rate of 5 ℃±2 ℃per minute to a temperature of130℃±2 ℃ and remained for 30min at this temperature.Observe the variation of the battery’s appearance.4.3环境适应性能Environment Adaptation Performance序号NO. 项目Item 标准Standard 测试方法Test Method1恒定湿热性能Static Humidity电池不起火、不爆炸放电时间≥180minDischarge Time ≥180minNo remarkable deformationNo smoking\ explosion电池标准充电后，置于温度为40℃±2℃，相对湿度为90％的恒温恒湿箱中，搁置48h后，取出电池20±5℃环境下搁置2h。
观察电池外观变化。
然后以0.2C5A放电至终止电压。
Standard charge. Put the battery into a 40℃±2℃ and 90％ RH chamber for 48h, then get itout and store it for 2h at room temperature.Observe the variation of the battery’s appearanceand then discharge at 0.2C5A to discharge cut-offvoltage, measuring final capacity.2 跌落性能Drop不起火、不爆炸放电时间≥255minNo smoking 、No fire、No explosionDischarge time≥255min标准充电后，将电池样品由高度(最低点高度)为1m的位置自由跌落到18～20mm的硬木板上，要求各面各跌落一次。
