mettler toledo xk3141称重显示控制器

xk3139称重显示控制器xk3139称重显示控制器介绍控制柜是IND560仪表专用控制柜。

可以按照用户需要选择合理的选件板组合和最优化的参数设置，搭建以IND560为核心的过程称重控制器。

该产品充分利用IND560仪表在过程控制方面的强大功能，为用户提供从功能设计到系统布线的完整解决方案。

IND560 控制柜是IND560仪表专用控制柜，致力于促进IND560标准产品的市场推广，简化用户的配置难度。

控制柜内含以下部件：指示灯三个，按钮两只，急停开关一只，空气开关一只，24VDC开关电源一只，接线端子若干，安装图纸一份。

xk3139称重显示控制器METTLER TOLEDO称重显示控制器 XK3141-6000 33P100000000000 1 METTLER TOLEDO称重显示控制器 XK3139-6000 56H1-00000-000-023 2 METTLER TOLEDO称重显示控制器 XK3141-6000 33P100000A00000 4 METTLER TOLEDO称重显示控制器 XK3127-6000 PRGN-1008-023 2xk3139称重显示控制器图片xk3139称重显示控制器XK3139 56P1-00000-000XK3139 56P4-00000-000XK3139 56H1-00000-000XK3139 56H4-00000-000XK3139 56P1-0000B-0F0XK3139 56P4-0000B-0F0XK3139 56H1-0000B-0F0XK3139 56H4-0000B-0F0xk3139称重显示控制器规格- IND560物料控制仪表型号：XK3139（IND560）56H100000000023Mounting options 台式、墙式、面板式、柱式Resolution 100,000 divisionsDisplay 21mm 真空荧光型Keyboard 25 键触摸-感应式键盘，其中包括数字键盘、各种导航键和功能键A/D rate (int./ext) 超过366 Hz 的内部转化速度、50 Hz 的设定点对比、20 Hz 的PLC 输出转化速度Applications 标准过程/贸易称重、过量/残余量检测称重、产品添加Degree of protection 防尘式–IP69K，面板式–类型4/12Digital Input/Output 最多18个输入和12个输出Hazardous area approval 等级1，分区2，组A-D、F、G 和欧洲类别3Housing 防尘式–不锈钢；平板固定–不锈钢面板、铝制底座Number of attachable platforms 最多8个350 ohm 的称重单元Options 模拟输出、Profibus、A-B RIO、数字离散I/O、Fill-560 应用软件Resolution (approvable) 模拟- 10,000e OIML、10,000d NTEP；IDNet –100,000d OIML、NTEPSignal processing TraxDSP™过滤Suitable platforms / weigh modules 模拟、IDNet（MMR）Dimensions 防尘式- 16.0 x 26.5 x 17.0 cm；面板式- 16.0 x 26.5 x 9.2 cm Interfaces 串行、PLC A-B、远程I/O、Profibus L2 DP、模拟输出、4-20mA、0-10V、DeviceNet以上内容技术参数以《OIML60号国际建议》92年版为基础，最新具体变化可查看《JJG669—12托利多广州南创传感器事业部检定规程》。

梅特勒托利多xk3141,称重显示控制器梅特勒托利多xk3141称重显示控制器梅特勒托利多xk3141称重显示控制器METTLER TOLEDO（梅特勒托利多）仪表供应72234167 称重显示控制器 XK3141-6000 33P100000000000 1 72187421 称重显示控制器XK3139-6000 56H1-00000-000-023 272234764 称重显示控制器 XK3141-6000 33P100000A00000 4 170815 称重显示控制器 XK3127-6000 PRGN-1008-023 2157374 称重显示控制器 XK3130-3000 KTGK-1100-023 3136719 称重显示控制器 XK3130-3000 KTGN-1100-023 172234866 称重显示控制器 XK3141-6000 33H100000A00J00 1 72183758 称重显示控制器 PTPN-1000N-023 172183763 称重显示控制器 PTPN-1800N-023 1梅特勒托利多xk3141称重显示控制器图片梅特勒托利多xk3141称重显示控制器XK3123 Panther称重终端是一款专为化工、制药、食品和其他过程工业应用而设计的高品质称重终端产品，为工业称重需要提供多种应用方式：XK3123 Panthe主要性能电流型模拟量输出模块（13M电缆）直接输出4~20mA电流便于远距离传输；可以单只传感器使用输出4~20mA信号，也可以两只使用输出4~20mA信号；适用于各种大吨位的料位计及配料称重控制；外形高度低安装方便快速；容量2~500t；综合精度高，长期稳定性好；不锈钢材质，焊接密封，防护等级IP68；XK3123 Panthe，METTLER TOLEDO(梅特勒托利多) 称重显示仪表：XK3123 Panther称重终端停产了，替代IND331梅特勒托利多xk3141称重显示控制器面板式：原型号替代型号PTPN-1000N 33P1-00000-000-000PTPN-1020N 33P1-0000B-000-000PTPN-1400N 33P1-00000-D00-000PTPN-1600N 33P1-00000-B00-000PTPN-1800N 33P1-00000-A00-000PTPN-1900N 33P1-00000-P00-000防尘式：原型号替代型号PTHN-1000N 33H1-00000-000-J00PTHN-1400N 33H1-00000-D00-J00PTHN-1600N 33H1-00000-B00-J00PTHN-1800N 33H1-00000-A00-J00PTHN-1900N 33H1-00000-P00-J00以上内容技术参数以《OIML60号国际建议》92年版为基础，最新具体变化可查看《JJG669—12托利多广州南创传感器事业部检定规程》。

梅特勒托利多XK3141 IND131称重显示控制器梅特勒托利多XK3141 IND131称重显示控制器IND131是梅特勒-托利多公司最新推出的一款专为OEM客户设计的高品质称重控制终端。

它集称重显示、定值控制、料位监控、流量监测功能于一身，可广泛应用于化工、冶金、制药、烟草、食品等工业领域。

紧凑新颖的安装方式、稳定可靠的性能、丰富的接口配置、方便灵活的标定方法、便捷的参数设置与系统备份，必将为您提供一种简便灵活的方案，来应对日益多样的称重需求。

紧凑新颖的安装方式梅特勒托利多XK3141 IND131称重显示控制器产品图片梅特勒托利多XK3141 IND131称重显示控制器预置点功能• 可应用于散装物料的包装、配料、灌装等类似情况中的物料的定量称重和给料控制• 单、双速输出任选• 新增预置点锁存功能比较器功能• 可应用于原料罐、计量罐的料位监控• 提供3个独立的比较器• 可根据用户需要灵活应用便捷的参数设置与系统备份• InsiteTM PC配置工具通过串口即可实现远程监控、参数配置和程序更新• SD存储卡即插即用，能够轻松实现系统的备份与恢复，以及多台仪表的统一设置梅特勒托利多XK3141 IND131称重显示控制器技术指标特性导轨式接线盒式尺寸(WxHxD) 68x138x111 mm 251x246x123 mm外壳/结构塑料外壳 304L全不锈钢外壳安装方式导轨安装墙面，地面防护等级 IP20 IP69K电源 85~264VAC交流电源或18~36VDC直流电源使用环境认证温度：-10~+40℃；操作温度：-30~+60℃；相对湿度：10%~95%，不冷凝显示绿色OLED点阵显示屏。

重量显示高度4 mm键盘 4个轻触薄膜功能按键CPTZ精度最大显示分度100000d，最大检定分度6000e(OIML)/10000d(NTEP)速率 A/D转换速率366Hz；重量比较速率50Hz；PLC更新率20Hz 秤台可连接1台模拟式秤台传感器可连接4个350欧姆的传感器激励电压 5VDC接口串口(1个RS232和1个RS232/485(选件))，2I/4O，PLC接口计量认证美国：NTEP Class III/IIIL-10000d；加拿大：Class III-10000d；Class IIIHD - 20000d；欧洲：OIML Class III-6000e以上内容技术参数以《OIML60号国际建议》92年版为基础，最新具体变化可查看《JJG669—12托利多广州南创传感器事业部检定规程》。

METTLER TOLEDO(梅特勒-托利多)称重仪——培训资料注：本资料只针对梅特勒-托利多IND131/331型号称重仪，侧重于称重仪的标定及常见参数设置一、产品基本信息1 名称：METTLER TOLEDO(梅特勒-托利多)2 称重显示控制器型号: IND131/331防尘式3 称重传感器型号：SB-1t4 数量及分布：LT 入库区2台CT1 外部接口区2台CT1 尾料区1台CT1 清洁区2台CT1 装箱区3台CT2 外部接口区1台CT2 装箱区4台共15台二、传感器安装1 安装时每台称重仪均由4个传感器组成，其中一组对角为2个全浮动型传感器，另外一组对角为1个半浮动型传感器和1个固定型传感器2 安装时4个传感器要处于同一水平面3 按照传感器上的标牌指示进行接线+EXC 绿色电源正极-EXC 黑色电源负极SHELD 黄色（粗）屏蔽线+SEN 黄色（细）正反馈线-SEN 蓝色负反馈线+SIN 白色正信号线-SIN 红色负信号线三、称重显示控制器安装1 按照手册将各个模块插接并固定2 按照传感器的接线规则装接信号线（注意要接好屏蔽线）3 连接PROFIBUS DP线4 连接电源线（请确保主柜的相应的断路器断开）四、设置参数1 熟悉面板常用键功能2 数据含义3设置通信站址长按“打印”键3秒——通过“去皮”、“清皮”键选择“SET UP”菜单，按“打印”键进入——输入密码“1”，并进入——选择“通讯”菜单，并进入——选择“PLC”菜单，并进入——选择“PROFIBUS”,并进入——选择“节点地址”，并进入——设置通信站址——设置成功后按多次“清零”键，返回显示界面4设置密码长按“打印”键3秒——通过“去皮”、“清皮”键选择“SET UP”菜单，按“打印”键进入——输入密码“1”，并进入——选择“仪表”菜单，并进入——选择“用户”菜单，并进入——设置密码——设置成功后按多次“清零”键，返回显示界面五、称重仪的标定1 标定零点长按“打印”键3秒——通过“去皮”、“清皮”键选择“SET UP”菜单，按“打印”键进入——输入密码“1”，并进入——选择“称台”菜单，并进入——选择“标定”菜单，并进入——选择“标定零点”菜单，并进入——选择“空称”菜单，并进入——按“打印”键开始标定——显示标定成功，进行下一步2设置标定量程标定零点显示标定成功后，按“打印”键确认——按“打印”键选择“标定量程”——设置量程值——放置砝码3放置标准砝码：放置砝码时应该使4个传感器的受重均衡，并使重量在整个称重仪上均匀分布4标定量程放置砝码成功后，按“打印”键，开始标定量程——显示标定成功后，按按“打印”键确认——按多次“清零”键，返回显示界面注意：在标定零点和标定量程的过程中，不要碰触称台，以免造成干扰！5 测试效果进行效果测试时，应该先拿一个标准砝码，分别放置在四个传感器处，查看示数是否在误差范围内并且示数基本一致。
