焊接专业术语中英文对照整理机械——焊接专业术语中英文对照（郭运）整理1Single 单面的2V—groove V型坡口3Joint 焊接接头4Edges overlap 接头形式5Butt 对接6T T型焊接7Fillet 角焊缝8Edge 端接9Corner 角接10Radius 半径11Joint root 焊接根部12Bevel angle 削边角度13Groove angle 坡口角度14Root face 根部钝边15Groove face 坡口面16Plug weld 塞焊17Spot weld 点焊18Seam weld 缝焊19Slot weld 槽焊20Double—flare—bevel—groove K型坡口焊缝21Single—flare—V 单面V型22Edge flange 翻边端接23Corner flange 卷边端接24Flange weld 卷边焊缝25Flare weld 扩口焊缝26Fillet weld 角焊缝27Slot weld 槽焊缝28Spot weld 点焊缝29Surfacing weld 堆焊焊缝30Melt—through weld 熔透焊缝31Backing weld 打底焊缝32Back weld 背面焊缝33Root weld 根部焊缝34Crown weld 隆起部分35Weld reinforcement 焊缝加强36Weld face 焊缝表面37Cap pass 盖面焊道38Weld edge 焊缝边缘39Leg 焊脚40Toe 焊趾41Buildup 堆焊42Weld reinforcement 焊缝加强高43Effective throat 有效焊喉44Concave weld 凹形焊缝45Convex weld 凸形焊缝46Unequal leg fillet 不等脚角焊47Oversize weld 大尺寸焊缝48Depth of fusion 熔合深度49Depth of penetration 熔透深度50Root penetration 根部熔深51Joint penetration 接头熔深52Weld interface 焊缝分界面53Diameter of weld at point of contact 焊缝在接触点上的直径54Thickness 厚度55Tail 尾部56Arrow 箭头57Reference line 参考线58Arrow side 箭头一边59Weld symbol 焊缝符号60Near side 近侧61Arrow side 箭头侧62Far side 远侧63Other side 另一侧64Put the weld on either—side 在任意一侧施焊65There is noside significance 没有方向区别66Edge flange 双卷边67Corner flange 单卷边68Weld size 焊缝尺寸69Effective throat 有效厚度70Root opening 根部间隙71Full penetration double bevel—groove weld K形坡口全焊透焊缝72Full penetration double V—groove weld 双V形坡口全焊透焊缝73Partial penetration double bevel—groove weld K形坡口部分焊透焊缝74Partial penetration double V—groove weld 双V形坡口部分焊透焊缝75Bevel groove 削边坡口76Flare groove 喇叭形坡口77Flange groove 卷边坡口78V—groove V形坡口79Staggered intermittent fillet weld 交错间断角焊缝80Chain intermittent fillet weld 链状间断角焊缝81Segmented fillet weld 分段角焊缝82Pitch distance 间距83Depth of filling 填充深度84Slot weld width 槽焊缝宽度85Plug weld diameter 塞焊缝的直径86Angle of countersink 深孔角度87A dimension to the right of the symbol 在符号右边的尺寸88A dimension of the required suggest diameter 所要求的直径尺寸89A value for the required shear strength per spot 每点所要求的剪切强度值90Spot weld size 点焊缝尺寸91Spot weld length 点焊缝的长度92Number of spot required 所要求的点的数量93Pitch distance between adjacent spots 两个相邻点的间距94Reference line 参考线95Melt—through of weld from other side 焊缝在另一侧熔透96Single bevel—groove weld with backing weld 加垫板的单边坡口焊缝97Single bevel—groove weld with back weld 背面焊的单边坡口焊缝98Single bevel—groove weld with backing weld 带垫板的V 形坡口焊缝99Single bevel—groove weld with back weld背面焊的V形坡口焊缝100Square groove 直边坡口101Skewed groove 斜坡口102Sloped groove 倾斜坡口103Scarf 斜嵌接104Gas metal arc spot weld 气体保护点焊105Resistance spot weld 电阻点焊106Gas metal arc seam weld 气体保护滚焊缝107Resistance seam weld 电阻滚焊缝108Gas metal arc slot weld 气体保护槽焊缝109The type of electrode to use 所要求焊条形式110The weld quality standard 焊缝质量标准111The weld procedure to use 所用的焊接程序112Codes 规范113Drawing 图纸114Specifications 技术要求115Contracts 合同116General 一般注解117Local 局部注解118The point for lifting an object 吊装一物体的点119Filler metals 填充金属120Pressure vessel fabrication 压力容器制造121Be as simple as possible 尽可能简单122Welder 焊工123Code body 规范本身124Shielded metal arc 手工电弧焊125Submerged arc 埋弧焊126Face bend 面弯127Root bend 背弯128Side bend 侧弯129Nick break 缺口破坏130Tensile 拉伸131Monitoring production welding 监视生产中的焊接132Strength 强度133Toughness 韧性134Hardness 硬度135Ductility 延展性136Compressive 压缩137Impact 冲击138Fatigue 疲劳139Undercut 咬边140Overlap 焊瘤141Cracking 裂纹142Porosity 气孔143Ultimate tensile strength 极限拉伸强度144Percent elongation 延伸率145Percent reduction of area 断面收缩率146Impact strength 冲击强度147Yield strength 屈服强度148Brinell 布氏149Vickers 韦氏150Rockwell 洛氏151Knoop 努氏152Fatigue test 疲劳试验153T ensile test 拉伸试验154Micro--hardness test 显微硬度试验155Charpy impact test 夏比冲击试验156Soundness test 致密性测试157Fillet break 角焊缝断裂158Metallographic 金相159Transverse fillet weld shear test 横向角焊缝剪切试验160Quality of the fractured weld 焊缝端口的质量161Ductility of the weld metal 焊缝金属的延展性162Impact strength of the weld 焊缝的冲击强度163Tensile strength of the base metal 母材的拉伸强度164Weld—ability 可焊性165Scratches caused by improper handling 由不适当的处理导致的划痕166Incomplete fusion 未熔合167Distortion 变形168Slag inclusions 夹渣169Vibratory stress relief 振动消除应力170External restraint 外部拘束171Thermal stress relief 热消除应力172Peening 锤击173Annealing 退火174Quenching 淬火175Tempering 回火176Normalizing 正火177Decrease current 降低电流178Decrease voltage 降低电压179Increase travel speed 加快焊接速度180Change from weave to stringer bead technique 从横向摆动焊道改成直线焊道技术181Result in a wider heat—affected zone hardness导致热影响区更宽182Produce a lower heat—affected zone hardness 降低热影响区硬度183Slow down the cooling rate 降低冷却速度184Reduce the tendency to produce martensite in the heat—affected zone 减少在热影响区形成马氏体的倾向185Stress relief 消除应力186Crater crack 弧坑裂纹187SMAW 手动电弧焊188PAW 等离子焊189FCAW 药芯焊190SAW 埋弧焊191Underfill 未焊满192Excess convexity 太凸193Excess weld reinforcement 焊缝余高太高194Overfill 过充195Scratch start 擦伤196Arc strike 引弧烧伤197Tungsten inclusion 夹钨198Lamination 分层199Lamellar tear 片状撕裂200Seam 划伤201Pipe shrinkage 缩孔202Longitudinal crack 纵向裂纹203Transverse crack 横向裂纹204Underbead crack 焊道中裂纹205T oe crack 焊趾裂纹206Root crack 根部裂纹207Base metal crack 母材裂纹208Before welding 焊接前209During welding 焊接时210After welding 焊接后211Waiting time 等待时间212Penetrating time 渗透时间213Soak time 吸入时间214Dwell time 驻留时间215AC 交流电216DC 直流电217DCEP 直流反接218。
最常用焊缝符号表示方法焊缝符号表示法是一种用于表示焊接接头的标准方法。
这些符号包括基本符号、辅助符号、补充符号和尺寸符号。
以下是一些最常用的焊缝符号及其表示方法：1.基本符号：基本符号是代表焊缝横截面形状的符号。
常用基本符号包括角焊缝（100）、点焊（110）、一类焊缝（101）、v形焊缝（102）、单面v形焊缝（103）、带钝边的v形焊缝（104）。
在图纸中标注焊缝基本符号时，应标明焊缝的类型及位置。
2.辅助符号：辅助符号是代表焊缝表面形状特征的符号。
常用辅助符号包括平面符号（200）、凹面符号（201）、凸符号（202）、带衬垫符号底面带有垫板的v形对接焊缝（203）等。
这些符号通常用于表示焊缝的表面形状特征，以帮助焊接工人更好地了解焊接要求。
3.补充符号：补充符号用于补充和解释焊缝的一些特征。
常用补充符号包括带衬垫符号底面带有垫板的v形对接焊缝（300）、三面焊接符号角焊缝应在工件的三面进行，焊接方法应为手工电弧焊（301）、焊接符号周围在工件周围应用角焊缝（302）等。
这些符号通常用于表示焊缝的一些特殊要求，如坡口形状、焊接方法等。
4.尺寸符号：尺寸符号是用于表示焊接尺寸的符号。
常用尺寸符号包括焊接尺寸K角焊缝焊脚尺寸为k（400）、焊缝宽度实际喉部cS一类焊缝焊缝宽度为c焊缝厚度为s（401）、内径d塞焊焊缝芯径d点焊焊点直径d（402）等。
这些符号通常用于标注焊接接头的大小和形状，以帮助焊接工人更好地了解焊接要求。
在实际应用中，这些焊缝符号通常会标注在焊接图纸上，以帮助焊接工人更好地了解焊接要求和操作方法。
同时，这些焊缝符号也可以用于焊接过程中的质量控制和检验，以确保焊接质量和安全性。
此外，在进行焊接操作时，需要根据焊接方法代号进行标注。
常用的焊接方法代号包括手工电弧焊（111）、气体保护电弧焊（121）、埋弧焊（131）、钨极氢弧焊（141）等。
在进行组合焊接时，可以使用“/”将不同焊接方法的代号分开，如V形坡口对接焊缝可以先采用钨极氢弧焊打底，后用手工电弧焊盖面，标注为141/111。
焊接专业术语中英对照焊接欠缺与检验焊接欠缺welding imperfection焊接缺陷weld defect气孔blowhole/ gas pore针尖状气孔pinhole密集气孔porosity条虫状气孔wormhole裂纹crack外表裂纹surface crack咬边undercut焊瘤overlap凹坑pit烧穿burn through塌陷excessive penetration未焊透incomplete penetration/ lack of penetration未熔合lack of fusion/ incomplete fusion 未焊满incompletely filled weld根部凹陷root concavity电弧擦伤arc scratch夹渣slag inclusion夹杂物inclusion夹钨tungsten inclusion白点fish eye/ flake错边misalignment/ dislocation焊接检验试件test piece试样test specimen无损检验nondestructive test破坏检验destructive test外观检查visual examination超声波探伤ultrasonic inspection直射法超声波探伤straight beam method斜射法超声波探伤angle beam method液浸法超声波探伤immersion method射线探伤radiographic inspection/ radiographyX射线探伤X-ray radiographic inspection γ射线探伤gamma-ray inspectionX射线工业电视探伤X-ray industrial television inspection磁粉探伤magnetic particle inspection电磁探伤electromagnetic inspection/ eddy current test探伤灵敏度flaw detection sensitivity浸透探伤penetration inspection荧光探伤flurescent penetrant inspection 着色探伤dye penetrant inspection密封性检验leak test气密性检验air tight test枕形气密检验pillow test耐压检验pressure test水压检验hydraulic test气压检验pneumatic test液晶检验liquid crystal test声发射检测acoustic emission testing面弯试验face bend testing背弯试验root bend test侧弯试验side bend test横弯试验horizontal bend test纵弯试验axial bend test压扁试验squeezing testactual weld-throat thick-ness焊缝厚度all-around weld整周焊缝all-around weld (整周焊缝)环焊缝angle butt weld斜对接焊angle weld角焊appearance of weld焊缝成形arc-seam weld电弧缝焊arc-spot weld电弧点焊arc-weld电弧焊aspect ratio of weld焊缝成形系数at weld edge在焊缝边上attachment weld连接焊缝automatic spot weld自动点焊法automatic weld自动焊接axis of a weld焊缝行南? 焊接轴线axis of weld焊缝轴线; 焊接轴线back of weld焊缝反面backing groove of weld焊缝反面坡口backing weld底焊; 底焊焊缝bare metal arc weld裸焊条电弧焊bead weld珠焊; 堆焊bead-on-plate weld堆焊焊缝beading weld凸焊beam-to-beam weld梁间焊接; 梁式引线焊接block sequence weld分段多层焊bond weld钢轨接头焊接bridge seam weld桥缝焊接; 桥线焊brize weld硬焊butt weld对接焊缝butt weld ends对头焊接端butt-weld碰焊; 平式焊接; 对头焊接butt-weld in the downhand position对接平焊butt-weld joint对头焊接butt-weld pipe mill对焊管轧机button spot weld按电钮点焊cap weld最后焊层; 盖面焊缝carbon content of weld materials焊接材料的碳含量cast-weld construction铸焊构造caulk weld填缝焊caulking weld密实焊缝chain intermittent fillet weld链式分段角焊; 并列连续角焊缝chain intermittent weld并列焊接circular weld环形焊缝circumferential weld环缝; 环焊缝cleft weld裂口焊closed weld底边无缝焊; 无间隙焊缝closed-chamber fusion weld闭室熔焊cluster weld丛聚焊缝coil weld卷板对接焊; 卷板对接焊; 板卷焊cold weld冷压接commutator-controlled weld换向控制焊接complete penetration butt weld贯穿对焊composite weld严密焊缝; 强度密封焊缝concave filled weld凹形角焊缝concave filler weld凹角焊concave fillet weld凹面填角焊concave weld凹焊缝; 凹面焊; 凹形焊缝; 轻型焊connective weld联络焊缝continuous butt-weld mill连续式炉焊管机组continuous fillet weld连续(填)角焊缝; 连续角焊缝; 连续贴角焊continuous weld连续焊缝continuous weld process连续式炉焊管法contour weld特形焊接convex fillet weld凸角焊缝; 凸形角焊缝convex weld凸焊缝; 凸形焊缝copper weld wire包铜钢丝corner flange weld单卷边角焊缝corner weld角焊corner-flange weld卷边角焊缝; 卷边角焊缝crack of weld焊部裂纹cross weld十字穿插焊缝; 横向焊缝cross-wire weld十字焊crotch weld楔接锻接; 楔接焊接cup weld带盖板焊缝depth of weld焊接深度dissimilar weld metal不同的焊接金属; 不同金属的焊接distance between the toes of a weld焊缝宽度double groove weld双面坡口焊缝double-bevel groove weld双斜边坡口焊缝; 双斜坡口焊double-flanged butt weld双弯边对接焊缝double-V groove weld双斜边坡口焊缝; 双斜坡口焊downhand weld平焊缝duplex spot weld双点点焊接头edge joint weld边缘焊edge weld端接焊; 端接焊缝; 端面焊缝; 对边焊electric resistance weld mill电阻焊管机electric weld-pipe mill电焊管机焊接专业英语词汇〔通用部分〕acetylene 乙炔 ampere 电流安培angle welding 角焊 arc 电弧argon arc welding 氩弧焊接 bare electrode 光熔接条butt welding 对接焊接 camber 电弧弯曲cascade 阶叠熔接法 clad weld 被覆熔接crator 焊疤 excess metal 多余金属filler rod 焊条 fillet weld 填角焊接gas shield 气体遮蔽 groove welding 起槽熔接hand face shield 手握面罩 hard facing 硬外表堆焊jig welding 工模焊接 laser beam welding 雷射光焊接metal electrode insert gas welding MIG熔接nugget 点焊熔核overlaying 堆焊 peening of welding 珠击熔接法plug welding 塞孔熔接 positioned welding 正向熔接pressure welding 压焊 propane gas cutting 丙烷气切割pure nickel electrode 纯镍熔接条reinforcement of weld 加强焊接resist 抗蚀护膜 root running 反面熔接seam 焊缝 seaming 接合seam welding 流缝熔接 series seam welding 串联缝熔接skip welding process 跳焊法 spark 火花spot welding 点焊接 stitch welding 针角焊接stud arc welding 电弧焊接 under laying 下部焊层void 焊接空隙 weld flow mark 焊接流痕weld flush 焊缝凸起 weld line 焊接纹weld mark 焊接痕 weld penetration 熔接透入weld zone 焊接区 welding 焊接welding bead 焊接泡 welding direction 焊接方向welding distortion 焊接变形 welding flux 焊剂welding ground 电熔接地 welding interval 焊接周期welding stress 熔接应变 welding torch 熔接气炬welding electrode production line 电焊条消费线welding electrode 焊条welding fixture 焊接夹具welding generator 电焊机welding goggles 焊工护目镜welding gun 焊枪welding helmet 电焊帽welding inspection ruler 焊接检验尺welding machine 焊接机welding mill 焊管机welding motor generator 电动焊接发电机welding nozzle 焊嘴welding paste 焊接药膏welding pipe 焊接收welding powder 焊粉welding rectifier 焊接整流器welding robot 焊接机器人welding rod extrusion press 焊条挤压机welding rod with acidic coating 酸性焊条welding rod with alkaline coating 碱性焊条welding rod 焊条welding simulator 焊接模拟器welding stainless electrode 不锈电焊条welding steel tube 焊接钢管welding tin billet 焊锡棒料welding tongs 焊接夹钳welding torch 焊炬welding transformer 电焊变压器welding unit 焊机welding wire machine 焊线机welding wire 焊丝welding-cutting hose 熔焊及切割胶管welding-cutting tool 焊割具welding-rod core 焊条芯welding-seam cleaner 焊缝清理机weldless pipe 无缝管weldless steel tube 无缝钢管well borer 凿井机well counter 井式计数器well deck vessel 井形甲板船well drill 钻井机well platform 钻井平台well rig 钻井机well testing truck 试井车well thermometer 井温计well tube filter 井管滤管well type tempering electric furnace 井式回火电炉well winch 矿井绞车well-logging probe 测井探头well-type counter 井型计数器Wella Balsam Conditioner 威娜宝护发素Wella Balsam shampoo 威娜宝香波Wellene 韦纶聚酯短纤维wellhead acid preventer 井口防酸器wellington 惠灵顿防雨呢Wellingtons 长筒皮靴Welltite 韦纶泰特聚丙烯和聚乙烯单丝Welsbach's alloy 韦尔斯巴赫发火合金Welsh flannel 威尔士法兰绒Welsh wool 威尔士粗羊毛welsh-onion stalk 葱白welsh-onion 葱welt cementing machine 贴边粘合机welt coloring machine 贴边染色机welt cutting machine 切沿条机welt fitting machine 贴边机welt footwear 加贴边的鞋welter screen 翻滚筛welter 镶边机Wepsin 三唑磷胺Werlisa 威里沙牌照相机Werner 维尔纳牌手表weskit 紧身背心Wessel silver 韦塞尔铜镍锌合金West cigarette 威狮牌香烟West ginseng 西洋参West Lake Dragon Well tea 西湖龙井茶West Lake silk umbrella 西湖绸伞West Lake silk 西湖丝绸West Lake water shield 西湖莼菜Westeeco 韦斯蒂科镍铬铁耐热合金Western king prawn 宽沟对虾Western saddle pants 西式马裤Western sand cherry 沙樱桃Western shirt 西式衬衫western style bed sheet 西式床单Western style hat 西式呢帽Western style pajamas 西式睡衣裤Western style pants 西裤Western style shirt 西式衬衫Western style shirt-waist blouse 西式衬衫上衣Western style suit 西服western tie 西式领带Western wool 美国西部羊毛Western-made shirt in plaid gingham 长方格贞咸布西式衬衫Westinghouse alloy 西屋镍铜热磁补偿合金wet spinning frame 湿纺细纱机wet air compressor 湿空气压缩机wet air pump 湿空气泵wet and dry bulb hygrometer 干湿球湿度计wet and dry bulb recording hygrometer 干湿球自记湿度计wet and dry bulb thermometer 干湿球温度计wet ball mill 湿式球磨机wet blue goat leather 山羊蓝湿革wet blue goat skin 蓝湿山羊皮wet board machine 湿式纸板机wet brush 湿刷wet chrome goat skin 铬湿山羊皮wet cleaner 湿法清洗器wet cloth 湿光布wet clutch 湿式离合器wet collector 湿式除尘器wet condenser 湿式冷凝器wet crude 含水原油wet crushing mill 湿粉碎机wet cylinder liner 湿式气缸套wet drill 湿式风钻wet dust collector 湿式收尘器wet dust separator 湿式除尘器wet electro-magnet 湿式电磁铁wet electrolytic capacitor 电解液电容器wet feeder 湿式给料机wet fiber filter 湿式纤维过滤器wet filter 湿式过滤器wet fourdrinier board machine 长网湿抄机wet frame 湿纺机wet furfural condenser 含水糖醛冷凝器wet gas meter 湿式气量计wet gas scrubber 湿法气体洗涤质量合格证书certification of fitness原材料rawmaterial 底板 bottom plate垫层 cushion侧壁 sidewall中心线center line条形根底 strip footing附件 accessories型钢 profile steel钢板 steel plate熔渣 slag飞溅 welding spatter定位焊 tacking引弧 generating of arc熄弧 quenching of arc焊道 welding bead坡口 beveled edges外观检查 visual inspection重皮 doubleskin程度方向弧度 radian in horizontal direction 成型 molding直线度 straightness accuracy焊缝角变形 welding line angular distortion 程度度 levelness铅垂度 verticality翘曲变形 buckling deformation角尺 angle square对接焊缝 butt weld母材 parent metal法兰密封面 flange sealing surface夹层interlayer外表锈蚀浓度 surface corrosion concentration挠曲变 bending deformation超声波探伤 ultrasonic testing/ ultrasonic examination压力容器 pressure vessel预制下料prefabrication baiting排版直径 set-type diameter焊缝 welding line中幅板 ? center plate测量方法 measuring method基准点 datum mark跳焊 skip welding允许偏向 allowable variation补强板 stiffening plate开孔 tapping对接接头 banjo fixing butt jointing角钢 angle iron安装基准圆 installation fundamental circle 吊装立柱 hoisting upright column焊接钢管 welded steel pipe向心斜拉筋 centripetal canting pull rope 带板 band plate槽钢胀圈 channel steel expansion ring环口 collar extension部分变形 local distortion环缝 circumferential weld顶板 top plate拱顶 vault顶板加强肋 stiffening rib对接 butt joint胎具 clamping fixture卷板机 plate bending rolls中心支架 center bearing bracket椭圆度 ovality等分线 bisectrix搭接宽度lap width点焊spot welding搭接焊 overlap welding对称：symmetrically螺旋爬梯cockle stairs放料阀baiting valve液位计 content gauge充水试验 filling water test错边量 unfitness of butt joint底圈 foundation ring真空度检漏 vacuum degree leak test丁字焊缝 tee welding浸透探伤 oil whiting test充水试验 filling water test内侧角焊缝接头 interior angle welding line jointfoundation settlement 根底沉降测量基准点 datum mark?稳定性试验 stability test排气阀 outlet valve角钢 angle steel构件 component part机械损伤 mechanical damage缩孔 shrinkage cavityenfoldment 折迭碳钢管 carbon steel tube公称直径 nominal diameter预埋件 embedded part轴测图 axonometric drawing布置图arrangement diagram氧乙炔气割 oxyacetylene gas cutting低合金钢管low alloy steel 热影响区 heat affected area修磨polish砂轮片grinding wheel等离子plasma panel重皮 coldlap凹凸unevenness缩口necking down端面 head face倾斜偏差 dip deviation外径 external diameter砂轮grinding wheel管件 pipe casting单线图single line drawing平齐parallel and level两端 two terminals满扣 buckle螺栓紧固 bolton周边 periphery附加应力 additional stress同轴度 axiality平行度 parallelism随机 stochastic允许偏差 allowable variation重直度verticality程度度 levelness隔离盲板 blind plate氩弧焊argon arc welding压盖螺栓 gland bolt间距spacing有效期 period of validity担任 take charge of ;undertake焊条 welding rod碳钢焊条carbon steel焊丝 welding wire熔化焊 melting钢丝 steel wire气体保护焊 gas shielded arc welding 烘干drying清洗ablution制度system焊接工艺welding procedure相应corresponding手工电弧焊manual electric arc welding 手工钨极 manual tungsten electrode打底render电源power source交流alternating current焊件 weldment管壁厚度 pipe thickness对接焊缝 butt weld工件壁厚 workpiece飞溅物 splash沾污 smirch油污 oil stain细锉 smooth file铣刀 milling cutter氧化膜 oxide film脱脂处理 ungrease treatment]棉质纤维 cotton fibre丙酮acetone硫 sulfur焊剂 welding flux钢板 steel plate纵向焊缝 l0ngitudinal weld l0ngitudinal seam筒节 shell ring封头 end socket卷管 reelpipe强度试验strength test起弧arc starting穿堂风draught熔合fusion反面reverse side整体integral封堵block up焊口 weld bond医用胶布medical proof fabric高频 high frequency焊炬welding torch送气air supply焊接专业英语词汇〔熔化焊〕熔接fusion welding压接pressure welding焊接过程welding process焊接技术welding technique焊接工艺welding technology/procedure焊接操作welding operation焊接顺序welding sequence焊接方向direction of welding焊接位置welding position熔敷顺序build-up sequencedeposition sequence焊缝倾角weld slope/inclination of weld axis 焊缝转角weld rotation/angle of rotation平焊位置flat position of welding横焊位置horizontal position of welding立焊位置vertical position of welding仰焊位置overhead position of welding 平焊downhand welding/flat position welding 横焊horizontal position welding立焊vertical position welding仰焊overhead position welding全位置焊all position welding：熔焊时，焊件接逢所处空间位置包括平焊、横焊、仰焊等位置所进展的焊接。
常用焊接术语中英文对照焊接 Welding10.1 焊接种类 Varieties of Welding电弧焊 arc welding电熔焊 electric fusion welding (EFW)气熔焊 fusion gas welding (FGW)电阻焊 electric resistance welding (ERW)有保护的金属电弧焊 shielded metal arc welding (SMAW)手工或自动隋性气体保护钨极电弧焊 manual and automatic inert gas tungsten arc welding (GTAW)自动埋弧焊 automatic submerged arc welding金属极隋性气体保护电弧焊 gas metal arc weiding (GMAW)氩弧焊 argon-arc welding，气体保护电弧焊 gas-shielded arc welding气焊 gas welding; flame welding等离子焊 plasma welding硬钎焊 braze welding电渣焊 electroslag welding爆炸焊 explosive welding10.2 焊接形式 Type of Welding角焊 fillet welding间断焊 intermittent welding点焊 spot welding对焊 butt welding搭焊 lap welding塞焊 plug welding珠焊 bead welding槽焊 slot welding堆焊 build up welding垫板焊 backing weld坡口 grooveV形坡口 V groove单面U形坡口 single U grooveK形坡口 double bevel grooveX形坡口 double V groove双面U形坡口 double U grooveU-V组合坡口 combination U and V groove根部间隙 root gap焊接符号 symbol of weld错边量 alignment tolerance10.3 焊接位置 Welding Position仰焊 overhead welding现场焊 field weld (F.W.)封底焊 back run welding立焊 vertical welding平焊 flat welding工厂（车间）焊接 shop weld定位焊 tack weld跳焊 skip welding节距 pitch10.4 焊接缺陷 Defects of Welding焊接裂纹 weld crack根部裂纹 root crack微裂纹 micro crack错位 mismatch弧坑 pit; crater焊穿 burn through夹渣 slag inclusion咬边；咬肉 undercut焊瘤 overlap气孔 porosity, blow hole砂眼 blister针孔 pin hole严重飞溅 excessive spatter未溶合 incomplete fusion; lack of fusion 根部未焊透 incomplete penetration10.5 其它母材；基层金属 base metal预热 preheating热影响区 heat affected zone (HAZ)焊条 welding electrode (rod)焊丝 welding wire焊药（剂） flux。
焊接符号大全详解在现代工业生产中，焊接是一种极为重要的连接工艺。
为了准确、清晰地表达焊接的要求和技术规范，焊接符号应运而生。
焊接符号就像是一种特殊的语言，它能够在图纸上向焊接工人传递各种关键信息，确保焊接工作的质量和准确性。
接下来，让我们详细了解一下焊接符号的世界。
焊接符号通常由基本符号、辅助符号、补充符号、焊缝尺寸符号和指引线等部分组成。
基本符号是焊接符号的核心部分，它用来表示焊缝的横截面形状。
常见的基本符号有以下几种：1、Ⅰ形焊缝：这是最简单的一种焊缝形状，通常用于薄板的焊接。
2、 V 形焊缝：其横截面呈 V 形，具有一定的坡口角度，适用于较厚板材的焊接。
3、 X 形焊缝：也称为双面 V 形焊缝，需要在焊接件的两面进行坡口加工和焊接，能够提供较大的焊缝强度。
4、 U 形焊缝：具有较深的坡口，能够保证焊缝根部的熔透，常用于对焊接质量要求较高的场合。
辅助符号用于补充说明焊缝的某些特征，比如焊缝表面形状、焊缝的分布等。
例如，平面符号表示焊缝表面是平的；凹面符号表示焊缝表面下凹；凸面符号表示焊缝表面凸起。
补充符号则用于表示焊缝的某些特殊要求，如焊接方法、焊缝的段数等。
比如，带垫板符号表示在焊缝底部放置垫板；周围焊缝符号表示焊缝环绕工件的整个周边。
焊缝尺寸符号用于明确焊缝的具体尺寸，包括焊缝的宽度、深度、余高、坡口角度等。
这些尺寸信息对于焊接工艺的制定和焊接质量的控制至关重要。
指引线一般由箭头线和基准线组成。
箭头线直接指向焊缝位置，基准线则用来标注各种符号和尺寸。
在实际应用中，焊接符号的组合方式多种多样。
例如，一个简单的角焊缝可能由基本符号（如三角形）、焊缝尺寸（如焊脚尺寸）和指引线组成。
而对于一个复杂的对接焊缝，可能还会包括坡口角度、钝边尺寸等详细信息。
此外，还有一些特殊的焊接符号需要注意。
比如，点焊缝符号通常用于薄板的连接，用一个圆来表示；塞焊缝和槽焊缝符号则分别用于表示填充在圆孔或长槽中的焊缝。
Weld symbol 焊接符号welding symbol 焊缝符号supplementary [,sʌpli'mentəri]补充的,补充物Placement 标注illustration [ɪlə'streɪʃ(ə)n] 插图说明joint type 接头类型General provision for welding symbols 焊接符号中的通用规定signification [,sɪgnɪfɪ'keɪʃ(ə)n] 意义arrow ['ærəʊ] 箭头Location signification of the arrow 箭头位置的意义Respect to 关于combination weld symbols 组合焊缝符号multiple ['mʌltɪpl] 多数的Reference 参考field weld [fiːld]现场施焊denoted [dɪ'nəʊt] 表示weld dimension tolerance 焊缝尺寸公差backing welds 打底焊joints with backing 带衬垫的接头intermittent [,intə'mitənt] 间歇的angle ['æŋg(ə)l] 角度spacing 距离involving [ɪn'vɒlv] 包含，涉及Spot welds 点焊surfacing a previous weld 在前一焊道上堆焊adjust [ə'dʒʌst] dimension 调整尺寸special preparation not specified没有指定的特殊处理elements 内容US customary and SI units 美国的习惯和SI 单位designator [,dɛzɪg'netɚ] 符号Joint type designators 组合形式符号root opening 根部间隙groove angle 坡口角度Partial joint 部分熔透焊缝intermittent welds 间断焊joints with backing or spacers 带有垫板或者间隔的接头Indicating ['indikeitiŋ]表明requirement 要求include 包含provision [prə'vɪʒ(ə)n]规定Graphical ['græfɪk(ə)l] representation 表现Graphical representation 图解表示法specify['spɛsɪfaɪ] 指定，详细说明extent [ik'stent] 范围，长度convention [kən'vɛnʃən] 惯例常规convey [kən'veɪ] 传达illustrative['ɪləstrətɪv; ɪ'lʌst-] 说明的examples featuring ['fiːtʃə] 例子展示beyond the scope of this standard 超出标准的范围fully addressed 充分描述normative references 引用标准constitute ['kɑnstətut] 组成dated references 以前的引用标准subsequent ['sʌbsɪkwənt] 后来的amendment[ə'mɛndmənt] 修正most recent editions 最新版本mandatory ['mændətɔri] 强制的guide for 指南term [tɝm] 条款eliminate[ɪ'lɪmɪnet] 消除designating ['dɛzɪɡnet] 标注peening ['pi:niŋ] 锤击pertinent['pɝtnənt] 相关的pertinent data 相关资料regarding 关于interpreted [ɪn'tɝprɪt] 理解interpreted as 理解为refer to 指的是placement 分布，布置weld all around 满焊convex['kɒnveks] 凸面concave ['kɒnkeɪv] 凹面flat 平面contour ['kɑntʊr] 轮廓lap joint 搭接arrow side 箭头侧consider [kən'sɪdɚ] 认为，当做arrow ['ærəu] contact 箭头指向specified by 用。
焊接英语（完整版）焊缝符号 welding symbol焊缝金属 weld metal填充金属 filler metal熔敷金属 deposited metal焊缝表面weld face/ face of weld焊缝背面 back of weld焊缝轴线axis of weld焊缝尺寸 size of weld焊缝宽度weld width/ width of weld焊缝长度 weld length/ length of weld 焊缝有效长度 effective length of weld 焊缝厚度 throat depth/ throat thickness 焊缝计算厚度theoretical throat焊缝实际厚度actual throat熔深penetration/ depth of penetration 焊缝成形appearance of weld焊缝成形系数form factor of weld余高 reinforcement/ excess weld metal 背面余高root reinforcement削平焊缝flush weld/ weld machined flush 对接焊缝butt weld角焊缝fillet焊脚leg/ fillet weld leg角焊缝断面形状profile of fillet weld 平形角焊缝flat fillet凸形角焊缝convex fillet weld凹形角焊缝concave fillet weld角焊缝凹度concavity侧面角焊缝side fillet weld/ fillet weld in parallel shear正面角焊缝front fillet weld/ fillet weld in normal shear立角焊缝fillet weld in the vertical position横角焊缝fillet weld in the horizontal position平角焊缝fillet weld in the flat position斜角焊缝oblique fillet weld连续焊缝continuous weld断续焊缝intermittent weld连续角焊缝continuous fillet weld断续角焊缝intermittent fillet weld 交错断续角焊靤taggered intermittent fillet weld并列断续角焊缝chain intermittentfillet weld端接焊缝edge weld卷边焊缝flanged edge weld塞焊焊缝plug weld纵向焊缝longitudinal weld横向焊缝transverse weld环行焊缝girth weld/ circumferential weld螺旋形焊缝spiral weld/ helical weld 密封焊缝seal weld承载焊缝strength weld联系焊缝connective weld定位焊缝tack weld焊道bead/ run/ pass焊波ripple焊根weld root/ root of weld焊趾weld toe/ toe封底焊道sealing run (after making main weld)/ back weld打底焊道backing weld (before making main weld)/ back weld根部焊道root pass/ root run填充焊道filling bead盖面焊道cosmetic bead/ cover pass回火焊道temper bead/ annealing bead 熔透焊道penetration bead焊层 layer焊接接头welded joint接头形状joint geometry等强匹配接头equalmatching weld joint 低强匹配接头undermatching weld joint 超强匹配接头overmatching weld joint 接头根部root of joint对接接头butt jointI形对接接头square butt jointV形对接接头single V butt jointU形对接接头single U butt jointJ形坡口接头single J butt joint双V形对接接头double V butt joint双单边V形对接接头double bevel butt joint/ K groove butt joint带钝边U形对接接头double U butt joint 带钝边J形坡口接头double J joint角接接头corner jointT形接头T joint斜T形接头inclined T joint十字接头cruciform joint/ cross-shaped joint三联接头joint among three members搭接接头lap joint套管接头muff joint/ sleeve joint双盖板接头double strapped joint盖板接头strapped joint端接接头edge joint卷边接头flanged edge joint锁底对接接头lock butt joint斜对接接头oblique butt joint混合接头mixed joint/ composite joint 有间隙接头open joint无间隙接头closed joint焊接电弧welding arc电弧形态arc shape电弧物理行为arc physics behaviour引弧striking arc引弧电压striking voltage电弧气氛arc atmosphere阴极cathode热阴极hot cathode冷阴极cold cathode阴极斑点cathode spot阴极区cathode region阴极区电场强度intensity of the electric field in the cathode region 阴极压降cathode drop阳极anode阳极斑点anode spot斑点压力spot pressure阳极区anode region阳极区电场强度intensity of the electric field in the anode region阳极压降anode drop弧柱arc column/ arc stream弧柱压降voltage drop in arc column弧柱电位梯度potential gradient in the arc column 弧焰arc flame弧心arc core硬电弧forceful arc/ hard arc软电弧soft arc旋转电弧rotating arc脉冲电弧pulsed arc脉冲喷射电弧pulsed spray arc起皱现象puckering phenomena起皱电弧puckering arc起皱临界电流 puckering critical current间接电弧 indirect arc压缩电弧 compressive arc磁控电弧 magnetic controlling arc电弧力 arc force电磁力 electromagnectic force电磁收缩效应 pinch effect电弧飘移 wandering of arc电弧稳定性 arc stability电弧静特性 static characteristic of arc 电弧动特性 dynamic characteristic of arc最小电压原理 principle of minimum voltage电弧挺度arc stiffness电弧偏吹 arc blow磁偏吹 magnetic blow阴极清理作用 cleaning action of the cathode电弧自身调节 arc self-regulation挖掘作用 digging action极性效应 polarity effect熔滴 droplet熔滴比表面积 specific surface of droplet熔滴过渡metal transfer过度频率 transition frequency粗滴过渡globular transfer; drop transfer短路过渡short circuiting transfer喷射过渡spray transfer旋转喷射过渡 rotating spray transfer 脉冲喷射过渡 pulsed spray transfer爆炸过渡 explosive transfer渣壁过渡 flux wall guided transfer熔池 molten pool沸腾状熔池 boiling molten pool弧坑crater熔渣slag渣系 slag system渣系相图 slag system diagram碱性渣 basic slag酸性渣 acid slag碱度 basicity酸度 acidity长渣 long slag短渣 short slag粘性熔渣 viscous slag氧化物型熔渣 oxide melting slag盐型熔渣 salt melting slag盐-氧化物型熔渣 salt-oxide melting slag熔渣流动性 fluidity of the slag; slag fluidity熔渣solidified slag多孔焊渣 porous slag玻璃状焊渣 vitreous slag自动脱落焊渣 self-releasing slag脱渣性 slag detachability焊接设备 welding equipment; welding set 焊机 welding machine; welder电焊机 electric welding machine; electric welder焊接电源 welding power source焊接专业英语词汇（熔化焊一）熔接 fusion welding压接 pressure welding焊接过程 welding process焊接技术 welding technique焊接工艺 welding technology/procedure 焊接操作 welding operation焊接顺序 welding sequence焊接方向 direction of welding焊接位置 welding position熔敷顺序 build-up sequence/deposition sequence焊缝倾角 weld slope/inclination of weld axis焊缝转角weld rotation/angle of rotation平焊位置 flat position of welding横焊位置 horizontal position of welding 立焊位置 vertical position of welding 仰焊位置 overhead position of welding 平焊downhand welding/flat position welding横焊 horizontal position welding立焊 vertical position welding仰焊 overhead position welding全位置焊 all position welding：熔焊时，焊件接逢所处空间位置包括平焊、横焊、仰焊等位置所进行的焊接。
焊接专业英语词汇（通用部分）Fierce welding 满焊焊烧Symmetry welding 对称焊接Welding deformation 焊接变形Seal 封口Vertical position welding 立焊Horizontal position welding 横焊Over-head position welding 仰焊acetylene 乙炔ampere 电流安培angle welding 角焊arc 电弧argon arc welding 氩弧焊接bare electrode 光熔接条butt welding 对接焊接camber 电弧弯曲cascade 阶叠熔接法clad weld 被覆熔接crator 焊疤excess metal 多余金属filler rod 焊条fillet weld 填角焊接gas shield 气体遮蔽groove welding 起槽熔接hand face shield 手握面罩hard facing 硬表面堆焊jig welding 工模焊接laser beam welding 雷射光焊接metal electrode insert gas welding MIG熔接nugget 点焊熔核overlaying 堆焊peening of welding 珠击熔接法plug welding 塞孔熔接positioned welding 正向熔接pressure welding 压焊propane gas cutting 丙烷气切割pure nickel electrode 纯镍熔接条reinforcement of weld 加强焊接resist 抗蚀护膜root running 背面熔接seam 焊缝seaming 接合seam welding 流缝熔接series seam welding 串联缝熔接skip welding process 跳焊法spark 火花spot welding 点焊接stitch welding 针角焊接stud arc welding 电弧焊接under laying 下部焊层void 焊接空隙weld flow mark 焊接流痕weld flush 焊缝凸起weld line 焊接纹weld mark 焊接痕weld penetration 熔接透入weld zone 焊接区welding 焊接welding bead 焊接泡welding direction 焊接方向welding distortion 焊接变形welding flux 焊剂welding ground 电熔接地welding interval 焊接周期welding stress 熔接应变welding torch 熔接气炬welding electrode production line 电焊条生产线welding electrode 焊条welding fixture 焊接夹具welding generator 电焊机welding goggles 焊工护目镜welding gun 焊枪welding helmet 电焊帽welding inspection ruler 焊接检验尺welding machine 焊接机welding mill 焊管机welding motor generator 电动焊接发电机welding nozzle 焊嘴welding paste 焊接药膏welding pipe 焊接管welding powder 焊粉welding rectifier 焊接整流器welding robot 焊接机器人welding rod extrusion press 焊条挤压机welding rod with acidic coating 酸性焊条welding rod with alkaline coating 碱性焊条welding rod 焊条welding simulator 焊接模拟器welding stainless electrode 不锈电焊条welding steel tube 焊接钢管welding tin billet 焊锡棒料welding tongs 焊接夹钳welding torch 焊炬welding transformer 电焊变压器welding unit 焊机welding wire machine 焊线机welding wire 焊丝welding-cutting hose 熔焊及切割胶管welding-cutting tool 焊割具welding-rod core 焊条芯welding-seam cleaner 焊缝清理机weldless pipe 无缝管weldless steel tube 无缝钢管well borer 凿井机well counter 井式计数器well deck vessel 井形甲板船well drill 钻井机well platform 钻井平台well rig 钻井机well testing truck 试井车well thermometer 井温计well tube filter 井管滤管well type tempering electric furnace 井式回火电炉well winch 矿井绞车well-logging probe 测井探头well-type counter 井型计数器Wella Balsam Conditioner 威娜宝护发素Wella Balsam shampoo 威娜宝香波Wellene 韦纶聚酯短纤维wellhead acid preventer 井口防酸器wellington 惠灵顿防雨呢Wellingtons 长筒皮靴Welltite 韦纶泰特聚丙烯和聚乙烯单丝Welsbach's alloy 韦尔斯巴赫发火合金Welsh flannel 威尔士法兰绒Welsh wool 威尔士粗羊毛welsh-onion stalk 葱白welsh-onion 葱welt cementing machine 贴边粘合机welt coloring machine 贴边染色机welt cutting machine 切沿条机welt fitting machine 贴边机welt footwear 加贴边的鞋welter screen 翻滚筛welter 镶边机Wepsin 三唑磷胺Werlisa 威里沙牌照相机Werner 维尔纳牌手表weskit 紧身背心Wessel silver 韦塞尔铜镍锌合金West cigarette 威狮牌香烟West ginseng 西洋参West Lake Dragon Well tea 西湖龙井茶West Lake silk umbrella 西湖绸伞West Lake silk 西湖丝绸West Lake water shield 西湖莼菜Westeeco 韦斯蒂科镍铬铁耐热合金Western king prawn 宽沟对虾Western saddle pants 西式马裤Western sand cherry 沙樱桃Western shirt 西式衬衫western style bed sheet 西式床单Western style hat 西式呢帽Western style pajamas 西式睡衣裤Western style pants 西裤Western style shirt 西式衬衫Western style shirt-waist blouse 西式衬衫上衣Western style suit 西服western tie 西式领带Western wool 美国西部羊毛Western-made shirt in plaid gingham 长方格贞咸布西式衬衫Westinghouse alloy 西屋镍铜热磁补偿合金wet spinning frame 湿纺细纱机wet air compressor 湿空气压缩机wet air pump 湿空气泵wet and dry bulb hygrometer 干湿球湿度计wet and dry bulb recording hygrometer 干湿球自记湿度计wet and dry bulb thermometer 干湿球温度计wet ball mill 湿式球磨机wet blue goat leather 山羊蓝湿革wet blue goat skin 蓝湿山羊皮wet board machine 湿式纸板机wet brush 湿刷wet chrome goat skin 铬湿山羊皮wet cleaner 湿法清洗器wet cloth 湿光布wet clutch 湿式离合器wet collector 湿式除尘器wet condenser 湿式冷凝器wet crude 含水原油wet crushing mill 湿粉碎机wet cylinder liner 湿式气缸套wet drill 湿式风钻wet dust collector 湿式收尘器wet dust separator 湿式除尘器wet electro-magnet 湿式电磁铁wet electrolytic capacitor 电解液电容器wet feeder 湿式给料机wet fiber filter 湿式纤维过滤器wet filter 湿式过滤器wet fourdrinier board machine 长网湿抄机wet frame 湿纺机wet furfural condenser 含水糖醛冷凝器wet gas meter 湿式气量计wet gas scrubber 湿法气体洗涤质量合格证书certification of fitness原材料rawmaterial底板bottom plate垫层cushion侧壁sidewall中心线center line条形基础strip footing附件accessories型钢profile steel钢板steel plate熔渣slag飞溅welding spatter定位焊tacking引弧generating of arc熄弧quenching of arc焊道welding bead坡口beveled edges外观检查visual inspection重皮doubleskin水平方向弧度radian in horizontal direction 成型molding直线度straightness accuracy焊缝角变形welding line angular distortion 水平度levelness铅垂度verticality翘曲变形buckling deformation角尺angle square对接焊缝butt weld母材parent metal法兰密封面flange sealing surface夹层interlayer表面锈蚀浓度surface corrosion concentration挠曲变bending deformation超声波探伤ultrasonic testing/ ultrasonic examination 压力容器pressure vessel预制下料prefabrication baiting排版直径set-type diameter焊缝welding line中幅板? center plate测量方法measuring method基准点datum mark跳焊skip welding允许偏差allowable variation补强板stiffening plate开孔tapping对接接头banjo fixing butt jointing角钢angle iron安装基准圆installation fundamental circle吊装立柱hoisting upright column焊接钢管welded steel pipe向心斜拉筋centripetal canting pull rope 带板band plate槽钢胀圈channel steel expansion ring 环口collar extension局部变形local distortion环缝circumferential weld顶板top plate拱顶vault顶板加强肋stiffening rib对接butt joint胎具clamping fixture卷板机plate bending rolls中心支架center bearing bracket椭圆度ovality等分线bisectrix搭接宽度lap width点焊spot welding搭接焊overlap welding对称：symmetrically螺旋爬梯cockle stairs放料阀baiting valve液位计content gauge充水试验filling water test错边量unfitness of butt joint底圈foundation ring真空度检漏vacuum degree leak test丁字焊缝tee welding渗透探伤oil whiting test充水试验filling water test内侧角焊缝接头interior angle welding line joint foundation settlement 基础沉降测量基准点datum mark?稳定性试验stability test排气阀outlet valve角钢angle steel构件component part机械损伤mechanical damage缩孔shrinkage cavityenfoldment 折迭碳钢管carbon steel tube公称直径nominal diameter预埋件embedded part轴测图axonometric drawing布置图arrangement diagram氧乙炔气割oxyacetylene gas cutting 低合金钢管low alloy steel热影响区/受热区heat affected area 修磨polish砂轮片grinding wheel等离子plasma panel重皮coldlap凹凸unevenness缩口necking down端面head face倾斜偏差dip deviation外径external diameter砂轮grinding wheel管件pipe casting单线图single line drawing平齐parallel and level两端two terminals满扣buckle螺栓紧固bolton周边periphery附加应力additional stress同轴度axiality平行度parallelism随机stochastic允许偏差allowable variation重直度verticality水平度levelness隔离盲板blind plate氩弧焊argon arc welding压盖螺栓gland bolt间距spacing有效期period of validity担任take charge of ;undertake焊条welding rod碳钢焊条carbon steel焊丝welding wire熔化焊melting钢丝steel wire气体保护焊gas shielded arc welding 烘干drying清洗ablution制度system焊接工艺welding procedure相应corresponding手工电弧焊manual electric arc welding手工钨极manual tungsten electrode打底render电源power source交流alternating current焊件weldment管壁厚度pipe thickness对接焊缝butt weld工件壁厚workpiece飞溅物splash沾污smirch油污oil stain细锉smooth file铣刀milling cutter氧化膜oxide film脱脂处理ungrease treatment]棉质纤维cotton fibre丙酮acetone硫sulfur焊剂welding flux钢板steel plate纵向焊缝longitudinal weld longitudinal seam筒节shell ring封头end socket卷管reelpipe强度试验strength test起弧arc starting穿堂风draught熔合fusion反面reverse side整体integral封堵block up焊口weld bond医用胶布medical proof fabric高频high frequency焊炬welding torch送气air supply喇叭形坡口flare groove锁底坡口single bevel groove with backing locked 坡形板边tapered edge焊缝weld接逢seam焊缝符号welding symbol焊缝金属weld metal填充金属filler metal熔敷金属deposited metal焊缝表面weld face/ face of weld焊缝背面back of weld焊缝轴线axis of weld焊缝尺寸size of weld焊缝宽度weld width/ width of weld焊缝长度weld length/ length of weld焊缝有效长度effective length of weld焊缝厚度throat depth/ throat thickness焊缝计算厚度theoretical throat焊缝实际厚度actual throat熔深penetration/ depth of penetration焊缝成形appearance of weld焊缝成形系数form factor of weld余高reinforcement/ excess weld metal背面余高root reinforcement削平焊缝flush weld/ weld machined flush 对接焊缝butt weld角焊缝fillet焊脚leg/ fillet weld leg角焊缝断面形状profile of fillet weld平形角焊缝flat fillet凸形角焊缝convex fillet weld凹形角焊缝concave fillet weld角焊缝凹度fillet weld concavity侧面角焊缝side fillet weld/ fillet weld in parallel shear 正面角焊缝front fillet weld/ fillet weld in normal shear 立角焊缝fillet weld in the vertical position横角焊缝fillet weld in the horizontal position平角焊缝fillet weld in the flat position斜角焊缝oblique fillet weld连续焊缝continuous weld断续焊缝intermittent weld连续角焊缝continuous fillet weld断续角焊缝intermittent fillet weld交错断续角焊缝staggered intermittent fillet weld并列断续角焊缝chain intermittent fillet weld端接焊缝edge weld卷边焊缝flanged edge weld塞焊焊缝plug weld纵向焊缝longitudinal weld横向焊缝transverse weld环行焊缝girth weld/ circumferential weld螺旋形焊缝spiral weld/ helical weld密封焊缝seal weld承载焊缝strength weld联系焊缝connective weld定位焊缝tack weld焊道bead/ run/ pass焊波ripple焊根weld root/ root of weld焊趾weld toe/ toe封底焊道sealing run (after making main weld)/ back weld打底焊道backing weld (before making main weld)/ back weld 根部焊道root pass/ root run填充焊道filling bead盖面焊道cosmetic bead/ cover pass回火焊道temper bead/ annealing bead熔透焊道penetration bead焊层layer焊接接头welded joint接头形状joint geometry等强匹配接头equalmatching weld joint低强匹配接头undermatching weld joint超强匹配接头overmatching weld joint接头根部root of joint对接接头butt jointI形对接接头square butt jointV形对接接头single V butt jointU形对接接头single U butt jointJ形坡口接头single J butt joint双V形对接接头double V butt joint双单边V形对接接头double bevel butt joint/ K groove butt joint 带钝边U形对接接头double U butt joint带钝边J形坡口接头double J joint角接接头corner jointT形接头T joint斜T形接头inclined T joint十字接头cruciform joint/ cross-shaped joint三联接头joint among three members搭接接头lap joint套管接头muff joint/ sleeve joint双盖板接头double strapped joint盖板接头strapped joint端接接头edge joint卷边接头flanged edge joint锁底对接接头lock butt joint斜对接接头oblique butt joint混合接头mixed joint/ composite joint有间隙接头open joint无间隙接头closed joint焊接电弧welding arc电弧形态arc shape电弧物理行为arc physics behaviour引弧striking arc引弧电压striking voltage电弧气氛arc atmosphere阴极cathode热阴极hot cathode冷阴极cold cathode阴极斑点cathode spot阴极区cathode region阴极区电场强度intensity of the electric field in the cathode region 阴极压降cathode drop阳极anode阳极斑点anode spot斑点压力spot pressure阳极区anode region阳极区电场强度intensity of the electric field in the anode region 阳极压降anode drop弧柱arc column/ arc stream弧柱压降voltage drop in arc column弧柱电位梯度potential gradient in the arc column弧焰arc flame弧心arc core硬电弧forceful arc/ hard arc软电弧soft arc旋转电弧rotating arc脉冲电弧pulsed arc脉冲喷射电弧pulsed spray arc起皱现象puckering phenomena起皱电弧puckering arc起皱临界电流puckering critical current间接电弧indirect arc压缩电弧compressive arc磁控电弧magnetic controlling arc电弧力arc force电磁力electromagnectic force电磁收缩效应pinch effect电弧飘移wandering of arc电弧稳定性arc stability电弧静特性static characteristic of arc电弧动特性dynamic characteristic of arc最小电压原理principle of minimum voltage 电弧挺度arc stiffness电弧偏吹arc blow磁偏吹magnetic blow阴极清理作用cleaning action of the cathode 电弧自身调节arc self-regulation挖掘作用digging action极性效应polarity effect熔滴droplet熔滴比表面积specific surface of droplet熔滴过渡metal transfer过度频率transition frequency粗滴过渡globular transfer; drop transfer短路过渡short circuiting transfer喷射过渡spray transfer旋转喷射过渡rotating spray transfer脉冲喷射过渡pulsed spray transfer爆炸过渡explosive transfer渣壁过渡flux wall guided transfer熔池molten pool沸腾状熔池boiling molten pool弧坑crater熔渣slag渣系slag system渣系相图slag system diagram碱性渣basic slag酸性渣acid slag碱度basicity酸度acidity长渣long slag短渣short slag粘性熔渣viscous slag氧化物型熔渣oxide melting slag盐型熔渣salt melting slag盐-氧化物型熔渣salt-oxide melting slag熔渣流动性fluidity of the slag; slag fluidity 熔渣solidified slag多孔焊渣porous slag玻璃状焊渣vitreous slag自动脱落焊渣self-releasing slag脱渣性slag detachability焊接设备welding equipment; welding set焊机welding machine; welder电焊机electric welding machine; electric welder焊接电源welding power source热丝MIG焊hot wire MIG weldingMIG熔接metal electrode insert gas weldingX射线衍射法X-ray stress analysisX射线探伤X-ray radiographic inspectionX射线工业电视探伤X-ray industrial television inspectionTigamajig 薄板焊接裂纹试验Tigamajing thin plate cracking test 热丝TIG焊hot wire TIG welding100℃残余扩散氢diffusible hydrogen remained at 100℃射频熔接; 高频焊接radio-frequency welding预热preheat预热preheat预热温度preheat temperature预热时间preheat time预热电流preheat *预热火焰preheat flame预热氧preheat oxygenCO2预热器CO2 heater预热Preheating预热温度Preheat temperature错边量unfitness of butt joint埋弧焊submerged arc welding (SAW)埋弧焊Submerged arc welding （SAW）自动埋弧焊automatic submerged arc welding窄间隙埋弧焊焊剂flux for narrow-gap submerged arc welding 埋弧焊submerged arc welding (SAW)多丝埋弧焊multiple wire submerged arc welding纵列多丝埋弧焊Tandem sequence (submerged-arc welding) 横列多丝埋弧焊series submerged arc welding (SAW-S)横列双丝并联埋弧焊transverse submerged arc welding热丝埋弧焊hot wire submerged-arc welding窄间隙埋弧焊narrow-gap submerged arc welding埋弧焊机submerged arc welding machine接合线, 焊线埋弧焊bonding wire埋弧焊Submerged arc welding （SAW）对接接头butt joint对接接头banjo fixing butt jointing对接接头butt jointI形对接接头square butt jointV形对接接头single V butt jointU形对接接头single U butt joint双V形对接接头double V butt joint双单边V形对接接头double bevel butt joint/ K groove butt joint 带钝边U形对接接头double U butt joint锁底对接接头lock butt joint斜对接接头oblique butt joint对接接头banjo fixing butt jointing搭接对接接头butt and lap joint焊接weld硬焊, 铜焊, 钎焊braze welding焊接法, 定位焊接welding碳极弧焊carbon arc weld平焊缝downhand weld凹角焊concave fillet weld气压焊gas-pressure weld凸面对焊法烂raised face welding neck flange轨端补焊rail-end welding射频熔接; 高频焊接radio-frequency welding自动点焊法automatic spot weld爆炸焊接explosive weld特形焊接contour weld坡口焊groove weld双斜边坡口焊缝, K形坡口焊缝double-bevel groove weld 对接焊缝butt weld焊(接)件weldment无焊缝的weldless可焊的weldable硬焊, 铜焊, 钎焊braze welding可焊的weldable空气-乙炔焊接air-acetylene weldingwelding自动电渣焊automatic slag-pool welding自动调弧氩弧焊, 惰性气体保护金属极弧焊aircomatic welding 铸焊, 铝热剂焊接aluminothermic welding对接焊, 对焊butt welding不锈钢(焊条)焊接austenite welding自动埋弧焊automatic submerged arc welding氩护电弧焊argon shielded arc welding焊工welder焊工Weldor焊工护目镜welding goggles焊工welder电焊工manual arc welder气焊工gas welder焊工培训welders training焊工模拟训练器trainer of synthetic weld焊工考试welder qualification test焊工合格证welder qualification/ welder qualified certification 焊工升降台welder’s lifting platform焊工尘肺pheumocomsis of welder车轮系统< English> Wheeling System轮毂< English> Wheel Hub轮胎< English> Tire轮胎汽门嘴< English> Tire Valve轮圈< English> Wheel Disk轮圈盖< English> Wheel Cover车轮系统< English> Wheeling System电装品< English> Electrical Parts电瓶< English> Battery中央门控< English> Central Door Lock分电盘< English> Distributor火星塞< English> Spark Plug汽车用电子钟< English> Digital Clock汽车音响< English> Car Audio防盗器< English> Car Burglar Alarm雨刷及雨刷连杆< English> Wiper / Linkage保险丝座< English> Fuse Seat保险丝< English> Fuse洗涤壶< English> Windshield Washer配线< English> Wire Harness马达类< English> Motor高压线组< English> Ignition Cable喇叭< English> Horn发电机(零件) < English> Alternator (Components)开关类< English> Switch蜂鸣器< English> Buzzer预热塞< English> Glow Plug仪表< English> Combination Meter灯泡< English> Bulb灯类< English> Lamp点火线圈< English> Ignition Coil继电器< English> Relay倒车雷达< English> Reverse Sensor电池充电器< English> Battery Charger闪光器< English> Flasher省电器< English> Energy Saving Unit端子< English> Terminal电动座椅装置< English> Power Seat Unit马达零件< English> Motor Components电装品< English> Electrical Parts汽车用光盘< English> Car CD汽车用液晶显示器< English> Car LCD调整器< English> Regulator整流器< English> Rectifier电子点火器< English> Ignition Module倒车显示器< English> Rear View Display定速器< English> Cruise ControllerHID车灯安定器组合< English> HID Ballast Complete Set for HeadlightsLED 灯< English> LED Lamp车灯控制器< English> Lighting Controller点火线圈模块< English> Ignition Coil Module外装品< English> Exterior Parts水箱饰罩< English> Radiator Grille天线< English> Antenna车身护条< English> Side Protector防撞护垫< English> Bumper Pad后视镜< English> Door Mirror装饰贴纸、标志< English> Ornament Mark轮弧< English> Fender Trim挡泥板< English> Mud Guard扰流板< English> Spoiler前防撞杆< English> Guard Assy (Front)后防撞杆< English> Grard Assy (Rear)内装品< English> Interior Parts仪表板< English> Instrument Panel中央置物箱< English> Console孔塞< English> Grommet Plug地毯< English> Floor Mat安全带< English> Seat Belt车门扶手< English> Door Armrest车门把手< English> Door Handle车门锁< English> Door Lock车顶内衬< English> Roof Lining车窗升降摇柄< English> Window Lifter Handle车窗升降机< English> Window Lifter防水衬条< English> Weather strip油量表< English> Fuel Gauge门饰板< English> Door Trim室内镜< English> Room Mirror音响喇叭盖< English> Speaker Cover(电动)座椅< English> (Electric) Seat顶蓬< English> Headlining烟灰缸< English> Ashtray各类隔音垫< English> All Kinds of Silencer饰板/饰条< English> Garnish / Trim仪表饰板< English> Instrument Panel Garnish遮阳板< English> Sun visor压条< English> Moulding点烟器< English> Cigar Lighter备胎板< English> Trim for Spare Tire天窗< English> Sun Roof后置物板< English> Rear Parcel Shelf后舱室饰板< English> Rear Trunk Trim仪表板支架< English> Instrumental Panel Mounting其它< english> Others随车工具< english> Tools千斤顶< english> Jack尼龙绳、特多龙绳< english> Nylon Rope生产、检测及涂装设备< English> Production, Test & Painting Equipment各类孔盖< English> Cap、Cover扣具< English> Cargo Lash夹片、管束< English> Clamp, Clip油土与基准模型< english> Clay Model and Master Model油封< english> Oil Seal门铰链< english> Door Hinge故障标志< english> Reflector玻璃类< english> Glass修理业< english> Repairing & Maintenance粉末冶金< english> Powder Metallurgy轴承< english> Bearing塑料件< english> Plastic Parts隔热材< english> Heat Insulator电子件< english> Electrical Parts垫片类< english> Seal、Gasket、Washer、Packing碳刷< english> Carbon Brush管类< english> Pipe, Hose, Tube铜套类< english> Bushing弹簧< english> Spring橡胶件< english> Rubber Parts帮浦类< english> Pump螺帽/螺栓/螺丝< english> Nut/Bolt/Screw锻造件(加工) < english> Forging Parts (Processing)滤清器类< english> Filter锁< english> Lock镜类< english> Mirror铸造件(加工) < english> Casting Parts (Processing)引擎盖铰链< english> Hinge of Engine Hood行李箱铰链< english> Hinge of Trunk Lid保险杆支撑< english> Mount of BumperCAD/CAM车身设计< english> CAD/CAM Car Body Design 汽车清洁保养用品< english> Cosmetics for Automobile 涂料< english> Paints合成木材< english> Synthetic Wood电磁阀< english> Solenoid Valve热水阀< english> Heater Valve冷煤电磁阀< english> Refrigerate Solenoid valve玻璃滑槽< english> Glass Run双面胶带< english> Acrylic Foam Tape触媒转换器缓冲绵< english> Catalytic Converter Mate黑烟过滤器< english> Diesel Particle Filter车用灭火器< english> Extinguisher零组件用材料< english> Components Materials汽车用行动电话< english> Car Hand-free Mobile Phone 汽车保全系统< english> Car Security System汽车导航系统< english> Car Navigation System人造革< english> Artificial Leather铭板< english> Nameplate汽车用计算机< english> Car Computer无线电胎压侦测仪< english> Wireless Tire Monitor汽车内装用牛皮< english> Leather for Car Interior打蜡机< english> Buffer (Car Polisher)金属表面处理(材料) < english> Metal Surface Treatment (Material)插接件< english> Connector Clip胎压不足警示器< english> Tire Low Pressure Indicator温度感应器< english> Water Temperature Sensor油压感应器< english> Oil Pressure Sensor机油< english> Engine Oil自动变速箱油< english> Automatic Transmission Oil油品添加剂< english> Oil Additive热处理< english> Heat Treatment传动件< english> Transmission曲柄组< english> Chainwheel & Crank飞轮< english> Flywheel链条< english> Chain变速杆< english> Shift Lever变速器< english> Derailleur电动自行车马达< english> Electric Bicycle Motor电动自行车控制器< english> Electric Bicycle Driver齿轮箱< english> Gear Box车轮及剎车< english> Wheel and Brake轮胎< english> Tire夹式剎车器< english> Caliper Brake快拆< english> Quick Release花鼓< english> Hub & Free Hub液压式剎车器< english> Hydraulic Brake脚剎车器< english> Coaster Brake碟式剎车器< english> Disk Brake轮圈< english> Rim辐条/辐帽< english> Spoke/Nipple悬臂式剎车器< english> Cantilever Brake控制拉线< english> Control Cable剎车来令片< english> Brake Lining Shoe配件< english> Accessories铃< english> Bell反光片< English> Reflector水壶架< English> Bottle Cage打气筒< English> Floor Pump商标贴纸< English> Sticker货架< English> Luggage Carrier速度表< English> Speed Meter车体打造(改装) < English> Car Body Building (Refitting) 引擎< english> Engine引擎波司< english> Engine Bush引擎修理包< english> Engine Gasket Kits引擎零件< english> Engine Parts凸轮轴< english> Camshaft凸轮轴链轮< english> Sprocket Camshaft皮带张力器< english> Tensioner曲轴< english> Crankshaft曲轴皮带盘< english> Crankshaft Pulley曲轴轴承片< english> Crankshaft Bearing气门 < english> Valve气门座 < english> Valve Seat气门摇臂 < english> Valve Arm气门摇臂盖 < english> Rocker Cover气门弹簧 < english> Valve Spring气门导管 < english> Valve Guide气缸头(盖) < english> Cylinder Head气缸衬套 < english> Cylinder Liner气缸体 < english> Cylinder Block波司垫片< english> Washer活塞< english> Piston活塞肖< english> Piston Pin活塞环< english> Piston Ring活塞衬套< english> Piston Liner飞轮< english> Flywheel飞轮环齿轮< english> Ring Gear of Flywheel时规炼条/皮带< english> Timing Chain/Belt连杆< english> Connecting Rod连杆轴承片< english> Connecting Rod Bearing摇臂轴< english> Rocker Arm Shaft汽门锁< english> Valve Cotter止推垫片< english> Thrust Washer共鸣箱< english> Resonator喷油嘴< english> Injection Nozzle燃料系统< english> Fueling System油箱< english> Fuel Tank油箱浮筒< english> Gauge Fuel Tank空气滤清器< english> Air Cleaner空气滤清器盖< english> Air Cleaner Cover空气滤清器导管< english> Air Intake Tube空气滤蕊< english> Air Cleaner Element消音器< English> Exhaust Muffler排气歧管< English> Exhaust Manifold排气管< English> Exhaust Pipe进气歧管< English> Intake Manifold节流阀< English> Throttle Valve燃油管< English> Fuel Pipe燃油帮浦< English> Fuel Pump燃油滤清器< English> Fuel Filter触媒转化器< English> Catalytic Converter柴油车黑烟净化器< English> Diesel Particulate Filter时规炼条/皮带外盖< English> Timing Chain/Belt Cover燃料系统< English> Fueling System废气回收管< English> EGR Tube冷却系统< English> Cooling System水箱< English> Radiator水管< English> Water Hose水箱水管< English> Radiator Hose水帮浦< English> Water Pump水箱风扇< English> Radiator Fan风扇< English> Fan副水箱< English> Auxiliary Radiator节温器< English> Thermostat调节器< English> Regulator水箱支架< English> Radiator Mounting冷却系统< English> Cooling SystemA/C风扇< English> A/C Fan润滑系统< English> Lubrication System油底壳< English> Oil Pan自排车用滤油器< English> Oil Filter for Automatic Transmission 机油尺< English> Oil Level Gauge机油帮浦< English> Oil Pump机油滤清器< English> Oil Filter机油滤网< English> Oil Strainer润滑系统< English> Lubrication System机油尺导管< English> Oil Level Gauge Tube空调系统< English> Air-conditioning System冷气总成< English> A/C Assembly冷气配管< English> A/C Hose冷气导风管< English> A/C Duct冷气压缩机< English> A/C Compressor冷凝器< English> A/C Condenser暖气总成< English> Heater Assembly鼓风机< English> Blower Assembly蒸发器< English> Evaporator冷媒管< English> A/C Pipe储液瓶< English> A/C Receiver空调相关零件< english> A/C Related Components 空气清净机< english> Air Purifier空调滤网< english> A/C Filter空调系统< english> Air-conditioning System提速器< english> Actuator车身钣金件< english> Body & Stamping Parts引擎支撑< english> Engine Mounting引擎盖< english> Engine Hood车身< english> Car Body车门< english> Door Panel车顶板< english> Roof底盘及其另件< english> Chassis and Related Parts 底盘车架< english> Frame门框< english> Sash保险杆< english> Bumper钣金件< english> Stamping Parts叶子板< english> Fender横梁< english> Cross Member行李箱盖< english> Trunk Lid车柱< english> Pillar车身钣金件< english> Body & Stamping Parts支架< english> Bracket补强板< english> Reinforcement Plate底盘系统< english> Chassis System下臂< english> Lower Arm上臂< english> Upper Arm手剎车拉柄< english> Parking Brake Lever支柱总成< english> Strut Assembly方向盘< english> Steering Wheel比例阀< english> Proportional Valve主轴、副轴< english> Mainshaft / Countershaft平衡杆< english> Stabilizer Bar扭力杆< english> Torsion Bar剎车分泵< english> Brake Cylinder剎车来令片< english> Brake Lining Shoe剎车油管(软) < english> Brake Hose剎车油管(硬) < english> Brake Tube剎车真空倍力器< english> Brake Vacuum Booster 剎车总泵< english> Brake Master Cylinder后轴总成< english> Rear Axle Assembly动力方向系统< english> Power Steering System。
史上最全的焊接专业术语中英文对照表，绝对值得收藏备用小编将网络上众多的参考资料编辑整理，为了方便您的查阅，特将各种专业术语的中英文对照按照焊接方法进行分类。
目录：一、熔化焊二、气焊、热剂焊、水下焊三、钎焊四、电阻焊摩擦焊爆炸焊扩散焊超声波焊等五、热喷涂与热切割六、焊接安全与防护一、熔化焊熔接fusion welding压接pressure welding焊接过程welding process焊接技术welding technique焊接工艺welding technology/procedure焊接操作welding operation焊接顺序welding sequence焊接方向direction of welding焊接位置welding position熔敷顺序build-up sequence/deposition sequence焊缝倾角weld slope/inclination of weld axis焊缝转角weld rotation/angle of rotation平焊位置flat position of welding横焊位置horizontal position of welding立焊位置vertical position of welding仰焊位置overhead position of welding平焊downhand welding/flat position welding横焊horizontal position welding立焊vertical position welding仰焊overhead position welding全位置焊all position welding向下立焊vertical down welding/downward welding in the vertical position向上立焊vertical up welding/upward welding in the vertical position倾斜焊inclined position welding上坡焊upward welding in the inclined position下坡焊downward welding in the inclined position对接焊butt welding角焊fillet welding搭接焊lap welding船形焊fillet welding in the downhand position/fillet welding in the flat position平角焊horizontal fillet welding立角焊fillet welding in the vertical position仰角焊fillet welding in the overhead position坡口焊groove weldingI形坡口对接焊square butt welding喇叭形坡口焊 flare groove welding卷边焊flanged edge welding纵缝焊接welding of l0ngitudinal seam横缝焊接welding of transverse seam环缝焊接girth welding/ circumferential螺旋缝焊接welding of spiral seam/welding of helical seam环缝对接焊butt welding of circumferential seam定位焊tack welding单面焊welding by one side双面焊welding by both sides单道焊single pass welding/single run welding多道焊multi-pass welding单层焊single layer welding多层焊multi-layer welding分段多层焊block sequence/ block welding分层多道焊multi-layer and multi-pass welding连续焊continuous welding断续焊intermittent welding打底焊backing weld封底焊back sealing weld盖面焊cosmetic welding深熔焊deep penetration welding摆动焊welding with weaving/weave bead welding前倾焊 foreward welding (英国)/ forehand welding (美国) 后倾焊 backward welding(英国)/ backhand welding(美国) 分段退焊backstep welding跳焊skip welding对称焊balanced welding/ balanced welding sequence 左焊法leftward welding forehand welding右焊法rightward welding/backhand welding挑弧焊whipping method自动焊automatic welding手工焊manual welding/hand welding车间焊接shop welding工地焊接site welding(英国)/ field welding (美国)拘束焊接restraint welding堆焊surfacing/building up/overlaying隔离层堆焊buttering端部周边焊boxing/end return返修焊rewelding补焊repair welding塞焊plug welding槽焊slot welding衬垫焊welding with backing焊剂垫焊welding with flux backing窄间隙焊narrow-gap welding强制成形焊enclosed welding脉冲电弧焊pulsed are welding电弧点焊arc spot welding螺柱焊stud welding热风焊hot gas welding高能焊high grade energy welding固态焊接solid-state welding单面焊双面成形one-side welding with back formation 焊接条件welding condition焊接工艺参数welding parameter极性polarity正接electrode negative/straight polarity反接electrode positive/reversed polarity运条方式manipulation of electrode焊接电流welding current焊接电流增加时间welding current upslope time焊接电流衰减时间welding current downslope time电流密度current density短路电流short circuit current脉冲电流pulse level/pulse current level脉冲电流幅值pulse current amplitude基值电流background level脉冲频率pulse frequency脉冲焊接电流占空比duty cycle of pulse duration电弧电压arc voltage再引弧电压reignition voltage焊接速度welding speed行走速度rate of travel/travel speed送丝速度wire feed rate线能量heat input/energy input热输入heat input预热preheat后热postheat焊后热处理posweld heat treatment/postheat treatment 预热温度preheat temperature层间温度interpass temperature焊接终了温度finishing temperature后热温度postheating temperature焊丝伸出长度wire extension弧长arc length熔化速度melting rate熔化时间melting time熔化系数melting coefficient熔敷速度rate of deposition/deposition rate熔敷系数deposition coefficient熔敷效率deposition efficiency损失系数loss coefficient飞spatter飞溅率spatter loss coefficient融合比fusion ratio稀释dilution稀释率rate of dilution合金过度系数transfer efficiency/recovery (of an element)坡口groove坡口面groove face坡口面角度angle of bevel (英国)/ bevel angle (美国)坡口角度included angle(英国)/groove angle(美国)坡口高度groove depth钝边root face钝边高度thickness of root face/width of root face根部间隙root gap(英国)/root opening (美国)根部半径root radius/groove radius根部锐边root edge卷边高度height of flange卷边半径radius of flange单面坡口single groove双面坡口double groove坡口形式groove typeI形坡口square grooveV形坡口single V grooveY形坡口single V groove with root face双Y形坡口double Vgroove with root face带钝边U形坡口single U groove带钝边双U形坡口double U grooveVY形坡口single compound angle groove带钝边J形坡口single J groove带钝边双J形坡口double J groove单边V形坡口single bevel groove双V形坡口double V groove不对称双V形坡口 asymmetric double V groove双单边V形坡口 double bevel groove/K groove带垫板V形坡口 V groove with backing/ single V groove withbacking喇叭形坡口flare groove锁底坡口single bevel groove with backing locked 坡形板边 tapered edge焊缝 weld接逢 seam焊缝符号 welding symbol焊缝金属 weld metal填充金属 filler metal熔敷金属 deposited metal焊缝表面weld face/ face of weld焊缝背面 back of weld焊缝轴线axis of weld焊缝尺寸 size of weld焊缝宽度weld width/ width of weld焊缝长度 weld length/ length of weld焊缝有效长度 effective length of weld焊缝厚度 throat depth/ throat thickness焊缝计算厚度theoretical throat焊缝实际厚度actual throat熔深penetration/ depth of penetration焊缝成形appearance of weld焊缝成形系数form factor of weld余高 reinforcement/ excess weld metal背面余高root reinforcement削平焊缝flush weld/ weld machined flush对接焊缝butt weld角焊缝fillet焊脚leg/ fillet weld leg角焊缝断面形状profile of fillet weld平形角焊缝flat fillet凸形角焊缝convex fillet weld凹形角焊缝concave fillet weld角焊缝凹度concavity侧面角焊缝side fillet weld/ fillet weld in parallel shear 正面角焊缝front fillet weld/ fillet weld in normal shear 立角焊缝fillet weld in the vertical position横角焊缝fillet weld in the horizontal position平角焊缝fillet weld in the flat position斜角焊缝oblique fillet weld连续焊缝continuous weld断续焊缝intermittent weld连续角焊缝continuous fillet weld断续角焊缝intermittent fillet weld交错断续角焊缝staggered intermittent fillet weld并列断续角焊缝chain intermittent fillet weld端接焊缝edge weld卷边焊缝flanged edge weld塞焊焊缝plug weld纵向焊缝l0ngitudinal weld横向焊缝transverse weld环行焊缝girth weld/ circumferential weld螺旋形焊缝spiral weld/ helical weld密封焊缝seal weld承载焊缝strength weld联系焊缝connective weld定位焊缝tack weld焊道bead/ run/ pass焊波ripple焊根weld root/ root of weld焊趾weld toe/ toe封底焊道sealing run (after making main weld)/ back weld打底焊道backing weld (before making main weld)/ back weld 根部焊道root pass/ root run填充焊道filling bead盖面焊道cosmetic bead/ cover pass回火焊道temper bead/ annealing bead熔透焊道penetration bead焊层 layer焊接接头welded joint接头形状joint geometry等强匹配接头equalmatching weld joint低强匹配接头undermatching weld joint超强匹配接头overmatching weld joint接头根部root of joint对接接头butt jointI形对接接头square butt jointV形对接接头single V butt jointU形对接接头single U butt jointJ形坡口接头single J butt joint双V形对接接头double V butt joint双单边V形对接接头double bevel butt joint/ K groove butt joint带钝边U形对接接头double U butt joint带钝边J形坡口接头double J joint角接接头corner jointT形接头T joint斜T形接头inclined T joint十字接头cruciform joint/ cross-shaped joint三联接头joint among three members搭接接头lap joint套管接头muff joint/ sleeve joint双盖板接头double strapped joint盖板接头strapped joint端接接头edge joint卷边接头flanged edge joint锁底对接接头lock butt joint斜对接接头oblique butt joint混合接头mixed joint/ composite joint有间隙接头open joint无间隙接头closed joint焊接电弧welding arc电弧形态arc shape电弧物理行为arc physics behaviour引弧striking arc引弧电压striking voltage电弧气氛arc atmosphere阴极cathode热阴极hot cathode冷阴极cold cathode阴极斑点cathode spot阴极区cathode region阴极区电场强度intensity of the electric field in the cathode region阴极压降cathode drop阳极anode阳极斑点anode spot斑点压力spot pressure阳极区anode region阳极区电场强度intensity of the electric field in the anoderegion阳极压降anode drop熔滴 droplet熔滴比表面积 specific surface of droplet熔滴过渡metal transfer过度频率 transition frequency粗滴过渡globular transfer; drop transfer短路过渡short circuiting transfer喷射过渡spray transfer旋转喷射过渡 rotating spray transfer脉冲喷射过渡 pulsed spray transfer爆炸过渡 explosive transfer渣壁过渡 flux wall guided transfer熔池 molten pool沸腾状熔池 boiling molten pool弧坑crater熔渣slag渣系 slag system渣系相图 slag system diagram碱性渣 basic slag酸性渣 acid slag熔渣solidified slag多孔焊渣 porous slag玻璃状焊渣 vitreous slag自动脱落焊渣 self-releasing slag脱渣性 slag detachability焊接设备 welding equipment; welding set 焊机 welding machine; welder氢脆 hydrogen embrittlement层状偏析 lamellar segregation愈合 healing effect断口金相fractography断口 fracture延性断口 ductile fracture韧窝断口dimple fracture焊接性weldability使用焊接性 service weldability工艺焊接性 fabrication weldability冶金焊接性 metallurgical weldability热焊接性 thermal weldability母材 base metal; parent metal焊接区 weld zone焊态 as-welded (AW)母材熔化区 fusion zone半熔化区 partial melting region未混合区 unmixed zone熔合区 bond area熔合线 weld junction (英)；bond line (美) 热影响区 heat-affected zone (HAZ)过热区 overheated zone粗晶区 coarse grained region细晶区 fine grained region过渡区 transition zone硬化区 hardened zone裂纹敏感性 cracking sensibility焊接裂纹 weld crack焊缝裂纹 weld metal crack焊道裂纹 bead crack弧坑裂纹crater crack热影响区裂纹 heat-affected zone crack纵向裂纹 l0ngitudinal crack横向裂纹 transverse crack微裂纹 micro-crack; micro-fissure热裂纹 hot crack凝固裂纹 solidification crack晶间裂纹 intercrystalline crack穿晶裂纹 transcrystalline crack多边化裂纹 polygonization crack液化裂纹 liquation crack失延裂纹 ductility-dip crack冷裂纹 cold crack延迟裂纹 delayed crack氢致裂纹 hydrogen-induced crack焊道下裂纹 underbead crack焊根裂纹 root crack焊趾裂纹 toe crack锯齿形裂纹 chevron cracking焊接材料welding consumables二、气焊、热剂焊、水下焊气焊gas welding氧乙炔焊 oxy-acetylene welding氢氧焊 oxy-hydrogen welding空气乙炔焊 air-acetylene welding氧乙炔焊 oxy-acetylene flame氢氧焰 oxy-hydrogen flame氧煤气焰 oxy-coal gas flame焊接火焰 welding flame混合比 mixing ratio混合气体可燃范围 inflammable limit of the gaseous一次燃烧 primary combustion二次燃烧 secondary combustion燃烧速度 combustion rate燃烧强度 combustion intensity火焰热效率 flame heating efficiency焰芯 inner cone; flame cone内焰 internal flame外焰 flame envelope中性焰 neutral flame氧化焰 oxidizing flame碳化焰 carburizing flame回火 flashback逆火 backfire回烧 flashback气体发生速度 gasification speed焊炬 torch; blow pipe等压式焊炬 balanced pressure torch射吸式焊炬 injector torch氧乙炔焊炬 oxy-acetylene torch焊割两用炬 combined cutting and welding torch 混合室 mixing chamber喷射器 injector焊嘴 welding nozzle; welding tip液氧气化器 oxygen evaporator气瓶 gas cylinder乙炔瓶 acetylene cylinder阀罩 cylinder cap气瓶阀 cylinder valve汇流排 cylinder manifold减压器 pressure regulator; gas regulator单级减压器 single stage regulator两级减压器 two stage regulator回火防止器 flashback arrestor干式回火防止器 dry flashback arrestor水封式回火防止器 water-closing type arrestor净化器 purifier乙炔发生器 acetylene generator低压乙炔发生器 low pressure acetylene generator热剂补焊 thermit repair welding钢轨热剂焊 thermit rail welding热剂 thermit powder热剂钢水 thermit steel热剂反应 thermit reaction热剂溶渣 thermit slag热剂铸模 thermit mold; mold for thermit weld水下气体保护电弧焊 underwater gas shielded arc welding水下等离子弧焊 underwater plasma arc welding温式水下焊wet method underwater welding干式水下焊 dry method underwater welding局部干式水下焊 local dry underwater welding水帘局部干式水下焊water curtain type dry underwater welding三、钎焊硬钎焊brazing软钎焊soldering烙铁钎焊iron soldering火焰钎焊torch brazing/ torch soldering热风钎焊hot gas soldering感应钎焊induction brazing电阻钎焊resistance brazing接触反应钎焊contact-reaction brazing电弧钎焊arc brazing浸渍钎焊dip brazing/ dip soldering盐浴钎焊saltbath dip brazing (soldering)金属浴钎焊molten metal bath dip brazing炉中钎焊furnace brazing/ furnace soldering保护气氛钎焊brazing in controlled atmosphere真空钎焊vacuum brazing蒸气钎焊vapor phase soldering超声波钎焊ultrasonic soldering扩散钎焊diffusion brazing波峰钎焊flow soldering/ wave soldering分级钎焊step brazing/ step soldering红外线钎焊infra-red brazing (soldering)光束钎焊light soldering (brazing)激光钎焊laser brazing (soldering)电子束钎焊electron beam brazing钎接焊braze-welding钎料brazing filler metal/ solder硬钎料brazing filler metal软钎料solder (m)自钎剂钎料self-fluxing brazing alloy/ self-fluxing filler metal 活性钎料active filler metal/ active metal brazing alloy成形钎料preformed filler metal/ solder preform非晶态钎料amorphous filler metal粉状钎料powdered filler metal钎料膏braze cream/ braze paste/ solder cream/ solder paste 药皮钎料 flux coated brazing(soldering)rod层状钎料 sandwich filler metal药芯钎料丝 flux-cored colder wire敷钎料板 clad brazing sheet钎剂 brazing flux; soldering flux气体钎剂 gas flux反应钎剂 reaction flux松香钎剂 colophony flux; rosin flux钎剂膏 flux paste阻流剂 stopping-off agent钎剂活性 flux activity钎剂活性温度范围 activation temperature range of flux 钎剂热稳定性thermal stability of flux钎焊过程 brazing (soldering) process钎焊操作 brazing (soldering) operation工艺镀层 technological coating钎焊面 faying face钎焊参数 brazing process variables钎焊温度 brazing temperature钎焊时间 brazing time钎焊保温时间 holding time of brazing钎缝 brazing seam; soldering seam钎缝界面区 interfacial region钎缝金属 brace metal钎角 fillet钎焊接头 braced joint; soldered joint平面搭接头 joggled lap joint; flush lap joint搭接对接接头 butt and lap joint搭接T形接头 lapped T-joint; flanged T-joint锁缝接头 folded joint平面锁缝接头 lick side seam joint; flat lock seam joint 锁缝角接接头 lock corner joint; corner double seam嵌入T形接头 inset T jointT形管接头 branch T saddle joint套管接头 socket joint外喇叭口套管接头 flare tube fitting扩口套管接头 spigot joint钎焊性 brazability; solderability润湿性 wettability润湿角 wetting angle; contact angle铺展性 spreadability铺展系数 spread factor; coefficient of spreading 钎着率 brazed rate脱钎 de-brazing; de-soldering润湿称量试验 wetting balance test铺展性试验 spreadability test填缝性试验 clearance fillability test未钎透 incomplete penetration虚钎 cold soldered joint钎料熔析 liquation of filler metal溶蚀 erosion钎料流失 brazing filler metal erosion钎剂夹杂 flux inclusion四、电阻焊、摩擦焊、爆炸焊、扩散焊、超声波焊等电阻焊 resistance welding (RW)点焊 spot welding; resistance spot welding凸焊 projection welding缝焊 seam welding滚点焊 roll-spot welding连续点焊 stitch welding多点焊 multiple spot welding手压点焊 push welding; poke welding脉冲点焊 pulsation spot welding; multiple-impulse welding 双面点焊 direct spot welding单面点焊 indirect spot welding串联点焊 series spot welding多点凸焊multiple projection welding频道进缝焊 step-by-step seam welding压平缝焊 mash seam welding串联缝焊 series seam welding对接缝焊 butt seam welding; foil-butt seam电阻对焊 upset butt welding闪光对焊 flash butt welding (FBW)储能焊 stored energy welding电容储能点焊 condenser discharge spot welding高频电阻焊 high frequency resistance welding冲击电阻焊 percussion welding胶接点焊 spot weld-bonding; weld-bonding闪光 flashing; flash过梁 bridge; lintel顶锻 upsetting; upset夹紧力 clamping force顶锻力 upsetting force; upset force电极压力 electrode force; electrode pressure电极滑移 electrode skid焊接循环 welding cycle预压时间 squeeze time锻压时间 forge-delay time; forge time焊接通电时间（电阻焊）welding time (resistance welding) 预热时间 preheat time加热时间 heat time冷却时间 cool time间歇时间 quench time; chill time回火时间 temper time维持时间 hold time休止时间 off time闪光时间flash time; flashing time顶锻时间 upset time; upsetting time 有电顶锻时间 upset current time无电顶锻时间 upset current-off time闪光速度 flashing speed闪光电流 flashing current; flash current 顶锻电流 upset current预热电流 preheat current回火电流 temper current调伸长度 initial overhange; extension 闪光留量 flash allowance电极接触面 electrode contact surface 贴合面 faying surface焊点 welding spot熔核 nugget熔核直径 diameter of nugget塑性金属环区corona bond焊透率penetration rate压痕indentation压痕深度depth of indentation压深率indentation ratio翘离sheet separation缩孔shrinkage cavity胡须intrusion电极粘损electrode pick up喷溅splash/ expulsion毛刺fin飞边upset metal/ fin焊点距weld spacing/ spot weld spacing边距edge distance分流shunt current接触电阻contact resistance电阻焊机resistance welding machine点焊机spot welding machine多点焊机multiple spot welding machine移动式点焊机portable spot welding machine缝焊机seam welding machine纵横两用缝焊机universal seam welder对焊机butt resistance welding machine凸焊机projection welding machine三相低频焊机three phase low frequency welder工频电阻焊机mains frequency resistance welding machine低频电阻焊机frequency converter resistance welding machine高频焊机high frequency induction welder逆变式电阻焊机inverter type resistance welding machine全波阻焊电源full wave resistance welding power source斩波阻焊电源chopped wave resistance welding power source 旋转焊接变压器rotary welding transformerC形点焊钳C-type welding head/ C-type gunX形点焊钳pincer spot welding head/ pliers spot welding head断续器contactor同步断续器synchronous contactor异步断续器non-synchronous contactor程序控制器sequencer程序时间调节器sequencer timer电极臂arm电极握杆electrode holder电极台板backup die/ bolster摩擦焊friction welding (FW)转速friction speed摩擦压力friction pressure/ heating pressure摩擦时间friction time摩擦变形量burn-off length摩擦变形速度burn-off rate停车时间stopping time顶锻变形量forge length顶锻变形速度forge rate摩擦表面friction surface储能摩擦焊fly-wheel type friction welding径向摩擦焊radial friction welding扩散焊diffusion welding (DW)过渡液相扩散焊transient liquid phase diffusion welding 热等静压扩散焊hot isotatic pressure diffusion welding 热轧扩散焊roll diffusion welding质量比mass ratio平行法parallel plate configuration角度法preset angle configuration均匀布药average arranging explosive梯形布药gradient arranging explosive爆炸焊参数explosive welding parameters初始参数initial parameters动态参数dynamic parameters界面参数interface parameters爆轰速度detonation velocity覆板速度cladding plate velocity碰撞点impact point碰撞点速度velocity of the impact point界面波长length of the interfacial wave界面波幅amplitude of the interfacial wave熔化层molten layer熔化袋molten pocket雷管区detonator zone边界效应edge effect焊接性窗口weldability windows焊着率ratio of welding area内爆法internal explosion process外爆法external explosion process半圆柱试验法semi-cylinder experiment method 超声波焊ultrasonic welding (UW)超声波点焊ultrasonic spot welding超声波缝焊ultrasonic seam welding超声波点焊机ultrasonic spot welder超声波缝焊机ultrasonic seam welder冷压焊cold pressure welding (CPW)热压焊hot pressure welding热轧焊hot roll welding旋弧压力焊rotating arc pressure welding埋弧压力焊submerged arc pressure welding电渣压力焊electroslag pressure welding气压焊gas pressure welding锻焊forge-welding/ blacksmith welding磁力脉冲焊magnetic-pulse welding五、热喷涂与热切割热喷涂 thermal spraying火焰喷涂 flame spraying电弧喷涂 electric arc spraying等离子喷涂 plasma spraying高频感应喷涂 high frequency spraying 金属喷涂 metal spraying; metallizing塑料喷涂 plastic spraying陶瓷喷涂 ceramic spraying喷熔 spray-fusing表面粗糙化处理 surface roughening电火花拉毛 electrospark roughening抛锚效应 anchoring喷涂层 spray-fused coating喷熔层 spray-fused coating结合层 bond coating; under coating工作层 work coating结合强度 adhesive strength涂层强度 strength of coating封孔处理 sealing封孔剂 sealant喷涂率 spray rate沉积效率 deposition efficiency孔隙率 porosity喷涂材料 spraying material自熔剂合金粉末 self-fluxing alloy powder 喷炬（枪）spray torch;热切割 thermal cutting (TC)气割 gas cutting; oxygen cutting氧溶剂切割 powder cutting氧-石英砂切割 quartz powder cutting电弧切割 arc cutting氧气电弧切割 oxy-arc cutting空气电弧切割 air arc cutting等离子弧切割 plasma arc cutting (PAC)空气等离子弧切割 air plasma arc cutting氧等离子切割 oxygen plasma arc cutting水再压缩空气等离子弧切割air plasma water injection arc cutting双层气流等离子弧切割dual gas plasma arc cutting; shielded gas plasma arc cutting激光切割 laser cutting(LC); laser beam cutting电子束切割 electron beam cutting喷气激光切割 gas jet laser cutting碳弧切割 carbon arc cutting水下切割 underwater cutting喷水式水下电弧切割 waterjet method underwater arc cutting 氧矛切割 oxygen lancing; oxygen lance cutting溶剂氧切割 powder lancing手工气割 manual oxygen cutting自动气割 automatic oxygen cutting仿形切割 shape cutting数控切割 NC (numerical-control) cutting快速切割 high-speed cutting垂直切割 square cut叠板切割 stack cutting坡口切割 beveling; bevel cutting碳弧气割 carbon arc air gouging火焰气刨 flame gouging火焰表面清理 scarfing氧熔剂表面修整powder washing预热火焰preheat flame预热氧preheat oxygen切割氧cutting oxygen/ cutting stream切割速度cutting speed切割线lone of cut/ cut line切割面face of cut/ cut face切口kerf切口上缘cutting shoulder切口宽度kerf width后拖量drag切割面平面度evenness of cutting surface/ planeness of cutting surface割纹深度depth of cutting veins/ stria depth切割面质量quality of cut face上缘熔化度shoulder meltability/ melting degree of shoulder 切口角kerf angle缺口notch挂渣adhering slag结瘤dross割炬cutting torch/ cutting blowpipe/ oxygen-fuel gas cutting torch割枪cutting gun割嘴cutting nozzle/ cutting tip快速割嘴divergent nozzle/ high-speed nozzle表面割炬gouging blowpipe水下割炬under-water cutting blowpipe水下割条electrode for under-water cutting粉剂罐powder dispenser数控切割机NC cutting machine门式切割机flame planer光电跟踪切割机photo-electric tracing cutting火焰切管机pipe flame cutting machine磁轮式气割机gas cutting machine with magnetic wheels六、焊接安全与防护焊接烟尘weld fume焊接发尘量total amount of fumes焊接烟尘浓度weld fume concentration焊接烟尘容限浓度threshold limit values of weld fume (TLV) 焊接发尘速率weld fume emission rate焊接有害气体welding toxic gases/ weld harmful gases标定卫生空气需要量nominal hygienic air requirement焊工尘肺pheumocomsis of welder焊工锰中毒chronic occupational manganese poisoning of welder焊工氟中毒fluorosis of welder焊工金属烟热metal fume fever of welder电光性眼炎eye-flash (arc eye)电光性皮炎electro-photo dermatitis电弧紫外线灼伤ultraviolet ray burn防电击装置voltage reducing device除尘装置dust collection device焊工手套welding gloves护脚welding spats防护鞋shielding shoes文章来源：焊接切割联盟根据网络资料编辑整理。
