•PLC基础概念与原理•西门子PLC硬件组成与选型•西门子PLC编程软件与编程语言•西门子PLC通信网络技术•西门子PLC控制系统设计实践•西门子PLC培训总结与展望PLC基础概念与原理PLC （Programmable Logic Cont…一种数字运算操作的电子系统，专为在工业环境应用而设计的。
要点一要点二发展历程从最初的顺序控制到现在的复杂过程控制，PLC 技术不断发展，功能日益强大。
PLC 定义及发展历程工作原理与特点工作原理PLC采用循环扫描的工作方式，执行用户程序并控制输出。
特点可靠性高、编程方便、组态灵活、安装方便、运行速度快等。
应用领域及市场需求应用领域PLC广泛应用于工业自动化领域，如机械制造、电力、交通、环保等。
市场需求随着工业自动化程度的提高，对PLC的性能和功能要求也越来越高。
0102 03S7-200 SMART系列经济型PLC，适用于小型自动化项目。
S7-300/400系列中高端PLC，适用于中大型自动化项目，具有强大的通信和扩展能力。
S7-1200/1500系列高端PLC，采用模块化设计，支持多种编程语言和通信协议，适用于复杂的自动化控制系统。
西门子PLC产品系列介绍西门子PLC硬件组成与选型硬件基本构成CPU模块电源模块输入模块输出模块通信模块负责执行程序指令，处理数据，控制输入输出等操作。
为PLC系统提供稳定可靠的直流电源。
将外部信号转换为PLC内部可识别的数字信号。
将PLC内部数字信号转换为外部设备可识别的控制信号。
实现PLC与其他设备或系统之间的数据通信。
电源模块功能具备过压、欠压、短路等保护功能，确保PLC 系统稳定运行。
CPU 模块功能具备高速处理能力，支持多种编程语言，内置丰富的指令集和函数库，提供实时时钟、中断处理等功能。
输入模块功能支持多种输入信号类型，如开关量、模拟量等，具备滤波、隔离等功能，提高信号抗干扰能力。
通信模块功能支持多种通信协议和接口类型，实现与上位机、触摸屏、变频器等设备的通信连接。
