Subject to reasonable modifications due to technical advances.Copyright Pepperl+Fuchs, Printed in GermanyPepperl+Fuchs Group • T
el.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.comKFD2-SCD-Ex1.LK
1Release date 2006-03-01 15:08Date of issue 2006-03-01122033_ENG.xmlSMART repeaterOutput EEx ia IIC
Safe area or hazardous area, zone 2Hazardous area
Power supplyInputgreenred
SMART communicatorSMART communicator
Power Rail2-1+J?
LB/LK2-1+
-+12- 11+9+9+8+8+7-7-250Ω
CompositionConnection
•1-channel•Output EEx ia IIC•Device installation permissible in zone 2•Lead breakage (LB) monitoring and short-circuit (SC) monitoring•Suitable for HART communication (galvanically isolated)•EMC acc. to NAMUR NE 21•Up toSIL2acc.toIEC61508KFD2-SCD-Ex1.LKA 4mA...20mA current is transferred from the safe area to the hazardous area. Digital signals can be superimposed on the analogue values in either the hazardous area or the safe area. A bidirectional communication between a SMART-(HART) device in the field and the corresponding SMART-communicator in the safe area is possible. When the current source has a low AC impedance, it may be important to connect it to terminals 7- and 9+ in order to obtain a fault free HART transmission. In order to facilitate the connection of a hand held terminal to the circuit, the KFD2-SCD-Ex1.LK is usually delivered with KFD-STP-** device connectors. The applicable test jacks are integrated into these connectors.Lead monitoring, input characteristicsNormal operation:100 Ω ... 700 Ω field currentLead short circuit:up to < 50 Ω loadLead breakage:up to > 2 kΩ load when ION = 20 mAThe range above a load of 700Ω is not designated for transferring signals. In case of short circuit or lead breakage in the field circuit the input resistance is increased to > 100kΩ. The field current decreases to < 1mA, and the red LED flashes. During normal operation the DC input voltage is lower than 4V (200Ω at 20mA respectively). The AC input impedance corresponds to the output impedance of the unit.Function2Subject to reasonable modifications due to technical advances.Copyright Pepperl+Fuchs, Printed in GermanyPepperl+Fuchs Group • T
el.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.comKFD2-SCD-Ex1.LKTechnical data
Release date 2006-03-01 15:08Date of issue 2006-03-01122033_ENG.xmlSupplyConnection Power Rail or terminals 11+, 12-Rated voltage 20 ... 35 V DCRipple within the supply tolerancePower loss 1.3 WPower consumption 1.3 WInputConnection terminals 7-, 8+Voltage drop Udapprox. 4 V or internal resistance 200 Ω at 20 mAInput resistance > 100 kΩ, when wiring resistance in the field < 50 Ω or > 800 Ω at 20 mACurrent 4 ... 20 mA limited to approx. 25 mAOutputConnection terminals 1+, 2-Current 4 ... 20 mAVoltage ≥ 14 V at 20 mALoad 100 ... 700 ΩTransfer characteristicsDeviation After calibration at 293 K (20 °C): ≤ ± 0.1 % incl. non-linearity and hysteresisInfluence of ambient temperature ≤ ± 20 p.p.m/KRise time < 100 µs (bounce from 10 ... 90 %)Electrical isolationInput/power supply basic insulation acc. to EN 50178, rated insulation voltage of 50 V ACDirective conformityElectromagnetic compatibility Directive 89/336/EC EN 50081-2, EN 50082-2ConformityInsulation coordination EN 50178Electrical isolation EN 50178Electromagnetic compatibility NE 21Protection degree IEC 60529Ambient conditionsAmbient temperature -20 ... 60 °C (253 ... 333 K)Mechanical specificationsProtection degree IP20Mass approx. 100 gDimensions 20 x 107 x 115 mm (0.8 x 4.2 x 4.5 in)Data for application in conjunction with hazardous areasEC-Type Examination Certificate BAS 00 ATEX 7215 , for additional certificates see www.pepperl-fuchs.comGroup, category, type of protection ¬ II (1) G D [EEx ia] IIC (-20 °C ≤ Tamb ≤ 60 °C)VoltageU0 25.2 VCurrentI0 93 mAPowerP0 585 mWSupply Safety maximum voltage Um250 V rms (Attention! The rated voltage can be lower.)quipment VoltageUo 25.5 VCurrent Io 93 mAPowerP0 0.58 WInternal capacitanceCi 0 µFInternal inductanceLi 0 mHPermissible connection values [EEx ia] Explosion group IIAIIBIICExternal capacitance 2.9 µF 0.82 µF 0.107 µFExternal inductance 36.02 mH 17.72 mH 4.3 mHInput Safety maximum voltage Um250 V rms (Attention! The rated voltage can be lower.)Statement of conformity TÜV 99 ATEX 1499 X , observe statement of conformityGroup, category, type of protection, temperature classification ¬ II 3 G EEx nA II T4Electrical isolation Input/output safe electrical isolation acc. to EN 50020, voltage peak value 375 VOutput/power supply safe electrical isolation acc. to EN 50020, voltage peak value 375 VDirective conformity 3Subject to reasonable modifications due to technical advances.Copyright Pepperl+Fuchs, Printed in GermanyPepperl+Fuchs Group • T
