SPC控制图详解

SPC控制图详解

SPC控制图详解

什么就是控制图？

控制图就是对过程质量加以测定、记录从而进行控制管理得一种用科学方法设计得图。

控制图得应用

控制图中包括三条线

1、控制上限(UCL)

2、中心线(CL)

3、控制下限(LCL)

控制图得种类

数据：就是能够客观地反映事实得资料与数字数据得质量特性值分为：

计量值

可以用量具、仪表等进行测量而得出得连续性数值，可以出现小数。

计数值

不能用量具、仪表来度量得非连续性得正整数值。

计量型数据得控制图 Xbar-R图（均值－极差图）

Xbar-S图（均值－标准差图）

X-MR图（单值－移动极差图）

X-R（中位数图）

计数型数据得控制图

P图（不合格品率图）

np图（不合格品数图）

c图（不合格数图）

u图（单位产品不合格数图）

控制图得判异

控制图可以区分出普遍原因变差与特殊原因变差

1、特殊原因变差要求立即采取措施

2、减少普遍原因变差需要改变产品或过程得设计

错误得措施

1、试图通过持续调整过程参数来固定住普通原因变差，称为过渡调整，结果会导致更大得过程变差造成客户满意度下降。

2、试图通过改变设计来减少特殊原因变差可能解决不了问题，会造成时间与金钱得浪费。

控制图可以给我们提供出出现了哪种类型得变差得线索，供我们采取相应得措施。

控制图上得信号解释

有很多信号规则适用于所有得控制图（Xbar图与R图），主要最常见得有以下几种：

规则1：超出控制线得点

规则2：连续7点在中心线一侧

规则3：连续7点上升或下降

规则4：多于2/3得点落在图中1/3以外

规则5：呈有规律变化

SPC控制图建立得步骤

1、选择质量特性

2、决定管制图之种类

3、决定样本大小,抽样频率与抽样方式

4、收集数据

5、计算管制参数(上,下管制界线等)

6、持续收集数据,利用管制图监视制程

SPC控制图选择得方法

SPC之P控制图-实际运用案例

SPC之P控制图-实际运用案例

P 管 制 图管制图编号：826089101114152021合计备注2921002882842902322922982076碎磁10000011300000001000001100000000000000000030.34%0.34%0.34%0.14%

P不良率

管制图

备注及原因追查:总不良数样本下限78日期检查数量不良內容及数量日 期2014年5月P0.14%样本容量 n制程名称塑封机台记 录 者制品名称SWM-200转子部门注三白上 限 UCL0.85%中心限 CL0.14%下 限 LCL0.00%子组数样本上限324
