中兴DWDM系统完成长距离光传输工程随着全球经济一体化进程的加快，通讯业务量快速增长，在全球范围内都需要大容量的传输系统搭建通信的基础平台，而其主要的技术手段就是采用光通信技术。
目前，光通信发展方向主要表现为两个方面。
一方面光纤通信系统一直在追求单波长传输速率更高（从2.5Gbit/s到现在的10Gbit/s，正向40Gbit/s 发展）、波长数更多（从单波到8波到现在的40波，正向160波以上发展）、无电中继距离更长；另一方面未来的光传送网将向更灵活、智能化方向随着全球经济一体化进程的加快，通讯业务量快速增长，在全球范围内都需要大容量的传输系统搭建通信的基础平台，而其主要的技术手段就是采用光通信技术。
目前，光通信发展方向主要表现为两个方面。
一方面光纤通信系统一直在追求单波长传输速率更高（从2.5Gbit/s到现在的10Gbit/s，正向40Gbit/s 发展）、波长数更多（从单波到8波到现在的40波，正向160波以上发展）、无电中继距离更长；另一方面未来的光传送网将向更灵活、智能化方向发展，经济有效、业务透明、频带可管理将成为其特征。
而对于WDM技术而言，前一个方向更是发展的重点。
大容量超长距离光传输系统可简化骨干网的结构，便于业务调度和管理，并可大大减少昂贵的电再生器件的使用，从而减少网络投资、降低运营费用，节省占用空间和功率需求，并易于升级，是光网络的基本支撑技术。
所以无电中继传输距离更长、波长数更多、单通道速率更高的大容量超长距离光传输系统是国内外研究一大热点。
在这一领域，中兴通讯近期取得了重要进展，在中国新疆建设复用段总长度1104km的WDM大容量超长距离光传输示范工程（如图1所示），通过了国家863专家组的现场验收并已投入运营。
该工程为中国国内某主流运营商的省级干线工程，总容量为40×10Gbit/s（厂验时配置为160×10Gbit/s），采用了AFEC （AdvancedForwardErrorCorrection）、ERZ（Electr ic al Return－Zero）、Raman放大器、集中波长监控、功率管理和色散管理等一系列先进、成熟的技术。
