单轴步进控制器PMC1110-03使用说明书

PMC100-3运动控制器操作手册第二版（C++版）•2018三英精控（天津）仪器设备有限公司版权申明三英精控（天津）仪器设备有限公司保留所有权利（以下简称三英精控）保留在不事先通知的情况下，修改本手册中的产品和产品规格等文件的权利。

三英精控不承担由于使用本手册或本产品不当，所造成直接的、间接的、附带的或相应产生的损失或责任。

三英精控具有本产品及其软件的专利权、版权和其它知识产权。

未经授权，不得直接或间接地复制、制造、加工、使用本产品及其相关部分。

目录一、概述： (3)二、硬件说明： (4)三、PMC100-3编译器介绍： (7)四、命令介绍： (10)五、附录：样例； (13)一、概述：敬爱的用户：你好！非常感谢您使用PMC100-3步进电机控制器，和国内外同类高档控制器相比，先进的特点如下：1.1、用户编程方便，使用PMC100-3控制器，您不必再为修改程序发愁。

该控制器提供独立的编程环境，不必借助任何工具，您可以随时对程序进行修改或重写。

她的指令设置合理并简单，符合人们的思维习惯，不会在指令的熟悉上浪费您宝贵的时间。

1.2、可控制三轴步进电机。

PMC100-3系列控制器具有驱动最多三轴步进电机的能力，各轴分别带有两个硬件限位点和一个零位。

1.3、显示方式为真彩TFT液晶屏和触摸屏。

1.4、通用2个输入、2个输出点，实现逻辑控制。

1.5、支持控制器计算机下载。

1.6、支持指令控制。

1.7、支持PC机直接控制。

二、硬件说明：2.1、硬件说明1、适用于步进电机的各种场合控制应用。

2、提供运算指令，可进行复杂控制。

3、2个通用输入点、2个输出点，实现逻辑控制。

4、每轴2个硬件限位点。

5、每轴1个零位控制点。

6、默认8细分步进控制，最大256细分。

2.2、性能指标;1、输出脉冲频率：单轴控制400－30000Hz任意值可设定。

2、1K用户程序空间。

3、当前坐标实时显示。

2.3机箱正视图：1、采用2.8寸TFT液晶屏，触摸屏。

单轴运动控制器操作手册目录一与外部驱动器及IO（输入输出）接线图 (4)二用户管理操作 (5)三系统参数设置 (6)四IO（输入输出）设置 (7)五系统自检操作 (10)六手动操作 (12)七编程操作 (14)八自动执行 (17)九指令详解 (18)十电子齿轮计算及公式 (20)十一编程案例 (23)十二常见问题及处理 (28)一与外部驱动器及IO（输入输出）接线图1.控制器与步进驱动器或伺服驱动器的连接（红色线为1号线）2.IO（外部开关及继电器）的接线图（红色线为1号线）注：因输入采用低电平有效，若选用光电开关，则需要选择NPN型。

二用户管理操作注意：所有重要参数只有用户登录以后才可修改保存。

防止他人随意更改参数，影响加工质量。

从主画面进入参数设置，并进入用户管理，进行密码输入。

输入用户密码，按确认键，若输入正确，则提示“用户登陆成功”，否则提示“密码错误，请重新输入”。

用户密码出厂值为“123456”。

用户登录成功后，则可进行加工参数的修改保存。

否则加工参数不可修改保存。

若进入此界面后，提示“用户已登录！”，表示用户登录成功。

然后直接按退出按键，对系统参数及IO设置进行编辑，编辑完成，再次进入用户管理，并选择用户退出，按确认键，当前参数设置里的内容全部不可更改。

若需要修改，再次进入用户管理进行登录。

注：用户密码可以修改。

但是必须要记忆下新设的密码，否则加工参数将不可修改保存。

三系统参数设置从主界面的参数设置里进入系统参数，通过移动光标，对光标所在位置进行数据修改。

共分两屏，按“上页”“下页”键切换。

控制参数修改完毕可进入速度参数界面进行速度的参数修改，共2屏，修改方式同上。

修改完成后，按参数保存进入参数保存界面，按确认键对当前修改完成的数据进行保存。

若保存成功则提示“参数保存成功”。

注：加工过程中禁止进行参数保存。

按空格键，可将当前参数值清零。

当设定的速度值小于启动速度时，则速度值为启动速度。
