混合高斯背景建模matlab代码

clear all

% source = aviread('C:\Video\Source\traffic\san_fran_traffic_30sec_QVGA');

source = mmreader('SampleVideo.avi');

frameQYT=get(source,'NumberOfFrames');

% ----------------------- frame size variables -----------------------

fr = read(source,1); % 读取第一帧作为背景

fr_bw = rgb2gray(fr); % 将背景转换为灰度图像

fr_size = size(fr); %取帧大小

width = fr_size(2);

height = fr_size(1);

fg = zeros(height, width);

bg_bw = zeros(height, width);

% --------------------- mog variables -----------------------------------

C = 4; % 组成混合高斯的单高斯数目(一般3-5)

M = 0; % 组成背景的数目

D = 2.5; % 阈值（一般2.5个标准差）

alpha = 0.01; % learning rate 学习率决定更新速度(between 0 and 1) (from paper 0.01)

thresh = 0.75; % foreground threshold 前景阈值(0.25 or 0.75 in paper)

sd_init = 6; % initial standard deviation 初始化标准差(for new components) var = 36 in paper

w = zeros(height,width,C); % initialize weights array 初始化权值数组

mean = zeros(height,width,C); % pixel means 像素均值

sd = zeros(height,width,C); % pixel standard deviations 像素标准差

u_diff = zeros(height,width,C); % difference of each pixel from mean 与均值的差p = alpha/(1/C); % initial p variable 参数学习率(used to update mean and sd)

rank = zeros(1,C); % rank of components (w/sd)

% ------initialize component means and weights 初始化均值和权值----------

pixel_depth = 8; % 8-bit resolution 像素深度为8位

pixel_range = 2^pixel_depth -1; % pixel range 像素范围2的7次方0—255（# of possible values)

for i=1:height

for j=1:width

for k=1:C

mean(i,j,k) = rand*pixel_range; % means random (0-255之间的随机数)

w(i,j,k) = 1/C; % weights uniformly dist

sd(i,j,k) = sd_init; % initialize to sd_init

end

end

end

%----- process frames -处理帧--，这里去第八帧

n = 8;

fr = read(source,n); % read in frame 读取帧

fr_bw = rgb2gray(fr); % convert frame to grayscale 转换为灰度图像

% calculate difference of pixel values from mean 计算像素差值

for m=1:C

u_diff(:,:,m) = abs(double(fr_bw) - double(mean(:,:,m)));

end

% update gaussian components for each pixel 更新每个像素的背景模型

for i=1:height

for j=1:width

match = 0;

for k=1:C

if (abs(u_diff(i,j,k)) <= D*sd(i,j,k)) % pixel matches component像素匹配了模型

match = 1; % variable to signal component match 设置匹配记号

% update weights, mean, sd, p 更新权值，均值，标准差和参数学习率

w(i,j,k) = (1-alpha)*w(i,j,k) + alpha;

p = alpha/w(i,j,k);

mean(i,j,k) = (1-p)*mean(i,j,k) + p*double(fr_bw(i,j));

sd(i,j,k) = sqrt((1-p)*(sd(i,j,k)^2) + p*((double(fr_bw(i,j)) - mean(i,j,k)))^2);

else % pixel doesn't match component 几个模型中都没有匹配的

w(i,j,k) = (1-alpha)*w(i,j,k); % weight slighly decreases 权值减小

end

end

bg_bw(i,j)=0;

for k=1:C

bg_bw(i,j) = bg_bw(i,j)+ mean(i,j,k)*w(i,j,k); %更新背景

if(bg_bw(i,j)>thresh)

k=k-1;

M=k;

end%???? 这里有问题，背景权值和大于阈值时，背景建模的数目M取k-1,
