新型高亮度一字线性绿光灯

L11产品规格书产品概述应用环境：室内、户外产品尺寸图（单位：mm）L11线条灯是专为户外景观亮化设计的一款小功率LED 条形产品。

采用航空级6063挤压铝外壳，阻燃塑胶PC端盖，通过高导热耐候PU胶灌封防水；灯条体积小，外观精致；灯条间通过国标定制柔性线缆连接；产品长度、顔色可定制，能适应大曲线或曲面的安装；适用于建筑物立面轮廓勾边，内外表面装饰亮化。

产品特点：★新一代T T L串行技术设计★标准D M X512控制协议★行业领先的无线扣式防拽连接设计★高导热胶全灌封防水设计★户外防雷及静电（E S D）专用防护设计★产品的上盖可选：支持P C透明或乳白弧盖★产品采用独创的隐藏式安装滑块★支持R G B/W电流单独可调（低亮高灰）技术参数产品选型表基 本 参 数 色 彩/灰 度 RGB/W 各256级灰度； 光 源 类 型 3535 /5050 /2835 光 源 数 量48-72pcs/米 (0.25米-1米，长度可以按要求定制)材 质 铝喷涂外壳 / 阳极氧化 + 光学PC 罩寿 命 50,000h 重 量 710g/米 光 电 参 数 工 作 电 压 DC24V最 大 功 率 12-20W/米 RGB 光 强 180cd/米白 光 360cd/米 光 束 角 30° / 45° / 60° / 90° / 120°电 气 等 级 III 类其 它 参 数 工 作 温 度 -20°C to 50°C 储 存 温 度 -40°C to 70°C 防 护 等 级IP66配光曲线规格型号 光源 数量 光源类型 颜色控制类型 DC 工作电压 功率 白色 光强 DA028-48AT 48PCS 3535 RGB/W 单线串行TTL 24V 12W 120cd DA028-48AD 48PCS 3535 RGB/W DMX512 24V 12W 120cd DA028-48XD 48PCS 5050 RGBW DMX512 24V 15W 180cd DA028-48CN 48PCS 3535 2835 W 无控制 24V 12W 240cd DA028-60AT 60PCS 3535 RGB/W 单线串行TTL 24Vz 15W 150cd DA028-60AD 60PCS 3535 RGB/W DMX512 24V 15W 150cd DA028-60XD 60PCS 5050 RGBW DMX512 24V 20W 225cd DA028-60CN 60PCS 3535 2835 W 无控制 24V 15W 300cd DA028-72AT 72PCS 3535 RGB/W 单线串行TTL 24V 18W 180cd DA028-72AD 72PCS 3535 RGB/W DMX512 24V 18W 180cd DA028-72CN72PCS3535 2835W无控制24V18W360cd安装件外观尺寸安装底座尺寸图（单位mm）；固定式安装底座安装方式示意：①安装载体钻孔,装膨胀胶塞：在载体上按灯具安装位置做好记号，并钻孔(建议用6mm钻头）；把膨胀胶塞用锤子敲入钻孔里（注：胶塞不可松动）；②固定灯具安装底座：将灯具安装底座孔位对准膨胀胶塞孔，选用合适的自攻螺丝将灯具安装底座固定到安装载体上；③灯具安装：将灯具对准灯具安装底座，并扣到灯具安装底座上；④灯具加固,完成安装：装好灯具后，从侧下边打两个自攻螺丝将型材上盖与型材安装底座固定在一起，防止型材上盖坠落。

上海磐川光电科技有限公司一字线定位灯（一字激光定位灯）产品说明书一字线定位灯（一字线激光定位灯）型号：PL-66100L专业术语：一字线定位灯又俗称：一字线激光定位灯,一字定位灯,一字划线仪,红光一字线定位仪,一字线光源,一字线光源激光器等产品特点：*半导体激光管芯；*高效透过率光学系统；*智能反馈控制电路；*低功耗，高效能光功率输出；应用领域：广泛引用于工业机械设备标线定位，防伪检测，机械、金属锯床、SMT/电路板的对刀、标线、定位、对齐等技术参数：型号：PL-66100L波长660nm 激励方式电激励输出功率5-200mW 光斑模式一字线形运行方式连续工作激光器供电电压DC3-5V工作电流20-300mA 光学透镜光学镀膜玻璃透镜光束发散度0.1~1mrad 出光张角度10°~135°直线度≥1/5000 线宽≤1.0mm/≤0.5mm 工作温度-10℃~50℃储存温度-40℃~85℃尺寸Φ10-26×30-120mm；（可根据用户定制）使用寿命〉10000hrs激光安全等级ClassⅢa / ClassⅢb产品工业用途：一字线定位灯（一字线激光定位灯）的特点除了激光器的单色性好、相干性好、方向性好以及高亮度之外一字线直度高是其重要优势，可以广泛应用于工业检测、工业机械、数控设备、电动工具、工程施工、建筑装璜、印刷、纺织服装、切割焊接等领域的激光定位、激光标线、激光水平、激光垂准、激光指示仪以及激光娱乐照明等；.方便快捷、直观实用、易于安装、稳定可靠，可以提高工作效率，降低人力和生产时间的成本，提高工作精确度。

（工业应用场合）售后服务产品提供一年质保，三年保修。

使用注意事项1）激光定位灯使用应注意相关的激光使用安全规定，不能直射人眼；2）激光器中半导体激光管属静电敏感器件，应遵守相关的静电防护规定。

测试和使用环境应保证没有静电；3）电源线请勿用力拽拉；4）电源电压不要超过DC 5 V，最好选用激光器专用直流稳压电源供电，“+”（红线）、“−”（黑线）极性绝对不可接反；5）激光器通电时，“+”（红线）、“−”（黑线）极电源线绝对不可短路，以免烧毁激光器；6）自制稳压电源请注意消除浪涌脉冲电压电流，稳压5V或<5V将延长使用寿命，避免在各种浪涌脉冲较大的场合中使用激光器；7）激光器人为损坏或私自拆开激光器后不予保修。

激光划线仪简介及其应用实例姓名马静班级 041151031.激光划线仪的产生研究数控多坐标激光划线仪是“七五”国家重点科技攻关项目和湖北省重点打算项目，由华中理工大学机一系自动化教研室与北京机床研究所、沙市机床工业公司一起承担。

它是光机电一体化高技术高难度的复杂设备，它集国内研究激光器、数控机床、数控系统、激光加工工艺等方面处于领先水平的技术为一体，以解决常规工艺无法解决的三维空间曲面不同材料和外形的壳体零件的高质量切割和大型模具划线达标等技术难题，并可大大提高划线速度和精度、切割切口光洁度和工作效率，保证切割质量。

这种划线仪可在汽车、飞机和模具制造行业普遍应用。

华中理工大学在 1991 年成功研制我国第一台数控五轴联动激光划线切割机，标志着我国在研制数控多坐标激光划线切割机方面已进入国际先进行列。

4 月 28 至 29 日这台激光切割机由国家教委和湖北省科委在沙市一起主持通过了鉴定。

2.激光划线仪的工作原理激光划线仪利用半导体泵浦激光器作为光源，通过一组透镜组合整合后能够发射出高准直度的点状光源，在通过特制棱镜打散后能够形成一条亮度均匀的光线。

由于采纳特殊设计的棱镜扩散光线，有效幸免了采纳一般柱镜扩散光线后产生光线两头光强弱中间光强的缺点，棱镜在扩散光线后能够使光线两头和中间的亮度相同(肉眼分辨)，经功率测试结果分析得出两头光强和中间光强误差在 3之内，肉眼无法分辨出亮度差。

能够在利用距离40 米的位置清楚分辨出光线，有效的解决了人工划线不直的缺点，并加大了工作强度。

综上所述，激光划线仪包括三个要紧部份: 一.半导体泵浦激光器，包括二极管、发光晶体和高温爱惜装置。

二.激光器电源，为激光器提供稳固的恒流供电。

三.光学透镜组合，把激光点扩散成一条均匀的细线。

3.激光划线的益处与优势激光划线仪全新的整体式系统设计，提高了照射强度和利用寿命，使之能够加倍适应于恶劣环境和工业环境下的视觉及机械视觉应用，全新设计激光及成像系统，能够有效幸免工业环境下的震动等产生的阻碍。

绿色激光一字灯的参数波长：532nm管芯功率：0~200mw工作电流：0~2000mA工作电压：5V 12V 24V 36V外形尺寸：Φ16×55mm Φ16×80mm Φ22×85mm Φ26×110mm（可选择）光束发散度：0.3～1.5mrad出光张角：10 º～135º光线直径：≤0.5mm ＠0.5m；≤1.0mm ＠3.0m；≤1.5mm ＠6.0m；直线度：≤1.0mm ＠3.0m光学透镜：光学镀膜玻璃或塑胶透镜工作温度：－10～75℃储存温度：－40～85℃工作介质：半导体等级：Ⅲb可选配：专用支架、电源主要技术指标（CYH25煤矿用氧气测定器）1、测量范围：（0.0～25.0）%O2；2、基本误差：不超过±3.0% ；3、报警点：（1）在（18.0 ～20.0）%O2范围内任意设定，出厂默认设置为18.0%O2，报警误差应不大于0.3% O2。

（2）报警声级强度应不小于75dB（A）；（3）报警光信号应能在黑暗中20m处清晰可见，颜色为红色。

4、响应时间：不大于20s。

5、分辨率：0.1%O2。

6、电源：测定器采用YT-083436-1000mAh锰酸锂电池外串1.4Ω/16W限流电阻后用环氧树脂封装，构成本安电池组件。

额定电压Ue：3.7V，最高输出电压Uo：4.2V，最大输出电流Io：2.3A。

.电池组具有过充过放和短路保护功能，当线路出现短路故障时电池组串接的限流电阻和温度保护PTC能使短路电流的热量释放并随着温度升高PTC阻值增大从而使短路电流减小到零,电路故障排除后电池又自动恢复供电。

DODGE DURANGO P O L I C E L I G H T I N G PA C K A G EA comprehensive guide to Whelen’s lighting and warning products.LINSV2™ V-Series ™Utilizing multiple planes of light in one lighthead, LINSV2 V-Series lightheads are two-in-one 180° warning and puddle lights for under surface mounting. Includes glamour cap.Mirror-Beam ™ & Mirror-Beam ION ™ V-SeriesCustom molded Black housings fit over the vehicle’s existing mirror glamour caps and feature ION or ION V-Series Super-LED ® lightheads.Vertex ™ SeriesVertex Series lightheads offer three different optical light output models:omni-directional, side emitter, and directional. These small lightheads install easily with a 1” hole and utilize an in-line lamp driver.LINV2™ V-SeriesUtilizing multiple planes of light in one lighthead, LINV2 V-Series lightheads are two-in-one 180° warning and puddle lights for surface mounting. Includes Black flange.Micron ™ SeriesCompact and durable Micron series lightheads are available in single or split colors. Models are available in surface or stud mount.ION SeriesEngineered for optimal versatility, ION Series lightheads provide high intensitywarning or illumination. Designed to mount in many applications, ION lightheads are available in directional, wide-angle, DUO ™ (two color interleaved), or TRIO ™ (three color interleaved) models. Models are available in surface or universal mount.ION V-SeriesUtilizing multiple planes of light in one lighthead, ION V-Series lightheads are available in three-in-one combination or single color warning models. Models are available in surface or universal mount.ION T-Series ™The ION T-Series features Linear Super-LED ® technology and a sleek and low profile design, with a depth of only 1.50”. ION T-Series lightheads are available in SOLO ™ (single color), split, or DUO models.ION Mini T-Series ™Introducing the smallest ION yet. The ION Mini T-Series features Linear Super-LED technology and a sleek and low profile design, with a depth of only .50” and a length of only 3.34”. ION Mini T-Series lightheads are available in SOLO or DUO models.M2 SeriesWith a unique lens shape and patented Linear-LED ® designed reflector assembly, the M2 Series is completely illuminated for unmatched high intensity warning and low current consumption. The M2 Series is available in standard or wide-angle models.V23™ V-SeriesUtilizing multiple planes of light in one lighthead, V23 V-Series lightheads are three-in-one 180° wide-angle warning, illumination, and puddle light.New! Arges ™Arges is Whelen’s new remote spotlight designed with officer safety in mind. Its small footprint can help reduce blind spots while driving and its all-new collision-safe control head eliminates the need for an internal handle. Arges works seamlessly with CenCom Core ™ and features revolutionary control, with 360° of continuous rotation and a 180° tilt range.LIGHTHEADSWARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit/regulatoryION™ License Plate BracketUniversal license plate bracket for two ION lightheads.ION T-Series™ License Plate BracketUniversal license plate bracket for two ION T-Series lightheads.ION Mini T-Series™ License Plate BracketUniversal license plate bracket for two ION Mini T-Series lightheads. LICENSE PLATE BRACKETSDASH & DECKLIGHT ARRA YSTracer™ SeriesEngineered to increase vehicle visibility, the Tracer Series utilizes sleek vehicle specific mounting bracketsconform to vehicle rocker panels for maximum versatility. The durable clamshell design allows for easyreconfiguration and serviceability. Tracer now includes a Traffic-Advisor™ in 4-6 lamp versions. The newlydesigned, fully encapsulated control module is designed for exterior or interior installation and featurestwo additional inputs for Traffic Advisor functions. The Tracer Series is available in SOLO, DUO,or TRIO models.Avenger® II SeriesThe Avenger II Series features combination Linear/TIR optics for high-intensity warning and illuminationand a smaller profile to maximize space for optimal versatility. The Avenger II is available in SOLO™, DUO™,or TRIO™models.WARNING: These products may contain chemicals known to the State of California to cause cancerand birth defects or other reproductive harm. For more information, visit/regulatoryLIGHTBARS3Liberty™II Series Redesigned and reinvented for exactly what your fleet needs, the Liberty II features Super-LED®optics and builds on the Liberty’s reputation for excellent reliability and performance. Increase clarity with Whelen’sall-new, patent pending Proclera®Silicone Optics (available in take-down lights). The Liberty II Series is available in SOLO ™, DUO+™, or TRIO ™ models with WeCan ®, WeCanX ™, or low current technology.Legacy ® SeriesThe low-profile Legacy Series provides 360° of high-intensity light output. Engineered for optimal durability with a UNI-DOME construction and aluminum top, the Legacy Series is available in SOLO, DUO+, or TRIO models with WeCan, WeCanX, or low current technology.Inner Edge ®FST ™SeriesThe newly designed, low-profile Inner Edge FST Series mounts to visor anchor points and better utilizes vehicle contours, providing higher visibility and a custom fit. Models feature BroadBand Blue ™. BroadBand Blue delivers a higher intensity, creates a larger optical image, and produces a more consistent color, all while being easier on the eyes—especially at night. Increase clarity with Whelen’s all-new, patent pending Proclera Silicone Optics. The Inner Edge FST Series is available in SOLO, DUO, or TRIO models with WeCanX technology.Mounting KitsMKEZ85, and MKAJ85, straps mount 52”-58” lightbars CMK85 straps mount 48” Cenator lightbarsCenator ® SeriesIntroducing the innovative and economic Cenator Series. Featuring Linear Super-LED optics and an all-new low-profile design, the Cenator Series is engineered for versatility and convenience. Laser etched opaque colored domes provide full customization. A multitude of options areavailable, including a center speaker and lighted signs. The Cenator Series is available in SOLO, DUO ™, or TRIO models with WeCan, WeCanX, or high current technology.Freedom ® IV SeriesEngineered for high intensity warning, the Freedom IV Series features Linear Super-LED optics, DYAD ™ two level technology, and 360° ofcontiguous light. Multiple options are available for full customization. The Freedom IV is available with WeCan, WeCanX, or low current technology.Inner Edge RST ™ SeriesThe newly designed, low-profile Inner Edge RST Series better utilizes vehicle contours by mounting to the rear deck of sedans and the rear headliner of SUVs and pickup trucks, providing higher visibility and a custom fit. Models feature BroadBand Blue. BroadBand Blue delivers a higher intensity, creates a larger optical image, and produces a more consistent color, all while being easier on the eyes—especially at night. Increase clarity with Whelen’s all-new, patent pending Proclera Silicone Optics. The Inner Edge RST Series is available in SOLO, DUO, or TRIO models with WeCanX technology.Outer Edge ® Rear PillarNewly designed featuring six Micron ™ or ION ™ lightheads and an all new service loop for easy reconfiguration, Whelen’s durable Outer Edge rear lights are engineered for weather and vibration resistance. The Outer Edge Rear Pillar is available in WeCan or WeCanX capable or low current models.WARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit /regulatory10CONTROL SYSTEMSWARNING: These products may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit /regulatoryNew! CenCom Core ™With the greatest configurability, speed, and expansion yet, CenCom Core is a system created to enhance officer safety with advanced automation and remote connectivity. Every aspect of Core is engineered for performance and designed for vast configuration, allowing for access to every connector and fuse from the top of the box. Core features WeCanX ™, our newest CAN-based communication system. Providing true system synchronization, greater speed capabilities, expanded peripheral add-ons, and full support of diagnostics, WeCanX is designed for optimal situational awareness programming.CanTrol ® WCThe best way to connect you with your vehicle and the world around you is CanTrol—intelligent technology that makes every day on the job safer, whether you’re inside or outside your vehicle. CanTrol features situation based integration and conditional programming. Models are now available with the CANport ™ OBDII Interface, a simple plug-in connection to your vehicle. Using the CANport, CAN bus signals are easily applied to automate warning system functions. (Only available through authorized CanTrol distributors)CenCom Carbide ™CenCom Carbide features a newly designed control head and all new configuration software, both engineered to help maintain situational awareness of the officer. Numerous innovative features and optional expansion modules make Carbide a convenient, single box programming solution. Models are now available with the CANport ™ OBDII Interface, a simple plug-in connection to your vehicle. Using the CANport, CAN bus signals are easily applied to automate warning system functions.HHS3200 & HHS4200Whelen’s innovative HHS Series features standard switching and a completely redesigned molded amplifier housing, providing excellent durability. HHS3200 Series models arecompatible with low current or high current products, or any light with a built-in flasher. HHS4200 Series models includes a WeCan ® port that supports the Inner Edge ® FST ™ and RST ™ Series, WeCan lightbars, or a WeCan external amplifier.CONTROL HEADSCANCTL5Handheld combination microphone and controller, 5 position progressive light/siren control, 9 push-buttons,and microphone extension cableCANCTL63 section control head with a4 position slide switch, 8push-buttons, 3 Traffic Advisor ™ switches, 7 position rotary knob, manual airhorn, microphone, and microphone extension cable CANCTL73 section control head with a4 position slide switch, 18 push-buttons, 3 Traffic Advisor switches, microphone, and microphone extension cableNew! CCTL63 section control head with a4 position slide switch, 13 push buttons, 7 position rotary knob, microphone, and microphone extension cableNew! CCTL73 section control head with a4 position slide switch, 21 push buttons, microphone, and microphone extension cableErgonomically designed for situational awareness of the officer, various control heads are compatible with Whelen systems. Completely configurable by the user, these control heads are designed with features such as tick marks, raised surfaces, and recessed areas for ease of use, allowing officers to focus on the road.SIRENS & SPEAKERSWARNING: These products may contain chemicals known to the State of California to cause cancerand birth defects or other reproductive harm. For more information, visit/regulatorySA315P Siren SpeakerThe SA315P is a multi-port, 100 watt speaker with a nylon compositehousing that easily installs to the radiator cross member to deliver powerful traffic clearing capability.New! Howler™ Siren & SpeakerAdding a layer of warning for intersections and high risk areas when used with your 100/200 watt siren amplifier, Howler provides deep tones to penetrate other vehicles, alerting drivers and pedestrians of your approach. Available with WeCanX™ technology.295SLSA6 Hands-Free Electronic SirenEngineered for under-dash or console mounting, the compact 295SLSA6 Series is a siren and light controller with a hard-wired or plug-in noise cancelling microphone. Easily change functions with nine individually programmable switches for full customization.295SSA & 295SDA Siren SeriesNow available with a single or dual amplifier and two control head options, the economic 295SSA and 295SDA remote sirens are designed for powerful trafficclearing capability and ease of operation.MODELSand birth defects or other reproductive harm. For more information, visitENGINEERING COMPANY, INC.51 Winthrop Road, Chester, CT 06412-0684P O L I C E L I G H T I N G PA C K A G EDODGE DURANGOWhelen Engineering reserves the right to upgrade and improve products without notice.NASCAR® is the registered trademark of the National Association for Stock Car Auto Racing, Inc.© 2020 Whelen Engineering Company, Inc.Printed in the U.S.A. Form No. 13313D - 01/17/2020W h e l e n E N GISO 9001 Registered QMS。

IRIS EMERGENCY LIGHTInstallation Instructions Montageanleitung Montážní návodMonteringsvejledning Paigaldusjuhend AsennusohjeNotice de montage Szerelési útmutatóUputstvo za montažu Montagehandleiding Instructiuni de montaj EN DE CZ DK EE FI FR HU HR NL RO Istuzioni di montaggio Montavimo Instrukcijos Instalacijas instrukcija Monteringsanvisning Instrukcja montażu Installationsanvisning Инструкция по монтажуInstrukcija za instalaciju Montážny návod Navodilo za montažo 安装说明书IT LT LV NO PL SE RU SRB SK SLO CNIRIS EMERGENCY LIGHTSelf-testThe emergency kits carry out self-tests automatically to ensure its functionality.The self-test includes 3 types of tests:Initial test-As soon as mains supply is connected, the emergency kit will carry out a 5-seconds functional test automatically.In case of battery failure, LED indicator will turn flashing red; In case of LED light source failure, LED indicator will turn permanent red. Otherwise, the charge mode will start.Functional test- Refers to charging, discharging and the functioning of load.- Carry out for 10 seconds automatically every 30 calendar days.Duration test- Refers to the test of batteries capacity.- Carry out every 180 calendar days.Rest modeRest mode can be initiated during emergency mode by pressing test switch longer than 3 seconds.The rest mode will be exited automatically after reconnect AC mains.Test switch functionality-Press and hold the test switch by less than 5 seconds to perform an emergency function test, as long as the test switch is activated.-Press and hold the switch for more than 15 seconds, and it will return to the factory setting (the self-test time returns to the starting time).-Press and hold the test switch >10S in the fault status to eliminate the fault display.Please noteIf mains supply is off during self-test period, emergency conversion module would terminate self-test immediately and go into emergency mode.Self-test is under the regulation of EN62034.Yearly manual test will have no impact on battery life.。
