1文档概述
文档变更历史
2详细功能描述
●选择屏幕：
ZSD200单证发货平台里，增加一个按钮或一个菜单，叫：转出对海关文件。

输出文件模板：盛基家居结汇发票.
xlsx
●数据展示列如下：
字段和逻辑：
录入字段描述表-字段取数逻辑SUNJOY
INVOICE NO.:
VBAK-ZZFPH
INVOICE DATE: VBAK-ZZSWFM
TERMS OF
SALE:
VBKD-INCO1+VBAK-ZCKGK
PO NO: VBKD-BSTKD SO1的客户PO号
CONTRACT NO. EKPO-EBELN 当VBAP-VBELN=VBEP-VBELN，取出VBAP-VBELN(销售订单
号)，VBEP-POSNR(销售订单行项目)和VBEP-BANFN（请购单号）
和VBEP-BNFPO(请购单行项目)
当VBEP-BANFN=EKPO-BANFN AND
VBEP-BNFPO=EKPO-BNFPO
取出EKPO-EBELN, (采购订单)
xxxx家居结汇发票
3技术说明
3.1程序逻辑：
1，制单人显示中文
取值逻辑：取ADRP-NAME_LAST+ADRP-NAME_FIRST
根据LIKP-ERNAM= USR21-BNAME 取出USR21-PERSNUMBER
AND USR21-PERSNUMBER =ADRP- PERSNUMBER
3.2自定义的表/结构：
无
确认签字。
