电压计/计时器Hobbs 公司的电压计/计时器将两个重要仪表的功能部件组合在一个坚实的密封外壳内Hobbs 的伏特计小时表精确地监控蓄电池电力系统的状态并同时测定它们所装设备经过的总运行时间使用过程中在微处理器控制下交替显示电压(15秒)和总工作时间(1秒)耐高冲击力的聚碳酸酯外壳经密封后可防灰尘和湿气可提供各种仪表前盖和安装结构Hobbs 伏特计/小时表是各种应用的理想选择技术规格:电压范围:7至19VDC伏特计精度: ±0.1 VDC 小时表精度: ±200 ppm ±.02% 电流消耗: 在12VDC 时为8mA 接线端子: 1/4”插片 外壳材料: 聚碳酸酯 温度范围:-40°C 至+85°C特 点:双功能 数字读出以小时和伏特表示永久性存储器标准 结构紧凑直径2孔瞬时电压保护: 电负载电感电磁干扰和反极性安装孔直接替代现有的计时表应用场合:草坪和花园 小型发动机 发电机 租赁设备 商品草坪的维护 维修部门2SUNSTAR传感与控制/TEL:0755-********FAX:0755-********E-MAIL:**************商斯达公司是美国公司中国区一级代理商，长期致力于世界先进的传感和控制技术的推广及应用，专业代理推广世界著名品牌 的传感及控制元件，为客户提供最优的技术解决方案。
如今, 商斯达公司在中国已成为公司最专业的代理公司。
我们的客户涵盖了家用电器、医疗设备、马达控制、工业自控、仪器仪表、办公自动化、环境监控、电源保护、金融器具、商业机器等各个领域。
我们的目标是帮助客户提高产品质量、降低生产成本、增强市场竞争力，从而达到互利增长！我们奉行双赢的原则，即与我们的客户一起成长；同时，我们致力于了解客户的需求，加强与客户的沟通，降低产品的综合成本，便利客户与我们的合作，从而提高双方的生产率。
商斯达公司是以通信、数据网络、有线电视、电力自动化、工业自控、仪器仪表、医疗设备、汽车电子、金融电子、移动终端、信息电子、办公自动化设备、消费电子、军工应用等行业市场为服务对象的专业代理公司，致力于将世界先进传感科技和光通信技术引进到中国，为客户提供包括新产品推介、快速样品提供、及时库存、应用支持、方案设计、售后及物流等方面的专业服务。
SS490SERIESLinear Hall-effect Sensor ICsDESCRIPTIONThe SS490 Series are small, versatile, linear Hall-effect devices that are operated by the magnetic field from a permanent magnet or an electromagnet. The ratiometric output voltage is set by the supply voltage and varies in proportion to the strength of the magnetic field. The integrated circuitry provides increased temperature stability and sensitivity. Laser-trimmed, thin film resistors provide high accuracy (null to ±%, sensitivity up to ±3%) and temperature compensation.They respond to either positive or negative Gauss, monitoring either or both magnetic poles. The quad Hall sensing element minimizes the effects of mechanical or thermal stress on the output. The positive temperature coefficient of the sensitivity (+0.02%/°C typical) helps compensate for the negative temperature coefficients of low-cost magnets, providing a robust design over a wide temperature range. Rail-to-rail operation (over full voltage range) provides a more usable signal for higher accuracy. These products have an operating temperature range of -40°C to 150°C [-40°F to 302°F], appropriate for industrial and automotive environments.PORTFOLIOHoneywell offers a variety of linear Hall-effect sensor ICsfor potential use in many applications. To view the entire product portfolio, click here.005843Issue 4FEATURES• Linear output for circuit design flexibility• Quad-Hall IC design minimizes mechanical stress effects• Responds to either positive or negative Gauss• Uses 7 mA at 5 Vdc for energy efficiency• Single current sinking or current sourcing output• Rail-to-rail operation provides more usable signal for higher accuracy• Temperature-compensated magnetics help provide stable operation over a wide temperature range of -40°C to 150°C [-40°F to 302°F]The SS490B versions offer cost-effective sensing solutions with wider null and sensitivity tolerances, and a wider drift over temperature than the SS490A higher performance products. Both the SS490A and SS490B versions have a typical sinking or sourcing output of 1.5 mA continuous, use 7 mA supply current at 5.0 V at 25°C [77°F], and provide predictable performance over the full temperature range. For design flexibility, these products are available in the following flat TO-92 package styles:• SS4XX: Straight standard leads, bulk pack• SS4XX-L: Straight long leads, bulk pack• SS4XX-T2: Formed leads, ammopack tape-in-box• SS4XX-T3: Straight standard leads, ammopack tape-in-box• SS4XX-SP: Surface mount, pocket tape and reelPOTENTIAL APPLICATIONS• Basic current sensing for motor load monitoring, detection• Anti-tampering magnetic field sensor in smart remote utility meters• Pump control in heavy-duty equipment and household appliances• Simple linear or angular displacement sensing• Handlebar/throttle position sensing in e-bikes and scooters• Current sensing in appliances• Speed adjustment trigger in tools and appliances• Magnetic code reading in safes, security and building access control systemsNOTICEThe magnetic field strength (Gauss) required to cause the switch to change state (operate and release) will be as specified in the magnetic characteristics. To test the switch against the specified limits, the switch must be placed in a uniform magnetic field.NOTICEAbsolute maximum ratings are the extreme limits the device will momentarily withstand without damage to the device. Electrical and mechanical characteristics are not guaranteed if the rated voltage and/or currents are exceeded, nor will the device necessarily operate at absolute maximum ratings.FIGURE 3. TRANSFER CHARACTERISTICS: TYPICAL OUTPUT VOLTAGE2.50.5Magnetic Range (Gauss)-400-200200400V o l t a g e (V )4.5 2.50.5Magnetic Range (Gauss)-640-320320640V o l t a g e (V )4.52.50.5Magnetic Range (Gauss)-800-400400800V o l t a g e (V )4.5SS495XSS494XSS496XFIGURE 1. BLOCK DIAGRAMFIGURE 2. MAXIMUM SUPPLY VOLTAGE VS TEMPERATUREsupply (+)Ambient Temperature (°C [°F])[257]V o l t a g e (V )[302]FIGURE 4. SS490 SERIES FLAT TO-92-STYLE MOUNTING AND DIMENSIONAL DRAWINGS (FOR REFERENCE ONLY: MM/[IN].)A. Straight Standard Leads Sensor IC, Bulk PackB. Straight Long Leads Sensor IC, Bulk PackNote: Ensure the minimum hole size in the PCB is 0,68 mm [0.027] dia. based on the IPC 2222 Level B standard.C. Formed Leads Sensor IC, Ammopack Tape-in-BoxD. Straight Leads Sensor IC, Ammopack Tape-in-Box (See Figure 5.A. for individual sensor IC dimensions.)FIGURE 5. SS490 SERIES FLAT TO-92-STYLE MOUNTING AND DIMENSIONAL DRAWINGS (CONTINUED)E. Surface Mount Sensor IC, Pocket Tape and ReelArbor hole1,70Section A-ATop cover tapeSS49X-T2SS49X-T3NOTICEProducts ordered in bulk pack (plastic bag) may not have perfectly straight leads as a result of normal handling and shipping operations. Please order a tape packaging option forapplications requiring straight leads.005843-4-EN | 4 | 05/22WARRANTY/REMEDYHoneywell warrants goods of itsmanufacture as being free of defective materials and faulty workmanship during the applicable warranty period. Honeywell’s standard product warranty applies unless agreed to otherwise by Honeywell in writing; please refer to your order acknowledgment or consult your local sales office for specific warranty details. If warranted goods are returned to Honeywell during the period ofcoverage, Honeywell will repair or replace, at its option, without charge those items that Honeywell, in its sole discretion,finds defective. The foregoing is buyer’s sole remedy and is in lieu of all other warranties, expressed or implied, including those of merchantability and fitness for a particular purpose. In no event shall Honeywell be liable for consequential, special, or indirect damages.While Honeywell may provide application assistance personally, through ourliterature and the Honeywell web site, it is buyer’s sole responsibility to determine the suitability of the product in the application.Specifications may change without notice. The information we supply isbelieved to be accurate and reliable as of this writing. However, Honeywell assumes no responsibility for its use.m WARNINGPERSONAL INJURYDO NOT USE these products as safety or emergency stop devices or in any other application where failure of the product could result in personal injury.Failure to comply with theseinstructions could result in death or serious injury.m WARNINGMISUSE OFDOCUMENTATION•The information presented in this product sheet is for reference only. Do not use this document as a product installation guide.•Complete installation, operation, and maintenance information is provided in the instructions supplied with each product.Failure to comply with theseinstructions could result in death or serious injury.HoneywellAdvanced Sensing Technologies 830 East Arapaho Road Richardson, TX 75081FOR MORE INFORMATIONHoneywell Advanced SensingTechnologies services its customers through a worldwide network of sales offices and distributors. For application assistance, current specifications, pricing or the nearest Authorized Distributor, visit our website or call:USA/Canada +1 302 613 4491Latin America +1 305 805 8188Europe +44 1344 238258Japan +81 (0) 3-6730-7152Singapore +65 6355 2828Greater China +86 4006396841。
FEATURES⏹ Quad Hall Element for Stable Output ⏹ Operating Voltage: 4.5V~18V⏹ Low Power Consumption: 4mA at 5VDC ⏹ Linear Output Sink or Source Current⏹ Built-In Laser Trimmed Resistors For Precise Sensitivity And Temperature Compensation ⏹ Responds To Either Positive Or Negative Gauss ⏹ Rail-To-Rail Operation Provides More Useable Signal For Higher Accuracy⏹ Operating Temperature: -40°C ~ +150°C ⏹ Low Profile Package: SIP-3LAPPLICATIONS⏹ Speed Adjustment ⏹ Current Sensor ⏹ Encoder ⏹ RPM DetectionGENERAL DESCRIPTIONThe AS495 is a rail-to-rail linear hall sensor for high temperature application. It has a ratiometric output voltage, set by the supply voltage. It varies in proportion to the strength of the magnetic field.Built-in laser trimmed resistors provide high accuracy and temperature compensation to reduce null and gain shift over temperature. The quad hall element minimizes the effects of mechanical or thermal stress on the output. The positive temperature coefficient of the sensitivity helps compensate for the negative temperature coefficients of low cost magnets, providing a robust design over a wide temperature range. .PIN CONFIGURATIONTOP VIEW1：VCC2：GND 3：OUTBLOCK DIAGRAMPINSYMBOL FUNCTION1 VCC Supply Voltage2 GND Ground3 OUT OutputORDER INFORMATIONABSOLUTE MAXIMUM RATINGS (T A =25°C)ParameterSymbol Rating UnitSupply Voltage VCC 21 VMagnetic FluxB Unlimited GaussOperating temperature Range T OT -40~+150 °CStorage temperature Range T ST -55~+165 °CRECOMMENDED OPERATING CONDITIONSParameterSymbol Min Max UnitSupply voltageV CC 4.5 18 V Operating Temperature (Note2)T A -40 +125 °CELECTRICAL CHARACTERISTICS (V S =5.0V, T A =25°C, unless otherwise noted)ParameterSymbol Conditions Min Typ. Max UnitSupply Voltage VCC 4.5 5.0 18.0 VSupply Current I CC V CC =5.0V - 4.5 - mA Output Current I O V CC >4.5V, Sind or Source - 1.5 - mA Magnetic Range B ±600 ±670 - GaussOutput Voltage Span Vo 0.4 to (Vcc-0.4)0.2 to(Vcc-0.2)- VNull Output V NULL B=0 Gauss 2.425 2.50 2.575V SensitivitySen 3.0 3.125 3.25 mV/G Linearity % of Span Lin - -1.0 -1.5 % Temperature ErrorNull Drift - ±0.06 - %/°C Sen Drift -0.01 - +0.05%/°CTRANSFER CHARACTERISTICS at V CC =5.0VMARKING INFORMATIONPACKAGE INFORMATION (All Dimensions in mm)。
经济型线性位置传感器SS49E/SS59ET系列特点•微型设计• 5Vdc能效时的功耗为6mA •单一电流源输出•线性输出，使电路设计灵活多样•低噪声输出，实际上排除了对滤波的需求•薄膜式电阻，使输出稳定而精确•温度范围在-40℃至100℃（-40°F至212°F）•在正或负高斯都能响应典型应用•电流传感•电动机控制•位置传感•磁码读数•旋转编码器•铁金属探测器•振动传感•液位传感•重量传感SS49E和SS59ET系列经济型线性霍尔效应传感器，为小型、通用、线性、霍尔效应传感器装置，它的运行依靠永久磁铁或电磁铁的磁场。
线性电流源输出电压由供电电压设定，并随磁场强度成比例地变化。
此集成电路具有低噪声输出的特点，致使不再需要采用外部滤波。
它还包括有薄膜式电阻，能提高温度的稳定性和准确性。
这些线性霍尔效应传感器的工作温度范围为-40℃至100℃（-40°F至212°F），适用于各种商业、用户和工业环境条件。
经济型线性位置传感器SS49E/SS59ET 系列运行特性（V S =5.0V ，T A =-40°C 至85°C ，另有说明的除外） 供电电压（Vdc ） 3.0至6.5 标准值 6 供电电流（mA ） 25℃时 最大值 10 最小（V S ﹥3.0V ） 1.0输出电流（mA ） 标准（V S ﹥3.0V ） 1.5最小 1.0标准 1.4 输出电压（mV/G ） 最大 1.75最小 2.25 标准 2.50在0高斯时的零（位）值（Vdc ） 最大 2.75最小 1.05至（V S -1.05）输出电压范围（Vdc ） 标准 0.95至（V S -0.95）最小 ±650磁场强度范围（高斯） 标准 ±1000线性度（量程的%） -0.7 输出类型 线性，电流源 磁性类型 模拟 响应时间（μs ） 3 最小 1.0 标准 1.4灵敏度（mV/高斯） 在25℃时 最大 1.75工作温度 -40℃至100℃[-40°F 至212°F] 温度误差（%/℃） 最小 -0.10零位漂移 最大 0.10≥25℃最小 -0.15灵敏度漂移 ≥25℃最大 0.05 ＜25℃最小 -0.04＜25℃最大 0.185绝对最大额定值*供电电压（Vs ） 0.5Vdc 至8.0Vdc输出电流 10mA 存储温度 -55℃至165℃[-67°F 至329°F]*绝对最大额定值在装置不损坏的条件下能承受的极限值。
3 pin SIP (suffix UA) DescriptionSS3503 Linear Hall-effect sensor is small, versatile linear Hall-effect device that is operated by the magnetic field from a permanent magnet or an electromagnet. The linear sourcing output voltage is set by the supply voltage and varies in proportion to the strength of the magnetic field. The integrated circuitry features low noise output, which makes it unnecessary to use external filtering. It also includes thin film resistors to provide increased temperature stability and accuracy. The linear Hall sensor has an operating temperature range of -40 °C to 150 °C appropriate for commercial, consumer and industrial environments.Typical ApplicationsMotor controlMagnetic code readingFerrous metal detectorCurrent sensingPosition sensingFunctional Block DiagramPins DefinitionPin DescriptionAbsolute Maximum RatingsParameterSymbolValueUnitsSupply V oltage (operating) V CC 8.0 V Output CurrentI OUT 20 mA Operating Temperature Range T A -40~150 ℃ Storage Temperature RangT S -65~150℃Electrical Characteristics（TA =25℃，VCC =5.0V）TypUnitsMinMaxTestParameter SymbolConditionsV Operating voltage V CC Operating 3.0 6.5mA8.0Supply current I CC Average 4.21.5 mA Output Current I OUT 1.0Response Time T ack 3 uS Quiescent Output V oltage V o B=0G 2.25 2.5 2.75 V2.0mV/G1.8Sensitivity △V out T A=25℃ 1.6Min Output V oltage B=-1500G 0.86 VMax Output V oltage B=1500G 4.21 V Performance Characteristics输出电压与磁场强度曲线静态输出电压与工作电压关系曲线Package InformationPackage UA, 3-Pin SIP:Ordering InformationPart No. Pb-free Temperature Code Package Code PackingSS3503EUA YES -40°C to 85°C TO-92 Bulk, 1000 pieces/bag SS3503KUA YES -40°C to 125°C TO-92 Bulk, 1000 pieces/bag SS3503LUA YES -40°C to 150°C TO-92 Bulk, 1000 pieces/bag。
3 pin SIP (suffix UA) DescriptionSS1302 Linear Hall-effect sensor is small, versatile linear Hall-effect device that is operated by the magnetic field from a permanent magnet or an electromagnet. The linear sourcing output voltage is set by the supply voltage and varies in proportion to the strength of the magnetic field. The integrated circuitry features low noise output, which makes it unnecessary to use external filtering. It also includes thin film resistors to provide increased temperature stability and accuracy. The linear Hall sensor has an operating temperature range of -40 °C to 150 °C appropriate for commercial, consumer and industrial environments.Typical ApplicationsMotor controlMagnetic code readingFerrous metal detectorCurrent sensingPosition sensingFunctional Block DiagramPins DefinitionPin DescriptionAbsolute Maximum RatingsParameterSymbolValueUnitsSupply V oltage (operating) V CC 8.0 V Output CurrentI OUT 20 mA Operating Temperature Range T A -40~150 ℃ Storage Temperature RangT S -65~150℃Electrical Characteristics（TA =25℃，VCC =5.0V）TypUnitsMinMaxTestParameter SymbolConditionsV Operating voltage V CC Operating 3.0 6.5mA8.0Supply current I CC Average 4.21.5 mA Output Current I OUT 1.0Response Time T ack 3 uS Quiescent Output V oltage V o B=0G 2.25 2.5 2.75 V2.0mV/G1.8Sensitivity △V out T A=25℃ 1.6Min Output V oltage B=-1500G 0.86 VMax Output V oltage B=1500G 4.21 V Performance Characteristics输出电压与磁场强度曲线静态输出电压与工作电压关系曲线Package InformationPackage UA, 3-Pin SIP:Ordering InformationPart No. Pb-free Temperature Code Package Code PackingSS1302EUA YES -40°C to 150°C TO-92 Bulk, 1000 pieces/bag SS1302KUA YES -40°C to 125°C TO-92 Bulk, 1000 pieces/bag SS1302LUA YES -40°C to 150°C TO-92 Bulk, 1000 pieces/bag。
DESCRIPTIONThe SS39ET/SS49E/SS59ET Series Low-cost Linear Hall-effect sensors are small, versatile devices that are operated bythe magnetic field from a permanent magnet or anelectromagnet.The linear sourcing output voltage is set by the supply voltageand varies in proportion to the strength of the magnetic field.Low voltage capability as low as 2.7 Vdc and reduced currentconsumption of only 6 mA typically at 5 Vdc help make thisproduct energy efficient.The integrated circuitry features low noise output, which makesit unnecessary to use external filtering. It also includes thin filmresistors to provide increased temperature stability andaccuracy. These linear Hall-effect sensors have an operatingtemperature range of -40 C to 100 C [-40 F to 212 F],appropriate for commercial, consumer, and industrialenvironments.VALUE PROPOSITION∙Designed and manufactured for cost competitiveness∙All packages can be supplied on tape for automated,lower-cost assembly∙SS39ET’s small footprint takes up less space on the PCboard, typically allowing for more components∙Interfaces with many electrical components withoutbuffering∙Thermally balanced integrated circuit for stable operationover a full temperature rangeFEATURES AND BENEFITSMiniature and subminiature construction: Designed forcompact designs with tight space requirementsEnergy efficient: Low current consumption of 6 mA at5 VdcEasy PC board interface: Single current sourcing outputfor common electronic circuitsCircuit design flexibility: Voltage range of 2.7 Vdc to6.5 VdcLow noise output:Virtually eliminates the need for filteringStable output:Thin film resistors improve accuracyWide range of environments: Temperature range of-40 °C to 100 °C [-40 °F to 212 °F]Application flexibility: Responds to either positive ornegative GaussPOTENTIAL APPLICATIONSIndustrial:∙Basic current sensing for motor load monitoring, detection∙Anti-tampering magnetic field sensor in smart remoteutility meters∙Pump control in heavy-duty equipment and householdappliances∙Simple linear or angular displacement sensing∙Handlebar/throttle position sensing in e-bikes and scooters∙Current sensing in appliances∙Speed adjustment trigger in tools and appliances∙Magnetic code reading in safes, security and buildingaccess control systemsMedical:∙Position sensing in infusion pumps-55 C to 165 C [-67 F to 329 F]XXX –+04,1[0.16]1,6[0.06]1,7[0.07]0,64[0.025]0,38[0.015]14,99[0.59]3,0[0.12]0,3[0.015]0,76[0.03]1,3[0.05]2,5[0.10]HALLELEMENT CENTERN S2,5[0.10]XXX–+04,1[0.16]1,7[0.07]0,64[0.025]0,38[0.015]18,669[0.735]3,0[0.12]HALLELEMENT CENTER1,3[0.05]1,6[0.06]0,3[0.015]0,76[0.03]N SXXX–+04,1[0.16]1,6[0.06]1,7[0.07]0,64[0.025]0,38[0.015]14,99[0.59]3,0[0.12]0,3[0.015]0,76[0.03]2,54[0.10]2,5[0.10]HALLELEMENT CENTERN SSensing and Control Honeywell1985 Douglas Drive NorthGolden Valley, MN 55422 /sensing 005850-2-ENFebruary 2012© 2012 Honeywell International Inc. All rights reserved.PERSONAL INJURYDO NOT USE these products as safety or emergency stop WARRANTY/REMEDYHoneywell warrants goods of its manufacture as being free of defective materials and faulty workmanship. Honeywell’s standard product warranty applies unless agreed to otherwise by Honeywell in writing; please refer to your order acknowledgement or consult your local sales office for specific warranty details. If warranted goods are returned to Honeywell during the period of coverage, Honeywell will repair or replace, at its option, without charge those items it finds defective. The foregoing is buyer’s sole remedy and is in lieu of all other warranties, expressed or implied, including those of merchantability and fitness for a particular purpose. In no event shall Honeywell be liable for consequential, special, or indirect damages.While we provide application assistance personally, through our literature and the Honeywell web site, it is up to the customer to determine the suitability of the product in the application.Specifications may change without notice. The information we supply is believed to be accurate and reliable as of this printing. However, we assume no responsibility for its use.MISUSE OF DOCUMENTATIONThe information presented in this product sheet is forreference only. Do not use this document as a productinstallation guide.Complete installation, operation, and maintenanceinformation is provided in the instructions supplied witheach product.Failure to comply with these instructions could result in death or serious injury.SALES AND SERVICEHoneywell serves its customers through a worldwide network of sales offices, representatives and distributors. For application assistance, current specifications, pricing or name of the nearest Authorized Distributor, contact your local sales office or:E-mail:*********************Internet: /sensingPhone and Fax:Asia Pacific +65 6355-2828+65 6445-3033 FaxEurope +44 (0) 1698 481481+44 (0) 1698 481676 FaxLatin America +1-305-805-8188+1-305-883-8257 FaxUSA/Canada +1-800-537-6945+1-815-235-6847+1-815-235-6545 Fax。
反极性低灵敏霍尔集成电路ES572 1.概述ES572是一款基于混合信号CMOS技术的单极锁存型霍尔效应传感器，器件内部集成了电压调节器、带动态偏置补偿系统的霍尔传感器、施密特触发器和一个开漏极输出驱动，这些都在同一个封装里。
这款IC采用了先进的斩波稳定技术，因而能够提供准确而稳定的磁开关点。
除了以下“应用”中列出的应用外，这款传感器还有很多其他应用。
因为ES572的宽工作电压以及宽泛的温度选择范围，使得它非常适合用于汽车、工业以及消费行业中。
2.特点◆宽工作电压范围：3.5V~24V◆插件N极感应，贴片S极感应◆CMOS工艺◆稳定的斩波放大▫优越的温度稳定性▫极低的开关点漂移▫对物理应力不敏感◆低电流消耗◆开漏极输出◆贴片型SOT23-3L、插件TO-92S 3.应用◆汽车、消费、工业◆固态开关◆断流器◆速度检测◆线性位置检测◆角位置检测◆接近探测4.功能框图V DDOUT VoltageRegulatorChopperHallPlateGND UA封装SO封装Pin1–VDD Pin1–V DD Pin2–GND Pin2–OUT Pin3–OUT Pin3–GND反极性低灵敏霍尔集成电路ES572 5.专业术语术语描述MilliTesla(mT)高斯，磁感应强度单位1mT=10高斯RoHS危险物质限制SOT小轮廓晶体管（SOT封装）—也可以用封装号“SO”引用ESD防静电BLDC无刷直流Operating Point(B OP)使输出导通的作用于封装标记面的磁感应强度（V OUT=V DSon）Release Point(B RP)使输出截止的作用于封装标记面的磁感应强度（V OUT =high）6.管脚定义和描述SO引脚编号UA引脚编号名称类型功能11V DD电源电源电压引脚23OUT输出开漏极输出引脚32GND地接地引脚572XX 572 xxxx7.独特特性基于混合信号CMOS工艺，Innosen ES572是一款N极敏感的霍尔效应器件，这种多用途锁存器符合大多数应用需求。
1、概述：YS495A 线性霍尔效应传感器，其输出信号电平决定于施加在器件敏感面的磁场强度，随磁场强度成比例地变化。
当YS95A 处于零磁场时，其输出电压是电源电压的一半。
S 磁极出现在YS95A 标记面时，输出电压将随磁场强度增加而线性升高；相反，N 磁极将使输出电压随磁场强度增加而线性降低。
YS95A 具有低噪声输出的特点，无需采用外部滤波，同时内置薄膜电阻，能提高温度的稳定性和准确性。
工作温度范围为-40℃至150℃，适用于各种商业应用和工业环境工作。
封装形式为TO-92，SOT-89包装：1000/包。
2、产品特点：●在5V 电源时，电源电流典型值为4.5mA ●内含修正的电阻提供精确的灵敏度和温度补偿●比较宽的工作温度范围：-40~150℃●快速上电耐机械应力●一致性好可靠性高低噪声低功耗3、典型应用：●电流传感器●电机控制铁质金属检测●位置传感器磁编码器●震动检测液位传感器●压力传感器位移检测●位置移动转速检测角度测量4、电路内部框图：YS495A 高精度线性霍尔元件5、磁特性（V DD=5V，T A=25℃）参数符号最小最大单位电源电压V DD-0.530V 输出电压V OUT-0.330V 电源电流I DD--20mA 输出电路I OUT--2mA 储存温度T J-50～165℃6、电学特性（VDD=5.0V,TA=25℃）参数符号测试条件最小值典型值最大值单位供电电压V DDT J<T J(Max) 3.5 5.010.5V电源电流I DDV DD=5.0T A=25℃CC CC=5.0V,T A2.5 4.510.0mA输出负载电阻R LO UT to V DD4----KΩO UT to G ND4----KΩ输出电压范围V OUT(H)T A=25℃B=1000G S4.8 4.95.0V V OUT(L)T A=25℃B=-1000G S00.10.2V静态电压输出V OUT(Q)B=0GS T A=25℃ 2.3 2.5 2.7V线性度L IN----±1%灵敏度S ENS2.753.125 3.5mV/Gs响应时间T RESP--1--µS灵敏度漂移(WENP)ΔSensT A=-40～105℃±10%管脚定义1脚：电源VDD 2脚：接地GND 3脚：输出OUT 脚7、典型的磁电转换特性：（单位：Gauss）-640-32003206408、外型尺寸图（mm）：TO-92SOT-89：管脚定义1脚：电源VDD2脚：接地GND3脚：输出OUT注意事项1.霍尔是敏感器件，在使用过程以及存储过程中请注意采取静电防护措施。
模拟霍尔位置传感器*散装，每包1000个表面安装型：加后缀S 如：SS495A-S 线带包装T1型：加后缀T1线带包装 P 型（表面安装）：加后缀SPMilliTesla=Guass x 10-1订货指南V S =5.0V, T A =-40至+150℃（除非另外标明）特点：●体积小巧（0.16x 0.118″） 低功耗—典型7mA 在5VDC ● 电源沉或源线性输出● 内含激光修正的薄膜电阻提供精确的灵敏 度和温暖度补偿●工作温度范围-40~+150 ● 可反应于正的或负的磁场● 方块霍尔传感元件提供稳定的输出● Rail-to-Rail 性能可提供更有效的信号以达到更高精度SS495 系列传感器的输出与电源电压成比率变化关系，并与磁场强度成正比。
新的霍尔电路提供增强的温度稳定性和灵敏度。
激光修正的薄膜电阻提供高精度（零点±3%，灵敏度±3%）以下和温度补偿减小零点和增益温飘，方块霍尔芯片把影响输出的机械和热应力效应减少到最小程度，正的灵敏度温度系数（0.02%/˚C 典型值）有助于补偿低成本磁钢负的温度系数。
Rail-to-Rail （全电压范围）性能可提供更有用的信号以达到高的精度。
内部电路结构图指标供电电压（VDC ）供电电流@25℃（mA ）输出类型（电流沉源）输出电流（mA ）典型电流源最小电流源最小电流沉最小电流沉磁特性 @25℃，5VDC 磁场范围输出电压范围零点电压（输出@0高斯，伏）灵敏度（mV/G ）线性误差（%量程）温度误差零点漂移（%/℃）灵敏度漂移（%/℃）SS495A 标准4.5-10.57.08.7比率变化1.51.00.61.0SS495A1高精度4.5-10.57.08.7比率变化1.51.00.61.0SS495A2＊基本型4.5-10.57.08.7比率变化1.51.00.61.0典型值最大值Vs>4.5V Vs> 4.5V Vs >4.5V Vs >5.0V典型值最小值典型值最小值典型值最大值≥25°C(最大值)<25°C(最大值)±0.04%-0.02, +0.060.0, +0.06高斯：-670 ~ +670(-67~ +67mT)高斯：-600 ~ +600(-60~ +67mT)0.2 ~ (Vs-0.2)0.4 ~ (Vs-0.4)2.500±0.0753.125±0.1253.125±0.094-1.0%-1.5%2.5±0.1003.125±0.156±0.07%-0.02, +0.06-0.01, +0.07±0.06%-0.01, +0.050.0, +0.06VS VS对Vs对比率典型频率反应VNULL线性度VS Vs供电电流VS温度输出曲线VS 5.0VDC灵敏度/V VS VsGuass:-840-+840(-84-+84mT)Guass:-750-+750(-75-+75mT)0.2-(Vs-0.2)0.4-(Vs-0.4)-1.0%-1.5%模拟霍尔位置传感器SS490指标V S =5.0V,T A =－40~150℃(除非另外标明)指标供电电压（VDC ）供电电流@25℃（mA ）输出类型（电流沉源）输出电流（mA ）典型电流源最小电流源最小电流沉最小电流沉磁特性 @25℃，5VDC 磁场范围输出电压范围零点电压（输出@0高斯，伏）灵敏度（mV/G ）线性误差（%量程）温度误差零点漂移（%/℃）灵敏度漂移（%/℃）SS496B 标准4.5-10.57.08.7比率变化1.51.00.61.02.500±0.1502.500±0.200±0.06%-0.02， +0.06-0.02， +0.06SS496A1高精度4.5-10.57.08.7比率变化1.51.00.61.02.500±0.0752.500±0.075±0.032%-0.01， +0.06-0.00， +0.06（典型值）.（最大值）.Vs>4.5V Vs> 4.5V Vs >4.5V Vs >5.0V典型值最小值典型值最小值典型值最大值≥25℃(最大值)<25℃(最大值)零点漂移VS 温度灵敏度漂移VS 温度典型频率反应V NULL VS Vs 对比率线性度VS Vs供电电流VS 温度输出曲线@Vs=5.0VDC灵敏度/V VS Vs安装尺寸（仅供参考）传感器封装可选表面封装形式推荐型号SS495A1 SS495A SS496B特点高精度标准型标准型。
FITELNINJA NJ001Quick Reference guideFTS-B495Issue 3① Turn on power.< Fiber Preparation > Stripping the fiber coatingS210 Fiber Stripper Fiber CleaningFiber CleavingLint-freetissue with ethanolPlace fiber on Single Fiber Adapter. Hold the fiber tightly.Then move S210 into the direction indicated by the arrow mark.Safety InstructionsBefore operating this pr oduct, please read the user’s manual of safety instructions. The safety instructions are to help you use this product in a safe and correct way, and to prevent danger or injury to yourself or others.Single Fiber AdapterSplicing ProcedureEnd.⑫ Remove the fiber.⑪ Press key. ⑩ Place fiber to heater. ⑨ Slide protection sleeve overspiced point. ⑧ Remove spliced fiber. ⑦ Press key. ⑥ Set fibers to the splicer. ⑤ Prepare the fibers. ④ Insert protection sleeve. ③ Perform Arc Check.※ Please see “Arc Check” fordetails. ② Select applicable program. Setting the fiber on the splicerThe edge of the fiber coating should match with the edge of the tight holder. Edge of the coatingPress the lever.Select applicable heater program.Enter “All Programs”.< Fusion Program>Enter “Fusion PRGM ” in menu.< Heater Program>Enter Heater PRGM in menu. Select applicable fusion program.Open the windshield and set the fibers. Then enter “Arc Check”.Splicer automatically feeds the fibers and discharges an arc.The results are indicated. If the results are negative, the machine willautomatically adjust the arc power. Please perform the arc check again.Procedure of Changing ProgramArc CheckArc Check is the function to adjust the arc power in order to ensure optimal splicing results. Electrode wear and environmental conditions such as temperature, humidity, and altitude, may affect the arc power.Please perform the Arc Check at the beginning of each daily operation.To ensure optimal splicing results< Cleaning V-groove> < Cleaning Fiber Clamp> Maintenance< Cleaning Electrodes> < Cleaning Lens Cover> Clean V-groove by a cleaning brush and a cotton swab soaked with ethanol.Run fiber across V-groove to remove dust in V-groove.Clean Fiber Clamp byusing cotton swab soaked with ethanol.Loosen the screw and remove the lid of electrode. Then replace with a new one.After replacement, press the key 10 times with closing windshield to remove the dust.< Replacement of Electrodes>Stick the tip of anelectrode into the electrode sharpener and turn/twist the electrode 3-4 times.Fiber ClampElectrode Sharpener Cleaning brushRemove both electrodes and V-groove. Then clean Lens Cover by using cotton swab soaked with ethanol.Lens CoverPower KeyTurn the power on/off.Start KeyStart/Pause/Restart the splicing processHeating KeyStart/Stopthe heating processUp/ Down/ Left/ Right KeyMove the cursor and change the valueFunction 1 KeySelect the function shown on the right bottom corner of LCD.Function 2 KeySelect the function shown on the left bottom corner of LCD.Selected Splice programSelected Heater programSplice ProcessFiber ViewCurrent Function of Function KeysFusion SplicerOperation KeysScreen IndicationDate and Time Status Splice CountStorage Space of Hard Carrying CaseAC Power Cable AC AdapterSpare Electrodes。
