一般规格书 电导率传感器

7100E Inductive Conductivity System for Reliable Wide-Range MeasurementI n d u c t i v e C o n d u c t i v i t y7100ENon-Fouling Sensors PEEK or PFA Wetted Parts Excellent Chemical Resistance 0/4 to 20mA Outputs for Conductivity & Tempreature 4 Relays PID ControlTHORNTONLeading Pure Water Analytics27100E S y s t e m7100E Inductive Conductivity SystemKey FeaturesAdvantages at a glance.The Mettler-Toledo Thornton 7100E inductive conductivity transmitter has an extremely wide measuring range of 0-2000 mS/cm. The unit also pro-vides simultaneous readings of the measured value (conductivity, con-centration or salinity) and tempera-ture, clearly portrayed in a well-arranged LC display, with analog outputs for both. Status annunciators indicate the mode of operation. The AC/DC universal power capability allows the transmitter to be con-nected to almost any power source.Process safety - in the foreground.SensoCheck ®continuously monitors the sender coil and wiring for short circuits, and the receiver coil for any disruptions. GainCheck ®allows a manual functional check of the transmitter at any time. In addition,an installed background program carries out an independent, periodic check of all instrument functions. A red LED in the front panel optically signals any alarm condition. A 22mA alarm signal can be set in the event of a malfunction.Rapid connection and start-up.Plug-in terminals and front panel access allow rapid installation of sensors and output wiring. Instru-ment mounting configurationsinclude wall, pipe or panel mounting.The robust plastic enclosure can withstand the harshest process conditions with a rating of IP65,NEMA 4X.Simple calibration.Calibration of the transmitter and sensor is carried out either through direct entry of the factory calibrated cell factor orthrough manual validation of the cellfactor using a standard calibration solution. Temperature may also be calibrated to provide more precise automatic temperature compensation of the measured conductivity values.Variety of process adaptions.The sensors can be inserted into a process pipe by means of athreaded bushing or Tri-Clamp fitting.PID proportional, integral, deriva-tive control.Built-in control enables complete loop autonomy where desired. Control output is through relays based on pulse frequency for metering pumps or pulse duration for solenoid valves. Analog outputs are still available for conductivity and temperature.ApplicationsSemiconductor processescan be monitored with sensors of glass-filled PEEK and no wetted metal parts. Process purity require-ments are protected.Waste water monitoring reliability is assured with non-fouling inductive sensors even at high conductivity and suspended solids levels.Inductive sensors measure even in concentrated, zero-dis-charge applications.Deionization Regeneration acid and base concentrations can be controlled reliably and accurately with inductive conductivity measure-ment. Direct temperature-compen-sated, % by weight readout isprovided for all chemicals used for deionizer and softener regeneration.Pharmaceutical Clean-in-Place (CIP) processes requiring control of chemical concentrations can use inductive conductivity measurement.It can also be used to validate con-centrations at the return end of the line and for waste treatment.7100E Inductive Conductivity SystemDimensions: inches (mm).3Conductivity Input Mettler-Toledo Thornton 7250 Series inductive sensors Conductivity Ranges0.000 to 9.999 mS/cm –00.00 to 99.99 mS/cm 0.000 to 9.999 S/m 000.0 to 999.9 mS/cm 00.00 to 99.99 S/m0000 to 1,999 mS/cm–Concentration Ranges NaCI 0 to 26%(0 to 60 °C)HCI 0 to 18%(-20 to 50 °C)NaOH 0 to 14%(0 to 100 °C)H 2SO 40 to 30%(-17 to 110 °C)HNO 30 to 30%(-20 to 50 °C)H 2SO 432 to 84%(-17 to 115 °C)H 2SO 492 to 99%(-17 to 115 °C)HCI 22 to 39%(-20 to 50 °C)HNO 335 to 96%(-17 to 115 °C)NaOH18 to 50%(0 to 100 °C)Salinity Range 0.0 to 45.0% (0 to 35 °C)Measurement Error < 1% of measured value + 0.005 mS/cm Temperature Input*Pt100 / Pt1000 / NTC 100 k ΩMeasuring Range Pt: -20 to +200 °C / -4 to +392 °F NTC: -20 to +130 °C / -4 to +266 °F Resolution 0.1 °C / 1 °FMeasurement Error 0.5 K; ±1K with Pt100Temperature Compensation Linear: 00.00 to 19.99 %/K (Reference temp. 25 °C)Non-Linear: natural water to EN 27888 (0 to 35 °C)Display 3-1/2 digit liquid crystal display with alarm LEDCurrent Outputs Two, 0 to 20 mA or 4 to 20 mA, max. 10 V, isolated, 22 mA for error message, can be disabled; dedicated to conductivity and temperature Current Characteristics Linear or logarithmicCurrent Error < 0.3 % of current value ± 0.05 mAStart/End ScaleSelectable within the measurement range for mS, S, % by wt, salinity, temperatureMinimum Measurement SpanLinear: 5% of selected measurement range Logarithmic: 1 decade47100E S y s t e m7100E Inductive Conductivity Transmitter Specifications7100E Inductive Conductivity TransmitterSpecificationsCell Factor Range00.100 to 19.999Monitoring of Cell Sensocheck®: monitoring of sender coil and leads for short circuits, and ofthe receiver coil for disruption (can be disabled).Relays* 4 SPST relay switching contacts, isolatedRelays 1 & 2 for limits, with adjustable NO/NC, hysteresis and delayOptionally, relays 1 & 2 for PID controlRelay 3 for system alarmRelay 4 for sensor washRelay Ratings AC: < 250 V, < 3 A, < 750 VADC: < 30 V, < 3 A, < 90 WPID Process Controller*Output via relay contactsProportional Action Controller Gain K C: 0010...9999%Integral Action Reset Time T R: 0000...9999 SDerivative Action Reset Time T D: 0000...9999 SController Type Pulse length or pulse frequency controllerPulse Period0001...0600 S, minimum ON time 0.5 S (pulse length controller)Maximum Pulse Frequency0001...0180 pulses/minute (pulse frequency controller)Power Supply20 to 253 VAC/DC, AC: 45 to 65 Hz, approx. 5 VA , 2.5 WOvervoltage category II; Protection class IIAmbient Conditions Operating/ambient temperature -20 to +55 °C;Transport and storage temperature -20 to +70 °CRelative humidity 10 to 95% non-condensingEnclosure Polymer case, PBTP (polybutyleneterephthalate)Installation Wall-mounting hardware, standardPipe/bracket for 1-1/4 to 2” pipe, φ40 to 60 mm, with kit ordered separatelyControl panel, cutout to DIN 43700, with kit ordered separatelyDimensions144 x 144 x 105 mm (5.67 x 5.67 x 4.13 in.)Protection IP 65, NEMA 4XCable Entry 5 ports for cable glands M20 x 1.5 or 1/2” conduitWeight Approx. 1 kg (0.5 lb.)FM/CSA NI, Class I, Div 2, Group A, B, C, D; T4EMC EN 61326EN 61326/A1EN 61000-4-5, Installation Class 2* ConfigurableDescription Part No.Inductive Conductivity Transmitter with Wall Mounting Hardware7100EPanel Mounting Kit for 7100E52 120 740Pipe Mounting Kit for 7100E (1-1/4” to 2” Pipe)52 120 741567100E S y s t e m⏹Chemically resistant PEEK (polyetheretherketone) or PFA (perfluoro alkoxy)⏹No metal wetted parts⏹High-Temperature to 180 °C (356 °F)⏹Wide measuring range to 2,000 mS/cm ⏹Unaffected by severe fouling⏹Simple installation of sensors and accessories ⏹Variety of process insertion fittings⏹Submersion installation for wastewater treatment ⏹Robust sensor design for maintenance-free operation⏹Integrated temperature probe for direct temperature compensationFeaturesOperationThe inductive conductivity sensor consists of two high-grade toroids (coils) which are incorporated concentrically and adjacent to one another in a polymer body. These coils form a current transformer.The sensor is designed so part of the liquid media forms a closed con-ductive current path passing through the toroids. The primary coil is acti-vated with a sinusoidal alternating voltage, which induces an alternating voltage in the liquid loop (sample medium). In liquids which conduct electricity, this causes a current flow which is proportional to the conduc-tivity of the sample medium.The liquid loop is also acting as the primary winding of the secondary coil which functions as a current transformer. This current is rectified to the correct phase and amplified. If the toroid of the sensor is mounted in a relatively small (< 3”) pipe, the field around the toroid, and therefore the effective cell factor, will be influenced. In that case, calibration in thepipe is needed to achieve rated accuracy.* PFA versionDimensions: mm (inches).7250 Inductive Conductivity SensorsDescriptionA B C Part No.Threaded bushing 2” NPT PVDF 2” NPT SW7524 (0.95”)52 403 453Sanitary Fitting 2” Tri-Clamp SS–––58 084 013PeekPFA0 to 2,000 mS/cm 0 to 2,000 mS/cm 2.17 2.301201202”NPT bushing or Tri-Clamp fitting (see table below)2”NPT bushing or Tri-Clamp fitting (see table below)0.9 kg (2 lb.)0.9 kg (2 lb.)Pt 1000Pt 1000Approx 5 minutes (90%)Approx 5 minutes (90%)Glass filled PEEK (GF30)Unfilled PFA1.4435 (316) Stainless Steel 1.4435 (316) Stainless Steel Viton / Viton FEP/PTFE 5, 10 m (16, 33 ft)5,10 m (16, 33 ft)7-20 to 100 °C (-4 to 212 °F)-20 to 180 °C (-4 to 356 °F)7250 Series SensorsMeasuring Range Cell Factor Transfer Ratio Installation WeightTemperature Sensor Temperature Response Wetted Material Mounting Thread O-ring / Gasket Cable LengthsTemperature Part No.52 002 7375 m (16 ft)10 m (33 ft)52 002 738Max Pressure Measurement Value Deviation Cable Jacket MaterialCable Length m (ft)PVC 8 bar (116 psig)±(0.5% of measurement + 25 µS/cm)52 002 7405 m (16 ft)10 m (33 ft)52 002 741Silicone 20 bar (290 psig)±(0.5% of measurement + 1 µS/cm)A combination of high pressure, high temperature and/or aggressive process medium can reduce sensor life.7250 Series Insertion Adapters7250 Series Adapter Dimensions7250 Inductive Conductivity Sensors & Accessories-20 to 125 °C (-4 to 257 °F)16 bar (232 psig)±(0.5% of measurement + 25 µS/cm)Silicone52 005 4245 m (16 ft)10 m (33 ft)52 005 425Mettler-Toledo Thornton, Inc.36 Middlesex Turnpike Bedford, MA 01730 USA Tel. +1-781-301-8600Fax +1-781-301-8701Toll Free +1-800-510-PURE ******************** Subject to technical changes © Mettler-Toledo Thornton, Inc. ML0080 Rev.E 06/08Visit for more information/thorntonQuality certificate.Develop-ment, production and testing toISO 9001.A certified ServiceXXL provider.CE CompliantConductivity Standard SolutionsProvided for sensor verification and recalibration, conductivity standards are produced, analyzed, and documented in the Mettler-Toledo Thornton ISO 9001 certified facility with processes similar to those used to calibrate high accuracy Thornton conductivity sensors. They are provided with label and certificate with lot number, certified value, expiration date, plus ASTM and NIST traceability data. These standards are analyzed and used at equilibrium with the atmosphere.Standard Accuracy Shelf Life Part No.1000 µS/cm, 500 mL, KCl± 1%12 mo58 078 003 10,000 µS/cm, 500 mL, KCl± 1%12 mo58 078 004 100,000 µS/cm, 500 mL, KCl± 1%12 mo58 078 005。

产品说明书00813-0106-3225, Rev AC2023 年 5 月Rosemount™ 225环形电导率传感器高电导率卫生应用的可靠传感器Rosemount 225 环形电导率传感器为需要卫生设计的制药、食品及饮料应用而设计。

此类耐腐蚀和抗污染传感器适用于测量 CIP 溶液浓度、检测产品/水界面、检查产品质量和监测色谱溶液中的元素。

概述Rosemount 225 是适合高电导率卫生应用的可靠传感器。

Rosemount 225 环形电导率传感器为需要卫生设计的制药、食品及饮料应用而设计。

此类耐腐蚀和抗污染传感器适用于测量CIP 溶液浓度、检测产品/水界面、检查产品质量和监测色谱分离中的洗脱剂。

符合各项卫生要求。

■符合 USP VI 级要求。

■符合 FDA 食品接触 21CFR177.2415 标准。

■符合 3-A 卫生标准之 74-06。

易于安装。

■2-in. tri-clamp 过程连接件。

■安装灵活，配合分体式接线盒（另购），传感器和变送器之间电缆最长可达到 200 ft. (61 m)（标准为 100 ft. [30 m] 内）。

高性能、高可靠性。

■可靠的测量 - 对过程流量和方向不敏感。

■具有 PEEK 和 Tefzel ® 等多种耐化学品的主体材质选项，可满足应用的兼容性需求。

内容概述.......................................................................................................................................................................................................2订购信息...............................................................................................................................................................................................3技术规格...............................................................................................................................................................................................4尺寸图...................................................................................................................................................................................................5附件.......................................................................................................................................................................................................6工程规格.. (6)2023 年 5 月/Rosemount订购信息Rosemount 225 卫生型环形电导率传感器在最高 2 S/cm (2,000,000 µS/cm) 电导率的液体中表现良好。

NBI水质EC（电导率）传感器用户手册深圳市农博创新科技有限公司使用前须知•使用前请仔细阅读本说明书，因不遵守本说明书的操作规程及注意事项而造成产品损坏或失效的，农博创新将视情况不提供保修服务。

•使用前请检查包装是否完好，若发现产品有损坏，请将损坏货品与包装物一并寄回农博创新。

•因产品功能、性能的持续改进和优化，如有参数变动，恕不另行通知。

1.概述1.1功能及应用介绍农博创新水质EC传感器是一款用于水质电导率实时监测的传感器，可准确测量微生物、鱼虾类、水草类、泥沙等多种环境下淡水或海水水体的电导率。

配合农博创新Watcher Pro••1.2.2尺寸1.2.3各部位说明传感器接头探头保护帽2.使用方法2.1安装方式水质EC传感器采用沉入式安装，详细的信息请参见Watcher Pro2(Aqua)无线水质监测产品用户手册。

3.维护3.1贮存水质EC传感器使用完毕后需要长时间贮存时，应先将水质EC传感器冲洗干净，然后插入加有保护溶液的保护帽，或者可将水质EC传感器浸没到保护溶液中。

同时应避免传感器探头4.注意事项1请勿将传感器置于水流较快的地方，会导致污染物堆积过快6.联系我们深圳市农博创新科技有限公司地址：中国广东省深圳市南山区讯美科技广场2座7楼709官网：联系电话：400-015-1568邮箱：**********************保修条例1.本产品保修期为半年。

从发货之日起六个月内，本产品保修期内按说明书正常使用的状况下产生的故障，予以免费维修。

2.属于以下情况之一不属于免费保修范围，农博创新提供有偿服务，敬请留意：(1)超过保修有效期；(2)未按产品说明书的要求使用、安装而造成的损坏；(3)由非农博创新授权维修服务者拆修造成的损坏；(4)因用户使用不当而造成的产品损坏，如摔坏、机械破坏等；(5)因不可抗力（如火灾、地震、台风等）造成的损坏；(6)其他非产品本身设计、技术、制造、质量等问题而导致的故障或损坏。

产品说明书00813-0106-3228, Rev AC2023 年 五月Rosemount™ 228环形电导率传感器全能电导率传感器，应对多样化应用挑战Rosemount 228 环形电导率传感器能可靠测量电导率最高为 2 S/cm (2,000,000 μS/cm) 的高电导率液体。

此类传感器在金属电极传感器会发生故障的脏污和腐蚀性环境中仍可正常工作。

Rosemount 228 的稳固设计十分适合测量酸、碱、盐溶液的浓度。

概述高性能和可靠性：■具有 PEEK 和 Tefzel ® 等多种耐化学品的主体材质选项，可满足具挑战性的应用需求。

■强化的内部金属框架设计具有优良的耐振动性。

■可耐受最高 392 °F (200 °C) 过程温度的高温选项，并且适合在最高 295 psig (2135 kPa [abs]) 的高压下使用。

满足您的过程安装需求：■适合插入式和浸入式应用。

■丰富的安装选项，可使用 ¾-in. MNPT 或 ⅝-in. 11 UNC 过程连接件。

■使用可选的收回组装工具包，可在不关闭过程的情况下从管道或储罐上卸下传感器。

订购信息Rosemount 228 环形电导率传感器由具有化学抗性的玻璃充填 PEEK 或 Tefzel ™制成，十分适合测量酸、碱、盐溶液的浓度。

该传感器包含一个补偿温度的一体化 PT-100 热电阻 (RTD) 和一根 20 ft. (6.1 m) 长的一体化电缆。

Rosemount 228 可用于多种插入式转接器，满足您的安装需要（参阅 附件）。

注如需更高的 EMI/RFI 屏蔽性，请选择 56-61 电缆选项（用于 Rosemount 1181T 、1054 和 2054）。

3 级和 4 级允许的组合：54-61、56-61 和 54-62。

表 1: Rosemount 228 环形电导率传感器订购信息内容概述.......................................................................................................................................................................................................2订购信息...............................................................................................................................................................................................2技术规格...............................................................................................................................................................................................3尺寸图...................................................................................................................................................................................................6附件.. (11)2023 年 五月/Rosemount2023 年 五月不适用于选项 -50-62 和 -54-62。

Technical Data 7220X7220XData Retention parameters and calibration data > 10 years (EEPROM)in Case of Power Failure logbook, statistics, cal record > 1 year (lithium battery)clock, reserve power > 1 year (lithium battery)no battery replacement required (according to NAMUR3)NE 32)Explosion Protection 7220X EEx ib [ia] IIC T6, PTB No. Ex–96.D.2172RFI Suppression to EN 50 081-1 and EN 50 081-2Immunity to ESD to EN 50 082-1 and EN 50 082-2 and in accordance withNAMUR3) -NE 21 EMC recommendation for process andlaboratory control equipmentEnvironmental Temperature operation4) –20 to +50 °Ctransport and storage –20 to +70 °CEnclosure case with separate terminal compartment,suitable for outdoor mountingmaterial: acrylonitrile butadiene styrene (ABS), front: polyesterIP65 protectionCable Glands 5 Pg 13.5 threaded cable glandsDimensions refer to dimension drawingWeight approx. 1.5 kg3) German committee for measurement and control standards in the chemical industry.4) At ambient temperatures below 0 °C the readability of the display may be reduced, however the unit functions are not impaired. Concentration ChartTerminal AssignmentsCertificates 7220Xinput2-/4 electrode sensorDimension Drawings 7220Xcontrol panelterminal compartmentPG 13,5 (5 pieces)for vertical or horizontal posts or pipesZU 0125 bracket kitZU 0136 mounting plateZU 0157 protective hoodZU 0157 protective hood, ZU 0136 mountingplate ZU 0125 bracket kitholes for wall mountingNote: all dimensions in millimetersfront removable forinstrument installationprotective cover, transparent Pg 13,57220X Unit with lockable control-panel cover (Opt. 432)protective cover,transparentcontrol panelterminal compartmentPG 13,5 (5 pieces)protective caseZU 0158 protective case forvertical or horizontal postsor pipes。

CX100 Loop-Powered Contacting Conductivity TransmitterSpecificationsConductivity Ranges: R1: 0-19.99 µS/cm, 0.01 µS/cm resolutionR2: 0-199.9 µS/cm, 0.1 µS/cm resolutionR3: 0-1999 µS/cm, 1µS/cm resolutionR4: 0-10.00 mS/cm, 0.01 mS/cmresolutionR5: 0-19.99 mS/cm, 0.01 mS/cmresolutionR6: 0-199.9 mS/cm, 0.1 mS/cm,resolutionCell Constants k=0.1, R1-R5k=1.0,R1-R6k= 10.0, R2-R6Accuracy ±1% of full scale reading in respectiverangeTemperature 0 °C to 100 °C (32 °F to 212 °F) Temperature Resolution 0.1 °C (0.1 °F)Relative Temperature Accuracy ±0.5 °C (±0.9 °F)Sensor Pt100 (3 wire / 2 wire)Temperature Compensation Auto/ManualOutput 4.0-20.0mA (Galvanically isolated)Cell Constant User-Selectable (0.10 to 10.00)Temperature Coefficient 0 to 10% (selectable) Normalization Temperature 20.0 °C to 25 °CDisplay Dual Display Custom LCDPower Requirements 12 to 24V DC, maximum 600 Ohm load Dimension 96 x 96 x 66 mm (3.78 x 3.78 x 2.6 inch) Weight 210 g Six selectable conductivity ranges for a wide range of measurementsIsolated Output prevents output interference caused by electrical noise or leakage from the input source Out-of-range Output Current Indicator indicates an out-of-range measurement by emitting a 3.8mA output currentHold Output Current Indicator to indicate ‘HOLD’ mode during calibration or set up mode.Scaleable 4-20 mA Current OutputPrimary and secondary display for simultaneous display of Conductivity and Temperature valuesEasy Push Button OperationAutomatic (with Pt 100) or manual Temperature CompensationPanel or Wall Mount, Nema 4x, IP65 Weatherproof HousingThis isolated output 4-20mA industrial transmitter, a sturdy microprocessor-based instrument, measures conductivity and temperature. It transmits conductivity measurements via a two-wire power supply loop. The industrial transmit-ter has many user friendly features—all of which are easily accessible via the water resistant membrane keypad. Ideal for connecting to a PLC for advanced control systems, the transmitter can also be connected to a recorder for a low-cost documentation system. The instrument housing is designed for panel or wall mounting.11751 Markon Dr.Garden Grove, CA 92841 USA Tel: 714-895-4344 Fax: 714-894-4839E-mail:*****************Ordering InformationPart number Description CX1001/4 DIN, 2-wire, loop-powered, 4-20mA, contacting conductivity transmitterCX100 Loop-Powered ContactingConductivity Transmitter。

环形电导率传感器⋅非接触（环形）电导率传感器－抗腐蚀，防堵；⋅可用于浓度测量－酸液、碱液和含盐溶液的浓度测量；⋅多种安装方式可供选择－沉浸式、插入式和流通式；⋅与分析仪器的适配性－可以与Rosemount Analytical的所有环形电导率分析仪器配套使用；⋅卫生型传感器225－满足3A卫生标准。

性能和应用Rosemount Analytical的环形电导率传感器适合于腐蚀性强和容易产生堵塞的溶液测量。

环形（电感应）电导率传感器的测量原理采用一对线绕金属环形线圈，传感器的电极与过程是完全隔离的。

两个线圈，一个作为发送器，另一个作为接收器。

当给发送器线圈通电时，则电解质溶液导电产生感应电流，该感应电流与溶液的电导率成正比，接收器线圈检测该电流的大小，从而求出溶液的电导率值。

225、226和228环形电导率传感器是将两个线绕金属环形线圈定制在具有防腐性能的PEEK或Tefzel环形模具中。

222环形电导率传感器的结构则稍有不同，其也有发送器和接收器两个线圈，但这两个线圈是装在内衬聚四氟乙烯的短管内，工艺介质从短管中流过。

由于环形线圈不是直接插入被测溶液中，因此，要求用外部接线把电路接通。

所谓外部接线就是用短接片连接两个金属环。

金属环即是环形电导率传感器的两个工作线圈，同时也与工艺介质接触，短接片起连通线圈的作用。

对于222传感器，接触线圈就是传感器与工艺过程管线连接的法兰。

环形电导率传感器适用于高电导率检测，最高可以测量0-2S/cm（0-2,000,000µS/cm），而最低检测值则取决于传感器圆环的大小和环上缠绕的线圈数，最低检测值范围为50至500µS/cm。

环形电导率传感器的测量值与溶液的流速和流向无关，但一定要保证传感器的环形孔不能堵。

200系列环形电导率传感器可以与Rosemount Analytical的所有环形电导率分析仪器配套使用。

所有传感器均内置测温热电阻，其对电导率的检测值进行温度补偿。

General电导率 EXA SC Specifications 探头/传感器■ 概要YOKOGAWA 提供监测或控制液体和溶液中电导率值的优良的在线分析仪器。

现在，YOKOGAWA 提供四线制电导率控制器（SC402G ），两线制电导率变送器（SC200、SC202）和盘装式的电导率控制器（SC150）。

当使用控制器或变送器时，为了能精确地测量液体电导率值，YOKOGAWA 也将提供各种传感器。

YOKOGAWA 的控制器/变送器与其传感器相结合可满足苛刻的要求。

YOKOGAWA 的仪器除可以进行标准电厂和化工应用方面传统的水质测量以外，还满足不断增长的半导体和医药等行业的超纯水需求。

■ 电导率传感器类型■ 传感器测量范围注意：在高电导率的液体或被污染的液体中使用，传感器有可能被极化。

极化可能降低被测量液的电导率值。

﹡四电极系统■技术参数1、 SC4A ：带针形接头的电缆（可用于SC150、SC402G 和SC202）测量对象：测量溶液的电导率值 测量原理：两电极系统 电极常数：0.02cm -1、0. 1 cm -1 测量范围：0.03-200μS/cm （电极常数：0.02cm -1） 0.2μS/cm -10mS/cm （电极常数：0. 1 cm -1） 温度范围：电极，0-100℃流通池，见图1电极消毒：在135℃（275℉）下蒸汽持续消毒30分钟。

压力范围：电极，0-1MPa流通池，见图1图1 流通池（选项：/PS、/PF、/SA1、/SA2、/SB1、/SB2、/SC1）温度和压力的容许值范围样液条件：虽然在测量时没有限制流速，要获得正确的测量值，气泡不能混合在样液中。

温度电极：Pt1000材料：壳体和电极：SUS316L（用于所有支架型）或钛（仅适用于接头安装类型-AD），氟橡胶 O形圈。

绝缘材料：PEEK安装接头：聚偏二氟乙烯（仅用于/PF）或SUS316L（用于其它）重量：电极：·接头安装型{SC4A-S-AD- 09-002-05}约450g；·接头安装型（SC4A-S-AD-15-002-05）约520g；·焊接头型（SC4A-S-SA-NN- 002-0.5）约670g；·1-1.5"焊接夹型（SC4A-S-SB- NN-002-05）约550g；· 2"焊接夹型（SC4A-S-SC-NN-002-05）约670g。

PHE-7352-15是一款组合pH 传感器，可在需要更多管路进入的工艺及废水应用中插入使用。

外部壳体材料为PPS ，前后端具有3⁄4 MNPT （或可选1 MNPT ）的表面螺纹，插入深度为57.1 mm (21⁄4")。

该传感器的特点是具有密封的双液接结构，对能产生电极污染的溶液（通常指那些含有浓度较大的氰化物、氨、硫和重金属的溶液）具有高耐受性。

传感器采用具有专利的无污垢可渗透PTFE 液接，可确保参比电解质的稳定表现。

配合新型活塞式pH 玻璃电极设计，该传感器可确保在大多数应用中保持低维护率和较长使用寿命。

在工作温度持续超过80°C (176°F)的情况下，建议使用高温型号。

规格pH 值范围：0 ~ 14 pH温度范围：0 ~ 80°C (32 ~ 176°F) 或0 ~ 110°C (32 ~ 230°F) （HT 高温款）压力范围：0 ~ 100 psig 或0 ~ 150 psig （HT 高温款），满量程b ±0.1%钠差：12.8 pH 时0.1摩尔的Na +离子溶液中低于0.05 pH 的误差阻抗：150 M Ω @ 25°C (77°F)参比室：双液接KNO 3和KCl/AgCl 零电势：7.0 pH ± 0.2 pH 接液材料：PPS 、PTFE 、氟橡胶、玻璃响应时间：95%的读数在10秒内漂移：每周<2 mV应用U 适用于恶劣条件U 大直径管路插入U 废水管路插入U 坚固的PPS 壳体U 低维护U 插入长度可短可长U 任意角度定位指定自动温度补偿传感器：请添加“-PT100”以获得100 Ω Pt RTD ，或添加“-PT1K ”以获得1000 Ω Pt RTD （需付额外费用）。

订购示例：PHE-7352-15-PT100-HT 是一款坚固耐用浸没式安装pH 传感器，带有“-HT ”（用于高温） 和 100 Ω Pt RTD ATC 。
