NE40E系列路由器典型业务配置

Product OverviewHuawei ® NetEngine40E Universal Service Router (NE40E) Series routers are high-end network products developed by Huawei. The NE40E Series routers are usually deployed at core nodes on enterprise wide area networks (WANs), access nodes on large-scale enterprise networks, interconnection and aggregation nodes on campus networks, and edge nodes on large-scale Internet Data Center (IDC) networks. The NE20E, NE40E, and NE5000E can work together to provide a complete hierarchical IP network solution.The NE40E Series includes the NE40E-X3, NE40E-X8, NE40E-X16, NE40E-X3A, NE40E-X8A and NE40E-X16A, as shown in Figure 1.Figure 1Huawei NE40E Series routers (Front)NE40E-X3 (DC)NE40E-X3 (AC)NE40E-X8NE40E-X16NE40E-X16A NE40E-X8ANE40E-X3A(DC)NE40E-X3A(AC)Figure 2Huawei NE40E Series routers (Back)NE40E-X3 (DC)NE40E-X3 (AC)NE40E-X8NE40E-X16NE40E-X16ANE40E-X8ANE40E-X3A(AC)NE40E-X3A(DC)The NE40E Series routers run on the Versatile Routing Platform (VRP ®) operating system and useHuawei-developed NP chips and hardware-based forwarding and non-blocking switching technologies. Based on distributed hardware forwarding, non-blocking switching technologies, distributed Clos architecture, and industry-leading 2T bps platform, the NE40E Series routers have the following features:●Support for 1T routing line cards in each slot, with excellent compatibility with currently used line cards toprotect carriers' investments to the largest extent.●Line speed forwarding capabilities, industry-leading reliability, excellent scalability, a well-designedquality of service (QoS) mechanism, and strong service processing capabilities.●Powerful service access and aggregation capabilities and various features, such as Layer 2 virtual privatenetwork (L2VPN), L3VPN, multicast, multicast VPN (MVPN), and Multiprotocol Label Switching - Traffic Engineering (MPLS-TE).●Various service features, such as IP Security (IPSec), Network Address Translation (NAT), and NetStream.●Support for IPv6 and smooth transition from IPv4 to IPv6.The NE40E can be flexibly deployed at the edge or core of IP or MPLS networks, simplifying network structure. With its ability to provide an extensive range of services and reliable service quality, the NE40E is driving IP and MPLS bearer networks to develop greater broadband capacity and to become more secure, more intelligent, and more service-oriented.Product FeaturesTable 1 lists the features of the Huawei NE40E Series Routers. Table 1.Features of Huawei NE40E Series RoutersProduct SpecificationsTable 2 lists the specifications of Huawei NE40E Series Routers. Table 2.Specifications of Huawei NE40E Series Routers1. In the physical dimensions shown in the table, the width (W) does not include the rack-mounting ears.2. Temperature and humidity are measured at 1.5 m (4.92 ft.) above the floor and 0.4 m (1.31 ft.) in front of the cabinet. Thereshould be no protection board on the front or back of the cabinet.3. "Short-term" refers to continuous working time that does not exceed 96 hours and accumulated working time per yearthat does not exceed 15 days. If the working time exceeds either of these values, it is considered "nominal" or "long-term".4.The bundle values in "Weight (full configuration)" include the weight of the interface boards in full configuration.Ordering InformationTo place an order, visit the UniSTAR SCT Workspace.Basic Hardware ConfigurationsTable 3.NE40E-X16A Basic Configuration BundleTable 4.NE40E-X8A Basic Configuration BundleTable 5.NE40E-X3A Basic Configuration BundleTable 6.NE40E-X16 Basic Configuration BundleTable 7.NE40E-X8 Basic Configuration BundleTable 8.NE40E-X3 Basic Configuration BundleTable 9.NE40E-X16A/X8A/X16/X8 PowersTable 10.NE40E-X3A/X3 PowersTable 11.CF/SDRAM/Other ComponentsService Interface BoardsTable 12.NE40E Series 50G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 13.NE40E Series 50G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 14.NE40E Series 120G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 15.NE40E Series 120G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 16.NE40E Series 200G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 17.NE40E Series 200G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 18.NE40E Series 240G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 19.NE40E Series 240G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 20.NE40E Series 480G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 21.NE40E Series 480G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 22.NE40E Series 1T Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 23.NE40E Series 2T Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Versatile Service BoardsTable 24.NE40E Series Service Process Units ("●" indicates "support", and "-" indicates "not support")Software ConfigurationTable 25.Software LicenseDocumentsTable 26.Documents for NE40EOptical/Electrical Transceivers Table 27.100G Optical TransceiverTable 28.50G Optical TransceiverTable 29.40G Optical TransceiverTable 30.FE/GE/10GE Optical TransceiverTable 31.622M SFP/eSFP Optical TransceiverTable 32.155M SFP/eSFP Optical TransceiverTable 33.GE CWDM Optical TransceiverTable 34.10GE CWDM Optical TransceiverPower Distribution BoxesTable 35.High-power distribution boxesBreakoutTable 36.100G QSFP28 Breakout BoxesTelescopic SlidesTable 37.Telescopic SidesSoftware Upgrade PathsVisit Software Upgrade Paths to get VRP software release version or patches.For More InformationFor more information about the Huawei NE40E Series Routers, visit or contact us in the following ways:●Global service hotline: /en/service-hotline●Logging into the Huawei Enterprise technical support web: /enterprise/●Sendinganemailtothecustomerservicemailbox:********************Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.Trademark Notice, HUAWEIandare trademarks or registered trademarks of Huawei Technologies Co., Ltd.Other trademarks, product, service and company names mentioned are the property of their respective owners.General DisclaimerThe information in this document may contain predictive statementsincluding, without limitation, statements regarding the future financial and operating results, future product portfolio, new technology, etc. There are a number of factors that could cause actual results and developments to differ materially from those expressed or implied in the predictivestatements. Therefore, such information is provided for reference purpose only and constitutes neither an offer nor an acceptance. Huawei may change the information at any time without notice.HUAWEI TECHNOLOGIES CO.,LTD.Huawei Industrial BaseBantian, LonggangShenzhen 518129, P.R. ChinaTel: +86-755-28780808。

Quidway NetEngine40E通用交换路由器操作手册 IP路由分册VRP5.30-31Quidway NetEngine40E通用交换路由器操作手册分册： IP路由分册资料版本： 03 (2006-09-12)产品版本： VRP5.30-31BOM 编码： 31161951华为技术有限公司为客户提供全方位的技术支持。

通过华为技术有限公司代理商购买产品的用户，请直接与销售代理商联系。

直接向华为技术有限公司购买产品的用户，可与就近的华为办事处或用户服务中心联系，也可直接与公司总部联系。

华为技术有限公司地址：深圳市龙岗区坂田华为总部办公楼邮编：518129网址：声明版权所有 © 华为技术有限公司 2006。

保留一切权利。

非经本公司书面许可，任何单位和个人不得擅自摘抄、复制本文档内容的部分或全部，并不得以任何形式传播。

商标声明和其他华为商标均为华为技术有限公司的商标。

本文档提及的其他所有商标或注册商标，由各自的所有人拥有。

注意由于产品版本升级或其他原因，本文档内容会不定期进行更新。

除非另有约定，本文档仅作为使用指导，本文档中的所有陈述、信息和建议不构成任何明示或暗示的担保。

前言版本说明本手册对应的产品版本为Quidway NetEngine40E通用交换路由器VRP5.30-31。

相关手册Quidway NetEngine40E通用交换路由器主要手册及用途如下：手册名称用途《Quidway NetEngine40E通用交换路由器安装手册》介绍NE40E路由器的安装，包括机柜和设备的安装、线缆的安装与布放、设备的启动与配置介绍，硬件维护及标签制作规范、接地规范等内容。

《Quidway NetEngine40E通用交换路由器设备手册》 介绍NE40E设备，包括：设备简介、电源模块、散热系统、液晶显示模块、单板和设备线缆和一些附录。

《Quidway NetEngine40E通用交换路由器操作手册系统分册》介绍系统管理和可靠性的配置，包括搭建配置环境、基本配置、用户登录、文件管理、系统维护、NTP、SNMP、HWPing、RMON和RMON2、BFD、VRRP和HA，并提供缩略语。

NE40E简介及维护NE5000E/NE80E机箱36U（1U=44.45mm）高，外形尺寸为442mm×669mm×1600mm（宽×深×高）。

NE40E全业务路由器是华为公司面向新一代万兆级边缘交换路由器。

NE40E 的操作系统采用功能强大的通用路由平台VRP（Versatile Routing Platform）操作系统，具有超大容量、高性能和高可靠性的特点。

NE40E提供了功能强大的监控系统。

LPU为接口线路板,路由交换板SRU （Switch and Route Unit）上的主控模块MPU（Main Processing Unit）可实现对整个系统的管理维护。

主控模块可实现对单板、风扇模块、电源模块和时钟模块的管理、监控和维护。

NE40E完全满足EMC（Electro Magnetic Compatibility）要求，整个系统采用模块级设计。

并且每个拉手条采用整体钢板设计，实现了单板间的EMC隔离。

NE40E包括NE40E-8和NE40E-4两款产品。

NE40E-8外形尺寸为442mm×669mm×886mm（宽×深×高）;NE40E-4外形尺寸为442mm×673mm×442mm（宽×深×高）.防尘网主要作用是为机框内部各组件的散热进风提供灰尘过滤功能。

NE5000E/80E/40E系列路由器在进风框和电源面板安装有防尘网，二者的维护方法相同。

为了保证系统散热和通风状况良好，避免防尘网被灰尘堵住，必须定期清洗防尘网。

建议至少3个月定期清洗一次，机房防尘环境较差的清洗频率应更高。

一、查询新更换风扇的运行状态:<Quidway> display fanSlotid : 19Present : YESRegistered: YESStatus : MANUALFanSpeed : [No.]Speed[1]100% [2]100%如果显示信息如上，则表示新风扇框的功能已经恢复正常。

NE40E配置４、MPLS配置mpls lsr-id 61.177.248.3 LSR ID使用IPv4地址格式，在MPLS域内唯一mpls 使能本节点的MPLSmpls ldp使能本节点的LDPinterface Pos1/0/1mpls 使能接口的MPLSmpls ldp 使能接口的LDP５、MPLS/BGP VPN配置ip vpn-instance edu 创建VPN实例，并进入VPN实例视图route-distinguisher 61.177.248.3:1 配置VPN实例的RDvpn-target 1000:10 export-extcommunity 为VPN实例创建VPN-target扩展团体vpn-target 1000:10 import-extcommunityinterface GigabitEthernet2/0/0ip binding vpn-instance edu 将当前接口与VPN实例关联ip address 10.1.0.2 255.255.255.0bgp 64522 配置PE-PE间使用MP-IBGP，PE之间必须使用32位掩码的Loopback 接口地址来建立MP-IBGP对等体关系，以避免由于路由聚合导致报文不能找到正确的路由。

到Loopback接口的路由通过MPLS骨干网上的IGP发布给对端PEipv4-family vpnv4policy vpn-target 缺省对接受到的vpnv4路由进行过虑，作为ASBR时，应禁止过虑。

peer 61.177.248.2 enable 使能对等体交换VPN-IPv4路由信息，会引起BGP会话重建立，取消也会引起BGP会话重建立，影响到用户的路由发布。

peer 61.177.248.1 enable配置PE-CE间使用静态路由，直连路由bgp 64522ipv4-family vpn-instance edunetwork 0.0.0.0 如需上公网，华为BGP 不把缺省路由当静态，需另发布一条。

NE40E全业务路由器NE40E全业务路由器产品概述NetEngine40E系列全业务路由器（以下简称NE40E）是华为公司推出的高端网络产品，主要应用在IP骨干网、IP城域网以及其他各种大型IP网络的边缘位置，与NE5000E、NE80E核心路由器产品配合组网，形成结构完整、层次清晰的IP网络解决方案。

NE40E基于分布式的硬件转发和无阻塞交换技术，具有良好的线速转发性能，优异的扩展能力，完善的QoS机制和强大的业务处理能力。

NE40E基于最新的可扩展400G平台，实现到400G/slot的平滑扩展，且兼容现网所有线卡，最大限度保护客户的投资。

NE40E具有强大的汇聚接入能力，凭借丰富的特性支持，可以灵活部署L2VPN、L3VPN、组播、组播VPN、MPLS TE、QoS等，实现业务运营级的可靠承载；支持视频增强功能，快速频道切换（FCC）、丢包重传（RET）和实时的视频监控极大提升IPTV视频业务体验；同时，NE40E全面支持IPv6，可以实现IPv4到IPv6的平滑过渡。

因此，NE40E可以灵活应用在IP/MPLS网络的边缘、核心，可以简化网络结构，提供丰富的业务类型和可靠的服务质量，是IP/MPLS承载网向宽带化、安全化、业务化、智能化发展的重要源动力。

外观NE40E系列主要包括NE40E-X16、NE40E-X8和NE40E-X3，适应不同规模的网络组网需求。

N E40E-X16N E40E-X8N E40E-X3产品特点领先的400G平台NE40E系列节能减排机框基于400G平台，每槽位可以平滑扩容到400Gbps带宽，提供100G单板，实现大容量业务承载，满足未来带宽增长需求。

同时NE40E系列基于现有VRP软件平台，完全兼容现网所有线卡，充分利旧，最大限度保护客户的投资。

整机采用高密度端口、紧凑性设计，可以有效的节省空间。

绿色的设计理念NE40E整机采用完全绿色的设计，更加环保节能。
