1.目的规范仪器操作程序和日常维护,指导操作人员正确使用仪器,保证检测工作顺利进行。
2.适用范围适用于本实验室赛默飞ICAP PRO X(ICP-OES)仪器的使用操作。
3.职责3.1操作人员按照本作业指导书操作仪器,对仪器进行日常维护。
3.2保管人员负责监督仪器操作是否符合规程,对仪器进行定期维护、保养。
3.3科室负责人要加强本科室检测设备管理,严格落实检测设备管理责任制。
4.操作程序4.1开机4.1.1 开总电源,开稳压器(220V);电电脑,开仪器电源(在仪器右后方);insrument status灯闪烁;4.1.2 打开软件,界面显示彩色为正常(显示灰色很可能为连接不正常),开氩气(压力在0.55-0.60MPa,并确认氩气罐内剩余气量是否足以支持实验的进行),等1h驱气;4.2点火4.2.1 再次确认氩气是否开够1h,再次确认氩气是否充足;4.2.2 打卡排风(排风风量为1.0-1.4m/s,一般已调整设置好,只需要检查软件-控制面板-排风信号灯是否为绿色,若不是绿色才需要进行调整);打开循环冷水机(水位在80%,水质用RO一级水,温度设置在20-22度,压力在0.3-0.4MPa);注意水机需要等待温度达到设定的才能进行点火操作;4.2.3 卡住泵管(可以设置载气流量为0.5L/min,泵速为45rpm,通过观察进样针是否正常进样、废液管是否正常排液来确认是否卡号;另外需观察主要对应的卡环,共有三道,左右方向要在一个道内,最后主要扳下卡环卡紧,同时要注意泵管进出方向是否对;4.2.4 点击软件的点火图标(控制面板正中间),点火(立即在窗口观察火焰颜色,绿色为正常,出现其他颜色火焰应立即打开炬室门关火),预热30min;中间稍微停顿可以预热15min,停顿时间更短可以预热5min;观察软件,当所有标示为绿色时,可以进行测样操作;4.3建立仪器方法4.3.1 点击软件中LabBooks,依次输入名称、选择位置,点击选择从空白中创建一个新的LabBook选项,在评价中选择eQuant,点击创建;4.3.2 点击方法参数中的分析物,选择分析元素(以下元素选用仪器推荐波长Cr:267nm;Na:589nm;Mg:285nm;Ca:422nm;Al:167nm或396nm)其他元素选用仪器默认设置即可 4.3.3 点击方法参数中的采集参数,选择相应的等离子体观测方式(水平或垂直,水平的优势检出限更低,更灵敏;垂直的优势是干扰更少)4.3.4 点击方法参数中的标准,点击新建,选择元素标准,输入标准名称,选择使用分析物列表创建标准,点击确定;4.3.5 如果使用内标,则执行此步骤,如不使用内标则跳过此步骤。
