浙大中控主推Web Fieid JX-300XP 和利时主推HOLLiAS MACS硬件方面主控制器:和利时,冗余配置,单CPU设计,工业级嵌入式芯片。
掉电保功能,无扰切换功能。
贴片化设计,主控支持热插拔,机笼式无风扇设计。
系统网络,控制网络,主从控制,运行故障指示诊断功能。
外部主控地址设置功能。
面板系统程序清零功能。
在线手动主控切换功能。
浙大中控,冗余配置,主从CPU设计,工业级嵌入式芯片。
掉电保护功能,无扰切换功能。
贴片化设计,主控不支持热插拔,板卡式无风扇设计。
故障报警或复位,工作卡件运行,工作/备用,准备就绪,备用卡件运行,通讯网络端口0的通讯状态,通讯网络端口1的通讯状态,Slave CPU运行,网络通信和I/O采样运行指示。
I/O卡件:浙大中控,主控和现场I/O中间存在数据转发卡,所有卡件为贴片化,板卡设计。
模拟量卡件是否配电,卡件地址跳线设置集成于板卡上。
和利时,主控通过PROFIBUS –DP直接与现场I/O卡件相连,FM型卡非贴片化设计,SM和核电专用卡为贴片化设计。
所有卡件均为模块化设计。
模块底坐拔码设定卡件地址。
通讯方面WebField JX-300XP系统采用三层网络结构:第一层网络是信息管理网Ethernet(用户可选)采用以太网络,用于工厂级的信息传送和管理,是实现全厂综合管理的信息通道。
通讯速率100Mbps。
第二层网络是过程控制网SCnetII 连接了系统的控制站、操作员站、工程师站、通信接口单元等,是传送过程控制实时信息的通道。
通讯速率100Mbps。
第三层网络是控制站内部I/O控制总线,称为SBUS 控制站内部I/O控制总线。
主控制卡、数据转发卡、I/O卡件都是通过SBUS进行信息交换的。
SBUS总线分为两层:双重化总线SBUS-S2通讯速率1Mbps和SBUS-S1通讯速率156Kbps网络。
主控制卡通过它们来管理分散于各个机笼内的I/O卡件。
HOLLiAS MACS系统采用四层网络结构第一层网络是信息管理网,通过实时关系数据库与系统服务器,采用以太网络通讯,通讯速率100Mbps。
和利时三取二逻辑模块(原创实用版)目录1.和利时三取二逻辑模块的概述2.和利时三取二逻辑模块的工作原理3.和利时三取二逻辑模块的应用领域4.和利时三取二逻辑模块的优势与不足5.总结正文一、和利时三取二逻辑模块的概述和利时三取二逻辑模块是一种数字逻辑电路,它的主要功能是实现“与”、“或”和“非”三种基本逻辑运算。
在实际应用中,它可以用于各种电子设备和计算机系统,以实现对信号的控制和处理。
和利时三取二逻辑模块具有较强的通用性和灵活性,可以满足不同领域的应用需求。
二、和利时三取二逻辑模块的工作原理和利时三取二逻辑模块的核心部分是逻辑门电路。
逻辑门电路是数字逻辑电路的基本组成单元,它可以实现特定逻辑功能。
和利时三取二逻辑模块主要由以下三种逻辑门电路组成:1.与门:实现逻辑运算“与”。
当所有输入信号都为 1 时,输出信号为 1;否则,输出信号为 0。
2.或门:实现逻辑运算“或”。
当任意一个输入信号为 1 时,输出信号为 1;只有当所有输入信号都为 0 时,输出信号才为 0。
3.非门:实现逻辑运算“非”。
它只有一种输入信号,即输入信号本身。
当输入信号为 1 时,输出信号为 0;当输入信号为 0 时,输出信号为 1。
通过不同逻辑门电路的组合,和利时三取二逻辑模块可以实现各种复杂的逻辑运算。
三、和利时三取二逻辑模块的应用领域和利时三取二逻辑模块广泛应用于以下领域:1.电子设备:用于实现对电子设备的控制和信号处理,例如计算机、通信设备、家电等。
2.计算机系统:作为计算机系统的基本逻辑组件,实现对计算机系统中数据的运算和处理。
3.工业自动化:在工业自动化领域,和利时三取二逻辑模块可以用于实现对生产线的自动控制,提高生产效率。
4.科研领域:在科研领域,和利时三取二逻辑模块可以作为数字逻辑电路的研究平台,助力科研人员进行相关研究。
四、和利时三取二逻辑模块的优势与不足1.优势:(1)通用性强:和利时三取二逻辑模块可以实现多种逻辑运算,具有较强的通用性。
HOLLiAS MACS V6 K系列硬件杭州和利时培训部学习目标熟悉K系列硬件的特点和使用方法。
掌握K系列硬件在实际项目中的配置。
目录一、系统概述四、I/O单元二、主控单元三、控制柜供电六、相关说明五、系统接地系统概述系统概述1.控制站规模2.硬件简介系统概述1.控制站规模单个现场控制站规模:I/O模块数:100个(MAX) I/O点数:1280点控制回路数:300个,其中模拟量控制回路数量≤1282.硬件简介MACS-K硬件采用模块式结构、DIN35标准导轨安装,可适应各种尺寸类型的机柜。
机柜正面机柜背面2.硬件简介◆机柜MACS-K硬件采用模块式结构、DIN35标准导轨安装,可适应各种尺寸类型的机柜。
主机柜型号:KP104-A2辅助柜型号:KP502-A2现场控制站2.硬件简介◆控制单元现场控制站的核心控制器采用“背板+模块”单元设计,1个控制器背板上可以插2个控制器和2个控制网连接模块。
◆ I/O 单元I/O模 块I/O 单元I/O 底 座2.硬件简介2.硬件简介◆总线复合电缆连接复合电缆中包含系统电源总线、现场电源总线、控制网通讯总线。
主控I/O 模块选用不同的控制网连接模块,网络拓扑结构可以实现星型和总线型。
2.硬件简介◆总线复合电缆连接星型 K-BUS02总线型 K-BUS03◆ 操作员站、现场控制站、IO 模块的地址如何设置,在什么硬件设备上实现?◆ 系统网和控制网的通讯协议和通讯介质?◆ 在K 硬件构成的现场控制站中,哪部分作为DP 从站? 请回答前两个问题,并带着第三个问题展开后续学习思考主控单元1.概述2.K-CUT01 4槽底座3.K-CU01 控制器4.IO-BUS 模块主控单元1.概述“背板+模块”主控单元是现场控制站的中央处理单元,主要承担本站的部分信号处理、控制运算、与上位机及其它单元的通讯等任务。
1.概述◆相关产品型号说明2.K-CUT01 4槽底座◆K-CUT01 外观与接口2.K-CUT01 4槽底座 K-CUT01 技术指标2.K-CUT01 4槽底座支持插装4个模块,并为通讯及电源提供外接接口。
和利时DCS模块使用说明FM802(一组2个)-------------DPU。
FM301---------------------------控制器底座。
FM910---------------------------冗余电源模块,每个控制器底座上6个。
FM931---------24V查询电源模块(给DI模块外部供电)SM911---------冗余电源模块,24VDC,给模块供电,一列为一组电源。
理解:每个控制器底座上6个FM910,共3组电源。
对于扩展柜,需要安装6个SM911模块,也分为3组,给柜内模块供电,一组正面,一组反面,另一组给FM931,以及剩余的DI模块查询电源使用(这里需要加保险丝段子)。
FM171-------------16路触点型开关量输出模块(DO模块)FM138--------------16路继电器模块(DO模块)FM131-E----------电缆连接型端子底座(DO模块)FM192A-TR-------------DP终端电阻FM131A------------------普通端子底座(DI,AI,AO,TC,RTD)FM192B-CC--------------热电偶冷端补偿模块(TC)FM1201--------------------DP总线模块(中继器)FM1303--------------------DP总线模块底座(中继器)FM148A--------------------8路模拟量输入模块(AI)FM151A---------------------8路模拟量输出模块(AO)FM143------------------------8路热电阻输入模块(RTD)FM147------------------------8路热电偶输入模块(TC)FM161D--------------------16路开关量输入模块(DI)具体接线说明:FM148A/FM131A-----------8通道模拟量输入模块(AI)每个通道占用4个端子,合计4×8=32个端子。
和利时新一代DCS—K系列硬件产品应用优势李秋香【摘要】HangzhouHollysys Automation Co.,Ltd.summary years of hardware development and project experience,independent research and development of a new generation of DCS hardware - K series modules,the concept of innovation in product,technology advanced,reliable application, in the actual project site use give full play to the performance advantages of its, has been well received by the majority of users.%杭州和利时自动化有限公司总结多年的硬件开发及工程项目经验,自主研发出了新一代DCS硬件——K 系列模块,其产品理念创新,技术先进,应用可靠,在实际的现场项目使用中充分发挥了其性能优势,得到了广大用户的好评.【期刊名称】《电子测试》【年(卷),期】2015(000)015【总页数】3页(P89-91)【关键词】DCS控制系统;K系列模块;可靠性;安全【作者】李秋香【作者单位】杭州和利时自动化有限公司,杭州,310018【正文语种】中文SM系列硬件是和利时公司于2002年推出的产品,经过十多年的发展,有一些设计理念已经滞后,因此HOLLiAS MACS—K系列DCS是在分析工业自动化技术发展的基础上,明确了新一代工业自动化控制系统的发展方向,充分考虑了流程企业需求,总结完善以往工程经验,进行产业化升级而形成的第四代大型综合DCS控制系统。
K系列硬件模块在2013年经过德国莱茵检测认证中心的认证,获得了CE证书。
HOLLiAS MACS-K Series DCS Hardware SpecificationVersion 1.1April 2013CONTENTS1.Overview (1)1.1.Features (1)1.2.System Architecture (3)1.3.System Specifications (4)1.4.Hardware Design (5)2.Controller (10)2.1.Overview (10)2.2.K-CU01 Controller (10)3.I/O Unit (12)3.1.Overview (12)3.2.K-AI01 8-Channel AI Module (15)3.3.K-AIH01 8-Channel AI Module with HART (16)3.4.K-RTD01 8-Channel RTD Module (17)3.5.K-TC01 8-Channel TC Module (18)3.6.K-AO01 8-Channel AO Module (19)3.7.K-AOH01 8-Channel AO Module with HART (20)3.8.K-DI01 16-Channel 24VDC DI Module (21)3.9.K-DI11 16-Channel 48VDC DI Module (23)3.10.K-SOE01 16-Channel 24VDC SOE Module (24)3.11.K-SOE11 16-Channel 48VDC SOE Module (25)3.12.K-PI01 8-Channel PI Module (26)3.13.K-DO01 16-Channel 24VDC DO Module (27)4.Fieldbus Communication Unit (29)4.1.Overview (29)4.2.K-MOD01 DP/Modbus Communication Module (30)4.3.K-PA01 Profibus-DP/PA Communication Module (31)4.4.K-DP02 Profibus-DP Y-Link Gateway Module (32)1. Overview1.1. FeaturesHOLLiAS MACS-K offers customers a reliable and highly flexible DCS solution which meets the demands of different industrial applications.High Reliability•Full RedundancyRedundant configuration is available in every aspect,from the system network (SNET), control network(CNET), power supply, controller to the I/O modules,protecting the system against any single-point failure.•Multiple IsolationSystem power and the field power are suppliedseparately; the module communication is isolatedoptically from the field signal; and galvanic isolation isprovided between the I/O channels.•Harsh Environment AdaptabilityThe system is built to perform under harsh industrial environment, with the EMC requirements compliant with IEC 61000 and the airborne contaminants level satisfying ISA S71.04 G3.•Real-time and Secure NetworkThe Deterministic Real-time Industrial Ethernet is adopted in the system network (SNET), and anti network-storm components are equipped inside the controller.•Comprehensive DiagnosticsComplete self-diagnostics are conducted by the controller and I/O modules all the time. All types of faults, such as communication failure, open wire, short circuit and over range, can be detected and reported to the operator in a timely manner.•Fail-safe ConceptsSignal quality is verified before logic calculation; output can automatically switch to the pre-defined safe value when failure occurs; multiple digital bits are used to represent 0/1 to detect and screen the memory error under extreme environment. Fail-safe design is implemented throughout the system.Ultimate Flexibility•P-to-P (Peer to Peer), C/S (Client/Server), or hybridsystem architecture can be selected to meet theneeds of both large and medium/small applications.•HART, PROFIBUS-DP, PROFIBUS-PA, MODBUSand other fieldbus protocols are supported tointegrate intelligent devices.•HollySys legacy I/O modules are fully compatible tohelp upgrade the legacy systems risk-free andcost-effectively.•HOLLiAS AMS (Asset Management System), BATCH, APC (Advanced Process Control), SIS (Safety Instrumentation System), MES (Manufacturing Execution System), OTS (Operator Training System) and other HollySys products can be seamlessly integrated with HOLLiAS MACS-K, so as to offer a total automation solution•Programming language is compliant with IEC61131-3, and user-defined function blocks, symbols and scripts are supported.•Hardware hot-swap and logic online change provide the customers with the easy and safe maintenance method without any stop or disturbance to the process.1.2. System ArchitectureHOLLiAS MACS-K consists of 3 layers of network: the management network (MNET), the system network (SNET) and the control network (CNET).System ArchitectureThe management network (MNET) is used to communicate with the plant-level management systems and publish information through INTERNET with security control.The system network (SNET) connects the Engineering Station, the Operator Station, the Field Control Station and other system nodes. P-to-P (Peer to Peer), C/S (Client/Server) or hybrid system architecture can be selected according to the project scale; star and ring topology is available for 100/1000Mbps redundant network.The control network (CNET) is the link between controller, I/O modules and intelligent devices. Star and bus topology is supported in compliance with IEC 61158/EN 50170 to ensure the reliable, real-time and fast field communication.1.3. System Specifications1.4. Hardware DesignHOLLiAS MACS-K adopts modular structure and DIN35 standard rail installation, applicable to different sizes of cabinets.Front View of Cabinet Rear View of CabinetController2 controllers and 2 K-BUS modules can be inserted into the 4-slot controller baseplate to realize redundant configuration.The controller baseplate can be mounted on the top of the cabinet, linking the I/O modules through K-BUS cables.4-Slot Controller BaseplateK-BUS2 redundant K-BUS cables link the controllers and I/O modules, in each of which there’re system power bus, field power bus and CNET communication bus. Thus the system power supply, the field power supply and the CNET communication are all redundant to each I/O module.The redundant K-BUS cables are drawn from the redundant K-BUS modules. Each K-BUS module has 6 interfaces to connect the local I/O modules, each interface connecting 1 column I/O modules (up to 10 modules per column).Besides, there is an extension interface to connect the remote I/O modules in expansion cabinets.There are 2 types of K-BUS modules, realizing star and bus topology respectively.•K-BUS02 Star-type K-BUS ModuleK-BUS02 is applicable to large/medium control stations. It can utilize all the 6 local interfaces to connect 60 local I/O modules, and the extension interface to connect another 40 remote I/O modules. K-BUS02 converges the 7 connections into a star topology.•K-BUS03 Bus-type K-BUS ModuleK-BUS03 is a cost-effective choice for small control stations within 30 I/O modules. It supports up to 3 local interfaces to connect up to 30 I/O modules, linking the 3 connections toa bus topology.Star-type Linking and ExtensionI/O UnitEach K series I/O unit consists of one I/O module and one terminal base.The I/O module realizes the main I/O functions, such as A/D conversion and signal conditioning.The terminal base is used to connect field wires and provide different auxiliary functions such asredundancy, misconnection protection and DB37 interface.I/O UnitThere are three types of K series terminal bases available.K Series Terminal BasesThe dimensions of the non-redundancy types are the same, measuring the length of 120mm. The length of redundancy type base is 240mm, double of that of non-redundancy type.The three types of terminal bases allow for flexible wiring, while the field signals can be wired to the terminals directly, or connected through expansion terminal blocks via DB37 interface.2. Controller2.1. Overview2.2. K-CU01 Controller⏹Features•Hot-standby redundancy guarantees the seamless switchover without any disturbance to the field.•Fully compatible with HollySys FM and SM series I/O modules to make the upgrade risk-free and cost-effectively.⏹Specifications3. I/O Unit3.1. OverviewAll the I/O units of K series are designed with the following features which deliver customers fast field engineering and easy maintenance:•1:1 RedundancyRedundancy can be realized by simply inserting a pair of I/O modules on the redundant terminal base, no extra configuration needed.•Power Supply IsolationThe system power and field power are supplied separately. The field interferences will not influence the system calculation and communication.•Powerful Fault DiagnosticsOpen wire, short circuit, over range, auxiliary power failure and other faults can be quickly detected and reported to the operator.•Comprehensive LED IndicatorsThe running status such as power supply, communication and channel faults are displayed to users in an intuitive way.•Protection KeysProtection keys are designed to prevent the installation of mismatching I/O module and terminal base.•Optimized Structure DesignThe vertical mounting is convenient for terminal wiring, while the tilted module insertion creates air channels for fast heat dissipation in the enclosure.•Hot SwapAll modules can be removed and replaced without the need to stop the process.I/O Unit ListNote:K-DOT01 is the universal terminal base providing DB37 interface.DI/DO units with K-DOT01 can connect to expansion terminal blocks (K-DIR01, K-DIR03, K-DOR) via the DB37 interface on it, realizing relay or high voltage signal input/output.AI/AO units can also utilize K-DOT01 for easy connection with safety barriers in the remote cabinets.3.2. K-AI01 8-Channel AI Module⏹Features•Supports 2-wired and 4-wired transmitters.•Channel over-voltage protection up to 220VAC.•Individual input filtering parameter can be set for each channel.•Supports NAMUR limit detection.⏹Specifications3.3. K-AIH01 8-Channel AI Module with HART⏹Feature•Supports 2-wired and 4-wired transmitters.•Channel over-voltage protection up to 220VAC.•Individual input filtering parameter can be set for each channel.•Supports HART protocol.⏹Specifications3.4. K-RTD01 8-Channel RTD Module⏹Feature•Supports 2-wired, 3-wired and 4-wired input.•Individual input filtering parameter can be set for each channel.⏹Specifications3.5. K-TC01 8-Channel TC Module⏹Features•Built-in Pt100 inside the terminal base for cold-junction compensation.•Channel over-voltage protection up to ±10VDC.•Individual input filtering parameter can be set for each channel.⏹Specifications3.6. K-AO01 8-Channel AO Module⏹Features•Channel over-voltage protection up to 220VAC.•Individual fault output value can be configured for each channel. The output will keep the last state or set to the pre-defined safe value if there’s a failure.⏹Specifications3.7. K-AOH01 8-Channel AO Module with HART⏹Features•Channel over-voltage protection up to 220VAC.•Individual fault output value can be configured for each channel. The output will keep the last state or set to the pre-defined safe value if there’s a failure.•Supports HART protocol.⏹Specifications3.8. K-DI01 16-Channel 24VDC DI Module⏹Features•Relay input or high voltage input (110V/220V AC and 110V/220V DC) can be connected in through expansion terminal block.•Channel over-voltage protection up to 220VAC.⏹SpecificationsExpansion Terminal BlockRelay input or high voltage input (110V/220V AC and 110V/220V DC) can be connected through expansion terminal block, which connects the terminal base via DB37 interface.3.9. K-DI11 16-Channel 48VDC DI Module⏹Features•Channel over-voltage protection up to 220VAC.⏹Specifications3.10. K-SOE01 16-Channel 24VDC SOE Module⏹Features•1ms SOE resolution.•Channel over-voltage protection up to 220VAC.⏹Specifications3.11. K-SOE11 16-Channel 48VDC SOE Module⏹Features•1ms SOE resolution.•Channel over-voltage protection up to 220VAC.⏹Specifications3.12. K-PI01 8-Channel PI Module⏹Features•Supports frequency measuring and counting function.•Supports active and passive pulse signals.⏹Specifications3.13. K-DO01 16-Channel 24VDC DO Module⏹Features•Various DO types are supported: normally open (NO) and normally closed (NC), dry contact and wet contact.•Expansion terminal block can be used to drive field devices with AC or DC load.•Easy and safe maintenance. Fuses are equipped on both the relay contact side and auxiliary power supply side; both relays and fuses are with sockets.•Individual fault output value can be configured for each channel. The output will keep the last state or set to the pre-defined safe value if there’s a failure.⏹SpecificationsExpansion Terminal Block4. Fieldbus Communication Unit4.1. OverviewFor interconnection with 3rd-party intelligent devices, K series communication units are offered as the gateway.The communication units are designed with similar style and features as the normal I/O units, in order to deliver easier installation and more stable interconnection.Intelligent Field DeviceCommunication UnitCommunication Units4.2. K-MOD01 DP/Modbus Communication Module⏹Features•The DP/Modbus communication module acts as a DP slave in K system, while as the Modbus master/slave for 3rd-party field PA devices.•1:1 redundancy.⏹Specifications4.3. K-PA01 Profibus-DP/PA Communication Module⏹Features•The DP/PA communication module acts as a DP slave in K system, while as the PA master for 3rd-party field PA devices.•1:1 redundancy.⏹Specifications4.4. K-DP02 Profibus-DP Y-Link Gateway Module⏹Features•The Y-Link gateway module acts as a DP slave in K system, while as the DP master for 3rd-party field DP devices.•1:1 redundancy.⏹SpecificationsAutomation for Better LifeHangzhou HollySys Automation Co., Ltd.North 1, No. 19 StreetXiasha Economic & Technological Development Area 310018, Hangzhou, Zhejiang, P.R. ChinaTel: +86 571 8163-3800Fax: +86 571-8163-3700Beijing HollySys Co., Ltd.No. 2, Disheng Middle RoadEconomic-Technological Development Area 100176, Beijing, P.R. ChinaTel: +86 10 5898-1000Fax: +86 10 5898-1100HollySys (Asia Pacific) Pte Ltd200 Pandan Loop, #08-01Pantech 21, Singapore 128388Tel: +65 6777-0950Fax: +65 6777-2730.sg。
FM811 主控单元
FM191 电源模块
FM131 普通端子模块
FM131-C 电缆连接型端子模块
FM131-D D型插座端子模块
FM132 冗余模出端子模块
FM133 电流型冗余模入端子模块
FM134 电压型冗余模入端子模块
FB136 交直流通用开关量输入端子板
FB137 交直流通用开关量输出端子板
FB138-AC 16路D型交流开关量输出端子板
FB138-DC 16路D型直流开关量输出端子板
FB138-SSR 16路D型固态继电器开关量输出端子板FM141 八路大信号模拟量输入模块
FM143 八路热电阻模拟量输入模块
FM146 DEH伺服单元
FM147 八路热电偶模拟量输入模块
FM148R 冗余大信号模拟量输入模块
FM148A/FM148B 八路大信号模拟量输入模块
FM151 八路模拟量输出模块
FM152 六路冗余模拟量输出模块
FM344 四路隔离型大信号输入模块
FM351 四路隔离型大信号输出模块
FM161 十六路触点型开关量输入模块
FM161-SOE 十六路SOE输入模块
FM161-48 十六路触点型开关量输入模块
FM161-48-SOE 十六路SOE输入模块
FM162 八路脉冲量输入模块
FM163 汽机转速测量模块
FM171 十六路继电器开关量输出模块
FM172 八路晶体管开关量输出模块
FM181 单回路调节模块
FM182 电动执行器控制模块
FM182A 电动执行器控制模块
FM192-TR DP有源终端匹配器
FM192-CC 热电偶冷端补偿模块。
