6000系列 产品说明书

Agilent 6000 系列 LC/MS安全指南安全2仪器上的标志2通用仪器安全5人身伤害安全6常规化学品安全9化学废弃物安全10生物危险品安全11符合性和标准12安全与规范认证12电磁兼容性13环境条件14声音发射声明14本指南包含有关 Agilent 6000 系列 LC/MS 的安全性、符合性和标准的信息。

当处理溶剂和化学品或未装配的部件时，请始终穿戴适当的防护用品，包括护目用具、实验室工作服和手套。

安全仪器上的标志安全仪器上的标志电气标志下表描述了可在 LC/MS 仪器上显示的电气标志。

表 1电气标志标志说明表示受保护的接地端。

断路器。

交流电流保险丝安全仪器上的标志安全标志下表描述了可在 LC/MS 仪器上显示的安全标志。

每个标志单独出现，或与用于解释相关危险的文本一起出现。

这些安全标志还可能出现在危险、警告或小心提示的旁边。

表 2安全标志标志说明或对于标有此标志的仪器，用户应参阅说明手册，以免对操作员造成伤害并防止损坏仪器。

表示危险电压。

如果较热表面可触及并且用户不应在加热后接触该表面，则仪器上会标有此标志。

设备放电 (ESD) 危害。

爆炸危险。

安全仪器上的标志在有氢气或者任何其他易燃气体或烟雾存在时，不要操作仪器。

在这类环境中操作任何电子仪器会造成一定的安全隐患。

不要将该电气／电子产品丢弃在家庭垃圾中。

在更换保险丝之前，需从电源插座断开电源插头。

两条带电电路。

在进行维护之前，断开两根电源线。

生物风险表 2安全标志（续）标志说明安全通用仪器安全通用仪器安全人身伤害危险：仅按照用户说明中指定的方式使用 LC/MS 仪器。

如果不按照Agilent Technologies 指定的方式使用系统，可能会导致人身伤害或仪器损坏。

移动或抬起系统人身伤害危险：LC/MS 仪器很重。

至少需由两个人抬起 6100 系列 LC/MS 仪器。

至少需由四个人抬起 6200、6400 和 6500 系列 LC/MS 仪器。

EI-6000L型火灾报警控制器安装使用说明书A V3.624.124SS拟制：审核：标准化：批准:蚌埠依爱消防电子有限责任公司目录一、概述 (1)二、主要技术指标 (1)三、主要功能 (1)四、外形及安装尺寸 (2)五、键盘/显示说明 (3)六、菜单操作 (5)七、接线 (7)八．注意事项 (8)附录 (9)重要说明火灾报警系统能否长期稳定地运行，取决于产品可靠的质量、规范的安装、全一、概述EI-6000L型火灾报警控制器集火灾报警、防盗报警和可燃气报警等多种功能于一体，满足GB4717-93国标的要求，采用壁挂式结构形式，是面向二十一世纪的综合型安防报警设备，可适用于各类小型工程。

该产品系统功耗低，抗干扰、抗振动能力强，工作可靠、性能稳定、误报率最低, 且扩展灵活、维护方便；采用液晶及汉字显示技术, 方便用户操作、使用。

可广泛适用于计算机房、资料室、配电室、变电室、通讯机站等场所。

二、主要技术指标1．交流输入电压：220V±1015%, 50Hz±1%交流输入功率≤100W直流备电： DC24V/2.2Ah, 全密封免维护蓄电池2．使用环境温度：0℃～40℃；湿度：≤95%RH ( 40℃)3．容量探测器最大数量：共128点4．继电器容量火警输出继电器：一组有源信号，可以检测短路和断线，另一组为无源常开信号，两组触点均为DC24V/2A 故障输出的继电器：一组无源常开信号，触点容量为 DC24V/2A5．24V电源最大输出电流：1A；6．回路线制：两总线制7．探测回路长度：小于1500米8．外形尺寸：380mm×260mm×95mm三、主要功能1．火警报警功能，能以两总线制方式挂接本公司生产的EI6000系列智能感烟、感温探测器、手动报警按钮，亦可通过智能中继器挂接非编码感烟、感温探测器，接收探测器的火警信号。

2．监管报警功能，能以两总线制方式挂接本公司生产的EI6000系列智能入侵探测器、智能可燃气探测器、输入模块，接收探测器的盗警和可燃气灯信号。

NPort 6400/6600Series4/8/16/32-port RS-232/422/485secure terminal serversFeatures and Benefits•LCD panel for easy IP address configuration (standard temp.models)•Secure operation modes for Real COM,TCP Server,TCP Client,PairConnection,Terminal,and Reverse Terminal•Nonstandard baudrates supported with high precision •Port buffers for storing serial data when the Ethernet is offline •Supports IPv6•Ethernet redundancy (STP/RSTP/Turbo Ring)with network module •Generic serial commands supported in Command-by-Command mode •Security features based on IEC 62443CertificationsIntroductionThe NPort®6000is a terminal server that uses the SSL and SSH protocols to transmit encrypted serial data over Ethernet.Up to 32serial devices of any type can be connected to the NPort®6000,using the same IP address.The Ethernet port can be configured for a normal or secure TCP/IP connection.The NPort®6000secure device servers are the right choice for applications that use large numbers of serial devices packed into a small space.Security breaches are intolerable and the NPort®6000Series ensures data transmission integrity with support for DES,3DES,and AES encryption algorithms.Serial devices of any type can be connected to the NPort®6000,and each serial port on the NPort®6000can be configured independently for RS-232,RS-422,or RS-485transmission.No Data Loss If Ethernet Connection FailsThe NPort®6000is a reliable device server that provides users with secure serial-to-Ethernet data transmission and a customer-oriented hardware design.If the Ethernet connection fails,the NPort®6000will queue all serial data in its internal 64KB port buffer.When the Ethernet connection is re-established,the NPort®6000will immediately release all data in the buffer in the order that it was ers can increase the port buffer size by installing an SD card.LCD Panel Makes Configuration EasyThe NPort®6600has a built-in LCD panel for configuration.The panel displays the server name,serial number,and IP address,and any of the device server’s configuration parameters,such as IP address,netmask,and gateway address,can be updated easily and quickly.Note:The LCD panel is only available with standard-temperature models.Adjustable Resistor Values for RS-485CommunicationThe NPort®6600provides adjustable termination,pull high,and pull low resistors for RS-485communication.In some criticalenvironments,termination resistors may be needed to prevent the reflection of serial signals,and the pull high and pull low resistors may need adjusting to maintain the integrity of the electrical signal.Since no set of resistor values works for every environment,the NPort®6600allows manual adjustment of the resistor values for each serial port using built-in DIP switches.SpecificationsMemorySD Slot Up to32GB(SD2.0compatible)Input/Output InterfaceAlarm Contact Channels Resistive load:1A@24VDCEthernet Interface10/100BaseT(X)Ports(RJ45connector)1Auto MDI/MDI-X connectionMagnetic Isolation Protection 1.5kV(built-in)Compatible Modules NM Series expansion modules for optional extension of RJ45and fiber Ethernet ports Optical Fiber800Typical Distance4km5km40kmWavelengthTypical(nm)13001310TX Range(nm)1260to13601280to1340 RX Range(nm)1100to16001100to1600Optical PowerTX Range(dBm)-10to-200to-5 RX Range(dBm)-3to-32-3to-34 Link Budget(dB)1229 Dispersion Penalty(dB)31Note:When connecting a single-mode fiber transceiver,we recommend using anattenuator to prevent damage caused by excessive optical power.Note:Compute the“typical distance”of a specific fiber transceiver as follows:Linkbudget(dB)>dispersion penalty(dB)+total link loss(dB).Ethernet Software FeaturesConfiguration Options Web Console(HTTP/HTTPS),Windows Utility,Device Search Utility(DSU),MCC Tool,Serial Console,Telnet/SSH ConsoleManagement ARP,BOOTP,DHCP Client,DNS,HTTP,ICMP,IPv4/IPv6,PPPOE,SMTP,SNMPv1/v2c/v3,SNTP,TCP/IP,Telnet,UDPWindows Real COM Drivers Windows95/98/ME/NT/2000,Windows XP/2003/Vista/2008/7/8/8.1/10(x86/x64),Windows2008R2/2012/2012R2/2016/2019(x64),Windows Embedded CE5.0/6.0,Windows XP EmbeddedLinux Real TTY Drivers Kernel versions:2.4.x,2.6.x,3.x,4.x,and5.xFixed TTY Drivers SCO UNIX,SCO OpenServer,UnixWare7,QNX4.25,QNX6.x,Solaris10,FreeBSD,AIX5.x,HP-UX11i,Mac OS X,macOS10.12,macOS10.13,macOS10.14,macOS10.15 Android API Android3.1.x and laterMIB MIB-IITime Management SNTP ClientUnicast Routing RIPV1/V2,Static RouteAuthentication Local Account Accessibility,RADIUS,TACACS+Serial InterfaceConnector NPort6600Models:8-pin RJ45NPort6450Models:DB9maleNo.of Ports NPort6450Models:4NPort6600-8Models:8NPort6600-16Models:16NPort6600-32Models:32Serial Standards NPort6610Models:RS-232NPort6450/6650Models:RS-232/422/485Secure Operation Modes Reverse SSH,Secure Pair Connection,Secure Real COM,Secure TCP Client,SecureTCP Server,SSHStandard Operation Modes Disabled,Ethernet Modem,Pair Connection,PPP,Printer,Real COM,Reverse Telnet,RFC2217,TCP Client,TCP Server,Terminal,UDPBaudrate50bps to921.6kbps(supports non-standard baudrates)Console Port NPort6600Models:RS-232(TxD,RxD,GND),8-pin RJ45(19200,n,8,1)Data Bits5,6,7,8Stop Bits1,1.5,2Parity None,Even,Odd,Space,MarkFlow Control RTS/CTS,DTR/DSR,XON/XOFFPull High/Low Resistor for RS-485NPort6450/6650Models:1kilo-ohm,150kilo-ohmsRS-485Data Direction Control NPort6450/6650Models:support ADDC®(automatic data direction control) Terminator for RS-485NPort6450/6650Models:120ohmsSerial SignalsRS-232TxD,RxD,RTS,CTS,DTR,DSR,DCD,GNDRS-422Tx+,Tx-,Rx+,Rx-,GNDRS-485-4w Tx+,Tx-,Rx+,Rx-,GNDRS-485-2w Data+,Data-,GNDPower ParametersInput Current NPort6450Models:730mA@12VDCNPort6600Models:DC Models:293mA@48VDC,200mA@88VDCAC Models:140mA@100VAC(8ports),192mA@100VAC(16ports),285mA@100VAC(32ports)Input Voltage NPort6450Models:12to48VDCNPort6600Models:AC Models:100to240VACDC-48V Models:±48VDC(20to72VDC,-20to-72VDC)DC-HV Models:110VDC(88to300VDC)ReliabilityAutomatic Reboot Trigger Built-in WDTAlert Tools Built-in buzzer and RTC(real-time clock)Physical CharacteristicsHousing MetalDimensions(with ears)NPort6450Models:181x103x35mm(7.13x4.06x1.38in)NPort6600Models:480x195x44mm(18.9x7.68x1.73in) Dimensions(without ears)NPort6450Models:158x103x35mm(6.22x4.06x1.38in)NPort6600Models:440x195x44mm(17.32x7.68x1.73in) Weight NPort6450Models:1,020g(2.25lb)NPort6600-8Models:3,460g(7.63lb)NPort6600-16Models:3,580g(7.89lb)NPort6600-32Models:3,600g(7.94lb)Interactive Interface LCD panel display(non-T models only)Push buttons for configuration(non-T models only) Installation NPort6450Models:Desktop,DIN-rail mounting,Wall mountingNPort6600Models:Rack mounting(with optional kit) Environmental LimitsOperating Temperature Standard Models:0to55°C(32to131°F)-HV Models:-40to85°C(-40to185°F)All other-T Models:-40to75°C(-40to167°F)Storage Temperature(package included)Standard Models:-40to75°C(-40to167°F)-HV Models:-40to85°C(-40to185°F)All other-T Models:-40to75°C(-40to167°F)Ambient Relative Humidity5to95%(non-condensing)Standards and CertificationsEMC EN55032/24EMI CISPR32,FCC Part15B Class AEMS NPort6450Models:IEC61000-4-2ESD:Contact:4kV;Air:8kVIEC61000-4-3RS:80MHz to1GHz:3V/mIEC61000-4-4EFT:Power:1kV;Signal:0.5kVIEC61000-4-5Surge:Power:1kVIEC61000-4-6CS:150kHz to80MHz:3V/m;Signal:3V/mIEC61000-4-8PFMFIEC61000-4-11NPort6600Models(except-48V/-HV models):IEC61000-4-2ESD:Contact:4kV;Air:8kVIEC61000-4-3RS:80MHz to1GHz:3V/mIEC61000-4-4EFT:Power1kV;Signal0.5kVIEC61000-4-5Surge:Power:2kVIEC61000-4-6CS:150kHz to80MHz:3V/m;Signal:3V/mIEC61000-4-8PFMFIEC61000-4-11NPort6600-48V Models:IEC61000-4-2ESD:Contact:4kV;Air:8kVIEC61000-4-3RS:80MHz to1GHz:3V/mIEC61000-4-4EFT:Power:1kV;Signal:0.5kVIEC61000-4-5Surge:Power:1kVIEC61000-4-6CS:150kHz to80MHz:3V/m;Signal:3V/mIEC61000-4-8PFMFIEC61000-4-3RS:80MHz to1GHz:3V/mIEC61000-4-4EFT:Power:4kV;Signal:2kVIEC61000-4-5Surge:Power:2kVIEC61000-4-6CS:150kHz to80MHz:3V/m;Signal:3V/mIEC61000-4-8PFMFSafety UL60950-1Traffic Control NEMA TS2Vibration IEC60068-2-6Freefall IEC60068-2-34DeclarationGreen Product RoHS,CRoHS,WEEEMTBFTime NPort6450Models:850,905hrsNPort6610-8Models:135,891hrsNPort6610-16Models:102,373hrsNPort6610-32Models:68,707hrsNPort6650-8Models:636,600hrsNPort6650-16Models:439,673hrsNPort6650-32Models:310,078hrsNPort6650-8-HV-T:501,171hrsNPort6650-16-HV-T:380,006hrsNPort6650-32-HV-T:290,914hrsStandards NPort6450Models:Telcordia(Bellcore)Standard TR/SRNPort6600Models:Telcordia(Bellcore)StandardWarrantyWarranty Period5yearsDetails See /warrantyPackage ContentsDevice1x NPort6400/6600Series terminal serverInstallation Kit2x rack-mounting ear(NPort6600models)Cable1x DB9male to RJ458-pin(NPort6600models)Power Supply1x power cable,suitable for your region(AC models except-T models)1x power adapter,suitable for your region(NPort6450) Documentation1x quick installation guide1x warranty cardDimensionsNPort6450NPort6600Ordering InformationModel Name No.of Serial Ports Serial Standards Serial Interface Operating Temp.Input Voltage NPort64504RS-232/422/485DB9male0to55°C12to48VDC NPort6450-T4RS-232/422/485DB9male-40to75°C12to48VDC NPort6610-88RS-2328-pin RJ450to55°C100-240VACNPort6610-8-48V8RS-2328-pin RJ450to55°C 48VDC;+20to+72 VDC,-20to-72VDCNPort6610-1616RS-2328-pin RJ450to55°C100-240VACNPort6610-16-48V16RS-2328-pin RJ450to55°C 48VDC;+20to+72 VDC,-20to-72VDCNPort6610-3232RS-2328-pin RJ450to55°C100-240VACNPort6610-32-48V32RS-2328-pin RJ450to55°C 48VDC;+20to+72 VDC,-20to-72VDCNPort6650-88RS-232/422/4858-pin RJ450to55°C100-240VAC NPort6650-8-T8RS-232/422/4858-pin RJ45-40to75°C100-240VACNPort6650-8-HV-T8RS-232/422/4858-pin RJ45-40to85°C 110VDC;88to300VDCNPort6650-8-48V8RS-232/422/4858-pin RJ450to55°C 48VDC;+20to+72 VDC,-20to-72VDCNPort6650-1616RS-232/422/4858-pin RJ450to55°C100-240VACNPort6650-16-48V16RS-232/422/4858-pin RJ450to55°C 48VDC;+20to+72 VDC,-20to-72VDCNPort6650-16-T16RS-232/422/4858-pin RJ45-40to75°C100-240VACNPort6650-16-HV-T16RS-232/422/4858-pin RJ45-40to85°C 110VDC;88to300VDCNPort6650-3232RS-232/422/4858-pin RJ450to55°C100-240VACNPort6650-32-48V32RS-232/422/4858-pin RJ450to55°C 48VDC;+20to+72 VDC,-20to-72VDCNPort6650-32-HV-T32RS-232/422/4858-pin RJ45-40to85°C 110VDC;88to300VDCAccessories(sold separately)CablesCBL-RJ45F25-1508-pin RJ45to DB25female serial cable,1.5mApplicable Models:NPort6650-8-48VNPort6650-8-HV-TNPort6650-32-48VNPort6650-32-HV-TNPort6650-16-HV-TNPort6650-16-48VCBL-RJ45F9-1508-pin RJ45to DB9female serial cable,1.5mApplicable Models:NPort6650-16NPort6650-8-48VNPort6610-32-48VNPort6650-16-48VNPort6650-16-TNPort6650-8NPort6650-8-HV-TNPort6610-16NPort6650-32-HV-TNPort6610-8NPort6650-32-48VNPort6650-16-HV-TNPort6610-32NPort6610-16-48VNPort6610-8-48VNPort6650-8-TNPort6650-32CBL-RJ45M25-1508-pin RJ45to DB25male serial cable,1.5mApplicable Models:NPort6650-8NPort6650-8-HV-TNPort6610-16NPort6650-8-TNPort6610-32-48VNPort6650-16-TNPort6650-8-48VNPort6650-16-HV-TNPort6650-16-48VNPort6650-16NPort6650-32-HV-TNPort6650-32NPort6610-8NPort6610-8-48VNPort6650-32-48VNPort6610-16-48VNPort6610-32CBL-RJ45M9-1508-pin RJ45to DB9male serial cable,1.5mApplicable Models:NPort6610-32-48VNPort6610-8-48VNPort6650-32NPort6650-8NPort6650-32-HV-TNPort6610-16NPort6610-8NPort6650-16-HV-TNPort6610-16-48VNPort6610-32NPort6650-32-48VNPort6650-8-TNPort6650-16-TNPort6650-8-HV-TNPort6650-16-48VCBL-RJ45SF25-1508-pin RJ45to DB25female serial cable with shielding,1.5mApplicable Models:NPort6610-16NPort6610-32-48VNPort6610-32NPort6650-32NPort6650-32-48VNPort6610-8NPort6650-16-TNPort6610-16-48VNPort6650-32-HV-TNPort6650-16NPort6650-8NPort6650-16-48VNPort6650-16-HV-TNPort6650-8-TNPort6610-8-48VNPort6650-8-48VNPort6650-8-HV-TCBL-RJ45SF9-1508-pin RJ45to DB9female serial cable with shielding,1.5mApplicable Models:NPort6610-32NPort6650-8NPort6650-32NPort6650-8-HV-TNPort6650-16-HV-TNPort6610-8NPort6650-16NPort6610-16NPort6650-16-48VNPort6650-8-TNPort6650-8-48VNPort6650-32-48VNPort6650-16-TNPort6610-32-48VNPort6610-8-48VNPort6610-16-48VNPort6650-32-HV-TCBL-RJ45SM25-1508-pin RJ45to DB25male serial cable with shielding,1.5mApplicable Models:NPort6650-8NPort6650-8-48VNPort6610-32-48VNPort6650-8-TNPort6650-32-HV-TNPort6650-32NPort6610-16NPort6650-16NPort6610-8-48VNPort6650-16-TNPort6610-8NPort6610-16-48VNPort6650-16-48VNPort6610-32NPort6650-8-HV-TNPort6650-32-48VNPort6650-16-HV-TCBL-RJ45SM9-1508-pin RJ45to DB9male serial cable with shielding,1.5mNPort6650-8-TNPort6610-32-48VNPort6610-16-48VNPort6650-16-48VNPort6610-8NPort6650-32-HV-TNPort6610-8-48VNPort6650-16-HV-TNPort6650-32-48VNPort6650-8-HV-TNPort6650-16-TNPort6610-32NPort6650-8-48VNPort6650-16NPort6650-8ConnectorsMini DB9F-to-TB DB9female to terminal block connectorApplicable Models:NPort6450NPort6450-TDIN-Rail Mounting KitsDK35A DIN-rail mounting kit,35mmApplicable Models:NPort6450NPort6450-TExpansion ModulesNM-TX01110/100BaseTX portNM-TX01-T110/100BaseTX port,-40to75°C operating temperatureNM-TX02210/100BaseTX portsNM-TX02-T210/100BaseTX ports,-40to75°C operating temperatureNM-FX01-M-SC1100BaseFX port,multi-mode,SC connectorNM-FX01-M-SC-T1100BaseFX port,multi-mode,SC connector,-40to75°C operating temperatureNM-FX01-S-SC1100BaseFX port,single-mode,SC connectorNM-FX01-S-SC-T1100BaseFX port,single-mode,SC connector,-40to75°C operating temperatureNM-FX02-M-SC2100BaseFX ports,multi-mode,SC connectorNM-FX02-M-SC-T2100BaseFX ports,multi-mode,SC connector,-40to75°C operating temperatureNM-FX02-S-SC2100BaseFX ports,single-mode,SC connectorNM-FX02-S-SC-T2100BaseFX ports,single-mode,SC connector,-40to75°C operating temperaturePower AdaptersPWR-12125-DT-S2Desktop power supply(requires power cord),12VDC,1.25A,100to240VAC,0to40°C operatingtemperatureApplicable Models:NPort6450NPort6450-TPWR-12150-AU-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,Australia(AU)plug,-40to75°C operatingtemperatureApplicable Models:NPort6450-TNPort6650-16-HV-TNPort6650-16-TNPort6650-32-HV-TNPort6650-8-HV-TPWR-12150-CN-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,China(CN)plug,-40to75°C operatingtemperatureApplicable Models:NPort6450-TNPort6650-16-HV-TNPort6650-16-TNPort6650-32-HV-TNPort6650-8-HV-TNPort6650-8-TPWR-12150-EU-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,Continental Europe(EU)plug,-40to75°Coperating temperatureApplicable Models:NPort6450-TNPort6650-16-HV-TNPort6650-16-TNPort6650-32-HV-TNPort6650-8-HV-TNPort6650-8-TPWR-12150-UK-SA-T Locking barrel plug,12VDC,1.5A,100to240VAC,United Kingdom(UK)plug,-40to75°C operatingtemperatureApplicable Models:NPort6450-TNPort6650-16-HV-TNPort6650-16-TNPort6650-32-HV-TNPort6650-8-HV-TNPort6650-8-TPWR-12150-USJP-SA-T Locking barrel plug,12VDC1.5A,100to240VAC,United States/Japan(US/JP)plug,-40to75°Coperating temperatureApplicable Models:NPort6450-TNPort6650-16-HV-TNPort6650-16-TNPort6650-32-HV-TNPort6650-8-HV-TNPort6650-8-TPower CordsPWC-C13AU-3B-183Power cord with Australian(AU)plug,1.83mApplicable Models:NPort6610-16-48VNPort6650-8-48VNPort6650-16-HV-TNPort6610-8-48VNPort6610-32NPort6650-8NPort6650-32NPort6610-32-48VNPort6610-8NPort6650-8-TNPort6610-16NPort6650-16-48VNPort6650-8-HV-TNPort6650-32-48VNPort6650-32-HV-TNPort6650-16NPort6650-16-TPWC-C13CN-3B-183Power cord with three-prong China(CN)plug,1.83mApplicable Models:NPort6650-32NPort6650-8-TNPort6650-8-48VNPort6650-16NPort6650-16-48VNPort6650-16-TNPort6650-8-HV-TNPort6610-16NPort6650-8NPort6610-32-48VNPort6650-16-HV-TNPort6610-16-48VNPort6610-8-48VNPort6650-32-48VNPort6610-8NPort6650-32-HV-TPWC-C13EU-3B-183Power cord with Continental Europe(EU)plug,1.83mApplicable Models:NPort6650-8-48VNPort6650-8-HV-TNPort6650-32NPort6650-16NPort6650-16-TNPort6650-16-HV-TNPort6610-32NPort6650-16-48VNPort6610-16-48VNPort6610-8NPort6610-8-48VNPort6650-32-48VNPort6650-32-HV-TNPort6650-8NPort6610-16NPort6610-32-48VNPort6650-8-TPWC-C13JP-3B-183Power cord with Japan(JP)plug,7A/125V,1.83mApplicable Models:NPort6650-16-TNPort6650-8NPort6610-8NPort6650-8-HV-TNPort6650-32NPort6610-8-48VNPort6650-8-TNPort6650-16NPort6610-16-48VNPort6610-32-48VNPort6650-16-HV-TNPort6650-8-48VNPort6610-16NPort6650-16-48VNPort6610-32NPort6650-32-48VNPort6650-32-HV-TPWC-C13UK-3B-183Power cord with United Kingdom(UK)plug,1.83mApplicable Models:NPort6650-16-HV-TNPort6650-16NPort6610-32NPort6610-16NPort6610-8-48VNPort6650-16-TNPort6610-8NPort6610-32-48VNPort6650-8NPort6650-8-TNPort6650-16-48VNPort6650-32NPort6650-32-HV-TNPort6650-8-48VNPort6650-32-48VNPort6650-8-HV-TNPort6610-16-48VPWC-C13US-3B-183Power cord with United States(US)plug,1.83mApplicable Models:NPort6650-32NPort6650-8NPort6650-16NPort6610-8NPort6650-8-HV-TNPort6610-32NPort6610-8-48VNPort6610-16NPort6610-16-48VNPort6650-16-48VNPort6650-8-48VNPort6650-8-TNPort6610-32-48VNPort6650-32-48VNPort6650-32-HV-TNPort6650-16-HV-TNPort6650-16-TPWC-C7AU-2B-183Power cord with Australian(AU)plug,2.5A/250V,1.83mApplicable Models:NPort6450-TNPort6450PWC-C7EU-2B-183Power cord with Continental Europe(EU)plug,2.5A/250V,1.83mApplicable Models:NPort6450NPort6450-TPWC-C7JP-2B-183Power cord for desktop-type power adapters with Japan(JP)plug,7A/125V,1.83mApplicable Models:NPort6450-TNPort6450PWC-C7UK-2B-183Power cord with United Kingdom(UK)plug,2.5A/250V,1.83mApplicable Models:NPort6450-TNPort6450PWC-C7US-2B-183Power cord with United States(US)plug,10A/125V,1.83mApplicable Models:NPort6450NPort6450-TCBL-PJ21NOPEN-BK-30Locking barrel plug to bare-wire cableWall-Mounting KitsWK-35-01Wall-mounting kit with2plates(35x44x2.5mm)and6screwsApplicable Models:NPort6450NPort6450-TRack-Mounting KitsWK-44-01Rack-mounting kit,2L-shaped plates,8screws,44x57.5x1.6mmApplicable Models:NPort6610-8NPort6610-32NPort6610-32-48VNPort6610-16-48VNPort6610-16NPort6610-8-48VNPort6650-16-TNPort6650-16-48VNPort6650-16NPort6650-32-HV-TNPort6650-16-HV-TNPort6650-8-TNPort6650-32NPort6650-32-48VNPort6650-8-HV-TNPort6650-8NPort6650-8-48V©Moxa Inc.All rights reserved.Updated Aug11,2021.This document and any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of Moxa Inc.Product specifications subject to change without notice.Visit our website for the most up-to-date product information.。

目录第一章系统简介 (1)1.1简介 (1)1.2系统最低配置要求 (1)1.3系统推荐配置：..................................................................... 错误！未定义书签。

1.3系统参数 (2)第二章硬件安装 (3)第三章驱动程序安装 (4)1.1、通用安装 (4)第四章系统程序安装 (15)第五章系统软件功能和操作说明 (16)一、主界面介绍 (16)1.1 基本操作 (16)1.2 屏幕显示 (17)1.3 颜色调节 (18)1.4 云台控制 (18)1.5 手动录像 (18)1.6 信息显示 (19)二、系统管理 (19)2.1 系统设置 (19)2.2 报警设置 (21)2.3 视频报警 (23)2.4 日志管理 (24)2.5 计划管理 (24)2.6 区域设置(V2.1版本此项目已经取消) (25)2.5 用户设置 (25)2.8 监看管理(V2.1版本此项目已经取消) (26)2.9 快球设置 (27)3.0 云台辅助 (27)3.1 恢复视频 (28)三、回放操作 (28)3.1 通道选择及操作信息显示 (29)3.2 操作区 (29)3.3 时间显示 (29)3.4 录像方式说明 (29)3.5 日期时间选择 (30)附录: 常见问题解答: (30)第一章系统简介1.1简介本说明书描述了与6000/8000 系列视频压缩卡（简称压缩卡）有关的硬件安装、软件安装、系统设置、软件使用等方面的内容，请务必按照说明书的指导进行这些工作，以确保监控系统正常、稳定地运行。

1.2系统最低配置要求注：1、显示器分辨率设定为1024×768或以上。

2、在系统安装完后，在控制面版中的电源选项里将关闭硬盘、关闭监视器和系统待机等选项设置为“从不”。

3、检查所有设备是否存在冲突，对于存在冲突的设备，可以通过调整中断号、内存地址或者重新安装驱动程序等方法来解决。
