GPR系列精密调压阀图纸

阀门有哪些种类？其结构及工作原理在这里给大家分类总1.截断阀类主要用于截断或接通介质流。

包括闸阀、截止阀、隔膜阀、球阀、旋塞阀、蝶阀、柱塞阀、仪表针型阀等。

2.调节阀类主要用于调节介质的流量、压力等。

包括调节阀、节流阀、减压阀等。

3.止回阀类用于阻止介质倒流。

包括各种结构的止回阀。

4.分流阀类用于分离、分配或混合介质。

包括各种结构的分配阀和疏水阀等。

5.安全阀类用于介质超压时的安全保护。

包括各种类型的安全阀。

一、闸阀靠阀板的上下移动，控制阀门开度。

阀板象是一道闸门。

闸阀关闭时，密封面可以只依靠介质压力来密封，即只依靠介质压力将闸板的密封面压向另一侧的阀座来保证密封面的密封，这就是自密封。

大部分闸阀是采用强制密封的，即阀门关闭时，要依靠外力强行将闸板压向阀座，以保证密封面的密封性。

闸阀的种类,按密封面配置可分为楔式闸板式闸阀和平行闸板式闸阀, 楔式闸板式闸阀又可分为: 单闸板式、双闸板式和弹性闸板式；平行闸板式闸阀可分为单闸板式和双闸板式。

按阀杆的螺纹位置划分，可分为明杆闸阀和暗杆闸阀两种。

国内生产闸阀的厂家比较多，连接尺寸也大多不统一。

性能特点：优点：1、流动阻力小。

阀体内部介质通道是直通的，介质成直线流动，流动阻力小。

2、启闭时较省力。

是与截止阀相比而言，因为无论是开或闭，闸板运动方向均与介质流动方向相垂直。

3、高度大，启闭时间长。

闸板的启闭行程较大，降是通过螺杆进行的。

4、水锤现象不易产生。

原因是关闭时间长。

5、介质可向两侧任意方向流动，易于安装。

闸阀通道两侧是对称的。

6、结构长度(系壳体两连接端面之间的距离)较小。

7、形体简单, 结构长度短，制造工艺性好，适用范围广。

8、结构紧凑，阀门刚性好，通道流畅，流阻数小，密封面采用不锈钢和硬质合金，使用寿命长，采用PTFE 填料．密封可靠．操作轻便灵活．缺点：密封面之间易引起冲蚀和擦伤，维修比较困难。

外形尺寸较大，开启需要一定的空间，开闭时间长。

结构较复杂。

1P r e c i s i o n P r e s s u r e R e g u Typical Applications• Environmental Analyzers —Helium or Hydrogen Carrier Gas • Precision Nitrogen Control forChemical Analysis• Laboratory and Process GasChromatography applicationsForward Pressure RegulatorsPhysical PropertiesModel 8310 / 8311Precision Pressure RegulatorProduct Specifications1Parker Precision Fluidics Model 8310 / 8311 Regulators incorporate a threadless valve seat assembly with a precision glass ball. It is ideal for very low flow carrier gas applications and provides bubble tight shut-off. The 8310 / 8311 is a direct-acting, non-relieving pressure regulator supplied with a replaceable sintered stainless steel cartridge filter on the inlet. It can be configured with a stainless steel diaphragm to reduce permeability. Each regulator is performance tested and ideally suited for manufacturers of analytical equipment.1Performance characteristics are based on 60 psig (4.14 barg) helium supply pressure at 50 psig (3.45 barg) outlet pressure.Features• Direct-acting and non-relieving• Compact design enables panel mounting• All bar stock construction reduces production variation • Bubble tight shut-off• Cleaned for Analytical Service Use • Pressure gauge port included •RoHS and REACH compliant2For more information call +1 603 595 1500 or email ppfinfo @Typical Droop (Flow Sensitivity) Curve (Fairprene Diaphragm Unit)Typical Regulator Output vs. Change in Supply Pressure (Supply Pressure Effect)(Fairprene Diaphragm Unit)Model 8310 / 8311Precision Pressure RegulatorTypical Flow Curves50.03.45p s i gbarg49.8 3.4349.6 3.4249.4 3.4149.2 3.3949.03.38Flow SCCM Helium PressureO u t l e t P r e s s u r e p s i gpsigbargbarg O u t l e t P r e s s u r e3.523.483.453.413.38Supply PressureTypical Droop (Flow Sensitivity) Curve (Stainless Steel Diaphragm)Typical Regulator Output vs. Change in Supply Pressure (Supply Pressure Effect)(Stainless Steel Diaphragm)p s i gpsigbargbargO u t l e t P r e s s u r e1801601401001208060403.483.453.413.383.353.31Supply Pressure50.0 3.45p s i gbarg49.649.83.433.4249.249.4 3.413.3748.849.0 3.393.3548.448.6 3.383.34Flow SCCM Helium PressureO u t l e t P r e s s u r e3For more information call +1 603 595 1500 or email ppfinfo @Principle of OperationAs gas enters the regulator body from the inlet (left), the pressure rises which pushes the diaphragm, closing the control inlet valve and preventing any more gas from entering the regulator .When gas is drawn from the outlet (right) side, the pressure inside the regulator body falls. As a result, the diaphragm is pushed back by the spring and the valve opens, allowing more gas in from the supply until equilibrium is reached between the outlet pressure and the spring.The outlet pressure is a function of the spring force which may be modified by the adjustment knob. The outlet pressure and the inlet pressure hold the quad ring poppet assembly in the closed position against the force of the spring.56 threads/in. (2.2 threads/mm) stem for 15 turns resolutionRange SpringStainless Steel or Fairprene DiaphragmIntegral 100 Micron FilterQuad Ring PoppetModel 8310 / 8311Precision Pressure Regulator4For more information call +1 603 595 1500 or email ppfinfo @Mechanical IntegrationDimensions83108311Model 8310 / 8311Basic DimensionsUnits In (cm)Precision Pressure Regulator5P r e c i s i o n P r e s s For more information call +1 603 595 1500 or email ppfinfo @Model 8310 / 8311Typical Flow DiagramVOC Emissions Monitoring AnalyzerPrecision Pressure Regulator6For more information call +1 603 595 1500 or email ppfinfo @Model 8310 / 8311Ordering InformationInstallation Guide• For NPT connections, a high quality sealant compatible with the customer’s process gas must be used.• May be installed in any orientation.• Support inlet and outlet piping to reduce strain on regulator body.Key Things to Remember:• To minimize your Helium gas costs, consider using 2.5 or 5 psig Pressure Range (0.17 or 0.34 barg) only available from Parker. • Choice of Diaphragm Materials – Stainless Steel Diaphragms provide extremely low perme-ability. Coated Fabric Diaphragms, available in Buna or FKM, offer unmatched sensitivity.• Fine Pitch Adjusting Stem – 56 threads/in. (2.2 threads/mm) stem for 15 turns resolution pitch on all regulator adjusting stems gives precise control over incremental pressure adjustments.• Bar Stock Construction and Analytical Service Cleaning – Machined from bar stock in your choice of aluminum or stainless steel. All parts are cleaned to procedures developed specifically for analytical service use, minimizing contaminant generation in low-level analyzer applications.• Extensive Choice of Pressure Range – This ensures maximum resolution at specificpressure and temperature requirements.(ASTM A228) onlyNOTE: In order to provide the best possible solution for your application, please provide the following requirements when contacting Applications Engineering: • Media, Inlet & Outlet Pressures • Mimimum Required Flow Rate.Please click on the ORDER ON-LINE button (or go to www.parker .com/prescision fluidics/regulators) to configure your Precision Pressure Regulator. For more detailed information, visit us on the web orcall Applications Engineering.Precision Pressure Regulator7P r e c i s i o n Portfolio ReviewModel 4000Flow control from 0.5 slpm to 10 slpmSmaller SizeModel 9000Model 8286Models 8310 & 8311CustomizationContact Division Applications at (603) 595 1500 or ppfinfo @parker .com.Model 8310 / 8311PPF PPR - 002/US October 2016© 2016 Parker Hannifin Corporation Parker Hannifin Corporation Precision Fluidics Division 26 Clinton Dr., Unit 103Hollis, NH 03049Flow control from 1 sccm to 3 slpmFlow control from 1 slpm to 40 slpmFlow control from 10 sccm to 1 slpm Back Pressure RegulatorPrecision Pressure Regulator。

GP1/GP2 INSTALLATION & MAINTENANCE INSTRUCTIONSDESCRIPTION / IDENTIFICATIONThe GP series control valve is an electronic pressure regu-lator designed to precisely control the pressure of gaseous media proportional to an electronic signal.The GP1 operates using two normally closed solenoid valves, a pressure sensor, and a control circuit. One valve is actuated to allow unregulated supply media into the sys-tem. The second valve is actuated to allow working media to vent to atmosphere. The pressure sensor provides feed-back to the control circuit. The control circuit comparesthe pressure sensor feedback to the user supplied electronic command signal and actuates the appropriate valve until the two signals match.The GP series can be teamed with a variety of one-to-one ratio high pressure volume boosters for even greater flow. When using a volume booster, the GP2 can be used toachieve accuracy similar to the GP1 alone with higher flow capacity.GP series product comes with a monitor output signal. This output is an electrical signal originating from the inter-nal sensor used in the control circuit of the GP1 valve. On GP2 units this signal originates from the external trans-ducer. This allows the system parameters to be monitored and provides a signal for data acquisition needs.The output of this signal can be configured to either 0-10Vdc or 4-20mA.The GP2 is similar to the GP1 but uses a double loop con-trol scheme. In addition to the internal pressure transducer, the GP2 also receives a 0-10Vdc feedback signal from an external sensing device. The external signal functions as the primary feedback and is compared to the command sig-nal. A difference between the two comparisons causes one of the two solenoid valves to open allowing flow in or out of the system.A Proportion-Air DSY or DSTY will work as a second loop feedback to the GP2 (See ordering information).The GP series has several other beneficial features. An on board split power supply allows true zero for command and monitor even though the GP is powered by a conventional single ended power supply. The GP utilizes advanced on board power management hardware to minimize current draw and heat build up. The GP also features status indi-cating LEDs for power and TTL. The TTL signal is a con-ditional on/off signal to use for diagnostic purposes. This signal is LOW when the pressure is within 1% of final set-ting.• Description & identification • General specifications • Connection procedure • Re-calibration procedure • Repair procedure•Dimensions, ordering and accessoriesBefore you get started, please read these warnings:♦ Examine the product. Ensure that you received what you ordered. ♦ Read this guide first before you start and save it for later use.♦ You must have a good understanding of what the adjustments are on this product before using them.♦All compressed air and power should be shut off before installing, removing or performing maintenance on this prod-uct.♦ Installation and use of this product should be under the supervision and control of properly qualified personnel inorder to avoid the risk of injury or death.e s y of C M A /F l o d y n e /H y d r a d y n e ▪ M o t i o n C o n t r o l ▪ H y d r a u l i c ▪ P n e u m a t i c ▪ E l e c t r i c a l ▪ M e c h a n i c a l ▪ (800) 426-5480 ▪ w w w .c m a f h .c o mGENERAL SPECIFICATIONS & PERFORMANCE CHARACTERISTICSELECTRICALMINIMUM TYPICAL MAXIMUM Supply Voltage Supply Current Command Signal VoltageCurrent Command Signal Impedance Voltage Current Analog Monitor Output Voltage Current (Sourcing) TTLSatisfied Not-Satisfied 2nd Loop Input 15VDC100mADC (standbystate) 0VDC 4mADC- - 0VDC 4mADC- - 0VDC - - - - 10K Ω 100Ω - - 0VDC 5VDC - 24VDC985mADC (operating)10VDC 20mADC- - 10VDC 20mADC- - 10VDCPNEUMATIC MINIMUM TYPICAL MAXIMUM Input PressurePressure Range Flow RateFiltration Required Accuracy (Pressure) Accuracy (Monitor) Hysteresis/Linearity Repeatability Port Size (all) Critical Volume VacuumVacuum 0 SCFM (0 m³/hr)40 micron ±0.1%F.S.- 0%F.S. - - - 110% of full scalecalibration-5 SCFM (8.5 m³/hr)20 micron ±0.25%F.S. ±0.3%F.S. ±0.2%F.S. ±0.05%F.S. 1/8 inch NPT female3 in³1100 psig (75.84 bar)1000 psi (68.95 bar) 10 SCFM (17 m³/hr)- ±0.5%F.S. ±0.5%F.S. ±0.5%F.S.Depends on Hysteresis- -(Note 1)(Note 2)(Note 3)(Note 4)PHYSICALMINIMUM TYPICALMAXIMUM Operating Temperature Environment Protection WeightElectrical Connector32ºF (0ºC)- - -- -3.75 lbs (1.75 kg)6 pin molded 16 gauge wire158ºF (70ºC) NEMA 4/IP65- -(Note 5) (Note 6)(Note 1) Pressure ranges are customer specified.(Note 2) Pressure range up to 250 PSI (17.24 BAR) may be ordered as PSIG or PSIA. Pressure range above 251 PSI (17.3 BAR) may be ordered as PSIS or PSIA.(Note 3) User adjustable(Note 4) The minimum downstream closed volume is determined by the pressure range, orifice size, hysteresis window, plumbing, aswell as other factors. Consult factory for small volume applications. (Note 5) CE approval pending(Note 6) Depends on density of manifold materialLINEARITY12345678910Command [Volts]0102030405060708090100P r e s s u r e [% o f s c a l e ]Fig 1Times for GP to fill/exhaust a closed chamber. Step command signal Fig 2% o f S c a l eTime (seconds)Volume = 5 cu.in. [82mL]e s y of C M A /F l o d y n e /H y d r a d y n e ▪ M o t i o n C o n t r o l ▪ H y d r a u l i c ▪ P n e u m a t i c ▪ E l e c t r i c a l ▪ M e c h a n i c a l ▪ (800) 426-5480 ▪ w w w .c m a f h .c o mGP CONNECTION PROCEDURE Electrical connections:1. Ensure all power is off before making any electricalconnections. 2. Figure 2 shows the location of the GP electrical con-nector and figure 3 shows the connector. Table 2 iden-tifies the color codes Note: Both current and voltage command units require that both the command (+) and command (–) pins be connected.3. See figure 4 and 5 for second loop connections.Pneumatic Connections:1. A typical 20 micron (minimum 40 micron) in-linefilter is recommended on the inlet of the GP. 2. Connect supply pressure to the “I” inlet port (figure 1)not to exceed rated supply pressure. (Table 1) 3. Connect one of the “O” outlet port (figure 1) to thedevice being controlled and plug the unused one. 4. Proceed with electrical connection.MAX calibrated pressure of:Max inlet pressure is:Vacuum up to 15 psig (Vac. to 1.03 bar) 30 psig (2.07 bar) 16 up to 30 psig (1.1 to 2.07 bar) 60 psig (4.14 bar) 31 up to 50 psig (2.14 to 2.45 bar) 100 psig (6.89 bar) 51 up to 100 psig (3.52 to 6.89 bar) 200 psig (13.79 bar) 101 up to 250 psig (6.96 to 17.24 bar) 500 psig (34.47 bar) 251 up to 500 psig (17.31 to 34.47 bar)600 psig (41.37 bar)501 up to 1000 psig (34.54 to 68.95 bar) 1100 psig (75.84 bar)TABLE 1RATED PRESSURE FOR GP VALVESTABLE 2WIRE COLOR*FUNCTION WHITE COMMAND (+) RED ANALOG OUTPUT GREEN DC COMMON ORANGE TTL OUT BLACK 15-24 VDC POWER BLUECOMMAND (-)e s y of C M A /F l o d y n e /H y d r a d y n e ▪ M o t i o n C o n t r o l ▪ H y d r a u l i c ▪ P n e u m a t i c ▪ E l e c t r i c a l ▪ M e c h a n i c a l ▪ (800) 426-5480 ▪ w w w .c m a f h .c o me s y of C M A /F l o d y n e /H y d r a d y n e ▪ M o t i o n C o n t r o l ▪ H y d r a u l i c ▪ P n e u m a t i c ▪ E l e c t r i c a l ▪ M e c h a n i c a l ▪ (800) 426-5480 ▪ w w w .c m a f h .c o mREPAIR PROCEDURE:1.) Disassemble GP unit:A. Remove the two 8-32 flat head screws and o’rings on the GP lid. Figure 7B. Unplug main connector wires and LED wires from the board. Figure 8C. Remove lid, lid o’ring and can assembly from manifold . Figure 9D. Unplug valve and sensor wires from board. Figure 8E. Remove the two 8-32 SHCS screws and o’rings from manifold to remove both the regular tall standoff and the boardstandoff. Figure 10F. Of each valve assembly, remove hex nuts and disassemble valve tube from coil and valve housing. (Keep coil washer,valve housing and hex nut because they are not included in the repair kit and can be reused) Figure 14G. Using span wrench (figure 11) , remove valve tube from manifold cavity.H. Remove poppet and o’ring spacer from manifold. See figure 12 for o’ring spacer location and figure 14 for valve ori-entationI. If sensor needs to be replaced, unthread sensor from manifold. See figure 13 for sensor locationFIGURE 10FIGURE 8LEDesyofCMA/Flodyne/Hydradyne▪MotionControl▪Hydraulic▪Pneumatic▪Electrical▪Mechanical▪(8)426-548▪www.cmafh.comFIGURE 14e s y of C M A /F l o d y n e /H y d r a d y n e ▪ M o t i o n C o n t r o l ▪ H y d r a u l i c ▪ P n e u m a t i c ▪ E l e c t r i c a l ▪ M e c h a n i c a l ▪ (800) 426-5480 ▪ w w w .c m a f h .c o mPROPORTION-AIR, INC. BOX 218 MCCORDSVILLE, IN USA 46055PHONE: (317)335-2602 FAX: (317)335-3853Proportion-Air products are warranted to the original purchaser only against defects in material or workmanship for one (1) year from the date of manufac-ture. The extent of Proportion-Air's liability under this warranty is limited to repair or replacement of the defective unit at Proportion-Air's option. Pro-portion-Air shall have no liability under this warranty where improper installation or filtration occurred.All specifications are subject to change without notice. THIS WARRANTY IS GIVEN IN LIEU OF, AND BUYER HEREBY EXPRESSLYWAIVES, WARRANTIES OR LIABILITIES, EXPRESS, IMPLIED OR STATUTORY, INCLUDING WITHOUT LIMITATION ANY OBLI-GATION OF PROPORTION-AIR WITH REGARD TO CONSEQUENTIAL DAMAGES, WARRANTIES OF MERCHANTABILITY, DE-SCRIPTION, AND FITNESS FOR A PARTICULAR PURPOSE.............................................................................................................................................................................................................WARNING: Installation and use of this product should be under the supervision and control of properly qualified personnel in order to avoid the risk of injury or death.e s y of C M A /F l o d y n e /H y d r a d y n e ▪ M o t i o n C o n t r o l ▪ H y d r a u l i c ▪ P n e u m a t i c ▪ E l e c t r i c a l ▪ M e c h a n i c a l ▪ (800) 426-5480 ▪ w w w .c m a f h .c o m。

38张阀门动图-工作状态和原理一目了然!38张阀门动图工作状态和原理一目了然！2016-05-25 11:08小七导读：液压阀是一种用压力油操作的自动化元件，它受配压阀压力油的控制，通常与电磁配压阀组合使用，可用于远距离控制水电站油、气、水管路系统的通断。

今天，小七为大家配上动图来介绍各种液压阀的原理和功能！按控制方法分类：手动，电控，液控按功能分类：流量阀（节流阀、调速阀，分流集流阀）、压力阀（溢流阀，减压阀，顺序阀，卸荷阀）、方向阀（电磁换向阀、手动换向阀、单向阀、液控单向阀）◆◆◆单向阀单向阀是流体只能沿进水口流动，出水口介质却无法回流，俗称单向阀。

单向阀又称止回阀或逆止阀。

用于液压系统中防止油流反向流动,或者用于气动系统中防止压缩空气逆向流动。

安装止回阀时，应特别注意介质流动方向，应使介质正常流动方向与阀体上指示的箭头方向相一致，否则就会截断介质的正常流动。

底阀应安装在水泵吸水管路的底端。

止回阀关闭时，会在管路中产生水锤压力，严重时会导致阀门、管路或设备的损坏，尤其对于大口管路或高压管路，故应引起止回阀选用者的高度注意。

单向阀有控制油时+换向阀换向阀是具有两种以上流动形式和两个以上油口的方向控制阀。

是实现液压油流的沟通、切断和换向，以及压力卸载和顺序动作控制的阀门。

这种变换阀在石油、化工生产中有着广泛的应用，在合成氨造气系统中最为常用。

此外，换向阀还可作成阀瓣式的结构，多用于较小流量的场合。

工作时只需转动手轮通过阀瓣来变换工作流体的流向。

◆◆◆换向阀-二位二通二位即表示阀芯工作在两种状态下，线圈不通电时阀芯在一个位置，通电时运动到另一个位置，通过位置的变换来切换阀的导通状态；二通的意思是阀有两个接口（一进一出）。

二位二通阀实际上就是一个截止阀，起关断/打开管路的目的，没有换向的功能。

+◆◆◆换向阀-二位四通二位四通换向阀适用干油或稀油集中润滑系统,以转换供油方向或开闭供油管道。

此换向阀采用大扭矩直流减速电机驱动换向，因此即使在恶劣的工况下（如低温或粘度很高的润滑脂），换向动作也十分可靠。

恒流量调节阀（自力式流量控制阀）原理图恒流量调节阀的特点一、技术性能：1、流量调节范围宽：最大流量为最小流量的10至20倍。

2、压差控制范围大：为0.03Mpa ~ 0.45Mpa。

3、流量控制精度高：相对误差仅为5%-8%。

二、新型的专利结构：1、新型的阀瓣：获得中国专利，并已通过国际专利初审。

2、全部构件装在同一轴线上：为上部可拆卸的单向结构，维护清理方便。

3、可采取多种驱动方式：其手动简便直观，并可实施电动、自控和遥控。

4、符合截止阀的标准结构长度：为传统的外形，小巧的体积。

5、感压元件采用金属波纹管：可靠性高，使用寿命长。

三、加工精密、材质优良：1、产品加工精度高，装配精密，并逐台通过严格的实测和检定。

2、阀瓣、阀轴均采用青铜铸件加工制造。

（美标954）3、金属波纹管和阀内紧固件的材质均为不锈钢（美标316）。

4、阀壳、手轮为精密铸件，外表喷涂环氧树脂防腐。

集中供暖分户热计量的技术措施分户热计量是采用热量商品化设备、室温手动和自动调控设备实现节能供暖，并促使用户主动节能的综合技术措施。

热量表（热量商品化设备）——实现按照用户的用热量收费，使热量真正成为商品；散热器恒温控制阀（室温手动和自动调控设备）——热量的使用者可以根据自己的需求，主动地调节用热量，与此同时它的自动控制装置可根据用户对室温的要求自动调节用热量。

压差控制阀——为散热器恒温控制阀提供合适的和稳定的工作压头，保障它正常可靠的工作恒流量调节阀——消除动态和稳态失调，保障未分户热计量的用户正常供暖；变频调速泵——根据用户的需求提供可靠的流量和扬程，保障正常供暖的同时降低电耗；锅炉运行自控系统——根据室外气候和用户的需要，自动调节控制产热量，以最小的能耗保证供热，同时保障锅炉在最佳状态下高效运行；。

Precision pressure regulators LRP/LRPSPrecision pressure regulators LRP, size 40Peripherals overviewPeripherals overviewPrecision pressure regulator LRP-1/8-6Precision pressure regulator LRP-7.0-62d I nternet: /catalogue/...Subject to change – 2023/10Precision pressure regulators LRP, size 40 Type codesType codes32023/10 – Subject to change d I nternet: /catalogue/...Precision pressure regulators LRP, size 40 DatasheetFunction-M-Flow rate300 l/min-Q-Temperature range–10 ... +60°C-L-Operating pressure1 ... 8 barLRP-1/8-6LRP-7.0-6H--NoteA manifold block MRS is required to connect the precision pressure regu-lator LRP-7.0-6 to the compressed air supply. The mounting kit with screws and sealing rings is included with the device.The precision pressure regulator issuitable for sensitive applications thatrequire a pressure hysteresis of0.02 bar. The output pressure p2 canbe set within the pressure regulationrange.In the event of a failure of the com-pressed air supply, the output pres-sure p2 is exhausted via port 3 (sec-ondary exhausting).• Precision pressure adjustment pos-sible both in static and dynamic ap-plications• Operating pressure fluctuations arealmost entirely compensated• Good response characteristics dur-ing rapid changes to operating pres-sure and flow rate1)Measured at p1 = 8 bar and p2 = 6 bar, Δp2 = 100 mbar.2)Measured on manifold block MRS-4 at p1 = 8 bar and p2 = 6 bar, Δp2 = 100 mbar.1)More information: /x/topic/crc4d I nternet: /catalogue/...Subject to change – 2023/10Precision pressure regulators LRP, size 40DatasheetMaterialsSectional viewStandard flow rate qn as a function of output pressure p2LRP-1/8-6LRP-7.0-6Operating pressure p1 = 8 bar Operating pressure p1 = 8 barStandard flow rate qn2-3 through secondary exhausting as a function ofoutput pressure p2Output pressure p2 as a function of operating pressure p1Operating pressure p1 = 8 bar5 2023/10 – Subject to change d I nternet: /catalogue/...6d I nternet: /catalogue/...Subject to change – 2023/10Precision pressure regulators LRP, size 40DatasheetInternal air consumption qn as a function of operating pressure p1max.min.Precision pressure regulators LRP/LRPS, size 50 Peripherals overviewPeripherals overviewPrecision pressure regulator LRP Precision pressure regulator LRPS7 2023/10 – Subject to change d I nternet: /catalogue/...Precision pressure regulators LRP/LRPS, size 50 Type codesType codes8d I nternet: /catalogue/...Subject to change – 2023/1092023/10 – Subject to change d I nternet: /catalogue/...Precision pressure regulators LRP/LRPS, size 50DatasheetFunction-M- Flow rate800 ... 2300 l/min -Q- Temperature range –10 ... +60°C -L-Operating pressure 1 ... 12 bar-É-The precision pressure regulator con-trols the operating pressure (secondary side) using a diaphragm pilot control. This acts on the main seat and thus improves the regulating characteris-tics.• Precision pressure adjustment pos-sible both in static and dynamic ap-plications• Pressure hysteresis of < 0.02 bar for flow rate characteristic curves • Good response characteristics dur-ing rapid changes to input pressure and flow rate• Input pressure fluctuations are al -most entirely compensated • Product variants LRP-...-EX4 can be used in zones 1 and 2 of explosive gas atmospheres and in zones 21 and 22 of explosive dust atmos-pheres1)Measured at p1 = 12 bar and Δp2 = 100 mbar.1)More information: /x/topic/crc10d I nternet: /catalogue/...Subject to change – 2023/10Precision pressure regulators LRP/LRPS, size 50DatasheetMaterialsSectional viewqn [l/min]500100015002000250000.511.522.533.54qn [l/min]5001000150020002500300001234567891011Operating pressure p1 = 5 ... 12 bar Operating pressure p1 = 7 ... 12 bar Operating pressure p1 = 10 ... 12 bar Operating pressure p1 = 5 barOperating pressure p1 = 7 bar Operating pressure p1 = 10 bar Operating pressure p1 = 12 barPrecision pressure regulators LRP/LRPS, size 50 DatasheetInternal air consumption qn as a function of operating pressure p1Operating pressure p1 = 5 ... 12 barPrecision pressure regulators LRP/LRPS, size 50Datasheetp1 [bar]01234567891011122p1 [bar]7891011127.927.947.967.988Precision pressure regulators LRP/LRPS, size 50 DatasheetPrecision pressure regulators LRP/LRPS AccessoriesManifold block MRSFor precision pressure regulator LRP-7.0-6• For manifold assembly of 2 or 4 valves• Continuous compressed air supply in the manifold block• G3/8 connection for compressed air supply, G1/8 connections for work-ing pressure• Vacant positions can be sealed with blanking plugsOperating pressure: –0.9 ... 10 bar Material:Wrought aluminium alloyRoHS-compliant MRS-4MRS-21)More information: /x/topic/crcPrecision pressure regulators LRP/LRPS AccessoriesMounting bracket HRFor precision pressure regulatorLRP/LRPS, size 50• For wall mountingMaterial: Galvanised steel LABS (PWIS) conformity:VDMA24364-B1/B2-L1)More information: /x/topic/crc2)Recommended for production systems for manufacturing Li-ion batteries. More information: /x/topic/bat. Regulator lock LRVS-LRPFor precision pressure regulator LRP,size 50Material:Cap: Polyacetal Locking plate: Steel Knurled nut: AluminiumLABS (PWIS) conformity: VDMA24364-B1/B2-LAmbient temperature:–20 ... +60°CPadlock LRVS-DFor precision pressure regulator LRP, size 50Material:Housing: BrassLABS (PWIS) conformity:VDMA24364-B1/B2-LPrecision pressure regulators LRP/LRPS Accessories。

3D工程图学应用与提高手压阀装配实例手压阀的结构与工作原理l 手压阀的结构如图所示。

手压阀是开启或关闭液路的一种手动阀门。

手柄向下压紧阀杆时，弹簧受压，阀杆向下移动，使入口和出口相通，阀门打开；松开手柄，因弹簧力作用，阀杆向上压紧阀体，入口与出口不通，阀门关闭。

l 手压阀的结构1—球头；2—手柄；3—销；4—销钉；5—阀杆；6—螺套；7— 阀体；8—填料；9—弹簧；10—调节螺钉；11—胶垫(1) 创建手压阀的所有零件。

(2) 新建一部件文件，选择“新建”→“Standard.iam”。

(3) 单击“放置”按钮 ，在弹出的对话框中找到需要装入的零部件路径，装入阀体零件，单击鼠标右键结束。

为清晰说明手压阀内部的装配情况，在第10步之前采用1/4剖的阀体，练习时请直接使用阀体零件。

(4) 单击“放置”按钮 ，在弹出的对话框中，选择装入阀杆零件。

(5) 安装阀杆 单击“约束”按钮 ，弹出【放置约束】对话框，单击“配合”按钮 ，将约束类型设置为“面对面” 。

选取阀体上阀座的锥面与阀杆上的锥面，使它们面贴合，单击“应用”按钮，此时阀杆除了能绕自身的轴线转动，其他的自由度都被限制，如图所示。

安装阀杆(6) 安装弹簧 使用设计加速器设计弹簧，然后装配。

点击菜单栏“工具”，选择“自定义”图标，在弹出来的对话框中选择“工具栏”，将设计加速器显示。

选择“压缩弹簧生成器” ，弹出【压缩弹簧零部件生成器】对话框。

选择弹簧放置的轴为阀杆的轴线，然后在对话框中输入弹簧的参数，弹簧的长度为62 mm，弹簧钢丝直径为4 mm，弹簧总圈数为8.5，弹簧有效圈数为6，弹簧为右旋，生成符合参数要求并在阀杆轴线上的弹簧。

此时弹簧只可沿阀杆的轴线移动，选择“配合”按钮 ，将约束类型设置为“面对面” ，选择阀杆上的安装面与弹簧的末端的平面，点击应用，将弹簧安装完成，如图所示。

安装弹簧有缘学习更多＋谓ｙｇｄ３０７６考证资料或关注桃报：奉献教育（店铺）(7) 安装胶垫 单击“放置”按钮 ，在弹出的对话框中，选择装入胶垫零件。
