DA14580最小蓝牙模块MN581A 模块是针对无线智能产品设计的一款超低功耗的,超小体积的蓝牙模块。
基于德国DAILOG超级蓝牙芯片DA14580设计，包含天线部分仅有5.50mm*8.0mm,高度仅有1.7mm 片上集成32 位ARM Cortex M0™处理器国际标准的Blue-tooth® Smart协议栈。
特别适合对体积和高度有特殊需求的智能穿戴式设备。
例如智能手环，蓝牙手表、无线键盘、无线鼠标、平板电脑、手机、笔记本电脑等产品。
可帮助客户快速开发蓝牙4.0产品。
1.1 主要的特点超低功耗最小尺寸内嵌16MHZ32位ARMCortexM0™处理器专用链路层处理器内置aes-128位加密处理器-Time-Programmable(OTP)内存系统SRAM记忆存储器支持多个数字接口：通用I/o、2个UARTs与硬件流控制1MBd、SPI+™接口总线在100kHz,400千赫硬件正交解码能力支持模拟接口设备内置4通道10-bitADC完全集成2.4GHzCMOS收发器单线天线:内置50欧姆天线匹配直接连接2.4G的天线电源电流:传输输出功率-93dBm接收机灵敏度1.2 应用市场智能穿戴式设备蓝牙手表无线键盘无线鼠标平板电脑手机笔记本电脑1.3 管脚定义及尺寸图名称功能输入输出说明GND 接地—VCC模块电源正极2.7V to3.3V—支持聚合物（需降压）、钮扣电池P0_6/TX 模块串口发送端OP0_5/RX 模块串口接收端IP0_3 模块状态切换脚I模块状态切换脚（下降沿唤醒、上升沿睡眠）P0_0 蓝牙数据引脚O蓝牙数据引脚（蓝牙连接\断开\接收数据时都会使此IO 电平变换）VPP,SW_CLK,SWDIO-- 调试软件用VPP,SW_CLK,SWDIO1.5 外围参考设计1.6 模块功耗睡眠模式：2uA唤醒后功耗：500uA连接状态功耗（以1k的发送速率）：625uA1.7 模块工作说明本模块为透传模块，在配置完模块的对应I/O 后，应切换下P0_3 的高低电平以保证，模块处于用户所希望的状态（睡眠或者唤醒）。
BDF002-如何将产测程序（prod_test）与应用程序放在同一个img文件中--避免生产时需要烧录两次程序的麻烦文档版本：v0.0.1蓝牙生产过程中，对其进行RF性能测试是不可避免的流程，官方在SDK中提供了DA1458x的RF测试工程prod_test，那么问题来了，为了测试，产线上先得烧录一个prod_test程序，测试完毕再烧录最终的应用软件，这样无疑增加了产线的负担，从而令生产成本上升。
那么，能不能一次性解决问题呢？当然是可以的。
这里我们以DA14580为例：当然，需要进行这样的操作，DA14580必须外挂FLASH，且空间必须能放下我们所需要的所有代码。
本文的最终目的是制作一个烧录镜像，此镜像包含了最终的量产程序、prod_test程序以及支持OTA的bootloader，通过一个IO口来配置需要运行的程序，如：P01拉低，则程序进入prod_test程序；P01拉高（浮空），则进入正常工作程序。
我们这里以支持SUOTA的img为基础，在这之前，我们需要一些工具，此工具并非SDK中原版的工具，是经过改良的：其中hex2bin.exe为hex转换为bin文件的工具，此工具SDK中已存在，直接用即可；Mkimage.exe为制作img的工具，基于SDK中对应工程修改而来；Prod_test_580.bin为测试用的prod_test程序，直接用SDK中的工程生成即可；Secondary_bootloader.hex需要根据SDK中对应工程修改。
为了方便大家，以上工具我做了一个下载地址，有需要可直接下载，具体地址见文章最后。
看到这里，镜像文件基础上，在FLASH（EEPROM）的最后增加一个prod_test应用程序，在bootloader启动的时候，通过IO口选择时跳转到fw_x.img还是跳转到prod_text.img。
这样就实现了我们之前提出的功能，一个程序解决程序烧录以及RF测试。
如何利用官方开发板(DA14580 B luetooth S mart d evelopment K it-‐Pro)测功耗文档版本：v0.0.2本文主要介绍如何利用官方开发板DA14580/581/583 B luetooth S mart development K it-‐Pro（下文简称KitPro） 和软件SmartSnippets来测试DA14580/581/583（下文只简称为DA14580）的功耗。
Kit-‐Pro是Dialog官方推出的开发板之一，属于不同档次中的一种，自带Jlink、串口，能够用SmartSnippets配合测功耗。
KitPro分母板和子板，子板根据芯片不同有不同选择，在测功耗方面无太大差别，这里不再做过多说明。
SmartSnippets是Dialog官方的一款工具，可以在官网上下载到（当然前提是要注册一个账号），关于工具的使用，也不是本文重点，请查看其它相关说明。
接下来我们一步步说明功耗测试方法：首先，按照UART方式连接跳线帽（具体查看开发板上的丝印），先拔掉小板，然后用USB连接电脑，正常的话会自动安装所有驱动，否则请自行在网上寻找相关驱动。
然后打开SmartSnippets，打开后会出现以下界面：首次打开左边的框内是没有工程信息的，需要新建一个，点击“New”按钮出现以下对话框：Project N ame随便输入一个，然后点“Save”。
选择刚刚创建的Project，并按照下图选择，最后“Open”。
打开后出现以下界面（可能会不同），选择左侧第一个图标，会打开“Board Setup”对话框，确保串口选择的是“P0_4,P0_5”.选择左边第三个按钮出现“Power P rofiler”对话框，点击下面的“Initialize”按钮。
然后点击“Start”：这时软件会运行，查看右上角“Avg C urret”下的数值并记下：点击“Stop”，然后点击“Config”：在新出来的对话框中，“Calibration O ffset”中填入刚刚记录的数值的负数，前面测出来的值是板子的电流（不包含DA14580小板，前面已经拔掉啦，如果没拔掉，那拔掉重测），因为我们要测的是小板的电流，所以这个主板电流需要减去。
产品概述E104-BT02是一款超高性价比的1mW（0dBm）串口转BLE模块，使用PCB天线。
工作在2.4GHz频段。
模块可使用串口收发蓝牙数据，降低了蓝牙应用的门槛。
E104-BT02模块是基于Dialog公司的DA14580芯片研发，模块集成了透传功能、主从一体，即拿即用。
支持串口指令配置模块参数和功能，广泛应用于穿戴设备、家庭自动化、家庭安防、个人保健、智能家电、配饰与遥控器、汽车、照明、工业互联网等领域，模块具有稳定性高和超低的睡眠功耗，从机模式最低工作电流2uA以下（开启广播功能），可实现纽扣单电池供电。
数据传输稳定高效，从机模式下，支持波特率最大19200bps的数据连传功能，是一款名副其实的数据透传模块。
E104-BT02模块支持BluetoothV4.2标准，简单配置后可与符合蓝牙4.2协议的主机建立蓝牙连接，实现串口数据透传。
模块支持主从角色配置，支持主从模块点对点连接实现数据快速透传功能。
最大限度减少开发者的工作和项目开发时间。
目录产品概述 (3)1.产品特点62.典型应用： (6)3.技术参数74.机械特性85.功能简述95.1.封装95.2.推荐连线图95.3.工作模式95.4.数据有效指示 (10)5.5.角色切换105.6.MAC地址绑定 (10)5.7.串口连传105.8.蓝牙包长配置 (10)5.9.UUID配置115.10.蓝牙嗅探115.11.B EACON数据可切换 (11)5.12.空中配置126.操作指令126.1.模块复位指令 (13)6.2.恢复出厂模式 (13)6.3.串口波特率配置指令 (13)6.4.读串口波特率指令 (13)6.5.串口停止位配置指令 (14)6.6.读串口停止位指令 (14)6.7.串口校验位配置指令 (14)6.8.读串口校验类型 (14)6.9.开启广播指令 (14)6.10.停止广播指令 (14)6.11.查询广播状态 (14)6.12.设置普通广播数据 (15)6.13.设置IB EACON广播数据 (15)6.14.设置固定广播数据 (15)6.15.设备名设置156.16.读设备名156.17.设置厂商名156.18.读厂商名156.19.设置软件版本号 (16)6.20.读软件版本号 (16)6.21.设置硬件版本号 (16)6.22.读硬件版本号 (16)6.23.设置模块SN号 (16)6.24.读模块SN号 (16)6.25.设置S YSTEM ID (16)6.26.查询S YSTEM ID (17)6.27.设置模块编号 (17)6.28.查询模块编号 (17)6.29.设置广播间隙 (17)6.30.读广播间隙176.31.设置最大连接间隙 (17)6.32.读最大连接间隙 (17)6.33.设置最小连接间隙 (18)6.34.读最小连接间隙 (18)6.35.设置连接超时 (18)6.36.读连接超时186.37.断开当前连接 (18)6.38.查询蓝牙连接状态 (18)6.39.查询本地MAC地址 (18)6.40.查询已连接设备MAC地址 (19)6.41.设置绑定连接的MAC地址 (19)6.42.读设定的绑定MAC地址 (19)6.43.关闭MAC地址过滤 (19)6.44.开启模式反馈 (19)6.45.关闭模式反馈 (19)6.46.启动扫描196.47.停止扫描206.48.读扫描状态206.49.设置扫描间隙 (20)6.50.查询扫描间隙 (20)6.51.设置扫描窗口时间 (20)6.52.查询扫描窗口时间 (20)6.53.开启嗅探功能 (20)6.54.关闭嗅探功能 (21)6.55.读取当前RSSI值 (21)6.56.打开128BIT UUID显示 (21)6.57.关闭128BIT UUID显示 (21)6.58.设置服务名UUID (21)6.59.设置RXUUID (21)6.60.设置TXUUID216.61.设置MTU长度 (22)6.62.查询MTU长度 (22)6.63.查询设备角色 (22)6.64.串口唤醒开226.65.串口唤醒关226.66.开启数据输出指示 (22)6.67.关闭数据输出指示 (22)6.68.进入休眠后关闭蓝牙连接 (23)6.69.进入休眠后保持蓝牙连接 (23)6.70.空中配置密码认证 (23)6.71.空中配置密码更新 (23)7.UUID说明 (23)8.快速使用239.生产指导2710.常见问题2811.重要声明2812.关于我们错误!未定义书签。
