第1章切削加工基础知识切削加工概述切削cutting;加工machining;金属切削metal cutting (metal removal);金属切削工艺metal-removal process; 金属工艺学technology of metals;机器制造machine-building;机械加工machining;冷加工cold machining；热加工hot working;工件workpiece;切屑chip;常见的加工方法universal machining method;钻削drilling;镗削boring;车削turning；磨削grinding;铣削milling;刨削planning;插削slotting;锉filing ;划线lineation;錾切carving;锯sawing;刮削facing;钻孔boring;攻丝tap;零件表面构成及成形方法变形力deforming force;变形deformation;几何形状geometrical;尺寸dimension;精度precision;表面光洁度surface finish;共轭曲线conjugate curve;范成法generation method;轴shaft;机床的切削运动及切削要素主运动main movement;主运动方向direction of main movement; 进给方向direction of feed;进给运动feed movement;合成进给运动resultant movement of feed;合成切削运动resultant movement of cutting;合成切削运动方向direction of resultant movement of cutting ;切削速度cutting speed;传动drive/transmission;切削用量cutting parameters;切削速度cutting speed;切削深度depth of cut;进给速度feed force;切削功率cutting power;金属切削刀具合金工具钢alloy tool steel;高速钢high-speed steel;硬质合金hard alloy;易加工ease of manufacturing ;切削刀具cutting tool;1刀具cutter;车刀lathe tool;主切削刃main cutting edge;副切削刃assistant cutting edge;刀体tool body ;刀柄tool shank;前刀面rake face;主后刀面major flank;刀尖nose of tool;主剖面系tool orthogonal plane system;切削平面tool cutting edge plane;主剖面tool orthogonal plane;切削宽度width of the uncut chip;进给平面系assumed working plane system;加工表面transient surface;前角rake angle;后角clearance angle;主偏角tool cutting edge angle;刀尖角nose angle;刀具切削过程及磨削机理塑性变形plastic distortion;微观组织，显微结构microstructure ;切削力cutting force;切削温度cutting temperature;积屑瘤built-up edge;刀尖磨损nose wear;月牙洼crater;残留应力residual stress;应力stress;硬度rigidity;磨削grinding;砂轮grinding wheel;磨粒grain;剪切shear;摩擦friction;内力internal force;~ 切削加工质量、材料的切削加工性、切削液的选择加工精度machining accuracy;表面质量surface finish;工艺性能technological performance;材料切削加工性指标machinability index of material;切削液cutting fluid ;切削油cutting oil;件的装夹及夹具定位梢dowel;定位allocation;机床夹具jig;组装线Assembly line;机械零件mechanical parts;钳工locksmith；精加工finish machining;粗加工rough machining;气动夹紧pneuma-lock;同心，同心度concentricity ;垂直度perpendicular;基准benchmark;基准线reference line;夹具fixture;通用夹具universal fixture;专用夹具Fixture for special purpose;2可调夹具adjustable fixture;组合夹具modular fixture;工序process;设计基准designing datum;工艺基准datum features in process;金属切削机床machine tool;机床运动motion of machine;机床型号machine tool model;机床加工精度machining accuracy of machine tool;车床lathe;普通车床engine lathe;卧式车床horizontal lathe;立式车床vertical lathe;钻床drill press;镗床boring machine;铣床milling machine;grinder（grinding machine）;牛头刨床shaper;龙门刨床planer;插床slotting machine（slotter）;第2章常用加工方法综述及加工方案选择一、车削车削turning;车刀lathe tool ;车床lathe ;普通车床engine lathe;卧式车床horizontal lathe;立式车床vertical lathe; 仿形车床duplicating lathe (copy lathe); 转塔车床turret lathe;细长轴long slender shaft纵向车削straight turning;锥体车削taper turning;仿形车削contour turning;端面车削facing;回转表面surface of revolution;平面flat surface;圆面round surface ;仿形表面contoured surface ;退刀槽recess ;卡盘chuck;尾架tailstock;床头箱，主轴箱headstock;销pin;卡箍bar clasp;花盘faceplate;主轴spindle;二、钻削钻削drilling;钻床drill press;钻头drill;锪孔counter boring;内表面internal surface ;铰孔、扩孔reaming;攻丝tapping;孔加工spot facing machining;铰ream;铰刀reamer;盲孔blind hole;麻花钻twist drill;3埋头孔countersink;锥柄taper shank;三、镗削镗削bore;镗床boring machine;镗杆boring bar ;纵向镗削straight boring;表面光洁度surface finish;卧式镗孔机horizontal boring machine;四、铣削铣削mill;铣床milling machine ;铣刀milling cutter;缝Slot ;槽groove;平面flat surface;圆面round surface ;仿形表面contoured surface;周铣Peripheral milling ;端铣face milling; multi model miller;靠模铣床; copy milling machine;仿形铣床; contouring machine;五、磨削磨削grinding;grinder（grinding machine）;外圆磨削external grinding;内圆磨削internal grinding(cylindrical grinding);平面磨削plane grinding abrasive;外圆磨床cylindrical grinding machine; 平面磨床surface grinder;外圆磨床cylindrical grinding machine ;内圆磨床internal cylindrical machine;成形磨床form grinding machine;仿形磨床copy grinding machine ;万能工具磨床universal tool grinding machine;六、拉削拉削broaching;broaching machine;拉刀broaching tool;外表面拉削external surface broaching;内表面拉削internal surface broaching;多功能机床multifunction machine;多齿刀具multitooth tool;切屑槽chip gullet;七、刨削刨削planning;牛头刨床shaper;龙门刨床planer;龙门刨削planning;旋臂刨床radial drilling machine ;仿形刨床copy shaping machine;八、加工加工gear machining;齿轮gear;滚齿gear hobbing;滚齿刀hobbing cutter;直齿圆柱straight toothed spur gear;斜齿圆柱齿轮helical-spur gear;4直齿锥齿轮straight bevel gear ;齿轮齿条pinion and rack;蜗轮worm and worm gear;九、螺纹加工螺纹加工thread machining;螺纹切削thread cutting;攻丝tapping;丝锥tap;板牙die;螺钉screw;标准件standard component;位移displacement ;截面section;十、光整加工光整加工micro finishing;研磨mull (lapping);研磨剂lapping compound;研磨膏paste;研磨机床lapping machine抛光polishing ;抛光膏buffing cream;抛光轮polishing wheel;抛光机polisher ;珩磨honing ;珩磨轮honing wheel;珩磨机床honing machine;超精加工机床superfinishing machine;超精加工superfinish;第3章机械加工工艺过程机械加工工艺过程machining process;工步step of an operation;工位work station;工序process;工艺文件manufacturing process document;工艺卡片technological card;工艺规程process plan;机械加工工艺卡machining process sheet; 工艺设计technological design;设计基准designing datum;工艺基准datum features in process;基准重合consistency of datum feature;基面统一原则unified datum principle;机械加工工序卡machining operation sheet;工艺过程设计process planning;;工艺路线process route;工艺过程卡process sheet;产品规格product specification;产品用途product use;产品责任product liability;生产线production line;生产进度计划production schedule;生产率productivity;批量生产batch production;第4章切削加工零件结构工艺性切削cutting;加工machining;工件workpiece;零件part;毛坯rough;工艺性能processing property;5装配结构的合理性rationality of assembly structure;零件结构合理性rationality of detail structure;标准化standardization;第5章先进制造技术先进制造技术Advanced Manufacturing Technology;信息技术information Technology;产品product;设计design；加工machining;检测check;管理manage;销售sell;使用use;服务serve;回收reclaim;计算机集成制造系统Computer Integrated Manufacturing System（CIMS）;智能制造系统Intelligent Manufacturing System (IMS);精密工程precise engineering;成组技术group technology;方式（法）methodology;柔性制造系统Flexible Manufacturing System（FMS）;数控机床numerically controlled machine tool;加工中心Machining Center（MC）;计算机数字控制computerized numerical control (CNC);自动换刀装置automatic tool changer （ATC）;直接数字控制Direct numerical control （DNC）;分布式数字控制Distributed numerical control（DNC）;群控DNC;单机自动化stand-alone automatization ;自动机床Automatic machine;组合机床combination machine;专用机床special machine;NC钻床NC drilling machine ;NC磨床NC grinding machine ;NC车床NC lathe ;卧式加工制造中心horizontal machine center;立式加工制造中心vertical machine center;车间shop floor;库存inventory;工艺process;分类classification;编码系统coding system;零件外型part configuration;工艺规划process planning;单元式制造cellular manufacturing;小车维修站Cart maintenance station;零件清洗站Parts wash station;装卸站Unload station;回收系统Recovery system;小车转弯站Cart turnaround station；集成化integration ;协调tradeoff;6成族零件family-of-part;换刀装置Tool changer;机床控制装置machine control unit;组装线Assembly line;第6章先进制造运行模式先进制造运行模式Advanced Manufacturing Operation Model;计算机集成制造系统Computer Integrated Manufacturing Systems （CIMS）;精益生产(LP亦称精良生产)Lean Production;敏捷制造Agile Manufacturing（AM）;绿色制造Green Manufacturing;计算机辅助设计Computer Aided Design(CAD);计算机辅助制造Computer Aided Manufacturing(CAM);计算机辅助工艺过程设计Computer Aided process planning(CAPP);物料需求计划Material Requirements Planning（MRP）;计算机辅助教育Computer Aided Education (CAE);虚拟制造Virtual Manufacturing(VM);并行工程Concurrent Engineering (CE);面向装配的设计Design For Assembly(DFA);面向制造的设计Design For Manufacturing(DFM);第7章特种加工特种加工（NTM）Nontraditional Manufacturing;一、电火花加工电火花加工spark-erosion machining;电火花加工electrical discharge wire – cutting;电火花穿孔spark-erosion drilling;电火花雕刻spark-erosion carving;二、电解加工电解加工Electrolytic machining;三、超声波加工超声波加工Ultrasonic machining;变幅杆Transducer nose ;铜垫圈Copper washer;放大刀具夹持器Amplifying tool holder ; 超声波振动Ultrasonic vibration;银钎焊Sliver braze;仿形刀具Shaped tool;蜡焊缝Wax weld ;支持材料Backup material;磨料悬浮液Abrasive slurry;吸入管Suction line ;四、激光加工激光加工Laser processing;激光束加工Laser beam machining ;激光切割laser cutting ;激光打孔laser drilling;激光焊接laser welding;7。

第1章切削加工基础知识1.1切削加工概述切削cutting;加工machining;金属切削metal cutting (metal removal); 金属切削工艺metal-removal process; 金属工艺学technology of metals;机器制造machine-building;机械加工machining;冷加工cold machining；热加工hot working;工件workpiece;切屑chip;常见的加工方法universal machining method;钻削drilling;镗削boring;车削turning；磨削 grinding;铣削milling;刨削planning;插削slotting ;锉filing ;划线lineation;錾切carving;锯sawing;刮削facing;钻孔boring;攻丝tap;1.2零件表面构成及成形方法变形力deforming force;变形deformation; 几何形状geometrical;尺寸dimension ;精度precision;表面光洁度surface finish;共轭曲线conjugate curve;范成法generation method;轴shaft;1.3机床的切削运动及切削要素主运动main movement;主运动方向direction of main movement; 进给方向direction of feed;进给运动feed movement;合成进给运动resultant movement of feed;合成切削运动resultant movement of cutting;合成切削运动方向direction of resultant movement of cutting ;切削速度cutting speed;传动drive/transmission;切削用量cutting parameters;切削速度cutting speed;切削深度depth of cut;进给速度feed force;切削功率cutting power;1.4金属切削刀具合金工具钢alloy tool steel;高速钢high-speed steel;硬质合金hard alloy;易加工ease of manufacturing ;切削刀具cutting tool;刀具cutter;车刀lathe tool;主切削刃main cutting edge;副切削刃assistant cutting edge;刀体tool body ;刀柄tool shank;前刀面rake face;主后刀面major flank;刀尖nose of tool;主剖面系tool orthogonal plane system;切削平面tool cutting edge plane;主剖面tool orthogonal plane;切削宽度width of the uncut chip;进给平面系assumed working plane system;加工表面transient surface;前角rake angle;后角clearance angle;主偏角tool cutting edge angle;刀尖角nose angle;1.5刀具切削过程及磨削机理塑性变形plastic distortion;微观组织，显微结构microstructure ;切削力cutting force;切削温度cutting temperature;积屑瘤built-up edge;刀尖磨损nose wear;月牙洼crater;残留应力 residual stress;应力stress;硬度rigidity;磨削grinding; 砂轮grinding wheel;磨粒grain;剪切shear;摩擦friction;内力internal force ;1.6~1.8 切削加工质量、材料的切削加工性、切削液的选择加工精度machining accuracy;表面质量surface finish;工艺性能technological performance;材料切削加工性指标machinability index of material;切削液cutting fluid ;切削油cutting oil;1.9 件的装夹及夹具定位梢dowel;定位allocation;机床夹具jig;组装线Assembly line;机械零件mechanical parts;钳工locksmith；精加工finish machining;粗加工rough machining;气动夹紧pneuma-lock;同心，同心度concentricity ;垂直度perpendicular;基准benchmark;基准线reference line;夹具 fixture;通用夹具universal fixture;专用夹具Fixture for special purpose;可调夹具adjustable fixture;组合夹具modular fixture;工序process;设计基准designing datum;工艺基准datum features in process;1.10 金属切削机床机床machine tool;机床运动motion of machine;机床型号machine tool model;机床加工精度machining accuracy of machine tool;车床lathe;普通车床engine lathe;卧式车床horizontal lathe;立式车床vertical lathe;钻床drill press;镗床boring machine;铣床milling machine;磨床grinder（grinding machine）;牛头刨床shaper;龙门刨床planer;插床slotting machine（slotter）;第2章常用加工方法综述及加工方案选择一、车削车削turning;车刀lathe tool ;车床lathe ;普通车床engine lathe;卧式车床horizontal lathe;立式车床vertical lathe; 仿形车床duplicating lathe (copy lathe); 转塔车床turret lathe;细长轴long slender shaft纵向车削straight turning;锥体车削taper turning;仿形车削contour turning;端面车削facing;回转表面surface of revolution;平面flat surface;圆面round surface ;仿形表面contoured surface ;退刀槽recess ;卡盘chuck;尾架tailstock;床头箱，主轴箱headstock;销pin;卡箍bar clasp;花盘faceplate;主轴spindle;二、钻削钻削drilling;钻床drill press;钻头drill;锪孔counter boring;内表面internal surface ;铰孔、扩孔reaming;攻丝tapping;孔加工spot facing machining;铰ream;铰刀reamer;盲孔blind hole;麻花钻twist drill;埋头孔countersink;锥柄taper shank;三、镗削镗削bore;镗床boring machine;镗杆boring bar ;纵向镗削straight boring;表面光洁度surface finish;卧式镗孔机horizontal boring machine;四、铣削铣削mill;铣床milling machine ;铣刀milling cutter;缝Slot ;槽groove;平面flat surface;圆面round surface ;仿形表面contoured surface;周铣Peripheral milling ;端铣face milling; multi model miller;靠模铣床; copy milling machine;仿形铣床; contouring machine;五、磨削磨削grinding;磨床grinder（grinding machine）;外圆磨削external grinding;内圆磨削internal grinding(cylindrical grinding);平面磨削plane grinding abrasive;外圆磨床cylindrical grinding machine; 平面磨床surface grinder;外圆磨床cylindrical grinding machine ; 内圆磨床internal cylindrical machine;成形磨床form grinding machine;仿形磨床copy grinding machine ;万能工具磨床universal tool grinding machine;六、拉削拉削broaching;拉床broaching machine;拉刀broaching tool;外表面拉削external surface broaching; 内表面拉削internal surface broaching;多功能机床multifunction machine;多齿刀具multitooth tool;切屑槽chip gullet;七、刨削刨削planning;牛头刨床shaper;龙门刨床planer;龙门刨削planning;旋臂刨床radial drilling machine ;仿形刨床copy shaping machine;八、齿轮加工齿轮加工gear machining;齿轮gear;滚齿gear hobbing;滚齿刀hobbing cutter;直齿圆柱齿轮straight toothed spur gear;斜齿圆柱齿轮helical-spur gear;直齿锥齿轮straight bevel gear ;齿轮齿条pinion and rack;蜗杆蜗轮worm and worm gear;九、螺纹加工螺纹加工thread machining;螺纹切削thread cutting;攻丝tapping;丝锥tap;板牙die;螺钉screw;标准件standard component;位移displacement ;截面section;十、光整加工光整加工micro finishing;研磨mull (lapping);研磨剂lapping compound;研磨膏paste;研磨机床lapping machine抛光polishing ;抛光膏buffing cream;抛光轮polishing wheel;抛光机polisher ;珩磨honing ;珩磨轮honing wheel;珩磨机床honing machine;超精加工机床superfinishing machine; 超精加工superfinish;第3章机械加工工艺过程机械加工工艺过程machining process;工步step of an operation;工位work station;工序process;工艺文件manufacturing process document;工艺卡片technological card;工艺规程process plan;机械加工工艺卡machining process sheet; 工艺设计technological design;设计基准designing datum;工艺基准datum features in process;基准重合consistency of datum feature; 基面统一原则unified datum principle;机械加工工序卡machining operation sheet;工艺过程设计process planning;;工艺路线process route;工艺过程卡process sheet;产品规格product specification;产品用途product use;产品责任product liability;生产线production line;生产进度计划production schedule;生产率productivity;批量生产batch production;第4章切削加工零件结构工艺性切削cutting;加工machining;工件workpiece;零件part;毛坯rough;工艺性能processing property;装配结构的合理性rationality of assembly structure;零件结构合理性rationality of detail structure;标准化standardization;第5章先进制造技术先进制造技术Advanced Manufacturing Technology;信息技术information Technology;产品product;设计design；加工machining;检测check;管理manage;销售sell;使用use;服务serve;回收reclaim;计算机集成制造系统Computer Integrated Manufacturing System（CIMS）; 智能制造系统Intelligent Manufacturing System (IMS);精密工程precise engineering;成组技术group technology;方式（法）methodology;柔性制造系统Flexible Manufacturing System（FMS）;数控机床numerically controlled machine tool;加工中心Machining Center（MC）;计算机数字控制computerized numerical control (CNC);自动换刀装置automatic tool changer （ATC）;直接数字控制Direct numerical control （DNC）;分布式数字控制Distributed numerical control（DNC）;群控DNC;单机自动化stand-alone automatization ; 自动机床Automatic machine;组合机床combination machine;专用机床special machine;NC钻床NC drilling machine ;NC磨床NC grinding machine ;NC车床NC lathe ;卧式加工制造中心horizontal machine center;立式加工制造中心vertical machine center;车间shop floor;库存inventory;工艺process;分类classification;编码系统coding system;零件外型part configuration;工艺规划process planning;单元式制造cellular manufacturing;小车维修站Cart maintenance station;零件清洗站Parts wash station;装卸站Unload station;回收系统Recovery system;小车转弯站Cart turnaround station；集成化integration ;协调tradeoff;成族零件family-of-part;换刀装置Tool changer;机床控制装置machine control unit;组装线Assembly line;第6章先进制造运行模式先进制造运行模式Advanced Manufacturing Operation Model;计算机集成制造系统Computer Integrated Manufacturing Systems （CIMS）;精益生产(LP亦称精良生产)Lean Production;敏捷制造Agile Manufacturing（AM）; 绿色制造Green Manufacturing;计算机辅助设计Computer Aided Design(CAD);计算机辅助制造Computer Aided Manufacturing(CAM);计算机辅助工艺过程设计Computer Aided process planning(CAPP);物料需求计划Material Requirements Planning（MRP）;计算机辅助教育Computer Aided Education (CAE);虚拟制造Virtual Manufacturing(VM);并行工程Concurrent Engineering (CE); 面向装配的设计Design For Assembly(DFA);面向制造的设计Design For Manufacturing(DFM);第7章特种加工特种加工（NTM）Nontraditional Manufacturing;一、电火花加工电火花加工spark-erosion machining;电火花线切割加工electrical discharge wire – cutting;电火花穿孔spark-erosion drilling;电火花雕刻spark-erosion carving;二、电解加工电解加工Electrolytic machining;三、超声波加工超声波加工Ultrasonic machining;变幅杆Transducer nose ;铜垫圈Copper washer;放大刀具夹持器Amplifying tool holder ; 超声波振动Ultrasonic vibration;银钎焊Sliver braze;仿形刀具Shaped tool;蜡焊缝Wax weld ;支持材料Backup material;磨料悬浮液Abrasive slurry;吸入管Suction line ;四、激光加工激光加工Laser processing;激光束加工Laser beam machining ;激光切割laser cutting ;激光打孔laser drilling;激光焊接laser welding;（注：范文素材和资料部分来自网络，供参考。

机床加工外文翻译参考文献机床加工外文翻译参考文献(文档含中英文对照即英文原文和中文翻译)基本加工工序和切削技术基本加工的操作机床是从早期的埃及人的脚踏动力车和约翰·威尔金森的镗床发展而来的。

它们为工件和刀具提供刚性支撑并可以精确控制它们的相对位置和相对速度。

基本上讲，金属切削是指一个磨尖的锲形工具从有韧性的工件表面上去除一条很窄的金属。

切屑是被废弃的产品，与其它工件相比切屑较短，但对于未切削部分的厚度有一定的增加。

工件表面的几何形状取决于刀具的形状以及加工操作过程中刀具的路径。

大多数加工工序产生不同几何形状的零件。

如果一个粗糙的工件在中心轴上转动并且刀具平行于旋转中心切入工件表面，一个旋转表面就产生了，这种操作称为车削。

如果一个空心的管子以同样的方式在内表面加工，这种操作称为镗孔。

当均匀地改变直径时便产生了一个圆锥形的外表面，这称为锥度车削。

如果刀具接触点以改变半径的方式运动，那么一个外轮廓像球的工件便产生了；或者如果工件足够的短并且支撑是十分刚硬的，那么成型刀具相对于旋转轴正常进给的一个外表面便可产生，短锥形或圆柱形的表面也可形成。

平坦的表面是经常需要的，它们可以由刀具接触点相对于旋转轴的径向车削产生。

在刨削时对于较大的工件更容易将刀具固定并将工件置于刀具下面。

刀具可以往复地进给。

成形面可以通过成型刀具加工产生。

多刃刀具也能使用。

使用双刃槽钻钻深度是钻孔直径5-10倍的孔。

不管是钻头旋转还是工件旋转，切削刃与工件之间的相对运动是一个重要因数。

在铣削时一个带有许多切削刃的旋转刀具与工件接触，工件相对刀具慢慢运动。

平的或成形面根据刀具的几何形状和进给方式可能产生。

可以产生横向或纵向轴旋转并且可以在任何三个坐标方向上进给。

基本机床机床通过从塑性材料上去除屑片来产生出具有特别几何形状和精确尺寸的零件。

后者是废弃物，是由塑性材料如钢的长而不断的带状物变化而来，从处理的角度来看，那是没有用处的。

第1章切削加工基础知识1.1切削加工概述切削cutting;加工machining;金属切削metal cutting (metal removal);金属切削工艺metal-removal process;金属工艺学technology of metals;机器制造machine-building;机械加工machining;冷加工cold machining；热加工hot working;工件workpiece;切屑chip;常见的加工方法universal machining method;钻削drilling;镗削boring;车削turning；磨削 grinding;铣削milling;刨削planning;插削slotting ;锉filing ;划线lineation;錾切carving;锯sawing;刮削facing;钻孔boring;攻丝tap;1.2零件表面构成及成形方法变形力deforming force;变形deformation;几何形状geometrical;尺寸dimension ;精度precision;表面光洁度surface finish;共轭曲线conjugate curve;范成法generation method;轴shaft;1.3机床的切削运动及切削要素主运动main movement;主运动方向direction of main movement;进给方向direction of feed;进给运动feed movement;合成进给运动resultant movement of feed;合成切削运动resultant movement of cutting;合成切削运动方向direction of resultant movement of cutting ; 切削速度cutting speed;传动drive/transmission;切削用量cutting parameters;切削速度cutting speed;切削深度depth of cut;进给速度feed force;切削功率cutting power;1.4金属切削刀具合金工具钢alloy tool steel;高速钢high-speed steel;硬质合金hard alloy;易加工ease of manufacturing ;切削刀具cutting tool;刀具cutter;车刀lathe tool;主切削刃main cutting edge;副切削刃assistant cutting edge;刀体tool body ;刀柄tool shank;前刀面rake face;主后刀面major flank;刀尖nose of tool;主剖面系tool orthogonal plane system;切削平面tool cutting edge plane;主剖面tool orthogonal plane;切削宽度width of the uncut chip;进给平面系assumed working plane system; 加工表面transient surface;前角rake angle;后角clearance angle;主偏角tool cutting edge angle;刀尖角nose angle;1.5刀具切削过程及磨削机理塑性变形plastic distortion;微观组织，显微结构microstructure ;切削力cutting force;切削温度cutting temperature;积屑瘤built-up edge;刀尖磨损nose wear;月牙洼crater;残留应力 residual stress;应力stress;硬度rigidity;磨削grinding;砂轮grinding wheel;磨粒grain;剪切shear;摩擦friction;内力internal force ;1.6~1.8 切削加工质量、材料的切削加工性、切削液的选择加工精度machining accuracy;表面质量surface finish;工艺性能technological performance;材料切削加工性指标machinability index of material;切削液cutting fluid ;切削油cutting oil;1.9 件的装夹及夹具定位梢dowel;定位allocation;机床夹具jig;组装线Assembly line;机械零件mechanical parts;钳工locksmith；精加工finish machining;粗加工rough machining;气动夹紧pneuma-lock;同心，同心度concentricity ;垂直度perpendicular;基准benchmark;基准线reference line;夹具 fixture;通用夹具universal fixture;专用夹具Fixture for special purpose;可调夹具adjustable fixture;组合夹具modular fixture;工序process;设计基准designing datum;工艺基准datum features in process;1.10 金属切削机床机床machine tool;机床运动motion of machine;机床型号machine tool model;机床加工精度machining accuracy of machine tool;车床lathe;普通车床engine lathe;卧式车床horizontal lathe;立式车床vertical lathe;钻床drill press;镗床boring machine;铣床milling machine;磨床grinder（grinding machine）;牛头刨床shaper;龙门刨床planer;插床slotting machine（slotter）;第2章常用加工方法综述及加工方案选择一、车削车削turning;车刀lathe tool ;车床lathe ;普通车床engine lathe;卧式车床horizontal lathe;立式车床vertical lathe;仿形车床duplicating lathe (copy lathe); 转塔车床turret lathe;细长轴long slender shaft纵向车削straight turning;锥体车削taper turning;仿形车削contour turning;端面车削facing;回转表面surface of revolution;平面flat surface;圆面round surface ;仿形表面contoured surface ;退刀槽recess ;卡盘chuck;尾架tailstock;床头箱，主轴箱headstock;销pin;卡箍bar clasp;花盘faceplate;主轴spindle;二、钻削钻削drilling;钻床drill press;钻头drill;锪孔counter boring;内表面internal surface ;铰孔、扩孔reaming;攻丝tapping;孔加工spot facing machining;铰ream;铰刀reamer;盲孔blind hole;麻花钻twist drill;埋头孔countersink;锥柄taper shank;三、镗削镗削bore;镗床boring machine;镗杆boring bar ;纵向镗削straight boring;表面光洁度surface finish;卧式镗孔机horizontal boring machine;四、铣削铣削mill;铣床milling machine ;铣刀milling cutter;缝Slot ;槽groove;平面flat surface;圆面round surface ;仿形表面contoured surface;周铣Peripheral milling ;端铣face milling; multi model miller; 靠模铣床; copy milling machine;仿形铣床; contouring machine;五、磨削磨削grinding;磨床grinder（grinding machine）;外圆磨削external grinding;内圆磨削internal grinding(cylindrical grinding); 平面磨削plane grinding abrasive;外圆磨床cylindrical grinding machine;平面磨床surface grinder;外圆磨床cylindrical grinding machine ;内圆磨床internal cylindrical machine;成形磨床form grinding machine;仿形磨床copy grinding machine ;万能工具磨床universal tool grinding machine;六、拉削拉削broaching;拉床broaching machine;拉刀broaching tool;外表面拉削external surface broaching;内表面拉削internal surface broaching;多功能机床multifunction machine;多齿刀具multitooth tool;切屑槽chip gullet;七、刨削刨削planning;牛头刨床shaper;龙门刨床planer;龙门刨削planning;旋臂刨床radial drilling machine ;仿形刨床copy shaping machine;八、齿轮加工齿轮加工gear machining;齿轮gear;滚齿gear hobbing;滚齿刀hobbing cutter;直齿圆柱齿轮straight toothed spur gear; 斜齿圆柱齿轮helical-spur gear;直齿锥齿轮straight bevel gear ;齿轮齿条pinion and rack;蜗杆蜗轮worm and worm gear;九、螺纹加工螺纹加工thread machining;螺纹切削thread cutting;攻丝tapping;丝锥tap;板牙die;螺钉screw;标准件standard component;位移displacement ;截面section;十、光整加工光整加工micro finishing;研磨mull (lapping);研磨剂lapping compound;研磨膏paste;研磨机床lapping machine抛光polishing ;抛光膏buffing cream;抛光轮polishing wheel;抛光机polisher ;珩磨honing ;珩磨轮honing wheel;珩磨机床honing machine;超精加工机床superfinishing machine;超精加工superfinish;第3章机械加工工艺过程机械加工工艺过程machining process;工步step of an operation;工位work station;工序process;工艺文件manufacturing process document;工艺卡片technological card;工艺规程process plan;机械加工工艺卡machining process sheet;工艺设计technological design;设计基准designing datum;工艺基准datum features in process;基准重合consistency of datum feature;基面统一原则unified datum principle;机械加工工序卡machining operation sheet;工艺过程设计process planning;;工艺路线process route;工艺过程卡process sheet;产品规格product specification;产品用途product use;产品责任product liability;生产线production line;生产进度计划production schedule;生产率productivity;批量生产batch production;第4章切削加工零件结构工艺性切削cutting;加工machining;工件workpiece;零件part;毛坯rough;工艺性能processing property;装配结构的合理性rationality of assembly structure;零件结构合理性rationality of detail structure;标准化standardization;第5章先进制造技术先进制造技术Advanced Manufacturing Technology;信息技术information Technology;产品product;设计design；加工machining;检测check;管理manage;销售sell;使用use;服务serve;回收reclaim;计算机集成制造系统Computer Integrated Manufacturing System （CIMS）;智能制造系统Intelligent Manufacturing System (IMS);精密工程precise engineering;成组技术group technology;方式（法）methodology;柔性制造系统Flexible Manufacturing System（FMS）;数控机床numerically controlled machine tool;加工中心Machining Center（MC）;计算机数字控制computerized numerical control (CNC); 自动换刀装置automatic tool changer（A TC）;直接数字控制Direct numerical control（DNC）;分布式数字控制Distributed numerical control（DNC）; 群控DNC;单机自动化stand-alone automatization ;自动机床Automatic machine;组合机床combination machine;专用机床special machine;NC钻床NC drilling machine ;NC磨床NC grinding machine ;NC车床NC lathe ;卧式加工制造中心horizontal machine center;立式加工制造中心vertical machine center;车间shop floor;库存inventory;工艺process;分类classification;编码系统coding system;零件外型part configuration;工艺规划process planning;单元式制造cellular manufacturing;小车维修站Cart maintenance station;零件清洗站Parts wash station;装卸站Unload station;回收系统Recovery system;小车转弯站Cart turnaround station；集成化integration ;协调tradeoff;成族零件family-of-part;换刀装置Tool changer;机床控制装置machine control unit;组装线Assembly line;第6章先进制造运行模式先进制造运行模式Advanced Manufacturing Operation Model;计算机集成制造系统Computer Integrated Manufacturing Systems （CIMS）;精益生产(LP亦称精良生产)Lean Production;敏捷制造Agile Manufacturing（AM）;绿色制造Green Manufacturing;计算机辅助设计Computer Aided Design(CAD);计算机辅助制造Computer Aided Manufacturing(CAM);计算机辅助工艺过程设计Computer Aided process planning(CAPP); 物料需求计划Material Requirements Planning（MRP）;计算机辅助教育Computer Aided Education (CAE);虚拟制造Virtual Manufacturing(VM);并行工程Concurrent Engineering (CE);面向装配的设计Design For Assembly(DFA);面向制造的设计Design For Manufacturing(DFM);第7章特种加工特种加工（NTM）Nontraditional Manufacturing;一、电火花加工电火花加工spark-erosion machining;电火花线切割加工electrical discharge wire – cutting;电火花穿孔spark-erosion drilling;电火花雕刻spark-erosion carving;二、电解加工电解加工Electrolytic machining;三、超声波加工超声波加工Ultrasonic machining;变幅杆Transducer nose ;铜垫圈Copper washer;放大刀具夹持器Amplifying tool holder ; 超声波振动Ultrasonic vibration;银钎焊Sliver braze;仿形刀具Shaped tool;蜡焊缝Wax weld ;支持材料Backup material;磨料悬浮液Abrasive slurry;吸入管Suction line ;四、激光加工激光加工Laser processing;激光束加工Laser beam machining ;激光切割laser cutting ;激光打孔laser drilling;激光焊接laser welding;。

MILLING 铳削Milling is a basic machining process in which the surface is generated by the progressive formation and removal of chips of material from the workpiece as it is fed to a rotating cutter in a direction perpendicular to the axis of the cutter・ In some cases the workpiece is stationary and the cutter is fed to the work・ In most instances a multiple-tooth cutter is used so that the metal removal rate is high, and frequently the desired surface is obtained in a single pass of the work・ The tool used in milling is known as a milling cutter・ It usually consists of a cylindrical body which rotates on its axis and contains equally spaced peripheral teeth that intermittently engage and cut the workpiece ・ 1 In some cases the teeth extend part way across one or both Ends of the cylinder・Because the milling principle provides rapid metal removal and can produce good surface finish, it is particularly well-suited for mass-production work, and excellent milling machines have been developed for this purpose・ However, very accurate and versatile milling Machines of a general-purpose nature also have been developed that are widely used in jobshop and tool and die work・ A shop that is equipped with a milling machine and an engine lathe can machine almost any type of product of suitable size・Types of Milling Operations・ Milling operations can be classified into two broad categories, each of which has several variations:1・ In peripheral milling a surface is generated by teeth located in the periphery of the cutter body; the surface is parallel with the axis of rotation of the cutter・ Both flat and formed surfaces can be produced by this method・ The cross section of the resulting surface corresponds to the axial contour of the cutter・ This procedure often is called slab milling・2・ In face milling the generated flat surface is at right angles to the cutter axis and is the combined result of the actions of the portions of the teeth locatedon both the periphery and the face of the cutter ・ 2 The major portion of the cutting different methods depicted in Fig ・ 16-2・ Note that in up milling the cutter rotates againsi the direction of feed the workpiece, whereas in down milling the rotation is in the same direction as the feed ・ As shown in Fig ・ 16一2, the method of chip formation is quite different in the two cases ・ In up milling the c hip is very thin at thebeginning, where the tooth first contacts the work, and increases in thickness, becoming a maximum where the tooth leaves the work ・ The cutter tends to push the work along and lift it upward from Tool-work relationshios in peripheral and face milling the table ・ This action tends to eliminate any effect of looseness in the feed screw and nut of the milling machine table and results in a smooth cut ・ However, the action also tends to loosen the work from the clamping device so that greater clamping forcers must beemployed ・ In addition, the smoothness of the generated surface depends greatly on the sharpness of the cutting edges ・In down milling, maximum chip thickness cecum close to the point at which the tooth contacts the work ・ Because the relative motion tends to pull the workpiece into the cutter, all possibility of looseness in the table feed screw must be eliminated if down milling is to be used ・ It should never be attempted on machines that are not designed for this type of milling ・ Inssmush as the material yields in approximately a tangential direction at the end of the tooth engagement, there is much less tendency for themachined surface to show tooth marks than when up milling is used ・ Another considerable advantage of down milling is that the cutting force tends to hold the work against the machine table, permitting lower clamping force to be employed ・ 3 This is particularly advantageous when milling thin workpiece or when taking heavy cuts ・Sometimes a disadvantage of down milling is that the cutter teeth strike against the surface of the work at the beginning of each chip ・ When the workpiece has a hard surface, such as castings do, this may cause the teeth to dull rapidly ・Milling Cutters ・ Milling cutters can be classified several ways ・ One method is to group them into two broad classes, based on tooth relief, as follows: 1・ Profile-cutters have relief provided on each tooth by grinding a small land back of the cutting edge ・ The cutting edge may be straight or curved ・ 2・ In form or cam-reheved cutters the cross section of each tooth is an eccentric the cutter ・ Arbor cutters are those that have a center hole so they can be mounted on an arbor ・ Shank cutters have either tapered or straight integral shank ・ Those with tapered shanks can be mounted directly in the milling machine spindle, whereas straight-shank cutters are held in a chuck ・ Facing cutters usually are bolted to the end of a stub arbor ・is done by the peripheral portions of the a finishing action ・The basic concepts of peripheral and face Peripheral milling operations usually are spindles, whereas face milling is done onmachines ・ Surface Generation in Mimng ・ Surfaces can teeth with the face portions providing milling are illustrated in Fig ・ 16一1・ performed on machines having horizontal both horizontal- and vertical-spindle be generated in milling by two distinctly curve behind the cutting edge, thus providing relief ・ All sectionsrelief, parallel with the cutting edge, must have the same contour edge ・ Cutters of this type are sharpened by grinding only the face withthe contour of the cutting edge thus remaining unchanged ・ Anotheruseful method of classification is according to the methodof the as the of the eccentric cutting teeth, of mountingThe common types of milling cutters, classified by this system are as follows: Types ofMilling Cutters・ Hain milling cutters are cylindrical or disk-shaped, having straight orhelical teeth on the periphery. They are used for milling flat surfaces・ This type ofoperation is called plain or slab milling・ Each tooth in a helical cutter engages thework gradually, and usually more than one tooth cuts at a given time・ This reduces shockand chattering tendencies and promotes a smoother surface・ Consequently, this type ofcutter usually is preferred over one with straight teeth・Side milling cutters are similar to plain milling cutters except that the teeth extend radially part way across one or both ends of the cylinder toward the :center・ The teeth may be either straight or helica1・ Frequently these cutters are relatively narrow, being disklike in shape・ Two or more side milling cutters often are spaced on an arbor to make simultaneous, parallel cuts, in an operation called straddle milling・Interlocking slotting cutters consist of two cutters similar to side mills,but made to operate as a unit for milling slots・ The two cutters are adjusted to thedesired width by inserting shims between them・Staggered-tooth milling cutters are narrow cylindrical cutters having staggered teeth,and with alternate teeth having opposite helix angles・ They are ground to cut only onthe periphery, but each tooth also has chip clearance ground on the protruding side・These cutters have a free cutting action that makes them particnlarly effective inmilling deep slots・Metal-slitting saws are thin, plain milling cutters, usually from 1/32 to 3/16 inchthick, which have their sides slightly dished to provide clearance and prevent binding・They usually have more teeth per inch of diameter than ordinary plain milling cutters andare used for milling deep, narrow slots and for cutting-off operations・数控铳削铳削是机械加工的•个基础方法。
