奥地利微电子推出系列高速模拟信号开关
佚名
【期刊名称】《电子与电脑》
【年(卷),期】2005(000)010
【摘要】@@ 工业、医疗、通信及汽车应用集成电路设计者和制造商奥地利微电子公司(austriamicrosystems)推出首批高性能模拟开关.这些高速、低电压、双/单刀单掷(SPST)模拟开关的性能超过了目前市场上的同类产品.其切换时间提速了40%以上,同时保持了卓越的导通电阻(Ron)平直度和通道匹配.频宽为1 30MHz的改进器件是视频和高速数据信号的理想解决方案.其电源电压范围在1.6 V～3.6 V 之间,支持的设计范围相当广泛.
【总页数】1页(P45)
【正文语种】中文
【中图分类】TN929.53
【相关文献】
1.奥地利微电子推出先进的光学传感器系列 [J],
2.奥地利微电子推出两款应用于移动设备单节锂电池开关式充电器芯片 [J],
3.奥地利微电子推出业界超高效、双DC-DC转换器系列 [J],
4.奥地利微电子推出音频信号低电压双通道0．5Ω SPDT模拟开关 [J],
5.奥地利微电子高速模拟信号开关系列再添新成员 [J],
