组合机床滑台液压系统设计The design of hydraulic system of modular machine tool slide组合机床滑台液压系统设计摘要作为一种高效率的专用机床,组合机床在大批量机械加工生产中应用广泛。
本次课程设计将以组合机床动力滑台液压系统设计为例,介绍该组合机床液压系统的设计方法和设计步骤,其中包括组合机床动力滑台液压系统的工况分析、主要参数确定、液压系统原理图的拟定、液压元件的选择以及系统性能验算等。
组合机床是以通用部件为基础,配以按工件特定外形和加工工艺设计的专用部件和夹具而组成的半自动或自动专用机床。
组合机床一般采用多轴、多刀、多工序、多面或多工位同时加工的方式,生产效率比通用机床高几倍至几十倍。
组合机床兼有低成本和高效率的优点,在大批量生产中得到广泛应用,并可用以组成自动生产线。
组合机床通常采用多轴、多刀、多面、多工位同时加工的方式,能完成钻、扩、铰、镗孔、攻丝、车、铣、磨削及其他精加工工序。
液压系统由于具有结构简单、动作灵活、操作方便、调速范围大、可无级连续调节等优点,在组合机床中得到了广泛应用。
液压系统在组合机床上主要是用于实现工作台的直线运动和回转运动,本次设计组合机床动力滑台为一台卧式钻、镗组合机床上的动力滑台液压系统要求完成动作为“快进—工进—快退—原位停止”的工作循环:最大切削力为FL=12KN,动力头自重FG=20KN,工作进给要求能在0.02—1.2m/min的范围内无级调速,快进、快退速度为6m/min;工进行程为100mm,快进行程为300mm;采用平导轨,其静、动摩擦系数取fs=0.2、fd=0.1;往复运动的加速、减速时间要求不大于0.5S。
关键词:液压系统修正节流阀分流集流阀液压锁The design of hydraulic system of modular machine tool slideAbstract as a special machine for high efficiency, the combination of machine tools are widely used in large batch machining production. The curriculum designto combination machine tool hydraulic pressure system design as an example,introduces the design method of the hydraulic system of modular machine tooland the design procedure, including combination machinetool hydraulic system of power slipway condition analysis, the main parameters, hydraulic system principle diagram of the quasi fixed, the choice of hydraulic components and systemperformance checking.Combination machine is based on common components, with special componentsdesigned according to workpiece specific shape and process and fixture andconsisting of semi-automaticor automatic machine tool. Combination machinegenerally adopts the multi axis, multi knife, multi process, multi or multistage and processing, production efficiency several times to several times higher than the general machine tool. The combination machine has the advantages of high efficiency and low cost, widely used in mass production, and can be used tocompose the automatic production line. Combination machine tools usually adopts the multi axis, multiknife, multi-faceted, multi station and processing, can complete thedrilling, boring, tapping, reaming, expansion, cars, milling, grindingand other finishing processes.The hydraulic system has the advantages of simple structure, flexible action,convenient operation, wide speed range, the advantages of continuous stepless regulation, has been widely applied in the modular machine tool. Hydraulicsystem in modular machine is mainly used to achieve the worktable linearmovement and rotary movement, the design of combined machine tool power sliding table is a horizontal drilling, hydraulic system of power slipway boring modular machine to complete the requirements of action as "fast forward -feeding - rewind in-situ stop" work cycle: the maximum cutting force for FL=12KN,a power head weight FG=20KN, feed requirements canbe stepless in the range of 0.02 - 1.2m/min in speed, fast forward, rewind speed is6m/min; feedingschedule for 100mm, fast forward stroke is 300mm; using flat guide rail, thestatic,dynamic friction coefficient fs=0.2, fd=0.1; acceleration, the reciprocating motion of the time requirements not more than 0.5S.Key words: Hydraulic system Amendment throttle valve Flow distributing and collecting valve Hydraulic lock目录第一章绪论 (1)1.1 液压传动的发展状况 (1)1.2 液压技术的应用 (2)第二章组合机床滑台设计依据 (2)第三章工况分析 (2)3.1 负载分析 (2)3.2 负载图和速度图 (3)第四章初步拟定液压系统原理图 (4)4.1 选择液压基本回路 (4)4.2 组成液压系统原理图 (5)第五章确定液压系统参数 (6)5.1 初选液压缸工作压力 (6)5.2 计算液压缸的结构尺寸 (7)5.3 绘制工况图 (8)第六章液压元件的计算和选择 (8)6.1 确定液压泵的规格和电机功率 (8)6.2 选择液压阀 (9)6.3 确定管道尺寸 (10)6.4 确定油箱容量 (11)第七章液压系统的性能验算 (11)7.1 液压缸的速度验算 (11)7.2 回路压力损失验算 (11)7.3 液压系统发热与温升验算 (12)第八章液压技术未来的发展 (13)总结 (14)致谢 (14)参考文献 ....................................................................................................错误!未定义书签。
项目七组合机床动力滑台液压系统的安装与调试学习任务一:液压基本回路认识2【学习目标】1.掌握速度调节和平衡等基本回路的组成和工作原理。
§7.1.1速度调节回路【知识链接】速度调节回路就是调定执行元件的工作速度。
在液压系统中,执行元件为液压缸和液压马达。
若不考虑油液的可压缩性和泄露的情况,执行元件的速度为:液压缸: v = q v/A液压马达:n = q v/V由上两式可知,改变输入执行元件的流量q v、液压缸的有效工作面积A或液压马达的排量V均可以达到调节速度的目的。
对于液压缸而言,其结构参数是确定的,液压缸的有效工作面积A无法调节,只能通过改变输入执行元件的流量q v调节速度,使用时既可以选择定量泵供油、节流阀调节流量的方法,也可以采用变量泵、通过调节泵的排量来调速;对于液压马达,可选用变量马达调节排量,也可通过改变液压马达的流量来调速。
概况起来,液压系统执行元件的速度调节有三类方法:1.定量泵节流调速——改变流量q;2.变量泵容积调速——改变排量V;3.容积节流调速--既可改变q,又可改变V用定量泵供油,由流量控制阀改变执行元件的流量来调节速度。
节流调速回路主要优点是结构简单、速度稳定性好,能够获得较低的运动速度;主要缺点是存在节流损失和溢流损失,功率损失较大、发热多、效率低。
故一般多用于小功率系统中,如机床的进给系统。
按流量控制阀在液压系统中的安装位置不同,节流调速回路可分为进油节流调速回路、回油节流调速回路和旁路节流调速回路三种。
一、进油节流调速回路进油节流调速回路是将流量控制阀设置在执行元件的进油路上,如图3所示,由于节流阀串联在电磁换向阀之前,所以活塞的往复运动均属于进油节流调速回路。
调节节流阀阀口的大小,便能控制进入液压缸的流量,多余的油液经溢流阀流回油箱。
根据进油路节流调速回路的特点,节流阀进油节流调速回路适用于低速、轻载、负载变化不大合对速度稳定性要求不高的场合。
图7-1-1 进油节流调速回路图7-1-2 回油节流调速回路二、回油节流调速回路回油节流调速回路是将流量控制阀设置在执行元件的回油路上,如图7-1-2。
