文献翻译-机械加工中心

题目机械加工介绍学院专业班级姓名学号指导教师Machining Processing Introduction1 LatheLathes are machine tools designed primarily to do turning, facing and bori ng, Very little turning is done on other types of machine tools, and none can do it with equal facility. Because lathes also can do drilling and reaming, their versatility permits several operations to be done with a single setup of the work piece. Consequently, more lathes of various types are used in manufacturing than any other machine tool.The essential components of a lathe are the bed, headstock assembly, tailstock assembly, and the leads crew and feed rod.The bed is the backbone of a lathe. It usually is made of well normalized or aged gray or nodular cast iron and provides s heavy, rigid frame on which all the other basic components are mounted. Two sets of parallel, longitudinal ways, inner and outer, are contained on the bed, usually on the upper side. Som makers use an inverted V-shape for all four ways, whereas others utilize one inverted V and one flat way in one or both sets, they are precision-machined to assure accuracy of alignment. On most modern lathes the way are surface-hardened to resist wear and abrasion, but precaution should be taken in operating a lathe to assure that the ways are not damaged. Any inaccuracy in them usually means that the accuracy of the entire lathe is destroyed.The headstock is mounted in a foxed position on the inner ways, usually at the left end of the bed. It provides a powered means of rotating the word at various speeds. Essentially, it consists of a hollow spindle, mounted in accurate bearings, and a set of transmission gears-similar to a truck transmission—through which the spindle can be rotated at a number of speeds. Most lathes provide from 8 to 18 speeds, usually in a geometric ratio, and on modern lathes all the speeds can be obtained merely by moving from two to four levers. An increasing trend is to provide a continuously variable speed range through electrical or mechanical drives.Because the accuracy of a lathe is greatly dependent on the spindle, it is of heavy construction and mounted in heavy bearings, usually preloaded tapered roller or ball types. The spindle has a hole extending through its length through which long bar stock can be fed. The size of maximum size of bar stock that can be machined when the material must be fed through spindle.The tailsticd assembly consists, essentially, of three parts. A lower casting fits on the inner ways of the bed and can slide longitudinally thereon, with means for clamping the entire assembly in any desired location; an upper casting fits on the lower one and can be moved transversely upon it, on some type of keyed ways, to permit aligning the assembly is the tailstock quill. This is hollow steel cylinder, usually about 51 to 76mm (2to 3 inches) in diameter, that can be moved several inches longitudinally in and out of the upper casting by means of a hand wheel and screw.The size of a lathe is designated by two dimensions. The first is known as theswing. This is the maximum diameter of work that can be rotated on a lathe. It is approximately twice the distance between the line connecting the lathe centers and the nearest point on the ways, the second size dimension is the maximum distance between centers. The swing thus indicates the maximum work piece diameter that can be turned in the lathe, while the distance between centers indicates the maximum length of work piece that can be mounted between centers.Engine lathes are the type most frequently used in manufacturing. They are heavy-duty machine tools with all the components described previously and have power drive for all tool movements except on the compound rest. They commonly range in size from 305 to 610 mm(12 to 24 inches)swing and from 610 to 1219 mm(24 to 48 inches) center distances, but swings up to 1270 mm(50 inches) and center distances up to 3658mm(12 feet) are not uncommon. Most have chip pans and a built-in coolant circulating system. Smaller engine lathes-with swings usually not over 330 mm (13 inches) –also are available in bench type, designed for the bed to be mounted on a bench on a bench or cabinet.Although engine lathes are versatile and very useful, because of the time required for changing and setting tools and for making measurements on the work piece, thy are not suitable for quantity production. Often the actual chip-production tine is less than 30% of the total cycle time. In addition, a skilled machinist is required for all the operations, and such persons are costly and often in short supply. However, much of the operator’s time is consumed by simple, repetitious adjustments and in watching chips being made. Consequently, to reduce or eliminate the amountof skilled labor that is required; turret lathes, screw machines, and other types of semiautomatic and automatic lathes have been highly developed and are widely used in manufacturing.2 Numerical ControlOne of the most fundamental concepts in the area of advanced manufacturing technologies is numerical control (NC). Prior to the advent of NC, all machine tools ere manually operated and controlled. Among the many limitations associated with manual control machine tools, perhaps none is more prominent than the limitation of operator skills. With manual control, the quality of the product is directly related to and limited to the skills of the operator. Numerical control represents the first major step away from human control of machine tools.Numerical control means the control of machine tools and other manufacturing systems through the use of prerecorded, written symbolic instructions. Rather than operating a machine tool, an NC technician writes a program that issues operational instructions to the machine tool. For a machine tool to be numerically controlled, it must be interfaced with a device for accepting and decoding the programmed instructions, known as a reader.Numerical control was developed to overcome the limitation of human operators, and it has done so. Numerical control machines are more accurate than manually operated machines, they can produce parts more uniformly, they are faster, and the long-run tooling costs are lower. The development of NC led to the development of several other innovations in manufacturing technology:Electrical discharge machining, Laser cutting, Electron beam welding.Numerical control has also made machine tools more versatile than their manually operated predecessors. An NC machine tool can automatically produce a wide of parts, each involving an assortment of widely varied and complex machining processes. Numerical control has allowed manufacturers to undertake the production of products that would not have been feasible from an economic perspective using manually controlled machine tolls and processes.Like so many advanced technologies, NC was born in the laboratories of the Massachusetts Institute of Technology. The concept of NC was developed in the early 1950s with funding provided by the U.S. Air Force. In its earliest stages, NC machines were able to made straight cuts efficiently and effectively.However, curved paths were a problem because the machine tool had to be programmed to undertake a series of horizontal and vertical steps to produce a curve. The shorter the straight lines making up the steps, the smoother is the curve, each line segment in the steps had to be calculated.This problem led to the development in 1959 of the Automatically Programmed Tools (APT) language. This is a special programming language for NC that uses statements similar to English language to define the part geometry, describe the cutting tool configuration, and specify the necessary motions. The development of the APT language was a major step forward in the fur ther development from those used today. The machines had hardwired logic circuits. The instructional programs were written on punched paper, which was later to be replaced by magnetic plastic tape. Atape reader was used to interpret the instructions written on the tape for the machine. Together, all of this represented a giant step forward in the control of machine tools. However, there were a number of problems with NC at this point in its development.A major problem was the fragility of the punched paper tape medium. It was common for the paper tape containing the programmed instructions to break or tear during a machining process. This problem was exacerbated by the fact that each successive time a part was produced on a machine tool; the paper tape carrying the programmed instructions had to be rerun through the reader. If it was necessary to produce 100 copies of a given part, it was also necessary to run the paper tape through the reader 100 separate tines. Fragile paper tapes simply could not withstand the rigors of a shop floor environment and this kind of repeated use.This led to the development of a special magnetic plastic tape. Whereas the paper carried the programmed instructions as a series of holes punched in the tape, the plastic tape carried the instructions as a series of magnetic dots. The plastic tape was much stronger than the paper tape, which solved the problem of frequent tearing and breakage. However, it still left two other problems.The most important of these was that it was difficult or impossible to change the instructions entered on the tape. To make even the most minor adjustments in a program of instructions, it was necessary to interrupt machining operations and make a new tape. It was also still necessary to run the tape through the reader as many times as there were parts to be produced. Fortunately, computer technology became areality and soon solved the problems of NC associated with punched paper and plastic tape.The development of a concept known as direct numerical control (DNC) solved the paper and plastic tape problems associated with numerical control by simply eliminating tape as the medium for carrying the programmed instructions. In direct numerical control, machine tools are tied, via a data transmission link, to a host computer. Programs for operating the machine tools are stored in the host computer and fed to the machine tool an needed via the data transmission linkage. Direct numerical control represented a major step forward over punched tape and plastic tape. However, it is subject to the same limitations as all technologies that depend on a host computer. When the host computer goes down, the machine tools also experience downtime. This problem led to the development of computer numerical control.3 TurningThe engine lathe, one of the oldest metal removal machines, has a number of useful and highly desirable attributes. Today these lathes are used primarily in small shops where smaller quantities rather than large production runs are encountered.The engine lathe has been replaced in today’s production shops by a wide variety of automatic lathes such as automatic of single-point tooling for maximum metal removal, and the use of form tools for finish on a par with the fastest processing equipment on the scene today.Tolerances for the engine lathe depend primarily on the skill of the operator. The design engineer must be careful in using tolerances of an experimental part that has been produced on the engine lathe by a skilled operator. In redesigning an experimental part for production, economical tolerances should be used.Turret Lathes Production machining equipment must be evaluated now, more than ever before, this criterion for establishing the production qualification of a specific method, the turret lathe merits a high rating.In designing for low quantities such as 100 or 200 parts, it is most economical to use the turret lathe. In achieving the optimum tolerances possible on the turrets lathe, the designer should strive for a minimum of operations.Automatic Screw Machines Generally, automatic screw machines fall into several categories; single-spindle automatics, multiple-spindle automatics and automatic chucking machines. Originally designed for rapid, automatic production of screws and similar threaded parts, the automatic screw machine has long since exceeded the confines of this narrow field, and today plays a vital role in the mass production of a variety of precision parts. Quantities play an important part in the economy of the parts machined on the automatic screw machine. Quantities less than on the automatic screw machine. The cost of the parts machined can be reduced if the minimum economical lot size is calculated and the proper machine is selected for these quantities.Automatic Tracer Lathes Since surface roughness depends greatly on material turned, tooling , and feeds and speeds employed, minimum tolerances that can be held on automatic tracer lathes are not necessarily the most economical tolerances.In some cases, tolerances of 0.05mm are held in continuous production using but one cut . groove width can be held to 0.125mm on some parts. Bores and single-point finishes can be held to 0.0125mm. On high-production runs where maximum output is desirable, a minimum tolerance of 0.125mm is economical on both diameter and length of turn.机械加工介绍1.车床车床主要是为了进行车外圆、车端面和镗孔等项工作而设计的机床。

加工中心数控技术出处：数控加工中心的分类以及各自特点出版社:化学工业出版社; 第1版 (2009年3月16日)作者：徐衡、段晓旭加工中心是典型的集高技术于一体的机械加工设备，它的发展代表了一个国家设计制造的水平也大大提高了劳动生产率，降低了劳动成本，改善了工人的工作环境，降低了工人的劳动强度。

本文经过对不同运动方案和各部件的设计方案的定性分析比较确定该教立式加工中心的进给传动方案为：采用固定床身，电主轴通过安装座安装在床身导轨的滑座上，床身导轨采用滚动导轨，可以实现Y方向的进给运动。

由X-Y双向精密数控工作台带动工件完成X，Y两个方向的进给运动;X，Y，Z三个方向的进给运动均滚珠丝杠，并由交流伺服电机驱动。

导轨、滚珠丝杠有相应的润滑、防护等装置。

加工中心（英文缩写为CNC 全称为Computerized Numerical Control）：是带有刀库和自动换刀装置的一种高度自动化的多功能数控机床。

在中国香港，台湾及广东一代也有很多人叫它电脑锣。

工件在加工中心上经一次装夹后，数字控制系统能控制机床按不同工序，自动选择和更换刀具，自动改变机床主轴转速、进给量和刀具相对工件的运动轨迹及其他辅助机能，依次完成工件几个面上多工序的加工。

并且有多种换刀或选刀功能，从而使生产效率大大提高。

加工中心数控机床是一种装有计算机数字控制系统的机床，数控系统能够处理加工程序，控制机床完成各种动作。

与普通机床相比，数控机床能够完成平面曲线和空间曲面的加工，加工精度和生产效率都比较高，因而应用日益广泛。

数控机床的组成一般来说，数控机床由机械部分、数字控制计算机、伺服系统、PC控制部分、液压气压传动系统、冷却润滑和排泄装置组成。

数控机床是由程序控制的，零件的编程工作是数控机床加工的重要组成部分。

伺服系统是数控机床的驱动部分，计算机输出的控制命令是通过伺服系统产生坐标移动的。

普通的立式加工中心有三个伺服电机，分别驱动纵向工作台、横向工作台、主轴箱沿X向、Y向、Z向运动。

外文原文：Machining TurningThe engine lathe, one of the oldest metal removal machines, has a number of useful and highly desirable attributes. Today these lathes are used primarily in small shops where smaller quantities rather than large production runs are encountered.The engine lathe has been replaced in today’s production shops by a wide variety of automatic lathes such as automatic tracer lathes, turret lathes, and automatic screw machines. All the advantages of single-point tooling for maximum metal removal, and the use of form tools for finished on a par with the fastest processing equipment on the scene today.Tolerances for the engine lathe depend primarily on the skill of the operator. The design engineer must be careful in using tolerances of an experimental part that has been produced on the engine lathe by a skilled operator. In redesigning an experimental part for production, economical tolerances should be used.Turret LathesProduction machining equipment must be evaluated now, more than ever before, in terms of ability to repeat accurately and rapidly. Applying this criterion for establishing the production qualification of a specific method, the turret lathe merits a high rating.In designing for low quantities such as 100 or 200 parts, it is most economical to use the turret lathe. In achieving the optimum tolerances possible on the turret lathe, the designer should strive for a minimum of operations.Automatic Screw MachinesGenerally, automatic screw machines fall into several categories; single-spindle automatics, multiple-spindle rapid, automatic chucking machines. Originally designed for rapid, automatic production of screws and similar threaded parts, the narrow field, and today plays a vital role in the mass production of a variety of precision parts. Quantities play an important part in the economy of the parts machined on the automatic screw machine. The cost of the parts machined can be reduced if the minimum economical lot size is calculated and the proper machine is selected for these quantities.Automatic Tracer LathesSince surface roughness depends greatly upon material turned, tooling, and feeds and speeds employed, minimum tolerances that can be held on automatic tracer lathes are not necessarily the most economical tolerances.In some cases, tolerances of ±0.05mm are held in continuous production using but one cut. Groove width can be held to ±0.0125mm on some parts. Bores and single-point finishes can be held to ±0.0125mm. On high-production runs where maximum output is desirable, a minimum tolerance of ±0.125mm is economical on both diameter and length of turn.MillingWith the exceptions of turning and drilling, milling is undoubtedly the most widely used method of removing metal. Well suited and readily adapted to the economical production of any quantity of parts, the almost unlimited versatility of milling process merits the attention and consideration of designers seriously with the manufacture of their product.As in any other process, parts that have to be milled should be designed with economical tolerances that can be achieved in production mill. If the part is designed with tolerances finer than necessary, additional operations will have to be added to achieve these tolerances-and this will increase the cost of the part.GrindingGrinding is one of the most widely used methods of finishing parts to extremely close tolerances and fine surface finishes. Currently, there are grinders for almost every type of grinding machine required. Where processing costs are excessive, parts redesigned to worthwhile. For example, wherever possible the production economy of centerless grinding should be taken advantage of by proper design consideration.Although grinding is usually considered a finishing operation, it is often employed as a complete machining process on work which can be ground down from rough condition without being turned or otherwise machined. Thus many types of forgings and other parts are finished completely with the grinding wheel at appreciable savings of time and expense.Classes of grinding machines include the following: cylindrical grinders, centerless grinders, internal grinders, surface grinders, and tool expense.The cylindrical and centerless grinders or taper work; thus splines, shafts, and similar parts are ground on cylindrical machines either of the common-center type orthe centerless machine.Thread grinders are used for grinding precision threads for thread gages, and threads on precision parts where the concentricity between the diameter of the shaft and pitch diameter of thread must be held to close tolerances.The internal grinders are used for grinding of precision holes, cylinder bores, and similar operations where bores of all kinds are to be finished.The surface grinders are for finishing all kinds of flat work, or work with plain surfaces which may be operated upon either by the edge of a wheel or by the face of a grinding wheel. These machines may have reciprocating or rotating tables.译文：机械加工金属切削机床中最早的一种是普通车床，当今仍有许多有用的特性。

中英文对照外文翻译文献(文档含英文原文和中文翻译)原文：Selection of optimum tool geometry and cutting conditionsusing a surface roughness prediction model for end milling Abstract Influence of tool geometry on the quality of surface produced is well known and hence any attempt to assess the performance of end milling should include the tool geometry. In the present work, experimental studies have been conducted to see the effect of tool geometry (radial rake angle and nose radius) and cutting conditions (cutting speed and feed rate) on the machining performance during end milling of medium carbon steel. The first and second order mathematical models, in terms of machining parameters, were developed for surface roughness prediction using response surface methodology (RSM) on the basis of experimental results. The model selected for optimization has been validated with the Chi square test. The significance of these parameters on surface roughness has been established with analysis of variance. An attempthas also been made to optimize the surface roughness prediction model using genetic algorithms (GA). The GA program gives minimum values of surface roughness and their respective optimal conditions.1 IntroductionEnd milling is one of the most commonly used metal removal operations in industry because of its ability to remove material faster giving reasonably good surface quality. It is used in a variety of manufacturing industries including aerospace and automotive sectors, where quality is an important factor in the production of slots, pockets, precision moulds and dies. Greater attention is given to dimensional accuracy and surface roughness of products by the industry these days. Moreover, surface finish influences mechanical properties such as fatigue behaviour, wear, corrosion, lubrication and electrical conductivity. Thus, measuring and characterizing surface finish can be considered for predicting machining performance.Surface finish resulting from turning operations has traditionally received considerable research attention, where as that of machining processes using multipoint cutters, requires attention by researchers. As these processes involve large number of parameters, it would be difficult to correlate surface finish with other parameters just by conducting experiments. Modelling helps to understand this kind of process better. Though some amount of work has been carried out to develop surface finish prediction models in the past, the effect of tool geometry has received little attention. However, the radial rake angle has a major affect on the power consumption apart from tangential and radial forces. It also influences chip curling and modifies chip flow direction. In addition to this, researchers [1] have also observed that the nose radius plays a significant role in affecting the surface finish. Therefore the development of a good model should involve the radial rake angle and nose radius along with other relevant factors.Establishment of efficient machining parameters has been a problem that has confronted manufacturing industries for nearly a century, and is still the subject of many studies. Obtaining optimum machining parameters is of great concern in manufacturing industries, where the economy of machining operation plays a key role in the competitive market. In material removal processes, an improper selection of cutting conditions cause surfaces with high roughness and dimensional errors, and it is even possible that dynamic phenomena due to auto excited vibrations may set in [2]. In view of the significant role that the milling operation plays in today‟s manufacturing world, there is a need to optimize the machining parameters for this operation. So, an effort has been made in this paper to see the influence of tool geometry(radial rake angle and nose radius) and cutting conditions(cutting speed and feed rate) on the surfacefinish produced during end milling of medium carbon steel. The experimental results of this work will be used to relate cutting speed, feed rate, radial rake angle and nose radius with the machining response i.e. surface roughness by modelling. The mathematical models thus developed are further utilized to find the optimum process parameters using genetic algorithms.2 ReviewProcess modelling and optimization are two important issues in manufacturing. The manufacturing processes are characterized by a multiplicity of dynamically interacting process variables. Surface finish has been an important factor of machining in predicting performance of any machining operation. In order to develop and optimize a surface roughness model, it is essential to understand the current status of work in this area.Davis et al. [3] have investigated the cutting performance of five end mills having various helix angles. Cutting tests were performed on aluminium alloy L 65 for three milling processes (face, slot and side), in which cutting force, surface roughness and concavity of a machined plane surface were measured. The central composite design was used to decide on the number of experiments to be conducted. The cutting performance of the end mills was assessed using variance analysis. The affects of spindle speed, depth of cut and feed rate on the cutting force and surface roughness were studied. The investigation showed that end mills with left hand helix angles are generally less cost effective than those with right hand helix angles. There is no significant difference between up milling and down milling with regard tothe cutting force, although the difference between them regarding the surface roughness was large. Bayoumi et al.[4] have studied the affect of the tool rotation angle, feed rate and cutting speed on the mechanistic process parameters (pressure, friction parameter) for end milling operation with three commercially available workpiece materials, 11 L 17 free machining steel, 62- 35-3 free machining brass and 2024 aluminium using a single fluted HSS milling cutter. It has been found that pressure and friction act on the chip – tool interface decrease with the increase of feed rate and with the decrease of the flow angle, while the cutting speed has a negligible effect on some of the material dependent parameters. Process parameters are summarized into empirical equations as functions of feed rate and tool rotation angle for each work material. However, researchers have not taken into account the effects of cutting conditions and tool geometry simultaneously; besides these studies have not considered the optimization of the cutting process.As end milling is a process which involves a large number f parameters, combined influence of the significant parameters an only be obtained by modelling. Mansour and Abdallaet al. [5] have developed a surface roughness model for the end milling of EN32M (a semi-free cutting carbon case hardening steel with improved merchantability). The mathematical modelhas been developed in terms of cutting speed, feed rate and axial depth of cut. The affect of these parameters on the surface roughness has been carried out using response surface methodology (RSM). A first order equation covering the speed range of 30–35 m/min and a second order equation covering the speed range of 24–38 m/min were developed under dry machining conditions. Alauddin et al. [6] developed a surface roughness model using RSM for the end milling of 190 BHN steel. First and second order models were constructed along with contour graphs for the selection of the proper combination of cutting speed and feed to increase the metal removal rate without sacrificing surface quality. Hasmi et al. [7] also used the RSM model for assessing the influence of the workpiece material on the surface roughness of the machined surfaces. The model was developed for milling operation by conducting experiments on steel specimens. The expression shows, the relationship between the surface roughness and the various parameters; namely, the cutting speed, feed and depth of cut. The above models have not considered the affect of tool geometry on surface roughness.Since the turn of the century quite a large number of attempts have been made to find optimum values of machining parameters. Uses of many methods have been reported in the literature to solve optimization problems for machining parameters. Jain and Jain [8] have used neural networks for modeling and optimizing the machining conditions. The results have been validated by comparing the optimized machining conditions obtained using genetic algorithms. Suresh et al. [9] have developed a surface roughness prediction model for turning mild steel using a response surface methodology to produce the factor affects of the individual process parameters. They have also optimized the turning process using the surface roughness prediction model as the objective function. Considering the above, an attempt has been made in this work to develop a surface roughness model with tool geometry and cutting conditions on the basis of experimental results and then optimize it for the selection of these parameters within the given constraints in the end milling operation.3 MethodologyIn this work, mathematical models have been developed using experimental results with the help of response surface methodolog y. The purpose of developing mathematical models relating the machining responses and their factors is to facilitate the optimization of the machining process. This mathematical model has been used as an objective function and the optimization was carried out with the help of genetic algorithms.3.1 Mathematical formulationResponse surface methodology(RSM) is a combination of mathematical and statisticaltechniques useful for modelling and analyzing the problems in which several independent variables influence a dependent variable or response. The mathematical models commonly used are represented by:where Y is the machining response, ϕ is the response function and S, f , α, r are milling variables and ∈is the error which is normally distributed about the observed response Y with zero mean.The relationship between surface roughness and other independent variables can be represented as follows，where C is a constant and a, b, c and d are exponents.To facilitate the determination of constants and exponents, this mathematical model will have to be linearized by performing a logarithmic transformation as follows:The constants and exponents C, a, b, c and d can be determined by the method of least squares. The first order linear model, developed from the above functional relationship using least squares method, can be represented as follows:where Y1 is the estimated response based on the first-order equation, Y is the measured surface roughness on a logarithmic scale, x0 = 1 (dummy variable), x1, x2, x3 and x4 are logarithmic transformations of cutting speed, feed rate, radial rake angle and nose radius respectively, ∈is the experimental error and b values are the estimates of corresponding parameters.The general second order polynomial response is as given below:where Y2 is the estimated response based on the second order equation. The parameters, i.e. b0, b1, b2, b3, b4, b12, b23, b14, etc. are to be estimated by the method of least squares. Validity of the selected model used for optimizing the process parameters has been tested with the help of statistical tests, such as F-test, chi square test, etc. [10].3.2 Optimization using genetic algorithmsMost of the researchers have used traditional optimization techniques for solving machining problems. The traditional methods of optimization and search do not fare well over a broad spectrum of problem domains. Traditional techniques are not efficient when the practical search space is too large. These algorithms are not robust. They are inclined to obtain a local optimal solution. Numerous constraints and number of passes make the machining optimization problem more complicated. So, it was decided to employ genetic algorithms as an optimization technique. GA come under the class of non-traditional search and optimization techniques. GA are different from traditional optimization techniques in the following ways:1.GA work with a coding of the parameter set, not the parameter themselves.2.GA search from a population of points and not a single point.3.GA use information of fitness function, not derivatives or other auxiliary knowledge.4.GA use probabilistic transition rules not deterministic rules.5.It is very likely that the expected GA solution will be the global solution.Genetic algorithms (GA) form a class of adaptive heuristics based on principles derived from the dynamics of natural population genetics. The searching process simulates the natural evaluation of biological creatures and turns out to be an intelligent exploitation of a random search. The mechanics of a GA is simple, involving copying of binary strings. Simplicity of operation and computational efficiency are the two main attractions of the genetic algorithmic approach. The computations are carried out in three stages to get a result in one generation or iteration. The three stages are reproduction, crossover and mutation.In order to use GA to solve any problem, the variable is typically encoded into a string (binary coding) or chromosome structure which represents a possible solution to the given problem. GA begin with a population of strings (individuals) created at random. The fitness of each individual string is evaluated with respect to the given objective function. Then this initial population is operated on by three main operators – reproduction cross over and mutation– to create, hopefully, a better population. Highly fit individuals or solutions are given the opportunity to reproduce by exchanging pieces of their genetic information, in the crossover procedure, with other highly fit individuals. This produces new “offspring” solutions, which share some characteristics taken from both the parents. Mutation is often applied after crossover by altering some genes (i.e. bits) in the offspring. The offspring can either replace the whole population (generational approach) or replace less fit individuals (steady state approach). This new population is further evaluated and tested for some termination criteria. The reproduction-cross over mutation- evaluation cycle is repeated until the termination criteria are met.4 Experimental detailsFor developing models on the basis of experimental data, careful planning of experimentation is essential. The factors considered for experimentation and analysis were cutting speed, feed rate, radial rake angle and nose radius.4.1 Experimental designThe design of experimentation has a major affect on the number of experiments needed. Therefore it is essential to have a well designed set of experiments. The range of values of each factor was set at three different levels, namely low, medium and high as shown in Table 1. Basedon this, a total number of 81 experiments (full factorial design), each having a combination of different levels of factors, as shown in Table 2, were carried out.The variables were coded by taking into account the capacity and limiting cutting conditions of the milling machine. The coded values of variables, to be used in Eqs. 3 and 4, were obtained from the following transforming equations:where x1 is the coded value of cutting speed (S), x2 is the coded value of the feed rate ( f ), x3 is the coded value of radial rake angle(α) and x4 is the coded value of nose radius (r).4.2 ExperimentationA high precision …Rambaudi Rammatic 500‟ CNC milling machine, with a vertical milling head, was used for experimentation. The control system is a CNC FIDIA-12 compact. The cutting tools, used for the experimentation, were solid coated carbide end mill cutters of different radial rake angles and nose radii (WIDIA: DIA20 X FL38 X OAL 102 MM). The tools are coated with TiAlN coating. The hardness, density and transverse rupture strength are 1570 HV 30, 14.5 gm/cm3 and 3800 N/mm2 respectively.AISI 1045 steel specimens of 100×75 mm and 20 mm thickness were used in the present study. All the specimens were annealed, by holding them at 850 ◦C for one hour and then cooling them in a furnace. The chemical analysis of specimens is presented in Table 3. The hardness of the workpiece material is 170 BHN. All the experiments were carried out at a constant axial depth of cut of 20 mm and a radial depth of cut of 1 mm. The surface roughness (response) was measured with Talysurf-6 at a 0.8 mm cut-off value. An average of four measurements was used as a response value.5 Results and discussionThe influences of cutting speed, feed rate, radial rake angle and nose radius have been assessed by conducting experiments. The variation of machining response with respect to the variables was shown graphically in Fig. 1. It is seen from these figures that of the four dependent parameters, radial rake angle has definite influence on the roughness of the surface machined using an end mill cutter. It is felt that the prominent influence of radial rake angle on the surface generation could be due to the fact that any change in the radial rake angle changes the sharpness of the cutting edge on the periphery, i.e changes the contact length between the chip and workpiece surface. Also it is evident from the plots that as the radial rake angle changes from 4◦to 16◦, the surface roughness decreases and then increases. Therefore, it may be concluded here that the radial rake angle in the range of 4◦to 10◦would give a better surface finish. Figure 1also shows that the surface roughness decreases first and then increases with the increase in the nose radius. This shows that there is a scope for finding the optimum value of the radial rake angle and nose radius for obtaining the best possible quality of the surface. It was also found that the surface roughness decreases with an increase in cutting speed and increases as feed rate increases. It could also be observed that the surface roughness was a minimum at the 250 m/min speed, 200 mm/min feed rate, 10◦radial rake angle and 0.8 mm nose radius. In order to understand the process better, the experimental results can be used to develop mathematical models using RSM. In this work, a commercially available mathematical software package (MATLAB) was used for the computation of the regression of constants and exponents.5.1 The roughness modelUsing experimental results, empirical equations have been obtained to estimate surface roughness with the significant parameters considered for the experimentation i.e. cutting speed, feed rate, radial rake angle and nose radius. The first order model obtained from the above functional relationship using the RSM method is as follows:The transformed equation of surface roughness prediction is as follows:Equation 10 is derived from Eq. 9 by substituting the coded values of x1, x2, x3 and x4 in terms of ln s, ln f , lnαand ln r. The analysis of the variance (ANOV A) and the F-ratio test have been performed to justify the accuracy of the fit for the mathematical model. Since the calculated values of the F-ratio are less than the standard values of the F-ratio for surface roughness as shown in Table 4, the model is adequate at 99% confidence level to represent the relationship between the machining response and the considered machining parameters of the end milling process.The multiple regression coefficient of the first order model was found to be 0.5839. This shows that the first order model can explain the variation in surface roughness to the extent of 58.39%. As the first order model has low predictability, the second order model has been developed to see whether it can represent better or not.The second order surface roughness model thus developed is as given below:where Y2 is the estimated response of the surface roughness on a logarithmic scale, x1, x2, x3 and x4 are the logarithmic transformation of speed, feed, radial rake angle and nose radius. The data of analysis of variance for the second order surface roughness model is shown in Table 5.Since F cal is greater than F0.01, there is a definite relationship between the responsevariable and independent variable at 99% confidence level. The multiple regression coefficient of the second order model was found to be 0.9596. On the basis of the multiple regression coefficient (R2), it can be concluded that the second order model was adequate to represent this process. Hence the second order model was considered as an objective function for optimization using genetic algorithms. This second order model was also validated using the chi square test. The calculated chi square value of the model was 0.1493 and them tabulated value at χ2 0.005 is 52.34, as shown in Table 6, which indicates that 99.5% of the variability in surface roughness was explained by this model.Using the second order model, the surface roughness of the components produced by end milling can be estimated with reasonable accuracy. This model would be optimized using genetic algorithms (GA).5.2 The optimization of end millingOptimization of machining parameters not only increases the utility for machining economics, but also the product quality toa great extent. In this context an effort has been made to estimate the optimum tool geometry and machining conditions to produce the best possible surface quality within the constraints.The constrained optimization problem is stated as follows: Minimize Ra using the model given here:where xil and xiu are the upper and lower bounds of process variables xi and x1, x2, x3, x4 are logarithmic transformation of cutting speed, feed, radial rake angle and nose radius.The GA code was developed using MATLAB. This approach makes a binary coding system to represent the variables cutting speed (S), feed rate ( f ), radial rake angle (α) and nose radius (r), i.e. each of these variables is represented by a ten bit binary equivalent, limiting the total string length to 40. It is known as a chromosome. The variables are represented as genes (substrings) in the chromosome. The randomly generated 20 such chromosomes (population size is 20), fulfilling the constraints on the variables, are taken in each generation. The first generation is called the initial population. Once the coding of the variables has been done, then the actual decoded values for the variables are estimated using the following formula: where xi is the actual decoded value of the cutting speed, feed rate, radial rake angle and nose radius, x(L) i is the lower limit and x(U) i is the upper limit and li is the substring length, which is equal to ten in this case.Using the present generation of 20 chromosomes, fitness values are calculated by the following transformation:where f(x) is the fitness function and Ra is the objective function.Out of these 20 fitness values, four are chosen using the roulette-wheel selection scheme. The chromosomes corresponding to these four fitness values are taken as parents. Then the crossover and mutation reproduction methods are applied to generate 20 new chromosomes for the next generation. This processof generating the new population from the old population is called one generation. Many such generations are run till the maximum number of generations is met or the average of four selected fitness values in each generation becomes steady. This ensures that the optimization of all the variables (cutting speed, feed rate, radial rake angle and nose radius) is carried out simultaneously. The final statistics are displayed at the end of all iterations. In order to optimize the present problem using GA, the following parameters have been selected to obtain the best possible solution with the least computational effort: Table 7 shows some of the minimum values of the surface roughness predicted by the GA program with respect to input machining ranges, and Table 8 shows the optimum machining conditions for the corresponding minimum values of the surface roughness shown in Table 7. The MRR given in Table 8 was calculated bywhere f is the table feed (mm/min), aa is the axial depth of cut (20 mm) and ar is the radial depth of cut (1 mm).It can be concluded from the optimization results of the GA program that it is possible to select a combination of cutting speed, feed rate, radial rake angle and nose radius for achieving the best possible surface finish giving a reasonably good material removal rate. This GA program provides optimum machining conditions for the corresponding given minimum values of the surface roughness. The application of the genetic algorithmic approach to obtain optimal machining conditions will be quite useful at the computer aided process planning (CAPP) stage in the production of high quality goods with tight tolerances by a variety of machining operations, and in the adaptive control of automated machine tools. With the known boundaries of surface roughness and machining conditions, machining could be performed with a relatively high rate of success with the selected machining conditions.6 ConclusionsThe investigations of this study indicate that the parameters cutting speed, feed, radial rake angle and nose radius are the primary actors influencing the surface roughness of medium carbon steel uring end milling. The approach presented in this paper provides n impetus to develop analytical models, based on experimental results for obtaining a surface roughness model using the response surface methodology. By incorporating the cutter geometry in the model, the validity of the model has been enhanced. The optimization of this model using geneticalgorithms has resulted in a fairly useful method of obtaining machining parameters in order to obtain the best possible surface quality.翻译：选择最佳工具，几何形状和切削条件利用表面粗糙度预测模型端铣摘要：刀具几何形状对工件表面质量产生的影响是人所共知的，因此，任何成型面端铣设计应包括刀具的几何形状。

机床加工外文文献翻译(含：英文原文及中文译文)文献出处：Shunmugam M. Basic Machining Operations and Cutting Technology[J]. Journal of the Institution of Engineers, 2014, 1(2):22-32. 英文原文Basic Machining Operations and Cutting TechnologyShunmugam MBasic Machining OperationsMachine was developed from the early Egyptian pedal car and John Wilkinson's trampoline. They provide rigid support for workpieces and tools and can precisely control their relative position and relative speed. Basically, metal cutting refers to a sharpened pry tool that removes a very narrow metal from the surface of a tough workpiece. Chips are discarded products. Compared with other workpieces, the chips are shorter, but there is a certain increase in the thickness of the uncut parts. The geometry of the workpiece surface depends on the shape of the tool and the path of the tool during machining operations.Most machining processes produce parts of different geometries. If a rough workpiece rotates on the central axis and the tool cuts into the workpiece surface parallel to the center of rotation, a rotating surface is created. This operation is called turning. If a hollow tube is machined on the inner surface in the same way, this operation is called boring. Whenthe diameter is evenly changed, a conical outer surface is produced, which is called taper turning. If the tool contact point moves in a way that changes the radius, then a workpiece with a contour like a ball is produced; or if the workpiece is short enough and the support is very rigid, then the forming tool normally feeds one outside the axis of rotation. Surfaces can be produced, and short tapered or cylindrical surfaces can also be formed.Flat surfaces are often required and they can be produced by radial turning of tool contact points with respect to the axis of rotation. It is easier to fix the tool and place the workpiece under the tool for larger workpieces while planing. The tool can feed reciprocally. The forming surface can be produced by a forming tool.Multi-blade cutters can also be used. Using a double-edged groove drilling depth is 5-10 times the hole diameter. Regardless of whether the drill rotates or the workpiece rotates, the relative motion between the cutting edge and the workpiece is an important factor. During milling, a rotating tool with many cutting edges comes into contact with the workpiece and the workpiece slowly moves relative to the tool. Flat or shaped surfaces may occur depending on the tool geometry and feed method. A horizontal or vertical axis rotation can be generated and can be fed in any of three coordinate directions.Basic machineThe machine tool produces parts with special geometry and precise dimensions by removing chips from plastic material. The latter is waste, which is a change from the long continuous strip of plastic material such as steel, which is useless from a processing point of view. It is easy to handle cracked chips produced from cast iron. The machine performs five basic metal removal processes: turning, planing, drilling, and milling. All other metal removal processes are modified from these five basic procedures. For example, boring is internal turning; reaming, tapping and counterboring are further machining of drilled holes; gear machining is based on Milling operation. Polishing and sanding are deformations that grind and remove the abrasive process. Therefore, there are only four basic types of machine tools that use specially controllable cutting tools: 1. Lathes, 2. Drilling machines, 3. Milling machines, 4. Grinding machines. The grinding process forms chips, but the geometry of the abrasive particles is uncontrollable.The amount and speed of material removal through various processing steps is enormous, just as high facets are removed in large turning operations, or in extremely small grinding and ultra-precision machining. A machine tool fulfills three major functions: 1. It supports work pieces or fixtures and tools 2. It provides relative motion to work pieces and tools 3. In each case provides a range of feeds and generally up to 4-32 species Speed choices.Processing speed and feedSpeed, feed, and depth of cut are three major variables in economic processing. The other quantities are tapping and tool material, coolant and tool geometry. The speed of the metal removal and the power required are dependent on these variables.Depth of cut, feed, and cutting speed are the mechanical parameters that must be established in any metalworking process. They all affect the force, speed and speed of metal removal. The cutting speed can be defined as the radius of the velocity recording surface that spreads radially at any instant during one revolution, or the distance between two adjacent grooves. The depth of cut is the depth of entry and the depth of the trench.Turning in the center of the latheBasic operations completed on a motorized bed have been introduced. Those operations that use a single point tool on the outside surface are called turning. In addition to drilling, reaming, and grinding of internal surfaces, the operation is done by a single point tool. All machining operations, including turning, can be categorized as roughing, finishing or semi-finishing. Finishing removes a large amount of material as quickly and efficiently as possible, while a small part of the material left on the workpiece is used for finishing. Finishing isThe workpiece gets the final size, shape and surface accuracy.Sometimes semi-finishing leaves a predetermined amount of material for finishing, which is prior to finishing.In general, longer workpieces are simultaneously supported by one or two lathe centers. Conical holes, so-called center holes, are drilled at both ends for the center of the lathe - usually along the axis of the cylindrical workpiece. The end of the workpiece near the frame is usually supported by the center of the tailstock. At the end near the main bearing is the center of the main bearing or clamped by the jaw plate. This method can firmly tighten the workpiece and can smoothly transmit the force to the workpiece. The auxiliary support provided by the chuck to the workpiece reduces the chattering tendency during cutting. If the chuck can be carefully and accurately used to support the workpiece, then Accurate results can be obtained.Supporting the workpiece between two centers can give very accurate results. One end of the workpiece has been machined, then the workpiece can be turned. The other end is machined on a lathe, and the center hole serves as a precise positioning surface and a supporting surface for carrying the weight of the workpiece and resisting the cutting force. When the workpiece is removed from the lathe for any reason, the center hole will accurately return the workpiece to this lathe or another lathe or a cylindrical grinder. Workpieces are not allowed to be clamped on the main bearing by the chuck and lathe center. However, the firstthing that comes to mind is a method of quickly adjusting the workpiece on the chuck, but this is not allowed because it is impossible to hold the center of the lathe while holding it by the chuck. The adjustment provided by the center of the lathe will not continue and the claw plate pressure will damage the center hole and lathe center, and even the lathe spindle. The floating claw plate provides an exception to the above statement. It is used almost exclusively for high production work. These chucks are real job drivers and are not used for the same purpose as ordinary three-jaw, four-jaw chucks.While large-diameter workpieces are fashioned in two centers, they are preferably held by the panel at the tail of the main bearing for smooth energy conversion; many lathe chucks do not provide sufficient energy conversion, although they can be used as special energy conversions.Mechanical processing introductionAs a method of producing a shape, machining is the most commonly used and the most important method in all manufacturing processes. The machining process is a process of producing a shape in which the drive device removes some of the material on the workpiece as chips. Although in some cases, the workpiece is supported using mobile equipment without support, most machining operations are performed by equipment that supports both the workpiece and the tool.Small batch, low cost. Machining has two applications in themanufacturing industry. Casting, forging, and pressure work produce each special shape, even one part, almost always with a higher mold cost. The shape of the weld depends largely on the raw material. By using equipment that has a high overall cost but does not have a special mold, machining is possible; starting from almost any kind of raw material, the shape is designed from any material as long as the external dimensions are large enough. Processing is therefore the preferred method. When producing one or several parts or even in mass production, the design of the parts logically leads to the casting, forging or stamping of the product. High precision, surface accuracy. The second application of mechanical machining is based on the possible high precision and surface accuracy. If mass production occurs in other processes, many low-volume components will produce low but acceptable tolerances. On the other hand, many parts produce general shapes from some large deformation processes and are only machined on selected surfaces with very high accuracy. For example, the inside process is seldom produced by any other machining method and the hole on the part may be processed immediately after the pressure operation.The main cutting parametersThere are four factors that fully describe the relationship between the basic tooling work during cutting: tool geometry, cutting speed and depth of cut. The tool must be made of a suitable material; it must have acertain strength, roughness, hardness and fatigue resistance. The tool geometry is described by face and angle and is correct for each cutting operation. Cutting speed refers to the speed at which the cutting edge passes through the work surface, which has been expressed in feet per minute. For machining efficiency, the cutting speed must be of an appropriate scale relative to the particular working combination. In general, the harder the work, the lower the speed. Feed is the rate at which the tool enters the workpiece. When the workpiece or tool rotates, the feed rate is in inches per revolution. When the tool or workpiece moves back and forth, the unit of feed is inches. In general, the feed rate is inversely proportional to the cutting speed in other similar situations. The cutting speed is expressed in inches and is represented by the distance the tool enters the workpiece. It refers to the width of the chips when turning or the thickness of the chips when cutting in a straight line. The depth of cut during roughing is greater than the depth of cut during finishing.Effect of Cutting Parameter Change on Cutting TemperatureIn metal cutting operations, heat is generated in the primary and secondary deformation zones and these results in complex temperatures throughout the tool, workpiece, and chips. A typical isothermal as shown in the figure, it can be seen that as predicted, when the workpiece material undergoes major deformation and is reduced, there is a very largetemperature gradient throughout the entire width of the chip. When the chips in the second deformed zone still have a short distance, the maximum temperature is reached.Because almost all of the work is done with metal cutting converted to heat, it can be predicted that the increased energy consumption per unit volume of metal removed will increase the cutting temperature. Therefore, when all the other parameters are unchanged, the rake angle becomes larger and the energy and cutting temperature per unit volume of metal removed will be reduced. When considering the increase in the thickness and speed of the non-formed chips, the situation is even more complicated. Increasing the thickness of the cut will often greatly affect the amount of heat transferred to the workpiece, the number of tools, and will keep the chips at a fixed amount, and at the same time the change in cutting temperature will be small. However, increasing the cutting speed will reduce the amount of heat transferred to the workpiece. This will increase the temperature rise of the main deformation of the chips. In addition, the second deformation zone is relatively small, and in this deformation zone it will increase the temperature. The other changes in cutting parameters hardly affect the removal of energy consumption per unit volume and the cutting temperature. It has thus been shown that even small changes in cutting temperature have a significant effect on tool wear rate, and it is appropriate to estimate the cutting temperature fromthe cutting data. The most direct and accurate method of testing high-speed steel tools, Trent gave detailed information on the temperature distribution of high-speed steel tools. This technique is based on the data detection of high-speed steel tools and is related to the microscopic changes in thermal history.Trent has described the measurement of cutting temperature and the temperature distribution of high-speed steel tools when machining a wide range of workpieces. Using scanning electron microscopy to study fine-scale microstructure changes, this technique has been further developed. This technique is also used to study the temperature distribution of high-speed steel single-point turning tools and twist drills.Tool wearBrittle fractures have been treated and there are basically three types of tool wear. Back flank wear, boundary wear and flank wear. Face wear occurs at the major and minor cutting edges. The main cutting edge is responsible for the removal of large amounts of metal, which increases the cutting force and temperature, and if left unchecked the vibration of the tool and the workpiece can be caused, and this can no longer be cut efficiently. The secondary cutting edge determines the workpiece size and surface finish. Wear of the flank causes poor surface accuracy in a large number of products. According to the actual cutting conditions, the main reason for the unacceptable use of the tool is that the wear of the mainflank before the secondary flank is very large, which results in the generation of an unacceptable portion. Due to the stress distribution of the tool, the frictional force in the sliding area is maximized between the chip and the surface at the beginning of sliding, and the final frictional force is zero. Therefore, abrasive wear occurs in this area. More wear occurs between the chip and the disengagement area adjacent to the area, which is more than adjacent to this point.This results in a localized pitting of the tool face at a certain distance from the face, which is usually partly arc-shaped. In many respects and based on actual cutting conditions, the boundary wear is a less severe wear than the flank, so that the wear of the face is a relatively common blunt standard. Then, as various authors have shown, with the increase of cutting speed, the increase of surface temperature is more than the increase of the blade surface, and because the temperature change seriously affects any type of wear rate, boundary wear usually occurs at higher cutting speeds. Situation.Where the tool is in contact with the uncut surface, the wear of the trailing portion of the main flank is more pronounced than that along the remaining wear surface. This is because the local influences such as the uncut surface are caused by the work hardening caused by the previous cutting, oxidation scale, and local high temperature. This localized wear is generally related to the wear of the boundary and is sometimes severe.Although the occurrence of a notch does not seriously affect the cutting performance of the tool, the notch is often deeper, and it is likely that the cutting tool will break if it continues.If any form of gradual wear continues to make its dramatic existence, the tool will face catastrophic failures, such as the cutting tool can not be cut, in good condition, the workpiece is scrapped, at worst, the mechanical tool may cause damage. For cemented carbide tools and various types of wear and tear, the maximum service life limit is reached before a catastrophic failure occurs. However, wear on high-speed steel cutting tools is uneven. It has been found that when wear continues and even catastrophic failure occurs, the most meaningful and reproducible results are obtained, but in practice, the cutting time is much less. At the time of failure. Several phenomena occur when a catastrophic failure occurs. The most common is a sudden increase in cutting force, a bright ring in the workpiece, and a significant increase in noise.Surface finishing mechanismThere are five basic mechanisms that affect the processed product: (1) The basic geometry of the cutting process, the single-point turning tool will advance axially a constant distance, the resulting surface will be on it, and the tool will feed in the vertical direction. A series of sharp points form the basic shape of the cutting tool. (2) The efficiency of cutting. It has already been mentioned that an unstable tumor willproduce a face that contains hardened tumor segments. This fragment reduces the surface finish. It can also be proved that under heavy cutting conditions, large feed rates, small rake angles and low cutting speeds can be used. In addition to these, the production conditions can also lead to unstable BDE products. The cutting process becomes unstable rather than continuous cutting in the shear zone. , Shattered, uneven discontinuous chips appear, and the surface is not smooth enough. This is especially true when working with ductile materials. (3) The stability of the machine tool. According to certain combinations of cutting conditions, workpiece dimensions, clamping methods and stiffness relative to the machine structure, instability is a tool-induced chatter. Under certain conditions, this kind of vibration will reach and maintain a certain amplitude, and vibrations based on other conditions will also be generated, unless the cutting prevents considerable damage or both the cutting tool and the workpiece may vibrate. This phenomenon is called chattering.Axial turning features a long spiral band on the workpiece and short pitch fluctuations on the temporary machined surface. (4) Remove the effectiveness of cuttings. In intermittent chip production processes, such as milling and turning of brittle materials, it is expected that whether due to gravity or cutting fluid, chips will leave the cutting zone and in any case will not affect the cutting surface. Consecutive chips are obvious, and if no measures are taken to control the chips, they may affect thecutting surface and leave marks. Inevitably, this marks only expectations.(5) The effective relief angle of the cutting tool. For small cutting edges and relief angles with a certain geometry, it is possible to cut at the main cutting edge and polish at the secondary cutting edge. This will result in good surface accuracy, but of course this combination of strictly metal forming cannot be recommended as an actual cutting method. However, due to occasional occurrence of these conditions, tool wear can cause changes in the surface properties.Limits and tolerancesMechanical parts are manufactured so they are interchangeable. In other words, each mechanical part or device is made to a size and shape suitable for other types of machines. In order to make the parts interchangeable, each part is dimensioned to fit the corresponding part in the right way. This is not only impossible, but it is impractical to make many parts into one size. This is because the machine is not perfect and the tool wears. A slight deviation from the correct size is usually allowed. The size of this deviation depends on the type of part being manufactured. For example, a part may be 6 inches and the upper and lower deviation is 0003 inches (one thousandth of a thousandth). So this deviation can be between 5,997 inches and 6003 inches and still maintain the correct size. This is bias. The difference between the upper and lower deviations is the tolerance.The tolerance is the maximum amount of change in part size, and the basic size is the size limit derived from the allowable variation and tolerance range. Sometimes the deviation allows only one direction to change. It allows the tolerance to change in the hole or axis without seriously affecting the fit. When the tolerance changes in both directions, it is called full deviation (positive and negative). The full deviation is separate and there will be on each side of the basic size. The limit size is only the largest size and the smallest size. Therefore, the tolerance is the difference between these two dimensions.Surface accuracy and size controlProducts have been completed in their proper shape and size, and often require some type of surface accuracy to enable them to perform their own functions. In some cases, in order to resist scratching and scratching, it is necessary to improve the physical properties of the surface material. In many manufacturing processes, dirt, chips, grease or other harmful substances are left on the surface of the product. Mixtures of different materials, the same materials processed in different ways, may require some special surface treatment to provide a uniform appearance.中文译文基本加工工序和切削技术Shunmugam M基本加工的操作机床是从早期的埃及人的脚踏动力车和约翰·威尔金森的镗床发展而来的。

【机械类⽂献翻译】CNC机械专业中英⽂⽂献翻译CNCCNC stands for Computerized Numerical Control and has been around since the early1970s. prior to this, it was called NC,for numerical control. While people in most walks of life have never heard of this term, CNC has touched almost every form of manufacturing process in one way or another. If you'll be working in manufacturing, it's likely that you'll be dealing with CNC on a regular basis.Before CNCWhile there are exceptions to this statement,CNC machines typically replace (or work in conjunction with) some existing manufacturing processes. Take one of the simplest manufacturing processes,drilling holes,for example.A drill press can of course be used to machine holes. A person can place a drill in the drill chuck that is secured in the spindle of the drill press. They can then (manually) select the desired speed for rotation (commonly by switching belt pulleys), and activate the spindle. Then they manually pull on the quill lever to drive the drill into the workpiece being machined.As you can easily see, there is a lot of manual intervention required to use a drill press to holes. A person is required to do something almost every step along the way! While this manual intervention may be acceptable for manufacturing companies if but a small number of holes workpieces must be machined, as quantities grow, so does the likelihood for fatigue due to the tediousness of the operation. And do note that we've used one of the simplest machining operations(drilling) for our example. There are more complicated machining operations that would require a much higher skill level (and increase the potential for mistakes resulting in scrap workpieces) of the person running the conventional machine tool. (We commonly refer to style of machine that CNC is replacing as the conventional machine.)By comparison, the CNC equivalent for a drill press (possibly a CNC machining center or CNC drilling & tapping center) can be programmed to perform this operation in a much more automatic fashion. Everything that the drill press operator was doing manually will now be done by the CNC machine, including:placing thedrill in the spindle, activating the spindle,positioning the workpiece under the drill, machining the hole, and turning off the spindle.How CNC worksAs you might already have guessed,everything that an operator would be required to do with conventional machine tools is programmable with CNC machines. Once the machine is setup and running, a CNC machine is quite simple to keep running. In fact CNC operators tend to get quite bored during lengthy production runs because there is so little to do. With some CNC machines, some of the specific programmable functions.Motion controlAll CNC machine types share this commonalty: They all have two or more programmable directions of motion called axes. An axis of motion can be linear(along a straight line) or rotary(along a circular path). One of the first specifications that imply a CNC machine's complexity is how many axes it has. Generally speaking, the more axes, the more complex the machine. The axes of any CNC machine are required for the purpose of causing the motions needed for the manufacturing process. In the drilling example, these axes would position then tool over the hole to be machined (in two axes) and machine the hole (with the third axis). Axes are named with /doc/811750010.htmlmon linear axis named X,Y,and Z. Common rotary names are A,B,and C. There are related to the coordinate system. Programmable accessoriesA CNC machine wouldn't be very helpful if all it could only move the workpiece in two or more axes. Almost all CNC machines are programmable in several other ways. The specific CNC machine type has a lot to do with its appropriate programmable accessories. Again,any required function will be programmable on full-blown CNC machine tools. Here are some examples for one machine type(machining centers).Automatic tool changerMost machining centers can hold many tools in a tool magazine. When required,the required tool can be automatically placed in spindle for machining.Spindle speed and activationThe spindle speed(in revolutions per minute) can be easily specified and the spindle can be turned on in a forward or reverse direction.It can also,of course, be turned off.CoolantMany machining operations require coolant for lubrication and cooling purposes. Coolant can be turned on and off from within the machine cycle.The CNC programThink of giving any series of step-by-step instructions. A CNC program is nothing more than another kind of instruction set.It's written in sentence-like format and the control will execute it in sequential order,step by step.A special series of CNC words are used to communicate what the machine is intended to do. CNC words begin with letter address(like F for feedrate,S for spindle speed,and X,Y,and Z for axis motion). When placed together in a logical method, a group of CNC words make up a command that resemble a sentence.The CNC controlThe CNC control will interpret a CNC program and active the series of commands in sequential order. As it reads the program, the CNC control will activate the appropriate machine functions, cause axis motion, and in general, follow the instructions given in the program.Along with interpreting the CNC program, the CNC control has several other purposes. All current model CNC controls allow programs to be modified(edited) if mistakes are found. The CNC control allows special verification functions(like dry run) to confirm the correctness of the CNC program. The CNC control allows certain important operator inputs to be specified separate from the program, like tool length values. In general, the CNC control allows functions of the machine to be manipulated.What is a CAM system?For simple applications (like drilling holes),the CNC program can developed。

Reference: classification and their respective characteristics of nc machining center Press: chemical industry press; Version 1 (March 16, 2009)Author: Xu Heng, Duan XiaoxuMachining center is a typical set of high-tech machining equipment in one, itsdevelopmentrepresents a country'slevel of design andmanufacture greatlyimproved laborproductivity, reducelabor costs, improvedworking environmentand reduce the laborof workers strength.This movementthrough the differentprograms and thedesign of variouscomponents of qualitative analysis and comparison of vertical machining centers to determine the progress of education to drive the program are: fixed-bed body, spindle seat installed by installing the sliding seat rail bed , use rolling guide rail bed can beachieved to the movement into the Y direction. Precision CNC XY table by a two-way drive to complete the workpiece X, Y two directions into a movement; X, Y, Z three directions of movement are ball screw feed, driven by AC servo motor. Guides, ball screws with the corresponding lubrication, protection and other devices.Processing center ( English abbreviate is CNC called Computerized Numerical Control ): is the library with a knife and automatic tool changer of a highly automated multi function numerical control machine tool. In China, Hongkong, Taiwan and Guangdong generation also has many people call it the computer gongs.Workpiece in machining center by a clamping, digital control system can control the machine tool according to different process, automatic selection and replacement of tools, automatically change the spindle speed, feed rate and cutting tool relative to the workpiece movement track and other auxiliary functions, followed by the completion of several surface workpiece multiple processing procedures. And there are a variety of changing knife or blade selection function, thereby greatly improving the production efficiency.Machining center CNC machine tool is provided with a computer numerical control system of machine tools, CNC system capable of processing procedures, control machine tools to complete a variety of actions. Compared with the general machine tools, CNC machine tools to complete the plane curve and space curve surface machining, the machining precision and the production efficiency is relatively high, so it has been widely applied.The composition of CNC machine toolsIn general, numerical control machine tool is composed of a mechanical part, a digital control computer, servo system, PC control part, hydraulic pressure drive system, cooling and lubrication and discharge device. CNC machine tool is controlled by a program, part of the programming work is the important part of NC machine tool. Servo system of CNC machine tool is driven in part, computer output control command is generated by the servo system coordinate movement. Ordinary vertical machining center with three servo motors to respectively drive workbench,longitudinal, transverse worktable, spindle box along the X direction, Y, Z to exercise. X, Y, Z are mutually vertical coordinate axis, so when the machine three coordinate linkage can machining space curved surface. And for the five axis linkage CNC machine, is a B axis and C axis. The Y axis of rotation of the shaft as the axis B, Z axis of rotation of the shaft as the C axis.The processing of CNC machine tools motionMachining by cutting the main movement and feed motor complete, control the main movement can be a reasonable speed, to control the feed can obtain all kinds of different machining surface. CNC machine tool coordinate motion is motion, for the three coordinate NC machine tool, the coordinates of the direction of movement is usually perpendicular to each other, whereby the respective along the Cartesian coordinates X, Y, Z axis positive and negative direction. How to control the moving coordinate system to complete different kinds of spatial curved surface processing is the main task of digital control. As we all know, in the three-dimensional Cartesian coordinates, space any point can be used X, Y, Z coordinate values to indicate, to a space curve can also use the three-dimensional coordinate function to express. How to control the axis of movement to finish machining of curved surface? Now to introduce it.Curved surface cutting tool moving trajectory and theoretic curves do not coincide, but an approximation line. Due to various interpolation formula is different, the approximation of the line are also different, usually has the following several calculation methods: point by point comparison method, integration method and time division method.The advantages, disadvantages of NC machine toolCNC machine tool has many advantages, it is developing very quickly, become the dominant machine machining.( 1) machining with NC machine tool can achieve good accuracy, stable processing qualityCNC machine tool transmission parts, particularly a ball screw with high precision. The assembly eliminates the transmission gap, and the use of improved stiffness measures, so the transmission precision is very high. Machine tool use rolling guide rail or bonded with the friction coefficient is small synthetic plastic, thus reducing the friction force, elimination of slow speed creeping. Loop, loop servo system, with high accuracy position detection device, and at any time to position error feedback to the computer, which can timely error correction. Thus the CNC machine tools to obtain high precision. CNC machine tools of all operations are performed by program control, if the control system is stable and reliable, it is very reliable, and the manual operation, numerical control machine tool without human interference, and stable processing quality.( 2) has a high production efficiencyIn the NC machine tool is usually not heavy grinding clamping type props, with hard surface coating, so the high cutting speed. Using a tool for cutting, machining center knife with a sufficient number of cutter, automatic tool change speed is very quick, air travel speed is in 15m/min above, some reached 240m/min, so the auxiliary time is short.Compared with the general machine tools, CNC machine tool production efficiency can be increased by 2~3 times, some can reach several tens of times.( 3) multiple functionsMany numerical control machine tool has many processing functions, on one machine can be boring, boring, milling, slot milling, milling plane cam curves and contours, and lettering.In addition to clampingsurface of thehexahedron fivesurface processing,sometimes also withthe coordinate planeangled plane processing. Installed in a card to complete a variety of processing, can be eliminated by the repeated clamping errors. Also reduces the measuring and clamping auxiliary time.( 4) in different parts of adaptabilityIn the same units of CNC machine tools can be adapted to different types and sizes of the parts processing, as long as the replacement of the processing procedures, can change the processing parts varieties.( 5) to complete the common machine tool can not complete the complex surface processingSome of the space curved surface, such as a screw surface, five coordinate NC machine tool processing, so that the performance is greatly improved; NC copying a broader range of applications, with repeated application, image processing function.( 6) CNC machine tools can greatly reduce the labor intensity of workers, and has higher economic benefit.Everything has its duality, CNC machine tools is not without drawbacks, mainly has the following several aspects:1) high price, a large investment.2) repair and operate more complicated requirements with high technical level and cultural level of the workers and staff in operation and repair repair. NC machine tool is the development of science and technology results. High technology products, certain requirements of high technology talent operation and repair, and if it is a weakness, still be inferior to saying it to people culture to improve the technology level of a promotion.CNC machine tool is applicable to many varieties, small batch production; the more complex shapes, high precision parts processing; frequent update of the products, the production cycle short processing; NC machine tool can be composed with automation workshop and factory automation ( FA ), the more is composed of flexible automation production line ( FML ), flexible manufacturing unit ( FMC ) and flexible manufacturing system ( FMS ).CNC machine tool classificationAt present, CNC machine too ls complete varieties, many specifications, but from different angles and in various principles of classification.According to the technological purpose classification( 1) metal cutting type NC machine tool of this kind of machine tool and the traditional general breed of machine tool, CNC lathes, CNC milling machine, CNC drilling machine, CNC grinding machines, CNC boring machine and machining center. Machining centers with automatic tool changer, installed in a card can be a variety of processes of CNC machine tools.( 2) metal molding CNC machines such as CNC bending machine, CNC bending machine, CNC turret press.( 3) NC machining and other types of CNC machines such as CNC wire cutting machine, CNC EDM machine, CNC laser cutting machine, CNC flame cutting machine.Vertical machining center: refers to the spindle axis and a worktable arranged vertically processing center, is mainly suitable for processing board type, disc type, mold and small housing complex parts. Vertical machining center can finish milling, boring, drilling, tapping and using thread cutting process. Vertical machining center is at least three two axis, the general can achieve three three axis. Some five axes, six axis control. Vertical machining center column height is limited, to a case-body-like workpiece processing to be reduced, this is a vertical machining center. But the vertical machining center the workpiece clamping, convenient location; cutting tool trajectory easy observation, convenient debugging program check measurement, can discover a problem in time, is shut down or modified; cooling condition easy to establish, cutting fluid can directly reach the tool and machining surface; a three coordinate axis and Cartesian coordinates anastomosis, intuitional sense and pattern from the perspective of consistent, chip easy removal and fall, to avoid scratching the processed surface. And the corresponding horizontal machining center, and has the advantages of simple structure, small occupied area, low price.Machining center is a under the control of the computer with automatic tool changing system can complete multiple process composite processing automationmachine tool, and a forward high speed, high precision, modularization, network and complex of the direction of development. The machining center is a typical set of high-tech in one of the mechanical processing equipment, its high production efficiency, good flexibility, the use of a machine and is easy to process the complex curve, surface features, has become the industry developed countries the main processing equipment and machinery industry. A national processing center has quantity, consumption and overall technical level and the national machinery industry manufacturing technology level is closely related to. China's processing center begins from 70 time, already had very great progress, but the technology, variety and quantity are not adapted to the economy of our country, the needs of technology development. Enter after twenty-first Century, Chinese processing center consumption with the military and civilian machinery industry large-scale technical reformation and rapid growth, such as the 2001 China machining center consumption was only 2662 (of which imports 2290 ), and the same year the United States, Japan and German machining center consumption respectively 11505, 6090 and 5291. By 2005, China processing center consumption soared to about 13200 ( estimates, machining center output data not released), which imports 10343. In 2005 the processing center consumption is 4.96 times that of 2001, year all amplitude is amounted to 49.2%, in one fell swoop over the United States, Japan, Germany and countries, to become the world most the country consumption processing center.According to the "machinist " magazine andother units of the survey,from nearly 600 copies onthe user's effectivequestionnaire results,machining centerapplication has beenthroughout the 26 industries, including automobiles, motorcycles and spare parts manufacturing industry accounted for 34%, aerospace and military industry accountedfor 24%, accounting for 18% of machine tool industry, the mold industry accounted for 15%, light industry machinery industry accounted for 9%. In these enterprises have the processing center, although the popular type of vertical and horizontal machining centers still accounted for the majority, but the multi-axis, high speed, large precision and other high-end machining centers also occupy a certain proportion, such as in a survey of nearly 600 users, with 5 axis machining center 24%. Description of Chinese consumption market of machining center although popular mid-range machine, but high-grade machine in consumption proportion is estimated that 15% to 20%. China's consumption of machining center most rely on imports ( 2005 imports accounted for more than 70% of consumption ), import an amount of $1297000000, ranking first in all kinds of machine tool imports, mainly from Japan, China, Taiwan, Germany and South Korea to import. The first half of 2006, China imported machining center 5511, amount 688000000 dollar, grow respectively compared to the same period 20% and 11%, still maintain two digit growth, China machining center market scale and growth space.The technological level of industrial equipment and modernization of the entire national economy determines the level and degree of modernization, numerical control technology and equipment is the development of new high-tech industry and cutting-edge industries ( such as information technology and industry, biological technology and industry of aviation, aerospace and other defense industry industries) of the enabling technology and the most basic equipment, Kyth once said, " the distinction between the economic times, what is not production which is how the production, what the production of labor manufacturing technology and equipment is the human production of the most basic means of production activities, and numerical control technology is today's advanced manufacturing technology and equipment, the core technology. This in order to enhance the level of manufacturing capacity and to increase the dynamic market, adapt to the widely used around the world NC manufacturing technology, in addition, the developed countries in the world the numerical control technology and numerical control equipment as the strategic materials of the country, not only take significant measures to develop its own digitaltechnology and its industry, but also in the "sophisticated " digital key technology and equipment to China's policy of closures and restrictions. In conclusion, develop energetically with numerical control technology as the core of the advanced manufacturing technology has become the world each developed countries to accelerate economic development, enhance comprehensive national strength and the national status of important ways.NC technology is the use of digital information on the mechanical movement and the work process control technology, numerical control equipment is based on CNC technology as the representative of the new technology to traditional industry and burgeoning manufacturing industry form the infiltration of electromechanical integration products, the so-called digital equipment, the technical scope covers many fields: ( 1) machinery manufacturing technology; ( 2) information processing, processing, transmission technology; ( 3) automatic control technology; ( 4) servo drive technology; sensor technology; ( 5) ( 6) software technology.The development tendency of CNC numerical control technology application is not only to the traditional manufacturing industry has brought a revolutionary change, make the manufacturing industry to become a symbol of industrialization, and, with the continuous development of NC technology and the expansion of application fields, beneficial to the people's livelihood he on some important industry ( IT, automobiles, light industry, medical and so on ) development plays a more and more important, because these industries needed equipment digital is a modern development trend.Numerical control technology in China started in 1958, nearly 50 years of the development process can be divided into 3 stages: the first stage is from 1958 to 1979, i.e. closed type development stage. At this stage, because foreign technology blockadeand our basic conditionsof development ofnumerical controltechnology is relativelyslow. The second stageis in the national " six five ", " seven five " and " eight five " during early restriction, namely technology introduction, digestion and absorption, preliminary build localization system stage. At this stage, because of reform and opening up the country, and the importance of research and development of environment and international environment improvement. Our country numerical control technology research and development as well as in the domestic products have made considerable progress. The third stage is in the national " eight five " and " Nine Five " of the late period, namely the implementation industrialization research, into the market competition stage. At this stage, China's domestic CNC equipment industry has made substantial progress. The "Nine Five " stage, domestic CNC machine tool 's 50% share of the domestic market with domestic NC system ( Universal ) also reached 10%. Looking at China's CNC technology development course of nearly 50 years, especially after the 4 5 years plan research, overall obtained the following results. Lay the CNC technology development foundation, basic knowledge of modern NC technique. China now has basically mastered from the NC system, servo drive, NC machine, special machines and accessories based technology. Most of these techniques have commercial development foundation, part of technology commercialization, industrialization. B. initially formed the industrial base of CNC, the research achievements and technology commercialization based on. To establish such as CNC, aerospace has a production capacity of the production plant of CNC system, CNC and a number of servo system and servo motor production plant, Beijing first machine tool plant, Ji'nan first machine tool plant of machine manufacturing plant. These factories basically formed our country numerical control industry base. C. established a CNC research, development, management personnel of the basic team. In the numerical control technology research and development and industrialization has made considerable progress, but we also should realise soberly, our high-end CNC technology research and development. Especially in the industrialization level of technical current situation and the reality of China's demand to still have bigger difference. Although from a longitudinal look at our country develops very fast, but transverse than ( contrast with abroad ) not only technical level to have difference, insome aspects of development speed also has difference, i.e. the number of sophisticated CNC equipment technical level difference has distensible tendency. Internationally, to our country numerical control technology and industrialization level is estimated as follows. The level of A. technique, with foreign advanced level lags behind about 10 ~ 15 years, in the sophisticated technology is larger. B. industrialization level, the market is had rate is low, breed coverage, has formed the scale of production, functional components of professional production level and complete sets of capacity is low; the appearance quality is relatively poor; reliability; commercialization; domestic CNC system has not been established their own brand, customer confidence. C. sustainable development ability of competition, before NC technology research and development, engineering ability is weaker; CNC technical application field strength is not strong; related standards, research, develop lag, analyse the existence of the gap between the main reason has the following sides, A. recognition. On domestic CNC industry process difficult, the complexity and the long-term characteristic of insufficient understanding; to the market is not standardized, overseas blockade and kill the system difficult underestimate; to our country numerical control technology application level and ability analysis is not enough. B. system, from the technical point of view about numerical control industrialization problem when much, from the system the angle of industrial catenary considering CNC industrialization problem when little; not the establishment of a complete quality system, perfect training, service network support system. C. mechanism of adverse mechanisms causing the loss of talented people, and restricted technology and technical route of innovation, product innovation, and restricts the effective implementation of the project, often the planning ideal, implementation difficulties. D. technology, enterprise technology independent innovation capability is not strong, the core technology of engineering ability is not strong, bed standard is backward, level is low, the new standard is not enough research of CNC system.control technology andindustrial development strategy:( 1) the strategic considerationof our country is a bigmanufacturing country in theworld, in the transfer ofindustry to accept the frontrather than the back transfer,namely to grasp the core technology of advanced manufacturing, or in the new roundinternational industry structural adjustment, our country manufacturing industry willfurther " air core ". Our resources, environment, market price exchange may be thenew world economic pattern in the international " machining center " or " assemblycenters ", rather than to master the core technology of manufacturing center position,this will seriously affect our country with the development of modern manufacturingprocess. First, from the social security, because we should stand in the height ofnational security strategy to take the numerical control technology and the industrycontrol, industry in China is the most populous industry employment, manufacturingindustry development can not only improve the people's living standard, but also canalleviate the pressure of employment of our country social stability; secondly, fromthe defense safety, western developed countries have sophisticated CNC products areclassified as national strategic material for China to realize embargo and restrictions, "Toshiba event " and " the Cox report " is the best example. ( 2) development strategyfrom the perspective of China's basic national conditions, to the needs of nationalstrategy and national economy to market demand-oriented, to improve China'sequipment manufacturing industry comprehensive competitive ability andindustrialization level as the goal, in a systematic way, leading to the beginning of thetwenty-first Century time choice of China's equipment manufacturing industryupgrade key techniques and support industrialization development technology,supporting technology as the research content of the development of equipmentmanufacturing industry leaping development. Emphasize the market demand oriented, i.e. to terminal NC products, to machine ( such as the large volume of CNC lathes, milling machine, high speed and high precision high performance machine tools, key industries and key equipment ) drives the NC industry development, solve CNC system and related functional components ( digital servo system with high speed electric motor, the spindle system and the new equipment accessories ) reliability and scale of production problems. No scale will not have the high reliability of the products; no scale will have low prices and competitive products; of course not the scale of China's CNC equipment finally to have one's day. In the sophisticated equipment research and development, production and research and to emphasize the end user closely, with " do, use, sell out " as the goal, according to the national will to tackle key problem, in order to solve the urgent state. In the competition before the NC technology, emphasis on innovation, emphasis on research and development with independent intellectual property rights of technology and products, to industry of our country numerical control, the equipment manufacturing industry and the manufacturing industry to lay the foundation for sustainable development.加工中心数控技术出处：数控加工中心的分类以及各自特点出版社:化学工业出版社; 第1版(2009年3月16日)作者：徐衡、段晓旭加工中心是典型的集高技术于一体的机械加工设备，它的发展代表了一个国家设计制造的水平也大大提高了劳动生产率，降低了劳动成本，改善了工人的工作环境，降低了工人的劳动强度。

外文原文：HF─12MExtra─Large Multi─CenterHF─12m Multi─Center is a bridge-type extra-large milling and boring machine designed for efficient five-face machining of large marine vessel engine blocks. Inheriting the machining capability and ease-of-operation features of SNKˈs long-selling HF family of milling and boring machines, HF-12M embodies SNKˈs accumulated technology for making large machine tools[Feature]1.The ram spindlehead is equipped with a rigid spindle (ISO No.60, 150/120kw,5~1,200min) designed for powerful machining operations.2.Thermally stable mechanical design for minimum thermal displacement of the spindleposition and for high machining accuracy.3.The W-axis(crossrail) twin drive system under numerical control and crossrail leveling(hydraulic balancing) according to the ram spindlehead position ensure consistent machining accuracy.4.The ram with a 550*550mm cross section equipped with a powerful clamping mechanismenables efficient machining even with a long attachment.5. A variety of attachments (11types) are available for efficient machining , ranging fromroughing to finishing, of workpieces of any configuration.6.Various devices and functions including an automatic tool changer , automatic attachmentchanger, five-face machining software, and automatic measurement and alignment functions are available for setup time reduction and automation.[Specifications]PRS ─ 1656 ─ Axis High ─ Speed ProfilerPRS-165 is a six-axis high-speed profiler with one rotary table axis and two rotary spindlehead axes, developed for three axis machining of inclined or indexed surface of medium and small-size aircraft parts and fire-axis machining of three dimensional contours.PRS-165shortens lead times by reducing the number of setups and enhances the accuracy and service life of end products by making unitized monolithic structures possible.[Features]1.The six-axis configuration consisting of three orthogonal linear axes and three rotary axesoffers a greater degree of freedom in axis selection than five-axis configuration , enabling creative approaches to machining.2.The powerful 37kw, 12,000min-1 spindle with an ISO No.50 nose taper enables the machiningof a wide verity of workpieces from titanium alloys to aluminum.3.The spindlehead with built-in piping and wiring minimizes interference with the workpiece.4. A small-size angle attachment (option) adds the ability to drill holes into pocket sidewalls.5.The spindle in the vertical position covers the entire table surface, which is ideally sized(1,650×1,650mm) for aircraft parts.6.The endless rotation capability of the B and C axes, which enables the programmer to preparepart programs without heeding rewinding, makes for higher efficiency and accuracy of machining.7.Machining operations can be automated with optional devices such as a large-capacity (120tools) automatic tool changer and an automatic attachment changer capable of storing two attachments.DCU-5Ultra-High-speed Milling MachineTo meet growing user needs for shorter lead times and streamlining of die-and mold-making processes, SNK has embodied its latest high-speed die and mold machining technologies in the machine ,attachments and control system of DCU-5. This newest addition to SNKˈfamily of high-speed milling machines is another major step toward the elimination of handwork and further improvement of machining efficiency.[feature]1.Reduced weight and increased rigidity of the machine have increased the maximum cuttingfeederate from 20m/min to 30 m/min , dramatically improving machining efficiency.2. A newly developed ultra-high-speed(40,000min-1) universal attachment and a high –speedextension attachment enable high-speed full-surface machining with a small-diameter end mill to produce a smooth surface.3.The automatic tool changerˈs ability to handle both No.50 and No.30 tool holders greatlyfacilitates automation.4.The increased ram stroke of 1,200mm meets the needs of machine shops producingincreasingly large dies and molds.5.The advanced dynamic controller DCS-IV , which incorporates SNKˈs unique high-speedcontrol technology, is designed for higher speed, efficiency and quality in die and mild machining.DC-5AS/5Axis High-Speed Milling Machine(Attachment Type)DC-5AS is one of SNKˈs solutions to the needs for in creasingly complex dies and molds being made possible by unitization. Consisting of SNKˈs model DC high-speed milling machine and a newly develop[ed attachment with two rotary axes. DC-5AS is SNKˈs newest continuous 5-axis high-speed milling machine designed for higher efficiency and accuracy in die and mold machining.[Fearure]1.Continuous 5-axis machining is made possible by installing a continuously indexable andautomatically detachable attachment with two rotary axes at the end of a ram of a three-linear-axis machine.2.Endless rotation of the C-axis makes it possible to prepare part programs without heedingrewinding, giving DC-5AS fully continuous 5-axis machining capability.3.DC-5ASˈs ability to perform not only five-face machining but also the machining of inclinedsurfaces boosts productivity in die and mold machining. This versatility also contributes to the development of new machining techniques.4.The powerful 5-axis attachment(power:37/30kw, maximum torque: 827/700Nm) dramaticallyreduces rough machining time.5.The advanced dynamic controller DCS-IV, which incorporates SNKˈs unique high-speedcontrol technology, is designed for higher speed, efficiency and quality in die and mold machining.6.Software and accessories that make SNKˈs wide variety of att achments and machines easierto use are available to meet varying die and mold machining needs.中文译文：HF-12M超大型多功能加工中心HF-12M多功能加工中心，是一个桥式超大钻铣床。

中英文资料翻译英文部分The new concept of cutting processingThe nowadays cutting tool company cannot only be again the manufacture and the sales cutting tool, in order to succeed, they must be consistent with the globalization manufacture tendency maintenance, through enhances the efficiency, cooperates with the customer reduces the cost. Approaches the instantaneous global competition after this after NAFTA, the WTO time, the world company is making quickly to the same feeling, is lighter, a cheaper response. In other words, they make the product and the components contain can in high speed under revolve, as a result of the cost pressure, best, is lighter moreover must make cheaply. Obtains these goals a best way is through develops and applies the new material, but these is new and the improvement material usually all with difficulty processes. In in this kind of commercial power and the technical difficulty combination is especially prominent in the automobile and the aviation industry, and has become has the experience the cutting tool company to research and develop the department the most important driving influence.For example, takes the modular cast iron to say that, it has become the engine part and other automobiles, the agriculture the material which see day by day with the equipment and in the machine tool industry components. This kind of alloy provides the low production cost and the good machine capability combination. They are cheaper than the steel products, but has a higher intensity and toughness compared to the cast iron. But at the same time the modular cast iron is extremely wear-resisting, has fast breaks by rubbing the cutting tool material the tendency. In this wear resistant very great degree bead luminous body content influence. Some known modular cast iron bead luminous body content higher, its resistance to wear better, moreover its machinability is worse. Moreover, the modular cast iron porosity causes off and on to cut, this even more reduces the life.May estimate that, the high degree of hardness and the high wear-resisting cutting material quality must consider the modular cast iron the high resistance to wear. And the material quality contains extremely hard TiC in fact (carbonized titanium) or TiCN (carbon titanium nitrides) thick coating when cutting speed each minute 300 meters processes the modular cast iron to prove usually is effective. But along with cutting speed increase, scrap/The cutting tool junctionplane temperature also is increasing. When has such situation, the TiC coating favors in has the chemical reaction with the iron and softens, more pressures function in anti- crescent moon hollow attrition coating. Under these conditions, hoped has one chemical stability better coating, like Al2O3 (although under low speed was inferior to TiC hard or is wear-resisting).The chemical stability becomes an important performance performance dividing line compared to the resistance to wear the factor, the speed and the temperature is decided in is processed the modular cast iron the crystal grain structure and the performance. But usually thick coating of TiCN and TiC or only ductile iron oxides in the soil coating is applied to, because the today majority of this kinds are processed the material the cutting speed in each minute 150 to 335 meters between. Is higher than each minute 300 meter applications regarding the speed, the people to this kind of material are satisfied.In order to cause this scope performance to be most superior, the mountain high researched and developed and has promoted in view of modular cast iron processing material quality TX150. This kind of material quality has hard also the anti- distortion substrate, is very ideal regarding the processing modular cast iron. Its coating the oxide compound coating which hollowly wears by thick very wear-resisting carbon titanium nitrides and a thin anti- crescent moon, the top is thin layer TiN. This kind of coating which needs the center warm chemistry gas phase deposition using the state of the art production resistance to wear and the anti- crescent moon hollow attrition which the CVD coating complete degree of hardness moreover the tough smoothness increases (MTCVD) the craft. Substrate/The coating combination performance gives the very high anti- plastic deformation and the cutting edge micro collapses the ability, causes it to become under the normal speed to process the modular cast iron the ideal material quality.The coating ceramics also display can effectively process the modular cast iron. In the past, the aluminum oxide ceramics application which not the coating tough good such as nitriding silicon and the silicon carbide textile fiber strengthened the work piece material chemistry paralysis limit. Today but could resist the scrap distortion process through the use to have the high thermal coating cutting tool life already remarkably to increase. But certain early this domains work piece processing use aluminum oxides spread the layer crystals to have to strengthen the ceramics, today most research concentrate in the TiN coating nitriding silicon. This kind of coating can remarkably open up the tough good ceramics the application scope.When machining, the work piece has processed the surface is depends upon the cutting tool and the work piece makes the relative motion to obtain.According to the surface method of formation, the machining may divide into the knife point path law, the formed cutting tool law, the generating process three kinds.The knife point path law is depends upon the knife point to be opposite in the work piecesurface path, obtains the superficial geometry shape which the work piece requests, like the turning outer annulus, the shaping plane, the grinding outer annulus, with the profile turning forming surface and so on, the knife point path are decided the cutting tool and the work piece relative motion which provides in the engine bed;The formed cutting tool law abbreviation forming, is with the formed cutting tool which matches with the work piece final superficial outline, or the formed grinding wheel and so on processes the formed surface, like formed turning, formed milling and form grinding and so on, because forms the cutting tool the manufacture quite to be difficult, therefore only uses in processing the short formed surface generally;The generating process name rolls cuts method, is when the processing the cutting tool and the work piece do unfold the movement relatively, the cutting tool and the work piece centrode make the pure trundle mutually, between both maintains the definite transmission ratio relations, obtains the processing surface is the knife edge in this kind of movement envelope, in the gear processing rolls the tooth, the gear shaping, the shaving, the top horizontal jade piece tooth and rubs the tooth and so on to be the generating process processing.Some machining has at the same time the knife point path law and the formed cutting tool method characteristic, like thread turning.The machining quality mainly is refers to the work piece the processing precision and the surface quality (including surface roughness, residual stress and superficial hardening).Along with the technical progress, the machining quality enhances unceasingly.The 18th century later periods, the machining precision counts by the millimeter; At the beginning of 20th century, machining precision Gao Yida 0.01 millimeter; To the 50's, the machining precision has reached a micron level; The 70's, the machining precision enhances to 0.1 micron.The influence machining quality primary factor has aspects and so on engine bed, cutting tool, jig, work piece semifinished materials, technique and processing environment.Must improve the machining quality, must take the suitable measure to the above various aspects, like reduces the engine bed work error, selects the cutting tool correctly, improves the semifinished materials quality, the reasonable arrangement craft, the improvement environmental condition and so on.Enhances the cutting specifications to enhance the material excision rate, is enhances the machining efficiency the essential way.The commonly used highly effective machining method has the high-speed cutting, the force cutting, the plasma arc heating cuts and vibrates the cutting and so on.The grinding speed is called the high-speed grinding in 45 meters/second above es the high-speed cutting (or grinding) both may enhance the efficiency, and mayreduce the surface roughness.The high-speed cutting (or grinding) requests the engine bed to have the high speed, the high rigidity, the high efficiency and the vibration-proof good craft system; Requests the cutting tool to have the reasonable geometry parameter and the convenience tight way, but also must consider the safe reliable chip breaking method.The force cutting refers to the roughing feed or cuts the deep machining greatly, uses in the turning and the grinding generally.The force turning main characteristic is the lathe tool besides the main cutting edge, but also some is parallel in the work piece has processed superficial the vice-cutting edge simultaneously to participate in the cutting, therefore may enhance to feed quantity compared to the general turning several times of even several pares with the high-speed cutting, the force cutting cutting temperature is low, the cutting tool life is long, the cutting efficiency is high; The shortcoming is processes the surface to be rough.When force cutting, the radial direction cutting force death of a parent is not suitable for to process the tall and slender work piece very much.The vibration cutting is along the cutting tool direction of feed, the attachment low frequency or the high frequency vibration machining, may enhance the cutting efficiency.The low frequency vibration cutting has the very good chip breaking effect, but does not use the chip breaking equipment, makes the knife edge intensity to increase, time the cutting total power dissipation compared to has the chip breaking installment ordinary cutting to reduce about 40%.The high frequency vibration cutting also called the ultrasonic wave vibration cutting, is helpful in reduces between the cutting tool and the work piece friction, reduces the cutting temperature, reduces the cutting tool the coherence attrition, thus the enhancement cutting efficiency and the processing surface quality, the cutting tool life may enhance 40% approximately.To lumber, plastic, rubber, glass, marble, granite and so on nonmetallic material machining, although is similar with the metal material cutting, but uses the cutting tool, the equipment and the cutting specifications and so on has the characteristic respectively.The lumber product machining mainly carries in each kind of joiner's bench, its method mainly has: The saw cuts, digs cuts, the turning, the milling, drills truncates with the polishing and so on.The plastic rigidity is worse than the metal, the easy bending strain, the thermoplastic thermal conductivity to be in particular bad, easy to elevate temperature the conditioning.When cutting plastic, suitably with the high-speed steel or the hard alloy tools, selects the small to feed quantity and the high cutting speed, and uses compressed air cooling.If the cutting tool is sharp, the angle is appropriate, may produce the belt-shaped scrap, easy to carry off the quantity of heat.Glass (including semiconducting material and so on germanium, silicon) but degree of hardness high brittleness is big.To methods and so on glass machining commonly used cutting, drill hole, attrition and polishing.To thickness in three millimeters following glass plates, the simple cutting method is with the diamond or other hard materials, in glass surface manual scoring, the use scratch place stress concentration, then uses the hand to break off.To the marble, the granite and the concrete and so on the hard material processing, mainly uses methods and so on cutting, turning, drill hole, shaping, attrition and polishing.When cutting the available circular saw blade adds the grinding compound and the water; The outer annulus and the end surface may use the negative rake the hard alloy lathe tool, by 10~30 meter/minute cutting speed turning; Drills a hole the available hard alloy drill bit; The big stone material plane available hard alloy planing tool or rolls cuts planing tool shaping; The precise smooth surface, available three mutually for the datum to the method which grinds, or the grinding and the polishing method obtains.Cutting tool in hot strong alloy applicationThe aviation processing also changes rapidly. For example, nickel base heat-resisting alloy like several years ago the most people had not heard Rene88 now occupies to the aircraft engine manufacture uses the total metal quantity 10~25%. Has very good showing and the commercial reason regarding this. For example, these heat strong alloy will be able to increase the engine endurance moreover to permit the small engine work on the big airplane, that will enhance the combustion efficiency and reduces the operation cost. These tough good materials also present the expense on the cutting tool. Their thermal stability causes on the knife point the temperature to be higher, thus reduced the cutting tool life. Similarly, in these alloy carbide pellet remarkably increased the friction, thus reduces the cutting tool life.As a result of changes in these conditions, can be very pleased to have processed many titanium alloys and nickel-based alloy materials C-2 hard metal alloys, in the application to today's cutting edge of blade to the crushing and cutting depth of the trench lines badly worn. But using the latest high-temperature processing of small particles hard metal alloys to be effective, cutlery life improved, but more importantly to enhance the reliability of applications in high-temperature alloys. Small particles hard metal than traditional hard metal materials higher compression strength and hardness, only a small increase in the resilience of the cost. And resulted in high temperature alloy processing than traditional hard metal resistance common failure mode more effective.PVD (physical gas phase deposition) coating also by certificate effective processing heat-resisting alloy. TiN (titanium nitrides) the PVD coating was uses and still was most early most receives welcome. Recently, TiAlN (nitrogen calorization titanium) and TiCN (carbontitanium nitrides) the coating also could very good use. In the past the TiAlN coating application scope and TiN compared the limit to be more. But after the cutting speed enhances them is a very good choice, enhances the productivity in these applications to reach 40%. On the other hand, is decided under the low cutting speed in coating superficial operating mode TiAlN can cause to accumulate the filings lump afterwards, micro collapses with the trench attrition.Recently, used in the heat-resisting alloy application material quality already developing, these coating but became by several combinations. The massive laboratories and the scene test has already proven this kind of combination and other any kind of sole coating compares in time the very wide scope application is very effective. Therefore aims at the heat-resisting alloy application the PVD compound coating possibly to become the focal point which the hard alloy new material quality research and development continues. With the MTCVD coating, the coating ceramics gather in the same place, they hopefully become a more effective processing to research and develop newly are more difficult to process the work piece material the main impact strength.Dry processingIncluding the refrigerant question is technical and the commercial expansion industrial production tendency another domain which the cutting tool makes. North America and the European strict refrigerant management request and the biggest three automobile manufacturer forces them the core supplier to obtain the ISO14000 authentication (the ISO9000 environment management edition), this causes the refrigerant processing cost rise. To the car company and their core supplier said obviously one of responses which welcome is in the specific processing application avoids completely the refrigerant the use. This kind did the processing the new world to propose a series of challenges for the cutting tool supplier.Recently, already appeared some to concern this topic to promulgate the speed, to enter for, the coating chemical composition and other parameters very substantial comprehensive nature very strong useful technical papers. Wants to concentrate the elaboration in here me "does the processing viewpoint" in the operation and commercial meaning automobile manufacturer new.The metal working jobholders can the very good understanding related refrigerant use question, but majority cannot understand concerns except the technical challenge (for example row of filings) beside does the processing question in the cutting tool - work piece contact face between. Usually may observe to the refrigerant disperser scrap which flows out, but the pressure surpasses 3,000 pounds/An inch 2 high speed refrigerant also can help to break the filings, specially soft also the continual scrap can cause in the cutting tool - work piece contact face trouble.Uses does the cutting craft the components result is the engine bed uses the wet typeprocessing components to be hotter than. Whether before you do allow them to survey in the open-air natural cooling? If processes newly the hot components put frequently to the turnover box, elevates the environment temperature, whether components full cooling and just right enough permission precision examination? Also has the handling side several dozens on hundred components to be able to operate the worker to increase the extra burden.With many cutting tools/The work piece technical question same place, these latent questions need to state whether dryly adds the ability line. Luckily, has very many ways to elaborate these questions. For example, the compressed air was proven row of filings becomes the question in very many applications the situation to have the successful echo.Another plan is called MQL (minimum lubrication) a technology, it replaces the traditional refrigerant by the application the quite few oil mists constitution. This is a recognition compromise plan, this kind of minimum technology can large scale reduce the refrigerant the headache matter, moreover the smooth finish which processes in many applications very is also good. This domain still had very many research to do, moreover the cutting tool company positively participated in such research was absolutely essential. If they will not do fall behind the competitor, will be at the disadvantageous position.In the factory the special details design other perhaps better plan according to the world in. The manufacturing industry jobholders possibly still could ask why they do have to use recent development the technology to replace the refrigerant method diligently which the tradition already an experience number generation of person improved enhances, because implemented especially does the experiment and the defeat which the processing or the subarid processing produced possibly causes the higher short-term cutting tool cost. The concise answer is when the bit probably accounts for the model processing components cost 3%, the refrigerant cost (from purchases to maintenance, storage, processing) can account for the components cost 15%.Perhaps does the dry processing is not all suits to each application, but above discusses likely other processing questions are same, needs from a wider operation, the environment and the commercial angle appraises. Will be able to help the cutting tool company which the customer will do this to have the competitive advantage, but these will not be able to provide unceasingly is in the passive position.Cutting tool and nanotechnologyCan fiercely change the cutting tool industry the enchanting new domain is the miniature manufacture, or the processing small granule forms the product which needs. Must refer to is its here does not have about the cutting tool miniature manufacture first matter; Second must say the matter is it is not remote.Why the miniature manufacture and are the cutting tool related. Because most main is theparticle size smaller, the hard alloy toughness of material better also is more wear-resisting. (Some experts define with the nanometer level pellet for are smaller than 0.2 mu m, but other people persisted a nanometer pellet had to be smaller than the hard alloy tools prototype which 0.1 mu m) made already to complete and the test,It is said that wear resistant theatrically increase. The question is the nanometer level hard alloy pellet cannot depend on the smashing big material formation, they are certain through the smaller material constitution, but processes the molecular level granule is not easy and the economical matter.中文部分切削加工新概念现今的刀具公司再也不能只是制造和销售刀具，为了成功，他们必须与全球化制造趋势保持一致，通过提高效率、同客户合作来降低成本。

机械专业文献带翻译Title: Research and Development of a Novel Mechanical Device for Automated Assembly of Small Parts。

Abstract:The assembly of small parts is a time-consuming and labor-intensive process, often requiring skilled workers to perform the task. In order to improve efficiency and reduce costs, a novel mechanical device for automated assembly of small parts has been developed. This device is capable of handling a variety of small parts with high precision and speed, and can significantly reduce the time and cost required for assembly.Introduction:The assembly of small parts is a critical process in many industries, including electronics, automotive, and medical device manufacturing. This process often requiresskilled workers to perform the task, which can be time-consuming and costly. In addition, human error can lead to defects and quality issues, further increasing costs and reducing efficiency.To address these challenges, a novel mechanical device for automated assembly of small parts has been developed. This device is capable of handling a variety of small parts with high precision and speed, and can significantly reduce the time and cost required for assembly.Design and Development:The mechanical device for automated assembly of small parts consists of several key components, including a feeder, a manipulator, and a control system. The feeder is responsible for delivering small parts to the manipulator, which then assembles the parts according to a predetermined pattern. The control system coordinates the movements of the feeder and manipulator, ensuring that the assembly process is carried out with high precision and speed.The design of the manipulator is particularly important, as it must be capable of handling a wide range of smallparts with varying shapes and sizes. The manipulatorconsists of a series of grippers and suction cups, whichcan be adjusted to accommodate different types of parts.The grippers and suction cups are controlled by a series of motors and sensors, which ensure that the parts are picked up and assembled accurately.Testing and Evaluation:The mechanical device for automated assembly of small parts has been tested extensively in a laboratory setting, and has demonstrated high levels of precision and speed.The device is capable of handling a wide range of small parts, including electronic components, screws, and bolts.In addition, the device has been shown to significantly reduce the time and cost required for assembly, compared to manual assembly methods.Future Directions:The mechanical device for automated assembly of small parts has significant potential for use in a variety of industries, including electronics, automotive, and medical device manufacturing. Further research and development is needed to optimize the design and performance of the device, and to explore its potential for use in new applications.Conclusion:The development of a novel mechanical device for automated assembly of small parts has the potential to revolutionize the assembly process in many industries. This device is capable of handling a wide range of small parts with high precision and speed, and can significantly reduce the time and cost required for assembly. Further research and development is needed to optimize the design and performance of the device, and to explore its potential for use in new applications.。
