CL-C08H1 规格书
- 格式：pdf
- 大小：1.62 MB
- 文档页数：27
序 号内 容页 数No.contentpages 变更履历Version history 式样书Specification 附录1 包装式样P.S.1 Packing 附录2 伺服PCB参考图P.S.2 Servo PCB reference drawing 附录3 伺服元件限高图P.S.3 Limit height of servo PCB unit drawing 附录4 15pin FPC规格P.S.4 Specification of 15pin FPC 附录5 开关分布图P.S.5 Switch arrangement drawing 附录6 参考插座规格P.S.6 Socket specification 附录7 进出碟时序图P.S.7 Load/Eject timing chart 附录8 外观图P.S.8 Appearance drawing 附录9 爆炸图P.S.9 Explode view71目 录Contents11213316141511118193101产品规格书变更履历表Version history序号版本变更内容生效日期制作确认批准No.Version Change description Date Prepared by Confirmed by Approved by 10首次发行2009.08.20黄显波李民阳荣华CL-C08H1 产品规格书SPECIFICATION FOR CL-C08H11、适用范围 Scope of application本仕样书适用于车用CD，机种编号为CL-C08H1（12cm disc only），是针对该机种作出的规定。
对本仕样书产生疑义或需要追加仕样时，通过双方协商决定。
This specification applies to the CD mechanism model CL-C08H1（120mm disc only） for car.However，when a certain doubt arises with this specification，or an additional specification is needed，the updating of this isdetermined on mutual discussion.2、形状、外观尺寸 Configuration and dimensionsW 141.7 × D 125 × 35.4详细请参照附录4外观图。
Refer to the separate appearance drawing，development drawing and parts list for development drawing.3、一般仕样 General specification3-1 构造方式 Mechanical system3-1-1入碟 Disc loadingPOWER LOADING 方式Power loading method3-1-2出碟 Disc dischargeSOFT EJECT 方式Soft eject method3-1-3放音 Play一入碟即放音方式（采用敝司的微控制器）Disc-in-play method（in case of applying the SHINWA's standard microcmputer）3-1-4耐振 Antivibration加硅胶的合成橡胶减震方式Silicon elastomer damper method3-1-5驱动源 Driving source三马达方式3-motor-method3-1-6重量 Weight约460gAbout 460g3-2 光学系列方式（光头） Optical system（pickup）method3-2-1 半导体激光 Semiconductor laser波长775～800nmWavelength ranging from 775 to 800nm3-2-2 物镜 Object lens非球面塑料Aspherical plastics3-2-3聚焦 FocusingSSD法SSD（spot size detection）method3-2-4追踪摄影（循道） Tracking三光束方式3-beam method3-2-5光探知器 Photo detector全息激光Hologram laser4、所使用的电气部品 Electric apparatuses4-1激光头 Optical pickup OPTIMA-726A1VICTOR1unit 4-2 主轴马达 Spindle motor RF-400CA MABUCHI1unit 4-3 进给马达 Feed motor FF-030PK09210 MABUCHI1unit 4-4装载马达 Loading motor FF-050SH-11190MABUCHI1unit 4-5最内周检测开关 Innermost periphery detecting switch SPPB11ALPS1unit 4-6 光碟检测开关 Disc detecting switch SPVG 420200ALPS 2 units5、使用条件 Standard operational condition5-1-1 前后方向 Front to Rear性能保证: -10°～ +45°Characteristic guarantee: -10°～ +45°动作保证: -10°～ +60°Operating guarantee: -10°～ +60°5-1-2 左右方向 Side to Side性能保证: -10°～ +10°Characteristic guarantee: -10°～ +10°动作保证: -10°～ +10°Operating guarantee: -10°～ +10°5-2 工作性能保证温度范围 Characteristic guarantee temperature -20℃～+70℃5-3 动作保证温度范围 Operating guarantee temperature -30℃～+80℃5-4 储存温度范围 Storage temperature range -40℃～+85℃5-5 工作湿度范围 Operating moisture 45% ～ 85% RH.5-6 储存湿度范围 Storage moisture range 30% ～ 90% RH.6、使用的碟片 Disc adopted原则上使用按RED BOOKLET 制定的规格生产的碟片（但不可使用8cm 碟）。
Disc that complies with the specification prescribed in RED BOOKLET. (However, 8cm disc cannot be used.)7、标准测量条件 Standard measuring condition 7-1检验环境 Ambient condition 温度：+20℃±3℃Atmospheric temperature ：In a range of +20℃±3℃湿度：65%±5%RHHumidity:In a range of 65%±5%场所：在无噪音的静室内.Criterion for place ：Quiet room without noise.但只要不产生疑义，在以下条件下亦可：温度：15℃～30℃、湿度：45%～85%、背景噪音在20dB （A ）以下的消音室。
However ，as long as no doubt arises with criterion ，the following condition is allowed ：Temperature ：15℃～30℃,humidity ：45%～85%7-2 机芯控制回路 Mechanical control circuit 敝司标准回路或同等品。
SHINWA's standard circuit ，or the equivalent.8、一般性能 General performance 8-1构造 Structure要把指定的零件安装在指定的位置上。
Prescribed parts shall be assembled and laid out in a prescribed place.储存Storage动作保证Operating guarantee 性能保证Characteristic guarantee动作保证Operating guarantee存储Storage℃℃℃℃℃℃8-2 外观 Appearance不能造成功能障碍，不能有不适当的伤痕、生锈、脏污、歪斜。
There shall be no functionally defective or inappropriate scratch ，rust ，dirtiness ，and deformation.8-3 动作性能 Operational performance 8-3-1碟片装入 Disc loading一旦把碟片插到规定的位置上，就会被吸入，被顺畅的卡到碟台上。
When inserting a disc as far as a prescribed position ，the disc shall be loaded ，and shall be smoothly chucked in the turntable.8-3-2 碟片排出 Disc discharge通过对排出按钮的操作，把碟片排出到规定位置上并停止。
When the discharge button is operated ，a loaded disc shall be discharged out as far as prescribed ，and be stopped there.8-3-3 放音 Playing若碟片装好后，就会顺畅的进入放音状态。
When a disc is loaded ，it shall be smoothly set into the regenerative state.8-3-4选曲动作 Tune selective action通过操作选曲按钮，选出指定的曲目，顺畅的进入放音状态。
