科技创新、节能环保1目录一、 产品概述二、 产品型号规格和说明1、 型号说明2、 常规产品的型号规格三、 产品外形与安装尺寸 四、 接线端子排列与定义 五、 产品应用电气连接及接线1、 三相共补接线图2、 混合补偿接线图六、 显示面板定义说明 七、 开机前的检查与试验 八、 操作说明1、 数据查看2、 参数设定科技创新、节能环保2九、 查看数据界面1、 三相共补式数据查看说明2、 单相分补式数据查看说明十、 参数设定界面1、 三相共补式参数设定说明2、 单相分补式参数设定说明十一、 常见故障分析1、 通电后产品数码管暗或无显示2、 PF 值显示负值3、 故障指示灯亮科技创新、节能环保3一、 产品概述DC868系列低压智能电容器是应用于0.4kV 低压电网的新一代无功补偿装置。

它由CPU 测控单元、同步开关、保护装置、两台(△型)或一台(Y 型)低压自愈式电力电容器组成一个独立完整的智能补偿单元，替代由智能无功控制器、熔丝(或微断)、晶闸管复合开关(或接触器)、热继电器、指示灯、低压电力电容器多种分散器件组装而成的自动无功补偿装置。

由DC868系列智能电容器组成的低压无功补偿装置具有补偿方式灵活(共补和分补可任意组合)、补偿效果好、装置体积小、功耗低、价格廉、安装维护方便、使用寿命长、保护功能强、可靠性高等特点，并真正做到过零投切，满足用户对无功补偿要切实达到提高功率因数、改善电压质量、节能降损的实际需求。

科技创新、节能环保4二、 产品型号说明1、 型号说明DC∕450二级容量（kvar ）分相补偿只有一级容量 一级容量(kvar) 额定电压（V ）显示方式：Y-液晶显示 数码显示无字母 补偿方式：S-共补 F-分补 组网方式：R-RS485 L-蓝牙W-无线 产品系列号：868-通用型868X-抗谐波型企业代号：得诚科技创新、节能环保52、常规产品型号规格科技创新、节能环保6三、 产品外形及安装尺寸注：高度尺寸见表1科技创新、节能环保7四、 接线端子排列与定义产品的接线端子分电源端子和测控联机端子，均置于产品的后部，三相补偿电源端子有“UA.UB.UC ”，分相补偿电源端子有：“UA.UB.UC.UN ”，测控联机端子使用插拔件，便于现场调试和调换，产品上有“1.2.3.4.5.6.7.8.9.10.11”，序号标志，其中6—11是标准的6针水晶头接口，两个并接，接线或调换时应充分注意。

3．运行工况界面运行工况里包含了配电电压、电流、功率因数、功率、电压各次谐波、电流各次谐波等各电参数的数值显示，以及测控仪与智能电容器的通信状况，通过“或”键切换界面查看各电参数以及测控仪与智能电容器的通信状况，按“”键返回到主菜单界面。

以下细分界面依次对各项进行介绍：（1）配电三相功率因数、电压、电流界面在使用过程中若出现过补偿或配电电流接线接反，则在上述界面中功率因数数值前显示‘-’，例如A相功率因数显示‘-0.960’，表示此时A相电容已过补偿或A相配电电流方向接反。

在使用过程中若出现过压或欠压现象，在上述界面中电压反显显示，例如A相电压显示“”，表示此时A相电压已超过设定过压值。

（2）有功、无功、电容电流界面P(KW) ：实时的有功功率；Q(Kvar)：系统当前过补偿或欠补偿的无功数值；C-I(A) ：实时的电容器电流值。

（3）通信界面测控仪与不同的智能电容器通讯，其显示的通信界面略有不同，如下图所示：图1 图2图3图1为测控仪与三相式智能电容器或智能抑谐式电容器（双电容电抗）通信界面；图2为测控仪与三相式智能抑谐式电容器（单电容电抗）的通信界面；图3为测控仪与分相式智能电容器的通信界面；“JH C1 C2”中“JH”表示三相式智能电容器的地址，“C1 C2”分别表示内部两组电容器的容量（如图所示“060 20.20”表示此三相式智能电容器地址为“60”，容量为20 Kvar +20Kvar）。

“JH C”中“JH”表示三相式智能抑谐式电容器（单电容电抗）的地址，“C”表示电容器的容量（如图所示“060 40”表示此三相式智能抑谐式电容器（单电容电抗）地址为“60”，容量为40 Kvar）。

“JH A B C”表示分相式智能电容器的地址及A、B、C三相容量（如图所示“06 6.6 6.6 6.6”表示此分相式智能电容器地址为6，电容器容量为20Kvar）。

智能电容器投入后，状态反显显示。

UA UB UCUo快速断路器 总电源接入端、总 开关，电流速切总保护。

智 能 组 件智能组件智能化载体。

配电电压测量和配电功率因数测 量的电压取样，以及过压、欠压、 失压保护取样。

零投切开关电器组件 投、退电 容器开关以及电容器过压、欠压、 失压、过流、断相、三相不平衡、 过温等保护出口。

微型CT 电容器电流测量取样以 及电容器过流、断相、三相不平衡 保护取样。

微型温度传感器 电容器温度测 量与保护取样。

低压电力电容器 容性负载，补 偿配电线路中的感性负载。

液晶显示屏与按键 用。

人机对话之2 4联机接插件 相互之间或与外设 之间联机之用，构成系统工作。

配电CT输入插件 配电电流取样。

TDS 13企业 企业 代号 产品 编号( ).()接线方式 C 安装方式 W 面板形式接线式 插件式 立式安装 卧式安装 一体式 F 分离式第2台电容器额定容量（kvar） 第1台电容器额定容量（kvar） 无抗谐波能力 抗谐波能力 (X) Z Z(Z) 控制方式 Z(L) J 有抗谐波能力 自动控制方式(RS-485通信接口) 自动控制方式(小载波通信模块) 自动控制方式(蓝牙通信模块) 接受控制方式(RS-485通信接口)额定电压（V）J(J) 接受控制方式(接点输出) S 补偿方式 F 三相补偿方式 分相补偿方式BAC0255075100125失效率（%）0255075100125衰减率（%）。

目录一.产品概述 (1)二.功能特点 (1)三.使用环境 (2)四.技术参数 (2)五.安装与接线 (2)六.操作与运行 (5)七.系统调试 (12)八.常见现象分析 (14)九.售后服务 (15)一.产品概述智能无功补偿控制器（以下简称控制器）是本公司在吸收了国内外多个无功自动补偿控制器技术的基础上研发出来的新一代产品，款式新，功能全，安装使用灵活，全中文液晶菜单，操作方便。

控制器具有RS-485通讯接口，与本公司生产的智能低压电力电容器配套使用，接线简洁，运行可靠。

二.功能特点1．参数设置功能1）过压值、欠压值、欠流值等保护定值的设置；2）延时时间、投入、切除门限等投切限值的设置；3）取样电流互感器变比的设置。

2．测量功能1）取样互感器极性自动判别，接入时无需考虑极性要求；2）配电电压、电流、功率因数、有功功率、无功功率测量。

3．控制功能1）自动、手动控制电容器的投切。

自动控制时，根据受控物理量-无功功率进行投切；2）容量相同的电容器按循坏投切方式工作，容量不同的电容器按无功缺额进行编码投切；3）最多可同时控制32台智能低压电力电容器。

4．保护功能配电系统过电压保护、过电压闭锁、欠电压保护、欠流保护、缺相保护。

5．信号功能1）各台电容器投运、退运状态信号显示，各台电容器容量信号显示，各台电容器温度信号显示；2）配电参数越限信号（过压、欠压等）显示；3）控制器本身或电容器故障显示。

三. 使用环境工作温度： -20℃-60℃ 相对湿度： ≤90%（20℃） 大气压力： 79.5-106.5kpa 海拔高度： ≤3000m无易燃易爆的介质存在，无导电尘埃及腐蚀性气体存在。

四. 技术参数额定电压： 交流50Hz ，380V ±20% 电流取样： ≤5A 额定频率： 50Hz ±5% 净重：约0.8kg五. 安装与接线1．安装在屏柜上开113*113mm 的方孔，将本产品从屏前推入方孔内，把配给的紧固件插入安装槽中，上紧即可固定在屏上。

UP-SC380智能电容控制器使用说明书（2014年1月版）恩联（北京）电气设备有限公司Union Power(Beijing) Electrical Equipment Co., Ltd.目录1. 概述 (3)2. 功能特性 (3)2．1 基本功能 (3)2．2 技术参数 (3)3. 外形结构 (5)4．端子接线 (6)4．1 智能电容控制器端子接线图 (6)4．2 端子接线说明 (6)5. 按键及显示 (7)5．1 面板及按键 (7)5．2 实时数据显示 (7)1. 概述智能电容控制器是一种与智能电容器配合使用的电力监控仪，它可以集中显示多组智能电容的投切状态，进行智能电容器投切测试，并且能够与DTU通信实现自动化功能。

该仪表可广泛应用于工矿企业、民用电力系统的配电装置及各类配电室、箱变、低压综合控制柜中，是配电自动化系统的系列产品之一。

本仪表符合《DL/T597-1996低压无功补偿控制器订货技术条件》等标准要求。

2. 功能特性2．1 基本功能智能电容控制器集配电变压器低压侧三相电气参数测量、记录、控制和通信等功能于一体，其主要功能包括：（1）实时显示电容的投切状态；（2）能够实现投切测试；（3）通信功能，上行与DTU通信，下行与智能电容通信；（4）参数集中设置。

2．2 技术参数(1) 工作电源：(85～265)VAC或(100～300)VDC(2) 通信功能：通信口具有RS-485通信方式。

通信规约：MODBUS通信规约。

波特率：（600～38400）bps 可选。

(3) 机械性能：外形尺寸：宽×高×厚:160mm×160mm×113.59mm。

重量：2.1kg。

(4) 运行环境：工作环境温度：-25℃～+75℃；相对运行湿度：20%～90%。

相对湿度<85%时采取特殊措施可运行在-35℃环境内。

耐受污秽等级IV级。

谐波含量〈20%。

海拔2000米及以下。

YBD868数字集成电路测试仪说明书（使用前请详细阅读此说明书）目录第一部分简介一．概述二．整机及配件三．技术指标四．测试范围五．功能综述六．维护保养第二部分操作说明一．自检二．操作说明第三部分可测器件清单第一部分简介一．概述YBD868型数字集成电路测试仪是一种性能较高的通用仪器，测试脚数量最大为双列直插式40脚，可测范围覆盖了大多数的数字集成电路，测试准确可靠，操作简便，基本功能如下：* 器件好坏测试* 器件型号判别* 器件动态老化* 器件代换查询YBD868型数字集成电路测试仪以先进的微处理器为核心，主要器件选用INTEL,MOTOROLA等著名器件公司出产的集成电路，配合软件和外围扩展系统来全面模拟被测器件的综合功能，几乎适合于所有具有固定输出的数字集成电路。

广泛用于维护，检测各类计算机，工业自动化设备，大型医疗仪器，数控机床，微机外围设备，程控交换机，电子仪器仪表，数字通讯设备，电子继电保护装置及各类电子产品。

二．整机及配件1．YBD 868型数字集成电路测试仪一台2．电源线一根3．特殊器件测试板一块4．说明书一本5．保修卡一张三．技术指标1．操作系统：十六位轻触式立体键盘双音提示系统，被测器件安装采用锁紧插座。

2．显示系统：六位数码管显示器显示被测器件型号或各种功能提示，四只LED显示仪器工作状态。

3．电源电压：220V±10%, 50HZ4．整机功耗：12VA5．适用温度：0℃--+40℃6．工作时间：工作1小时停电5分钟。

若连续工作，电源电压∠230V，环境温度∠25℃。

7．仪器结构：台式塑料机箱8．外形尺寸：292*235*75立方厘米9．整机重量：2.0KG四.测试范围YBD868型数字集成电路测试仪库存容量两千多片,包含以下各大系列：1．TTL54系列2．TTL55系列3．TTL74系列4．TTL75系列5．CMOS14系列6．CMOS40系列7．CMOS45系列8．光耦合器系列9．LED显示器系列10．常用RAM系列11．常用单片机系列12．微机外围电路系列五．功能综述1．器件好坏判别：当未知被测器件的好坏时，只要输入该器件的型号，并将器件放于对应的工作插座上，仪器即可判别出该器件的好坏。

1、电容器型号2、基本参数和技术条件主要技术条件见表1：3、安装运行导则：3.1、该电容器应安装在能满足表1中规定的正常环境条件的地方，对户内式产品来说，还要求装设电容器的地方不受阳光的直射、不被雨雪淋湿、无腐蚀性气体、无盐碱、金属粉末及尘埃少、机械震动小，并且通风良好。

3.2、当许多电容妻集中安装在某一部位，或者和其他易发热的设备一起安装在某一部位时，该部位的环境温度将会超过电容器允许工作环境温度的上限，这时，必须充分考虑有效的通风散热措施。

3.3在下列情况下，电容器有能处在过电压状态下运行：（1）电容起的接入可能会引起网路电压的升高，因此电容器容易在比其接入前测得的更高电压下运行。

（2）网路的实际电压可能高于其标准电压。

（3）由于串入电抗器，会引起电容器上的电压升高。

因此，必须在充分考虑了上述因素的前提下，来判定网路的实际电压是否与电容器额定电压相同，确保电容器线路端子上的实际电压不超过表1规定的电压值。

3.4在轻负荷时，由于接入电容器，使功率因素显著超前而容易产生过电压，这时，应将部分和全部电容器从线路中切除。

3.5电容器与感应电动机并接，并且共用一个开关开断时，由于自激现象容易产生过电压，在这种情况下，可按照电容器电流小于电动机空载（建议为90%左右）的原则来选配电容器容量。

3.6在安装电容器前后，必须注意检查测量电压波形和网路特性，如果存在谐波源（如大型整流器），则应考虑采取下列措施来降低有谐波引起的过电流：（1）将部分和全部电容器移到其他系统中去；（2）在电容器上串接适当的电抗器，以将回路的某一高次谐波降至干扰频率下；（3）在大型整流器近旁，增设滤波电容器；（4）如果存在超过规定值的谐波，将大大降低电容器的使用寿命，因此必须采取措施来消除谐波。

3.7在已经接入电容器的情况下，新的电容器投切时会产生很大的过渡过电流（涌流）考虑到电容器和其他设备仪器的容许值，此时应串接限流电抗器或采用带限流元件的接触器，将过渡过电流峰值限制在100In（额定电流有效值）以下。
