机械设计制造及其自动化外文翻译外文文献英文文献普通钻床改造为多轴钻床复习过程

机械设计制造及⾃动化中英⽂对照外⽂翻译⽂献中英⽂对照外⽂翻译⽂献(⽂档含英⽂原⽂和中⽂翻译)使⽤CBN砂轮对螺杆转⼦进⾏精密磨削的⽅法摘要：针对⾼精度加⼯螺杆转⼦，这篇论⽂介绍了利⽤⽴⽅氮化硼（CBN砂轮）对螺杆转⼦进⾏精密磨削的加⼯⽅法。

⾸先，使⽤⼩型电镀CBN砂轮磨削螺杆转⼦。

精确的CBN砂轮轴向轮廓的模型是在齿轮啮合理论的基础上建⽴开发的。

考虑到螺杆转⼦和涂层厚度之间的间隙，主动砂轮的修整引⼊了CBN的砂轮的设计⽅法。

主动砂轮的形状采⽤低速电⽕花线切割技术（低速⾛丝线切割机）进⾏加⼯线CBN主动砂轮的成形车⼑采⽤低速⾛丝机切割机进⾏加⼯。

CBN螺杆转⼦砂轮采⽤本⽂提出的原理进⾏有效性和正确性的验证。

电镀CBN砂轮对螺杆转⼦进⾏加⼯，同时进⾏机械加⼯实验。

在实验中获得的数据达到GB10095-88五级认证。

关键词： CBN砂轮精密磨削螺杆转⼦砂轮外形修整专业术语⽬录：P 螺杆转⼦的参数H 螺杆转⼦的直径Σ砂轮和转⼦的安装⾓度Au 砂轮和转⼦的中⼼距8 螺旋转⼦接触点的旋转⾓x1, y1, z1:转⼦在σ系统中的位置x, y, z: 砂轮端⾯的位置x u ,y u ,z u: x, x y z轴的法向量n x ,ny,nz:X Y Z轴的端⾯法向量n u , nu, nu:砂轮的⾓速度的⽮量:砂轮模块的⾓速度wu:螺旋转⼦的⾓速度w1螺旋转⼦模块的⾓速度转⼦接触点的⾓速度转⼦表⾯接触点的初始速度砂轮表⾯接触点的⾓速度砂轮表⾯接触点的初始速度l砂轮的理论半径砂轮轴的理想位置砂轮表⾯的修改半径砂轮轴的修改位置砂轮表⾯的法向量1.引⾔螺旋转⼦是螺杆压缩机、螺钉、碎纸机以及螺杆泵的关键部分。

转⼦的加⼯精度决定了机械性能。

⼀般来说，铣⼑⽤于加⼯螺旋转⼦。

许多研究者，如肖等⼈[ 1 ]和姚等⼈[ 2 ]，对⽤铣⼑加⼯螺旋转⼦做了⼤量的⼯作。

该⽅法可以提⾼加⼯效率。

然⽽，加⼯精度低和表⾯粗糙度不⾼是其主要缺点。

普通钻床改造为多轴钻床目前，我国中、小型企业的产品质量和生产效率都需要有一个新的提高,但是加工手段却远远不能满足需要,许多中小型企业都结合自己的实际对设备的技术状态进行改进，通过强化自身,以求自我发展普通钻床为单轴机床，但安装上多轴箱就会成为多轴的钻床，改造成多轴钻床后，能大大地缩短加工时间，提高生产效率。

多轴加工应用：据统计，一般在车间中普通机床的平均切削时间很少超过全部工作时间的15%。

其余时间是看图、装卸工件、调换刀具、操作机床、测量以及清除铁屑等等。

使用数控机床虽然能提高85%，但购置费用大。

某些情况下，即使生产率高，但加工相同的零件，其成本不一定比普通机床低。

故必须更多地缩短加工时间。

不同的加工方法有不同的特点，就钻削加工而言，多轴加工是一种通过少量投资来提高生产率的有效措施。

多轴加工优势：虽然不可调式多轴头在自动线中早有应用，但只局限于大批量生产。

即使采用可调式多轴头扩大了使用范围，仍然远不能满足批量小、孔型复杂的要求。

尤其随着工业的发展，大型复杂的多轴加工更是引人注目。

例如原子能发电站中大型冷凝器水冷壁管板有15000个ψ20孔，若以摇臂钻床加工，单单钻孔与锪沉头孔就要842.5小时，另外还要划线工时151.1小时。

但若以数控八轴落地钻床加工，钻锪孔只要171.6小时，划线也简单，只要1.9小时。

因此，利用数控控制的二个坐标轴，使刀具正确地对准加工位置，结合多轴加工不但可以扩大加工范围，而且在提高精度的基础上还能大大地提高工效，迅速地制造出原来不易加工的零件。

有人分析大型高速柴油机30种箱形与杆形零件的2000多个钻孔操作中，有40%可以在自动更换主轴箱机床中用二轴、三轴或四轴多轴头加工，平均可减少20%的加工时间。

1975年法国巴黎机床展览会也反映了多轴加工的使用愈来愈多这一趋势。

多轴加工的设备：多轴加工是在一次进给中同时加工许多孔或同时在许多相同或不同工件上各加工一个孔。

这不仅缩短切削时间，提高精度，减少装夹或定位时间，并且在数控机床中不必计算坐标，减少字块数而简化编程。
