GPS客户端用户手册

一、本调度软件是在车载机硬件安装完工后,在您的计算机上安装的跟车载机硬件相结合使用的软件（GPS/GSM综合GPS系统用户调度软件），打开调度软件输入GPS运营商提供的有效用户名与密码，登陆到监控系统监控调度车辆界面。

如下图：二、1、调度软件第一个菜单“系统”：a) 登陆与注销：打开菜单栏系统菜单下点击“登陆”，输入用户名跟密码进入监控调度软件正常连接状态界面；（如上图）。

点击“注销”，直接注销登陆账号，退出监控调度软件不连接状态而不退出监控调度软件。

b) 修改密码：打开菜单栏系统菜单下的“修改密码”根据提示输入您要改的密码然后点确定，更改您的登陆密码成功。

（如下图）c) 其他功能菜单一般情况下都不用管它，都采用默认状态。

2、调度软件第二个菜单“监控管理”a)更新设备信息：点击可以更新监控调度软件上的所有车辆的修改显示状态。

b)数据下载：是针对前些时段您没有看车辆的行驶状态的，进行数据下载，下载好数据后可以进行回放前些时段您没看的车辆的行驶状态。

数据下载有三种选择方式：一种是全部数据，包括车辆停车、行走等全部状态的数据，第二种是有状态变化，是车辆有状态变化的数据，第二种是有速度，是车辆行走有速度状态的数据。

如下图：c)历史回放：是针对你前些时段没看车辆的行驶状态而进行数据下载后所作的操作功能，数据下载后进行历史回放您车辆前些时段所行驶的路线轨迹。

历史回放有两种选择方式：一种是有速度变化的数据回放，另外一种是全部数据状态的回放，包括车停止、行走等全部数据回放。

如下图d)客户咨询：一般情况用不到，如果您有什么可以直接联系公司售后客服部。

e)里程查询：针对车辆的里程统计查询。

数据下载后可以里程统计查询您车辆所行驶的里程采集点数和里程公里数，并可以数据导出与打印备份。

如下图：f)车辆停车查询：是对车辆停车状态的查询，数据下载后进行车辆停车查询，可以看到您车辆的停车时间、发动时间、停车详细地址的状态，并可以数据导出与打印备份。

GPS Vehicle tracker(GPS+GSM+SMS/GPRS)User Manual(Version 5.0N)This user manual has been specially designed to guide you through the functions and features of your GPS vehicle tracker.1. Accessories:▶Device▶Power cord▶Relay▶Microphone▶SOS alarm cable & button▶User Manual2. SpecificationsDimension 106(L) x 54(W) x 16(H) mm Weight 96gBackup Battery 450mAh / 3.7VOperation Temperature-25℃-60℃Humidity 5% - 95%Standby Time 60hoursGSM Frequencies 850/900/1800/1900 MHz GPRS Class 12GPS Channel 20GPS Sensitivity -159dBmAcquisition Sensitivity -144dBmPosition Accuracy 10mTTFF （Open Sky）Cold Start: ＜38s Warm Start：＜15s Hot Start：＜2sGSM/GPS Antenna Built-in designLED Indicator GSM-green, GPS-blue, Power-redData Transmit TCP, SMSGeo-fence View any existing Geo-fence in the mapSpeeding Alarm Report when speeds higher than the pre-set value. Low Power Alarm Alarm when backup battery is running outNon-movement Detection Movement alarm based on built-in 3D motion sensor Mileage Report Track by time/distance intervalRemote Control Cut off petrol/electricity3. LED IndicationsGPS LED Indicator - BlueFlashing (interval 0.1s) Searching GPS signalSolid blue GPS fixOFF No GPS fix or initializingGSM LED Indicator - GreenQuick flashing (interval 0.1s) GSM initializingSlow flashing (flash 0.1s every 2s) Receive GSM signal normally Solid green Connected to GSM network OFF No GSM signalPower Status - RedFlashing (interval 0.1s) Low batterySlow flashing (interval 0.2s) Full chargeSlow flashing (flash 0.1s every 2s) Normal operatingSolid Red ChargingOFF Low battery/Power offIgnition detection indication: three LED indicators take turns flashing.4. Getting StartedPlease follow below instructions for ensuring safe and correct use.4.1 Install the SIM cardPlace the SIM card into the device with the gold-colored side facing down.Note: Make sure there is enough credit on the SIM card. If you will be using the GPRS function, you should pay attention to the current SIM card GPRS charge.4.2 Install the deviceYou need to choose somewhere that it won't be found, because the whole point of fitting covert GPS vehicle tracker is the secrecy element.Installation please refers to below picture.NOTE:1. Any high power devices such as reversing radar, anti-theft device or communication equipment would affect the signal of the device.2. All metallic cases of the windshield will attenuate the signal on the tracking device. It’s simply due to the shielding effects of the metal compound of the case.4.3 Wiring configurationLine No. Specification Color Instruction1. 2 Keypod Orange / Orange Connect to SOS button3. 4 MIC-,MIC+ Black / Red Connect to Microphone5 TX Green Sending data (TX) / backup6 RX White Receiving data (RX) / backup7 GND Black Ground wire8 MOTOR Yellow Connect to relay control line9 ACC White Connect to ACC ignition10 V- Black(thick) Negative side of 12V/24Vcar storage battery.11 V+ Red(thick)Notes of the relay wiringThe relay wiring of pump: oil connectors of both ends are a fine white line (85) and a fine yellow line (86). The fine white line (85) is connected to vehicle positive power (+12V). The fine yellow line is connected to the device relay control line.Cut off the positive connection line of the pump; then connect in series to the relay N.C. contact (thick green line 87a) and the other end to relay COM contact (thick green line 30).4.4 Device wiring diagramPlease choose the right relay (12V-standard / 24V-optional) for the proper installation. 4.5 Power/ACC/Tele-cutoff(petrol/electricity) control line (4 pin) 1. Your device comes with a power cord and is designed to use only manufacturer-specified original device. The red line is positive while the black one is negative (the side should not be connect with ground wire).2. The ACC line (white) connects to ACC switch of the vehicle. Please be sure to connect the ACC line; otherwise the device will enter ignition detectionstatus when disconnect the ACC line. If you don’t need to anti-theft temporarily, just connect the ACC line to the positive side in parallel.3. Tele-cutoff (petrol/ electricity) control line (yellow) is connected to pin 86 of the Tele-cutoff (petrol/ electricity) relay (equal to the yellow line of the relay socket).4. USB cable (3 pin)Firmware updating interface/expanded function to reserve space.5. MIC line (2 pin)Externally connect to microphone for voice monitoring function.6. SOS line (2 pin)Externally connect to SOS switch for SOS function.5. Quick Operation InstructionsOperation Tips: To properly use the device, common parameters should be set before initial use. This can be done by using the parameter editor or by sending SMS commands to the device. (“,”should be English comma and no space before and after the comma)5.1 APN settingTo connect default platform , please send the SMS command below:APN command format: APN,APN's Name#E.g: APN,internet# (“internet” is the APN of carrier)The device will reply “OK” if setting successfully.Note: The APN of some countries have user name and password, you may need to send SMS command as following:APN,APN name,user name,password#E.g: APN,internet,CLIENTE,AMENA#5.2 DNS settingTo connect other platform, please send the two SMS commands bleow: Command format：SERVER,1,DNS,Port,0#E.g:SERVER, 1,,8841,0#It will reply “OK” after set successfully.5.3 ON /OFF GPRSWhen you want to disable GPRS, you can SMS command to the SIM card number which used in the device.Command format:GPRS ON：GPRSON,1#GPRS OFF：GPRSON,0#It will reply “OK” after set successfully.5.4 Add specific numberSMS command to the device to set the SOS number.SOS,A,No.1,No.2,No.3#“A” means to add new numbers, for example:SOS,A,135****5991,135****5992,135****5993#If there is only one SOS number, you can appoint a specific number as SOS number. And the null means no adding.For example:SOS,A,135****5991#means to set the first number as SOS number SOS,A,,135****5992#means to set the second number as SOS number SOS,A,,,135****5993#means to set the third number as SOS numberIf set successfully, there is a “success” reply SMS.5.5 Delete specific numberBefore deleting specific number, please check its corresponding code. For the code, please SMS “PARAM#” to the device.SMS command to the device to delete the number.SOS,D,serial NO.1,serial NO.2,serial NO.3#“D” means to delete the number, for example:SOS,D,1# means to delete the first numberSOS,D,3# means to delete the third numberIf you want to delete more than one numbers, you can send this command: SOS,D,1,3# means to delete the first and third numbers.If you forget serial number of the mobile number you want delete, you can send this command:SOS,D,mobile number# means to delete the mobile number directly.For example:SOS,D,135****2360#meanstodeletethe135********directly.After deleting the SOS number, it will receive “Delete number 135XXXXXXXX success! specific number total 2” for successful deleting of the specific number.5.6 Set the center numberIf you want to cut off/restore oil by SMS command, you have to set a centernumber firstly. Only the center number can send the cut off/restore oil command to the device. You can set your own mobile number as center number.The command for setting center number is:CENTER,A,mobile number#Forexample:CENTER,A,159****3401#If set successfully, there is an “OK” reply message.NOTE：Only the SOS number can be used to set center number successfully.5.7 Delete the center numberSMS command to the device to delete the center number.The command is:CENTER,D#For example:CENTER,D#If set successfully, there is an “OK” reply SMS.NOTE：Only the SOS number can be used to delete center number successfully.Only SOS phone number can send this command successfully to set the center number. There is only one center number can be set.5.8 Check parameter settingSend command to the terminal, you can check the parameter setting. Command format: PARAM#e.g.: PARAM#
Information replied:IMEI: 353419032348877 ---IMEI number of the device;Timer: 10,10; ---GPS data uploading Interval;SENDS:5; --- the GPS working time when ACC is OFF;SOS:159****3401;---SOSnumbers,maximum3SOSnumberscanbeset and used for alarm and monitoring;CenterNumber:159****3401;---only1centernumbercanbesetandused for cutting off /restoring oil command;Sensorset:10,1,5,180 --- detect 5 vibrations in 10s; the alarm delay is 180s; Defense time: 10; --- the defense delay is 10 minute;TimeZone:E,8,0; --- set time zone; default as E8.The replied information contains IMEI number, GPS data uploading interval, SENDS, SOS, center number, sensor set time interval, defense time and time zone.5.9 Check GPRS parametersSMS command format：GPRSSET#Eg：GPRSSET#Reply message：GPRS:ON //GPRS on/off status// Currently use APN:,,; //APN setting information// Server:1,,8841,0; //platform information// URL:/maps?q=; //preset web link setting information // 5.10 GPS data uploading intervalThe default sending interval is 10,10. It means when ACC ON ,the device will upload positioning data to platform server every 10s.when ACC OFF ,the device will upload positioning data to platform server every 10s.Users can modify sending interval by SMS“TIMER,time1(seconds), time2(seconds)”The time1&time2 ranges from 10-18000sFor example:TIMER,10,20#It means when ACC ON ,the device will upload positioning data to platform server every 10s.when ACC OFF ,the device will upload positioning data to platform server every 20s.5.11 Sensor alarm time settingWhen the vehicle power is off and ACC is in low-level, if ACC is off over 10 minutes, the device will enter sensor alarm state. In this case, if the vehicle vibrates for a few times, it will activate the vibration alarm system. If the vehicle battery is still not on (ACC is in low level) after 3 minutes, the device will start vibration alarm.SMS format: “DEFENSE,TIME(minutes)#” The time ranges from 1 to 60 mins.For example: DEFENSE,15#. It means when ACC is in low level for 15mins, it will enter sensor alarm status (vehicle power is off)NOTE：1. Preset SOS numbers when send SMS alarm messages and calls2. If there is no need for vibration alarm, please SMS SENSOR,0# to close it.5.12 Restore to factory settingSMS command format: “FACTORY#” to set all parameter to default factory value. Once received “OK”, it succeeds.5.13 Reboot deviceWhen there is something wrong with the link of GPRS, e.g., The parameter setting of the device is correct, but you can't track the car on the platform. At this moment you can send a command to the device to reboot the device. The format is: RESET#After receiving this command, the device will reboot after 1mins.6. Operation of device6.1 Power on/ Power offPower on: Once insert a valid SIM card and connect all the wires, turn on the device, then Power LED will flash first, During signal searching process, GSM and GPS LED will flash. Once GPS LED keeps solid light, it means the device has been located and it starts to work.Power off: Just turn off the power switch.The device will begin to upload positioning data to server once inserting a valid SIM card and power on. During the working time, it can upload data to server every 10 seconds.6.2 Check location1. Via SMS1.1 SMS “WHERE#”, to the SIM number of device. The device will send a location message automatically. You can get the coordinates. If the device does not search any information of location, it will send “No data” to the cell phone.Example:Lat:N22.571285,Lon:E113.877115,Course:42.20,Speed:0.0740,DateTime:10-11-23 22:28:511.2 SMS “URL#”, to the SIM number of device. The device will send a location Google Map link. If the device does not search any information of location, it will send “No data” to the cell phone.Example:<Date Time：10-11-23 23:42:51> /maps?q=N22.571490,E113.8771032. Via platformGo to the platform website offered by dealers to check your vehicle location.6.3 SOS alarmIn emergent case, press SOS for 3s to activate SOS alarm. Then the device will send SOS SMS to preset specific numbers and then dial the numbers in circles until the call is picked up. At the meantime, the device will upload SOS alarm data to the server. And it will send:SOS Alarm! <DateTime:11-06-17 14：53：06>，/maps?q=N22576713,E113.916585Note: The specific numbers should be preset, just refer to 6.46.4 Wire cut-off alarmWhen the electricity supply of device is cut off, it will activate cut-off alarm. In this case, the device will send related SMS to the specific numbers and dial the numbers in circles. If nobody answers, the call just keeps 3 loops at most. At the meantime, the device will upload SOS alarm data to the server. And it will send:Cut Power！<Date Time:11-06-17 14：53：06>，/maps?q=N22576713,E113.916585Note: The specific numbers should be preset, just refer to 6.46.5 Low battery alarmWhen the device is only working with battery, once the internal voltage of battery is less than 3.7V, device will send low battery alarm sms to specific number and alarm on platform.Low battery alarm sms content example: “Attentionbattery too low, please charge.” Which means the battery is to low, to inform user charging it i n time. Note: The specific numbers should be preset, just refer to 6.46.6 Vibration alarmThe vibration alarm function is off by default. To activate this function, please send the following command: SENALM, ON#. The alarm will be sent to both the service platform and SOS numbers.When vehicle power is off, ACC status is low, and if the lead time of low ACC is more than 10 minutes （settable）, device will activate security alarm. When the security alarm is on, once the vehicle vibrates for several times, the alarm will be activated; in the next 3 minutes, if vehicle power is still off（ACC status is low）, device will start alarm. At this time, it will send alarm message to the service platform with the latitude and longitude, while the platform will reply the Chinese address. Then the terminal will send vibration alarm message to SOS numbers with the Chinese address, and call the SOS numbers in cycle. If nobody answers, it will stop calling after 3 loops.If the Chinese address can not be acquired for certain reason, the terminal will send a message with the website link to the SOS numbers.e.g.:Sensor Alarm！<11-23 14:53>,/maps?q=N22576713,E113.916585Note:1.The SOS numbers should be preset.2.Send “SEN ALM, OFF#” to turn off the vibration alarm.6.7 Voice monitoringWhen the special number cell phone dial device, ringing for 10 seconds, it will enter voice monitoring status. At this time, caller can monitoring the sound in vehicle. Incoming call from non special number will not activate voice monitoring function.Note:To realize this function, please set special number beforehand.The SIM card put into the device should be equipped with caller identification.6.8 Oil cut-off1. Via platformSend oil cut-off command on platform. To make sure the security of vehicle, tracker can only indicate to cut off oil when GPS is in valid position status, and the speed is less than 20KM/H or in static. Platform account password is needed when sending oil cut off command.2. Via SMSFirstly, you should set a center number. Please refer to 6.6.Only center number can send the command to the device to cut off and restore oil.The format is: RELAY,1#After the command is carried out, it will reply “Cut off the fuel supply: Success! Speed:0 Km/h”. If the command didn't carry out, it will reply the reason about fail to carry out.Note: To ensure the safety of the driver and the car, this command is valid only under two conditions: the GPS is located; the speed is less than 20km/h 6.9 Restoring Oil1. Via platformWhen the alarm is off, sending recover oil commands manually. Device will restore oil supplying, and vehicle will work normally again.Platform account password is needed when sending oil cut off command.2. Via SMSOnly center number can send the command to the device to restore oil.The format is: RELAY,0#After the command is carried out, it will receive “Restore fuel supply:Success!”6.10 Over speed AlarmWhen the car is moving over a limited speed in average in a limited time period, then the device will send over speed alarm SMS to user.To turn on the over speed function, please send below SMS command: SPEED,ON/OFF,Time,Limited speed,uploading mode#Speed alarm switch:ON/OFF default:OFFTime range (seconds):5-600s(default as 20s)Limited speed range(km/h):1-255km/h. default:100Mode:0/1. default:1 way of alarming,0 means GPRS only,1 meansSMS+GPRSExample:SPEED,ON,20,100,1#Means when the car is moving over 100km/h in average in 20 seconds,the device will send over speed alarm to user7．Web based tracking online activationThe GPRS web based tracking platform allows real time tracking with the latest Google maps. There is also a playback feature that allows you to view where the vehicle has been for up to 30 days in the past making it ideal for fleet management.8．Trouble shootingIf you are having trouble with your device, try these troubleshooting procedures before contacting a service professional.Problems Causes SolutionsFail to connect platform The fuse blows Replace the fuse ACC ignition disconnected Turn on ACC with keyFail to connect network Wrong installation of SIMcardCheck SIM card installation(Refer to 4.1 Install SIM card) Filth on the SIM card ironsurface.Clean itUseless SIM Contact internet serviceproviderImproper installation Check installation of device(Refer to 4.2 Install the device) Beyond GSM service area Use it in effective GSM serviceoffer areaBad signal Try again in a better signalareaFail to charge The voltage is unsuitable Connect with power withsuitable voltage Improper connection Check connection withcharger1. The warranty is valid only when the warranty card is properly completed, and upon presentation of the proof of purchase consisting of original invoice indicating the date of purchase, model and serial No.of the product. Wereserve the right to refuse warranty if this information has been removed or changed after the original purchase of the product from the dealer.2. Our obligations are limited to repair of the defect or replacement the defective part or at its discretion replacement of the product itself.3. Warranty repairs must be carried out by our Authorized Service Centre. Warranty cover will be void, even if a repair has been attempted by any unauthorized service centre.4. Repair or replacement under the terms of this warranty does not provide right to extension or renewal of the warranty period.5. The warranty is not applicable to cases other than defects in material, design and workmanship.Maintenance RecordShenZhen Concox Information Technology CO.,LtdTel: +86 755 2912 1200Fax: +86 755 2912 1290E-mail:**************.Add: 4/F, Building B, Gaoxinqi Industrial Park,Liuxian 1st Road, No.67 Bao'an District, Shenzhen DateServiced by Product ModelIMEI NumberFaultDescriptionsCommentsWarranty instructions and service。

1、第一步：打来手簿，开启管理软件点击配置选项→手簿端口配置→配置搜索→搜索到蓝牙****（移动站PIN号）→绑定→退出→确定。

2、基准站、移动站信号灯及按键的名称和作用
红色按键（开关机键）红色指示灯（电源指示灯）蓝色指示灯（卫星接收指示灯）绿色指示灯（接收基准站信号指示灯，1S/1次）黄色指示灯（数据指示灯）
3.、启动→点击测量（点击图标）→启动移动站接收器
4.、文件→新建任务→输入任务名称
5.、配置→坐标系管理→点管理器→查看中央子午线（每个地方不一样）和投影高（一般是甲方提供或默认为0）。

6.、成果桩导入手簿方法：用xls表格制作好原始坐标数据更改为（X、Y、Z）格式，保存时选择CSV格式，保存好后重命名后缀调为dat格式。

拷贝dat文件到手簿。

将手簿和计算机连接，找到移动设备，将dat文件拷贝到Built—in→RTKCE文件包内。

拷贝完后再手簿上操作将文件导入。

点击文件→导入→当地点（类型选择为call files）确定。

完成后导入成功。

7.当基准站关机后再开启时，要进行点的校对。

在控制点处点击手簿（测量→测量点→确定），（点击文件→元素管理器→点管理→选择测量点→点击详细→替换测量点位控制点）完成后对当前控制点进行点放样）。

1.开机进入待机画面！
2.进入功能菜单
3.打开如图所示小蜜蜂搜星软件（在内存卡的“3D导航文件夹的第一个就是”）
点开始搜GPS端口！
点OK确认，开始搜星！（在开阔的地方搜星哦，一般在家里是搜不到的哈）3个以上卫星的时候，把小蜜蜂退到后台，再打开凯立德。

搜到星后，上面的格数会显示变为蓝色，说明已定到位，此时可以打开内置在T卡里的凯里德地图！会自动定位当前所处位置！
以下为打开地图的步骤：
打开资源管理器！
打开如图所示T卡文件夹
打开“NA VIONE”地图文件，大屏幕的是点击loader
点“接受”，地图打开！
此处也可显示GPS星数！。

GPS监控软件 V3.0使用说明书北京兴远达科技有限公司地址：北京市丰台区科学城海鹰路5号赛欧科技孵化广场电话:(010)83682421一、软件介绍 (2)二、安装说明 (2)三、软件使用说明 (7)1、主界面 (9)2、google地图 (11)3、电子地图 (13)4、历史记录窗口 (15)5、照片下载窗口 (16)6、下发指令 (17)7、速度曲线 (19)8、报表下载 (20)9、手动报警查询 (21)10、超速报警查询 (22)11、疲劳驾驶查询 (23)12、修改密码 (23)14、显示关于信息 (25)四、网页版使用说明 (26)4、1修改密码 (27)4、2客户管理 (28)4、3管理工具 (32)4、4回收站 (36)一、软件介绍客户端软件采用CS（客户端/服务器）的方式，利用.Net平台开发，其中地图引擎采用MapInfo公司的MapXteme2004产品，该软件从应用服务器通过XML方式获取数据，在客户的电脑上通过地图、报表、曲线等多种方式显示出来。

目前该软件提供了车辆当前位置、车辆历史轨迹、温度曲线、速度曲线、车辆里程报表、车辆工作时间报表、车辆里程汇总表等，并可将数据或者报表导出到Excel、Word、PDF、图片、RPT等类型的文件中，供客户再进行进一步的分析或应用于其他信息系统中。

二、安装说明安装前请确保关闭所有应用程序，第一次安装过程中需要重启计算机，双击安装文件中如图2-1的setup.exe开始安装。

如果系统中没有安装Microsoft .NET framework SDKV1.1，将提示安装Microsoft .NET Framework SDK v1.1，点击同意，安装该语言包。

提示重启机器，重启机器后弹出如图2-2的提示，操作成功完成，点击“确定”（如果已存在Microsoft .NET Framework SDK v1.1，将跳过以上过程）。

安装界面进入如图2-3所示，填入用户和单位，在图2-4所示界面中选择安装模式，进入如图2-5所示的安装准备。

GPS 系统使用说明书Gps手机定位系统客户端软件说明一、启动程序点击GPS手机定位程序启动。

二、用户登录直接输入用户名、密码，点击确定。

您便成功登陆至GPS手机定位系统客户端软件。

三、界面介绍在地图窗口点右键，出现清除鼠标状态、放大当前地图、缩小当前地图、漫游当前地图、地图区域设置、刷新地图屏幕、，目标线路导航、目标实时跟踪、清除实时跟踪功能。

四、工具栏介绍1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 261、窗口管理：您可以在地图显示窗口中增加地图窗口。

点击增加窗口管理按钮后，地图显示窗口中就会出现一个新的监控窗口，最多可显示四个窗口。

2、删除窗口管理：您可以在地图显示窗口中删除地图窗口。

点击删除窗口管理按钮后，就可以删除一个监控窗口，至少会有一个窗口留下。

3、还原鼠标状态：将状态转换为可操作的鼠标状态。

4、放大地图：放大地图的比例。

5、缩小地图：缩小地图的比例。

6、地图漫游：平移地图。

7、测量距离：选择此键在界面的左下角显示您测的两点距离。

8、拷贝地图：可以将当前地图窗口显示的地图（按照您的要求填写对话框）拷贝转为地图文件。

9、地图还原：将现在所显示的地图画面转为初始状态下的地图窗口。

10、查看指定范围目标：选择此键在界面中会弹出所选范围的终端列表框。

11、设定圆形报警区域：选择此键后可在地图中设定您所需要的圆形报警范围。

12、设定特定报警区域：选择此键后可在地图中设定您所需要的任意形状报警范围。

（点击鼠标右键确认设置）13、目标导航：选择此键后可在地图中绘制您需要的路线，之后找到您要发送导航信息的ID号，点击鼠标右键发送此信息。

如要取消导航信息则点击键盘中的“DEL”键。

14、离线终端列表：显示超过规定时间GPS点位没有更新的终端。

15、选取图元：只可选取自定义的图元（及信息符号），不能选原图中的图元。

GPS实时监控系统（绿色版）操 作 说 明目录1.1 登陆界面 (3)2.1 监控界面 (3)2.1.1 菜单栏 (4)2.1.2工具栏 (4)2.1.3 设备列表 (5)2.1.4 设备查找 (7)2.1.5 设备状态 (8)2.1.6 报警信息 (8)2.1.7 地图定位信息 (8)3.1 报表输出 (8)4.1 系统设置 (11)5.1 常问问题回答 (12)此GPS监控平台无需安装数据库软件就可以使用，具有文件小、转移方便和使用简单等特点。

软件解压方法有两种：1.双击软件图标，按提示自动安装到指定目录下，并在桌面创建快捷方式。

2.单击软件图标，右键－解压到当前文件夹。

请运行GpsClient_new.exe 打开登入窗口。

1.1 登陆界面输入监控帐号和密码及服务器IP地址，服务器IP默认是我们服务器IP：211.162.76.154。

监控帐号和密码需向设备提供商索取。

2.1 监控界面运行GPS实时监控系统，系统地图可以设置为Google地图或者51灵图。

用户可在菜单栏的“地图管理”—“地图选择”，切换监控地图。

运行后的GPS实时监控系统用户界面如上图所示，主要包括菜单栏、工具栏、设备列表、设备查找、设备状态、报警信息和地图定位信息等。

2.1.1 菜单栏GPS实时监控系统菜单栏的菜单命令包括了基本的操作命令，用户可直接通过鼠标单击或快捷键，选择要执行的命令。

除了可在菜单栏中选择菜单命令外，还可通过在设备列表选择设备，使用鼠标右键单击历史回放或控制，弹出相应的控制列表，列表列出了在当前监控状态下相关的GPS监控、轨迹回放等可执行功能。

2.1.2工具栏GPS实时监控系统提供直接按钮有：历史回放、报表和系统配置，即时定位，客户端连接，下载端口连接。

用户可直接用鼠标左键单击工具栏上的按钮来执行命令。

2.1.3 设备列表设备列表罗列出该账户下的所有GPS车辆基本信息，车辆不在线：显示灰色；车辆在线，如果停止：显示蓝色，运动：显示绿色。

Traveling To Your DestinationSave Current LocationThis option tells the system to store the current location for later use. It does not change or cancel the route instructions you are using at the time to reach a destination.For example, you are following the system's directions to get to a destination. You are sitting at a stoplight and notice a curio shop on the corner. You do not have time to visit it right now, but you would like to in the future. This option saves the location of the intersection so you can select it as a destination at a later date.To save the location (while thevehicle is stopped), touch the vehicle position icon. When the current address is displayed, touch "Save Current Location." After the location is saved, select "Return" to return to the Map screen.The current location is saved in the previous destination list. Use the Previous Destination option in the Main Menu to select it. It will appear in the list as "Save" followed by the location.Navigation SystemTraveling To Your DestinationGPS Signal Strength Green — Strong Yellow — WeakNot shown — No signalNorth Pointer(In 1/20, 1/8, and 1/2 mile map scales, touch tochange map orientation)Time to DestinationMap Scale Adjustment (Appears only when you press Zoom In/Out buttons)Map Scale(Miles per half inch)Blue line — Calculated route White — HospitalYellow — Shopping Mall Orange — University Dark Green — ParkMedium Green — Golf CourseGray — Airport/Stadium/Business Light Blue — Body of WaterCurrent LocationCurrent RoadNavigation SystemMap ScreenDirection to DestinationDistance toDestinationTraveling To Your DestinationLandmark IconsLandmark icons will be shown in the screen if you select the "Show Icon on Map" in the "Set-up Screen". See "System Setup" on page 60.Going Off the RouteIf you leave the calculated route,"Off-route" (manual) or"Recalculating" (automatic) is displayed at the top of the screen.The system will recalculate the route from your current location anddirection to the desired destination;then give you a new route instruction.This recalculation is doneautomatically unless you set it to manual in the Setup Menu. See "System Setup" on page 60.Auto RecalculationIf this option is set to "Automatic"you will see. "Recalculating" flash at the top of the screen for several seconds as the system recalculates the route. This is followed by a new route instruction.Manual RecalculationIf this option is set to "Manual", you will hear a tone when the "Off-route"message is displayed. You mustpress the Joystick or "ReCal" icon in the screen before the system will recalculate your route.Navigation SystemTraveling To Your DestinationModifying the RouteSeveral functions in the system allow you to view the route the system has calculated. You can then have the system recalculate portions of the route. This is helpful if you are aware of road conditions along the calculated route that you wish to avoid.With the map screen displayed, you can push the MAP/GUIDE button at any time to display the guidance screen. With the guidance screen displayed, move the Joystick left or right to see the Direction List. This shows you all the route instructions between your current location and your destination.Instructions that have already been executed cannot be displayed.Push the joystick down to see the upcoming route instructions one at a time. Each push displays the next in-struction in the sequence. Push the joystick up to move backwardthrough the sequence to the current instruction. The display returns to the current route instruction in about 10 seconds if you stop pushing on the joystick.Navigation SystemTraveling To Your DestinationPressing the MENU button with either the map screen or theguidance screen displayed changes the display to:This menu lets you cancel or modify the current calculated route.DetourSelect this option if you encounter an unexpected obstacle, such as a closed road or extremely heavy traffic congestion. The system will calculate a route from your current location that detours you off the original route, and then back onto it after a certain distance.Avoid a StreetThis option lets you delete a street or streets from the current calculated route. This is helpful if you know of road construction or other snags on the prescribed route.Plan New TripSelecting this option cancels the current route and destination. The display returns to the "Main Menu".Back to Current RouteSelecting this option returns you to the original guidance screen.Navigation System。

GPS 導航系統使用者手冊特別提示圖1重要訊息:.除非車輛在完全靜止狀態下,駕駛中請勿操作本系統!.請保持視線在行車前方,不小心駕駛會造成嚴重的意外及傷害!.地圖信息無法保證準確,請務必遵守實際的道路狀況與交通規則駕駛。

.導引規則可能會與實際的路況不符,請勿理會任何造成危險的建議。

使用者開始使用本裝置時, 首先會出現一個訊息畫面, 如圖1,目的在提醒駕駛人, GPS導航系統為幫助駕駛人的輔助工具, 而不是控制駕駛人的駕駛工具, 在發生導航裝置與實際路況不符合時, 請以實際路況進行駕駛, 使用時請勿發生違法和不安全的行為。

目錄特別提示------------------------------------------------------------------------------------------------1 目錄------------------------------------------------------------------------------------------------------2 開始GPS導航系統----------------------------------------------------------------------------------3 範例1----------------------------------------------------------------------------------------------------5 範例2---------------------------------------------------------------------------------------------------11 擴音功能----------------------------------------------------------------------------------------------17 快速轉輪----------------------------------------------------------------------------------------------17 功能表介紹-------------------------------------------------------------------------------------------18 旋轉螢幕----------------------------------------------------------------------------------------------18 注音輸入法介紹------------------------------------------------------------------------------------18 歷史記錄---------------------------------------------------------------------------------------------18 我的地標---------------------------------------------------------------------------------------------19 定位簡訊---------------------------------------------------------------------------------------------19 設定---------------------------------------------------------------------------------------------------22圖2在點選”我已閱讀並同意”後, GPS導航系統就會開始讀取GPS衛星訊息, 經一小段時間計算後(計算時間依衛星訊號接收強弱不同而有所差異), 將使用者目前的位置以來放大地圖比例, 或是點選圖4註: 使用者可以點選後便會進入主選單畫面, 如圖5, 在此畫面中, 使用者可以利用導航程式提供的7種方式來查詢地點, 在本系統中, 地點的記錄分為兩類, 一種為系統資料庫提供的地點(目的地檢索), 另外一種為使用者輸入使用(我的地標及導航簡訊), 使用者可以使用7種方法進行位置搜尋及定位, 下面就示範如何以目前所在位置利用GPS導航系統進行目的地定位及導航。

GPS软件操作说明书一：运行ＧＰＳ软件，双击桌面上的快捷方式图标，然后软件运行后出现二：输入中心注册码和登录密码后:点击确定后,出现下面就GPS软件各个菜单使用说明一下:一：系统管理，系统管理里有六项：1．连接网络：主要是将系统与网络连接起来。

2．断开网络：将网络与系统断开。

3．保存图像：鼠标左键点击保存图像之后，就会出现下图：就是把当前地图截取以BitMap(*.bmp)格式保存在电脑里，例如我把当前的地图截取保存在E:\ 地图截取然后再输入文件名，选择保存就可以了，如下图：下面的图就是刚才截取的2：打印地图，就是把当前地图界面截取，然后以图片形式打印出来，如下图然后选择打印就可以把当前地图打印出来了。

3：注销登录，此功能可以用来切换操作员，以达到优化软件系统选择确定后，出现下面的界面然后再输其它的操作用户和登录密码重新登录，以达到切换操作员和优化软件系统的目的。

4：退出系统，可以关闭软件，以达到退出程序。

选择确定就可以退出系统了二：参数设置参数设置里有八项，如下：１：注册入网资料选择注册入网资料后，出现下面的界面选择新增后出现下面的界面：接下来按照客户入网资料登记相关信息：设备ＩＤ总供是6位，每台GPS终端的ＩＤ号不一样的。

选择用户安所装GPS设备的型号。

按客户入网登记录如实填写，为客户的车牌号码车载电话，就是车载机里装的中国移动ＳＩＭ卡的号码点击保存时，显示输入防伪密码（防伪密码在主机ID号下方可见）车辆组别是为了管理车辆而划分的组别，默认是“无分组”。

选择后，出现下图：点击新增出现在车辆组别信息中名称：是输入该辆汽车是哪个公司的负责人：输入该公司负责人姓名联系地址：输入该组别公司的联系详细地址联系电话：输入该组别公司的联系电话。

例如：点击保存后,出现该组别可以对你所选中车辆组别名称的内容进行修改然后再选择保存，就可以保存你所修改的内容。

可以取消对增加资料和修改资料的选择。

可以删除不用的组别名称。

User Manual（Version 2.1）1.AccessoriesThis user manual has been specially designed to guide you throughCharging cable (Standard)2.Specification3. Quick Operation InstructionsChange APN parameter by sending SMS “APN,666666,APN name#” and “SERVER,666666,1,,8821,0# ”to the device.3.1 Locate current position by GPRS/SMS3.2 GPS tracking platform:3.3 Track by time interval via GPRSSend SMS “TIMER,666666,,time(second)#” to device. 10s in minimum while 18000s(5 hours) in maximum.3.4 Change passwordThe default password is 666666. Send SMS “PASSWORD,old password (6 numbers),new password (6 numbers)#” to the device.3.5 Real-time Location Tracking via SMS3.5.1 Send SMS “WHERE,666666#” to the device, you will get the current location of the device.3.5.2 Send SMS “URL,666666#” to the device, you will get the URL of the current location by .4.My Device5. LED Indications6.Method of installation6.1 Preparation before installation1)Open the packing box to check whether the type of device is correct and whether the accessories are included.2)This product is a high-tech electronic device, installation should be undertaken by a professional.3)Please follow the following procedures to install your GT02A.During installation, there should be no power to the device.6.2 Installing SIM card: each GT02A need to insert a GSM SIM card. The SIM card used should be enabled for GPRS.1)Testing SIM card: to test SIM card, please install it into a normalGSM mobile and ensure it can send and receive SMS, and enables for GPRS.2)Installing SIM card:Remove the upper cover of device,insert SIM cardas shown then replace cover,lock the Shell With 3 bolts.6.3 Selecting installation place and fixing it.There are twokinds of installation: covert and non covert.If you need the covert installation, please refer installation to an auto electrical contractor.Note:1)To prevent theft of the GT02A,the device should be installed ascovertly as possible.2)Avoid placing the GT02A close to higher power electrical devices,such as reversing radar, anti-theft device or other vehiclecommunication equipment.3)The GT02A should be fixed into position with cable ties or widedouble-side tape.4)Your device has built-in GSM antenna and GPS antenna. During installation, please make sure the receiving side face is up, with no metal object above the device to interfere with GPS reception. The following places are suggested for installation:- Under the dash board below the front windshield;- In the parcel shelf in the rear;- In the front bumper( non-material face), please ensure the device cannot get wet;- Under the wiper version (non-metal), please ensure the device cannot get wet;Notice: If the windshield is pasted with metal thermal-protective coating, it may affect the performance of the device. In this case, please change the installation place after consulting the professional.5)Non Covert Installation,Firstly fix the device on the dash board below windshield.7. Cautions of device wiring7.1 The standard voltage is 9V-36V, the red wire is the positive, the black wire is the negative.7.2 Please connect the black wire to ground.7.3 After connecting the power cord, run the power cord plug to the device. After installation, supply power to device.7.4 Covert installation: car battery cord is standard, with 2A FUSE for short-circuit over current protection.7.5 Non covert installation: cigar lighter cord is optional, with 2A FUSE for short-circuit over current protection. Please contact your dealer if this mode is needed.8. Power on/ off8.1 The device will power on automatically when connected to power. During normal operation, red power LED flashes, while blue GPS LED and green GSM LED keep lighting. During signal searching process, GPS or GSM LED will flash. If there is no light presenting on LEDs, the device is not working normally.installation, please make sure the receiving side face is up, with no metal object above the device to interfere with GPS reception. The following places are suggested for installation:8.2 The device will power off after power is disconnected.9. Side key functionAt normal-work indication status, press the side key, all the three LEDs will extinguish and then the device will enter covert working mode. Press the key again, the three LEDs will go back to normal-work indication status.10. Troubleshooting10.1 If GPS can not receive the signals normally, please drive to the open areas for positioning. Generally, it needs 1-2 minutes to receive the first coordinates. If the data can not be received after 2-3 minutes, pleasecheck the installation position of the device, making sure it is not being shielded by any metal.10.2 If GSM can not receive the signals normally, please check whether SIM card is installed correctly or there is no GSM signal at the current location , such as a basement parking, please drive to a place covered by GSM signal.10.3 If the red LED does not work when power is connected, check whether the fuse is blown. If so, please replace the fuse.10.4 If the three LEDs do not turn on when power up, press the down side key, if the three LEDs recover normally, the device is working normally.10.5 If you have enabled the web based tracking application, and the device displays off-line on the platform, please check 3 LEDs status indicators first. You can check the status of the SIM card when you are in an inconvenient situation. Please refer to the following steps:1)Call the device to check whether you can get through.2)Check whether the SIM card supports GPRS and a local APN.3)Check the GSM/GPS reception area.4)Check whether there is enough credit on the SIM card.5)Check if the connector and terminal is loose or the fuse has blown out.11.SMS command。

SURVEY PRO For Windows R CEGPS用户手册美国TDS 公司（版权所有，侵权必究）目录第一章序言-------------------------------------------------------------3 第二章GPS坐标---------------------------------------------------------42.1．基准2.1.1水平基准2.2.2垂直基准2.2．坐标系统2.2.1水平坐标系统2.2.2垂直坐标系统2.2.3 Survey Pro 坐标系统数据库第三章GPS测量---------------------------------------------------------93.1．伪距法定位3.1.1差分GPS3.2．用survey pro做差分GPS第四章RTK数据采集--------------------------------------------------114.1．设置投影模式4.1.1投影模式概述4.1.2地图投影设置4.1.3选择大地水准面模型4.2．接收机设置4.2.1一般的硬件设置4.2.2基准站接收机设置4.2.3动态接收机设置4.3．解算水平投影4.3.1定位4.3.2地图投影4.4．解算垂直投影4.4.1定位4.4.2模拟大地水准面4.4.3椭球高4.5．RTK数据采集4.5.1测量模式4.5.2数据采集方法4.6．RTK放样第五章投影的利用------------------------------------------------255.1．投影计算器5.1.1计算器比例系数5.1.2收敛计算器5.2．重新平差点5.2.1大地到平面5.2.2平面到大地第六章用TDS 管理GPS坐标---------------------------------286.1．Survey Pro6.1.1人工模式6.1.2编辑点6.1.3输入一个.GPS文件6.2．Survey Link6.2.1文件输入6.2.2文件输出第七章数据采集后处理-----------------------------------------317.1．野外过程7.1.1开始后处理7.1.2接收机开始记录7.1.3数据采集7.2．内业工作第八章例程--------------------------------------------------------348.1．用控制点定位8.2．重复定位测量8.3．定位计算器和大地水准面模拟8.4．用GPS和常规的投影面测量疑难解答参考资料第一章序言本书分为两个部分：第一部分是用户手册，第二部分是参考手册。

GPS车辆监控管理系统使用说明深圳市三连星实业有限公司二零一零年目录GPS车辆监控管理系统 0一、简介 (2)二、客户端安装 (2)1.三连星GPS车辆监控系统.......................................................... 错误！未定义书签。

2.安装环境软件MAP5.0................................................................ 错误！未定义书签。

3.安装GPS监控客户端软件： (2)4.安装过程中要注意的问题 (3)三、车辆智能管理系统主界面： (4)四、查询车辆位置（定位） (4)五、地图放大缩小 (5)六、车辆追踪 (5)七、越界区域报警设置 (6)八、不规则区域设置 (7)九、里程统计 (8)十、历史回放 (8)十一、超速报警设置 (9)十二、按经纬度定位 (9)十三、报警处理 (9)一、简介GPS车辆智能管理系统是集现代车辆实时监控、智能管理、调度、防盗反劫为一体的系统，系统主要由控制台、地图、实时监控、车辆调度、警情处理、参数设置、报表查询、系统管理、窗口、帮助模块组成。

客户有绿色版本，不需要安装，直接使用。

更方便用户。

二、客户端安装1.安装GPS监控客户端软件：1)打开监控客户端文件夹，双击进行安装。

2)在桌面上找到图标进行双击看到如下界面：3)参数设置，在登陆GPS车辆监控系统之前，要进行参数设置，点击参数设置按钮，可以看到如下界面：通讯IP：通讯IP是指连接中心服务器的IP地址（默认为：119.145.5.86）。

数据库IP：数据库IP是指连接中心数据库服务器的IP地址（默认为：119.145.5.86）。

通讯端口：通讯端口是指连接中心服务器的端口号（默认为：8881）数据库端口：数据库端口是指连接中心数据库服务器的端口号（默认为：8890）地图路径：地图路径是指你电脑里的地图文件的存放路径，一般为D:\查询地图\位置查询地图.gst。

GPS-G5 User’s ManualContentsUsing the GPS (1)Description (1)Electrical Connections (2)Mounting (3)GPS Configuration (3)GPS Operation (3)Logging Device Configuration (4)Data Analysis (5)Specifications (6)Copyright 2008 – MoTeC Pty LtdThe information in this document is subject to change without notice.While every effort is taken to ensure correctness, no responsibility will be taken for the consequences of anyinaccuracies or omissions in this manual.17 Oct 2008Mo T eC Using the GPS 1 Using the GPSDescriptionThe GPS-G5 is a 5Hz GPS that is suitable for the high dynamics of motor sport applications and is compatible with MoTeC ADL3, ADL2, SDL & ACL logging devices. The G5 low supply current makes it suitable for use with all MoTeC 5V sensor supplies.The G5 consists of a GPS unit with a built in antenna.Global Positioning System (GPS) units provide speed and position information, as well as altitude, heading, date, time and GPS statistics.Speed The speed information can be used for display and logging purposes, eliminating the need for wheel speed sensors. This is particularly useful in boat and drag racing applications. These applications usually encounter difficulties in obtaining true speed measurements.Position GPS position information can be used in MoTeC i2 data analysis software to show and compare the driven lines and to create track maps. The driven lines can also be plotted over a Google Earth image, allowing circuit racers and off-road drivers to see the path travelled in a real life context.Lap timingIn circuit racing, a GPS unit can be a cost effective alternative to the traditional lap timing system. The position of the start/finish line can be marked either by a push button operated by the driver when passing the line or by entering the coordinates directly into the data acquisition system. This position can then be used by the logger or display as a beacon to calculate the lap time and by the data analysis software to indicate the start of each lap.2 Using the GPSElectrical ConnectionsThe G5 unit sends data (Standard NMEA RMC GGA) to the MoTeC logging device via an RS232 serial connection.The following tables show the pin-out of the two available G5 connectors andhow to wire them to MoTeC logging devices.DTM06-4PGPS Pin GPS Name Logging Device Name ADL3 ADL2 SDLACL1 Bat - Bat - 7 4 Bat- from VIM2 TX RX 79 34 153 RX Not Used 45V5V18 etc145V from VIMASL606-PNGPS Pin GPS Name Logging Device Name ADL3 ADL2 SDLACL1 Bat - Bat - 7 4 Bat- from VIM2 TX RX 79 34 153 RX Not Used4 5V 5V 18 etc 14 5V from VIM 5N/CN/CN/CN/CN/CNote: The ADL3, ADL2 and SDL logging devices only have one serial connection. MoTeC Serial To CAN (STC) can be used to add a G5 to the system via CAN bus in event that the serial port is already in use.Mo T eC Using the GPS 3 MountingThe G5 has an integrated antenna and should be mounted on an external horizontal surface that has a clear view of the sky.The G5 should be mounted away from sources of interference. Voice radios, data telemetry and TV broadcasting antennas are forms of interference.If mounting on a non-metallic surface it may be necessary to add a metallic ground plane under the unit to improve the signal level. The ground plane should be at least 150mm (6in) square and may be made of aluminium or steel.The unit has a magnetic mounting base and includes an M3 thread in the center.GPS ConfigurationThe G5 comes pre-configured from MoTeC USA to suit MoTeC logging devices. G5s operating outside of North America need additional programming.GPS OperationIn normal use the G5 unit should start operating within 1 to 45 seconds of power up, however during first start-up or if the G5 has been moved to a new location it may take up to 45 seconds before it gains satellite lock and starts transmitting data.To check that the G5 is operating correctly check the number of satellites being received using the device “Manager” software.The G5 requires at least 4 satellites to function however normally the G5 should see at least 7 satellites, more satellites improves accuracy and minimises satellite drop out.Loss of signal may occur when trees, buildings or a bridge obscures the satellites. The G5 will take a second or two to recover from this situation.4 Using the GPSLogging Device ConfigurationSoftware VersionThe logging device must be running the following software version (or higher) SDL Version 1.3 or higherADL2 Version 4.4 or higherADL3 Version 5.0 or higherACL Version 1.1 or higherSet up RequirementsCommunications Set Up:Select Inputs | Communications Set Up | RS232 | Select the "GPS -Standard RMC GGA" template. Change the baud rate to 19200 Logging Set Up:Select Functions | Logging Set Up and the following GPS Latitude, GPS Longitude, GPS Speed must be logged. The other GPS channels areoptional.The Logging Rate for all GPS channels should be set to 20Hz (eventhough the GPS is 5Hz)Optional GPS Beacon Set UpBeacon Set Up:Select Calculations | Lap Time and Number Set Up | Beacon Tab |Beacon Type set to GPS.Set the Detection radius. The default 16’ (5m) radius is sufficient butcan be changed if needed.Set GPS beacon trigger type, Coordinates or Push Button.CoordinatesThe start, stop and split beacon points are marked, by entering thecoordinates directly into the GPS Coordinates Editor. Details Editor |Venue type determines the function of the coordinates entered.Loop and Cross Over venues: 1st coordinates entered are start/stopbeacon point. Any additional coordinates will define the split beaconpoints.Mo T eC Using the GPS 5 Open venues: 1st coordinate defines the start beacon point 2ndcoordinate defines the finish beacon point. Any additional coordinateswill define the split beacon points.Push ButtonThe start, stop and split beacon points are marked by a push buttonoperated by the driver. A double press (within 1 second) will define asplit beacon for a loop or crossover venue, or a finish beacon for anopen venue.Data AnalysisGPS data analysis requires i2 version 1.02 or higher.All GPS channels (speed, heading, altitude etc) can be used in the usual way including plotting on a graph etc.The GPS position data (latitude and longitude) can also be used for the following:1. Plot the actual path travelled on a GPS Track component.Select Add | GPS Track.2. Generate the conventional track map.Select Tools | Track Editor, then click Generate Track and select the GPS method.3. Plot the path travelled over a Google Earth image.Select File | Google Earth Export. Requires Google earth to be installed on the analysis PC. An Internet connection or a previously saved cache isneeded to clearly plot the path travelled.6 SpecificationsSpecificationsElectricalPower Supply Voltage 4.0 to 5.5 VdcPower Supply Current ************ConnectionsConnectors Deutsch DTM06-4PDeutsch ASL 606-05 PN Cable length 7ft (2.13m)DataOutput Type RS232Output Levels 0V / 5Vdc (nominal)Baud Rate 19200 (Motec default)NMEA Sentences RMC, GGA (Motec default)PhysicalAntenna Built into GPS unit. RX Sensitivity -185 dBW minimum Size 2.4in diam x 0.77in (61 diam x 19.5mm)Weight 0.36lb (165g)Operating Temp -22F to 176F (-30C to +80C)Mounting Magnetic base + M3 centre threadGPS PerformanceUpdate Rate 5HzSatellite Channels 12Reacquisition Time < 2secsHot Start Time 1 secondsWarm Start Time 38 secondsCold Start Time 45 secondsDynamics >4G。
