DFT-S-OFDM系统中自适应调制技术分析及仿真何紫燕，桑林北京邮电大学电信工程学院，北京 (100876)E-mail：heziyan1117@摘要: 本文在阐明DFT-S-OFDM自适应调制系统架构原理以及详细分析DFT-S OFDM系统中不同调制技术的适用场合及对系统性能影响的基础上，给出了一种基于SNR门限值的适用于DFT-S OFDM系统的自适应调制技术。

理论及仿真结果都表明，调度的引入总能带来性能的增益，而这个增益随着信道质量的不同而不同。

关键词：DFT-S OFDM；自适应调制；SNR门限；快速傅里叶变换1．引言为了满足未来移动通信对上行链路的要求，如支持可升级带宽，适中的PAPR/CM，保证上行传输的正交性等，3GPP LTE计划组建议首选单载波传输方案SC-FDMA。

而作为SC-FDMA实现方案之一，DFT-S OFDM技术与下行的OFDM方案具有类似的结构，于是上下行链路可以共用很多参数，因此，DFT-S OFDM将成为未来上行传输中最具发展前景的物理层技术。

2．DFT-S-OFDM系统介绍通用陆地无线接入(UTRA)演进的目标是构建出高速率、低时延、分组优化的无线接入系统。

演进的UTRA致力于建立一个上行速率达到50 MHz、下行速率达到100 MHz、频谱利用率为3G R6的3～4倍的高速率系统。

为达到上述目标，多址方案的选择应该考虑在复杂度合理的情况下，提供更高的数据速率和频谱利用率。

在上行链路中，由于终端功率和处理能力的限制，多址方案的设计更具挑战性，除了性能和复杂度，还需要考虑峰值平均功率比(PAPR)对功率效率的影响。

在3GPP LTE的标准化过程中，诺基亚、北电等公司提交了若干多址方案，如多载波(MC)-WCDMA，MC-TD-SCDMA，正交频分多址接入(OFDMA)，交织频分复用(IFDMA)和基于傅立叶变换扩展的正交频分复用(DFT-S OFDM)。

OFDMA已成为下行链路的主流多址方案，并且是上行链路的热门候选方案。
