中兴智能集成多业务路由器ZSR2800产品介绍_20080320

中兴通讯2800交换机简单开局指导手册2800交换机简单开局指导手册1、交换机登录用CONSOLE线登录，缺省用户名是admin 密码是zhongxing，ENABLE密码也是zhongxing，2、设置远程登录的用户名和密码create user 123456 //增加远程telnet用户，用户名请自行定义loginpass 123456 //设置login密码，密码可以自行定义adminpass 123456 //enable密码，密码可以自行定义备注：登陆密码为空时，远程TELNET无法登陆3、端口配置set port 1 enable //使能端口1，端口缺省是打开的set port 1 disable //禁用端口1set port 1 auto disable //打开端口自适应，缺省自适应是打开的set port 1 auto disable //关闭端口自适应set port 1 duplex full //强制端口1全双工set port 1 speed 100 //强制端口1速率为百兆show port 1 //查看端口状态4、配置VLANzte(cfg)#create vlan 10 name test // 创建vlan 10, vlan的名字test //zte(cfg)#set vlan 10 enable // 使用vlan 10zte(cfg)#set vlan 10 add port 4 [untag | tag] //端口4加入vlan 10 (选择作为哪种方式加入VLAN：tagged或untagged)，tag就是打标记，一般用作级联口或者上联口，UNTAG一般作为普通业务口// zte(cfg)#set port 4 pvid 10 //把第4口如果配置成UNTAG方式加入VLAN10，还需要设置端口4的pvid为10，否则业务会不同// zte(cfg)show vlan //结果：系统VLAN配置列表5、配置管理IP地址加入管理VLAN是1000，16口是上联口zte(cfg)#create vlan 1000 name manager //创建管理VLAN 1000zte(cfg)#set vlan 1000 enable //使用vlan 1000zte(cfg)#set vlan 1000 add port 16 tag //在上行口打上vlan 1000标记zte(cfg)config router //进入路由配置模式set ipport 0 ipaddress 10.40.43.200 255.255.255.0 //增加交换机的管理IP地址set ipport 0 vlan 1000 //与VLAN 1000绑定set ipport 0 enable //激活ipportiproute 0.0.0.0 0.0.0.0 10.40.43.1 //增加默认路由exit6、配置端口聚合Set lacp enable|disable 开关交换机链路聚合功能Set lacp aggregator add|delete port portlist 在聚合组中加入|删除端口Set lacp aggregater dymanic|static|mixed 配置端口聚合模式show lacp //显示LACP的配置信息show lacp aggregator 3 //显示LACP聚合组聚合信息show lacp port 15-16 //显示LACP参与聚合的端口信息7、端口环路检测ZXR10(cfg)#set loopdetect port 1 enable开启端口1的环路检测功能ZXR10(cfg)#set loopdetect port 1 protect enable开启端口1的环路检测保护功能，当存在环路时自动关闭该端口，消除单环路造成的影响ZXR10(cfg)#show loopdetect 观察交换机环路检测情况8、端口隔离注意：整机只支持一个PVLAN。

MP2800系列增强型宽窄带一体化智能路由器MP2800系列路由器是针对“多业务整合”、“IP到终端”、“管理上收”的接入网络发展趋势，在MP2700系列路由器基础上由迈普公司自主研发的增强型宽窄带一体化智能路由器，其中包括MP2804、MP2804-DC48、MP2806、MP2806-DC48、MP2816-24、MP2816-24-DC48、MP2818-24、MP2818-24-DC48八款型号，延续迈普公司“低端高性能”的理念，是迈普公司打造多业务边缘智能网MeIN（Multi-service Edge-Intelligent Network）的高性能设备。

MP2800系列路由器采用固化和模块化相结合的结构，为用户提供宽窄带一体化的多业务集成智能解决方案，具有从LAN到W AN 以及LAN到LAN百兆线速的包转发能力，可用于金融、证券、保险、政府等行业的包括网络终端、PC、视频监控、IP电话等多以太接入的接入点/网点。

MP2800系列路由器提供极其丰富的软件特性，支持SNA/DLSw、VoIP、VPN、MPLS、组播、ACL、MAC地址绑定、访问控制、带宽限定、MSTP等多种应用技术，提供丰富的备份方案及QoS 特性，适用于数据、视频、语音等多种接入服务的解决方案。

MP2800系列路由器可与迈普全系列路由器一起为运营商、金融、政府、能源、交通、教育、军队等行业用户和大中型企业用户提供全方位的智能广域网解决方案。

MP2804路由器外观图MP2806路由器外观图MP2816-24路由器外观图MP2818-24路由器外观图关键特性⏹增强型宽窄带一体化，支持所有窄带或者宽带线路方式⏹智能实现多广域线路负载均衡，保证各类业务和谐共处⏹内置硬件加密技术，确保关键业务在IP线路上安全传输⏹全能智能以太接口，每个以太端口均可应用L2/L3技术⏹提供路由器故障自动诊断智能网管系统，实现“0现场服务”⏹提供安全接入控制功能，可实现IP网络“管理上收”后的端口级安全控制⏹支持高密度以太口和异步接口，满足大容量的异步终端向以太终端平滑过渡⏹提供层次化QoS，能在MSTP线路接口的指定带宽上实现不同业务的优先级⏹提供丰富的软件功能，全面支持MPLS/L2TP/IPSec/组播/MSTP等功能协议⏹和业界主流厂商产品全面兼容，支持原迈普窄带路由器业务模块，实现投资保护产品特点增强型宽窄带一体化，支持所有窄带或者宽带线路方式MP2800系列路由器全面继承迈普原有优秀窄带路由器的特点，并在MP2700系列路由器的基础上提供更多的高速多功能插槽，轻松实现各种N×64K/2M/N×2M等窄带线路的接入、10M/100M 等宽带线路的接入、以及MODEM、ISDN、ADSL等各种拨号备份方案，并通过大量的高速多功能插槽接入多个广域网模块（如E1、高速串口等）实现多个2M线路捆绑；同时迈普公司自主研发的快速转发引擎技术，可以使广域网100M线路接口达到线速转发，超前支持未来广域线路带宽扩展到100M的建设趋势。

Data SheetT3/E3 ATM Network Modules for Cisco 2800, 3800 and 3900 Integrated Services RoutersThe new Cisco T3/E3 ATM Network Module (NM-1A-T3/E3) is now available for the Cisco ISR 2800, 3800 and 3900 Series Routers that provide ATM WAN connectivity for enterprise regional and branch office connectivity. This combined T3/E3 ATM network module provides an ATM connection of either 44 Mbps for DS3/T3, or 34 Mbps for E3 using standard 75-ohm BNC connectors. Support is provided for ATM Forum compliant framing standard AAL5, as well as ATM Traffic Management support for Unspecified Bit Rate (UBR), UBR+ (For SVC’s only), Variable Bit Rate real-time (VBR-rt), Variable Bit Rate non-real time (VBR-nrt), Constant Bit Rate (CBR), and Available Bit Rate (ABR) classes of traffic.The T3/E3 ATM network modules provide a cost-effective solution that can be deployed in the Cisco 2800,3800, and 3900 ISR’s as Service Provider Managed customer premise equipment (CPE) or by Enterprise customers for T3/E3 and Fractional T3/E3 connectivity to medium-to-large size branch and smaller regional office locations for consolidating multiservice data, voice and video services over a single ATM link.Figure 1. T3/E3 ATM Network ModuleThe following key features are supported:●ATM Classes of Service support for: Unspecified Bit Rate (UBR), UBR+ (SVC’s only), Variable Bit Ratereal-time (VBR-rt), Variable Bit Rate non-real time (VBR-nrt), Constant Bit Rate (CBR), and Available Bit Rate (ABR)●RFC 1483 and RFC 1577 support●1024 maximum simultaneous Virtual Connections (VCs)●8 bits of VPI (VPI range 0-255), 16 bits of VCI (VCI range 0-65535)●Permanent Virtual Circuits (PVCs) and Switched Virtual Circuits (SVCs)●PLCP and HEC cell delineation support●Operations and Management (F4,F5 OAM) cell support●LANE support●ILMI 1.0 support●IETF PPP over ATM support●Multiprotocol Label Swapping (MPLS) VPN support●MPOA Client and Server●Next Hop Routing Protocol (NHRP)●On-line Insertion and Removal (OIR) on 3845●Permanent Virtual Path (PVPs) support●FRF.5/8 Interworking●ITU-T G.703 Compliant●ATM Traffic Management 4.1 compliant●ATM Forum UNI 3.1/4.0 PVC compliant●ATM Forum UNI 4.0 SVC compliantTable 1 shows minimum Cisco IOS release and feature sets requirement for the product.Table 1. Cisco IOS Support and Orderability Matrix for DS3/E3 ATM Network ModulesProduct IOS S/W Version Required IOS Feature Sets or LicensesRequiredMaximum supportedCisco 2800 Series (2811, 2821, 2851) 12.4(15)T All Cisco IOS12.4(15)T and above “SPServices” feature sets1Cisco 3825 12.4(15)T All Cisco 12.4(15)T and above “SPServices” feature sets1Cisco 3845 12.4(15)T All Cisco 12.4(15)T and above “SPServices” feature sets211Cisco 3925 15.0(1)M Data License 122Cisco 3945 15.0(1)M Data License 221 Maximum recommended modules does not imply will meet performance at wire rate2 Support for the DS3/E3 ATM network module in the 3925, and 3945 will be via the network module adapter card (SM-NM-ADPTR)Advanced Traffic ManagementAdvanced traffic management mechanisms in the DS3/E3 ATM network modules architecture allow for the support of bursty, client/server traffic, while supporting applications that require guaranteed or best-effort service. The ATM DS3/E3 supports all the ATM service classes, including UBR, UBR+, VBR-rt, VBR-nrt, and ABR. Supporting these ATM service classes allows the DS3/E3 network modules to concurrently support various network applications on the same ATM interface. VBR-rt is intended for applications that require guaranteed services, and ABR and UBR are intended for applications that need only “best-effort” service.The ABR support includes the Explicit Rate (ER), Relative Rate (RR), and Explicit Forward Congestion Indicator (EFCI) modes. ABR was defined specifically to minimize cell loss and maximize good put through the ATM network. Explicit Rate ABR is typically deployed in ATM WAN switches, and is used in products such as Cisco’s 8400/IGX and 8800/MGX ATM switches. Relative Rate ABR is more effectively deployed in the campus and is supported by the Cisco Lightstream 1010, and 8500 series ATM switches. EFCI is typically used for backward compatibility with legacy ATM switches that support neither Explicit nor Relative Rate. Please refer to Table 2 for ATM Service Class Definitions.Table 2. ATM Service Class DefinitionsATM Service Classes Typical UseVBR-nrt-non-real time Variable Bit Rate Used for all applications that require a level of Service guarantee through the ATM.VBR-rt-real-time Variable Bit Rate Used for connections that transmit at a rate varying with time and that can be described as bursty, oftenrequiring large amounts of bandwidth when active. Intended for applications that require tightlyconstrained delay and delay variation such as compressed VoIP and video conferencing.ABR-Available Bit Rate Used to maximize bandwidth utilization on the ATM link through the use of congestion feedbacknotification.UBR-Unspecified Bit Rate Most legacy data applications using fair best-effort service.CBR-Constant Bit Rate Provides guaranteed bandwidth for data applications such as SNA traffic.Per-VC Traffic ShapingTraffic shaping is a function typically provided on ATM edge devices to ensure that bursty traffic conforms to a predetermined Service Level Agreement (SLA). More specifically, traffic shaping ensures that traffic from one VC does not adversely impact another, resulting in data loss. This function is very important when connecting to an ATM WAN or public ATM network-especially when the ATM switches enable traffic policing that will discard all traffic that exceeds the predetermined contract at the ingress of the switch.The ATM DS3/E3 supports traffic shaping in hardware which eliminates performance degradation when shaping is enabled. Providing traffic shaping on a per-VC basis in done by the software using IP-to-ATM CoS mapping feature and allows total flexibly and control over every VC configured.For each ATM service class, the ATM DS3/E3 supports highly configurable parameters: peak cell rate (PCR), sustainable cell rate (SCR), maximum burst size (MBS) and minimum cell rate (MCR). These parameters can be defined based on the specific bandwidth requirements of an individual VC, as needed for a specific application. Table 3 lists ATM Class of Service Traffic Shaping Parameters supported on the product.Table 3. ATM Class of Service Traffic Shaping ParametersVBR -rt and nrt Parameters ABR Parameters UBR ParametersPCR (kbps) PCR (kbps) PCR (kbps)SCR (kbps) MCR (kbpsMBS (cells)The ATM DS3/E3 hardware “shapes” the VC to the specific parameters using a wheel-based scheduling algorithm to ensure fairness across the ATM interface. In the event that two cells compete for the same time slot, the VCs are prioritized in the following order (starting with highest priority): 1) CBR; 2)rt-VBR; 3)nrt-VBR; 3) ABR; and 4) UBR. OAM cells and signaling has the priority higher than any of the service classes. Prioritizing the VCs in this manner ensures that the high priority and guaranteed traffic have precedence over the best-effort traffic.To provide further flexibility, the ATM DS3/E3 allows each of these parameters to be set over a wide range of small increments. Please refer to Table 4 for the Traffic Shaping Granularity supported on this module.Table 4. Traffic Shaping GranularityParameter Range IncrementsPCR 64 kbps to line rate 64 kbpsSCR 64 kbps to line rate 64 kbpsOne cellMBS ●<32 up to 4 Mbps●<200 up to line rateNote: Although configuration to line rate is allowed, line rate is only reached with large packet sizes.Extended Virtual Connections CapabilitiesThe ATM DS3/E3 supports up to 1024 Virtual Connections (VC) and up to 256 Virtual Path (VP). Any combinations of VC and VP can be supported up to a maximum number of 1024 VC/VP combinations. These VCs can be either Permanent Virtual Connections (PVC) which are created manually or Switched Virtual Connections (SVC) created through point-to-point and point-to-multipoint UNI signaling. Table 5 provides Interface Specification details. Table 6 provides LED Indicator description.Table 5. Interface SpecificationsInterface Rate Connector Type Wavelength Maximum DistanceDS3 44.736 Mbps BNC Coaxial 450 ft.E3 34.368 Mbps BNC Coaxial 1250 ft.Note: The DS-3 version provides adaptive equalization for 0-450 ft. of cable and provides loopback capability. The E3 version provides adaptive equalization for 0-1250 ft. of cable and also provides loopback capabilities.The DS-3 version also has the ability to support line build-out for cable lengths of less than 50 ft. or greater than50 ft., as required.Table 6. LED IndicatorsATM NM LED Port Status FunctionEnable Green Indicates the ATM NM is successfully inserted and has established communications to the PCI bus. It isready to accept CLI commandsRCLK Green Indicates that a receive clock has been detectedFERF Yellow The framer has detected a Far End Receive FailureOOF Yellow The framer has detected an Out of Frame occurrenceAIS Yellow The framer has detected an Alarm Indication SignalSystem Requirements● A maximum of one NM-1A-T3/E3 Network Module is supported on the Cisco 2811,2821,2851 and 3845.Two are supported on the Cisco 3845. Line rate performance is not guaranteed for maximum NM-1A-T3/E3 Network Module support on the platforms.●Operates in conjunction with all currently available Cisco 3800 network modules and WAN interface cards(WICs) and with all currently available Cisco 3900 Network Modules, Service Modules, Internal ServicesModules, EHWICs, HWICs, WICs and VICs.●No slot placement restrictions●Support for the DS3/E3 ATM network module in the 3925, and 3945 will be via the network module adaptercard (SM-NM-ADPTR).Network ManagementSupported MIBs include:●Synchronous Optical Network (SONET) MIB●MIB II●AToM MIB (FRC 1695)●ILMI MIB●CISCO-BUS MIB●CISCO-LECS-MIB●CISCO-LES-MIB●LAN Emulation (LANE) MIB●Cisco-AAL5-MIB●DS3/E3 CISCO-ATM-IF-PHYS-MIBProduct Compliance StandardsThe DS-3 and E3 ATM network modules are to receive all the agency approvals necessary for unlimited international availability. The following regulatory approvals are supported:EnvironmentalTable 7. DS3/E3 ATM Physical SpecificationsProduct Specifications DescriptionsDimensions (H x W x D) 1.55 x 7.10 x 7.2 inWeight 2 lbs. MaximumEnvironmental Conditions ●Operating temp. 41-131°F (+5 -+55°C)●Non-operating temp. -13-158°F (-25-70°C)Relative Humidity 0 to 90%, noncondensingEMI Class B EMICabling 75 Ohm BNC type connectorLEDs Enabled, RX cells, RX carrier, RX AlarmSafety Regulatory Approvals●UL 1950 3rd edition/CSA C22.2, no. 950●C1950 (Canada)●AS/NZS 3260 (Australia/New Zealand)●EN60950 (Europe)●IEC 950 (National Deviations)Emission Regulatory Approvals●FCC Part 15J Class A (US/Canada)●VCCI Class 2 (Japan)●AS/NZS 3548 (Australia/New Zealand)●EN55022 (CISPR 22) Class B (Europe)Cisco and Partner Services for the BranchServices from Cisco and our certified partners can help you transform the branch experience and accelerate business innovation and growth in the Borderless Network. We have the depth and breadth of expertise to create a clear, replicable, optimized branch footprint across technologies. Planning and design services align technology with business goals and can increase the accuracy, speed, and efficiency of deployment. Technical services help improve operational efficiency, save money, and mitigate risk. Optimization services are designed to continuously improve performance and help your team succeed with new technologies. For more information, visit/go/services.。

Cisco 2800系列Cisco 2800系列集成多业务路由器提供了更高的性能、更高的安全性和语音性能、全新内嵌服务选项，以及更高的插槽性能和密度。

它保留了对Cisco 1700系列和Cisco 2600系列路由器大多数现有接口卡和模块的支持。

它由4个新的平台组成：Cisco 2801、Cisco2811、Cisco 2821和Cisco 2851，能够在多个T1/E1/xDSL连接上以线速提供多项高质量同步服务。

适用场合销售该产品当客户需要下列特性时Cisco 2800 需出色性能和密度，以便能在多个T1/E1/xDSL连接上并发提供数据、安全、语音和高级服务具有VPN连接，或计划后续迁移到该连接集成安全服务可实现网络设备保护、威胁防御、安全连接，以及终端保护和控制需安全的集成呼叫处理、语音留言、灵活的电话接口、针对集中呼叫处理的冗余性，或强大的DSP支持，包括本地会议和自动语音编码转换功能通过集成的IEEE 802.11 a/b/g接入点HWIC提供无线支持在从4端口到48端口的各种密度的产品中集成了第二层交换功能，且能使用Cisco StackWise连接关键特性模块化架构——拥有广泛的局域网和广域网选择。

网络接口能够现场升级以采用未来的技术；拥有若干类型的插槽，可根据“随发展随集成”的模式，在未来添加连接和服务内嵌安全硬件加速——内嵌硬件加密加速器，与可选的Cisco IOS软件升级配合，有助于实现广域网链路的安全和支持VPN服务集成双快速以太网或千兆以太网端口——在Cisco 2801和Cisco 2811上提供了2个10/100以太网端口，在Cisco 2821和Cisco 2851上提供了2个10/100/1000以太网端口配备增强功能的HWIC插槽，包括无线局域网接入点；双AIM插槽；母板上的分组语音DSP模块（PVDM）插槽IP语音解决方案是一个一体化V oIP解决方案，配备了Cisco Call Manager Express、语音接口和Cisco Unity Express，提供语音留言和自动接听功能基于硬件的板载加密功能，用于DES、3DES和AES，以及用于PVDM的板载插槽，它们都拥有高速以太网接口支持可选的专用安全AIMEzVPN通过从单一头端向远程站点推出新的安全策略，简化了点到点VPN管理DSP模块为模拟和数字语音、会议、自动语音编码转换和安全的实时传输协议（RTP）应用提供了支持网络准入控制（NAC）——这是一种思科自防御网络机制，通过只允许符合要求和可信任的终端设备接入网络，极大地提高了网络识别、防御和适应攻击的能力用于PoE配电的可选集成电源实时时钟支持竞争对手产品Juniper: J 系列3Com: SuperStack II NETBuilder SI 和Pathbuilder S400, 5000 & 6000 系列Intel/Shiva: LanRover系列Motorola: Vanguard 645x/643x Nortel/Bay: Advanced Remote Node (ARN), Passport 4400 系列Tasman: 2004, 1400Huawei: AR2800产品特性特性Cisco 2801 Cisco 2811 Cisco 2821 Cisco 2851固定的USB1.1端口1个2个与Cisco 2811相同与Cisco 2811相同板载局域网端口2个10/100 与Cisco 2801相同2个10/100/1000 与Cisco 2821相同板载AIM（内部）插槽2个与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同接口卡插槽4个插槽；2个插槽支持HWIC、WIC、VIC或VWIC类型的模块1个插槽支持WIC、VIC或VWIC类型的模块1个插槽支持VIC或VWIC类型的模块4个插槽，每个插槽都支持HWIC、WIC、VIC或VWIC类型的模块网络模块插槽没有1个插槽，支持NM和NME类型的模块1个插槽，支持NM、NME和NME-X类型的模块1个插槽，支持NM、NME、NME-X和NME-XD类型的模块扩展语音模块插槽0与Cisco 2801相同1个与Cisco 2821相同母板上的PVDM（DSP）插槽2个与Cisco 2801相同3个与Cisco 2821相同集成基于硬件的加密有与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同可选的PoE 有，需要AC-IP系统电源与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同控制台端口（高达115.2kbps）1个与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同辅助端口（高达115.2kbps）1个与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同最低Cisco IOS软件版本12.3(8)T4 与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同机架安装有，19英寸有，19和23英寸两种与Cisco 2811相同与Cisco 2811相同墙壁安装没有有与Cisco 2811相同与Cisco 2811相同交流输入电压100-240V AC 与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同交流输入频率47-63Hz 与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同交流输入电流2A（110V），1A（230V）与Cisco 2801相同3A（110V）；2A（230V）与Cisco 2821相同交流输入浪涌电流最大50A，一个周期（包括-48V电压）与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同交流IP最大馈线配电120W 160W 240W 360W交流IP输入电流4A (110V); 2A (230V) 与Cisco 2801相同8A (110V); 4A(230V)与Cisco 2821相同交流IP输入浪涌电流最大50A，一个周期（包括-48V电压）与Cisco 2801相同与Cisco 2801相同与Cisco 2801相同直流输入电压没有直流电源选项24-60VDC，自动调节正反向与Cisco 2811相同与Cisco 2811相同直流输入电流没有直流电源选项8A（24V）3A（60V）启动电流5A<10ms 12A（24V）5A（60V）启动电流50A<10ms与Cisco 2821相同功耗——交流交流，，没有PoE支持150W（511BTU/hr）170W（580BTU/hr）280W（955BTU/hr）与Cisco 2821相同功耗——交流交流，，带PoE-IP电话支持180W (612 BTU/hr.) 160W (546 BTU/hr.) 240W (819 BTU/hr.) 与Cisco 2821相同功耗——直流不适用180W（614BTU/hr）300W（1024BTU/hr）与Cisco 2821相同冗余电源支持（RPS）没有仅限于外部，缺省提供RPS连接器与Cisco 2811相同与Cisco 2811相同推荐RPS 设备没有RPS 选项Cisco RPS-675冗余电源系统与Cisco 2811相同 与Cisco 2811相同工作温度 32-104°F ；（0-40℃） 与Cisco 2801相同 与Cisco 2801相同 与Cisco 2801相同 工作湿度 10-85%非冷凝 5-95%非冷凝与Cisco 2811相同与Cisco 2811相同 非工作温度N/A-4-149℉（-20-65℃） 与Cisco 2811相同与Cisco 2811相同规格规格（（高x 宽x 长）1.72x17.5x16.5英寸（43.7x445x419毫米）1.75x17.25x16.4英寸（44.5x438.2x416.6毫米）3.5x17.25x16.4英寸（88.9x438.2x416.6毫米）与Cisco 2821相同 机架高度1个机架单元（1RU ）1个机架单元（1RU ） 2RU 与Cisco 2821相同 重量重量（（配置后配置后））13.7磅（6.2公斤） 14磅（6.4公斤）25磅（11.4公斤）与Cisco 2821相同噪音级别（最小/最大最大））39dBA ，正常工作温度（<90/32.3℉℃）53.5dBA （最高风扇速度）47dBA ，正常工作温度（<90/32.3℉℃） 57dBA （最高风扇速度）44dBA ，正常工作温度（<90/32.3℉℃） 53dBA （最高风扇速度）安全 UL 60950CAN/CSA C22.2 No.60950 IEC 60950 EN 60950-1 AS/NZS 60950与Cisco 2801相同 与Cisco 2801相同 与Cisco 2801相同抗干扰性 EN300386 EN55024/CISPR24 EN50082-1 EN6100-6-2与Cisco 2801相同 与Cisco 2801相同 与Cisco 2801相同EMCFCC Part 15;ICES-003 Class A;EN55022 Class A;CISPR22 Class A;AS/NZS 3548 Class A;VCCI Class A EN 300386;EN61000-3-3;EN61000-3-2TELCOM 视国家和接口类型的不同，遵循相应的电信标准。

ZXR10 ZSR2800智能集成多业务路由器ZXR10 ZSR2822/2842ZXR10 ZSR2800（Intelligent Integrated Service Router）智能集成多业务路由器采用模块化设计思想，提供丰富的语音接口、LAN接口、WAN接口；支持USB高速接口等。

ZXR10 ZSR2800路由器包括2822、2842、2882、2884等共4款，满足各类组网需求。

ZXR10 ZSR2800在一个机架中集成了安全、语音、数据、交换多业务，可以将用户原来分散的防火墙设备、语音网关、路由器、交换机集成到一个集成多业务路由器中，大大降低建设成本和维护费用。

产品定位* 中小型企业和企业分支结构* 连接远程机构、移动用户和合作伙伴外部网或服务供应商产品的关键特征Ø全模块化设计思想，并集成丰富的接口类型，具有灵活的可扩展性Ø采用固定接口与模块化接口卡相结合的方式，高性能RISC转发和高效的软件设计，V-BUS智能多总线和多种处理引擎，满足不同客户对性能和端口的要求。

Ø集成2个GE Combo接口和2个FE接口，支持2、4、8个扩展槽位，并提供2个内部AIM扩展功能插槽，可以扩充语音、数据加密等功能。

Ø支持超大容量的高速USB存储卡，可以方便的实现配置文件和系统文件的备份。

Ø可以在同一个平台上支持300bps到1000Mbps的不同接口速率，槽位通用，各种类型接口板可以任意混插。

Ø集成PCI总线、CPU BUS总线、USB总线、以太网交换总线、TDM语音交换总线等多套系统总线，可以为用户提供Data、Voice、Video并发的Triple-Play服务。

Ø智能集成数据、语音、QoS、VPN等多种业务功能Ø提供多种类型的语音接口，包括Z接口、环路中继语音接口、E1/ISDN PRI语音中继接口、传真等多种类型，提供中小企业的语音数据整体解决方案。

BSR2800-40路由器硬件安装手册目录目录第1章 BSR2800-40模块化路由器概述 (1)1.1 标准配置时的外形说明 (1)1.2 路由器系统特性参数 (2)1.3 ROHS说明 (3)第2章安装准备 (4)2.1 使用注意事项 (4)2.2 安全建议 (4)2.3 一般场所要求 (6)2.3.1 场所环境 (6)2.3.2 场所配置预防 (6)2.3.3 机架配置 (6)2.3.4 电源考虑 (7)2.4 安装工具和设备 (7)第3章安装路由器 (8)3.1 BSR2800-40路由器的安装流程 (8)3.2 路由器机箱安装 (8)3.2.1 安装机箱于桌面 (9)3.2.2 安装机箱于机架 (9)3.3 连接接口 (9)3.3.1 连接监控口 (9)3.3.2 连接千兆以太网接口 (11)3.3.3 连接USB接口 (12)3.4 网络接口卡 (12)第4章路由器维护 (14)4.1 打开机箱 (14)4.2 关闭机箱 (15)第5章硬件故障分析 (17)5.1 故障隔离 (17)5.1.1 电源和冷却系统故障 (17)5.1.2 端口、电缆和连接故障 (17)5.2 指示灯说明 (18)第1章BSR2800-40模块化路由器概述本节主要对BSR2800-40模块化路由器总体方面的特性、参数作了说明和介绍，让读者对BSR2800-40模块化路由器有一个总体的认识。

1.1 标准配置时的外形说明BSR2800-40模块化路由器标配端口由四个部分组成：二个10/100/1000M以太网端口，一个Console端口，一个AUX端口，一个USB口。

详细说明如下表。

表 1-1 标配端口特性表端口名称特点千兆以太网端口 速率10/100/1000M 自适应，UTP (RJ45)接口，带ACT、Link指示灯Console端口 速率1200bps—115200bps，RJ45接口，无指示灯AUX端口 速率1200bps—57600bps，RJ45接口，无指示灯USB口USB1.1接口，低速模式1.5Mbps和全速模式12Mbps。
