Data Sheet No. PD60263

Typical ConnectionProduct SummaryV

OFFSET600 V max.IO+/-130 mA/270 mAVOUT10 V - 20 Vton/off (typ.)680 ns/150 nsDeadtime (typ.)520 nsHALF-BRIDGE DRIVERFeatures•Floating channel designed for bootstrap operation•Fully operational to +600 V•Tolerant to negative transient voltage, dV/dtimmune•Gate drive supply range from 10 V to 20 V•Undervoltage lockout•3.3 V, 5 V, and 15 V logic compatible•Cross-conduction prevention logic•Matched propagation delay for both channels•Internal set deadtime•High side output in phase with HIN input•Low side output out of phase with LIN inputDescriptionThe IRS2103 is a high voltage, high speed powerMOSFET and IGBT drivers with dependent high andlow side referenced output channels. Proprietary HVICand latch immune CMOS technologies enable rugge-dized monolithic construction. The logic input iscompatible with standard CMOS or LSTTL output, downto 3.3 V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high sideconfiguration which operates up to 600 V.

www.irf.com1

VCCVB

V

SHO

LO

COM

HINLINLINHINup to 600 V

TOLOADVCCIRS2103(S)PbF

(Refer to Lead Assignments for correct configuration). This diagram shows electrical connections only. Please refer toour Application Notes and DesignTips for proper circuit board layout.Packages

8-Lead PDIPIRS21038-Lead SOICIRS2103S元器件交易网www.cecb2b.com IRS2103(S)PbF

www.irf.com2SymbolDefinitionMin.Max.UnitsVBHigh side floating absolute voltage-0.3625VSHigh side floating supply offset voltageVB - 25VB + 0.3VHOHigh side floating output voltageVS - 0.3VB + 0.3VCCLow side and logic fixed supply voltage-0.325VLOLow side output voltage-0.3VCC + 0.3VINLogic input voltage (HIN & LIN)-0.3VCC + 0.3dVs/dtAllowable offset supply voltage transient—50V/nsPDPackage power dissipation @ TA ≤ +25 °C(8 Lead PDIP)—1.0(8 Lead SOIC)—0.625RthJAThermal resistance, junction to ambient(8 Lead PDIP)—125(8 Lead SOIC)—200TJJunction temperature—150TSStorage temperature-55150TLLead temperature (soldering, 10 seconds)—300

Recommended Operating ConditionsThe input/output logic timing diagram is shown in Fig. 1. For proper operation the device should be used within therecommended conditions. The VS offset rating is tested with all supplies biased at a 15 V differential.SymbolDefinitionMin.Max.UnitsVBHigh side floating supply absolute voltageVS + 10VS + 20VSHigh side floating supply offset voltageNote 1600VHOHigh side floating output voltageVSVBVCCLow side and logic fixed supply voltage1020VLOLow side output voltage0VCCVINLogic input voltage (HIN & LIN)0VCCTAAmbient temperature-40125Absolute Maximum RatingsAbsolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage param-eters are absolute voltages referenced to COM. The thermal resistance and power dissipation ratings are measuredunder board mounted and still air conditions.

Note 1: Logic operational for VS of -5 V to +600 V. Logic state held for VS of -5 V to -VBS. (Please refer to the Design TipDT97-3 for more details).°CVV

W

°C/W

°C元器件交易网www.cecb2b.com IRS2103(S)PbF

www.irf.com3SymbolDefinitionMin.Typ.Max.UnitsTest ConditionsVIHLogic “1” (HIN) & Logic “0” (LIN) input voltage2.5——VILLogic “0” (HIN) & Logic “1” (LIN) input voltage——0.8VOHHigh level output voltage, VBIAS - VO—0.050.2VOLLow level output voltage, VO—0.020.1ILKOffset supply leakage current——50VB = VS = 600 VIQBSQuiescent VBS supply current—3055IQCCQuiescent VCC supply current—150270IIN+Logic “1” input bias current—310HIN = 5 V, LIN = 0 VIIN-Logic “0” input bias current——1HIN = 0 V, LIN = 5 VVCCUV+VCC supply undervoltage positive going88.99.8thresholdVCCUV-VCC supply undervoltage negative going7.48.29thresholdIO+Output high short circuit pulsed current130290—VO = 0 V, VIN = VIHPW ≤ 10 µsIO-Output low short circuit pulsed current270600—VO = 15 V, VIN = VILPW ≤ 10 µsSymbolDefinitionMin.Typ.Max.UnitsTest ConditionstonTurn-on propagation delay—680820VS = 0 VtoffTurn-off propagation delay—150220VS = 600 VtrTurn-on rise time—70170tfTurn-off fall time—3590DTDeadtime, LS turn-off to HS turn-on &400520650HS turn-on to LS turn-offMTDelay matching, HS & LS turn-on/off——60

Static Electrical CharacteristicsVBIAS (VCC, VBS) = 15 V and TA = 25 °C unless otherwise specified. The VIN, VTH, and IIN parameters are referenced toCOM. The VO and IO parameters are referenced to COM and are applicable to the respective output leads: HO or LO.Dynamic Electrical CharacteristicsVBIAS (VCC, VBS) = 15 V, CL = 1000 pF and TA = 25 °C unless otherwise specified.
