Drilling Calculations钻井计算,国外,英语

1. Drilling 钻井Carry out drilling operation in accordance with the drilling program. 按钻井程序进行钻井作业.Prepared bell nipple. 准备”喇叭口”短节.Make up 2 joints of drill pipe. 接两根钻杆.Break out this connection. 卸开该接头.Run hole opener to sea bed. 下扩眼器到海底Mix gel fluid for drilling conductor hole. 为钻导管井眼配制高粘度泥浆.Make up bottom hole assembly. 组合下部钻具Check and reset crown-saver on every tour. 每个班都要检查并重新调整天车防碰装置.Number stands on trip out and trip in. 起下钻时给立柱编号.Pick up BHA and run to seafloor. 将下部钻具下到海底.Pick up stands. 接立柱Don’t drill faster than 15 minutes for 1 stand. 钻进速度别超过15分钟1根立柱Drop TOTCO. 投(陶特)测斜仪Fish TOTCO with overshot. 用打捞筒捞起测斜仪Resume drilling to T.D. 继续钻进到总深Circulate 15 minutes.循环15分钟Run in hole. 下钻Put out of hole. 起钻Make an inventory of all ring gaskets. 开一个所有垫圈的清单Use spinning tong. 使用气动扳手Operate the air winch. 操作气动绞车Lay down 57 joints of 5”drill pipe. 甩57根钻杆Pick up drill stem test tool. 提起钻杆测试工具Circulate mud for 2 hours. 循环泥浆2小时Move string during circulation. 在循环时注意活动钻具Circulate hole clean. 循环清洗井眼Circulate bottoms up. 循环泥浆几周Fill up every 5 stands. 每5柱灌泥浆一次Check mud weight every 15 minutes. 每15分钟检查泥浆比重Reverse out excess cement. 反循环替出多余的泥浆Change/replace old mud by new mud. 用新的泥浆替换出旧的泥浆Stop drilling. 停止钻进Drilling ahead. 钻进Pull out of hole bit. 起出钻头Change bit. 换钻头Run the wear bushing. 下抗磨补心The bit thread type is regular pin. 钻头丝扣是正规公扣What’s the make-up torque? 上扣扭矩要多大?Run in 9”collars. 下9”钻铤The cathead can’t give enough torque. 猫头力量不够Connect crossover sub. 接上配合接头The tong angle is too small. 大钳的角度太小了Stop circulating. 停止循环泥浆Break out the stand. 卸立柱Set the single into the mousehole. 把这个单根放进鼠洞Can we break out the pipe with rotary table? 可用转盘卸扣吗?No! Break it out with tong. 不行! 要用大钳卸扣Spin it out with the air spanner. 用气动扳手卸扣Put the pipe wiper on the string. 装上钻杆刮泥器Don’t set this stand back. 这根钻杆不要放在钻杆盒上Make up the lift sub. 接好提升短节Secure the safety clamp. 上紧安全卡瓦The bit is nearing the shoe. 钻头快到套管鞋了Slow down the running speed. 放慢下放速度This is the undergauged interval. 这是缩径井段This is the drilling program. 这是钻井设计书How much weight on bit is required? 要加多少钻压?Keep the rotary speed at 120---140 RPM. 转速保持120---140转/分Keep the flow rate at 3000 LPM. 保持排量3000升/分The pump pressure is too high. 泵压太高了Don’t ream the hole too fast. 划眼不要太快Notice the rotary torque. 注意转盘扭矩的变化The penetration rate is getting slower. 钻速变慢了The bit is nearly worn out. 钻头快磨光了Stop drilling at 2000 meters. 钻至2000米停钻Circulate for one hour. 循环一个小时The pump pressure has increased. 泵压升高了One nozzle may be plugged. 可能有一个水眼(或: 喷嘴)堵了What is the hook load? 悬重多少?What’s the pick-up weight? 上提重量是多少?What’s the lowering weight? 下放重量是多少?Run in HWDP. 下加重钻杆A stabilizer is needed here. 这里需要一个扶正器This is a flexible sub. 这是挠性接头This is the BHA log. 这是下部钻具组合记录Record all outside and inside diameters. 记录好所有(入井工具的)内外径We need a short drill collar. 需要一根短钻铤Pull the cat line. 拉猫头Operate the break lever. 操作(或:扶)刹把Stop the pumps. 停泵Make a wiper trip. 通井Retrieve wear bushing. 取出抗磨补心Bleed off pressure. (释)放压(力)Keep 5 wraps on the drum. 滚筒上留5圈Set slips. 座上卡瓦If tight hole, repeat wiper trip. 如果井眼紧, 重复划眼Setback bottom hole assembly. 将下部钻具立于钻杆盒内Make sure all alarms are on. 确保所有的警报信号都开着Lay down TDS spinner. 拆下顶部驱动的旋扣器Run in hole bit #15 to bottom. 用15号钻头下钻到井底Run in hole to casing shoe. 下钻至套管鞋Pick up same bit and BHA. 装上同样的钻头和钻具组合Lay down 5”HW drill pipe. 甩5”加重钻杆Move string every 2 hours. 每2小时活动钻具一次Keep area around shaker clean. 保持振动筛区域干净Control trip gas. 控制起下钻气Ream if needed. 如必要时进行划眼Select the best penetration rate. 选择最佳钻进速度Fix the traveling assembly. 固定游动系统Check power tongs and spinning rope are on drill floor. 检查动力钳和尾绳是否在钻台What’s the weight on bit? 钻压是多少?What is the BHA of this well? 这口井的下部钻具如何组合?Drill out cement. 钻穿水泥Drill out 20”casing shoe. 钻穿20”套管鞋Latch the elevator. 扣吊卡Unlatch the elevator. 开吊卡Set the slips. 放卡瓦Adjust the crown-o-matic (crown saver). 调整防碰天车Lock the hook pin. 锁紧大钩销子Check OD of stabilizer. 检查扶正器的外径Perform leak off test. 进行地层破裂(或:渗漏)测试Connect kill and choke line. 接上压井和放喷管线Reverse out the drill pipe. 反循环清洗钻杆Make a short trip. 进行短途起下钻Change the cutters. 换割刀Slug the pipe. 灌重泥浆Drill the stand down. 钻完立柱Start/run the shale shaker. 开振动筛Start the desanders. 开除砂器Start the desilters. 开除泥器Change it with a 40 mesh screen. 换成40目筛布Shut it off. 关掉Pull it to the cat ramp. 把它拉到坡道上去Make a fast connection. 接单根要快Don’t dump the mud into the sea. 不要把泥浆排放到海里Disconnect it with a chain tong. 用链钳卸开Put a thread protector. 加一个(丝扣)护箍Can we use the power slips? 可以使用动力卡瓦吗?Casing and Cementing 下套管与固井Run in hole to bottom for wiper trip. 下钻通井This is the casing program. 这是套管程序Prepare for running casing. 准备下套管Make everything ready for running 7”casing. 做好下7”套管的准备Make cementing job. 固井Displace cementing with mud pump. 用泥浆泵替泥浆Set cement plug from 2940 to 2790m. 在2940到2790米井段打水泥塞Pick up cementing head. 接水泥头Cement samples are hard. 水泥样已凝固Pump in 3 cubic meters of spacer. 注3方隔离液Pump down the plug. 泵压(胶)塞Wait on cement. 候凝The guide shoe will be connected. 接引鞋Connect the floor collar. 接浮箍Connect the air line to the casing stabbing board. 接好套管扶正台的气管线Run casing with the 350T slip elevator. 用350吨卡瓦式吊卡下套管Clean and dry 20”casing threads with rags. 清洁并擦干20”套管丝扣Where is the rabbit for drifting the casing? 套管通径规在哪里?Rig Move, Anchoring and Positioning 拖航, 抛锚, 定位What is our position now? 我们现在船位在哪里?What’s the moving speed now? (What’s the towering speed?) 拖航速度是多少? The speed is about 4 knots. 船速是4节左右Which one is the main tug? 主拖是哪条船?The main tug is Nanhai 205. 主拖是南海205Which one is the chase boat? 护航船是哪一条?How much is the horse power? 有多大马力?She has 6000 HP. 有6000马力Move the rig off location 50 feet. 将平台移开50英尺We are ready to drop the anchor. 我们已经做好抛锚的准备了Secure all the movable equipment. 固定好各种活动的设备Preload. (自升式)压载Ballast. (半潜式)压载Put the preload water into the tank. 向压载舱灌压压载水We need 5500 tons of preload water. 需要5500吨压载水Shall we preload right now? 马上开始压载吗?Drain the water off. 放水The rig is overloaded. 平台已超载Jack up (jack down) the rig. 升(降)船The draft is 3.5 meters. 船体吃水3.5米The jetting pressure is 100psi. 冲桩压力是100psiPenetrate the legs. 插桩How much penetration do we have? 入泥多深了?No.1 and No.2 legs indicate 10 meters. 1,2号桩腿插入10米Fix the upper and lower wedges. 固定上下楔块Pay out the anchor line. 放出锚缆绳Skid the derrick. 移开井架The rig is short of potable water now. 平台缺乏饮用水Drop No.2 and No.3 anchors. 抛2号和3号锚Why has the main engine stopped? 主机为什么停?Unleash the drilling tools. 卸开钻具Tighten up. 绷紧(或:上紧)一点Turn on the cooling water for the windlasses. 开锚机刹车冷却水Retrieve the No.1 to No.8 anchors. 起1到8号锚Check the paint marks at the anchor winches. 检查锚机上的油漆记号Prepare for a location move. 准备好移井位Commence anchor handling. 开始起锚(或抛锚)Secure all equipment stored on deck. 固定好所有存放在甲板上的设备Carry out stability and load calculations. 做稳性和载荷计算Pass pendant line, shackle and buoy to anchor handling vessel. 将起抛锚短索, 卸扣和浮标吊起给起锚船Lower the windward anchor to seafloor. 抛上风锚到海底Pick up the leeward anchor first. 先起下风锚Take anchor chaser (or chaser) back to rig. 将捞/抛锚环送回平台Hook up towing lines to tug boat. 将拖缆连接到拖轮Sound fog signal for two seconds every twenty seconds. 发大雾信号, 每20秒钟响两秒Fishing 打捞The bit cutters have been lost in the hole. 牙轮落井Run in the reverse-circulation basket. 下反循环打捞篮There is a lot of junk in the hole. 井下有很多落物The fish is 235.46 meters long. 落鱼长度235.46米The fish top is at 2478.34 meters. 鱼顶位置2478.34米Coring 取芯Stop drilling for coring. 停钻准备取芯Make up core bit. 接取芯钻头What type of core bit is it? 这是什么型号的取芯钻头?Run in a diamond core bit. 下金刚石取芯钻头Let’s drop the ball for coring. 可以投球取芯The core has been broken off. 岩芯断了Put the core in the boxes. 把岩芯装在岩芯盒里Don’t brake suddenly. 不要猛刹车Take out the core. 岩芯出筒How long is the core? 岩芯多长The core recovery is 98%. 岩芯收获率是98%Run in the core barrel again. 继续下岩芯筒(或: 取芯筒)Run in hole core barrel. 下取芯筒Drop ball. 投钢球Recover core. 取出岩芯Use same parameters as for core #1. 使用与1#取芯同样的参数Freeing Stuck Pipe 卡钻与解卡The down-hole problems are very complicated. 井下情况很复杂The hole is tight. 遇阻了Overpull while tripping out. 起钻遇卡(overpull: 超拉力)The formation is unstable. 地层不稳定The wall caving is severe. 井壁垮塌严重There are many return cuttings. 返出岩屑特别多The mud returns have decreased. 返出泥浆减少The hole is enlarged. 井眼扩大了The pipe’s stuck. 卡钻了Pull up to 150 tons. 上提150吨Slack off to 50 tons. 下放至50吨Ream down all the tight points. 在所有遇阻点进行划眼The rotary table can’t rotate. 转盘转不动Where is the sticking point? 卡点在哪里Make a tensile test. 做拉伸试验Back it off above the free point. 在卡点以上倒扣Plug the well for side tracking. 打水泥塞侧钻。

DRILLING PROFESSONAL WORDSunit one -personnel and post1.Are you a driller? 2.Are you a technician of this crew? 3.What is this toolpusher 's name? 4.Is he a mud engineer? Yes. He is a senior engineer. 5.He is a directional engineer. 6.He is an assistant driller. He is not a driller. Who is the driller of this shift? 7.Mr. Leo is the driller of this shift. We are all roughnecks of this shift. 8.How many roughnecks and motormen are there in this shift? 9. Is the driller on the drillfloor? No .He is on the mud tank.10. When did he begin to work as a rig manager? How long have you worked as a toolpusher?STUDY STUDYSTUDY ．．．．．LEARNING ．．．．．．．．PRACTISE ．．．．．．．．11. How long have you worked as a mechanist?12. He is in charge of drilling operation.13. Where do the floormen work? The work on the drillfloor.14. What is the toolpushers job? He is in charge of the shift operation.15. What is the derrickman responsible for? Who is he responsible to?16. Derrickma is responsible for attaching or detaching the elevators, for clearing, oiling,greasing, inspecting and repairing the pulley blocks, etc. He is responsible to the toolpusher.17. Who is the toolpusher responsible to? He is responsible to the drilling supervisor.18. What is the drilling supervisor responsible for? He is responsible for all drilling operations.19. The man driving the earthmover is LEO.20. The man 0perating brake bar is our driller.21. There are two roughnecks helping the driller get everything read for running in hole.22. The man who operates a brake bar is a driller.23. Here comes our superintendent.unit two-drilling fluids1.How long have you worked as a mud boy? I have been working as a mud boy since takingpart in job.2.In the petroleum industry, what is mud? The fluid for cooling the bit is called mud.3.Who mixes the mud? Where is the mud mixed? The floormen mix it at the mud tanks.4.What is bentonite? Bentonite is a clay .It consists of calcium, magnesium and aluminum.5.How does the mud reach the bit? It passes through the hollow string.6.What method do you take to check the quantity of salt in the mud?7.How many tons of barite can be placed there?8.On the day there was some mud in the tank .How many water was there in that one? It isabout ten cubic meters.9.Will more salt water be needed? Yes. It needs 50 cubic meters more.10.Do you know how to keep this kind of mud material? Under no conditions should this kind ofmud material be put in the sun for too long. Otherwise its properties will go bad.11.Do you know how to use these mud materials? Before using these mud materials，we mustknow their properties.12.How long will it take you to clear the mud tank? This work takes up too much time to clearthe mud tank. It will take us about three hours.13.How often do you make an experiment with the mud properties? Every four hours.14.What is the name of the special fluid? This fluid is called mud.15.Who is the person in charge of the drilling fluid? This fluid is called mud.16.How do you check the mud from the bottom of the hole? First，waiting for the mud to travelfrom the bottom up through the annulus to the surface.17.Is the specific gravity of the drilling fluid programmed to be higher or lower than the specificgravity of the cuttings? Why? It must be higher so that it can hold the cuttings in suspension if the mud circulation stops.18.If for any reason the mud circulation stops, the cuttings will be held in suspension 。

钻井（Drilling）1、Carry out drilling operation in accordance with the drilling program. 按钻井程序进行钻井作业。

2、Prepare bell nipple. 准备“喇叭口”短节3、Make up 2 joints of drill pipe. 接两根钻杆4、Break out this connection. 卸开该接头。

5、Run hole opener to sea bed. 下扩眼器到海底。

6、Mix gel fluid for drilling conductor hole. 为钻导管井眼配制高粘度泥浆。

7、Make up bottom hole assembly (BHA). 组合下部钻具。

8、Check and reset crown-saver on every tour. 每个班都要检查并重新调整天车防碰装置。

9、Number stands on trip out and trip in. 起下钻进给立柱编号。

10、Pick up BHA and run to seafloor. 将下部钻具下到海底。

11、Pick up stands. 接立柱。

12、Don’t drill faster than 15 minutes for 1 stand. 钻进速度别超过15分钟1根立柱。

13、Drop TOTCO. 投（陶特）测斜仪。

14、Fish TOTCO with overshot. 用打捞筒捞起测斜仪。

15、Resume drilling to T.D. 继续钻进到总深。

16、Circulate 15 minutes. 循环15分钟。

17、Run in hole. 下钻。

18、Put out of hole. 起钻19、Make an inventory of all ring gaskets.开一个所有垫圈的清单。

第一章石油钻井工程英语基础第1节石油钻井工程基础词汇1.钻探，钻井：drill————拓展记忆钻井：drilling定向斜井directional drilling 欠平衡钻井under-balance 海上钻井off-shore陆地钻井on-land drilling 钻头：drill bit 刮刀钻头：drag bit 牙轮钻头rock bit 金刚石钻头diamond bit 喷射钻头jet bit 钻铤drill collar 衣领collar钻杆：drill pipe 钻井队drilling crew 钻机 drill rig 钻井泥浆drilling mud钻井液 drilling fluid2.油，石油：oil————拓展记忆原有 crude oil 石油 petroleum 中国石油 Petro-China 采油 oil production采油设备 oil production equipment 采油平台 oil production platform 油泵 oil pump 3.地质：geology————拓展记忆地质专业人员 geologist 物理 physics地球物理勘探 geo-physical probe，geo-physical exploration测井 logging 测井作业 logging operations 测井记录 logging record4.油井：well————拓展记忆井眼 hole 油井 oil well 试井，油井测试 well test 井下 down-hole井下作业 down-hole operation第2节石油钻井方法基础词汇原油 crude oil 天然气 natural gas 煤层气 coal-bed gas 一体化设计 integral design 钻井 drilling 钻井原理 the principles of drilling顿钻钻井 percussion drilling，cable-tool drilling 旋转钻井 rotary drilling液体冲击 fluid percussion 大位移 big deviation侧钻井 sidetracking drilling technology lateraldrilling水平井 horizontal well 探井 wildcat，wildcat drilling 深井 deep well 浅井 shallow well老井 maturing well 欠平衡钻井 under-balanced drilling 丛式钻井 cluster drilling technology煤层气井 coal-bed gas well 生产井 production wells 报废井 abandon wells停产井 non-production wells 绕障井、三维井 three-dimensional wells常温井 normal temperature well 注采井 injection and production well 稠油井 heavy oil well热洗井 hot washing pipe 井况 well condition石油钻井技术基础词汇技术规范，技术指标，技术性能：specification拉伸 tension 拉伸强度 tension strength 应力 stress 压力 pressure 应力点 stress point压力等级 pressure grade 压力降 pressure drop 压力梯度 pressure gradient回压 back pressure 大气压 atmosphere 压差 differential pressure静液柱压力 static fluid column pressure 特征 characteristic，feature定性讨论 qualitative argiment 定量使用quantitative use液体 liquid 固体 solid 气体 gas，air 正的positive 负的 negative虚线 dashed line，broken line 实线 full line 递减率 decline rate 正比于 be proportional to水平的 horizontal 垂直的vertical 油层静压 the formation static pressure石油钻井参数基础词汇负荷 load 扭矩 torque 扭转 twist 摩擦 friction钻压 WOB, weight on bit,weight, drilling weight钻速 rate of penetration, drilling rate, the rate of drilling, average ROP 钻井周期 drilling period钻速 rotary speed 地层压力预测 formation pressure prediction technology地层快速预测 the formation fast prediction 埋藏深度 bury depth产油层，产油带，pay zone，productive formation温度梯度 temperature gradient 地层压力 formation pressure 坍塌压力 collapse pressure破裂压力 fracture pressure 平衡压力 equilibrium pressure钻具（柱）压力 drilling string pressure 钻头振动 vibration of bit 钻井成本 drilling costs井眼尺寸 hole size，well size 参数计算 parameters calculation几何参数 geometric parameters 参数分析 parameter analysis 动态参数 dynamic data 静态监测 static data 注水参数 parameter of injection 参数、变量variables 井距well space垂直深度 vertical depth 水平位移 horizontal deviation 总深度 total depth水平位移 horizontal displacement 最大井斜角maximum hole inclination井眼环空 annulus space 压力调节器 pressure regulator 恢复（增加）压力the build-up pressure初始开采 primary recovery 含水地层 water bearing formation 套管漏失casing leak 摩擦损失 friction losses 气聚阀gas-lift valve 石蜡族 paraffin series含气液柱gas-laden column 增产措施stimulation treatment 流动能力flowing capacity生产速率 production rate 水驱 water drive 气驱 gas drive 网状系统 grid system水侵 water influx 五点法five-spot pattern 油井产量 well-productivity 径向流radial system富气 enriched gas 贫气lean gas 气顶 gas cap 气驱 gas drive（or gas flooding）水驱 water drive (or water flooding) 地层伤害 formation damage 波及系数 sweep efficiency泄油半径drainage radius 基岩处理matrix treatment 单级脱气single stage separation泄油面积drainage area 表面张力surface tension 束缚力connate water（or interstitial water）石油钻井作业现场工作人员名称1 钻井队 drilling crew 队、组 crew、team2 技术员 technician 钻井技术员 drilling technician 泥浆技术员 mud technician3 监督 supervisor 钻井监督 drilling supervisor 副监督 assisstant supervisor地质监督 geology supervisor4 工程师 engineer 泥浆工程师 mud engineer 泥浆工 mudman机械工程师 mechanic engineer 引擎、发动机 engine 工程 engineering钻井工程 drilling engineering 采油工程 production engineering石油工程 petroleum engineering 试油工程 oil test engineering拓展记忆---------------------------工作项目 project 希望工程 the hope project 三峡工程 the Three-Gorge Project项目经理 project manager 工程管理 project management 钻工：roughneck、floorman 司钻 driller 副司钻 assistant driller 钻井队长 drilling foreman 钻井领班 tool pusher井架工 derrick man 发动机工，机工 motorman 钻台工 floorman机械师 technicians，mechanic 电焊工 welder 电工electrician 医生 doctor材料员 material man，staff man 炊事员 cook 翻译 interpreter, tansalator洗衣工 laundry man石油作业现场常用工具石油作业现场普通工具扳手 wrench 螺丝起子 screwdriver 多角螺丝起子 Phlilips screwdriver活动扳手 monkey wrench，adjustable 钳子 pliers 手斧 hatchet 钩子 hook 台钳bench vice榔头 hammer 木锤 mallet 搬手 spanner 锯子 saw 电动手锯 jigsaw 电锯 power saw 钢锯hacksaw 硬尺rule 软尺tape measure 砂纸sandpaper 油漆paint 油漆刷paintbrush绝缘胶布 electrical tape 电线 wire 插头 plug 电插座 outlet 开关 switch 螺栓bolt螺帽 nut 钉子 nail 电钻 electric drill 钻头 bit 工作台 workbench 工具箱 toolbox 胶水 glue 交棒 glue bar 管钳 pipe tongs，pipe spanner，wrench链钳 chain tongs，chain spanner，chain wrench护丝 thread protector，screw protector 手轮 hand wheel 阀门搬手 valve wrench，valve spanner 链接法兰 coupling flange 安全带 safety belt 安全帽 safety cap 工作靴 working boots 千斤顶 jack 吊车 crane 拖拉机 tractor 推土机 dozer 刮刀 scraper1、石油作业现场专业工具接头 sub 配合接头 X-over，cross-over 提升短接 lifting sub，lifting nipple elevator 卡瓦 slip 母锥 box bell 公锥 taper tap 短节 joint 柔性短节 flex joint 井口wellhead螺旋钻铤 spiral collar 方钻杆 kelly 钻杆架 pipe rack 材料房 warehouse 绳卡 guyanchor润滑器 lubricator 维护保养 maintenance 内钳 lead tong 外钳 back-up tong液压大钳 hydraulic tong 兜绳 mule line 四通阀 four-way valve 软管 hose球阀 ball valve, globe valve 闸板阀 ram valve, gate valve 增压泵 booster pump 换配件 fittings change 灌注泵 charge pump第二章石油工程常用设备及专业术语第1节钻井设备部分1 井架 derrick 塔形井架 derrick A形井架 cantilever mast，mast-A 桅杆 mast底座大梁 sill 架，台 rack 架工操作台 monkey-board2 游动系统 travelling systemn 天车 crown block 天车梁 crown block beam游动滑车 travelling block 钻井大绳 drilling line, wire line 金属线, 电线 wire，line钢丝绳，测井电缆 wire line 金属线，电线 wire，line 钢丝绳股 strand 截断 cutoff 滑车，滑轮，皮带轮 pulley 吊耳 eye plate3 大钩与水龙头 hook and swivel 顶驱 top drive 大钩 hook 大钩弹簧 hook spring大钩销子 hook pin 大钩环 hook ring 大钩锁紧装置 hook locking device大钩悬挂高度 hook height 水龙头 swivel 鹅颈管 gooseneck 冲管 wash pipe水龙头盘根 swivel packing 钻井水龙带 drilling hose，rotary hose，kelly hose 立管stand pipe高压管线 high pressure line 低压管线 low pressure line 放压管线 relief line储气筒 gas holder，air holder4 转盘 rotary table 转盘方瓦 master bushing 方补心 kelly drive bushing方孔 square openning 小鼠洞 mouse hole 大鼠洞 rat hole （井架大门处）坡板 ramp 5 绞车drawworks，hoist 液压绞车hydraulically-powered winch 气动绞车air operated hoist绞车 hoist，windlass，drawworks 滚筒线轴卷轴 reel pool drum滚筒高速气离合器 drum high air clutch 滚筒低速气离合器 drum low high clutch猫头 cathead 液压猫头 hydraulic cathead 上扣猫头 make up cathead卸扣猫头 make out cathead 牙嵌离合器 jaw clutch 应急牙嵌离合器emergency jaw clutch涡磁刹车 eddy current brake 猫头轴 cathead shaft 猫头绳 cathead line猫头绳爪 cat line grip 死绳 dead line 死绳固定器 deadline anchor死绳固定器膜片 dead line diaphragm 上扣 spin up，screw on 卸扣，卸开 break out, screw off上紧，固定 tighten 松开，松扣 loosen 加载 load 卸载unload 拧紧 screw 拧松unscrew刹者 brake 刹车总成 brake assembly 刹车轴 brake axle，brake shaft 刹车带 brake band刹车片 brake band lining 刹车杆 brake bar 闸瓦 brake block 刹把 break crank，brake bar刹车鼓 brake drum 离合器 clutch 液压油箱 hydraulic reservoir液动试压泵 hydraulic test pump 液压大钳 hydraulic tong 倒档齿轮 reverse gear第2节钻井泵类及相关设备泥浆泵 mud pump，drilling pump，slush pump 活塞 piston 活塞杆 piston rod活塞皮瓦 piston cup 缸套 liner，pumpliner 凡尔体 valve body 凡尔座 valve cup 阀弹簧 valve spring 阀杆 valve lever 阀面 valve face 阀帽 valve bonnet泥浆泵安全阀 mud relief valve 排出阀 discharge valve 吸入阀 suction valve潜水泵 submersible pump 阀门 valve 阀盖 valve cap 阀座 valve seat 回压阀回压阀 back pressure valve 单向阀 check valve single-pass valve 安全阀 safety valve手动阀 manual valve 液动阀 hydraulic valve 冷缸cold cylinder 拉杆 tie rod，tension bear上水头 intake，suction end 排出口 discharge spout 高压管 high pressure压力表 pressure gauge 冲数 strokes 排量 displacement，discharge capacity，flow rate第3节井下泵类及相关设备泵筒 pump barrel 柱塞 plunger 关闭 shut down 尾管 tail pipe 抽油杆 sucker rod 长冲程 long stroke 低泵速 small pumping speed 泵充满度 the fullness efficient of the pump抽油杆 sucker rod 排气方法 gas bleeding method 泵效 pump efficiency三维空间 three dimensional space 有效生举 efficient lift for the deviated抽油杆扶正工具 sucker rod centralization tools 严重的管杆偏磨 serious string partial wear游动阀 the travelling valve 固定阀 the standing valve 部分磨损、偏磨 partial wear 无杆泵 rodless pump 小泵深抽 small pump deep pumping technology挂泵深度 pump setting depth 尾管长度 length of liner 管柱结构 the structure of pipe string防脱器 dropout-prevent device 井斜角hole angle 电热杆 borehole electric heating rod稠油开采 heavy oil production 空心杆热载体 hollow sucker rod heat carrier变扣器方补芯 bushing 终端器 terminal assembly 空心抽油杆 hollow sucker rod整体电缆传感器 continuous cable，sensor 空心光杆 hollow polish rod 悬挂器 hanger 防喷盒 stuffing box第4节采油设备采油树 Christmas tree 抽油机 pumping unit 往复运动 reciprocating motion泵杆 pumping rod 机械传动 mechanical transmission 载荷能力 peak polish rod load 系统效率 system efficiency 冲程stroke length 冲次 frequency of stroke无级可调 smooth regulation 沉降式抽油泵 the sinking sand pump 泵下沉砂 sinking 砂颗粒sand particles 胶质沥青gum asphalt含蜡量paraffin content 凝固点solidification point热流 hot fluid 参水mingle water第5节与泵操作有关的使用短语没有压力 no pressure 压力过高 the pressure is too high 返回太少 mud return is few 水太少 water is little 抢修 rush to repair 请看记录 please read the record没作记录 no record 加化学小品 put in chemicals 加高岭土粉 put in koaline powder 加云母片 put in mica sheet 加增粘剂 put in viscosifier 加稀释剂 put in diluent （thinner）加稳定剂 put in stabilizer（stabilizing agent）加烧碱 put in caustic soda测定比重 measure gravity，gravity test 测定失水 test filtration 测定切力 measure force开关 switch 停泵 stop the pump 请打手势 please make a gesture转动一周 turn round a circle 垫高一些 put something under it to raise 抓紧 firmly grasp抬高 lift it up 拿稳 hold firm 打一下 strike once 往下拉 pull out站稳 stand firm take a firm hand 小端 small end 大端 large end 光滑 smooth粗糙 rough,coarse 平面plane，flat 弯曲 winding，bending 放松 loosen绷直 stretch tight，draw tight 撬棍 pinch bar，pry bar 充氨气nitrogen aeration 气包 snubber冷却 cooling 润滑 lubricate 过载 overload 功率不足 inadequate power，power is not enough第6节钻台与底座钻台 drilling floor，derrick floor，rig floor 钻井记录drilling record司钻监视器driller’s monitor 司钻控制台driller’s console 指重表weight indicator转盘 rotary table 卡瓦 slip 吊卡 latch elevator 底座 substructure 井队活动房bunkhouse 钻台上值班房 doghouse 立根盒setback （place）立根盒容量setback capacity 井控设备 well-control device第7节防喷器万能防喷器 versatile blowout preventerBag type BOP单闸板防喷器 single ram preventer 双闸板防喷器 double ram preventer 闸板 pipe ram 全封闭式防喷器 blind ram 蓄能器 energy accumulator 压井管线 kill line 入口 inlet 出口 outlet 演习 drill 消防演习fire drill 防喷演习BOP drill防腐涂料油管 anti-corrosion coating material tubing 多功能管柱 multi-function string第三章钻井工程作业部分第1节钻井事故泄漏 leak 漏失 fluid loss 出砂 sand production 井喷 blow out 井涌 kick，flow off 井漏 lost of circulation，circulation lost坍塌，井壁坍塌 caving，cave in，collapse 出砂 sand production，sand flow 桥塞 bridge plug 砂桥 sand bridge 井堵 wellclogging卡钻sticking 卡钻杆 sticking the pipe 卡钻具sticking the drill stem 打捞fishing打捞工作 fishing job 侧钻 side-tracking 侧钻井眼 sidetracking hole水泥窜槽cement channeling 固井失败 cement failure 防砂 sand control，sand-proof第2节钻头牙轮钻头 rock bit，tooth-wheel bit 刮刀钻头 drag bit 金刚石钻头 diomand bit镶齿钻头 tungsten carbide bit，insert bit 喷射钻头 jet bit 铣齿钻头milled bit 牙轮 cone钻头装卸器 bit breaker 钻头直径 bit diameter 钻头寿命 bit life 钻头规格bit gauge 钻头磨损bit wear 钻头型号bit type 水眼尺寸nozzle size 水眼效率nozzle efficiency钻头接头 bit sub第3节钻具方钻杆kelly 方钻杆旋转短节 kelly spinner 方钻杆考克（旋塞）kelly cock 接头 sub 钻头接头 bit sub 钻具 drill stem，drilling string 钻杆drill pipe 管子 tube，pipe 钻具组合 drilling assembly 扶正器 stabilizer，centering guide 翼状扶正器 wing stabilizer扩眼器 reamer drill collar 无磁钻铤 drill collar 加重钻杆 heavy weight drill pipe 近钻头扶正器 near-bit stabilizer 绕性接头 flexible joint 震击器 jar 减震器 shock absorber螺旋钻铤 spiral drill collar 键槽破坏器 key seat reamer 安全接头 safety joint 钻杆刮泥器 drill pipe wiper 配合接头 crossover sub 减震器 shock sub井下钻具组合 BHA-bottom hole assembly泥浆动力钻具 mud motor 管线tubeline 钻柱 drill string 涡轮 tubine涡轮钻具 turbo-drill stem 斜度 taper，slope 塔式钻具tapered drill stem 接头 a joint，sub管接头 a joint of pipe 立根 stand，a stand，thribble 加厚 upset 内加厚 internal upset外加厚 external upset 内外加厚internal-external upset 丝扣 thread 母扣 box 公扣pin左旋螺纹left-hand thread 右旋螺纹 right-hand thread 正规接头 regular joint贯眼接头 full hole joint 内平接头 internal flush joint 护丝 thread protector 丝扣油 thread dope，thread oil 打捞篮 junk basket 打捞工具fishing tool打捞管柱 fishing string 打捞公锥 fishing nipple 打捞颈 fishing neck 打捞头fishing head 打捞作业 fishing operation 打捞母锥 fishing socket 牙轮打捞器 cone fisher倒扣工具 reversing tool 卡瓦打捞筒 slip socket 铣鞋 milling shoe 铣具 milling tool平底铣鞋 flat bottom mill 磁力打捞工具 magnetic fishing tool 套管打捞矛 casing spear打捞矛 fishing spear 打捞钩 fish hook 套管打捞筒 casing bowl 动力扳手 power wrench动力大钳 power tong 大钳活动牙块 hinged jaw 大钳锁销 latch 大钳悬臂 suspension unit气动工具pneumatic tool 打捞震击器 fishing jars 打捞缓冲器 fishing bumper sub 打捞环 die collar 打捞筒overshot 打捞短节junk sub 卡瓦slips 刮井器 scatcher 刮眼器扩井器 wiper 油位检查丝堵 oil lever check plug 油位 oil lever油尺 oil-lever dipstick 加油孔 lubrication hole 盘根盒 stuffing box 井筒工具well bore tool配套工具 matching tools 滚轮扶正器 idler wheel centralizer 减磨短节 friction reduction sub轴线加压 hydraulic thruster 扶正器 centralizer 防脱器、装置 anti-slip device 减磨扭矩接箍 torque-reduction sub 减扭接头 torque reduction sub轴向水力加压工具 hydraulic thruster 下套管漂浮接箍 casing floating coupling轴向加压器 hydraulic thruster第4节钻井工程地面作业实用词汇与短语方入 kelly-in 方余 kelly-up 开钻 spud in，starting drilling 作业指令 working instruction起钻 POOH=pull out of the hole 下钻 run in the hole 起下钻 make a trip 短起下钻short trip通井 wiper trip 起下循环一周 round a trip 循环时间 round time，circulating time 换钻头 change bit 甩钻具 laydown 填井 pack-hole封井 packed drilling发生故障 break down 接单根 connection 放卡瓦 set slip，setting slip，起卡瓦 pull slip扩眼 openning 划眼 reaming 二层台 double monkey board，runround 顶部驱动器 top drive吊环bail 吊卡elevator 安全卡瓦safety slips 接头sub adapter 短节sub substitute井下震击器 downhole（bumper）jar，down well shaker 打捞工具 fishing tool三片卡瓦 three slips，three pieces 补芯 bushing 方补芯 kelly drive bushings转盘补芯（大方瓦）rotary drive bushing 转盘刹车 rotary brake 丝扣油 thread lubricant oil刹把 brake crank，brake bar，brake lever 脚踏开关 pedal switch 挂档put into gear 拉猫头cathead 内钳 back-up tongs 外钳 lead tongs 气动大钳 pneumatic tongs 液压大钳 hydraulic tongs 机械手 mechanical arm 铁钻工 machine hand 司钻房driller room有故障 it has broken down, it has something wrong 已修好 the breakdown has been fixed马上去 go there at once 请下去 please go down 请上来 please come up躲开，危险 get out，danger 请翻译来 ask the interpretor to come here 冲洗 flushing 井口 well-head（well head）井下落物fish 一根钻杆（单根）single（pipe）三根钻杆组合（立根）thribble 甩单根 breaking down 接单根 make a connection气动绞车 pneumatic drawworks 吊篮 basket 卡子 clamp 绳套 rope sling loosening 紧固tightening 挪开 move it off 换班 change， shift 保养设备maintain equipment 钻井日志 boring journal，boring log 油管悬挂器 tubing hanger第5节钻井工程井口作业实用词汇与短语喇叭口 bell mouth，flare opening 贮能器 accumulater 液压阀 hydraulic valve液压管 hydraulic hose 阻流管 choke line 井控管汇 well control manifold泄压阀 pressure relief valve 调压针阀 pressure regulating needle valve回压阀backpressure valve 井口螺丝 the bolt of wellhead 井口绞车well head drawworks水刹车 water brake，hydraulic brake 电缆（electric）cable 井口压力wellhead pressure隔水导管 conductor riser 小心滑倒 Guard against slipping 不要掉下去 Take care not to fall down 我来清理 let me clean up 带把扳手来bring a spanner，please 带把铁锤来 bring a hammer，please. 带点密封剂 bring a little sealant，please 带个密封圈 bring a sealing washer用起子撬 prize with （using）screwdriver 用手推注 push by hand 卸下来了 it has been removed off 装配好了 it has been assembled 很快就好了 it will be finished right away抬一下 let’s lift it 上紧螺丝tighten the screw loosen 松开螺丝 loosen the screw 把绳子给我 give me the rope，please 把绳子拿走take the rope away。
