AIRBUS MECHANICAL DRAWINGS

AIRBUS INDUSTRIE

AIRBUS CUSTOMER SERVICES DIRECTORATE

DRAWING SET USER GUIDE

MECHANICAL DRAWINGSDRAWING SET USER GUIDE

The content of this document is the property of Airbus Industrie. It is

supplied in confidence and commercial security on its contents must be

maintained.

It must not be used for any purpose other than that for which it is

supplied, nor may information contained in it be disclosed to unauthorized

persons.

It must not be reproduced in whole or in part without permission in writing from

the owners of the copyright.

© Airbus Industrie 1992 - All rights reserved

Airbus Industrie

Customer Services Directorate

Technical Publications Department

31707 Blagnac Cedex

FRANCE

Drawing Set User GuideDSUG

Page: TOC 1

Issue: 06Date: JAN 97TABLE OF CONTENTS

1 -INTRODUCTION...................................................................................................................1

LIST OF ABBREVIATIONS...................................................................................................2

2 -THE DRAWING SET PACKAGE...........................................................................................3

2-1 -Description..................................................................................................................3

2-2 -The picture sheet........................................................................................................4

2-3 -The Schedule...............................................................................................................8

2-4 -The Parts Usage (PU)..................................................................................................15

2-5 -The Drawing Numerical Index (DNI)...........................................................................21

3 -DRAWING NUMBERING.......................................................................................................22

3-1 -Drawing Number Breakdown.....................................................................................22

3-2 -The Drawing Number..................................................................................................23

3-3 -The Part Number (PIN)................................................................................................23

4 -HOW TO USE THE DRAWING SET......................................................................................24

4-1 -How to search for a drawing number........................................................................24

4-2 -How to move within the drawing set.........................................................................24

5 -HOW TO MAINTAIN/UPDATE THE DRAWING SET............................................................25

6 -APPENDICES........................................................................................................................A01

1 - DRAWING APERTURE CARD (DAC)..........................................................................A03

2 -USE OF DRAWING SCHEDULE AND PICTURE SHEET............................................A05

- Examples.....................................................................................................................A07 TO A12

3 -USING THE PARTS USAGE........................................................................................A13

- Example.......................................................................................................................A15-A16

4 -GENERAL ASSEMBLY DRAWING.............................................................................A17

- Example.......................................................................................................................A19 TO A22

Drawing Set User GuideDSUG

Page: 1

Issue: 06Date: JAN 971 - INTRODUCTION

AIRBUS INDUSTRIE provides its customers with a customized set of engineering drawings. It

includes mechanical drawings for all major aircraft assemblies and installations (IAD).

All data related to aircraft wiring and equipment are contained in the wiring manuals. AIRBUS

INDUSTRIE non proprietary parts or items are not included.

The drawing set generally is delivered in two stages:

- basic set at aircraft delivery

- complementary drawings 6 months after first aircraft delivery.

The drawings set reflects the aircraft configuration at delivery. It is not subject to a regular

revision service but will be updated to incorporate additional aircraft, on the base of a bi-annual

customization cycle by aircraft family:

- A330/A340 Drawing set=February, August

- A319/A320/A321 Drawing set=April, October

- A300/A310/A300-600 Drawing set =June, December

The drawing set is supplied on 35 mm film aperture card.
