PHOENIX CONTACT GmbH & Co. KGPage 1 / 7http://www.phoenixcontact.de

Mar 11, 2008Extract from the onlinecatalog FKCT 2,5/ 3-ST-5,08Order No.: 1902123The figure shows a 10-position version of the producthttp://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1902123 Plug component, nominal current: 12 A, rated voltage: 250 V,pitch: 5.08 mm, no. of positions: 3, type of connection: Spring-cageconnection Commercial dataEAN4017918187279Pack50 Pcs.Customs tariff85366990Weight/Piece0.00565 KGCatalog page informationPage 187 (CC-2007)Product notesWEEE/RoHS-compliant since:01/01/2003http://www.download.phoenixcontact.comPlease note that the data givenhere has been taken from theonline catalog. For comprehensiveinformation and data, please referto the user documentation. TheGeneral Terms and Conditions ofUse apply to Internet downloads.Technical dataDimensions / positionsPitch5.08 mmDimension a10.16 mmNumber of positions3元器件交易网www.cecb2b.comFKCT 2,5/ 3-ST-5,08Order No.: 1902123http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1902123

PHOENIX CONTACT GmbH & Co. KGPage 2 / 7http://www.phoenixcontact.deMar 11, 2008Technical dataInsulating material groupIRated surge voltage (III/3)4 kVRated surge voltage (III/2)4 kVRated surge voltage (II/2)4 kVRated voltage (III/2)320 VRated voltage (II/2)630 VConnection in acc. with standardEN-VDENominal current IN12 ANominal voltage UN250 VNominal cross section2.5 mm2Maximum load current12 AInsulating materialPAInflammability class acc. to UL 94V0Internal cylindrical gageA2Stripping length10 mmConnection dataConductor cross section solid min.0.2 mm2Conductor cross section solid max.2.5 mm2Conductor cross section stranded min.0.2 mm2Conductor cross section stranded max.2.5 mm2Conductor cross section stranded, with ferrulewithout plastic sleeve min.0.25 mm2Conductor cross section stranded, with ferrulewithout plastic sleeve max.2.5 mm2Conductor cross section stranded, with ferrulewith plastic sleeve min.0.25 mm2Conductor cross section stranded, with ferrulewith plastic sleeve max.2.5 mm2Conductor cross section AWG/kcmil min.24Conductor cross section AWG/kcmil max122 conductors with same cross section, stranded,TWIN ferrules with plastic sleeve, min.0.5 mm22 conductors with same cross section, stranded,TWIN ferrules with plastic sleeve, max.1.5 mm2元器件交易网www.cecb2b.comFKCT 2,5/ 3-ST-5,08Order No.: 1902123http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1902123

PHOENIX CONTACT GmbH & Co. KGPage 3 / 7http://www.phoenixcontact.deMar 11, 2008Certificates / ApprovalsApproval logo CULNominal voltage UN300 VNominal current IN10 AAWG/kcmil26-12ULNominal voltage UN300 VNominal current IN10 AAWG/kcmil26-12CertificationCB, CUL, GOST, UL, VDE-PZIAccessoriesItemDesignationDescriptionAssembly1876880STZ 8-FKC-5,08Strain relief for snapping into the latching chambers of the plugcomponents, 8-pos.1876877STZ 4-FKC-5,08Strain relief for snapping into the latching chambers of the plugs,4-pos.Marking0804293SK 5,08/3,8:FORTL.ZAHLENMarker card, printed horizontally, self-adhesive, 12 identicaldecades marked 1-10, 11-20 etc. up to 91-(99)100, sufficient for120 terminal blocks0805085SK 5,08/3,8:SOMarker card, special printing, self-adhesive, labeled acc. tocustomer requirements, 12 identical marker strips per card, max.25-position labeling per strip, color: white0805412SK 5,08/3,8:UNBEDRUCKTMarker cards, unprinted, with pitch divisions, self-adhesive, 10-section marker strips, 12 strips per card, can be labeled with theM-PENPlug/Adapter1734634CP-MSTBCoding profile, is inserted into the slot on the plug or invertedheader, red insulating material元器件交易网www.cecb2b.comFKCT 2,5/ 3-ST-5,08Order No.: 1902123http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1902123

PHOENIX CONTACT GmbH & Co. KGPage 4 / 7http://www.phoenixcontact.deMar 11, 20080201689MPS-IH BUInsulating sleeve (blue), for MPS metal part to be orderedseparately (0201744)0201702MPS-IH GNInsulating sleeve (green), for MPS metal part to be orderedseparately (0201744)0201676MPS-IH RDInsulating sleeve (red), for MPS metal part to be orderedseparately (0201744)0201663MPS-IH WHInsulating sleeve (white), for MPS metal part to be orderedseparately (0201744)0201744MPS-MTTest plug, consisting of: Metal part for 2.3 mm diameter sockethole0201647RPSReducing plug, for transition from 4 mm diameter test plug socket,insulation: grayTools1205053SZS 0,6X3,5Screwdriver, bladed, matches all screw terminal blocks up to 4.0mm² connection cross section, blade: 0.6 x 3.5 mm, without VDEapprovalAdditional productsItemDesignationDescriptionGeneral1872473A-MSTBVA 2,5/ 3-G-5,08Header, nominal current: 12 A, rated voltage: 250 V, pitch: 5.08mm, no. of positions: 3, mounting: Mounting rail0707251DFK-MSTB 2,5/ 3-G-5,08Header, nominal current: 12 A, rated voltage: 320 V, pitch: 5.08mm, no. of positions: 3, mounting: Direct mounting1898842DFK-MSTBA 2,5/ 3-G-5,08Header, nominal current: 12 A, rated voltage: 250 V, pitch: 5.08mm, no. of positions: 3, mounting: Soldering1899142DFK-MSTBVA 2,5/ 3-G-5,08Header, nominal current: 12 A, rated voltage: 250 V, pitch: 5.08mm, no. of positions: 3, mounting: Soldering1880313EMSTBA 2,5/ 3-G-5,08Header, nominal current: 12 A, rated voltage: 250 V, pitch: 5.08mm, no. of positions: 3, mounting: Press in1859522EMSTBVA 2,5/ 3-G-5,08Header, nominal current: 12 A, rated voltage: 200 V, pitch: 5.08mm, no. of positions: 3, mounting: press in1873362FKIC 2,5/ 3-ST-5,08Plug component, nominal current: 12 A, rated voltage: 320 V,pitch: 5.08 mm, no. of positions: 3, type of connection: Spring-cage connection1786187IC 2,5/ 3-ST-5,08Plug component, nominal current: 12 A, rated voltage: 250 V,pitch: 5.08 mm, no. of positions: 3, type of connection: Screwconnection1823859ICC 2,5/ 3-STZ-5,08Plug component, nominal current: 12 A, rated voltage: 250 V,pitch: 5.08 mm, no. of positions: 3, type of connection: Crimpconnection元器件交易网www.cecb2b.com
