注塑专业英语词汇1

模具专业术语英语
模具专业涉及许多专业术语，在英语中对应的词汇如下：
1. Mold/Mould: 模具
2. Die: 模具，尤指金属冲压模
3. Cavity: 模穴
4. Core: 模芯
5. Runner: 喷嘴，注塑道
6. Gate: 浇口，进料口
7. Ejector Pin: 顶针，用于将制品从模具中推出
8. Injection Molding: 注塑成型
9. Blow Molding: 吹塑
10. Compression Molding: 压缩成型
11. Extrusion Molding: 挤出成型
12. Casting: 铸造
13. Hot Runner: 热流道系统
14. Cooling Channel: 冷却通道
15. Draft Angle: 脱模锥度
16. Shrinkage: 收缩率
17. Surface Finish: 表面处理/光洁度
18. Undercut: 模具槽，模具凹槽
这些词汇在模具制造和加工过程中经常使用，涵盖了模具设计、制造和加工等方面的专业术语。

注塑专业英语Surface Appearance 外观Glossiness/gloss finish 光洁度Matt finish/matt surface 毛面Glass fiber rich surface/glass emergence on the surface 玻纤外露Blooming/surface blooming 表面析出White patches on surface 表面白斑Silver marks/silver streak 银纹Splay mark 水纹Flow mark 流纹Weld line 溶结纹Brittle/brittleness 脆Bubbles/trapped gas 气泡Void 孔Burn marks 烧伤FR failed 阻燃不合格Flame rating V-2 阻燃V-2Poor dispersion 分散不好FR/PTFE …agglomerates etc 阻燃剂/PTFE…结块Pellet porous 粒子不密/蜜蜂窝Low impact/tensile etc 物理性能低High flow/filler content etc 流动性/填充…过高Longs/fines/doubles 长粒/碎屑/连粒Poor cut 粒形不好Bristle/voids 表面有小气泡/孔Glass bundles 玻纤结团Product was rejected due to 产品不能接受因为…High moisture level 高水分Warpage/warped 翘曲Shrinkage/shrink 收缩Sink marks 缩影Short shot/short molding 打不满Distortion 变形Over dimension 尺寸过大Under dimension 尺寸过小Flashing 飞边Discoloration 变色Off color 颜色差异Flow rate 流动率Viscous 粘High flow 高流动Low flow 低流动Sticky 粘Mold release 脱模Antioxidant 抗氧剂Flame retardant agent 阻燃剂Heat stabilizer 热稳定剂Chopped glass fiber 短切玻纤Roving glass fiber 粗纱/长玻纤Glass beads 玻璃微珠Milled fiber 碾磨纤Molybdenum disulfide/moly/MoS2 二硫化钼Colorant 着色剂Pigment 颜料Dye 染料Accepted product specification 接受产品规格Approved our product 认可我们的产品Re-set spec 重新定标准Add in extra …添加多一点…Reduced …content 减少…含量Dropped/reduced …by x％减少…含量…％Confirmed color standard 确认颜色标准Approved color standard 认可颜色标准Re-confirmed color standard 重新确认颜色标准Qualified our product 认可我们的产品Undergoing heat aging test 在做热老化实验Product is under testing 产品在测试当中Received first order 接了第一个定单Expected to finish by …预计在…完成Expected order is xMT 预计定单量…吨Estimated annual/monthly consumption 预计年/月用量成型工艺流程及条件介绍Molding technique procedure and parameter introduction第一節成型工艺Section 1 molding technique.1.成型工艺参数类型Sorts of molding parameter.(1).注塑参数Injection parameter.a.注射量Injection rate.b.计量行程Screw back positionc.余料量Cushiond.防诞量Sucking back ratee.螺杆转速Screw speedf.塑化量Plastic0 rateg.预塑背压Screw back pressureh.注射压力和保压压力Injection pressure and holding pressurei.注射速度Injection speed(2)合模参数Clamping parametera.合模力Clamping forceb.合模速度Clamping speedc.合模行程.Clamping stroked.开模力Opening forcee.开模速度Opening speedf.开模行程Opening positiong.顶出压力Ejector advance pressureh.顶出速度Ejector advance speedi.顶出行程Ejector advance position2.温控参数T emperature parametera.烘料温度Dry resin material temperatureb.料向与喷嘴温度Cylinder temperature and nozzle temperaturec.模具温度Mold temperatured.油温Oil temperature3.成型周期Molding cyclea.循环周期Cycle timeb.冷却时间Cool timec.注射时间Injection timed.保压时间Holding pressure timee.塑化时间Plant timef.顶出及停留时间Knocking out and delay timeg.低压保护时间Mold protect time成型工艺参数的设定须根据产品的不同设置.Molding technique parameter setting differs depending on type of product 成型条件设定Section 2 Molding parameter Setting按成型步骤:可分为开锁模,加热,射出,顶出四个过程.Molding steps: mold opening/closing, heating injection and knocking out.开锁模条件:Mold opening parameter:快速段中速度低压高压速度High-speedmid-speedLow pressure high pressure speed锁模条件设定:Mold closing parameter setting1锁模一般分:快速→中速→低压→高压Mold closing: high-speed →low-speed →low pressure→high pressure2.快锁模一般按模具情况分,如果是平面二板模具,快速锁模段可用较快速度,甚至于用到特快,当用到一般快速时,速度设到55-75%,完全平面模可设定到80-90%,如果用到特快就只能设定在45-55%,压力则可设定于50-75%,位置段视产品的深浅(或长短)不同,一般是开模宽度的1/3.In high-speed section, Mold closing speed depends on type of mold. For two –plate mold it can set quick and even especially quick usually, it set speed within 55-75%. For full-plate mold it set speed within80-90% while using especially high speed it set speed within 45-55% and pressure within 50-75% position distance setting differs depending on the volume of product and usually it can be set 1/3 of mold opening position.3.中速段,在快速段结束后即转换成中速,中速的位置一般是到模板(包括三板模,二板模)合在一块为止,具体长度应视模板板间隔,速度一般设置在30%-50%间,压力则是20%-45%间.In mid-speed section: Mold closing speed changes into mid-speed after high-speed section finish. Mid-speed start position is where two plates meet (include three-plate mold and two-plate mold ) Distance of mid-speed is up to distance of two plates plate it speed within 30-50% and pressure 20-45%.4.低压设定,低速设定一般是在模板接触的一瞬间,具体位置就设在机台显示屏显示的一瞬间的数字为准,这个数字一般是以这点为标准,,即于此点则起不了高压,高于此点则大,轻易起高压.设定的速度一般是15%-25%,视乎不同机种而定,压力一般设定于1-2%,有些机则可设于5-15%,也是视乎不同机种不同.Low-pressure section: Mold closing sets low-pressure when plates meeting. This position is set to the data of machine screen on this time. This point is the gage of the data. Data lower the point there is no high-pressure. Data higher the point there is high-pressure easily. It setspeed within 15-25% and pressure within 1-2% depending on type within 1-2% depending on type of injection molding machine.5.高压设定,按一般机台而言,高压位置机台在出厂时都已作了设定,相对来讲,是不可以随便更改的,比如震雄机在50P.速度相对低压略高,大约在30-35%左右,而压力则视乎模具而定,可在55-85%中取,比如完全平面之新模,模具排气良好,甚至于设在55%即可,如果是滑块较多,原来生产时毛边也较多,甚至于可设在90%还略显不足.High-pressure section: To normal injection molding machine, high-pressure position had been set before they were sent to customer. It can not be modified. For example high-pressure position of CHENHSONG machine is 50P.The speed of high-pressure section is about 30-35% and higher than that of low-pressure. The pressure is up to mold, it can set within 55-85% For full-plate mold, it‟s eject air well, it can set pressure 55% .If mold has a lot of slides and flash rate high in production, pressure can set 90%.加热工艺条件设定Heating technique parameter setting1.加热段温度设定必须按照产品所使用的原料的不同而不同,但却必须遵循一个这样的规则,即由射口筒到进科段温度是逐步递减的.且递减温度是以10.度为单位.The proper temperature setting differs depending on type of resin material, but it must be abide by a rule that temperature setting should diminish in step 10.C from nozzle to feeding resin material position.2特殊情况下.如料头抽丝,则射口筒温度应降低,如果是比较特殊的原料冷凝比较快的.则射口筒温度则不止比第二节法兰温度高10度.比如PPS.尼龙等.Nozzle temperature setting should low if product line. If resin material such asPPS, PA, cool very soon , Nozzle temperature should higher more 10.C than the second cylinder temperature.3.机台马达启动温度视乎机台不同而不同,一般出于对机台油路中的油封保护需要,油温最好能控制在40度-60度,以免油封长期高压而变化,缩短使用寿命,造成成型不稳定.Pump turning on temperature is different depending on type of injection molding machine. T o protect oil seal of machine it set oil temperature within 40.C-60.C, If oil seal work on condition that high pressure and damaged It‟s work time will be shorter, it can cause molding stable第三节常见塑料原料的有关温度值.原料Resin名称Name熔点℃Melt‟s成型温度℃Molding T emperature(‟c)分解温度℃Decomposing T emperature(…C)模具温度℃Mold T emperature(…c)干燥温度℃Resin dry temperature(…c)注射是把塑料原料经加热后射进模腔的过程,它一般可分为第一级,第二级,第三级,第四级及保压几段:Injection is a step which inject melt resin material into mold. It consists of stepl,step2 ,step3,step4 and holding pressure step:1.第一级注射一般是注射料头段.具注射量一般可根据料头的轻重来估计其行程,当然也可以依据公式来计算,如公式:Step l injects usually tunnel material, Injection Volume can be estimated according to the weight of course it can be calculated by formula:L=Si=Vi/0.785Ds2L:注射行程; Si:注射行程;L: injection stroke Si: injection strokeVi:理论注射容积; Ds:螺杆直径;Vi: injection volume of theoretical Ds: diameter of screw0.785:是Ω/4的值.0. 785: value ofΩ/4.当然,如果我们在成型时每设定一个参数都要计算一次,要成型出一个产品就要几个小时才能完成了.But it cost a lot of time to produce one product if every time molding parameter is setting by calculation.2.第二级是注塑产品约2/3的阶段,当然,根据产品特殊需要,也允许成型不到2/3阶段,比如避免结合线问题,这一阶段的成型速度及压力一般是整个成型段的最大值段,如果排的产品与机台基本是相吻合的.模具结构合理,排气良好,这一段的压力一般也不会超过80%.速度侧视产品需变,可能大到95%也可,自然一般都是在55%-80%间.Step 2 inject 2/3 of product. It can lower 2/3 of product according to requirement of product. For example to prevent weld line. Molding speed and pressure on this step is the maximum of whole molding section. If Mold suit the injection molding machine and mold structure reasonable and eject air well, pressure of this step should lower 80%. Molding speed setting within 55-80% but it may setting 95% for especial product.3.第三段是注射余下的1/3段,其速度和压力根据产品的需要,一般是小于第二段,速度和压力存在于一个往下降的过程.主要是为了防止产品毛边的产生,但同时又必须把产品充填饱满.Step3 inject remain 1/3 of product. According to product molding speed and pressure lower than that of step2 To prevent flash speed and pressure should decrease but it can‟t shot short.4.第四段:一般有机台还有第五,第六段,这段的成型速度和压力相同前,都存在两段一个递减过程.其作用都是起到一个再次充满的作用.Step4 section: Some injection machines have step5,step6 which are same as former molding speed and pressure this step should diminish and inject once more.5.保压段:不论成型什么产品,都存在一个保压过程.任何产品都不同程度的存在一个厚薄不一的问题,正常情况下,较厚的部分都可能存在一个收缩凹陷的现象,为了解决这种现象,就应应用到保压,保压一般来讲都应用较慢的射速,而压力的设置则应看缩水的情况如何,小到25%,大到80%都有可能.Holding pressure step: No matter what product there is a holding pressure step. Any product can‟t molding a same thickness. Usually the deeper section may sink mark . T o prevent this defect it should set holding pressure, The injection speed of holding pressure step is slow but holding pressure setting within 25-80% depending on sink mark.二.熔胶段工艺Plastic T echnique1.再复杂的熔胶旋转过程最多不会超过三段,因为熔胶本身就是存在于把胶熔进料筒的过程,如果原料粘度大,熔胶压力则大,但速度则应取决于原料的分解温度,熔胶速度越快,原料中的剪切力则会越大,料管温度则越高,局部原料产生分解的可能性则会越大,故一般熔胶会采用中速为宜,如45%-75%,熔胶同时会碰到一个比较重要的环节,那就是背压的使用,产品精度要求越大,背压的使用则更大,背压可使原料分子间结构更紧密,成型出的产品则尺寸更稳定,外观越好.当然,背压太大,则会产生流涎,所以背压的使用又应考虙到其它原因.Plastic should lower 3 steps, because plastic is a step to add melt resin material to cyclinder , Higher stick of resin material ,higher screw back pressure. Screw speed differs depending on decomposing temperature of resin material ,Higher screw speed ,Higher trim force of resin, higher cyclinder temperature. Some resin material may decomposes so it set screw speed in mid-speed such as 45-75%, In plastic step setting screw back pressure is very important, Higher screw back pressure ,higher quality of product screw back pressure make resin structure order, Molding product is beautiful and volume stable. But ,it maybe flow if screw back pressure too high . So all factors should be considered when using screw back pressure.2.熔胶过程还有一个比较重要的环节,那就是松退,松退分前松退和后松退,其作用一般是为了防止流涎和抽丝,设定值速度和压力都在20%-50%间,设定的行程一般在2-5cm间,太长的行程可能会使料筒里面贮存空气,导致下一模出现不期望的气泡.In plastic step sucking back is very important too. Sucking back include front sucking back and back sucking back It setting sucking back to prevent flow and line. It sets sucking back speed and pressure within 20-50% and distance within 2-5cm. TOO long distance make cyclinder reserve air and cause bubble at next molding.顶出的工艺设定knocking out technique setting产品经冷却定型后则有一个开模的过程,开模基本上是合模的反过程.开模的未段则有一个慢速设置,开模完成后,产品必须顶出的过程.There is a mold opening step after product cooling taking shape. Mold opening is a reverse step of mold closing. The last step of mold opening speed set slow. Product should be knocked out after mold opened.一.顶前:Knocking out顶前最好分两个阶级,第一阶可分为中压慢速,即是把产品轻轻顶出一部分,然后是中压中速顶,中压中速一般指的是35%-55%,而低速则有可能低到5%,这需视产品不同而言,顶出行程设定是顶出长度稍比产品垂直深度大1-2cm即可.Knocking out includes two steps, Step1 section setting mid-speed, knocks product out partly step2 section setting mid-pressure and mid-speed . Depending on different product, mid-pressure and mid-speed sets within 35-55% but low-speed can set 5%. Distance of knocking out longer 1-2cm than the vertical thickness of product.二.退针Back顶退包括两个过程与顶落的过程基本一致,顶退的终点应预留1-3cm的空间,以保护顶针油管不被顶坏.The same as knocking out, ejector back includes 2 steps. T o protect the ejector oil jar, it should make a 1-3mm distance in the ending point of ejector back.三.顶针方式还包括一个多次顶,单次顶及顶针停留的选择,机械手取产品,脱模顺利的情况都采取多项,为了顶针油缸寿命的延长,多次顶就以不超过三次为宜,顶针停留一般用在顶针带着产品退回有可能对增品产生损伤的模具,同时为配合机械手使用,有时也需要较短的顶针停留.The way of knocking out includes knocking out once, Knocking out repeat and ejector delay. T ake product by manipulator or take product easy, it should select knocking out once. T o longer the work time of ejector oiljar, times of knocking out lower 3 times. Ejector delay usedwhen product will be damaged if ejector back or suit manipulator.成型时间的设定Molding time setting在保证产品质量的前提下,周期时间是越短越好,周期时间又包括如下几项:射胶时间,保压时间,熔胶时间,冷却时间,顶出时间,锁模低压时间,甚至乎关系到时间因素的还有还开模与锁模,及顶出的快慢.Cycle time should shorter on condition that product quality well. Cycle time includes: injection time , holding pressure time, plastic time, cure time, knocking out time and mold protect time. Even mold opening closing sopeed and knocking out speed affect cycle.1.射胶时间包含保压时间,一般看起来,射胶时间越长,产品越饱和,但我们在讲求质量时,同时也须考虑产能,更何况,射胶时间过长,有可能会造成产品过于饱满而寻致粘模顶的变形呎寸偏大等一系列问题,故我们在设置射胶时间时应综合考虑,尽量在合乎质量要求时缩短射胶时间.Injection time consists holding pressure time. Longer injection time, fuller product, we should consider production quantity when we suit for quality. If injection time too long, it may cause a series of defects suck as flash strain. So all sorts of factors should be considered, injection time should be shout if quality suit for requirement.2.熔胶时间的长短取决于熔胶速度设定的快慢,背压设定的大小,但有一点,熔胶时间控制的长短一定要比冷却时间短.Plastic time depends on plastic speed and screw back pressure, but plastic time must shorter than cure time.3.冷却时间:冷却时间的长短直接影响到成型的周期,冷却时间越长,成型时间就越长,造成产能就越低,故我们在设定高压冷却时间时,只要能保证到产品成型顺利,不会直接影响到变形等问题,设定的时间也是越短越好.Cure time: Cure time affects molding cycle. Longer cure time, longer molding cycle, lower production quantity. So it sets cure time short on condition that product molding succed and can‟t deformation..4.在大量使用机械手的塑胶公司,我们的顶出时间一般是与机械手配合为宜,全自动使用机械手时顶出停留时间一般保持1.5-2秒,半自动生产,如因顶针退回会导致产品掉落或卡紧,而取不下产品,停留时间则应保持5秒左右.In PCE company, for using manipulator in abundence , knocking out time suits manipulator, Knocking out delay keeps 1.5-2 second when using manipulator full-manipulator, knocking out delay keeps about 5 second when using manipulator semi-manipulator and product will fall or can‟t be taken off if ejector back.5.低压保护时间对保护我们人身安全,模具安全起很大作用,配合好模具低压位置和低压压力的调整,低压保护的时间应取1-3秒,保护时间越短,可能造成的危害则越小.Low-pressure protect is very important for safety and protect mold, Mold protect time should adjust within 1-3 second suit low pressure and position of mold protect, shorter protect time,make damaged.渗漏leakage渗透peculation`渗透率fluidpermeability渗透率各向异性permeabilityanisotropy 渗透率恢复值returnpermeability渗透水化osmotichydration渗透性地层permeableformation渗析纯化purifiedbydialysismethod升程rise升距lift升膜式蒸发器upwardfilmevaporator生产能力productioncapacity生产阻力productiveresistance生化反应器biochemicalreactor生态环境ecologyenvironment生物处理biologicaltreatment生物毒性biotoxicity生物降解biologicaldegradation生物聚合物biologicalpolymer,xanthan 生物流化床法biologicalfluidbedmethod 生物滤池法bio-filterprocess生物转盘法biologicalrotarymethod声波测井soniclogging声波干燥器sound-wavedryer声幅值acousticamplitude失水waterloss失重weightlessness,weightloss施工作业fieldoperation湿法制粒机wettypegranulator湿挤压wet-extrusion十八醇octadecanol十字滑块联轴器doubleslidercoupling Oldham…scoupling 石膏gypsolyte,gypsum石灰lime石蜡alpha,paraffinwax石炭系carboniferoussystem石英quartz石油加工oilrefinery石油裂化petroleumcrackingprocess时间推移技术timedelayingmethod实际廓线camprofile实际啮合线actuallineofaction实验trail矢量vector示踪分析法mudfiltratetraceranalysis 事故率failurerate室内模拟实验simulatinglabtest室内实验和现场labandfield室内研究laboratorystudy室温ambienttemperature适量definedamount适应温度reactiontemperature释放release收缩shrink叔胺盐tertiaryammoniumsalt疏水性hydrophobicity输出功outputwork输出构件outputlink输出机构outputmechanism输出力矩outputtorque输出轴outputshaft输瓶机bottleconveyer输入构件inputlink输液剂机械infusionmachinery束缚irreducible束缚水bondwater树脂resin,colophonys数据库database数学模型mathematicmodel数学模型mathematicalmodel数字模拟digitalanalog衰变decay栓剂崩解器suppositorydisintegrationtester栓剂机械suppositorydrugmachinery栓壳成形灌封机suppositoryshellformingandfilling-sealingmachine 双层组合套管固井技术pipe-in-pipecasingstring双电层斥力doubleelectrodelayerrepulsion双分支侧钻水平井bi-lateralsidetrackinghorizontalwell双滑块机构double-slidermechanism,ellipsograph双列轴承doublerowbearing双曲柄机构doublecrankmechanism双曲面齿轮hyperboloidgear双头螺柱studs双万向联轴节constant-velocityordoubleuniversaljoint双向推力轴承double-directionthrustbearing双摇杆机构doublerockermechanism双转块机构Oldhamcoupling双锥回转式真空干燥机doubleconicrotaryvacuumdryer 双锥型混合机doubleconicalmixer水包油型乳化液oil-in-waterfluid水不溶物waterinsolublematter水层waterlayer水化hydration水化膨胀分散hydrousdisintegration水化抑制剂hydratecontrol水基泥浆water-basedrillingfluid水解hydration水解度hydrolyzingdegree水力学hydraulics水敏性watersensitivity水泥环cementsheath水泥浆cementslurry水泥石setcement水泥熟料cementclinker水泥早强剂cementhardener水平井段nethorizontalsection水平井段长extendedhorizontaldepth水平井偏心环空horizontaleccentricannulus水平位移horizontaldisplacement水溶性water-soluble水溶液aqueoussolution水锁waterlock水眼粘度bitnozzleviscosity,Cassonhighshearviscosity 水针剂机械injectionmachinery顺利gosmoothly顺时针clockwise瞬时滤失instantaneousfiltration,spurtloss瞬时速度instantaneousvelocity瞬心instantaneouscenter说明书折叠机synopsisfoldingmachine锶strontium死点deadpoint四苯硼酸钠sodiumtetraphenylborate四杆机构four-barlinkage四级固控系统fourstagesolidcontrolsystem四球机four-ballinstrument松边slack-side松弛测量法relaxationmeasurement松散地层unconsolidatedformation松散吸附水adsorbedwater送料装置conveyerformedicinematerial速度velocity速度波动speedfluctuation速度不均匀波动系数coefficient of speed fluctuation速度场velocityfield速度曲线velocitydiagram速度瞬心instantaneouscenterofvelocity速敏speed-sensitivity速凝fastsetting速凝剂accelerator塑料滴眼瓶成形灌封机eyedrugplastictubeformingandfilling-sealingmachine 塑料滴眼瓶清洗设备eyedrugplastictubecleaner塑料盖制造机plasticcapmakingmachine塑料口服液瓶成形灌封机plasticoralbottleformingandfilling-sealingmachine 塑料瓶输液检漏仪leakagedetectorforplasticbottleinfusion塑料瓶制造机plasticbottlemakingmachine塑料容器输液剂设备plasticinfusionequipment塑料软管灌封机plasticsofttubefilling-sealingmachine塑料输液袋灌封机plasticinfusionbagfilling-sealingmachine塑料输液瓶成形灌封机plasticinfusionbottleformingandfilling-sealingmachine 塑料小球plasticbeads塑料制瓶充填包装机plasticbottleformingandfilling-packagingmachine塑性水泥plasticcement塑性粘度plasticviscosity酸度计滴定法acidometertitration酸酐anhydride酸碱滴定法acid-basetitration酸敏acidsensitivity酸溶性acidsoluble酸性条件acidiccondition酸性粘土acidclay酸渣acid-slug虽然按照原文应该直翻成自动手枪，指的通常是半自动手枪semi-automaticpistol。

塑胶模具专业英语词汇1) Designer - 设计师。

2) Assembly drawing - 模具组装图。

3) Mold layout - 模具结构图。

4) 2D product drawing - 2D产品图。

5) 3D product data - 3D产品数据。

6) Part drawing - 散件图。

7) Insert molding - 镶件模。

8) 2 color mold / Double injection tool - 双色模。

9) Hydraulic system - 油/水压系统。

10) Parting line - 分模线。

11) Air venting - 排气槽。

12) Cooling system - 冷却系统。

13) Screw - 镙丝。

14) Hot runner system - 热流道。

15) Valve gate - 伐针入水口。

16) Fan gate - 扇型入水口。

17) Pin point gate - 针点进胶。

18) Moon gate -象牙入水口。

19) Submarine gate - 潜水口。

20) Injection machine tonnage - 注塑机吨数。

21) Number of cavity - 穴数。

22) Steel - 钢材。

23) Copper - 铜。

24) Tungsten copper - 钨铜。

25) Beryllium copper - 铍铜。

26) Hardening - 加硬/淬火。

27) Tempering - 回火。

28) Chroming - 电镀。

29) Painting - 喷漆。

30) Resin - 胶材。

31) Printing - 丝印。

32) Texturing - 嗮纹/咬花。

33) Socket screw - 带肩镙丝。

34) Inter lock / Straight lock - 模锁。

模具专业英语培训——注塑模English Training——Injection Mold（一）模具专业基本用词Professional Terms1．塑料—plastic, resin2．样件—sample3．钢料—steel4．注塑机—injection machine, press5．产品—part, product, moulding6．模具—mold, mould, toolA 简易模（样板模）—prototype moldB 量产用模具—production mold 7．三维造型（数模）—model, 3D data8．二维产品图—2D part drawing9．设计—design10．制造—manufacture, build up, construction11．检验—check, inspection12．测量—measure, inspection13．修改—change, modify, correction14．工程更改—engineer change15．质量—quality16．数量—quantity17．基准—datum, reference（二）如何解析2D 产品图？How to read 2D part drawing?一．产品几何Geometry1．点—point2．线（边）—line, edge3．面faceA 侧面—sideB 表面—surfaceC 外观面—appearance surface 4．壁厚—wall thickness, stock thickness5．加强筋（骨位）—rib6．孔—hole7．细长的槽—slot8．柱位—boss9．角—cornerA 圆角—filletB 倒角—chamferC 尖角—sharp corner 10．斜度—angle, taper11. 凹槽—recess , groove二．分模信息Splitting1．分型线—parting line (P/L), splitting line2．主分模方向—main direction, line of draw3．浇口设定—gating三．产品标识Part Identification1．产品名称—part name (P/N)2．产品编号+版本号—part number + revision (Rev.)3．型腔号—cavity number4．材料标记—material symbol5．模具编号—mold number (no.)6．日期印—dating insert, date code7．循环印—cycling code8．公司标志—company logo四．技术要求Specification (Special Requirement)1．项目启动表Kick-off sheet1）项目名称—program name, project name2）产品名称—part name, product name, part description3）产品编号—part number (P/N)4）客户模号—customer mold no.5）项目启动日期—kick off date, start date6）项目完成日期—due date,lead time7）内模件用钢—tool steel8）型腔数量—number of cavities9）数模文件编号—data file no.10）注塑材料—resin, plastic, raw material11）收缩率—shrink, shrinkage, shrink factor12）注塑机吨位—molding machine size, injection machine size 13）成型周期—cycle time14）型腔光洁度—cavity polish15）型芯光洁度—core polish16）皮纹（晒纹）—texture, grain17）拔模斜度—draft angle, removal taper18）注塑件颜色及光泽—molded color & gloss19）模具加工地—manufacturing facility20）热流道供应商—manifold manufacturer, manifold supplier 21）浇口位置—gate location / position22）浇口类型—gate type23）产品标识—stamp information, part identification24）特殊要求—special instructions2．产品质量及外观要求Part Quality & Appearance1）尺寸及公差Dimension & Tolerance①重要尺寸—critical dimension, important dim., key dim.②理论尺寸—nominal dimension③实际尺寸—actual dimension④公差—tolerance⑤公差带—tolerance range⑥尺寸超差—dimension deviation⑦接受（合格）—accept, OK⑧拒绝（不合格）—reject, refuse, obsolete, NG⑨让步接受—concession, special admit⑩返工—re-work2）产品缺陷（较常见）Defects (normal)①缩印—sink mark, shrinkage②飞边—flash, burr③段差—mismatch discrepancy④银丝纹—snake marks, streak⑤弯曲—warpage, distortion⑥打不足（缺料）—short shot⑦熔接线—weld line3．产品外观Part Appearance①产品颜色—part color②产品光泽—gloss③皮纹粒度—grain4．常用词汇、词组及短语Normal Word, Short Sentence1）单边—per side2）双边—both sides3）加入，添加—add, incorporate4）去除，取消—remove, cancel5）满足…的要求，符合，与…要求一致—according to, conform to, satisfy, meet 6）要求，需要—require, need, demand7）确认—be approved, agreed by …8）允许—permit, allow9）在…范围之内—within10）不可以，不允许，禁止—free from, prevent, avoid11）…，除非有另指—…unless otherwise specified12）…或少于—…or less13）自动化运作—automatic operation14）未注尺寸（详细形状）见三维造型Non dimensioned contour (detailed shape) see 3D model.15）分型线上的飞边（披缝）或段差应小于…Burrs and discrepancy on the P/L shall be … or less.五．标题栏Title Block1．产品名称—part name2．图纸编号 + 版本号（索引号）—drawing no. + level (index)3．一般公差[的标准] —general tolerance（三）如何阅读制模标准？How to read tooling standard? 一．模具结构术语Mold Construction TerminologyA．模架Mold Base1．模架量化特征Measurement Feature①长X 宽X 高—Length X Width X Height②模具推高尺寸（模厚）—stack height of mould③模具重量—total weight of mould, mould thickness2．定模底板—front plate, top clamping plate, clamp plate, clamping plate 3．定模板—cavity plate, fixed mould plate, A – plate4．动模板—core plate, moving mould plate, B – plate5．支撑板—support plate, backing plate6．模脚—support blocks, rails, risers, spacer block7．顶杆固定板—retaining plate, ejector retaining plate8．顶板—ejector plate9．动模底板—back plate10．导柱—guide pillar, leader pin, guide pin11．导套—guide bush, leader pin bush12．复位杆—return pin, push-back pin13．弹簧—spring14．撑头—support pillar15．推板导柱、导套—ejection guide pin / bush16．挡钉—stop pin, stop button17．站立脚—standing-off pillars18．标牌—plaque scutcheonB．成型零部件moulding components19．型芯—core20．型腔—cavity21．镶针—core pin22．镶块—insert, split23．滑块—slide, sliding split24．斜顶—lifter, angled-lift splitA 斜顶头—lifter headB 斜顶杆—lifter rod, lifter shaft 25．成型顶杆—moulding face pin, form pinC．浇注系统Feed System1．塑料Mouldinga．主流道—sprueb．分流道runner①主分流道—main runner②二级分流道—branch runner分流道断面形状cross-sectional shape of runner①圆形—full round②半圆形—semicircular③梯形—trapezoidalc．浇口gate常用浇口形式normal gate type :①边缘浇口（J型浇口）—edge gate, J – gate②侧浇口—side gate③潜伏式浇口—sub-gate, cashew gate, subsurface gate, submarine gate④潜伏式二次浇口(隧道式浇口) —tunnel gate onto feeder post⑤点浇口—pin gate⑥直接浇口(主流道型浇口) —sprue gate, direct gate⑦护耳式浇口—tab gated．模腔—impressione．冷料井—cold slug wellf．热流道—hot runner2．模具零件mold componentsa．定位圈—locating ring, location ring, register ringb．浇口套—sprue bushc．挡圈—stop ringd．浇口镶块—gate inserte．热流道板—manifoldf．热嘴—hot dropD．分型面及其锁紧、排气Parting Surface, inter-locking & venting1．分型线—parting line ( P/L )2．镶拼线—bodyline, joint line3．平/ 不平的分型面—flat / non – flat parting surface4．封胶面—shut off surfaces, seal-off surfaces5．擦位—shut off6．碰穿位—kiss-off7．管位—parting line lock8．分型面的释放(避空) —relief of parting surface9．分型面的平衡—balancing of parting surface10．锁紧角度—locking angle11．锁紧力—clamping force12．锁模板—safety strap13．精定位—Interlock, die lock14．困气—air trap15．排气槽—vent, vent slotE．滑块机构Slide1．驱动Actuation①斜导柱—angled pin, horn pin, cam pin②弹簧—spring③油缸—hydraulic cylinder2．制动Detention①滑块固定器—slide retainer②弹簧制动器—spring-loaded detention (plunger)③挡钉、挡板—stop pin, stop plate, slide stop3．导轨—gib, guide strip4．锁紧块（楔紧块）—heel block, locking heel, wedge block, chase block 5．耐磨片—wear plate, wear strip6．压板—retainer7．螺钉—screw8．定位销—dowelF．斜顶机构Lifter1．斜顶头—lifter head2．斜顶杆—lifter rod, lifter shaft3．开口销—split pin4．固定板（压板）—retainer plate5．耐磨片—wear plate6．铜导套—bronze bushing7．衬套—spacer8．导轨—L – gib9．滑动块—slideG．顶出系统Ejection System1．基本词汇Basic Word①顶出行程—ejection stroke②模具开档—daylight③粘模—stick④产品脱模—part is push off from, clear part of mould, separation of part 2．顶板机构Ejector plate assembly①顶板（推板）—ejector plate②顶板固定板—retaining plate③推板导柱—ejector guide pin④推板导套—ejector guide bush⑤撑头—support pillar, pillar support3．复位机构Return System①复位杆（回程杆）—return pin, push – back pin②挡钉—stop pin, stop button③压簧—compressed spring④碟簧— a stack of ―Belleville‖ washers⑤早复位机构—early return system⑥强制复位机构—positive return system4．顶出方法Ejection Techniques1）顶杆顶出—pin ejection2）顶管顶出—sleeve ejection3）顶块顶出—bar ejection4）扁顶顶出—blade ejection5）顶板顶出—stripper ejection6）油缸顶出—hydraulic ejection7）气顶—air ejection8）阀门顶出—valve ejection5．顶出元件Ejection Elements1）拉料杆—sprue puller, sucker pin2）顶杆—ejector pin3）阶梯式顶杆—stepped ejector pin4）顶管—ejection sleeve, sleeve5）扁顶—ejector blade, slabbed off ejector pin6）顶块—stripper bar7）顶环—stripper ring8）推板—stripper plate9）加速顶—accelerated ejection6．顶出辅助机构Supplementary operating system1）弹簧柱塞器—spring – loaded plunger2）弹珠定位器—ball catch system3）插销式锁扣—Latch – lock4）尼龙拉杆装置—friction puller device7．电器元件Electric Components1）压力传感器—pressure transducer2）限位开关—limit switchF．冷却系统Cooling System1．基本词汇Basic Word1）温差—temperature variation2）水孔（水道）—waterlines, water-ways, flow-way, channel3）水路—cooling circuit4）水路示意图—water schematic, schematic circuit5）冷却液—coolant, coolant fluid6）内连接—interconnect7）外连接—external connection8）出口、入口—outlet、inlet9）漏水—water leakage2．水路分布Circuits1）阶梯式水路—stepped system2）喷淋—baffled hole system3）斜孔式水路—angled hole system3．水路元件Components1）闷头（螺塞、止水栓）—（threadless）brass pressure plug : female plug & male 2）隔水片—baffle3）密封圈—O – ring4）快插水路接头—quick disconnect fitting, quick connection adaptor5）弯头—elbow6）偶合器（连接器、接头）—adaptor (including a plug & a socket)7）橡皮管—rubber hose8）分水板—water manifoldG．螺纹、螺纹孔& 螺钉Thread, thread hole & screw1．螺纹—thread2．管螺纹—pipe thread3．螺纹孔—screw hole, tapped hole4．起吊孔—handling hole, jack screw hole, eye bolt hole5．螺钉—screw6．内六角螺钉—socket headed cap screw （s.h.c.s.）7．沉头螺钉—flat headed cap screw （f.h.c.s）8．螺栓—bolt, eye bolt9．螺母—nut10．锁紧螺母—locknut11．螺纹标准Thread Standard①公制标准—Metric②英制标准—Imperial③英制管螺纹标准—British Standard Pipe thread （BSP）④美制管螺纹标准—NPT⑤美制粗螺纹标准—United Coarse thread （UNC）⑥美制细螺纹标准—United Fine thread （UNF）H．润滑Lubrication1．润滑槽—grease groove2．加油管—grease line3．油杯—lubrication fittingI．测量仪器Measuring Instruments1．游标卡尺—vernier caliper2．千分尺—micrometer3．高度规—height gauge4．刻度规—dial gauge5．三坐标测量仪—Coordinate Measure Machine（CMM）6．塞规—pin gauge7．圆角量规—radii gauge8．輪廓投影機—profile projectorJ．注塑机参数Injection Machine Parameter1．注塑机规格参数Injection Machine Specification①锁紧类型clamp typea．油缸—hydraulic b．肘杆式—toggle②垂直注塑机导柱间距—tie bar vertical clearance③水平注塑机导柱间距—tie bar horizontal clearance④台板尺寸—platen dim.⑤最小/ 最大模厚—mold height Min. / Max., Min. / Max. mold thickness⑥最小/ 最大注塑机开档—open daylight Min. / Max.⑦锁紧行程—clamp stroke⑧锁紧力—clamping force⑨顶出行程—ejector stroke⑩顶出力—ejector force2．试模工艺参数Moulding Process Parameter, machine setting①时间Timer（TM）, seca．注塑（充填）时间—filling time, injection timeb．冷却时间—cooling timec．补缩时间—packing timed．保压时间—holding timee．成型周期—cycle time②速率、速度Velocity, %、speed, in/seca．注塑（充填）速度—injection speedb．保压速率—hold pressure velocityc．螺杆转速—screw rotation speed③压力Pressure（Prs.）, psia．注塑压力—injection pressureb．保压压力—hold pressurec．回压（背压）—back pressure④温度Temperature（Temp.）, °Fa．注塑机喷嘴温度—nozzle temp.b．料筒前段、中段、后段温度—barrel front、middle、rear temp.c．模温—mould temp.d．料温—purged resin melt temp.e．空射料温—air shot melt temp.关于注塑成型对产品造成的各种缺陷及解决方法(一)熔接痕熔接痕是由于来自不同方向的熔融树脂前端部分被冷却、在结合处未能完全融合而产生的。

注塑英语词汇Injection machine 啤机Shot size（weight）实际射胶量 injection volume 理论射胶量 min mold height 最小容模厚度Max mold height 最大容模厚度 Tie bar clearance 拉杆间距 Die plate size 模板尺寸 Ejector stroke 顶出行程 barrel 炮筒，机筒 clamp force 锁模力 non-return valve 止回阀shear 剪切 opening 开模行程Injection pressure 射胶压力back pressure 背压 nozzle size 射咀尺寸Cycle time 循环周期down time 停机时间 hopper 料筒Mold release 脱模剂lubrication 润滑 work horse 主力，主要设备Reserve pressure / packing pressure保压mold trial 试模 shot （一）啤Decompress 减压oven 烤炉，烘灶 shrinkage rate 收缩率Residence time 滞留时间injection speed 注射速度 booster time 增压时间Compression ratio 压缩比 mold close time 合模时间Resin 胶料Plastification 塑化，增塑viscosity 粘性，粘度contamination 污染，杂物Thermoplastic 热塑性塑料thermosetting plastics 热固性塑料Booster time 增压时间 feed 喂料，填充purge 净化Flame retardant 阻燃 degradation 降解，软化 regrind 再粉碎Water absorption 吸水reinforce 增强，加固 specific gravity 比重Elongation 延伸率 density 密度 melting point 熔点Polystyrene 聚苯乙烯（PS） Styrene 苯乙烯Acrylonitrile 丙烯腈Polypropylene 聚丙烯（PP） Polyethylene 聚乙烯 glass fiber 玻纤Condensation 凝固，浓缩 crystalline resin 结晶形塑料compre sion molding 压缩成型flash mold 溢流式模具plsitive mold 挤压式模具split mold分割式模具cavity 型控母模core 模心公模taper 锥拔leather cloak 仿皮革shiver 饰纹flow mark 流痕welding mark 溶合痕post screw insert 螺纹套筒埋值self tapping screw 自攻螺丝striper plate 脱料板piston 活塞cylinder 汽缸套chip 细碎物handle mold 手持式模具（移转成型用模具）encapsulation molding 低压封装成型（射出成型用模具）two plate 两极式（模具）well type 蓄料井insulated runner 绝缘浇道方式hot runner 热浇道runner plat 浇道模块valve gate 阀门浇口band heater 环带状的电热器spindle 阀针spear head 刨尖头slag well 冷料井cold slag 冷料渣air vent 排气道welding line 熔合痕eject pin 顶出针knock pin 顶出销return pin 回位销反顶针sleave 套筒stripper plate 脱料板insert core 放置入子nner stripper plate 浇道脱料板guide pin 导销eject rod (bar)（成型机）顶业捧subzero 深冷处理three plate 三极式模具runner system 浇道系统stress crack 应力电裂orientation 定向sprue gate 射料浇口，直浇口nozzle 射嘴sprue lock pin 料头钩销(拉料杆) slag well 冷料井side gate 侧浇口edge gate 侧缘浇口tab gate 搭接浇口film gate 薄膜浇口flash gate 闸门浇口slit gate 缝隙浇口fan gate 扇形浇口dish gate 因盘形浇口diaphragm gate 隔膜浇口ring gate 环形浇口subarine gate 潜入式浇口tunnel gate 隧道式浇口pin gate 针点浇口Runner less 无浇道(sprue less) 无射料管方式long nozzle 延长喷嘴方式sprue 浇口;溶渣入水：gate 进入位：gate location 水口形式：gate type 大水口：edge gate 细水口： pin-point gate 水口大小：gate size 转水口：switching runner/gate 唧嘴口径：sprue diameter 流道: runner 热流道：hot runner,hot manifold 热嘴冷流道: hot sprue/cold runner 唧嘴直流: direct sprue gate 圆形流道：round(full/half runner 流道电脑分析：mold flow analysis 流道平衡:runner balance 热嘴：hot sprue 热流道板：hot manifold 发热管：cartridge heater 探针: thermocouples 插头：connector plug 插座： connector socket 密封/封料： seal 三、运水：water line 喉塞：line lpug 喉管：tube 塑胶管：plastic tube 快速接头：jiffy quick connector plug/socker 四、模具零件：mold components 三板模：3-plate mold 二板模：2-plate mold 边钉/导边：leader pin/guide pin 边司/导套：bushing/guide bushing 中托司：shoulder guide bushing 中托边L：guide pin 顶针板：ejector retainner plate 托板：support plate 螺丝： screw 管钉：dowel pin 开模槽：ply bar scot 内模管位：core/cavity inter-lock 顶针：ejector pin 司筒：ejector sleeve 司筒针：ejector pin 推板：stripper plate 缩呵：movable core,return core core puller 扣机（尼龙拉勾）：nylon latch lock 斜顶：lifter 模胚（架）： mold base 上内模：cavity insert 下内模：core insert 行位（滑块）： slide 镶件：insert 压座/斜鸡：wedge 耐磨板/油板：wedge wear plate 压条：plate 撑头: support pillar 唧嘴： sprue bushing 挡板：stop plate 定位圈：locating ring 锁扣：latch 扣鸡：parting lock set 推杆：push bar 栓打螺丝：S.H.S.B 顶板：eracuretun 活动臂：lever arm 分流锥：spure sperader 水口司:bush 垃圾钉：stop pin 隔片：buffle 弹弓柱：spring rod 弹弓:die spring 中托司：ejector guide bush 中托边：ejector guide pin 镶针：pin 销子：dowel pin 波子弹弓：ball catch 喉塞: pipe plug 锁模块：lock plate 斜顶：angle from pin 斜顶杆：angle ejector rod 尼龙拉勾：parting locks 活动臂：lever arm 复位键、提前回杆：early return bar 气阀：valves 斜导边：angle pin 术语：terms 承压平面平衡：parting surface support balance 模排气：parting line venting 回针碰料位：return pin and cavity interference 模总高超出啤机规格：mold base shut hight 顶针碰运水：water line interferes withejector pin 料位出上/下模：part from cavith (core) side 模胚原身出料位：cavity direct cut on A-plate,core direct cut on B-plate. 不准用镶件： Do not use (core/cavity) insert 用铍铜做镶件： use beryllium copper insert 初步（正式）模图设计：preliinary (final) mold design 反呵：reverse core 弹弓压缩量：spring compressed length 稳定性好：good stability,stable 强度不够：insufficient rigidity 均匀冷却：even cooling 扣模：sticking 热膨胀：thero expansion 公差：tolorance 铜公(电极）：copper electrode塑料成形模具 mould for plastics 热塑性塑料模 mould for thermoplastics 热固性塑料模 mould for thermosets 压缩模 compression mould 压注模、传递模 transfer mould 注射模 injection mould 热塑性塑料注射模 injection mould for thermoplastics 热固性塑料注射模 injection mould for thermoses 定模 stationary mould fixed half 动模 movable mould moving half 定模座板 fixed clamp plate, top clamping plate. top plate 动模座板 moving clamp plate. bottom clamping plate. bottom plate 上模座板 upper clamping plate 下模座板 lower clamping plate 凹模固定板 cavity-retainer plate 型芯固定板 core-retainer plate 凸模固定板 punch-retainer plate 模套 chase. bolster. frame 支承板 backing plate. supprr plate 垫块 spacer parallel 支架 ejector housing. mould base leg abrasive grinding 强力injection mould 注塑模injection 注射in-line-of-draw 直接脱模insert 嵌件inserted die 嵌入式凹模inspection检查,监督installation安装Surface Appearance 外观Glossiness/gloss finish 光洁度Matt finish/matt surface 毛面Glass fiber richsurface/glass emergence on the surface 玻纤外露Blooming/surface blooming 表面析出White patches on surface 表面白斑Silver marks/silver streak 银纹Splay mark 水纹Flow mark 流纹Weld line 溶结纹Brittle/brittleness 脆Bubbles/trapped gas 气泡V oid 孔Burn marks 烧伤FR failed 阻燃不合格Flame rating V-2 阻燃V-2 Poor dispersion 分散不好FR/PTFE …agglomerates etc 阻燃剂/PTFE…结块Pellet porous 粒子不密/蜜蜂窝Low impact/tensile etc 物理性能低High flow/filler content etc 流动性/填充…过高Longs/fines/doubles 长粒/碎屑/连粒Poor cut 粒形不好Bristle/voids 表面有小气泡/孔Glass bundles 玻纤结团Product was rejected due to 产品不能接受因为… High moisture level 高水分Warpage/warped 翘曲Shrinkage/shrink 收缩Sink marks 缩影Short shot/short molding 打不满Distortion 变形Over dimension 尺寸过大Under dimension 尺寸过小Flashing 飞边Discoloration 变色Off color 颜色差异Flow rate 流动率Viscous 粘High flow 高流动Low flow 低流动Sticky 粘Mold release 脱模Antioxidant 抗氧剂Flame retardant agent 阻燃剂Heat stabilizer 热稳定剂Chopped glass fiber 短切玻纤Roving glass fiber 粗纱/长玻纤Glass beads 玻璃微珠Milled fiber 碾磨纤Molybdenum disulfide/moly/MoS2 二硫化钼Colorant 着色剂Pigment 颜料Dye 染料Accepted product specification 接受产品规格Approved our product 认可我们的产品Re-set spec 重新定标准Add in extra … 添加多一点… Reduced … content 减少…含量Dropped/redu ced … by x％减少…含量…％Confirmed color standard 确认颜色标准Approved color standard 认可颜色标准Re-confirmed color standard 重新确认颜色标准Qualified our product 认可我们的产品Undergoing heat aging test 在做热老化实验Product is under testing 产品在测试当中Received first order 接了第一个定单Expected to finish by … 预计在…完成Expected order is xMT 预计定单量…吨Estimated annual/monthly consumption 预计年/月用量SPC statistic process control 品管保证Quality Assurance 品管控制Quality control 来料检验IQC Incoming quality control 巡检IPQC In-process quality control 校对calibration 动态试验dynamic test 环境试验Environmental test 非破坏性试验non-destructive test 光泽gloss 击穿电压(dielectric) breakdown voltage 拉伸强度tensile strength 冷热骤变试验thermal shock test 环境试验炉Environmental chamber 盐雾实验salt spray test 绝缘电阻测试验仪Insulating resistance meter 内应力internal stress 疲劳fatigue 蠕变creep 试样specimen 撕裂强度tear strength 缩痕shrink mark, sink mark 耐久性durability 抽样sampling 样品数量sample size AQL Acceptable Quality level 批量lot size 抽样计划sampling plan OC曲线operation curve 试验顺序sequence of tests 环境温度ambient temperature 可焊性solderability 阻燃性flame resistance XX电子有限公司XX Electronics CO., Ltd 总经理办公室General manager’s office 企管部Enterprise management department (EM) 行政部Administration department (AD) 销售部Sales department (SD) 财务部Financial department (FD) 技术部Technology department (TD) 物控部Production material control department (PMC) 生产部Production department(PD) 模具部Mold manufacturing department, Tooling manufacturing department (TM) 品管部Quality Assurance department (QA) 冲压车间Stamp workshop, press workshop 注塑车间injection workshop 装配车间Assembly workshop 模具装配车间Mold and die Assembly workshop 金属加工车间metal machine workshop 电脉冲车间Electric discharge process workshop 线切割车间wire cutting process workshop 工磨车间Grinding workshop 总经理General manager (GM) 副总经理Vice-general manager 经理manager 董事长president 副董事长Vice-president XX部门经理Manager of XX department 主任、主管supervisor 拉长Line leader 组长Foreman, forelady 秘书secretary 文员clerk 操作员operator 助理assistant。

coupling [kʌpliŋ]连接release [rili:s] 松开释放motor [məutə] 马达overload 超载mould heating off模具加热关闭mould open stop not reach[ri:tʃ]开模未到位mould safety time模具保护时间未响应no holding pressure[preʃə]无保压压力nozzle [nɔzl] guard[ɡɑ:d] not closed喷嘴保护门未关上oil level[levl] too low 油位太低oil prewarming 油预热fault[fɔ:lt] 缺点故障pump not running油泵未运行robot error机械手故障robot offline机械手断线screw back not reache[ri:tʃ]螺杆未回退到位stroke measurement[meʒəmənt] problem 电子尺故障temperature[tempəritʃə] controller problem 温控器故障temperature deviation[di:vieiʃən]温度偏差tolerance[tɔlərəns] deviation容许偏差Setup machine机器设置Mould sequence [ˈsi:kwəns]模具动作hydraulic [haiˈdrɔ:lik]ejector [iˈdʒektə]液压顶出injection unit射出装置mould direct [diˈrekt] 模具动控制process optimization [ˈɔptimaiˈzeiʃən]工艺优化temperature [ˈtempəritʃə] 温度ejector movement 顶出设置basic sequence [ˈsi:kwəns] 基本设置start position 开始位置move parallel [ˈpærəlel] 平行check position 检查位置time dependant [diˈpendənt]rotating [rəuˈteit] core 中子旋转switch on delay 时间延迟inpulsestroke [strəuk] 行程位置step mould 单级模式retract before dosing 预塑前退回retract after dosing 预塑后退回retract [riˈtrækt] stop 后退停止holding pressure release [riˈli:s] 保压释放cycle [ˈsaikl] time 周期dosing delay [diˈlei] 预塑延迟intrusionholding 保压position [pəˈziʃən] 位置cycle time overrun超出循环周期cylinder [ˈsilində]料筒cylinder heating is not optimized料筒加热未校正optimize [ˈɔptimaiz]有效core in 中子进core out 中子出ejector [iˈdʒektə] forward [ˈfɔ:wəd]顶出前进limit [ˈlimit] 限定限度defective [diˈfektiv] 有缺陷欠缺complete [kəmˈpli:t] 完整的完成emergency [iˈmə:dʒənsi] 紧急handing 机械手。

1.雾气Moisture Streaks2.玻纤分配不均Glass Fiber Streaks3。

困气Gas Trap Effect4。

银丝纹Sliver Marks5。

结合线Weld Line6。

水波痕Water Wave Effect7.黑点Dark Sport8.顶出印Visible Ejector Marks9。

变形Deformation During Demolding10.填充不足Short Filling11.冷料流痕Cold Slug12。

进胶口点不良Dull Spots Near The Sprue13.喷射痕Jetting14.表面起层Flaking Of The Surface Layer15。

浮泡Entrapped Air16.过热变色Burnt Streaks17.龟裂Stress Crack18。

缩水痕Sink Marks19.真空气泡Density Bubble20。

披锋Flash21.擦伤印Scratch MarksGlass fiber rich surface/glass emergence on the surface22 尺寸过大Over dimension23尺寸过小Under dimension24 翘曲Warpage/warped25 收缩Shrinkage/shrink26 缩影Sink marks27 打不满Short shot/short molding塑料模具mould of plastics注塑模具injection mould冲压模具die模架mould base定模座板Top clamping plateTop plateFixed clamp plate水口推板stripper plateA板A plateB板B plate支承板support plate方铁spacer plate底针板ejector plate面针板ejector retainer plate回针Return pin导柱Guide pin有托导套Shoulder Guide bush直导套Straight Guide bush动模座板Bottom clamp plateMoving clamp plate基准线datum line基准面datum plan型芯固定板core—retainer plate凸模固定板punch—retainer plate顶针ejector pin单腔模具single cavity mould多腔模具multi—cavity mould多浇口multi-gating浇口gate缺料starving排气breathing光泽gloss合模力mould clamping force锁模力mould locking force挤出extrusion开裂crack循环时间cycle time老化aging螺杆screw麻点pit嵌件insert活动镶件movable insert起垩chalking浇注系统feed system主流道sprue分流道runner浇口gate直浇口direct gate , sprue gate轮辐浇口spoke gate , spider gate点浇口pin—point gate测浇口edge gate潜伏浇口submarine gate ，tunnel gate 料穴cold—slug well浇口套sprue bush流道板runner plate排飞槽vent分型线(面）parting line定模stationary mould，Fixed mould动模movable mould，movable half上模upper mould，upper half下模lower mould，lower half型腔cavity凹模cavity plate，cavity block拼块split定位销dowel定位销孔dowel hole型芯core斜销angle pin, finger cam滑块slide滑块导板slide guide strip楔紧块heel block, wedge lock拉料杆sprue puller定位环locating ring冷却通cooling channel脱模斜度draft滑动型芯slide core螺纹型芯threaded core热流道模具hot-runner mould绝热流道模insulated runner mould熔合纹weld line （flow line）三板式模具three plate mould脱模ejection换模腔模具interchangeable cavity mould脱模剂release agent注射能力shot capacity注射速率injection rate注射压力injection pressure差色剂colorant保压时间holdup time闭模时间closing time定型装置sizing system阴模female mould，cavity block阳模male mould电加工设备Electron Discharge Machining数控加工中心CNC machine center万能铁床Universal milling machine卧式刨床Horizontal planer车床Engine lathe平面磨床Surface grinding machine去磁机Demagnetization machine万能摇臂钻床Universal radial movable driller 立式钻床Vertical driller超声波清洗机Ultrasonic clearing machine。

注塑方面英语术语注塑方面英语术语标签/分类：压铸 die-cast压炼 injection铸件 casting/cast/founding起泡/气泡 bubble/blister/airbubble缺料 shor-shots/undershot浇不足/*铸 under-founding多料 superfluities/superfluous material(alloy)顶针痕 ejector(pins) mark花纹 flow mark/flow line冷纹 cold mark/cold streak油纹 oil streak走水纹 splash mark银纹 silver streaks霜纹 splay mark夹水纹 silver streaks/flow line/weld line扣模/粘模 spruesticking砂眼/气眼 air hole（塑胶件）弯曲/变形 warping/warpage变形 deformation扭曲 twist翅曲 warp/warped材料错误 usingwrong plastic material凸痕 convex mark凹位/凹陷 sink mark/dent mark披锋 flashing批损 pare-mark/cutmark批凹 pare off锉纹 trim-mark/file-mark锉损 excessivetrim mark黑点/黑纹 black spots/black streak发白 white mark烧焦 burnmarks刮花/刮痕 scratch mark擦痕/擦伤 rub-mark/brush-burn裂缝 cracking裂纹 crakingline碰损 stress mark起皮 chip错位（合模线） part linemisaling ment孔位尺寸改变 dimensionvarious哑色 dull color表面变光滑（喷油面） glossy finishing表面 sruface/outside镶件 insert/insert word缩水/收缩 sinkmark/shrinkage/shrink mark 偏差 colordeviation色粉 colourment颜色 colour/color零件污糟 dirty mark on part顶白 stressmark/ejector mark屈曲 bent夹模线移位 part line misalignment胶件料厚不均 uneven wall thickness水口料 degradedmaterial凹印 sink mark擦花 abrasionmark混色 contamination mark热点不良 poor heat sticking模具方面：定位圈 locating ring唧嘴 spruebush (浇口套)A板 Aplate (定模板)B板 Bplate（动模板）方铁 spacer block (垫铁)底板 bottom clamp plate(动模底板)面板 top clamp plate(定模底板)顶针 ejector pin（顶杆）直边钉 guide pin (导柱)托司 shoulder guide bush(导套)直司 straight guide bush(导柱)回针 returnpin(回程杆)细水口边钉 support pin(副导柱)蓝弹簧 blue spring（回程弹簧）水口推板 runner stripper plate(卸流道板)中边钉 ejector guide pin (顶板导柱)顶针板 ejector retainer plate(顶杆固定板)顶针底板 ejectorplate(顶杆垫板)撑头 support pollar（支撑柱）垃圾钉 stop pin (限位钉)呵 core (后模肉内镶件)后模肉 back mold body(后模镶件)前模肉 cavity（前模镶件）扣鸡 P-lock。

塑胶模具类中英文对照专业术语塑胶模具类中英文对照专业术语工程部/ Design department:1) Designer - 设计师。

2) Assembly drawing - 模具组装图。

3) Mold layout - 模具结构图。

4) 2D product drawing - 2D产品图。

5) 3D product data - 3D产品数据。

6) Part drawing - 散件图。

7) Insert molding - 镶件模。

8) 2 color mold / Double injection tool - 双色模。

9) Hydraulic system - 油/水压系统。

10) Parting line - 分模线。

11) Air venting - 排气槽。

12) Cooling system - 冷却系统。

13) Screw - 镙丝。

14) Hot runner system - 热流道。

15) Valve gate - 伐针入水口。

16) Fan gate - 扇型入水口。

17) Pin point gate - 针点进胶。

18) Moon gate / Banana gate - 香蕉，象牙入水口。

19) Submarine gate - 潜水口。

20) Injection machine tonnage - 注塑机吨数。

21) Number of cavity - 穴数。

22) Steel - 钢材。

23) Copper - 铜。

24) Tungsten copper - 钨铜。

25) Beryllium copper - 铍铜。

26) Hardening - 加硬/淬火。

27) Tempering - 回火。

28) Chroming - 电镀。

29) Painting - 喷漆。

30) Resin - 胶材。

31) Printing - 丝印。

32) Texturing - 嗮纹/咬花。

模具专业英语词汇摘要：模具是一种用于生产特定形状的产品的工具，它在制造业中有着广泛的应用。

模具专业英语词汇是指与模具相关的专业术语，它涉及到模具的设计、制造、检验、使用等方面。

本文根据不同的主题，整理了一些常用的模具专业英语词汇，并用表格的形式进行了展示，以便于读者学习和参考。

1. 模具类型模具是一种用于生产特定形状的产品的工具，它可以分为不同的类型，根据加工方法和材料的不同，可以分为以下几类：中文英文注塑模injection mold压铸模die-casting mold冲压模stamping mold挤出模extrusion mold吹塑模blow mold硅胶模silicone mold砂型模sand mold石膏模plaster mold三板模three-plate mold双色模two-color mold2. 模具结构模具结构是指模具的组成部分和连接方式，它决定了模具的功能和性能。

一般来说，一个完整的模具由以下几个部分组成：中文英文模架mold base模芯core模腔cavity浇口系统gate system导向系统guiding system顶出系统ejection system冷却系统cooling system3. 模架模架是指支撑和固定模芯、模腔等部件的基础结构，它通常由标准件或定制件组成。

常见的模架部件有：中文英文定模座板fixed clamping plate动模座板moving clamping plate定模套板fixed bolster plate动模套板moving bolster plate支承板backing plate垫块spacer block4. 模芯和模腔模芯和模腔是指与被加工材料直接接触并形成产品形状的部件，它们通常由钢材或其他硬质材料制成。

常见的与模芯和模腔相关的术语有：中文英文凹面（内型面）concave surface (inner surface)凸面（外型面）convex surface (outer surface)分型面（合型面）parting surface (matching surface)型芯固定板（凸模固定板）core-retainer plate (punch-retainer plate)凹模固定板（凸模固定板）cavity-retainer plate (die-retainer plate)5. 浇口系统浇口系统是指将熔融或液态材料从注塑机或压铸机输送到型腔中的通道，它包括浇口、流道、冷料井等部件。

abrasive grinding 强力磨削abrasive 磨料的,研磨的absence 不在，缺席accesssory 附件accommodate 适应accordingly 因此,从而,相应地accuracy 精度,准确性actuate 开动(机器),驱动adequate 足够的adhesive 粘合剂adjacent 邻近的adopt 采用advance 进步advisable 可取的agitate 摇动a large extent 很大程度algorithm 算法align 定位，调准alignment 校直all-too-frequent 频繁allowance 容差,余量alternate 交替,轮流alternatively 做为选择,也许aluminiun 铝ample 充足的analysis 分析ancillary 补助的,副的angular 有角的annealing 退火aperture 孔applied loads 作用力appropriate 适当的arc 弧,弓形arise 出现,发生arrange 安排article 制品,产品ascertain 确定,查明assemble 组装attitude 态度auxiliary 辅助的avoid 避免axis 轴axle 轮轴,车轴alternative 替换物backup 备份batch 一批bearing 轴承,支座bed 床身behavior 性能bench-work 钳工工作bend 弯曲beneath 在•••下bin 仓，料架blank 坯料blank 冲裁,落料blanking 落料模blast 一阵（风）blemish 缺点,污点bolster 模座,垫板boring 镗削,镗孔bracket 支架brass 黄铜break down 破坏breakage 破坏brine 盐水brittle 易碎的buffer 缓冲器built-in 内装的bulging 凸肚burr 毛刺bush 衬套by far •••得多,最by means of 借助于boost 推进cabinet 橱柜call upon 要求carbide 碳化物carburzing 渗碳carriage 拖板,大拖板carry along 一起带走carry down over 从•••上取下carry out 完成case hardening 表面硬化case 壳,套cast steel 铸钢casting 铸造,铸件category 种类caution 警告，警示cavity and core plates 凹模和凸模板cavity 型腔,腔,洞centre-drilling 中心孔ceramic 陶瓷制品chain doted line 点划线channel 通道,信道characteristic 特性check 核算chip 切屑,铁屑chuck 卡盘chute 斜道circa 大约circlip (开口)簧环circuit 回路,环路circulate (使)循环clamp 夹紧clamp 压板clay 泥土clearance 间隙clip 切断，夹住cold hobbing 冷挤压cold slug well 冷料井collapse 崩塌,瓦解collapsible 可分解的combination 组合commence 开始,着手commence 开始commercial 商业的competitive 竞争的complementary 互补的complexity 复杂性complication 复杂化compression 压缩comprise 包含compromise 妥协,折衷concern with 关于concise 简明的,简练的confront 使面临connector 连接口,接头consequent 随之发生的,必然的console 控制台consume 消耗,占用consummate 使完善container 容器contingent 可能发生的CPU (central processing unit) 中央处理器conventional 常规的converge 集中于一点conversant 熟悉的conversion 换算,转换conveyer 运送装置coolant 冷却液coordinate (使)协调copy machine 仿形(加工)机床core 型芯,核心corresponding 相应的counteract 反作用,抵抗couple with 伴随contour 轮廓crack （使）破裂，裂纹critical 临界的cross-hatching 剖面线cross-section drawn 剖面图cross-slide 横向滑板CRT (cathoder-ray tube) 阴极射线管crush 压碎cryogenic 低温学的crystal 结晶状的cubic 立方的,立方体的cup (使)成杯状,引伸curable 可矫正的curvature 弧线curve 使弯曲cutter bit 刀头,刀片cyanide 氰化物complicated 复杂的dash 破折号daylight 板距decline 下落,下降,减少deform (使)变形demonstrate 证明depict 描述deposite 放置depression 凹穴descend 下降desirable 合适的detail 细节，详情deterioration 退化,恶化determine 决定diagrammmatic 图解的，图表的dictate 支配die 模具,冲模,凹模dielectric 电介质die-set 模架digital 数字式数字dimensional 尺寸的,空间的discharge 放电,卸下,排出discharge 卸下discrete 离散的,分立的dislodge 拉出,取出dissolution 结束distinct 不同的，显著的distort 扭曲distort (使)变形,扭曲distributed system 分布式系统dowel 销子dramaticlly 显著地drastic 激烈的draughting 绘图draughtsman 起草人drawing 制图drill press 钻床drum 鼓轮dual 双的，双重的ductility 延展性dynamic 动力的edge 边缘e.g.(exempli gratia) [拉]例如ejector 排出器ejector plate 顶出板ejector rob 顶杆elasticity 弹性electric dicharge machining 电火花加工electrode 电极electro-deposition 电铸elementary 基本的eliminate 消除,除去elongate (使)伸长,延长emerge 形成,显现emphasise 强调endeavour 尽力engagement 约束,接合enhance 提高,增强ensure 确保，保证erase 抹去,擦掉evaluation 评价,估价eventually 终于evolution 进展excecution 执行,完成execute 执行electrochemical machining 电化学加工exerte 施加experience 经验explosive 爆炸(性)的extend 伸展external 外部的extract 拔出extreme 极端extremely 非常地extremity 极端extrusion 挤压,挤出envisage 设想Fahrenheit 华氏温度fabricate 制作,制造flat-panel technology 平面(显示)技术facility 设备facing 端面车削fall within 属于,适合于fan 风扇far from 毫不,一点不,远非fatigue 疲劳feasible 可行的feature 特色,特征feed 进给feedback 反馈female 阴的,凹形的ferrule 套管file system 文件系统fitter 装配工,钳工fix 使固定,安装fixed half and moving half 定模和动模facilitate 帮助flexibility 适应性,柔性flexible 柔韧的flow mark 流动斑点follow-on tool 连续模foregoing 在前的,前面的foretell 预测,预示,预言forge 锻造forming 成型four screen quadrants 四屏幕象限fracture 破裂free from 免于gap 裂口,间隙gearbox 齿轮箱govern 统治,支配,管理grain 纹理graphic 图解的grasp 抓住grid 格子,网格grind 磨,磨削,研磨grinding 磨光,磨削grinding machine 磨床gripper 抓爪,夹具groove 凹槽guide bush 导套guide pillar 导柱guide pillars and bushes 导柱和导套handset 电话听筒hardness 硬度hardware 硬件headstock 床头箱,主轴箱hexagonal 六角形的,六角的hindrance 障碍,障碍物hob 滚刀,冲头hollow-ware 空心件horizontal 水平的hose 软管,水管hyperbolic 双曲线的i.e. (id est) [拉]也就是identical 同样的identify 确定,识别idle 空闲的immediately 正好,恰好impact 冲击impart 给予implement 实现impossibility 不可能impression 型腔in contact with 接触in terms of 依据inasmuch (as) co因为,由于inch-to-metric conversions 英公制转换inclinable 可倾斜的inclusion 内含物inconspicuous 不显眼的incorporate 合并,混合indentation 压痕indenter 压头independently 独自地,独立地inevitably 不可避免地inexpensive 便宜的inherently 固有的injection mould 注塑模injection 注射in-line-of-draw 直接脱模insert 嵌件inserted die 嵌入式凹模inspection 检查,监督installation 安装integration 集成intelligent 智能的intentinonally 加强地，集中地interface 界面internal 内部的interpolation 插值法investment casting 熔模铸造irregular 不规则的，无规律irrespective of 不论,不管irrespective 不顾的,不考虑的issue 发布，发出joint line 结合线kerosene 煤油keyboard 健盘knock 敲，敲打lance 切缝lathe 车床latitude 自由lay out 布置limitation 限度,限制,局限(性) local intelligence 局部智能locate 定位logic 逻辑longitudinal 纵向的longitudinally 纵向的look upon 视作,看待lubrication 润滑machine shop 车间machine table 工作台machining 加工made-to-measure 定做maintenance 维护,维修majority 多数make use of 利用male 阳的,凸形的malfunction 故障mandrel 心轴manifestation 表现,显示massiveness 厚实，大块measure 大小,度量microcomputer 微型计算机microns 微米microprocessor 微处理器mild steel 低碳钢milling machine 铣床mineral 矿物,矿产minimise 把减到最少,最小化minute 微小的mirror image 镜像mirror 镜子moderate 适度的modification 修改,修正modulus 系数mold 模,铸模mold 制模,造型monitor 监控monograph 专著more often than not 常常motivation 动机mould split line 模具分型线moulding 注塑件move away from 抛弃multi-imprssion mould 多型腔模narrow 狭窄的NC (numerical control) 数控nevertheless 然而,不过nonferrous 不含铁的,非铁的normally 通常地novice 新手,初学者nozzle 喷嘴,注口numerical 数字的objectionable 有异议的，讨厌的observe 观察obviously 明显地off-line 脱机的on-line 联机operational 操作的,运作的opportunity 时机,机会opposing 对立的,对面的opposite 反面optimization 最优化orient 确定方向orthodox 正统的，正规的overall 全面的,全部的overbend 过度弯曲overcome 克服,战胜overlaping 重叠overriding 主要的,占优势的opposite 对立的,对面的pack 包装package 包装pallet 货盘panel 面板paraffin 石蜡parallel 平行的penetration 穿透peripheral 外围的periphery 外围permit 许可,允许pessure casting 压力铸造pillar 柱子,导柱pin 销,栓,钉pin-point gate 针点式浇口piston 活塞plan view 主视图plasma 等离子plastic 塑料platen 压板plotter 绘图机plunge 翻孔plunge 投入plunger 柱塞pocket-size 袖珍portray 描绘pot 壶pour 灌,注practicable 行得通的preferable 更好的,更可取的preliminary 初步的，预备的press setter 装模工press 压,压床,冲床,压力机prevent 妨碍primarily 主要地procedure 步骤,方法,程序productivity 生产力profile 轮廓progressively 渐进地project 项目project 凸出projection 突出部分proper 本身的property 特性prototype 原形proximity 接近prudent 谨慎的punch 冲孔punch shapper tool 刨模机punch-cum-blanking die 凹凸模punched tape 穿孔带purchase 买，购买push back pin 回程杆pyrometer 高温计quality 质量quandrant 象限quantity 量，数量quench 淬火radial 放射状的ram 撞锤rapid 迅速的rapidly 迅速地raster 光栅raw 未加工的raw material 原材料ream 铰大reaming 扩孔,铰孔recall 记起,想起recede 收回,后退recess 凹槽,凹座,凹进处redundancy 过多re-entrant 凹入的refer 指,涉及,谈及reference 参照,参考refresh display 刷新显示register ring 定位环register 记录,显示,记数regrind 再磨研relative 相当的,比较的relay 继电器release 释放relegate 把降低到reliability 可靠性relief valves 安全阀relief 解除relieve 减轻,解除remainder 剩余物,其余部分removal 取出remove 切除,切削reposition 重新安排represent 代表,象征reputable 有名的,受尊敬的reservoir 容器,储存器resident 驻存的resist 抵抗resistance 阻力,抵抗resolution 分辨率respective 分别的,各自的respond 响应,作出反应responsibility 责任restrain 抑制restrict 限制，限定restriction 限制retain 保持,保留retaining plate 顶出固定板reveal 显示，展现reversal 反向right-angled 成直角的rigidity 钢度rod 杆,棒rotate (使)旋转rough machining 粗加工rough 粗略的routine 程序rubber 橡胶runner and gate systems 流道和浇口系统sand casting 砂型铸造satisfactorily 满意地saw 锯子scale 硬壳score 刻划scrap 废料,边角料,切屑screwcutting 切螺纹seal 密封section cutting plane 剖切面secure 固定secure 紧固,夹紧,固定segment 分割sensitive 敏感的sequence 次序sequential 相继的seriously 严重地servomechanism 伺服机构servomotor 伺服马达setter 安装者set-up 机构sever 切断severity 严重shaded 阴影的shank 柄shear 剪,切shot 注射shrink 收缩side sectional view 侧视图signal 信号similarity 类似simplicity 简单single-point cutting tool 单刃刀具situate 使位于,使处于slide 滑动,滑落slideway 导轨slot 槽slug 嵌条soak 浸,泡,均热software 软件solid 立体,固体solidify (使)凝固solidify (使)固化solution 溶液sophisiticated 尖端的,完善的sound 结实的,坚固的spark erosion 火花蚀刻spindle 主轴spline 花键split 侧向分型,分型spool 线轴springback 反弹spring-loaded 装弹簧的sprue bush 主流道衬套sprue puller 浇道拉杆square 使成方形Servomechanism Laboratoies 伺服机构实验室stage 阶段standardisation 标准化startling 令人吃惊的steadily 稳定地step-by-step 逐步stickiness 粘性stiffness 刚度stock 毛坯,坯料storage tube display 储存管显示storage 储存器straightforward 直接的strain 应变strength 强度stress 压力,应力stress-strain 应力--应变stretch 伸展strike 冲击stringent 严厉的stripper 推板stroke 冲程,行程structrural build-up 结构上形成的sub-base 垫板subject 使受到submerge 淹没subsequent 后来的subsequently 后来,随后substantial 实质的substitute 代替,替换subtract 减,减去suitable 合适的,适当的suitably 合适地sunk 下沉,下陷superior 上好的susceptible 易受影响的sweep away 扫过symmetrical 对称的synchronize 同步,同时发生tactile 触觉的,有触觉的tailstock 尾架tapered 锥形的tapping 攻丝technique 技术tempering 回火tendency 趋向,倾向tensile 拉力的,可拉伸的tension 拉紧,张紧terminal 终端机terminology 术语,用辞theoretically 理论地thereby 因此,从而thermoplastic 热塑性的thermoplastic 热塑性塑料thermoset 热固性thoroughly 十分地,彻底地thread pitch 螺距thread 螺纹thrown up 推上tilt 倾斜,翘起tolerance 公差two-plate mould 双板式注射模tong 火钳tonnage 吨位,总吨数tool point 刀锋tool room 工具车间toolholder 刀夹,工具柄toolmaker 模具制造者toolpost grinder 工具磨床toolpost 刀架torsional 扭转的toughness 韧性trace 追踪transverse 横向的tray 盘，盘子，蝶treatment 处理tremendous 惊人的,巨大的trend 趋势trigger stop 始用挡料销tungsten 钨turning 车削twist 扭曲，扭转tracer-controlled milling machine 仿形铣床ultimately 终于undercut moulding 侧向分型模undercut 侧向分型undercut 底切underfeed 底部进料的undergo 经受underside 下面,下侧undue 不适当的,过度的uniform 统一的,一致的utilize 利用Utopian 乌托邦的,理想化的valve 阀vaporize 汽化vaporize (使)蒸发variation 变化various 不同的,各种的vector feedrate computation 向量进刀速率计算vee 字形velocity 速度versatile 多才多艺的,万用的vertical 垂直的via prep经,通过vicinity 附近viewpoint 观点wander 偏离方向warp 翘曲washer 垫圈wear 磨损well line 结合线whereupon 于是winding 绕,卷with respect to 相对于withstand 经受,经得起work 工件workstage 工序wrinkle 皱纹使皱yield 生产zoom 图象电子放大。

注塑专业术语1 ，注塑，吸塑，吹塑以及搪塑的区别注塑injection molding 是一种工业产品生产造型的方法。

产品通常使用橡胶注塑和塑料注塑。

注塑还可分注塑成型模压法。

和压铸法。

注射成型机（简称注射机或注塑机）是将热塑性塑料或热固性料利用塑料成型模具制成各种形状的塑料制品的主要成型设备，注射成型是通过注塑机和模具来实现的。

橡胶注塑：.橡胶注塑成型是一种将胶料直接从机筒注入模型硫化的生产方法。

橡胶注塑的优点是：虽属间歇操作，但成型周期短，生产效率高取消了胚料准备工序，劳动强度小，产品质量优异。

2.塑料注塑：.塑料注塑是塑料制品的一种方法，将熔融的塑料利用压力注进塑料制品模具中，冷却成型得到想要各种塑料件。

有专门用于进行注塑的机械注塑机。

目前最常使用的塑料是聚苯乙烯。

所得的形状往往就是最后成品，在安装或作为最终成品使用之前不再需要其他的加工。

许多细部，诸如凸起部、肋、螺纹，都可以在注射模塑一步操作中成型出来。

吸塑：Blister molding一种塑料加工工艺，主要原理是将平展的塑料硬片材加热变软后，采用真空吸附于模具表面，冷却后成型，广泛用于塑料包装、灯饰、广告、装饰等行业。

吸塑包装的主要优点是，节省原辅材料、重量轻、运输方便、密封性能好，符合环保绿色包装的要求；能包装任何异形产品，装箱无需另加缓冲材料；被包装产品透明可见，外形美观，便于销售，并适合机械化、自动化包装，便于现代化管理、节省人力、提高效率。

【吸塑成型对材料的要求】：吸塑成型只能生产壁厚比较均匀的产品，（一般倒角处稍薄），不能制得壁厚相差悬殊的塑料制品吸塑成型的壁厚一般在 1 到2mm 范围之内或更加薄（小包装用吸塑包装的片材最常用的厚度为0.15 到0.25mm ）吸塑成型制品的拉伸度受到一定的限制，吸塑成型的塑料容器直径深度比一般不超过1 ，极端情况下亦不得超过1.5 .吸塑成型的尺寸精度差，其相对误差一般在百分之一以上。

06/13/2001 射出成型(品) Page:1/1流纹streak 皱纹wrinkle 浪痕 , 辉纹striation收缩(缩水) shrinkage 收缩孔Shrinkage pool ,sink mark 应力龟裂Stress cracking充填不足Short shot 痕迹 , 疤scar 辐纹Spider line缺胶面Resin starvedarea 表皮skin 翘曲Curling , curl ,warp , warpage过充填Over-packing 废料(料头) slagging 脆化温度Brittle temperature泛白blushing 成型molding 成型品moldings 射出压力Injection pressure 成型面积Mold area 脆性brittleness 注射shot 固化时间Setting time 染料dye烧 , 烤stoving 空气隙Air gap 喷嘴nozzle原色Nature color 排气Breathing ,degassing ,bumping成型纹Mold mark橡胶Gum , rubber 色片Color chip 杂质cull合模力Moldclamping(locking) force开模力Mold openingforce 压光法Press polish干燥时间Drying time 颜料pigment 硬化时间Curing time后加工Post processing 油漆,涂料paint 合模线Parting line异物Foreign matter 印刷printing 熔痕Weld mark熔合线Weld line 凝固coagulation 龟裂Crack , cracking 缺陷defect 潜变creep 冷料Cold slug刮伤abrasion 残留应力Residual stress 修整finishing喷射流纹jetting 热劣化Thermaldegradation 排气孔Vent , air gap吸附作用adsorption 背压Back pressure 加热桶barrel黑条线Black streak 渗透bleed 起泡blister毛边Burr , fin , flash 冷料井Cold slug well 裂纹crazing成型时间Cycle time 分解degradation 脱脂degreasing 变色discoloration 保压dwelling 保压时间Dwelling time 雾状haze 过充填Over-packing 退色fading坑,洼pit 后收缩Post shrinkage 补土putty除毛边trimming 加温Warming up 粘度viscosity修边deflashing ,definning 烧痕Burn mark 变形,毁坏deformation偏光板Polarizing plate 烘培Bake , baking 预热preheating脱模剂Mold releaseagent 老化时间Aging time 表面处理Surfacetreatment热劣化Thermaldegradation 瓦斯痕迹Gas mark 充填剂filler塑料粒料pellet 射出机拉杆Tie bar, tie rod 机台拉杆间距Tie bar distance料斗hopper 橘子皮Orange peel 流动性Flow behavior成品肉厚Wall thickness06/13/2001模具mold夹具jig 浇口sprue 衬板(承板) Backing plate , support plate调理conditioning 间隔块Spacer block 冲切punching脱料板Stripper plate 套管sleeve 顶出套管Sleeve ejection 行程stroke 空气顶出Air ejection 顶出杆Eject rod回弹Spring back 蚀刻etching 流入角Entrance angle 压花embossing 模孔orifice O环O ring导板Guide plate 垫圈gasket 合模机构Mold clamping mechanism合模时间Closing time 润滑剂lubricant 模座Mold base简易模Simplified mold 母模穴cavity 多穴模具Gang mold , multi-cavity钻孔drilling 导孔Dowel hole ,guide hole 导销(GP) Guide pin导套Dowel bushing 定位销Anchor pin 斜销Angular pin倒钩undercut 下料模Blanking die 镜面拋光Mirror polishing 切口notch 公模core 金钢砂emery复归销(RPN) Surface(return) pin 喷砂Sand blast 表面处理Surfacetreatment导流板baffle 起霜(油花) blooming 放电处理Electro-discharg e treatment锥度Taper , draft 定位环Locating ring 咬花texture钻石刀具Diamond cutter 压铸Die casting 衬垫packing布轮拋光buffing 冲头punch 铣削milling下料blanking 胚料blank 排气孔vent圆棒rod 脱模板Stripper plate 潜入式胶口Submarine gate 柄型胶口Tab gate 三板模Three plate mold 雕刻,咬花Engraving镶块Insert core ,Insertblock 衬套Bushing 模具冷却水路Cooling lines,water channel顶出系统Ejector systems 浇道系统Runner systems 滑块Slide core 斜销LifterCycle阀浇口Valve gate 公母模相嵌靠面Shutoff surface 耐磨板Wear plate 沟槽groove隔热板Insulator plate 环首螺栓Eye-bolt 石墨Graphite四方定位块interlock 组合模具Family mold 料头拉销Sprue ejector pin, Sprue puller pin, Sprue lock pin, runner lockpin浇道衬套Sprue bush 冲压模具Die 顶出板Ejector plate, knock-out plate拔模Draft 模具痕迹Mold mark 水路塞子baffle横浇道Runner 镶件滑动固定块Locking block,clamping block 冲压件切口Notch吊模孔Tapped hole forEyebolt 六角螺丝S.H.C.S. 连续模Progressive die分离式针尖浇口Detachableknock-out pingate顶针隧道式浇口Tunnel gate intopin牛角隧道式浇口Curved tunnelgate06/13/2001机构其它跟部圆弧半径Heel radius 尺寸稳定性Dimensionalstability 粘合Bonding , jointing滑入配合Snap fitting 静电Static electricity 接触角Contact angle滑动摩擦Sliding friction 绝缘材料Insulationmaterial 绝缘涂料Insulating coating喷雾枪Spray gun 空气喷枪Air gun 边缘引导Edge guide沿边Edge wise 砂布Emery cloth 砂纸Emery paper延伸,拉伸stretching 应力stress 污染contamination 重叠overlap 椭圆形状ovaloid 弯曲加工folding复原recovery 界面interface 表面张力Surface tension 硬度hardness 悬臂梁cantilever 热损失Heating loss打底涂层undercoat 印刷电路板Printed circuitsboard 印刷性printability透明漆Clear lacquer 亮光涂层Gel coating 熔接welding刚性rigidity 光彩,光泽gloss 热敏电子thermister自攻螺丝Tapping screw 粘着adhesion 背胶Adhesive tape防静电处理Antistatictreatment 背面涂布Back coating 带锯Band saw真空包装Blister package 圆角fillet 偏心Off center 拉钉One way rivet 上胶sizing 削尖接合Scarf joint浸泡soaking 快干胶Fast settingadhesives 损坏damage粘合(结合)时间Assembly time 粘性tackiness 疲劳fatigue压扁collapse 转印Decal , decalcomania ,transfer导电粘着剂Electroconductive glue渗透性permeability 行程Travel,Stroke 内应力Internal stress 锯切Saw cutting 剥离peeling 离型纸Release paper渗漏Sweat out 发泡成型Foaming ,expansionmolding膜泡包装Bubble pack滚桶研磨Barel polishing 比重Specific gravity 原型产品Prototype (电)镀plating 烤漆Baking paint 按键卡键Sticky key网版印刷Silk print 扭转Torgue,Twist 印刷模糊不清Printing muddyTBD To Be Define 平光面matted 退色FadeTA TravelCharger外露expose 表面刮伤Surface scratchCLA CigaretteCharger 折痕,皱纹Crease防静电包装袋Anti-static vinyl纸张破损Paper scrap 歪斜slant 保护贴纸Protect tape污点stain 暗淡,模糊Dimming 破音plosive混淆mix-up 双面胶Double tape 稀释剂Thinner脱落Come-off 螺丝头Screw tip 烧结sintering腐蚀corrosion 电镀层Gilding 不好的设计Poor design雷射雕刻Laser-Etch 截面Cross section 硬的stiff断裂点Break of point 圆锥形的conical06/13/2001试验冲击试验Impact test 扭力试验Torsion test 静电试验ESD Electrostatic dischargeRTC Real TimeCalculate融溶体积流动测试(MVR)Melt Volume-flowRate机构设计及生产常用专业英语单词组装、冲压、喷漆等专业词汇Assembly line组装线 Layout布置图 Conveyer流水线物料板 Rivet table拉钉机 Rivet gun拉钉枪 Screw driver起子Electric screw river子 Pneumatic screw driver气动起子 worktable 工作桌 OOBA开箱检查 fit together组装在一起fasten锁紧(螺丝) fixture 夹具(治具) pallet栈板 barcode条码 barcode scanner条码扫描器 fuse together熔合fuse machine热熔机 repair修理 operator作业员 QC品管 supervisor 课长 ME制造工程师 MT制造生技 cosmetic inspect外观检查inner parts inspect内部检查 thumb screw大头螺丝 lbs. inch镑、英寸 EMI gasket导电条front plate前板 rear plate后板 chassis 基座 bezel panel面板 power button电源按键 reset button重置键Hi-pot test of SPS高源高压测试 Voltage switch of SPS 电源电压接拉键 sheet metal parts 冲件plastic parts塑胶件 SOP制造作业程序 material check list物料检查表 work cell工作间 trolley台车 carton纸箱 sub-line支线left fork叉车 personnel resource department 人力资源部 production department生产部门 planning department企划部QC Section品管科 stamping factory冲压厂 painting factory烤漆厂 molding factory 成型厂 common equipment常用设备uncoiler and straightener整平机 punching machine 冲床 robot机械手 hydraulic machine油压机 lathe车床 planer |'plein?|刨床miller铣床 grinder磨床 driller??床 linear cutting线切割 electrical sparkle电火花 welder电焊机 staker=reviting machine铆合机position职务 president董事长 general manager总经理 special assistant manager特助 factory director厂长 department director部长deputy manager | =vice manager副理 section supervisor课长 deputy section supervisor =vice section superisor副课长group leader/supervisor组长 line supervisor线长 assistant manager助理 to move, to carry, to handle搬运be put in storage入库 pack packing包装 to apply oil擦油 to file burr 锉毛刺 final inspection终检to connect material接料 to reverse material 翻料 wet station沾湿台 Tiana天那水 cleaning cloth抹布to load material上料to unload material卸料to return material/stock to退料 scraped |'skr?pid|报废scrape ..v.刮;削 deficient purchase来料不良 manufacture procedure制程 deficient manufacturing procedure制程不良oxidation |' ksi'dei?n|氧化 scratch刮伤 dents压痕 defective upsiding down抽芽不良 defective to staking铆合不良embedded lump镶块feeding is not in place送料不到位stamping-missing漏冲 production capacity生产力education and training教育与训练 proposal improvement提案改善 spare parts=buffer 备件 forklift叉车 trailer=long vehicle拖板车compound die合模 die locker锁模器 pressure plate=plate pinch压板 bolt螺栓 name of a department部门名称administration/general affairs dept总务部 automatic screwdriver电动启子 thickness gauge厚薄规 gauge(or jig)治具power wire电源线 buzzle蜂鸣器 defective product label不良标签 identifying sheet list标示单screwdriver holder起子插座 pedal踩踏板 stopper阻挡器 flow board流水板 hydraulic handjack油压板车forklift叉车 pallet栈板 glove(s)手套 glove(s) with exposed fingers割手套thumb大拇指 forefinger食指 midfinger中指 ring finger无名指 little finger小指 band-aid创可贴 iudustrial alcohol工业酒精 alcohol container沾湿台 head of screwdriver起子头 sweeper扫把mop拖把 vaccum cleaner吸尘器 rag 抹布 garbage container灰箕 garbage can垃圾箱 garbage bag垃圾袋 chain链条jack升降机 production line流水线 chain链条槽 magnetizer加磁器 lamp holder灯架 to mop the floor拖地to clean the floor扫地 to clean a table擦桌子 air pipe 气管 packaging tool打包机 packaging打包 missing part漏件wrong part错件 excessive defects过多的缺陷 critical defect极严重缺陷 major defect 主要缺陷 minor defect次要缺陷not up to standard不合规格 dimension/size is a little bigger尺寸偏大(小) cosmetic defect外观不良slipped screwhead/slippery screw head螺丝滑头 slipped screwhead/shippery screw thread滑手speckle斑点mildewed=moldy=mouldy发霉rust生锈deformation变形burr(金属)flash(塑件)毛边 poor staking铆合不良excesssive gap间隙过大 grease/oil stains油污 inclusion杂质 painting peel off脏污 shrinking/shrinkage缩水mixed color杂色 scratch划伤 poor processing 制程不良 poor incoming part事件不良 fold of pakaging belt打包带折皱 painting make-up补漆 discoloration羿色 water spots水渍polishing/surface processing表面处理 exposed metal/bare metal金属裸露 lack of painting烤漆不到位safety安全 quality品质 delivery deadline交货期 cost成本 engineering工程 die repair模修enterprise plan = enterprise expansion projects企划QC品管die worker模工 production, to produce生产 equipment设备to start a press开机 stop/switch off a press关机 classification整理 regulation 整顿 cleanness清扫 conservation清洁culture教养 qualified products, up-to-grade products良品 defective products, notup-to-grade products不良品waste废料 board看板 feeder送料机 sliding rack滑料架 defective product box不良品箱 die change 换模 to fix a die装模to take apart a die拆模 to repair a die修模 packing material包材 basket蝴蝶竺 plastic basket胶筐isolating plate baffle plate; barricade隔板 carton box纸箱to pull and stretch拉深 to put material in place, to cut material, to input落料 to impose lines压线 to compress, compressing压缩 character die字模 to feed, feeding送料transportation运输 (be)qualfied, up to grade合格 not up to grade, not qualified 不合格material change, stock change材料变更 feature change 特性变更evaluation评估 prepare for, make preparations for 准备parameters参数 rotating speed, revolution转速manufacture management制造管理 abnormal handling异常处理 production unit生产单位lots of production生产批量 steel plate钢板 roll material卷料manufacture procedure制程 operation procedure作业流程to revise, modify修订 to switch over to, switch---to throw--over switching over 切换engineering, project difficulty工程瓶颈 stage die工程模 automation自动化 to stake, staking, reviting铆合add lubricating oil加润滑油 shut die架模 shut height of a die架模高度 analog-mode device类模器 die lifter举模器argon welding氩焊 vocabulary for stamping 冲压常词汇 stamping, press冲压 punch press, dieing out press冲床uncoiler & strainghtener整平机 feeder送料机 rack, shelf, stack料架 cylinder油缸 robot机械手 taker取料机 conveyer belt输送带 transmission rack输送架 top stop上死点bottom stop下死点 one stroke一行程 inch寸动to continue, cont.连动 to grip(material)吸料location lump, locating piece, block stop 定位块 reset复位 smoothly顺利 dent压痕 scratch刮伤 deformation变形filings铁削 to draw holes抽孔 inquiry, search for查寻 to stock, storage, in stock 库存receive领取 approval examine and verify审核 processing, to process加工 delivery, to deliver 交货 to return delivenry to .to send delinery back to retrn of goods退货registration登记 registration card登记卡 to control管制 to put forward and hand in提报 safe stock安全库存acceptance = receive验收 to notice通知 application form for purchase请购单 consume, consumption消耗to fill in填写 abrasion磨损 reverse angle = chamfer倒角 character die字模 to collect, to gather收集failure, trouble故障 statistics统计 demand and supply需求 career card履历卡 to take apart a die卸下模具to load a die装上模具 to tight a bolt拧紧螺栓 to looser a bolt拧松螺栓to move away a die plate移走模板 easily damaged parts易损件standard parts标准件 breaking.(be)broken,(be)cracked 断裂to lubricate润滑 common vocabulary for die engineering模具工程常用词汇die 模具 figure file, chart file图档 cutting die, blanking die冲裁模 progressive die, follow (-on)die 连续模 compound die复合模 punched hole冲孔 panel board镶块 to cutedges=side cut=side scrap切边to bending折弯to pull, to stretch拉伸 Line streching, line pulling线拉伸engraving, to engrave刻印 upsiding down edges翻边 to stake铆合 designing, to design设计design modification设计变化 die block模块 folded block折弯块 sliding block滑块 location pin定位销lifting pin顶料销 die plate, front board模板 padding block垫块 stepping bar垫条 upper die base上模座 lower die base下模座 upper supporting blank上承板upper padding plate blank上垫板 spare dies模具备品 spring 弹簧 bolt螺栓 document folder文件夹file folder资料夹 to put file in order整理资料 spare tools location手工备品仓 first count初盘人first check初盘复棹人 second count 复盘人 second check复盘复核人 equipment设备 waste materials废料work in progress product在制品 casing = containerazation装箱 quantity of physical invetory second count 复盘点数量quantity of customs count 会计师盘,点数量 the first page第一联filed by accounting department for reference会计部存查end-user/using unit(department)使用单位summary of year-end physical inventory bills 年终盘点截止单据汇总表bill name单据名称This sheet and physical inventory list will be sent to accountingdepartment together (Those of NHK will be sent to financialdepartment)本表请与盘点清册一起送会计部－(NHK厂区送财会部)Application status records of year-end physical inventory List andphysical inventory card 年终盘点卡与清册使用－状况明细表blank and waste sheet NO. 空白与作废单号plate电镀 mold成型material for engineering mold testing工程试模材料not included in physical inventory不列入盘点sample样品 incoming material to be inspected进货待验description品名 steel/rolled steel钢材material statistics sheet 物料统计明细表meeting minutes会议记录 meeting type 会别 distribution department分发单位 location地点 chairman主席 present members出席人员 subject主题conclusion结论 decision items决议事项responsible department负责单位 pre-fixed finishing date预定完成日approved by / checked by / prepared by核准/审核/承办PCE assembly production schedule sheet PCE组装厂生产排配表model机锺 work order工令 revision版次 remark备注 production control confirmation 生产确认 checked by初审approved by核准 department部门 stock age analysis sheet 库存货龄分析表 on-hand inventory现有库存available material良品可使用 obsolete material良品已呆滞to be inspected or reworked待验或重工total合计cause description原因说明part number/ P/N 料号type形态 item/group/class类别 quality品质prepared by制表 notes说明year-end physical inventory difference analysis sheet 年终盘点差异分析表 physical inventory盘点数量 physical count quantity帐面数量difference quantity差异量 cause analysis原因分析 raw materials原料materials物料 finished product成品 semi-finished product半成品packing materials包材 good product/accepted goods/ accepted parts/good parts良品 defective product/non-good parts不良品 disposed goods处理品warehouse/hub仓库 on way location在途仓 oversea location海外仓spare parts physical inventory list备品盘点清单spare molds location模具备品仓 skid/pallet栈板tox machine自铆机 wire EDM线割 EDM放电机 coil stock卷料sheet stock片料 tolerance工差 score=groove压线 cam block滑块 pilot导正筒 trim 剪外边pierce剪内边 drag form压锻差 pocket for the punch head挂钩槽 slug hole废料孔 feature die公母模 expansion dwg展开图 radius半径 shim(wedge)楔子torch-flame cut火焰切割 set screw止付螺丝form block折刀 stop pin定位销 round pierce punch=die button圆冲子 shape punch=die insert异形子stock locater block定位块 under cut=scrap chopper清角 active plate活动板baffle plate挡块 cover plate盖板 male die公模 female die母模groove punch压线冲子 air-cushion eject-rod气垫顶杆 spring-box eject-plate弹簧箱顶板bushing block衬套 insert 入块 club car高尔夫球车 capability能力parameter参数 factor系数phosphate皮膜化成 viscosity涂料粘度alkalidipping脱脂 main manifold主集流脉bezel斜视规 blanking穿落模dejecting顶固模 demagnetization去磁;消磁 high-speed transmission高速传递heat dissipation热传 rack上料 degrease脱脂 rinse水洗alkaline etch龄咬 desmut剥黑膜 D.I. rinse纯水次Chromate铬酸处理Anodize阳性处理 seal封孔revision版次part number/P/N料号 good products良品 scraped products报放心品defective products不良品 finished products成品 disposed products处理品 barcode条码 flow chart流程表单 assembly组装stamping冲压 molding成型spare parts=buffer备品 coordinate座标 dismantle the die折模 auxiliary fuction 辅助功能 poly-line多义线heater band 加热片thermocouple热电偶sand blasting喷沙 grit 砂砾 derusting machine除锈机 degate打浇口 dryer烘干机 induction感应 induction light感应光response=reaction=interaction感应ram连杆 edge finder巡边器 concave凸 convex凹short射料不足 nick缺口 speck瑕??shine亮班 splay 银纹 gas mark焦痕delamination起鳞 cold slug冷块 blush 导色 gouge沟槽;凿槽satin texture段面咬花 witness line证示线 patent专利 grit沙砾granule=peuet=grain细粒grit maker抽粒机 cushion缓冲magnalium镁铝合金magnesium镁金 metal plate钣金 lathe车 mill锉plane刨 grind磨 drill铝 boring镗 blinster气泡 fillet镶;嵌边 through-hole form 通孔形式voller pin formality滚针形式cam driver铡楔 shank摸柄 crank shaft曲柄轴augular offset角度偏差velocity速度 production tempo生产进度现状 torque扭矩 spline=the multiple keys 花键 quenching淬火tempering回火 annealing退火 carbonization碳化tungsten high speed steel钨高速的moly high speed steel钼高速的 organic solvent有机溶剂bracket小磁导 liaison联络单 volatile挥发性 resistance电阻ion离子 titrator滴定仪 beacon警示灯 coolant冷却液crusher破碎机 模具工程类 plain die简易模 pierce die冲孔模 forming die成型模 progressive die连续模 gang dies复合模 shearing die剪边模 riveting die铆合模 pierce冲孔forming成型(抽凸,冲凸) draw hole抽孔 bending折弯 trim切边emboss凸点 dome凸圆 semi-shearing半剪 stamp mark冲记号deburr or coin压毛边 punch riveting冲压铆合 side stretch侧冲压平reel stretch卷圆压平groove压线 blanking下料 stamp letter冲字(料号)shearing剪断tick-mark nearside正面压印tick-mark farside反面压印冲压名称类extension dwg展开图procedure dwg工程图die structure dwg模具结构图material材质material thickness料片厚度factor系数upward向上downward向下press specification冲床规格 die height range适用模高 die height闭模高度 burr毛边 punch wt.上模重量五金零件类inner guiding post内导柱 inner hexagon screw内六角螺钉dowel pin固定销 coil spring弹簧 lifter pin顶料销eq-height sleeves=spool等高套筒 pin销 lifter guide pin浮升导料销 guide pin导正销 wire spring圆线弹簧outer guiding post外导柱stop screw止付螺丝located pin定位销 outer bush外导套 模板类 top plate上托板（顶板）top block上垫脚 punch set上模座 punch pad上垫板 punch holder上夹板 stripper pad 脱料背板 up stripper上脱料板male die公模(凸模) feature die公母模 female die母模(凹模) upper plate上模板 lower plate下模板die pad下垫板 die holder下夹板 die set下模座 bottom block下垫脚 bottom plate下托板(底板) stripping plate内外打(脱料板)outer stripper外脱料板 inner stripper内脱料板 lower stripper下脱料板 零件类 punch冲头 insert入块(嵌入件) deburring punch压毛边冲子groove punch压线冲子 stamped punch字模冲子 round punch圆冲子 special shape punch 异形冲子bending block折刀 roller滚轴 baffle plate挡块 located block定位块 supporting block for location 定位支承块air cushion plate气垫板 air-cushion eject-rod气垫顶杆 trimming punch切边冲子stiffening rib punch = stinger 加强筋冲子ribbon punch压筋冲子 reel-stretch punch卷圆压平冲子 guide plate定位板 sliding block滑块 sliding dowel block滑块固定块active plate活动板 lower sliding plate下滑块板 upper holder block上压块 upper mid plate上中间板 spring box弹簧箱spring-box eject-rod弹簧箱顶杆 spring-box eject-plate弹簧箱顶板 bushing bolck衬套 cover plate盖板 guide pad导料块塑件&模具相关英文compre sion molding压缩成型 flash mold溢流式模具 plsitive mold挤压式模具 split mold分割式模具cavity型控 母模 core模心 公模 taper锥拔 leather cloak仿皮革 shiver饰纹 flowmark流痕 welding mark溶合痕post screw insert螺纹套筒埋值 self tapping screw自攻螺丝 striper plate脱料板 piston活塞 cylinder汽缸套chip细碎物 handle mold手持式模具 移转成型用模具 encapsulation molding低压封装成型 射出成型用模具two plate两极式（模具） well type蓄料井 insulated runner绝缘浇道方式 hot runner 热浇道runner plat浇道模块 valve gate阀门浇口 band heater环带状的电热器 spindle阀针 spear head刨尖头slag well冷料井 cold slag冷料渣 air vent排气道 h=0.02~0.05mm w=3.2mm L=3~5mm welding line熔合痕 eject pin顶出针knock pin顶出销 return pin回位销反顶针 sleave套筒 stripper plate脱料板 insert core放置入子 runner stripper plate浇道脱料板guide pin导销 eject rod (bar)（成型机）顶业捧 subzero深冷处理 three plate三极式模具runner system浇道系统 stress crack应力电裂 orientation定向 sprue gate射料浇口，直浇口 nozzle射嘴sprue lock pin料头钩销(拉料杆) slag well冷料井 side gate侧浇口 edge gate侧缘浇口 tab gate搭接浇口film gate薄膜浇口 flash gate闸门浇口 slit gate缝隙浇口 fan gate扇形浇口 dish gate 因盘形浇口H=F=1/2t~1/5t T=2.5~3.5mmdiaphragm gate隔膜浇口 ring gate环形浇口subarine gate潜入式浇口 tunnel gate隧道式浇口 pin gate针点浇口 Φ0.8~1.0mm Runner less无浇道(sprue less)无射料管方式 long nozzle延长喷嘴方式 sprue浇口;溶渣品质人员名称类QC quality control 品质管理人员 FQC final quality control 终点品质管制人员 IPQC in process quality control 制程中的品质管制人员 OQC output quality control 最终出货品质管制人员IQC incoming quality control 进料品质管制人员 TQC total quality control 全面质量管理POC passage quality control 段检人员 QA quality assurance 质量保证人员 OQA output quality assurance 出货质量保证人员QE quality engineering 品质工程人员 品质保证类FAI first article inspection 新品首件检查 FAA first article assurance 首件确认 TVR tool verification report 模具确认报告 3B 3B 模具正式投产前确认 CP capability index 能力指数CPK capability index of process 模具制程能力参数 SSQA standardized supplier quality 合格供应商品质评估OOBA out of box audit 开箱检查 QFD quality function deployment 品质机能展开 FMEA failure model effectiveness analysis 失效模式分析8 disciplines 8项回复内容 FA final audit 最後一次稽核 CAR corrective action request 改正行动要求corrective action report 改正行动报告FQC运作类AQL Acceptable Quality Level 运作类允收品质水准S/S Sample size 抽样检验样本大小 ACC Accept 允收 REE Reject 拒收 CR Critical 极严重的 MAJ Major 主要的MIN Minor 轻微的 AOQ Average Output Quality 平均出厂品质 AOQL Average Output Quality Level 平均出厂品质Q/R/S Quality/Reliability/Service 品质/可靠度服务 MIL-STD Military-Standard 军用标准 S I-S IV Special I-Special IV 特殊抽样水准等级P/N Part Number 料号 L/N Lot Number 特采 AOD Accept On Deviation 特采UAI Use As It 首件检查报告 FPIR First Piece Inspection Report 百万分之一PPM Percent Per Million 批号制程统计品管专类SPC Statistical Process Control 统计制程管制SQC Statistical Quality Control 统计品质管制 R Range 全距 AR Averary Range 全距平均值UCL Upper Central Limit 管制上限 LCL Lower Central Limit 管制下限 MAX Maximum 最大值 MIN Minimum 最小值 GRR Gauge Reproducibility&Repeatability 量具之再制性及重测性判断量可靠与否DIM Dimension 尺寸 DIA Diameter 直径 FREQ Frequency 频率 N Number 样品数其它品质术语类QCC Quality Control Circle 品质圈 QIT Quality Improvement Team 品质改善小组 PDCA Plan Do Check Action 计划 执行 检查 总结ZD Zero Defect 零缺点 QI Quality Improvement 品质改善 QP Quality Policy 目标方针 TQM Total Quality Management 全面品质管理 MRB Material Reject Bill 退货单 LQL Limiting Quality Level 最低品质水准RMA Return Material Audit 退料认可 QAN Quality Amelionrate Notice 品质改善活动 ADM Absolute Dimension Measuremat 全尺寸测量 QT Quality Target 品质目标7QCTools 7 Quality Controll Tools 品管七大手法通用之件类ECN Engineering Change Notes 工程变更通知(供应商)ECO Engineering Change Order 工程改动要求(客户)PCN Process Change Notice 工序改动通知PMP Product Management Plan 生产管制计划SIP Specification In Process 制程检验规格SOP Standard Operation Procedure 制造作业规范IS Inspection Specification 成品检验规范BOM Bill Of Material 物料清单PS Package Specification 包装规范SPEC Specification 规格DWG Drawing 图面系统文件类QC Quality System 品质系统ES Engineering Standarization 工程标准CGOO China General PCE龙华厂文件H Huston (美国)休斯敦C Compaq (美国)康伯公司C China 中国大陆A Assembly 组装(厂)S Stamping 冲压(厂)P Painting 烤漆(厂)I Intel 英特尔公司T TAIWAN 台湾IWS International Workman Standard 工艺标准ISO International Standard Organization 国际标准化组织GS General Specification 一般规格CMCS C-China M-Manufact C-Compaq S-Stamping Compaq产品在龙华冲压厂制造作业规范 CQCA Q-Quality A-Assembly Compaq产品在龙华组装厂品管作业规范CQCP P-Painting Compaq产品在龙华烤漆厂品管作业规范部类PMC Production & Material Control 生产和物料控制PPC Production Plan Control 生产计划控制MC Material Control 物料控制ME Manafacture Engineering 制造工程部PE Project Engineering 产品工程部A/C Accountant Dept 会计部P/A Personal & Administration 人事行政部DC Document Center 资料中心QE Quality Engineering 品质工程(部)QA Quality Assurance 品质保证(处)QC Quality Control 品质管制(课)PD Product Department 生产部LAB Labratry 实验室IE Industrial Engineering 工业工程R&D Research & Design 设计开发部P Painting 烤漆(厂)A Asssembly 组装(厂)S Stamping 冲压(厂)生产类PCS Pieces 个(根,块等)PRS Pairs 双(对等)CTN Carton 卡通箱PAL Pallet/skid 栈板PO Purchasing Order 采购订单MO Manufacture Order 生产单D/C Date Code 生产日期码ID/C Identification Code (供应商)识别码SWR Special Work Request 特殊工作需求L/N Lot Number 批号P/N Part Number 料号其它OEM Original Equipment Manufacture 原设备制造 PCE Personal Computer Enclosure 个人电脑外设 PC Personal Computer 个人电脑CPU Central Processing Unit 中央处理器SECC SECC` 电解片SGCC SGCC 热浸镀锌材料NHK North of Hongkong 中国大陆PRC People's Republic of China 中国大陆U.S.A the United States of America 美国A.S.A.P As Soon As Possible 尽可能快的E-MAIL Electrical-Mail 电子邮件N/A Not Applicable 不适用QTY Quantity 数量VS 以及REV Revision 版本JIT Just In Time 零库存I/O Input/Output 输入/输出OK Ok 好NG Not Good 不行,不合格C=0 Critical=0 极严重不允许ESD Electry-static Discharge 静电排放5S 希腊语 整理,整顿,清扫,清洁,教养ATIN Attention 知会CC Carbon Copy 副本复印相关人员APP Approve 核准,认可,承认CHK Check 确认AM Ante Meridian 上午PM Post Meridian 下午CD Compact Disk 光碟CD-ROM Compact Disk Read-Only Memory 只读光碟 FDD Floppy Disk Drive 软碟机HDD Hard Disk Drive 碟碟机REF Reference 仅供参考CONN Connector 连接器CAV Cavity 模穴CAD Computer Aid Design 计算机辅助设计ASS'Y Assembly 装配,组装MAT'S Material 材料IC Integrated Circuit 集成电路T/P True Position 真位度TYP Type 类型WDR Weekly Delivery Requitement 周出货需求C?T Cycle Time 制程周期L/T Lead Time 前置时间(生产前准备时间)S/T Standard Time 标准时间P/M Product Market 产品市场3C Computer,Commumcation,Consumer electronic's 消费性电子5WIH When,Where,Who,What,Why,How to5M Man,Machine,Material,Method,Measurement4MIH Man,Materia,Money,Method,Time 人力,物力,财务,技术,时间(资源) SQA Strategy Quality Assurance 策略品质保证DQA Desigh Quality Assurance 设计品质保证MQA Manufacture Quality Assurance 制造品质保证SSQA Sales and service Quality Assurance 销售及服务品质保证LRR Lot Rejeet Rate 批退率BS Brain storming 脑力激荡EMI Electronic Magnetion Inspect 高磁测试FMI Frequency Modulatim Inspect 高频测试B/M Boar/Molding(flat cable)C/P Connector of PCA/P AssemblySPS Switching power supply 电源箱DT Desk Top 卧式(机箱)MT Mini-Tower 立式(机箱)DVD Digital Vedio DiskVCD Vdeio Compact DiskLCD Liquid Crystal DisplayCAD Computer AID DesignCAM Computer AID ManufacturingCAE Computer AID EngineeringABIOS Achanced Basic in put/output system 先进的基本输入/输出系统 CMOS Complemeruary Metoll Oxide Semiconductor 互补金属氧化物半导体 PDA Personal Digital Assistant 个人数字助理IC Integrated Circuit 集成电路ISA Industry Standard Architecture 工业标准体制结构MCA Micro Channel Architecture 微通道结构EISA Extended Industry Standard Architecture 扩充的工业标准结构 SIMM Single in-line memory module 单项导通汇流组件DIMM Dual in-line Memory Module 双项导通汇流组件LED Light-Emitting Diode 发光二级管FMEA Failure Mode Effectivenes 失效模式分析W/H Wire Harness 金属线绪束集组件F/C Flat Calle 排线PCB Printed Circuit Board 印刷电路板CAR Correction Action Report 改善报告NG Not Good 不良WPR Weekly Delivery Requirement 周出货要求PPM Parts Per Million 百万分之一TPM Total Production Maintenance 全面生产保养MRP Material Requiremcnt Planning 物料需计划OC Operation System 作业系统TBA To Be Design 待定,定缺D/C Drawing ChangeP/P Plans & ProceduneEMI Electrical-Music Industry 电子音乐工业RFI Read Frequency Input 读频输入MMC Maximum Material ConditionMMS Maximum Material SizeLMC Least Material ConditionLMS Least Material Size模具技术用语各种模具常用成形方式accurate die casting 精密压铸 powder forming 粉末成形 calendaring molding 压延成形 powder metal forging 粉末锻造cold chamber die casting 冷式压铸 precision forging 精密锻造 cold forging 冷锻 press forging 冲锻compacting molding 粉末压出成形 rocking die forging 摇动锻造 compound molding 复合成形 rotary forging 回转锻造compression molding 压缩成形 rotational molding 离心成形dip mold 浸渍成形 rubber molding 橡胶成形encapsulation molding 注入成形 sand mold casting 砂模铸造 extrusion molding 挤出成形 shell casting 壳模铸造foam forming ?泡成形 sinter forging 烧结锻造forging roll 轧锻 six sides forging 六面锻造gravity casting 重力铸造 slush molding 凝塑成形hollow(blow) molding 中空(吹出)成形 squeeze casting 高压铸造hot chamber die casting 热室压铸 swaging 挤锻hot forging 热锻 transfer molding 转送成形injection molding 射出成形 warm forging 温锻investment casting 精密铸造 matched die method 对模成形法laminating method 被覆淋膜成形 low pressure casting 低压铸造lost wax casting 脱蜡铸造 matched mould thermal forming 对模热成形模各式模具分类用语bismuth mold 铋铸模 landed plunger mold 有肩柱塞式模具burnishing die 挤光模 landed positive mold 有肩全压式模具button die 镶入式圆形凹模 loading shoe mold 料套式模具center-gated mold 中心浇口式模具 loose detail mold 活零件模具chill mold 冷硬用铸模 loose mold 活动式模具clod hobbing 冷挤压制模 louvering die 百叶窗冲切模composite dies 复合模具 manifold die 分歧管模具counter punch 反凸模 modular mold 组合式模具double stack mold 双层模具 multi-cavity mold 多模穴模具 electroformed mold 电铸成形模 multi-gate mold 复式浇口模具expander die 扩径模 offswt bending die 双折冷弯模具extrusion die 挤出模 palletizing die 叠层模family mold 反套制品模具 plaster mold 石膏模blank through dies 漏件式落料模 porous mold 通气性模具duplicated cavity plate 复板模 positive mold 全压式模具fantail die 扇尾形模具 pressure die 压紧模fishtail die 鱼尾形模具 profile die 轮廓模flash mold 溢料式模具 progressive die 顺序模gypsum mold 石膏铸模 protable mold 手提式模具hot-runner mold 热流道模具 prototype mold 雏形试验模具ingot mold 钢锭模 punching die 落料模lancing die 切口模 raising(embossing) 压花起伏成形re-entrant mold 倒角式模具 sectional die 拼合模runless injection mold 无流道冷料模具 sectional die 对合模具 segment mold 组合模 semi-positive mold 半全压式模具shaper 定型模套 single cavity mold 单腔模具solid forging die 整体锻模 split forging die 拼合锻模split mold 双并式模具 sprueless mold 无注道残料模具squeezing die 挤压模 stretch form die 拉伸成形模sweeping mold 平刮铸模 swing die 振动模具three plates mold 三片式模具 trimming die 切边模unit mold 单元式模具 universal mold 通用模具unscrewing mold 退扣式模具 yoke type die 轭型模。

模具标件专业英语词汇一、模具（Mold）相关基础词汇。

1. Mold [məʊld] - 名词，模具；也可作动词，塑造，浇铸。

- 例句：This is a new type of injection mold.（这是一种新型的注塑模具。

）2. Die [daɪ] - 名词，冲模，钢模（在冲压工艺中使用）- 例句：The die is used for stamping metal sheets.（这个冲模用于冲压金属薄板。

）3. Cavity ['kævəti] - 名词，型腔；洞，凹处。

- 发音：['kævəti]- 例句：The cavity of the mold should be polished carefully.（模具的型腔应该仔细抛光。

）4. Core [kɔː(r)] - 名词，型芯；核心。

- 例句：The core is an important part of the mold.（型芯是模具的一个重要部分。

）二、模具标件（Standard Mold Components）词汇。

1. Guide Pin ['ɡaɪ d pɪn] - 名词，导柱。

- 例句：The guide pin helps to align the two parts of the mold.（导柱有助于使模具的两个部分对齐。

）2. Guide Bushing ['ɡaɪ d 'bʊʃɪŋ] - 名词，导套。

- 例句：The guide bushing is used in combination with the guide pin.（导套与导柱配合使用。

）3. Ejector Pin [i'dʒektə pɪn] - 名词，顶针。

- 例句：The ejector pin is used to push the finished product out of the mold.（顶针用于将成品从模具中顶出。

Surface Appearance外观Glossiness/gloss finish光洁度Matt finish/matt surface毛面Glass fiber rich surface/glass emergence on the surface 玻纤外露Blooming/surface blooming表面析出White patches on surface表面白斑Silver marks/silver streak银纹Splay mark水纹Flow mark流纹Weld line溶结纹Brittle/brittleness脆Bubbles/trapped gas气泡V oid孔Burn marks烧伤FR failed阻燃不合格Flame rating V-2阻燃V-2Poor dispersion分散不好FR/PTFE …agglomerates etc阻燃剂/PTFE…结块Pellet porous粒子不密/蜜蜂窝Low impact/tensile etc物理性能低High flow/filler content etc流动性/填充…过高Longs/fines/doubles长粒/碎屑/连粒Poor cut粒形不好Bristle/voids表面有小气泡/孔Glass bundles玻纤结团Product was rejected due to产品不能接受因为…High moisture level高水分Warpage/warped翘曲Shrinkage/shrink收缩Sink marks缩影Short shot/short molding打不满Distortion变形Over dimension尺寸过大Under dimension尺寸过小Flashing飞边Discoloration变色Off color颜色差异Flow rate流动率Viscous粘High flow高流动Low flow低流动Sticky粘Mold release脱模Antioxidant抗氧剂Flame retardant agent阻燃剂Heat stabilizer热稳定剂Chopped glass fiber短切玻纤Roving glass fiber粗纱/长玻纤Glass beads玻璃微珠Milled fiber碾磨纤Molybdenum disulfide/moly/MoS2 二硫化钼Colorant着色剂Pigment颜料Dye染料Accepted product specification接受产品规格Approved our product认可我们的产品Re-set spec重新定标准Add in extra …添加多一点…Reduced … content减少…含量Drop ped/reduced … by x％减少…含量…％Confirmed color standard确认颜色标准Approved color standard认可颜色标准Re-confirmed color standard重新确认颜色标准Qualified our product认可我们的产品Undergoing heat aging test在做热老化实验Product is under testing产品在测试当中Received first order接了第一个定单E xpected to finish by …预计在…完成Expected order is xMT预计定单量…吨Estimated annual/monthly consumption 预计年/月用量air vent vale 通气阀anchor pin 锚梢angular pin 角梢baffle 调节阻板angular pin 倾斜梢baffle plate 折流档板ball button 球塞套ball plunger 定位球塞ball slider 球塞滑块binder plate 压板blank holder 防皱压板blanking die 落料冲头bolster 上下模板bottom board 浇注底板bolster 垫板bottom plate 下固定板bracket 托架bumper block 缓冲块buster 堵口casting ladle 浇注包casting lug 铸耳cavity 模穴(模仁)cavity retainer plate 模穴托板center pin 中心梢clamping block 锁定块coil spring 螺旋弹簧cold punched nut 冷冲螺母cooling spiral 螺旋冷却栓core 心型core pin 心型梢cotter 开口梢cross 十字接头cushion pin 缓冲梢diaphragm gate 盘形浇口die approach 模头料道die bed 型底die block 块形模体die body 铸模座die bush 合模衬套die button 冲模母模die clamper 夹模器die fastener 模具固定用零件die holder 母模固定板die lip 模唇die plate 冲模板die set 冲压模座direct gate 直接浇口dog chuck 爪牙夹头dowel 定位梢dowel hole 导套孔dowel pin 合模梢dozzle 辅助浇口dowel pin 定位梢draft 拔模锥度draw bead 张力调整杆drive bearing 传动轴承ejection pad 顶出衬垫ejector 脱模器ejector guide pin 顶出导梢ejector leader busher 顶出导梢衬套ejector pad 顶出垫ejector pin 顶出梢ejector plate 顶出板ejector rod 顶出杆ejector sleeve 顶出衬套ejector valve 顶出阀eye bolt 环首螺栓filling core 椿入蕊film gate 薄膜形浇口finger pin 指形梢finish machined plate 角形模板finish machined round plate 圆形模板fixed bolster plate 固定侧模板flanged pin 带凸缘?flash gate 毛边形浇口flask 上箱floating punch 浮动冲头gate 浇口gate land 浇口面gib 凹形拉紧?goose neck 鹅颈管guide bushing 引导衬套guide pin 导梢guide post 引导柱guide plate 导板guide rail 导轨head punch 顶?冲头headless punch 直柄冲头heavily tapered solid 整体模蕊盒hose nippler 管接头impact damper 缓冲器injection ram 压射柱塞inlay busher 嵌入衬套inner plunger 内柱塞inner punch 内冲头insert 嵌件insert pin 嵌件梢king pin 转向梢king pin bush 主梢衬套knockout bar 脱模杵land 合模平坦面land area 合模面leader busher 导梢衬套lifting pin 起模顶?lining 内衬locating center punch 定位中心冲头locating pilot pin 定位导梢locating ring 定位环lock block 压块locking block 定位块locking plate 定位板loose bush 活动衬套making die 打印冲子manifold block 歧管档块master plate 靠模样板match plate 分型板mold base 塑胶模座mold clamp 铸模紧固夹mold platen 模用板moving bolster 换模保持装置moving bolster plate 可动侧模板one piece casting 整体铸件parallel block 平行垫块paring line 分模线parting lock set 合模定位器pass guide 穴型导板peened head punch 镶入式冲头pilot pin 导?pin gate 针尖浇口plate 衬板pre extrusion punch 顶挤冲头punch 冲头puncher 推杆pusher pin 衬套梢rack 机架rapping rod 起模杆re-entrant mold 凹入模retainer pin 嵌件梢retainer plate 托料板return pin 回位梢riding stripper 浮动脱模器ring gate 环型浇口roller 滚筒runner 流道runner ejector set 流道顶出器runner lock pin 流道拉梢screw plug 头塞set screw 固定螺丝shedder 脱模装置shim 分隔片shoe 模座之上下模板shoot 流道shoulder bolt 肩部螺丝skeleton 骨架slag riser 冒渣口slide(slide core) 滑块slip joint 滑配接头spacer block 间隔块spacer ring 间隔环spider 模蕊支架spindle 主轴sprue 注道sprue bushing 注道衬套sprue bushing guide 注道导套sprue lock bushing 注道定位衬套sprue puller 注道拉料?spue line 合模线square key 方键square nut 方螺帽square thread 方螺纹stop collar 限位套stop pin 止动梢stop ring 止动环stopper 定位停止梢straight pin 圆柱?stripper bolt 脱料螺栓stripper bushing 脱模衬套stripper plate 剥料板stroke end block 行程止梢submarine gate 潜入式浇口support pillar 支撑支柱/顶出支柱support pin 支撑梢supporting plate 托板sweep templete 造模刮板tab gate 辅助浇口taper key 推拔键taper pin 拔锥梢/锥形梢teeming 浇注three start screw 三条螺纹thrust pin 推力销tie bar 拉杵tunnel gate 隧道形浇口vent 通气孔wortle plate 拉丝模板plain die简易模pierce die冲孔模forming die成型模progressive die连续模gang dies复合模shearing die剪边模riveting die铆合模pierce冲孔forming成型(抽凸,冲凸) draw hole抽孔bending折弯trim切边emboss凸点dome凸圆semi-shearing半剪stamp mark冲记号deburr or coin压毛边punch riveting冲压铆合side stretch侧冲压平reel stretch卷圆压平groove压线blanking下料stamp letter冲字(料号) shearing剪断tick-mark nearside正面压印tick-mark farside反面压印extension dwg展开图procedure dwg工程图die structure dwg模具结构图material材质material thickness料片厚度factor系数upward向上downward向下press specification冲床规格die height range适用模高die height闭模高度burr毛边gap间隙weight重量total wt.总重量punch wt.上模重量三、模具塑料模具mould of plastics 注塑模具injection mould冲压模具die模架mould base 定模座板Top clamping plateTop plateFixed clamp plate水口推板stripper plateA板A plateB板B plate支承板support plate方铁spacer plate底针板ejector plate面针板ejector retainer plate回针Return pin导柱Guide pin有托导套Shoulder Guide bush直导套Straight Guide bush动模座板Bottom clamp plate Moving clamp plate基准线datum line基准面datum plan型芯固定板core-retainer plate凸模固定板punch-retainer plate顶针ejector pin单腔模具single cavity mould多腔模具multi-cavity mould多浇口multi-gating浇口gate缺料starving排气breathing光泽gloss合模力mould clamping force锁模力mould locking force挤出extrusion开裂crack循环时间cycle time老化aging螺杆screw麻点pit嵌件insert活动镶件movable insert起垩chalking浇注系统feed system主流道sprue分流道runner浇口gate直浇口direct gate , sprue gate轮辐浇口spoke gate , spider gate点浇口pin-point gate测浇口edge gate潜伏浇口submarine gate , tunnel gate 料穴cold-slug well浇口套sprue bush流道板runner plate排飞槽vent分型线（面）parting line定模stationary mould，Fixed mould 动模movable mould, movable half上模upper mould，upper half下模lower mould，lower half型腔cavity凹模cavity plate，cavity block拼块split定位销dowel定位销孔dowel hole型芯core斜销angle pin, finger cam滑块slide滑块导板slide guide strip楔紧块heel block, wedge lock拉料杆sprue puller定位环locating ring冷却通cooling channel脱模斜度draft滑动型芯slide core螺纹型芯threaded core热流道模具hot-runner mould绝热流道模insulated runner mould熔合纹weld line （flow line）三板式模具three plate mould脱模ejection换模腔模具interchangeable cavity mould脱模剂release agent注射能力shot capacity注射速率injection rate注射压力injection pressure差色剂colorant保压时间holdup time闭模时间closing time定型装置sizing system阴模female mould，cavity block阳模male mould电加工设备Electron Discharge Machining数控加工中心CNC machine center万能铁床Universal milling machine卧式刨床Horizontal planer车床Engine lathe平面磨床Surface grinding machine去磁机Demagnetization machine万能摇臂钻床Universal radial movable driller立式钻床Vertical driller超声波清洗机Ultrasonic clearing machine一、组织机构及职位XX电子有限公司XX Electronics CO., Ltd总经理办公室General manager’s office企管部Enterprise management department (EM)行政部Administration department (AD)销售部Sales department (SD)财务部Financial department (FD)技术部Technology department (TD)物控部Production material control department(PMC)生产部Production department(PD)模具部Mold manufacturing department, Tooling manufacturing department (TM)品管部Quality Assurance department (QA)冲压车间Stamp workshop, press workshop注塑车间injection workshop装配车间Assembly workshop模具装配车间Mold and die Assembly workshop金属加工车间metal machine workshop电脉冲车间Electric discharge process workshop线切割车间wire cutting process workshop工磨车间Grinding workshop总经理General manager (GM)副总经理Vice-general manager经理manager董事长president副董事长Vice-presidentXX部门经理Manager of XX department主任、主管supervisor拉长Line leader组长Foreman, forelady秘书secretary文员clerk操作员operator助理assistant六．物控保质期shelf lifeABC分类法ABC Classification反常需求Abnormal Demand措施信息Action Message活动报告标志Action-report-flag基于活动的成本核算Activity-based Costing (ABC) 实际能力Actual Capacity实际成本Actual Costs调整现有库存量Adjust-on-hand已分配量Allocation替代工序Alternative Routine装配订单Assembly Order装配零件表Assembly Parts List装配Assembly计划自动重排Automatic Rescheduling可达到库存Available Inventory可用材料Available Material达到库存Available Stock可利用工时Available Work可签约量Available-to-promise平均库存Average Inventory欠交订单Back Order倒序计划Back Scheduling倒冲法Back flush未完成订单Backlog现有库存余额Balance-on-hand Inventory批号Batch Number批量生产Batch Production标杆瞄准Benchmarking工时清单Bill of Labor提货单Bill of Lading物料清单Bill of Material分库Branch Warehouse经营规划Business Plan采购员Buyer能力管理Capacity Management能力需求计划Capacity Requirements Planning (CRP) 保管费率Carrying Cost Rate保管费Carrying Cost单元式制造Cellular Manufacturing修改批量日期Change Lot Date修改工序Change Route修改产品结构Change Structure检查点Check Point闭环物料需求计划Closed Loop MRP通用工序标识Common Route ID计算机集成制造Computer-integrated Manufacturing (CIM)配置代码Configuration Code约束管理/约束理论Constraints Management/Theory of Constraints (TOC)依成本的材料清单Costed Bill of Material急需零件Critical Part累计提前期Cumulative Lead Time现有运转时间Current Run Hour现有运转数量Current Run Quantity周期盘点Cycle Counting调整日期Date Adjust有效日期Date Available修改日期Date Changed结束日期Date Closed截止日期Date Due生产日期Date in Produced库存调整日期Date Inventory Adjust作废日期D ate Obsolete收到日期Date Received交付日期Date Released需求日期Date Required发货日期Date to Pull空负荷Dead Load需求管理Demand Management需求Demand实际能力Demonstrated Capacity非独立需求Dependent Demand直接增减库存处理法Direct-deduct Inventory Transaction Processing发料单Disbursement List派工单Dispatch List分销资源计划Distribution Resource Planning (DRP) 鼓－缓冲－绳子Drum-buffer-rope经济订货批量Economic Order Quantity (EOQ) 工程变更生效日期Engineering Change Effect Date工程变更生效单Engineering Change Effect Work Order工程停止日期Engineering Stop Date例外控制Exception Control呆滞材料分析Excess Material Analysis急送代码Expedite Code加工订单Fabrication Order补足欠交Fill Backorder总装提前期Final Assembly Lead Time确认的计划订单Firm Planned Order固定订货批量F ixed Order Quantity集中预测Focus Forecasting完全跟踪Full Pegging通用生产管理原则Generally Accepted Manufacturing Practices毛需求Gross Requirements在制品库存In Process Inventory独立需求Independent Demand投入/产出控制Input/ Output Control检验标识Inspection ID厂际需求Interplant Demand库存周转率Inventory Carry Rate仓库库位类型Inventory Location Type库存周转次数Inventory Turnover发送订单Issue Order项目记录Item Record物料项目Item加工车间Job Shop准时制生产Just-in-time (JIT)看板Kanban人工工时Labor Hour最后运输日期Last Shipment Date提前期Lead Time层Level负荷量Load Leveling负荷报告Load Report负荷Load仓位代码Location Code仓位备注Location Remarks仓位状况Location Status按需订货Lot for Lot批量标识Lot ID批量编号Lot Number批量Lot Size低位码Low Level Code机器能力Machine Capacity机器加载Machine Loading外购或自制决策Make or Buy Decision面向订单生产的产品Make-to-order Product面向库存生产的产品Make-to-stock Product制造周期时间Manufacturing Cycle Time制造资源计划Manufacturing Resource Planning (MRP II)主生产计划Master Production Schedule (MPS)物料成本Material Cost物料发送和接收Material Issues and Receipts物料需求计划Material Requirements Planning (MRP) 登陆标志MPS Book Flag MPS多重仓位Multiple Location净改变式MRP N et Change MRP净需求Net Requirements新仓位New Location新组件New Parent新仓库New Warehouse不活动报告No Action Report现有库存量On-hand Balance未结订单Open Order订单输入Order Entry订货点Order Point订货方针Order Policy订货承诺Order Promising订货备注Order Remarks双亲Parent零件清单Part Bills零件批次Part Lot零件编号Part Number零件Part反查Pegging领料单Picking List领料/提货Picking计划订单Planned Order后减库存处理法Post-deduct Inventory Transaction Processing前减库存处理法Pre-deduct Inventory Transaction Processing发票价格Price Invoice采购订单价格Price Purchase Order优先计划Priority Planning产品控制Product Control产品线Production Line生产规划编制Production Planning产品率Production Rate产品结构树Production Tree预计可用库存Projected Available Balance采购订单跟踪Purchase Order Tracking已分配量Quantity Allocation仓位数量Quantity At Location欠交数量Quantity Backorder完成数量Quantity Completion需求量Quantity Demand毛需求量Quantity Gross进货数量Quantity In排队时间Queue Time队列Queue重生成式MRP Regenerated MRP重排假设Rescheduling Assumption资源需求计划Resource Requirements Planning粗能力计划Rough-cut Capacity Planning工艺路线Routing 安全库存量Safety Stock保险期Safety Time预计入库量Scheduled Receipt残料率Scrap Factor发送零件Send Part维修件Service Parts发货地址Ship Address发货单联系人Ship Contact发货零件Ship Date发货单Ship Order工厂日历Shop Calendar车间作业管理Shop Floor Control损耗系数Shrinkage Factor标准产品成本Standard Product Cost标准机器设置工时Standard Set Up Hour标准单位运转工时Standard Unit Run Hour标准工资率Standard Wage Rate状况代码Status Code库存控制Stores Control建议工作单Suggested Work Order约束理论Theory of Constraints (TOC)时间段Time Bucket时界Time Fence单位成本Unit Cost采购计划员Vendor Scheduler采购计划法Vendor Scheduling工作中心能力Work Center Capacity工作中心Work Center在制品Work in Process工作令跟踪Work Order Tracking工作令Work Order工作进度安排Work Scheduling零库存Zero Inventories经济订货批量＝Squat(2*年订货量*平均一次订货准备所发生成本/每件存货的年储存成本)美国生产和库存控制协会APICS，American Production & Inventory Control Society二、产品连接器connector端子terminal条型连接器bar connector阴连接器Housing阳连接器wafer线束wire harness间距space额定电压rated voltage额定电流rated current接触电阻contact resistance绝缘电阻insulation resistance超声波焊接ultrasonic welding耐压withstand voltage针pin物料编号part number导线wire基体金属Base metal电缆夹cable clamp倒角chamfer接触面积contact area接触件安装孔contact cavity接触长度contact length接触件电镀层contact plating接触压力contact pressure接触件中心距contact space接触簧片contact spring插孔socket contact法兰、凸缘Flange界面间隙interfacial gap键Key键槽keyway过渡段ramp屏蔽套shielding定位基准Datum reference扁平电缆flat cable ，Ribbon cable柔性印刷电线Flexible printed wiring多层印制电路Multilayer printed circuit焊盘pad图形pattern间距pitch负极Negative pole正极positive pole回流Reflow原理图Schematic diagram单面板single sided board双面板Two-sided board，Double-sided board表面安装surface Mounting翘曲warp，bow波峰焊wave soldering编织层braid同轴电缆coaxial cable电介质dielectric电缆中导线的头数ends外部干扰external interference填充物filler护套jacket比重specific gravity电阻的温度系数Temperature coefficient of resistance三、品管SPC statistic process control品管保证Quality Assurance品管控制Quality control来料检验IQC Incoming quality control巡检IPQC In-process quality control校对calibration动态试验dynamic test环境试验Environmental test非破坏性试验non-destructive test光泽gloss击穿电压(dielectric) breakdown voltage拉伸强度tensile strength冷热骤变试验thermal shock test环境试验炉Environmental chamber盐雾实验salt spray test绝缘电阻测试验仪Insulating resistance meter内应力internal stress疲劳fatigue蠕变creep试样specimen撕裂强度tear strength缩痕shrink mark, sink mark耐久性durability抽样sampling样品数量sample sizeAQL Acceptable Quality level批量lot size抽样计划sampling planOC曲线operation curve试验顺序sequence of tests环境温度ambient temperature可焊性solderability阻燃性flame resistance四、生产注塑机injection machine冲床Punch machine混料机blender mixer尼龙nylon黄铜brass青铜bronze紫(纯)铜copper料斗hopper麻点pit配料compounding涂层coating飞边flash预热preheating再生料reworked material再生塑料reworked plastics工艺设计process design紧急停止emergency stop延时time delay七．QS-9000中的术语APQP Advanced Product Quality Planning and Control Plan，产品质量先期策划和控制计划PPAP Production Part Approval Process,生产件批准程序FMEA Potential Failure Mode and Effects Analysis,潜在失效模式及后果分析Injection machine 啤机Shot size（weight）实际射胶量injection volume 理论射胶量min mold height 最小容模厚度Max mold height 最大容模厚度Tie bar clearance 拉杆间距Die plate size 模板尺寸Ejector stroke 顶出行程barrel 炮筒，机筒clamp force 锁模力non-return valve 止回阀shear 剪切opening 开模行程Injection pressure 射胶压力back pressure 背压nozzle size 射咀尺寸Cycle time 循环周期down time 停机时间hopper 料筒Mold release 脱模剂lubrication 润滑work horse 主力，主要设备Reserve pressure/packing pressure保压mold trial 试模shot （一）啤Decompress 减压oven 烤炉，烘灶shrinkage rate 收缩率Residence time 滞留时间injection speed 注射速度booster time 增压时间Compression ratio 压缩比mold close time 合模时间Resin 胶料Plastification 塑化，增塑viscosity 粘性，粘度contamination 污染，杂物Thermoplastic 热塑性塑料thermosetting plastics 热固性塑料Booster time 增压时间feed 喂料，填充purge 净化Flame retardant 阻燃degradation 降解，软化regrind 再粉碎Water absorption 吸水reinforce 增强，加固specific gravity 比重Elongation 延伸率density 密度melting point 熔点Polystyrene 聚苯乙烯（PS）Styrene 苯乙烯Acrylonitrile 丙烯腈Polypropylene 聚丙烯（PP）Polyethylene 聚乙烯glass fiber 玻纤Condensation 凝固，浓缩crystalline resin 结晶形塑料Mold materials 模具General-purpose steel 多用途钢tool steel 模具钢Free-cutting steel 高速切削钢case hardening steel 表面硬化钢Pre-hardened steel 预硬钢ball and roller bearing steel 滚珠轴承钢Nonferrous steel 非铁合金high speed steel 高速钢cast iron 铸铁Steel specification 钢材规格steel certification 钢材合格证明书Stainless steel 不锈钢nickel 镍chrome 铬aluminum 铝Copper 铜brass 黄铜bronze 青铜titanium 钛Processing 钢材的加工方法Harding / quench 淬火nitride 氮化temper 回火anneal 退火Roll 轧制abrasive 研磨，磨损的finish 精加工，抛光（polish）Case-hardening 表面硬化milling machine 铣（锣）床Lathe车床drill 钻床wire cut 线割NC(numerical control ) 数控材料EDM (Electrical discharge machine) 电火花加工Cut steel 开料Precision ground 精密研磨heat treatment 热处理tap 丝锥，攻牙Texture 蚀纹weld 焊接forge 锻压deformation 变形Spraying 喷涂die-cast 压铸Properties 性能Resistance 电阻，抵抗能力abrasion / wear磨损erode / corrode 腐蚀Toughness 韧性yield strength 屈服强度tensile strength 拉伸强度Fatigue strength 疲劳强度break 断裂stress 应力hardness 硬度Humidity / moisture 潮湿，湿气roughness 粗糙度parameter 参数Thermal conductivity 导热系数manufacture 制造，加工drawback 缺点Ductility 延展性grain 晶粒property 性能，财产brittleness 脆性GD&T （Geometric Dimensions and Tolerance ）形位尺寸公差Flexural strength 挠曲强度impact 冲击conductivity 传导性，导电性Optical 光学的transparent 透明的insulation 绝缘Mechanical 机械的processability 可加工性能timeyield 蠕变Physical 物理的flow rate 流动速率compressive strength 压缩强度Adhesive 粘附的，胶合durability 耐用性Mold design 模具设计Tooling specification 模具规格mould flow 流动模拟sprue nozzle 唧咀孔Clearance 避空，间隙undercut 倒扣flush 插入，埋入legend 图例Groove 凹槽latch 插销class 类型，种类plan 平面图Orifice 孔，口column 柱位boss 凸台standard 标准，规格Rib 骨位tapered interlock 锥形管位块Bubbler 炮隆Bolt 螺钉，销顶identification mark 铭牌P/L strip 锁模片Overflow well / cold-slug well 冷料井Vent 排气pocket 槽Gate location 入水点full line 实线broken line 虚线Retainer 固定，支撑operator 操作者（啤工）receptacle 插座Lifting hole 吊令孔insulation plate 隔热板cavity number 型腔号Bolster 支撑，垫子vent channel 排气槽leak / filter 渗漏Leak test 试运水stamp / engrave 雕刻，印记（打字唛）Clamp slot 码模槽support button / pin 垃圾钉cut steel 开料Lodge 安装，放置inlay 镶嵌，插入cam / lifter 斜顶Stripper推方lifting bar 吊模方sprue 唧咀tolerance 公差Counter bore 沉孔slant 倾斜，斜面conical 圆锥的，圆锥形的Bolt 螺栓manifold 热流道板prototype tooling 原型试验Gusset 角撑reverse mold 倒装模constrain / restrict约束，限制Counter lock 反锁thermocouple 热电偶moldmaker 模具制造商Asset / property number 资产编号tool product destination 模具生产地点Accelerating ejection 加速顶出hydraulic 液压的pneumatic 气动的Trapezoid 梯形的semi-round 半圆形format 格式baffle 隔水片Electrode 电极，铜公spare part 配件gall 磨伤，插伤Cable 电缆，电线plating / coating （电）镀bonding / joint 接头Wall transition 壁厚过渡Product problem 产品问题Troubleshoot 故障处理reduce(add) plastic 减（加）胶Burr/flash披峰Burn mark 烧焦ejector mark 顶针印，顶白black specs 黑点，黑斑Discoloration 混色，污点gloss 光泽jetting/worming 走水纹Sink mark 缩水void / bubble 气泡，夹气distortion 变形Warpage 翘曲short molding / non-fill缺胶，未走齐Weld line / knit line 夹水线discarded as useless 报废Split line 夹线stick in sprue bushing / cavity / core 粘唧咀/前模/后模Break / crack 顶裂brittleness 脆性，易脆Others 其他Invoice 发票，清单vendor(er) 卖方vendee 买方guideline 方针，指导Intricate 复杂的confidential 机密的，不可外泄的proprietary 私有的Authorize 批准，授权recipient 接收者issue ①发布，提供；②问题Approve 确认，赞成requirement 需要，必需物const 常数，常量Regarding 关于，涉及opposite 相反的，对面的latitude 纬度，纵向的Version 版本definition 注释，解说transversal 横向的，截线Profile 轮廓，剖面eliminate / cancel 取消allow / permit 允许，许可Respective 各自的，分别的individual 单独的decrease 减少increase 增加Preliminary 初步的approximately大约，近似estimate / valuate估计，预算Adjust 调整，校准application 应用，申请maintain 维持Accurate / precise 精确的smooth 光滑，顺畅的device 装置，设备Convenient 方便的deadline 截至日期available 有用的，有空的Shift 轮班，换班critical 关键的，临界的exceptional 异常的，优异的Exceed 超过layout 布局，方案loss 损失，消耗install 安装，安置Rotation 旋转item 条款，项目quotation 报价stabilize 稳定Quality 质量quantity 数量couple 连接，接合configuration 构造，外形Illustrate 图解说明simulation 模拟，仿真recommend 推荐使用11 / 11。
