电牵引采煤机电控系统常见故障分析与处理一、一般电气故障1.按下“启动”按钮，不能启车A.检查顺槽开关是否正常。

B.检查隔离开关辅助接点是否闭合好。

C.检查盖板启、停按钮及其连接线。

D.检查启动二极管是否击穿或断路 。

E.检查进线电缆是否断线。

F.检查各电机的温度保护线接点是否闭合。

2.采煤机起车即停，顺槽开关显示故障：缺相A.首先要检查拖动电缆是否有断线（尤其是采煤机旋转砖头15米范围内），因为折弯的频率比较高，很容易造成电缆断线。

B.检查采煤机的隔离开关是否有一相未闭合。

C.检查顺槽开关（接触器、隔离开关）3.按采煤机总启按钮时，移动变电站跳闸A.将隔离开关断开，再隔离开关绝缘正常的情况下，按总起，如果继续跳闸，可确定不是采煤机的接地故障造成。

B.用5000V绝缘摇表，主进线 单相对地，检查 主回路和牵引变压器、油泵电机、控制变压器是否绝缘正常。

4.启动后不能自保A.检查控制PLC相应输出指示灯（主100CH01)是否亮。

B.检查自保继电器吸合是否正常。

C.检查端头站是否误发“总停”信号。

D.检查盖板总停按钮及其线路是否误动作。

E.检查瓦斯是否超限。

F.检查控制变压器高、低压保险是否熔断。

5.开机后摇臂自动上升或下降A.检查电磁阀阀芯是否堵卡，以致不能回到中位B.检查制动阀阀芯是否堵卡，以致不能回到中位。

C.检查电磁阀及其线路。

D.检查控制PLC输出继电器是否正常工作。

E.检查控制PLC输入部分是否有接点粘连等现象造成误动作。

6.摇臂上升或下降不动作A.检查按钮、遥控器等控制PLC输入信号是否 正常，可以通过控制PLC输入指示灯来判断。

B.检查电磁阀线圈是否短路、开路等，可以用正 常的一路来“替换”查找。

C.检查电磁阀工作电源是否正常。

D.检查控制计算机输出是否正常。

E.检查液压系统压力，管路等是否正常。

7.端头站、遥控器不动作A.检查端头站12V电源是否正常，遥控器电池电压是否正常。

B.检查端头站电缆的连接头是否紧凑、牢固、可靠。
