w w w .m o t o r o l a .c o mw w w .m o t o r o l a .c o m12345657891011101213131415716171819MTP850 ExQuick Start GuideC o n t r o l s a n d I n d i c a t o r sG e t t i n g S t a r t e dInstalling the Battery Attaching the AntennaUnlocking the TerminalHow to Hold Your TerminalLooking After Your TerminalBattery installing must occur only in non-hazardous areas. Remove the battery from its protective white paper box.Insert the battery top into the compartment as illustrated.Carefully slide the battery until it clicks into place.The terminal has two microphones: a top microphone for Simplexdispatcher/private calls and a bottom microphone for Duplex telephone-like calls. When using low audio, hold your terminal as you would a telephone. Speak into the bottom microphone. Listen via the earpiece. Keep antenna at least 2.5 centimetres from your head and body.When using high audio, hold terminal in a vertical position with its top microphone 5 to 10 centimetres away from your mouth. Speak into the top microphone. Listen via the terminal's internal speaker. Keep antenna at least 2.5 centimetres from your head and body.Antenna attaching must occur only in non-hazardous areas. Turn the terminal off before attaching the antenna.Align the bottom of the antenna and the screw-in base on the top of the terminal.Turn clockwise until snug. Do not force.Your terminal may be locked at power up. To unlock the terminal afterpowering on, enter the code at the prompt using Software Numeric Keypad.The unlock code is originally set to 0000. Your Service Provider may change this number before you receive your terminal.Never leave your terminal or battery in extreme temperatures (over 60 °C) - for example, behind windscreen in very hot, direct sunlight. Do not immerse your terminal in water.To clean your terminal, use a moistened or antistatic cloth. Do not use a dry or electrostatically charged cloth.LED Status IndicatorIndicator Solid green Flashing green Solid red Flashing red Solid orange Flashing orange No indicationStatus In use In service Out of service Connecting to a networkEntering DMO Transmit Inhibit in service Channel busy in DMO Incoming private or phone callSwitched offBattery Capacity InformationInformation Green icon Yellow icon Red icon Empty icon Low battery messageDescription Full (50% – 100% capacity)Middle (20% – 50% capacity)Low (10% – 20% capacity)Very low (5% – 10% capacity)Less than 5% capacityUnlocking/Locking KeysTo unlock/lock the keypad, press the Menu button and then Left Navigation Key.12345678910111213141516171819Antenna Emergency ButtonSpeaker Programmable Side Key Top Microphone Color DisplayMenu Key On-Off/End/Home Key Send Key Bottom Microphone Side Connector Battery Latch Speaker Control Key Four Way Navigation KeySoft Key LED IndicatorPush-To-Talk Button (PTT)EarpieceProgrammable Rotary Knobw w w .m o t o r o l a .c o mw w w .m o t o r o l a .c o mWhen printed by MotorolaIf using Hot Mic feature, wait for the Emgcy Mic On message to appear on the display and talk without pressing the PTT.To exit Emergency Mode, press and hold Exit soft key.MTP850 ExQuick Start GuideI c o n sU s i n g t h e T e r m i n a lMore Information on the TerminalMotorola Online@68015000205@68015000205-AThis document is copyright protected. Duplications for the purpose of the use of Motorola products are permitted to an appropriate extent. Duplications for other purposes, changes, additions or other processing of this document are not permitted. Only thiselectronically-saved document is considered to be the original. Duplications are considered merely copies. Motorola, Inc., and its subsidiaries and affiliates do not vouch for the correctness of such kinds of copies.MTP850 Ex Feature User Guide and related documentation Available at: https:///Visit the Motorola Web site at: /tetraterminalsMOTOROLA and the stylized M Logo are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their respective owners.© Motorola, Inc. 2009Turning the Terminal On/OffMaking a Simplex Private CallUsing the Terminal MenuTo power the terminal on/off, press and hold On/Off Key.To enter the menu, press the Menu Key.To scroll through the menu, press the Up or Down Navigation Key.To select a menu item, press Select or the Right Navigation Key.To return to previous level, press Back or the Left Navigation Key.To exit the menu items, press the Home Key.Selecting Trunked/Direct Mode OperationMaking a TMO/DMO Group CallFrom the Home display press Optns, select Trunked Mode or Direct Mode.From the Home display dial a number using Software Numeric Keypad (press and hold Right Navigation Key). Press and release the PTT. The ringing sounds. The called party answers. Wait for the called party to finish speaking. Press and hold the PTT. Wait for the talk permit tone (if configured) and talk. Release the PTT to listen. Press the End Key to terminate the call.Making a Duplex Private Call/Phone/PABX CallFrom the Home display dial a number. Press and release the Send Key. The ringing sounds. The called party answers. Press the End Key to terminate the call.Sending a New MessagePress the Menu Key and select Messages > New Message. Write your message. Select Send. Select your message recipient. Select Send, or press the Send Key to send the message.Sending a Status MessageSelect the desired group, then press the Menu Key and select Messages > Send Status. Select a status and press the Send Key or PTT.Enter TMO or DMO. From the Home display navigate to the desired group. Press Select (if configured). Press and hold the PTT. Wait for the talk permit tone (if configured) and talk. Release the PTT to listen.Making a TMO/DMO Emergency Group CallEnter TMO or DMO. Press and hold the Emergency Button. Emergency alarm is sent automatically. Press and hold the PTT. Wait for the talk permit tone (if configured) and talk. Release the PTT to listen.IconDescriptionNew Message Has ArrivedNew Message(s)Packet Data GPS WAP End-to-End Encryption Man Down Active IconsMan Down Alert Man Down Failure RUI Logon RUI Packet Data Call OutWAP BoxRMS IconDescriptionIn Service (TMO)No Service (TMO)Signal Strength Direct Mode (DMO)Gateway Mode(DMO)Repeater Mode (DMO)Emergency Mode Talkgroup Scrolling Battery Level All/Simplex/Duplex Ring MutedLow AudioHigh Audio Speaker OffScan (TMO)。
MTP850座充使用指南在用座充前端为对讲机充电时，请注意在对讲机刚放入座充时，在开机的情况下LED指示灯在5－8秒内为橙黄灯，如果在对讲机关闭情况下该指示灯在11－18秒内为橙黄灯。
然后LED指示灯将转为绿灯，表示正在充电，表示充电已完成>90%。
充电时请务必确认对讲机已开始正确充电。
注意１：对讲机在开机情况下会加快识别过程。
但摩托罗拉建议在为对讲机电池充电时最好关闭对讲机，这样可以缩短充电时间。
注意２：如果LED绿灯变亮，同时对讲机电池正在充电，此时表示连接中断。
请再重插。
注意３：对讲机电池完整的充电周期平均为3小时或更短时间.注意４：使用座充同时为对讲机和电池充电时，座充只能分别为对讲机（前端口）和电池（后端口）充电，且对讲机充电（前端口）优先，此时后端口的LED指示灯为橙黄色且闪烁，直到前端对讲机充电完毕才开始为后端电池充电。
更多的信息请参照下面的详细使用说明。
简介智能双座台式充电器可用于摩托罗拉认可的锂离子充电电池：FTN6573 （薄型）和FTN6574 （标准）。
充电器前充电座可以为带电池的对讲机充电。
后面的充电座只能为上述电池充电。
后面的充电座只能容纳一个薄型电池。
变亮的LED 指示充电的状态。
使用FKN4897/NKN6544B 机型RS232 （单独附带的数据电缆）时台式充电器可支持数据传输。
警告: 请不要使用数据电缆为对讲机电池或充电器后充电座中的电池充电。
对于数据应用，只能在对讲机中装入充满电的电池。
使用指南• 将带电池的对讲机插入充电器的前充电座并将第二块电池插入充电器后充电座之前，要记住先为台式充电器供电。
否则，对讲机电池充电将不能实行，并且显示：“RADIO （对讲机）”LED 上半部亮起稳定橙黄灯，下半部的指示灯则是熄灭的。
如果发生这种情况，请参考“故障排除”章节。
• 只能将数据电缆用于数据传输，不能将它用于电池充电。
• 前充电座充电的优先级高于后充电座。
因此，在后充电座中的电池开始充电之前，前充电座中的对讲机已完成充电。
Digital Car Kit for theMTP850 TETRA ™ TerminalBenefits of your Motorola MTP850 Digital Car Kit:• Meeting the needs for mobility requirements: - Transform the portable radio into a virtual mobile radio, with access to an external speaker, directional microphone and remotepush-to-talk.- Extended radio and GPS coverage through an external antenna. - In-vehicle battery charging and continuous power to the portable is provided through the car battery, allowing users to charge theirportable even while away from the office.• Safe hands-free communication system: - A three-axis rotating mounting bracket on the cradle allows user to set the unit in a position for easy convenient access. - Display is kept upright and in clear view, allowing easy access to buttons and keys which facilitates safe driving conditions. - Cradles provides secure holder for the portable ensuring safety while driving.• Enhanced in-vehicle audio performance: - Junction box provides vehicle speakerphone capability and includes the following features: - Digital signal processor for full-duplexhands-free communications operation with adaptive echo cancellation and noise reduction. - Simple on/off and ignition sense circuitry. - Audio amplifier with muting capability to drive external speaker and microphone.• Convenient installation for accessible functionalities:- The junction box provides one single interface box for connecting the cradle, external speaker, visor microphone, remote push-to-talk and power cables.- The release button allows quick removal of the portable ensuring all functionalities are always at the user fingertip while on the move. - The junction box provides power source to the external GPS antenna.The MTP850 Digital Car Kit is Motorola’s newest vehicle adapter designed to transform your portable into a virtual mobile radio providing in-vehicle battery charging, hands-free operation and extended coverage.Part number SS-MTP850. Printed in USA 06/08. MOTOROLA and the Stylized M Logo are registered in the US Patent & T rademark Office. All other product or service names are the property of their respective owners. ©Motorola, Inc. 2008. All rights reserved. For system, product or services availability and specific information within your country, please contact your local Motorola office or Business Partner. Specifications are subject to change without notice.Cradle to Junction Box Cable: 2m long terminated with male DB 26 connector Car Kit Operational Temperature Range: -30o C to 60o CBattery Charging: Battery Charger* @ nominal input voltage: Max Charge Current: 1ADead Battery Operation: Radio operational within2 minutes of being insertedOperating Temperature: 0o C to 40o CInput voltage:10.8-15.6VDC (Standard 12VDC automotive system)Antenna RF Connector: FME plugBelt Clip Compatibility: The cradle is not designed to hold the portable whilethe belt clip is attached to the MTP850Radio Compatibility: All MTP850 models Battery Compatibility: FTN6573_ Slim batteryFTN6574_ Extended battery Compatible GPS/TETRA Antennas**: - 380-430 MHz (GMAE4290A) - 800 MHz (GMAF4504A)- 350 MHz (GMAD4500A)* The GMLN4687A car kit provides battery charging voltage to the portable radio while the charging circuit resides in the portable radio. Battery charge times/temperatures are for reference only.**An external antenna kit is required and sold separately. A TETRA-only antenna may be used if GPS signal reception is not required.。
