激光传感器制作入门篇

激光传感器的工作原理激光传感器是一种基于激光技术的高精度、高灵敏度的测量设备，广泛应用于工业、环保、医疗、能源等领域。

本文将介绍激光传感器的工作原理及其应用。

一、激光传感器的基本组成激光传感器由三部分组成：发光器、接收器和信号处理器。

其中发光器负责发射激光信号，接收器负责接受反射回来的信号，信号处理器负责处理接收到的信号并输出测量结果。

二、激光传感器的工作原理激光传感器主要利用激光在介质中的传播和反射特性来进行测量。

具体工作原理如下：1.光的传播激光发射器向待测物体发射激光束，激光束在空气中传播时几乎不会发生散射和吸收，因此激光束的能量保持不变，能够远距离传播。

2.光的反射当激光束照射到待测物体表面时，一部分能量会被物体吸收或散射，但大部分能量会被物体表面反射回来。

这些反射光线会被接收器接收到，进而通过信号处理器进行分析。

3.测量距离通过测量激光束从发射器到物体表面的时间差，可以计算出距离。

激光束发射后，经过一段时间后，接收器会接收到反射回来的信号。

利用光速恒定的特性和时间差可以求出物体表面距离。

三、激光传感器的优点和应用激光传感器具有高精度、高灵敏度、广测量范围、快速反应等优点。

它可以被广泛应用于下列领域中：1.工业制造：激光传感器可以被用于精度高、速度快的零件检测、定位和测量。

可以用于测量机床加工时工件的距离和位置，以保证加工精度。

2.环境监测：激光传感器可以快速准确地测量大气、水资源、土壤等环境参数，例如通过测量水位来监测洪水。

3.医疗应用：激光传感器可以被应用于眼科手术、血糖测量和激光治疗等方面，广泛用于临床医学。

4.能源领域：激光传感器可以被用于监测油井的油气流量、井口压力，以及发电站锅炉的水位、流量和压力等。

激光传感器具备高精度、稳定可靠、快速响应等优点，应用范围广泛，是现代传感技术的重要研究方向之一。

四、激光传感器的分类激光传感器可以按照测量方式、应用行业和工作原理等不同标准分类。

Quick Start GuideClass 1 laser CMOS sensor with a bipolar (1 PNP & 1 NPN) output. Patent pending.This guide is designed to help you set up and install the Q4X Sensor. For complete information on programming, performance, troubleshooting, dimensions, and accessories, please refer to the Instruction Manual at BannerEngineering website. Search for p/n 181483 to view the manual. Use of this document assumes familiarity with pertinentindustry standards and practices.WARNING: Not To Be Used for Personnel ProtectionNever use this device as a sensing device for personnel protection. Doing so could lead to serious injury or death. This device does not include the self-checking redundant circuitry necessary to allow its use in personnel safety applications. A sensor failure or malfunction can cause either an energized or de-energized sensor output condition.FeaturesFigure 1. Sensor Features1.Output Indicator (Amber)2.Display3.Buttons2The display is a 4-digit, 7-segment LED. The main screen is the Run Mode screen, which shows the current distance to the target in millimeters.1.Stability Indicator (STB = Green)2.Active TEACH Indicators•DYN = Dynamic (Amber)•FGS = Foreground Suppression (Amber)•BGS = Background Suppression (Amber)••Off—Outputs not conducting (open)Stability Indicator (STB)•On—Stable signal within the specified sensing range•Flashing—Marginal signal, the target is outside the limits of the specified sensing range, or a multiple peak condition exists•Off—No target detected within the specified sensing rangeQ4X Stainless Steel Laser SensorActive TEACH Indicators (DYN, FGS, and BGS)•DYN, FGS, and BGS all off = Two-point TEACH mode selected (default)•DYN on = Dynamic TEACH mode selected•FGS on = Foreground suppression TEACH mode selected •BGS on = Background suppression TEACH mode selectedButtonsUse the sensor buttons (SELECT)(TEACH), (+)(LO/DO), and (-)(MODE)to program the sensor.(SELECT)(TEACH)•Press to select menu items in Setup mode•Press and hold for longer than 2 seconds to start the currently selected TEACH mode (the default is two-pointTEACH)(+)(LO/DO)•Press to navigate the sensor menu in Setup mode•Press to change setting values; press and hold to increase numeric values•Press and hold for longer than 2 seconds to switch between light operate (LO) and dark operate (DO)(-)(MODE)•Press to navigate the sensor menu in Setup mode•Press to change setting values; press and hold to decrease numeric values •Press and hold for longer than 2 seconds to enter Setup modeNOTE: When navigating the menu, the menu items loop.Laser Description and Safety InformationCAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Do not attempt to disassemble this sensor for repair. A defective unit must be returned to the manufacturer.Class 1 LasersClass 1 lasers are lasers that are safe under reasonably foreseeable conditions of operation, including the use of opticalinstruments for intrabeam viewing.Laser wavelength: 655 nm Output: < 0.20 mWPulse Duration: 7 µs to 2 msQ4X Stainless Steel Laser SensorInstallationInstall the Safety LabelThe safety label must be installed on Q4X sensors that are used in theUnited States.NOTE: Position the label on the cable in a location that has minimal chemical exposure.1.Remove the protective cover from the adhesive on the label.2.Wrap the label around the Q4X cable, as shown.3.Press the two halves of the label together.Figure 3. Safety Label InstallationSensor OrientationOptimize detection reliability and minimum object separation performance with correct sensor-to-target orientation. Toensure reliable detection, orient the sensor as shown in relation to the target to be detected.Figure 4. Optimal Orientation of Target to SensorSee the following figures for examples of correct and incorrect sensor-to-target orientation as certain placements may pose problems for sensing some targets. The Q4X can be used in the less preferred orientation and provide reliable detection performance; see Figure 10 on page 8 for the minimum object separation distance required for each case.Figure 5. Orientation by a wallFigure 6. Orientation for a turning objectIncorrectCorrect Figure 7. Orientation for a height difference HorizontalOrientation Vertical OrientationFigure 8. Orientation for a color or luster differenceQ4X Stainless Steel Laser SensorSensor Mounting1.If a bracket is needed, mount the sensor onto the bracket.2.Mount the sensor (or the sensor and the bracket) to the machine or equipment at the desired location. Do nottighten at this time.3.Check the sensor alignment.4.Tighten the screws to secure the sensor (or the sensor and the bracket) in the aligned position.Wiring Diagram+–NOTE:Open lead wires must be connected to a terminal block.5Key1 = Brown2 = White3 = Blue4 = Black5 = GrayNOTE: The input wire function is user-selectable; see the Instruction Manual for details. The default for the input wire function is off (disabled).Cleaning and MaintenanceHandle the sensor with care during installation and operation. Sensor windows soiled by fingerprints, dust, water, oil, etc.may create stray light that may degrade the peak performance of the sensor. Blow the window clear using filtered,compressed air, then clean as necessary using water and a lint-free cloth.Sensor ProgrammingProgram the sensor using the buttons on the sensor or the remote input (limited programming options).In addition to programming the sensor, use the remote input to disable the buttons for security, preventing unauthorized or accidental programming changes. See the Instruction Manual for more information.Setup ModeMODE SELECT SELECT to select a submenu option and return to the top menu, or press SELECT for longer than 2 seconds to select a submenu option and return immediately to Run mode.To exit Setup mode and return to Run mode, navigate toand press SELECT .Q4X Stainless Steel Laser Sensortwo-point static BGS dynamic BGSone-point BGSone-point Window (FGS)set Response Speed to 1.5 ms set Response Speed to 3 ms set Response Speed to 10 ms set Response Speed to 50 msset Response Speed to 25 ms off: no delays enabledenable on and/or off delay (set value in Delay Timer menu)1 Shot, fixed output pulse durationLO = On pulse when a target is detected inside of the switch point(s)DO = On pulse when a target is detected outside of the switch point(s)near: set zero displayed value to end of 18 mm barrel far: set zero displayed value to maximum detection rangesec range, set Delay Timer value (seconds have decimal)Gain menu is available when Response Speed is set to 10, 25 or 50 mslaser off when pulled low set: Remote Teach input off: remote teach input is not active master slavedisplay ondisplay on, inverteddisplay off (enters sleep mode after 60 seconds)display off, inverted (enters sleep mode after 60 seconds)end: select to exit setupno: do not reset to factory defaults yes: reset to factory defaultson: move the zero point after each teach off: zero point is either at end of barrel or maximum detection range to( default setting)high excess gain modestandard excess gain with increased noise immunitywhen is selected,1 to 9 ms is range available when Response Speed is Figure 9. Sensor Menu MapQ4X Stainless Steel Laser SensorBasic TEACH InstructionsUse the following instructions to teach the Q4X sensor. The instructions provided on the sensor display vary depending on the type of TEACH mode selected. Two-point TEACH is the default TEACH mode.1.Press and hold TEACH for longer than 2 seconds to start the selected TEACH mode.2.Present the target.3.Press TEACH to teach the target. The target is taught and the sensor waits for the second target, if required by theselected TEACH mode, or returns to Run plete steps 4 and 5 only if required for the selected TEACH mode:4.Present the second target.5.Press TEACH to teach the target. The target is taught and the sensor returns to Run mode.See the Instruction Manual for detailed instructions and other available TEACH modes. The TEACH modes include:•Two-point static background suppression —Two-point TEACH sets a single switch point. The sensor sets the switch point between two taught target distances, relative to the shifted origin location.•Dynamic background suppression—Dynamic TEACH sets a single switch point during machine run conditions. The sensor takes multiple samples and the switch point is set between the minimum and the maximum sampled distances.•One-point window (foreground suppression)—One-point window sets a window (two switch points) centeredaround the taught target distance.•One-point background suppression—One-point background suppression sets a single switch point in front of the taught target distance. Objects beyond the taught switch point are ignored.Manual Adjustments1.or2.PressNOTE: When FGS mode is selected (the FGS indicator is on), manual adjustment moves both sides of the symmetrical threshold window simultaneously, expanding and collapsing the window size. Manual adjustment does not move the center point of the window.Light Operate/Dark OperateThe default output configuration is light operate. To switch between light operate and dark operate, use the following instructions:1.Press and hold LO/DO for longer than 2 seconds. The current selection displays.2.Press LO/DO again. The new selection flashes slowly.3.Press SELECT to change the output configuration and return to Run mode.NOTE: If neither SELECT nor LO/DO are pressed after step 2, the new selection flashes slowly for a few seconds, then flashes quickly and the sensor automatically changes the output configuration and returns to Run mode.Locking and Unlocking the Sensor ButtonsUse the lock and unlock feature to prevent unauthorized or accidental programming changes. When locked,displays when the (SELECT)(TEACH) button is pressed. The switch point displays when (+)(LO/DO) or (-)(MODE) arepressed, butdisplays if the buttons are pressed and held.To lock or unlock the sensor using the buttons, press and hold orflashes,depending on the previous status.Q4X Stainless Steel Laser SensorSpecificationsSensing BeamVisible red Class 1 laser, 655 nmSupply Voltage (Vcc)10 to 30 V dcPower and Current Consumption, exclusive of load < 675 mWSensing Range25 mm (0.98 in) to 300 mm (11.81 in)Output ConfigurationBipolar (1 PNP & 1 NPN) outputOutput RatingOff-state leakage current: < 5 µA at 30 V dcPNP On-state saturation voltage: < 1.5 V dc at 100 mA load NPN On-state saturation voltage: < 1.0 V dc at 100 mA load Remote InputAllowable Input Voltage Range: 0 to VccActive Low (internal weak pullup—sinking current): Low State < 2.0 V at 1 mA max.Supply Protection CircuitryProtected against reverse polarity and transient over-voltages Beam Spot SizeTable 1: Beam Spot SizeTemperature Effect0.05 mm/°C at 125 mm0.35 mm/°C at 300 mmExcess GainTable 2: Excess Gain ( Excess Gain1)Connector5-pin Euro M12 Integral ConnectorConstructionHousing: 316 L stainless steelLens cover: PMMA acrylicLightpipe and display window: polysulfone Response SpeedUser selectable:•—1.5 milliseconds•—3 milliseconds•—10 milliseconds•—25 milliseconds•—50 millisecondsDelay at Power Up< 750 msAmbient Light Immunity> 5,000 luxMaximum TorqueSide mounting: 1 N·m (9 in·lbs)Nose mounting: 20 N·m (177 in·lbs)VibrationMIL-STD-202G, Method 201A (10 to 60 Hz, 0.06 in (1.52 mm) double amplitude, 2 hours each along X, Y and Z axes), with sensor operatingShockMIL-STD-202G, Method 213B, Condition I (100G 6x along X,Y and Z axes, 18 total shocks), with sensor operatingEnvironmental RatingIEC IP67 per IEC60529IEC IP68 per IEC60529IEC IP69K per DIN40050-9Chemical CompatibilityCompatible with commonly used acidic or caustic cleaningand disinfecting chemicals used in equipment cleaning andsanitation.Compatible with typical cutting fluids and lubricating fluidsused in machining centersOperating Conditions−10 °C to +50 °C (+14 °F to +122 °F)35% to 95% relative humidityStorage Temperature–25 °C to +75 °C (−13 °F to +167 °F)Application NoteFor optimum performance, allow 10 minutes for the sensorto warm upCertificationsClass 2 powerInd. Cont. Eq.3TJJUL Environmental Rating: Type 1Class 2 Power supply/source to beprovided with 1A overcurrentprotection device. Power supply couldbe current limiting or an 1A externalfuse is required on the power output.ECOLAB® chemical compatibility pending on somemodels; contact Banner Engineering for details.• excess gain provides increased noise immunityQ4X Stainless Steel Laser SensorPerformance CurvesMinimum Separation Distance Between Target and Background for: Uniform and Non-Uniform TargetsM i n i m u m S e p a r a t i o n T a r g e t c k g r o u n d (m m )D i m e n s i oTarget Switch Point DistanceBackground246810121416182022Figure 10. Minimum Object Separation Distance (90% to 6% reflectance)Banner Engineering Corp. Limited WarrantyBanner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp.will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product.THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS OR IMPLIED (INCLUDING, WITHOUT LIMITATION,ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE), AND WHETHER ARISING UNDER COURSE OF PERFORMANCE, COURSE OF DEALING OR TRADE USAGE.This Warranty is exclusive and limited to repair or, at the discretion of Banner Engineering Corp., replacement. IN NO EVENT SHALL BANNER ENGINEERING CORP. BE LIABLE TO BUYER OR ANY OTHER PERSON OR ENTITY FOR ANY EXTRA COSTS, EXPENSES, LOSSES, LOSS OF PROFITS, OR ANY INCIDENTAL,CONSEQUENTIAL OR SPECIAL DAMAGES RESULTING FROM ANY PRODUCT DEFECT OR FROM THE USE OR INABILITY TO USE THE PRODUCT, WHETHER ARISING IN CONTRACT OR WARRANTY, STATUTE, TORT, STRICT LIABILITY, NEGLIGENCE, OR OTHERWISE.Banner Engineering Corp. reserves the right to change, modify or improve the design of the product without assuming any obligations or liabilities relating to any product previously manufactured by Banner Engineering Corp.Q4X Stainless Steel Laser Sensor。

ifm激光传感器说明书
IFM激光传感器是一种高精度的光学传感器，通过激光束来测量目标物体的距离和位置。

它适用于工业自动化领域，可以广泛应用于物体定位、测距、测量和检测等方面。

IFM激光传感器的主要特点和功能如下:
1. 高精度测量: IFM激光传感器采用高精度的激光束，可以实现精确的距离测量，测量误差较小。

2. 宽测量范围: IFM激光传感器可以在较大的距离范围内进行测量，通常可以测量几米甚至更远的距离。

3. 高速测量: IFM激光传感器具有快速测量的能力，可以实时测量目标物体的位置和移动速度。

4. 多种测量模式: IFM激光传感器可以根据不同的应用需求选择不同的测量模式，如单点测量、连续测量和多点测量等。

5. 稳定可靠: IFM激光传感器采用优质的材料和制造工艺，具有良好的耐用性和稳定性，可以长时间稳定运行。

6. 易于安装和使用: IFM激光传感器通常采用小巧的设计，便于安装在各种设备和机器上，操作简单方便。

总之，IFM激光传感器是一种具有高精度、广泛应用和稳定可
靠的光学传感器，可为工业自动化领域提供精确的测量和检测功能。

Quick Start GuideLaser displacement sensor that supports IO-Link communication with analog and discrete (switched) outputs.This guide is designed to help you set up and install the L-GAGE LM Analog/Discrete Laser Sensor. For complete information on programming, performance, troubleshooting, dimensions, and accessories, please refer to the Instruction Manual at . Search for p/n 205812 to view the manual. Use of this document assumes familiarity with pertinentindustry standards and practices.WARNING:•Do not use this device for personnel protection•Using this device for personnel protection could result in serious injury or death.•This device does not include the self-checking redundant circuitry necessary to allow its use inpersonnel safety applications. A device failure or malfunction can cause either an energized (on) or de-energized (off) output condition.Features and Indicators132Three LED indicators provide ongoing indication of the sensing status.1. Analog Output LED IndicatorSolid Amber = Displayed distance is within the taught analog output window Off = Displayed distance is outside the taught analog output window 2. Power LED IndicatorSolid Green = Normal operation, power On and laser OnFlashing Green (1 Hz) = Power On and laser Off (laser enable mode)3. Discrete Output LED IndicatorSolid Amber = Discrete Output is On Off = Discrete Output is OffLaser Description and Safety InformationCAUTION:•Return defective units to the manufacturer.•Use of controls or adjustments or performance of procedures other than those specified herein mayresult in hazardous radiation exposure.•Do not attempt to disassemble this sensor for repair. A defective unit must be returned to themanufacturer.Class 2 Laser Models (LM150 Models)CAUTION:•Never stare directly into the sensor lens.•Laser light can damage your eyes.•Avoid placing any mirror-like object in the beam. Never use a mirror as a retroreflective target.For Safe Laser Use - Class 2 Lasers•Do not stare at the laser.•Do not point the laser at a person’s eye.•Mount open laser beam paths either above or below eye level, where practical.•Terminate the beam emitted by the laser product at the end of its useful path.Reference IEC 60825-1:2007, Section 8.2.L-GAGE ® LM Series Laser SensorOriginal Document 205811 Rev. D27 July 2020205811Class 2 LasersClass 2 lasers are lasers that emit visible radiation in the wavelength range from 400 nm to 700 nm, where eye protection is normally afforded by aversion responses, including the blink reflex. This reaction may be expected to provide adequate protection under reasonably foreseeable conditions of operation, including the use of optical instruments for intrabeam viewing.LASER LIGHTDO NOT STARE INTO BEAMCLASS 2 LASER PRODUCTAcc to IEC 60825-1:2007.λ=640-670nm; P=0.45mWPW: 45-1,750msComplies with 21 CFR 1040.10 and 1040.11Except for deviations pursuant to laser noticeNo. 50, Dated June 24, 2007.Figure 1. FDA (CDRH) warning label (Class 2)Class 2 Laser Safety NotesLow-power lasers are, by definition, incapable of causing eye injury within the duration of ablink (aversion response) of 0.25 seconds. They also must emit only visible wavelengths(400 to 700 nm). Therefore, an ocular hazard may exist only if individuals overcome theirnatural aversion to bright light and stare directly into the laser beam.Class 1 Laser Models (LM80 Models)Class 1 lasers are lasers that are safe under reasonably foreseeable conditions ofoperation, including the use of optical instruments for intrabeam viewing.Figure 2. FDA (CDRH) warning label (Class 1) Laser wavelength: 655 nm Output: < 0.33 mW Pulse Duration: 45 µs to 1750 µsInstallation InstructionsSensor InstallationNote: Handle the sensor with care during installation and operation. Sensor windows soiled by fingerprints,dust, water, oil, etc. may create stray light that may degrade the peak performance of the sensor. Blow thewindow clear using filtered, compressed air, then clean as necessary using 70% isopropyl alcohol and cottonswabs or water and a soft cloth.Install the Safety LabelThe safety label must be installed on or near the LM sensors.Note:Position the label on the cable or near the sensor in a location that has minimal chemical exposure.Figure 3. Typical installation; other mounting options are possible.1.Remove the protective cover from the adhesive on the label.2.Wrap the label around the LM cable, as shown.3.Press the two halves of the label together. - Tel: + 1 888 373 6767P/N 205811 Rev. DSensor OrientationCorrect sensor-to-object orientation is important to ensure proper sensing. See the following figures for examples of correct and incorrect sensor-to-object orientation as certain placements may pose problems for sensing distances.Figure 4. Orientation by a wall IncorrectCorrect Figure 5. Orientation in an openingIncorrectCorrectFigure 6. Orientation for a turning objectIncorrectCorrectFigure 7. Orientation for a height difference IncorrectCorrectFigure 8. Orientation for a color or luster difference Figure 9. Orientation for a highly reflective targetApplying tilt to sensor may improve performance on reflective targets. The direction and magnitude of the tilt depends on the application, but a 15° tilt is often sufficient.Mount the Device1.If a bracket is needed, mount the device onto the bracket.2.Mount the device (or the device and the bracket) to the machine or equipment at the desired location. Do not tighten themounting screws at this time.3.Check the device alignment.4.Tighten the mounting screws to secure the device (or the device and the bracket) in the aligned position.Wiring Diagrams+–* Push-Pull output. User-configurable PNP/NPN setting.*Key 1 = Brown 2 = White 3 = Blue 4 = Black 5 = Gray+–* Push-Pull output. User-configurable PNP/NPN setting.*The bare shield wire is connected internally to the sensor housing and should be connected as follows:•If the sensor housing is mounted so that it is in continuity with both the machine frame and earth ground, connect the barewire (also) to earth ground.•If the sensor housing is mounted so that it is insulated from the machine frame and you are experiencing noise, connectingthe bare wire to -V dc (together with the blue wire), may help.•If the sensor is mounted so that it is in continuity with the machine frame, but not with earth ground, do not connect thebare wire (e.g. cut off the bare wire).P/N 205811 Rev. D - Tel: + 1 888 373 67673Configuration InstructionsSensor ProgrammingProgram the sensor using the buttons on the RSD1 remote sensor display accessory, via IO-Link, or the remote input (limited programming options).If you are using the RSD1 for programming, from Run mode, use the buttons to access the Quick Menu and the Sensor Menu. See the instruction manual (p/n 205812) for more information on the options available from each menu. For TEACH options, follow the TEACH instructions in the instruction manual.In addition to programming the sensor, use the remote input to disable the buttons for security, preventing unauthorized or accidental programming changes. See the instruction manual for more information.from Run Mode> 4 sec.Access Sensor Menu Access RSD1 MenuFigure 10. Accessing the MenusRemote Display Buttons and the LMUse the RSD1 buttons Down , Up , Enter , and Escape to view or change RSD1 settings and information and to program a connected sensor.Down and Up Buttons Press Down and Up to:•Access the Quick Menu from Run mode •Navigate the menu systems •Change programming settings•Change individual digit values in distance based settings When navigating the menu systems, the menu items loop.Press Down and Up to change setting values. Press and hold the buttons to cycle through numeric values. After changing a setting value, the value slowly flashes until the change is saved using the Enter button.Enter Button Press Enter to:•Access the Sensor Menu from Run mode •Access the submenus•Move right one digit in distance based settings •Save changesIn the RSD1 Menu, a check mark in the lower right corner of the display indicates that pressing Enter accesses a submenu.Press Enter to save changes. New values flash rapidly, and the sensor returns to the parent menu. - Tel: + 1 888 373 6767P/N 205811 Rev. DEscape ButtonPress and hold Escape for 4 seconds to:•Access the RSD1 Menu while in Run modePress Escape to:•Leave the current menu and return to the parent menuImportant: Pressing Escape discards any unsaved programming changes.In the RSD1 Menu, a return arrow in the upper left corner of the display indicates that pressing Escape returns to the parent menu.Press and hold Escape for 2 seconds to return to Run mode from the RSD1 Menu.Quick MenuThe sensor includes a Quick Menu with easy access to view and change the analog and discrete output switch points.Access the Quick Menu by pressing Down or Up from Run mode. When in the Quick Menu, the current distance measurement displays on the first line and the menu name and the analog value alternate on the second line of the display. Press Enter to access the switch points.Press Down or Up to change the switch point to the desired value.Press Enter to save the new value and return to the Quick Menu.* In Setpoint mode, SPt1 Pt is replaced by SPt and SPt2 Pt is not available.In Dual mode, SPt1 is replaced by DualSPt and SPt2 Pt is not available.Sensor Menu (MENU)Access the Sensor Menu by pressing Enter from Run mode. The Sensor Menu is also accessible from the Quick Menu: navigate to MENU and press Enter. The Sensor Menu includes several submenus that provide access to view and change sensor settings and to view sensor information.P/N 205811 Rev. D - Tel: + 1 888 373 67675SensorMenu Full MapFrom Run mode, press Enter to enter the top-level menu system (A_OUT, D_OUT, INPUT, MEASURE, etc).Top Menu* Factory default setting - Tel: + 1 888 373 6767P/N 205811 Rev. DSpecificationsSupply Voltage (Vcc)10 V dc to 30 V dcUse only with a suitable Class 2 power supply (North America) Power and Current Consumption, exclusive of loadNormal Run Mode: 1.5 W, Current consumption < 62 mA at 24 V dc Supply Protection CircuitryProtected against reverse polarity and transient overvoltages Ambient Light Immunity10,000 luxConstructionHousing: stainless steelWindow: acrylic Sensing BeamVisible red, 655 nmSensing RangeLM80: 40 to 80 mmLM150: 50 mm to 150 mmDelay at Power Up2.1 sMeasurement/Output Rate0.25 ms to 4 ms; user selectable from the Speed menu Output ConfigurationAnalog output: 4 to 20 mA (LM...I Models) or 0 to 10 V DC (LM...U Models)Discrete output: Push/Pull, IO-LinkOutput RatingsDiscrete Output: 50 mA maximum (protected against continuous overload and short circuit)Output saturation voltage (PNP): < 3 V at 50 mAOutput saturation voltage (NPN): < 2.5 V at 50 mAAnalog current output (LM...I Models): 500 Ω maximumAnalog voltage output (LM...U Models): 1000 Ω minimum Maximum Torque1.5 N·mRemote InputAllowable Input Voltage Range: 0 to VccActive Low (internal weak pullup—sinking current):High State: > 3.6 VLow State: < 2.4 VActive High (internal weak pulldown—sourcing current): High State: > Vcc - 2.9 VLow State: < Vcc - 4.6 VMinimum Window Size, Analog and DiscreteLM80:Analog: 1 mmDiscrete: 0.024 mmLM150:Analog: 1 mmDiscrete: 0.1 mm Analog ResolutionLM80: 0.002 mmLM150: 0.004 mmRepeatabilityLM80: ± 0.001 mm1LM150: ± 0.002 mm 2Analog and IO-Link LinearityLM80:40–70 mm: ± 0.02 mm70–80 mm: ± 0.03 mmLM150:50–120 mm: ± 0.06 mm120–150 mm: ± 0.07 mmIO-Link Accuracy3LM80: ± 0.175 mmLM150: ± 0.2 mmTemperature Effect, TypicalLM80: ± 0.006 mm/°CLM150: ± 0.008 mm/°CResponse TimeTotal response speed varies from 0.5 ms to 2048 ms, depending on base measurement rate and averaging settings.See Instruction Manual for more information.Minimum Object SeparationLM80:Uniform targets (6% to 90% reflectivity) 40–70 mm: 0.04 mmUniform targets (6% to 90% reflectivity) 70–80 mm: 0.06 mmNon-uniform targets (6% to 90% reflectivity): 0.4 mmLM150:Uniform targets (6% to 90% reflectivity) 50–120 mm: 0.120 mmUniform targets (6% to 90% reflectivity) 120–150 mm: 0.140 mm Non-uniform targets (6% to 90% reflectivity): 0.8 mm Environmental RatingIEC IP67Operating Conditions–10 °C to +55 °C (+14 °F to +131 °F)90% at +55 °C maximum relative humidity (non-condensing) Storage Temperature–35 °C to 60 °C (–31°F to 140 °F)Boresighting± 0.70 mm at 40 mm± 0.87 mm at 50 mm± 1.40 mm at 80 mm± 2.62 mm at 150 mmVibration/Mechanical ShockMeets IEC 60947-5-2 (10 to 60 Hz max., double amplitude 0.06 in, max acceleration 10G. 30G 11 ms duration, half sine wave) Application NoteFor optimum performance, allow 10 minutes for the sensor to warm upCertificationsUL Type 1with 128× averaging. With 1× averaging, repeatability of ± 0.004 mm from 40 to 80 mm.with 128× averaging. With 1× averaging, repeatability of ± 0.005 mm from 50 to 120 mm and ± 0.010 mm from 120 to 150 mm.3The accuracy specification refers to the possible absolute offset when installing a sensor without taking any reference measurement.Linearity is the more relevant specification for most applications.P/N 205811 Rev. D - Tel: + 1 888 373 67677Typical Beam Spot Size4Required Overcurrent ProtectionWARNING: Electrical connections mustbe made by qualified personnel inaccordance with local and nationalelectrical codes and regulations.Overcurrent protection is required to be provided by endproduct application per the supplied table.Overcurrent protection may be provided with external fusing orvia Current Limiting, Class 2 Power Supply.Supply wiring leads < 24 AWG shall not be spliced.For additional product support, go to.FCC Part 15 and CAN ICES-3 (B)/NMB-3(B)This device complies with part 15 of the FCC Rules and CAN ICES-3 (B)/NMB-3(B). Operation is subject to the following two conditions:1.This device may not cause harmful interference, and2.This device must accept any interference received, including interference that may cause undesired operation.This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules and CAN ICES-3 (B)/NMB-3(B). These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:•Reorient or relocate the receiving antenna.•Increase the separation between the equipment and receiver.•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•Consult the manufacturer.Banner Engineering Corp. Limited WarrantyBanner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product.THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE), AND WHETHER ARISING UNDER COURSE OF PERFORMANCE, COURSE OF DEALING OR TRADE USAGE. This Warranty is exclusive and limited to repair or, at the discretion of Banner Engineering Corp., replacement. IN NO EVENT SHALL BANNER ENGINEERING CORP. BE LIABLE TO BUYER OR ANY OTHER PERSON OR ENTITY FOR ANY EXTRA COSTS, EXPENSES, LOSSES, LOSS OF PROFITS, OR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES RESULTING FROM ANY PRODUCT DEFECT OR FROM THE USE OR INABILITY TO USE THE PRODUCT, WHETHER ARISING IN CONTRACT OR WARRANTY, STATUTE, TORT, STRICT LIABILITY, NEGLIGENCE, OR OTHERWISE.Banner Engineering Corp. reserves the right to change, modify or improve the design of the product without assuming any obligations or liabilities relating to any product previously manufactured by Banner Engineering Corp. Any misuse, abuse, or improper application or installation of this product or use of the product for personal protection applications when the product is identified as not intended for such purposes will void the product warranty. Any modifications to this product without prior express approval by Banner Engineering Corp will void the product warranties. All specifications published in this document are subject to change; Banner reserves the right to modify product specifications or update documentation at any time. Specifications and product information in English supersede that which is provided in any other language. For the most recent version of any documentation, refer to: .For patent information, see /patents.© Banner Engineering Corp. All rights reserved。

激光传感器的工作原理及应用概述激光传感器是一种常见的光电传感器，利用激光束进行测量和探测。

它具有高精度、高灵敏度、非接触等特点，在工业自动化、机器人、安防监控等领域得到广泛应用。

本文将介绍激光传感器的工作原理以及其在不同领域的应用。

工作原理激光传感器的工作原理基于激光束的测距原理。

其核心部件是激光发射器、接收器和信号处理器。

1.激光发射器：激光传感器通过激光发射器产生并发射激光束。

激光束一般可以分为连续型和脉冲型两种。

连续型激光束是持续发射的，适用于距离较远的测量；脉冲型激光束则以脉冲的形式发射，适用于测量更近的距离。

2.接收器：激光传感器的接收器用于接收反射回来的激光束。

接收器通常包括光学透镜和光电探测器。

光学透镜用于聚焦激光束，而光电探测器则用于将激光转换为电信号。

3.信号处理器：激光传感器的信号处理器对接收到的电信号进行处理和分析，得出测量结果。

处理器可以根据接收信号的幅值、时序等信息计算出物体与激光传感器的距离、位置等参数。

应用领域激光传感器在各个领域都有广泛的应用。

以下是一些典型的应用案例：工业自动化•测距和测量：激光传感器可用于测量物体的距离、高度、宽度等参数，被广泛应用于机器人导航、机械加工、流水线控制等领域。

•检测和定位：激光传感器可以用于检测物体的位置、形状等特征，常用于自动控制、目标定位等系统。

•物体识别：激光传感器可以识别、辨别不同材料的物体，广泛应用于质量检测、物料分拣等场景。

安防监控•周界安防：激光传感器可以通过监测激光束是否被遮挡来实现周界安防，常用于仓库、园区等场所。

•运动检测：激光传感器可通过检测物体的运动来实现安防监控，常用于智能门禁、入侵报警等系统。

•人体检测：激光传感器可以识别和跟踪人体，用于人体计数、行为分析等应用场景。

环境监测•污染检测：激光传感器可以检测大气中的颗粒物，用于空气污染监测、工业排放监控等。

•温度测量：激光传感器可以通过测量物体表面的红外辐射来实现非接触式温度测量，常用于物体表面温度检测。

激光传感器工作原理激光传感器是一种利用激光技术进行测量和检测的传感器，它具有高精度、高灵敏度和快速响应的特点，被广泛应用于工业、医疗、环境监测等领域。

激光传感器的工作原理是基于激光的散射、反射、吸收等物理现象，通过测量激光的特性来实现对目标物体的测量和检测。

本文将从激光传感器的基本原理、工作过程和应用领域等方面进行介绍。

激光传感器的基本原理是利用激光的特性进行测量。

激光是一种具有高能量、高单色性和高方向性的光束，它可以在空间中传播并与物体发生相互作用。

当激光束照射到目标物体上时，会发生激光的散射、反射或吸收现象。

激光传感器利用这些现象来测量目标物体的距离、形状、表面特性等参数，实现对目标物体的检测和测量。

激光传感器的工作过程主要包括激光发射、激光与目标物体的相互作用、接收反射光信号和信号处理等步骤。

首先，激光传感器通过激光发射器发射一束激光束，该激光束照射到目标物体上并与目标物体发生相互作用，产生散射、反射或吸收现象。

然后，激光传感器的接收器接收目标物体反射回来的光信号，并将其转换为电信号。

最后，经过信号处理和数据分析，激光传感器可以得到目标物体的距离、形状、表面特性等信息。

激光传感器在工业、医疗、环境监测等领域有着广泛的应用。

在工业领域，激光传感器可以用于测量物体的距离、形状、表面粗糙度等参数，广泛应用于机器人、自动化生产线、三维扫描等领域。

在医疗领域，激光传感器可以用于医学影像、激光治疗、医疗仪器等方面，为医疗诊断和治疗提供了重要的技术支持。

在环境监测领域，激光传感器可以用于大气污染监测、水质监测、激光雷达等方面，为环境保护和资源管理提供了重要的技术手段。

综上所述，激光传感器是一种利用激光技术进行测量和检测的传感器，具有高精度、高灵敏度和快速响应的特点。

它的工作原理是基于激光的散射、反射、吸收等物理现象，通过测量激光的特性来实现对目标物体的测量和检测。

激光传感器在工业、医疗、环境监测等领域有着广泛的应用前景，将为各行业的发展和进步提供重要的技术支持。

传感器的制作方法嘿，朋友！今天咱来唠唠传感器的制作方法哈，这可是独家秘籍哦，一般人我可不告诉他！首先啊，咱得准备好材料。

就好比你要做饭，那总得有菜有肉有调料吧。

咱做传感器也得有那些关键玩意儿。

这就像你去打架，手里没家伙事儿可不行。

然后呢，咱就开始动手啦！第一步，把那些零件啥的都摆好，就像给你的小兵们排兵布阵一样，可别弄乱了，不然等会儿你都找不着北。

接着，就该焊接啦！这焊接就好比给它们牵红线，让它们紧紧地连在一起，不离不弃的。

哎呀，可别手抖啊，一抖就像给它们牵错线啦，那可就乱套喽！我跟你说，我有次焊接的时候，手一抖，好家伙，差点把旁边的东西都给点着了，那场面，跟放烟花似的！焊接好了之后，咱得检查检查，看看有没有哪里没接好。

这就像你出门前得照照镜子，看看自己有没有穿得邋里邋遢的。

下面这步也很重要哦，就是给传感器装上外壳。

这外壳就像是给它穿了件衣服，保护它不受伤害。

你想啊，要是没件衣服，它不就赤裸裸地在那，多可怜呀。

再之后，就是调试啦！这调试就像是给你的爱车调调方向盘，得让它走得直直的，不能跑偏喽。

在调试的时候，你可得细心点，就像给女朋友选礼物一样，得用心。

要是马马虎虎的，那可不行。

我记得我有次调试，没仔细看，结果弄出来个四不像，哎呀，真是哭笑不得。

还有哦，在整个过程中，一定要注意安全。

别电着自己啦，别烫着自己啦，可别为了做个传感器把自己弄伤了，那可就得不偿失了。

等你都弄好了，嘿，一个属于你自己的传感器就诞生啦！就像你生了个宝贝一样，那种成就感，简直爆棚！总之呢，做传感器就是要有耐心，要细心，还要有点小技巧。

按照我说的这些步骤来，保准你能做出一个超级棒的传感器。

加油吧，朋友！快去试试，等你成功了，记得来跟我分享哦！哈哈！。

ZLDS10X可左制激光位移传感器量程:2~ lOOOinm 〔可泄制〕精度：最髙0.1% 〔玻璃0.2%〕分辨率：最髙0.03%频率响应：2K.5K・8K・10K时间：2021.03. 09 创作：欧阳法基来源根基理是光学三角法：半导体激光器1被镜片2聚焦到被测物体6.反射光被镜片3收集，投射到CCD阵列4上：信号处理器5通过三角函数讣算阵列4上的光点位置获得距物体的距藹。

激光传感器原理与应用激光传感器是利用激光技术进行丈量的传感器。

它由激光器、激光检测器和丈量电路组成。

激光传感器是新型丈量仪表，它的优点是能实现无接触远距离丈量，速度快，精度高，疑程年夜，抗光、电干扰能力强等。

激光和激光器——激光是20世纪60年代呈现的最重年夜的科学技术成绩之一。

它成长迅速，已广泛应用于国防、生产、医学和非电丈量等各方而。

激光与普通光不合，需要用激光器产生。

激光器的工作物质，在正常状态下，大都原子处于稳左的低能级E1,在适当频率的外界光线的作用下，处于低能级的原子吸收光子能量受激发而跃迁到髙能级E2e光子能量E=E2El=hv,式中h为普朗克常数，v为光子频率。

反之，在频率为v的光的诱发下，处于能级E2的原子会跃迁到低能级释放能量而发光，称为受激辐射。

激光器首先使工作物质的原子变态地大都处于髙能级〔即粒子数反转散布〕，就能使受激辎射过程占优势，从而使频率为v的诱发光获得增强，并可通过平行的反射镜形成雪朋式的放年夜作用而产生强年夜的受激辐射光，简称激光。

激光具有3个重要特性：〔1〕髙标的目的性〔即髙泄向性，光速发散角小〕，激光朿在几公里外的扩展规模不过几厘米：〔2〕髙单色性，激光的频率宽度比普通光小10倍以上；〔3〕髙亮度，利用激光束会聚最高可产生达几百万度的温度。

激光器按工作物质可分为4种：〔1〕固体激光器：它的工作物质是固体。

经常使用的有红宝石激光器、掺敘的锂铝右•榴石激光器〔即YAG激光器〕和放玻璃激光器等。

手把手教你制作激光传感器越升电子科技 jack_channel 在做激光之前，我们先来了解一下激光的分类，现在飞思卡尔智能车里面常用的有650nm波长的可见激光和980nm波长的红外激光（不可见，要用摄像头才能看到），其中650nm 波长的可见激光被大多数学校所接纳。
