奥林巴斯BX41系统显微镜配置清单.doc

OIXMPUS生物显微镜CX31技术规格：用途：可观察普通染色的切片观察。

1. 工作条件1.1适于在气温为摄氏-40C〜+ 50C的环境条件下运输和贮存，在电源220V (10%) /50Hz、气温摄氏5C〜40C和相对湿度85%的环境条件下运行。

1.2配置符合中国有关标准要求的插头，或提供适当的转换插座。

2. 主要技术指标2.1生物显微镜*2.1.1光学系统：无限远光学矫正系统，齐焦距离必须为国际标准45mm。

2.1.2 放大倍率：40-1000倍*2.1.3 载物台：钢丝传动，无齿条结构，尺寸为188mm x 134mm,活动范围为X轴向76mm x 丫轴向50mm，双片标本夹2.1.4调焦机构：载物台垂直运动由滚柱(齿条一小齿轮)机构导向，米用粗微同轴旋钮，粗调行程每一圈为36.8mm，总行程量为25mm，微调行程为每圈0.2m m,具备粗调限位挡块和张力调整环2.1.5聚光镜：带有孔径光阑的阿贝聚光镜，N.A. 1.25，带有蓝色滤色片*2.1.6照明系统：内置6V30W卤素灯，内置透射光柯勒照明*2.1.7 三目观察筒：视场数> 20瞳距调节范围为48-75mm,铰链式2.1.8目镜：10X,带眼罩，视场数>20带目镜测微尺*2.1.9 物镜：平场消色差物镜4X( N.A. > 0.)、10X( NA > 0.2)40X( NA > 0.6)100X (N.A. > 1.2)2.1.11防霉装置：在三目观察筒、目镜、物镜都做了防霉处理*2.1.12整机原装进口,所采用光学元件均为环保无铅玻璃，样本上有ECO无铅认证标识。

所有光学部件都做了防霉处理，所以能确保获得持续清晰的图像，并延长显微镜的使用寿命，即使在湿热的环境中工作也不受影响3•成像系统技术规格一.图像采集部分CCD采用MT9J003-1/2.5英寸图像传感器核心，，保证了和目镜观察同步放大倍率，采用D65光源自动校正，对于非标准白光光源自动背景补偿。

BX3 Microscope Unit Guide BX63/BX53/BX43/BX46BX3 SeriesSystem MicroscopePLN (PLN-PH) SeriesAppropriate for a range of biological applications, these high-quality objectives offer flatness up to OFN 22 in transmitted brightfield (phase contrast) observation. The PLN-PH series is designed for phase contrast observation.PLAPON SeriesDesigned for high resolution andcontrast, Plan Apochromat objectivesreduce chromatic aberration to lowlevels.UPLFLN (UPLFLN-PH) SeriesThese Plan objectives provide flat imageswith high transmission up to the near-infrared region of the spectrum. Withtheir high signal-to-noise ratio, highresolution, and high contrast images,the objectives are especially effective inbrightfield and Nomarski DIC observations.The UPLFLN-PH series is optimized forphase contrast observation.1Objective Lens NA W.D.(mm)OFNCover GlassThickness(mm)Immersion SpringLoadedPLN2X0.06 5.822-PLN4X0.1018.522-PLN10X0.2510.622-PLN20X0.40 1.2220.17✓PLN40X0.650.6220.17✓PLN50XOI0.9-0.50.222-Oil✓PLN100XO 1.250.1522-Oil✓LPLN40X0.60 3.4-4.1220-1PLN10XPH0.2510.622-PLN20XPH0.40 1.2220.17✓PLN40XPH0.650.6220.17✓PLN100XOPH 1.250.1522-Oil✓UPLFLN4X0.131726.5-UPLFLN10X20.301026.5-UPLFLN20X0.50 2.126.50.17UPLFLN40X0.750.5126.50.17✓Objective Lens NA W.D.(mm)OFNCover GlassThickness(mm)Immersion SpringLoadedUPLFLN100XO2 1.300.226.50.17Oil✓UPLFLN100XOI2 1.3-0.60.226.50.17Oil✓UPLFLN10X2PH0.301026.5-UPLFLN20XPH0.50 2.126.50.17UPLFLN40XPH0.750.5126.50.17✓UPLFLN100XO2PH 1.300.226.50.17Oil✓PLAPON1.25X0.04 5.026.5-PLAPON2X0.08 6.226.5-MPLFLN10X0.301126.5-MPLFLN20X0.45 3.126.50MPLFLN40X0.750.6326.50✓MPLFLN100X0.90126.50MPLAPON60X0.900.426.50✓MPLAPON100X0.950.3526.50✓MPLAPON100XO2 1.450.1026.50Oil✓UPLXAPO SeriesThanks to novel manufacturing technology, Olympus UPLXAPO high-performance objectives offer improved optical performance in three critical areas—a larger numerical aperture (NA), better image flatness, and a wider range of chromatic correction. These advances enable high-quality, large field of view (FOV) imaging for versatility in numerous applications.Olympus’ BX3 series can be configured to meet the needs of your research. The combination of leading-edge imaging capabilities with the flexibility to customize the system to your specific application makes BX3 series microscopes powerful research tools.Series Objective Lens NA W.D.(mm)OFNCover GlassThickness(mm)ChromaticCorrectionRangeSpringLoadedX Line U LXA O4X0.161326.5-400-1000 nmU LXA O10X0.40 3.126.50.17400-1000 nmU LXA O20X0.800.626.50.17400-1000 nm✓U LXA O40X0.950.1826.50.11-0.23400-1000 nm✓U LXA O40XO 1.400.1326.50.17400-1000 nm✓U LXA O60XO 1.420.1526.50.17400-1000 nm✓U LXA O100XO 1.450.1326.50.17400-1000 nm✓U LXA O60XO H 1.420.1526.50.17400-1000 nm✓UPLXAPO100XOPH 1.450.1326.50.17400-1000 nm✓Objective LensIntroductionAccessories2Main Type Brightness BX43FManual2W LED Light Source (30W Halogen Equivalent)BX46F Manual2W LED Light Source (30W Halogen Equivalent)BX53F2Manual / Motorized14W LED Light Source (100W Halogen Equivalent)BX63F Motorized2W LED Light Source or 12V 100W Halogen Light SourceMicroscope FramesObservation Tube FN Type Angle Type FeatureU-BI30-222Binocular Fixing -U-TBI-322Binocular Tilting High Eye Point U-TBI-3-CLI 22Binocular Tilting Low Eye Point U-TTBI 22Binocular Tilting Telescopic U-TTLBI 22Binocular Tilting Lift Adjustment, TelescopicU-ETR-422Trinocular Fixing Erected ImageU-TR30-222Trinocular Fixing -U-TTR-222Trinocular Tilting -U-SWTR-326.5Trinocular Fixing Super Widefield U-SWETTR-526.5TrinocularTiltingErected Image, Super WidefieldObservation TubesEyepieces FN Reticle HelicoidWHN10X 22-WHN10X-H 22-✓CROSSWHN10X 22Crosshair✓SWH10X-H26.5-✓EyepiecesBX53F2U-TTR-2SWH10X-H WHN10X WHN10X-H CROSSWHN10X3Intermediate Tube Description U-EPA2Eyepoint Adjuster U-EPAL-2Eyepoint Adjuster U-CA Magnification ChangerU-KPA Intermediate Attachment for Simple Polarizing ObservationU-TRU Trinocular Intermediate Unit U-TRUS Trinocular Intermediate UnitU-DP Dual Port U-DP1XCDual Port 1XIntermediate TubesBright Field Light Source Bulb Brightness U-LH100-3Halogen 12V100WU-LHLEDC LED 2W (30W Halogen Equivalent)U-LHLEDC100LED14W (100W Halogen Equivalent)Bright Field Light SourcesIllumination Tube # of FL CubeTurret Type Illumination PatternBX3-URA 8Manual Normal BX3-RFAS 8Coded FlyEye BX3-RFAA8MotorizedFlyEyeIllumination TubesBX3-RFAAFluorescence Light Source Description U-HGLGPS Light SourceU-LH100HG 100 W Mercury Lamp Housing U-LH100HGAPO100 W Mercury Apo Lamp HousingFluorescence Light SourcesU-HGLGPSU-TRUMotorized Controller Description U-HSCBM Hand Switch for CBM U-HSEXP Hand Switch for ExposureBX3M-HSRE Hand Switch U-MCZ Controller BX3-CBH Control Box BX3-CBM Control BoxU-CBS Control Box for Coded Function U-IFRESInterface for Coded NosepieceMotorized ControllerU-MCZ4Nosepieces Type # of ObjectivesWorking SlotU-5RE-2Manual 5BX43-5RES Coded 5U-D6RE Manual 6✓U-D6RES Coded 6✓U-D7RES Coded 7✓U-D7REAMotorized7✓NosepiecesSample Holder Handle # of Slide Thickness U-HLD-4Left Double Thin U-HLDT-4Left Double Thick U-HLS-4Left Single Thin U-HLST-4Left Single Thick U-HRD-4Right Double ThinU-HRDT-4RightDoubleThickSample HoldersStage Accessories DescriptionBX3-SHEA Stage Handle Extention AdaptorU-SHG Rubber Grip U-SHGTRubber Grip (Thick)Stage AccessoriesStage Control HandleType Applicable SystemU-SVLB-4Left Manual All U-SVRB-4Right Manual All U-SVRC Right Manual Only BX46U-SVRC-CY Right Manual Only BX46BX3-SSU Motorized Motorized Only BX63U-SP No Handle Manual All IX-SVL2LeftManualOnly BX63StagesU-D7REAU-HR(L)DT -45TV Adaptor Description U-TV0.35XC-20.35X C-Mount Adaptor U-TV0.5XC-30.5X C-Mount Adaptor U-TV0.63XC 0.5X C-Mount Adaptor U-TV1XC 1X C-Mount Adaptor (XY adjustment)U-TV1X-2TV Adaptor U-CMAD3C-Mount Adaptor U-BMAD Bayonet-Mount Adaptor U-SMAD Sony Mount Adaptor U-TMAD T-Mount Adaptor U-FMT F-Mount Adaptor U-CMT C-Mount Adaptor U-DPCADDouble Port Tubes with C MountsTV AdaptorsCondenser NA Type Contrast MethodU-AC2 1.1Manual BF U-SC30.9Manual BF/PO U-LC 0.75Manual BF/PO U-AAC 1.4Manual BF U-PCD2 1.1Manual BF/PH/DF U-DCD 0.92Manual DF U-DCW 1.4Manual DF U-UCD8-2Oil Top Lens 1.4 / Dry Top Lens 0.9Manual BF/PH/DIC/DF/PO BX3-UCD8AOil Top Lens 1.4 / Dry Top Lens 0.9MotorizedBF/PH/DIC/DF/POCondensersAccessoriesU-TV0.63XCU-TV0.35XC-2BX3-UCD8AU-PCD2U-DCWU-DCDU-SC3U-AC2U-LCU-AACU-UCD8-2U-TV0.5XC-3U-TV1XCU-TV1X-2+U-CMAD3U-TV1X-2+U-BMAD6Polarizer/Analyzer/DIC Slider Description U-POT Polarizer BX45-PO PolarizerU-ANT Analyzer for Transmitted LightU-AN-2Analyzer SliderU-GAN Analyzer for Urate Crystals ObservationU-DFA Darkfield Ring U-PH1-S Phase Contrast Ring (small)U-PH2-S Phase Contrast Ring (small)U-PH3-S Phase Contrast Ring (small)U-DIC10DIC Prism U-DIC10S DIC Prism (small)U-DIC20DIC Prism U-DIC40DIC Prism U-DIC60DIC Prism U-DIC100DIC PrismU-DICT DIC Slider for Transmitted Light U-DICTS Shift DIC Slider for Transmitted LightU-FDICTDIC Mirror UnitPolarizer/Analyzer/DIC SliderMirror Unit Excitation FilterEmission FilterDichroic MirrorU-FF No Filter No Filter No Mirror U-FUW BP340-390BA420IF DM410U-FUN BP360-370BA420IF DM410U-FUNA BP360-370BA420-460DM410U-FBVW BP400-440BA460IF DM455U-FBW BP460-495BA510IF DM505U-FBWA BP460-495BA510-550DM505U-FBN BP470-495BA510IF DM505U-FBNA BP470-495BA510-550DM505U-FGW BP530-550BA575IF DM570U-FGWA BP530-550BA575-625DM570U-FGNA BP540-550BA575-625DM570U-FYW BP540-585BA600IF DM595U-FCFP BP425-445CFP BA460-510CFP DM455CFP U-FGFP BP460-480GFP BA495-540GFP DM490GFP U-FYFP BP490-500YFP BA515-560YFP DM515YFP U-FRFP BP535-555HQ BA570-625HQ DM565HQ U-FMCHEBP565-585BA600-690DM595Mirror UnitsU-DICTGroup Observation SystemsMulti-head discussion systems are invaluable for lab training and education. Olympus offers discussion systems for as few as two or as many as 26 people. With our BX3 series multi-discussion observation (MDO) system, every participant can see the same high-quality image. The integrated LED arrow pointer helps instructors highlight key features in the teaching specimen.Front to Back ObservationSide-by-Side ObservationHeads 22359101826Shape Front to BackSide by SideLinearLinearLinearH-ShapeH-ShapeH-ShapeU-DO31U-SDO31U-MDOB3111U-MDO10B3111U-MDO10R31U-MDOSV 1244812BX3-MDO18R 11BX3-MDOE248Multi Observation for 9 peopleMulti Observation for 26 people7BX46 System DiagramBX46 SYSTEM DIAGRAM Array8BX63 SYSTEM DIAGRAM910System DiagramBX53 System DiagramBX53 SYSTEM DIAGRAM Array1112System DiagramBX43 System DiagramBX43 SYSTEM DIAGRAM Array1314Microscope Frame Optical System UIS2 optical systemFocusBuilt-in motorized nosepiece focusStroke: 20 mm; minimum increment: 0.01 µm; maximum nosepiece movement speed: 5 mm/s IlluminatorBuilt-in Köhler illumination for transmitted light, light intensity LED indicator, built-in motorized field stop• High color reproductivity LED light source•12 V 100 W halogen bulb (pre-centered)Revolving Nosepiece • Motorized septuple revolving nosepiece• Interchangeable reversed coded sextuple/coded septuple nosepieceObservation Tube Widefield (FN 22)• Widefield tilting trinocular• Widefield trinocular• Widefield erect image trinocular• Widefield tilting binocular• Widefield tilting, telescopic, lifting binocular • Widefield ergo binocular• Widefield binocularStage • Ultrasonic stage (Stage stroke: X: 76 mm × Y: 52 mm; maximum stage movement speed: 30 mm/s • Ceramic-coated coaxial stage with left or right hand low drive control: with rotating mechanism and torque adjustment mechanism, optional rubber grips, and available stage handle extension adaptor• Cross stage with short left handleCondenser • Motorized universal condenser (NA 0.9, motorized 8-position turret, aperture stop, polarizing filter in/outmechanism, and top lens swing out mechanism), for 1.25X–100X [swing-out 1.25X-4X, with oil top lens: (NA 1.4)] • Swing out Achromatic (NA 0.9), for 1.25X–100X (swing-out: 1.25X–4X)• Achromatic Aplanatic (NA 1.4), for 10X–100X• Universal (NA 0.9), for 1.25X–100X [swing-out: 1.25X–4X, with oil top lens: (NA 1.4)]• Darkfield dry (NA 0.8–0.92), for 10X–100X• Darkfield oil (NA 1.20–1.40), for 20X–100XND Filter Wheel• Motorized 6-position ND filter wheelFluorescence Illuminator • Motorized multi-purpose coded type (FN 22, motorized 8-position mirror unit turret, 4-position ND slider) • Multi-purpose coded type (FN 22, 8-position mirror unit turret, 4-position ND slider)Fluorescence Light Source • 130 W mercury light guide illumination• 100 W mercury apo lamp housing and power supply unit • 100 W mercury lamp housing and power supply unitController• High-performance control box ( I/F: FireWire) BX63 SPECIFICATIONSMicroscope Frame Optical System UIS2 optical systemFocusVertical stage movement: 25 mm stage stroke with coarse adjustment limit stopper, torque adjustment for coarseadjustment knobs, stage mounting position variable, high sensitivity fine focusing knob (minimum adjustmentgradations: 1 μm)IlluminatorBuilt-in Koehler illumination for transmitted light, light preset switch, light intensity manager switch, high colorreproductivity 14 W LED light source (Brightness: equivalent to or brighter than a 100W halogen lamp,LED light emission method: 405nm excited RGB fluorescence substance)Revolving Nosepiece Interchangeable reversed quintuple/sextuple/septuple/coded sextuple/coded septuple nosepieceObservation Tube Widefield (FN 22)• Widefield tilting trinocular• Widefield trinocular• Widefield tilting binocular• Widefield tilting, telescoping and lifting binocular• Widefield ergo binocular• Widefield binocularSuper Widefield (FN 26.5)• Super widefield trinocular• Super widefield erect image tilting trinocularStage C eramic-coated coaxial stage with left or right hand low drive control: with rotating mechanism and torque adjustment mechanism, optional rubber grips and stage handle extension adaptor available (non stick grooved coaxial, plain, rotatable stages are also available)Condenser • Abbe (NA 1.1), for 4X–100X• Swing out Achromatic (NA 0.9), for 1.25X–100X (swing-out: 1.25X–4X)• Achromatic Aplanatic (NA 1.4), for 10X–100X• Phase contrast, darkfield (NA 1.1), [phase contrast: for 10X–100X, darkfield: for 10X–100X (up to NA 0.80)]• Universal (NA 0.9), for 1.25X–100X [swing-out: 1.25X–4X, with oil top lens:(NA 1.4)]• Low (NA 0.75), for 2X–100X (Dry)• Darkfield dry (NA 0.8–0.92), for 10X–100X• Darkfield oil (NA 1.20–1.40), for 20X–100XFluorescence Illuminator • Multi-purpose coded type (FN 22, 8-position mirror unit turret, 4-position ND slider)• Economical type (FN 26.5, 8-position mirror unit turret)Fluorescence Light Source 100 W mercury apo lamp housing and power supply unit, 100 W mercury lamp housing and power supply unit, or 130 W mercury light guide illuminationBX53 SPECIFICATIONS Specifications 15Microscope Frame Optical System UIS2 optical systemFocusVertical stage movement: 25 mm stage stroke with coarse adjustment limit stopper, torque adjustment for coarseadjustment knobs, stage mounting position variable, high sensitivity fine focusing knob (minimum adjustmentgradations: 1 μm)IlluminatorBuilt-in Koehler illumination for transmitted light, light intensity manager switchhigh color reproductivity 2 W LED light sourceRevolving Nosepiece Interchangeable reversed quintuple/coded quintuple/sextuple/septuple/coded sextuple/coded septuple nosepieceObservation Tube Widefield (FN 22)• Widefield tilting, telescopic and lifting binocular• Widefield tilting trinocular• Widefield trinocular• Widefield erect image trinocular• Widefield tilting binocular• Widefield ergo binocular• Widefield binocularSuper Widefield (FN 26.5)• Super widefield trinocular• Super widefield erect image tilting trinocularStage C eramic-coated coaxial stage with left or right hand low drive control: with rotating mechanism and torque adjustment mechanism, optional rubber grips and stage handle extension adaptor available (non stick grooved coaxial, plain, rotatable stages are also available)Condenser • Abbe (NA 1.1), for 4X–100X• Swing out Achromatic (NA 0.9), for 1.25X–100X (swing-out: 1.25X–4X)• Achromatic Aplanatic (NA 1.4), for 10X–100X• Phase contrast, darkfield (NA 1.1), [phase contrast: for 10X–100X, darkfield: for 10X–100X (up to NA 0.80)]• Universal (NA 0.9), for 1.25X–100X [swing-out: 1.25X–4X, with oil top lens:(NA 1.4)]• Low (NA 0.75), for 2X–100X (Dry)• Darkfield dry (NA 0.8–0.92), for 10X–100X• Darkfield oil (NA 1.20–1.40), for 20X–100XBX43 SPECIFICATIONSMicroscope Frame Optical System UIS2 optical systemFocusF ixed low stage nosepiece focus15 mm focus stroke with coarse adjustment limit stopTorque adjustment for coarse adjustment knobsHigh sensitivity fine focusing knob (adjustment gradations: 1 μm) IlluminatorBuilt-in Koehler illumination for transmitted light, light intensity manager switchHigh color reproductivity 2 W LED light sourceRevolving Nosepiece Fixed reversed coded quintuple nosepieceObservation Tube Widefield (FN 22)• Widefield tilting trinocular• Widefield trinocular• Widefield tilting binocular• Widefield tilting, telescopic, lifting binocular • Widefield ergo binocular• Widefield binocularStage C eramic-coated coaxial stage with left or right hand low drive control, rotating mechanism and torque adjustment mechanism (low torqe, plain, rotating stages are also available)Condenser B uilt-in condenser (NA 0.9) 1.25X–100X (swing out: 1.25X–2X) BX46 SPECIFICATIONSOperating Environment • Indoor use• Ambient temperature : 5˚ to 40˚C (41˚ to 104˚ F)• Maximum relative humidity : 80% for temperatures up to 31˚C (88˚F), decreasing linearly through 70% at 34˚C(93˚F), 60% at 37˚C (99˚F), to 50% relative humidity at 40˚C (104˚F)• Supply voltage fluctuations : not to exceed ±10 % of the normal voltageBX53/BX43/BX46 SPECIFICATIONS16BX63 FL DIMENSIONS(unit: mm)TOUCH PANEL CONTROLLER DIMENSIONS(unit: mm)BX3-CBH DIMENSIONS(unit: mm)BX53 DIMENSIONS(unit: mm)BX53 FL DIMENSIONS (unit: mm)BX43 DIMENSIONS (unit: mm)209.7*220BX46 DIMENSIONS (unit: mm)Dimensions17BX53+BX3-MDO18/MDO26 DIMENSIONS(unit: mm)BX53+U-MDO10 DIMENSIONS(unit: mm)BX53+U-DO DIMENSIONS (unit: mm)18Printed in Japan N8601578-102020Shinjuku Monolith, 2-3-1 Nishi-Shinjuku, Shinjuku-ku, Tokyo 163-0914, Japan•is ISO14001 certified.•is ISO9001 certified.•is ISO13485 certified.• Illumination devices for microscope have suggested lifetimes.Periodic inspections are required. Please visit our website for details.• All company and product names are registered trademarks and/or trademarks of their respective owners.• Images on the PC monitors are simulated.• Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer.。

- . -使用说明书BX51/BX52系统显微镜- . -本手册使用于BX51/BX52系统金相显微镜。

为了确保平安、获得最优性能并使您完全熟悉这种显微镜的使用，我们建议您在操作显微镜前全面、仔细地看完这本手册。

为了供您进一步参考，应该把本手册放在靠近工作台并容易拿到的位置。

A X 9 8 5 5- . -BX51/52 为了让显微镜发挥最正确性能，正确安装和调节及其重要。

如果您将自行安装显微镜，请仔细阅读第7节，“安装〞〔第27页到29页〕。

重要要平安使用显微镜，必须阅读本节1 各局部名称1-34-52 反射光明场观察步骤6-73 使用调解装置8-203-1 镜座..........................................................................................................................................................................................................................8-10电压指示光强预置按钮使用使用滤光片3-2 聚焦装置 (11)卸下微调焦旋钮调整粗调焦旋钮力环粗调焦旋钮限位杆3-3 载物台......................................................................................................................................................................................................... 12-14放置样品调整X轴Y轴旋钮旋物台调整载台高度3-4 观察镜筒.................................................................................................................................................................... 15-17调整瞳距调整屈光度使用眼罩使用目镜测微尺选择三眼目镜筒的光路调整倾角3-5 聚光镜....................................................................................................................................................................18－19聚光镜定中心物镜与聚光镜的相容3-6 油浸物镜 (20)使用油浸物镜3-7物镜工作修正 (20)4 故障检修指导5 规格6 光学特性7安装更换灯泡请阅读本节- . -- . -BX51/BX52本显微镜使用 UIS 〔万能无限远〕光学系统，只能与适用于BX2系列的UIS 目镜、物镜和聚光镜一起使用。

奥林巴斯相机说明书篇一：Olympus 荧光显微镜操作手册奥林巴斯（Olympus）荧光显微镜操作手册Olympus BX51物镜： 4 ×0.16（无DIC）10×0.4020×0.7540×1.00 oil100×1.40oil荧光滤色块转盘： 1. WU蓝2. WIB 绿（长通）3. WIBA 绿（带通）4. WIG 红5. CFP 青6. YFP 黄操作步骤：（注意：样品须在低倍镜下放置和取下）DIC观察：1. 打开明场电源开关（“︱”为开，“○”为关）2. 将样品置于载物台上，用样品夹夹好3. 将起偏器、检偏器、DIC棱镜推入光路，荧光滤块转盘拨到“1”位置，DIC棱镜应与相应的物镜倍数相匹配4. 先选用低倍物镜（“10×”）5. 调节透射光的强度，调节焦距，找到视野6. 换到高倍镜头，观察样品7. DIC观察时，光路选择拉杆拉到中间位置，既可观察，也可拍照荧光观察：1. 打开明场电源开关2. 打开汞灯电源开关3. 将样品置于载物台上，用样品夹夹好4. 检偏器、DIC棱镜在光路外5. 将荧光光路shutter打开（“○”为开，“●”为关），需保护样品时关闭shutter6. 光路选择拉杆推至最里边7. 根据样品的标记情况将荧光滤块转盘转到相应的位置8. 通过两组减光滤片调节激发光强度9. 从低倍镜开始观察，调焦，找到预观察视野，10. 依次换到高倍镜头，观察样品11. 拍照时光路选择拉杆完全拉出普通明场观察：1. 打开明场电源开关（“︱”为开，“○”为关）2. 将样品置于载物台上，用样品夹夹好3. 起偏器、检偏器、DIC棱镜在光路外，荧光滤块转盘拨到“1”位置，DIC棱镜拨到明场（BF）位置4. 先选用低倍物镜（“4×”）5. 调节透射光的强度，调节焦距，找到视野6. 依次换到高倍镜头，观察样品7. 光路选择拉杆拉到中间位置既可观察，也可拍照关机：1. 关闭汞灯电源（注意：汞灯需使用半小时以上方可关闭，关闭半小时以后方可再次开启）2. 将透射光调到最小，关闭明场电源开关3. 将镜头转到低倍镜，取出样品，若使用过油镜用干净的擦镜纸擦拭镜头4. 确认数据已经保存，关闭软件5. 使用光盘拷贝数据（禁止使用移动储存设备拷贝数据）6. 关闭电脑，登记使用时间、荧光数字等使用情况Olympus IX71物镜：物镜倍数相差环4 ×0.13 PHL10×0.30 PH120×0.45 PH140×0.60 PH260×1.35 oil （无相差）荧光滤色块转盘： 1. WU蓝2. WIB 绿（长通）3. WIBA 绿（带通）4. WIGA 红5. CFP6. YFP操作步骤：相差观察：1. 打开明场电源开关（“︱”为开，“○”为关）2. 将样品置于载物台上3. 将光路选择旋钮调至观察位置4. 从低倍镜开始观察，调节到与镜头相匹配的相差环，荧光滤块转盘拨到“1”的位置5. 调节透射光光强，调节焦距，找到预观察视野6. 依次换到高倍镜，（注意调节相差环）观察样品7. 拍照时将光路选择旋钮调至相机位置荧光观察：1. 打开明场电源开关2. 打开汞灯开关3. 将样品置于载物台上4. 将荧光光路shutter打开（“○”为开，“●”为关），需保护样品时关闭shutter5. 将光路选择旋钮调至观察位置6. 根据样品的标记情况将荧光滤块转盘转到相应的位置7. 通过两组减光滤片调节激发光强度8. 从低倍镜开始观察，调焦，找到预观察视野，9. 依次换到高倍镜头，观察样品10. 拍照时将光路选择旋钮调至相机位置普通明场观察：1. 打开明场电源开关（“︱”为开，“○”为关）2. 将样品置于载物台上3. 将光路选择旋钮调至观察位置4. 从低倍镜开始观察，相差环拨到明场（BF）位置，荧光滤色块转盘拨到“1”的位置5. 调节透射光光强，调焦，找到预观察视野6. 依次换到高倍镜，观察样品7. 拍照时将光路选择旋钮调至相机位置关机：1. 关闭汞灯电源（注意：汞灯需使用半小时以上方可关闭，关闭半小时以后方可再次开启）2. 将透射光强调到最小，透射光选择按钮按出3. 关闭明场电源开关4. 将镜头转到低倍镜，取出样品，若使用过油镜用干净的擦镜纸擦拭镜头5. 确认数据已经保存，关闭软件6. 使用光盘拷贝数据（禁止使用移动储存设备拷贝数据）7. 关闭电脑，登记使用时间、荧光数字等使用情况Olympus SZX16物镜：1×变倍：0.7~11.5荧光滤色块转盘：UV 蓝GFPHQ绿RFP2 红操作步骤：明场观察：将样品置于载物台上推入光路选择拉杆，荧光滤块转盘拨到空位选择合适的光源冷光源观察使用不透明的底板（黑或白），打开环形光电源开关（“︱”为开，“○”为关），调节光强度，找到预观察视野，调节变倍比，观察样品⑵底光源观察使用透明玻璃底板，打开底座电源开关（“︱”为开，“○”为关），将LBD滤片推入光路，调节反光镜方向、对比度和光强度，找到预观察视野，调节变倍比，观察样品4. 拍照时将光路选择拉杆拉出荧光观察：1. 将样品置于载物台上2. 一般选择黑色不透明底板3. 打开汞灯电源开关4. 荧光光路挡板推出 1. 2. 3. ⑴篇二：OLYMPUS在各国外使用总结经验及说明奥林巴斯 XZ-1 tipsXZ-1from Jonathon Donahue====================Here's a grab bag of XZ-1 information... from my posts, and others, on Dpreview... and from other places. 这里是一个大杂烩的XZ-1信息... 从我的帖子，和其他人，DPREVIEW ... 和其他地方。

BXiS 金相显微镜系统：数码成像无缝集成正立金相显微镜BXiS今日，各种各样的检查应用，都要求光学检查系统能够以多种方式完成高效的图像处理工作。

无论您是需要使用白光成像进行基本的测量，还是需要使用具有色彩高保真度的偏振光进行严格的材料鉴定，奥林巴斯都能以其灵活的方案满足您的需求。

BXiS ——您的个性风格。

在奥林巴斯产品方案中，高级显微镜产品可搭载特定的数码显微照相装置，保证了图像的高分辨率和精确的色彩还原。

奥林巴斯全面解决方案还包括高级图像软件。

该软件融合了各种操作功能，包括基本的图像拍摄、图像处理、报表生成、数据导出以及数据、图像和报表的全球网络连接共享。

BXiS ——您的个性系统。

奥林巴斯允许用户自由创建工作方案以满足不同环境的工作流程和其它需要。

用户在专心工作的同时，奥林巴斯还给用户提供了各种便捷、省时的工具，让日常的例行工作也变得轻松容易。

BXiS ——您的个性方案。

BXiS 系统——不论是现在还是未来，都能满足您个性风格的任何操作应用拥有 BX iS , iS 代表您的个性风格（i ndividual S tyle ）。

3多用途系统，满足您的个性风格奥林巴斯致力于创建可支持各种级别工作的显微镜系统方案5让工作流程精简高效OLYMPUS Stream 软件，满足您的每个需求BXiS 简化图像的拍摄流程BXiS 操作，不易疲劳9创建个人专属的奥林巴斯系统BXiS 按您的样本和方案设计完美的系统BXiS 拥有各种物镜各种奥林巴斯数码照相装置BXiS 拍摄您需要的图像从简单测量到复杂的图像分析16轻松扩展至未来的应用程序BXiS 的扩展功能可适应未来的需要奥林巴斯系统支持升级功能17系统图、规格BX51 / BX51M / BXFM 系统图BX61 系统图BX41M-LED 系统图BX51 IR 系统图规格外形尺寸让工作流程精简高效时间和工作环境同样重要，这正是BXiS的图像和控制软件可以个性化设置工作流程的原因。

电子胃肠镜系统招标参数（品牌奥林巴斯、宾得、富士）电子胃肠镜系统招标参数（品牌：奥林巴斯、宾得、富士）（一）电子胃肠镜主机参数1、整体要求：#1.1、制造商在安徽省设有分公司（提供营业执照复印件证明）,保证售后服务质量#1.2、投标人所投型号的产品在安徽省内用户不少于15家(提供用户名单及联系方式核实)*1.3、投标人必须投标各品牌最高端产品（例如：奥林巴斯CV-290内镜系统，宾得OE内镜系统，富士蓝激光内镜系统）。

2、系统配置要求：2.1、进口全数字化高清图像处理中心1套2.2 、进口氙气内窥镜冷光源 1套2.3 、胃肠镜台车 1台2.4、专业医用液晶监视器 1台2.5、电脑图文打印工作站1套2.6、原装水泵1台3、全数字化高清图像处理中心技术参数：3.1、具有高清HDTV信号输出：逐行扫描，图像分辨率1080P#3.2、具备窄波成像功能3.3、IHB血红色素浓度强调功能：基于内镜图像的IHB值来强调色彩的细微差异。

三种色彩强调模式可以选择。

用户预设功能可以设定一键强调按钮，可以用来控制是构造强调还是适应型IHB色彩强调。

3.4、具有IHB色图功能：计算内镜图像中每个像素的IHB值，并以模拟颜色显示，也可以显示图像的平均IHB值3.5 、具有彩虹现象修正功能：减小由于RGB信号之间的时间滞后而造成的色差，确保稳定、无闪烁的图像。

#3.6、兼容UPD大肠镜，便于初学肠镜医生操作肠镜3.7、标准色图输出：可以显示IHB色图或50%白色图。

3.8 、具有色调调节：“R”调节：≥±7档“B”调节：≥±7档3.9、具备电子放大功能#3.10、具备AFI功能，通过自体荧光将普通黏膜显示为绿色，异常病灶显示为紫红色3.11、一键测光模式选择功能：通过前面板上的按键可以选择三种测光模式。

1、平均测光：用于正常观察2、峰值测光：聚焦在小面积明亮区域时使用3、全自动测光：聚焦在图像中央观察时使用3.12、构造强调设定功能：电子强调内镜图像中的图案和轮廓。

高清电子腹腔镜技术参数最新产品高配190一、基本要求：1、要求产品为国际知名内窥镜品牌,所提供设备为全球同步技术;2、整机免费保修期：≥1年；负责终身维修;制造商在国内设有专业内窥镜维修站;在昆明设有厂家直属的办事处及售后服务机构;报修后,即时响应,48小时内到达现场;3、提供中文操作手册或技术资料;4、提供详细的软硬件配置清单;二、技术参数：高清电子腹腔镜1套,具体配置应包括以下设备：1、电子腹腔镜高清摄像主机1台,要求如下：①、具有优秀的兼容性：可兼容电子胸、腹腔镜、普通光学视管、软性纤维镜等,同时可兼容单晶片和三晶片摄像头②、输出图像达到1080线高清标准③、具有USB静态数码图像储存功能,并可通过电子镜或摄像头的遥控按钮控制拍照功能,获取术中图像；同时具有1394接口,HD-SDI接口、DVI接口等,可同时输出高清、标清数字和模拟视频信号;④、主机具备窄波成像功能,即通过特殊波段的光照射观察黏膜表面的异常变化;⑤、主机采用LVDS技术,可高速传输大量数据实现图像高清,并便于复制、保存管理;⑥、具备自动白平衡,轮廓强调,2种结构强调⑦、主机支持加热防雾功能,可感控镜体前端温度,达到消除雾气、保持清晰度的效果;2、电子腹腔镜高辉度氙灯冷光源1台,要求如下：①．300W,氙灯短弧、无臭氧冷光源②．广泛的兼容性,适用于任何内镜的使用③．具备高亮度模式和光透腹模式;④．亮度可自动、手动17级调节,与摄像主机通过调光电缆相连;⑤．具备备用灯,主副灯切换方便,面板上有主灯寿命计时器;3、高清电子腹腔镜1条,要求如下：①、直径10mm,视野方向：30°,视野角度不少于90度,输出图像为高清图像②、CCD前置,即CCD位于腹腔镜镜体前端,具有图像色彩还原好,视野清晰等特点;并且整个电子腹腔镜为一体化设计,即导光束、摄像头、适配器等与镜身完全一体,使用前无需任何组装;③、整条镜子可高温高压灭菌,并配备有原装进口消毒盒;并可采取全浸泡、环氧乙烷熏蒸、低温等离子等方式消毒;④、免调焦设计,景深21~200mm,镜子前端不起雾,始终能保持清晰的视野;⑤、镜体上有3个遥控按钮,可自由设定主机提供的不少于20种遥控功能;⑥、镜子支持窄带特殊光观察,即NBI窄带成像技术4、高流量自动气腹机1台,要求如下：①、大流量,最大流量不低于45升/分②、可设定小腔体模式,最小流速可控制在0.1升/分;精确实施小腔体手术或婴幼儿腔镜手术的气体控制③、和同品牌能量平台配置时,支持自动排烟;④、配置气腹针2根,旋塞2个,旋阀2个5、高频电工作平台1套,要求如下：①、涵盖单极、双极的所有应用模式,包括生理盐水下等离子电切,PK刀双极凝血、切割等,等离子电切功率最高320W；单极电切功率最高300W;;②、具有生理盐水、器械自动检测识别功能;③、主机面板采用触摸屏控制,方便,快捷④、配备单极电缆线2根,;双极电缆线1根,均可高温高压灭菌6、医用液晶监视器1台,要求如下：①、医疗用液晶监视器,不小于24英寸,分辨率在1920×1080或以上②、表层镀膜,多种信号输入接口;7、手术器械1批,每套应包括：①、5mm器械用TROCAR1套,含套管2个,套管针2根,不锈钢材质,可高温高压灭菌;②、10mm器械用TROCAR1套,含套管2个,套管针2根,不锈钢材质,可高温高压灭菌;③、12mm器械用TROCAR1套,含套管1个,套管针1根,不锈钢材质,可高温高压灭菌;④、5mm冲洗吸引管1套;外径缩小管2个,5mm电钩1把,,5mm左弯抓钳1把,5mm左弯剪1把,5mm左弯分离钳1把;5mm无创抓钳1把;⑤、10mm波浪形无创抓钳1把,10mm分离钳1把,10mm左弯分离钳1把,10mm钛夹钳1把,钛夹1盒;8、．国产台车1部,要求如下：1上下左右可旋式支架,固定液晶显示器,方便操作者不同角度观察图像;2可调节底板,随时调整主机放置高度,以便配合周边设备同时配置;3钢塑结构,坚固耐用;三、配置配套设施、设备要求：高清电子腹腔镜1套,具体配置应包括：高清摄像主机1台,高辉度氙灯冷光源1台,高清电子腹腔镜1条,气腹机1台,高频电工作平台1台,高清医用液晶监视器1台,手术器械1批,台车1部;四、售后服务要求：1、整机免费保修期：≥1年；负责终身维修;制造商在国内设有专业内窥镜维修站;在昆明设有厂家直属的办事处及售后服务机构;报修后,2小时内响应,24小时内到达现场;维修周期超过10天需提供维修备品;2．全免费的培训无次数限制;培训内容包括设备的维护基本知识、清洗、消毒、保养的基本知识,使用过程需注意的事项等五、安装、放置地点是否具备：科室已具备安装、放置地点和条件后附配置清单。

86.041C A RD I O I D M I R R O R CO N DE N S E RF O R DA R K F I E L D • T he 86.091-DFLED model is supplied with an oil immersion condenser with cardioid mirrors, a 5 W integrated NeoLED™ illumination and a S100x objective with built-in iris diaphragm for real 1000x darkfield applicationsI L L U M I N ATI O N• T he microscopes of the B and B+ series are equipped with either a 1W LED adjustable illumination system for increased light output with3 rechargeable batteries for cordless operation or a 20 W 6 V halogen adjustable illumination• All models have an integrated power supply for cordless operation.• 110 and 230 V mains versions available for halogen models I L L U M I N AT I O N F O R DA R K F I E L D• 5 W NeoLED™ adjustable illumination for model 86.091-DFLED.• B y using AE.3612 and 86.521 an existing brightfield microscope can be upgraded to darkfieldPAC K AG I N G• S upplied with power cord, dust cover, a spare fuse, user manual and 5 ml immersion oil for models with S100x objective.• M odels with a 20W halogen illumination are supplied with a spare bulb and a blue filter, models with 1 W LED illumination are supplied with white filter• All packed in a polystyrene box86.01086.02586.325M O D E L S W I T H P L A N I O S I N F I N I T Y CO R R E C T E D O B J E C T I V E SBinocularTrinocularWF 10x 18 mmWF 10x 20 mm4 objectives nosepiece5 objectives nosepieceSemi plan IOS 4x/10x/S40x/S100x oil objectivesPlan IOS 4x/10x/S40x/S100x oil objectives20 W halogen86.125•••••86.141•••••86.125-LED ••••86.141-LED ••••86.129-LED ••••86.149-LED••••M O D E L S W I T H S E M I P L A N O B J E C T I V E SMonocularBinocularTrinocularWF 10 x 18 mmWF 10 x 20 mm4 objectives nosepiece5 objectives nosepieceSemi plan4x/10x/S40x/S100x oil objectives20 W halogen86.010•••••86.025•••••86.041•••••86.010-LED ••••86.025-LED ••••86.041-LED ••••86.019-LED ••••86.029-LED ••••86.049-LED••••M O D E L S W I T H P L A N O B J E C T I V E SMonocularBinocularTrinocularWF 10x 18 mmWF 10x 20 mm4 objectives nosepiece5 objectives nosepiecePlan 4x/10x/S40x/S100x oil objectives20 W halogen86.060•••••86.075•••••86.091•••••86.060-LED ••••86.075-LED ••••86.091-LED ••••86.069-LED ••••86.079-LED ••••86.099-LED••••M O D E L S W I T H S E M I P L A N P H A S E CO N T R A S T O B J E C T I V E SMonocularBinocularTrinocularWF 10 x 18 mmWF 10 x 20 mm4 objectives nosepiece5 objectives nosepieceSemi plan phase 10x/20x/S40x/S100xoil objectives20 W halogen86.310•••••86.325•••••86.341•••••86.310-LED ••••86.325-LED ••••86.341-LED ••••86.319-LED ••••86.329-LED ••••86.349-LED••••M O D E L S W I T H P L A N P H A S E CO N T R A S T O B J E C T I V E SMonocular Binocular Trinocular WF10 x 18 mmWF10 x 20 mm4 objectivesnosepiece5 objectivesnosepiecePlan phase10x/20x/S40x/S100xoil objectives20 Whalogen86.360•••••86.375•••••86.391•••••86.360-LED••••86.375-LED••••86.391-LED••••86.369-LED••••86.379-LED••••86.399-LED••••M O D E L S W I T H S E M I P L A N O B J E C T I V E S A N D P L A N P H A S E S40X O B J E C T I V EMonocular Binocular Trinocular WF10 x 18 mm 4 objectivesnosepieceSemi plan4x/10x/S100xoil objectivesPhaseS40x20 Whalogen86.410••••••86.425••••••86.441••••••86.410-LED•••••86.425-LED•••••86.441-LED•••••86.572-P Wide field eyepiece HWF 10x/18 mm with pointer86.572 Wide field eyepiece HWF 10x/18 mm86.575 Wide field eyepiece HWF 10x/20 mm86.573 Wide field eyepiece WF 15x/12 mm80.882 Wide field eyepiece WF 20x/10 mm86.574 M icrometer eyepiece HWF 10x/18 mm, 10 mm/100,with adjustable eye lensAE.1110 Stage micrometer 1 mm, 100 partsAE.1111 Stage micrometer 2mm, 200 parts80.839 Eye cup with inner diameter 28 mm86.812 D iscussion head with one vertical and one oblique tube.Without eyepieces86.891 Semi plan SMP 4x/0.10 objective. WD 23.13 mm86.893 Semi plan SMP 10x/0.25 objective. WD 4.09 mm86.894 Semi plan SMP 20x/0.40 objective. WD 1.97 mm86.897 Semi plan SMP S40x/0.65 objective. WD 0.6 mmAE.5699 Achromatic S60x/0.85 objective. WD 0.20 mm86.900 S emi plan SMP S100x/1.25 oil immersion objective. WD 0.38 mm86.511 Plan PL 4x/0.10 objective. WD 17.9 mm86.513 Plan PL 10x/0.25 objective. WD 8.8 mm86.514 Plan PL 20x/0.40 objective. WD 8.6 mm86.517 Plan PL S40x/0.65 objective. WD 0.56 mm 86.519 Plan PL S60x/0.85 objective. WD 0.25 mm86.520 P lan PL S100x/1.25 oil immersion objective. WD 0.33 mm86.521 P lan PL S100x/1.25 oil immersion objective with iris diaphragm.WD 0.33 mm86.413 S emi plan phase PH 10x/0.25 objective. WD 6.61 mm86.414 Semi plan phase PH 20x/0.40 objective. WD 1.85 mm86.417 Semi plan phase PH S40x/0.65 objective. WD 0.64 mm86.420 S emi plan phase PH S100x/1.25 oil immersion objective. WD 0.19 mm86.313 Plan phase PLPH 10x/0.25 objective. WD 8.8 mm86.314 Plan phase PLPH 20x/0.40 objective. WD 8.6 mm86.317 Plan phase PLPH S40x/0.65 objective. WD 0.65 mm86.320 P lan phase PLPH S100x/1.25 oil immersion objective. WD 0.33 mm WD = Working distanceACC E S S O RI E S A ND S PA RE PA R TSEuromexMicroscopenbv•Papenkamp20•6836BDArnhem•TheNetherlands•T+31(0)263232211•F+31(0)263232833•****************•86.560 Plan PL 4x /0.12 infinity corrected IOS objective. WD 19.75 mm 86.562 P lan PL 10x/0.25 infinity corrected IOS objective. WD 5 mm 86.564 Plan PL 20x/0.40 infinity corrected IOS objective. WD 8.8 mm 86.566 Plan PL S40x/0.65 infinity corrected IOS objective. WD 0.66 mm 86.567 Plan PL S60x/0.80 infinity corrected IOS objective. WD 0.26 mm 86.568 P lan PL S100x/1.25 oil immersion infinity corrected IOS objective.WD 0.36 mm86.172D arkfield stop to be placed in filter holder. Suitable for objectives from 10x up to S40x86.627 D arkfield N.A. 1.40 oil immersion condenser with cardioidmirrors. To be used with a LE.5241 flexible light conductor and a cold light source LE.5210, LE.5211 or LE.5211-LED86.613S imple 40x phase contrast set consisting of a N.A. 1.25 condenser with a plan phase PLPH S40x N.A. 0.65 objective and associated phase plate. Delivered with centering telescope and green filter86.615Z ernike medium dark phase contrast set. The set consists of a disc phase N.A.1.25 condenser with rotating wheel of phase annuli and an aperture for brightfield illumination. Complete with semi plan phase DIN PH 10x/0.25, PH 20x/0.40, PHS40x/0.65 and PH S100x/1.25 oil immersion objectives. Delivered with centering telescope and green filter86.617Z ernike medium dark phase contrast set. The set consists of a disc phase N.A.1.25 condenser with rotating wheel of phase annuli and an aperture for brightfield illumination. Complete with plan phase DIN PLPH 10x/0.25, PH 20x/0.40, PH S40x/0.65 and PH S100x/1.25 oil immersion objectives. Delivered with centering telescope and green filter86.806 M irror with adapter for B and B+ series with halogen illuminationonlyAE.5168-B H eating stage with PID controller up to 50°C. Only supplied witha new microscopeAE.5130 U niversal SLR camera adapter with 2x projection lens for23.2 mm tubes. Need T2 adapterAE.5025 T2 adapter for Nikon D digital SLR cameras AE.5040 T2 adapter for Canon EOS digital SLR cameras Other T2 adapters on request86.820 SLR camera adapter with 2.5x and 4x magnification lenses DC.1320 1x objective with C-mount for cameras with 1” sensor. Suitablefor 23.2 mm tubesDC.1324 0.5x objective with C-mount for cameras with 1/2” sensor.Suitable for 23.2 mm tubesDC.1326 0.33x objective with C-mount for cameras with 1/3” sensor.Suitable for 23.2 mm tubesDC.1328 0.67x objective with C-mount for cameras with 2/3” sensor.Suitable for 23.2 mm tubes86.851 P olarizing attachment for B or B+ series with a halogenillumination86.852 P olarizing attachment for B or B+ series with a LED illumination 86.860 A ttachable Köhler diaphragm to be mounted on lamp house. Onlysuitable for models with halogen illumination86.961 Plastic case for polystyrene packaging of B series 86.970 Aluminum flight case 86.971Aluminum caseAE.5202 Blue filter, 32 mm diameter AE.5203 Yellow filter, 32 mm diameter AE.5204 Neutral gray filter, 32 mm diameter AE.5205 Green filter, 32 mm diameter AE.5207 Blue filter acrylic, 31.8 mm diameter AE.5227 Glass fuses 250 V 1 A, 10 pieces 86.889 Spare halogen bulb 6 V 20 W 86.101Spare LED module for B seriesAE.5227 Glass fuses 1 A 250 V, 10 piecesPB.5155 Microscope slides 76 x 26 mm, ground edges, 50 pieces PB.5165 Cover glasses 18 x 18 mm, thickness 0.13-0.17 mm, 100 pieces PB.5168 Cover glasses 22 x 22 mm, thickness 0.13-0.17 mm, 100 pieces PB.5245 Lens cleaning paper, 100 sheets per pack PB.5255 Immersion oil, n = 1.482 (25 ml) PB.5274 Isopropyl alcohol 99% (200 ml)PB.5275 C leaning kit: lens cleaning fluid, lint free lens tissue, brush, airblower, cotton swabsWD = Working distance。

植物学实验室仪器设备LG10-2.4A台式高速离心机产品特点：微电脑控制，数显/液显；无刷电机，噪音低；电动门锁；广泛应用于医疗卫生、科研教学、实验室及其它领域的混合液分离等。

数字显示/液晶显示，无刷电机最高转速:10000rpm最大相对离心力:11000*g定时范围:0-99min电源:AC220V 50HZ 10A外形尺寸:510*430*300mm重量:27kg标准配置（转子）:6*40mlSc2546低速离心机台式结构，采用直流无刷、无级调速电机驱动，微电脑控制转速和离心时间，键盘设定工作参数，数码显示离心时间、转速和离心力。

该机转子采用Nylon复合材料热压成型，转子可与多种常规试管相匹配。

特性：— 直流无刷无级调速电机驱动，运行宁静清洁— 设有离心力专用键，可设定离心力，也可在运行中随时观察离心力— 开门自动停机，确保操作安全最高转速 4000rpm最大相对离心力 2432×g角转子容量 15ml/20ml×12T6可见分光光度计技术参数：1、光学系统： 双光束比例监测2、波长范围： 190～1100nm（T6新世纪）；325～1100nm（T6新悦）3、.波长准确度：±1nm（T6新世纪）；±2nm（T6新悦）4、波长重复性：≤0.2nm（T6新世纪）；≤0.4nm（T6新悦）5、光谱带宽： 2nm6、杂散光： ≤0.05%T（T6新世纪）；≤0.1%T（T6新悦）7、光度准确度：±0.002A(0-0.5A)；±0.004A(0.5-1A)；±0.3%T(0-100%T)8、光度重复性：≤0.001A(0-0.5A)；≤0.002A(0.5-1A)；≤0.15%T(0-100%T)9、光度噪声：±0.001Abs/h(500nm,P-P），开机预热半小时后10、基线平直度：±0.002A(200-1000nm)（T6新世纪）；±0.002A(325-1000nm)（T6新悦）11、基线漂移：≤0.001Abs/h(500nm,0Abs ，预热2小时后）（T6新世纪）；≤0.002Abs/h(500nm,0Abs ，预热2小时后）（T6新悦）。
